INSTALLATION MANUAL©
ST-PTZIR480-30X
High-Speed Intelligent Dome
IR PTZ Color Camera
Copyright North American Cable Equipment, Inc.

PACKAGE CONTENTS
This package contains:
One ST-PTZIR480-30X high-speed intelligent dome color camera.
One mounting bracket.
One 24VAC 3A power supply.
One installation manual.
PRODUCT DESCRIPTION
The ST-PTZIR480-30X is a professional grade infrared intelligent dome color camera with pan, tilt and zoom (PTZ)
capability and 480TVL resolution. The camera’s non-volatile digital memory allows the saving of all settings. Its
200 preset positions provide versatility for cruise routes and tour functions. The ST-PTZIR480-30X’s mechanical
design permits continuous horizontal 360rotation and 90vertical flip. Temperature management is built-in.
Functions and Features
Non-volatile design ensures data will not be lost if power fails.
Recovery function allows the camera to continue previous functions after power is restored.
Support for 200 presets and 4 preset tours, each containing up to 32 presets.
4 patterns, each can be recorded for 1000 discrete PTZ controller moves.
Support for 4-auto scans.
Soft and hard ID settings can be edited on the DIP switch or via the OSD menu.
Integrated multi-protocol control: PELCO“P”, PELCO“D”.
2 ch alarm input; 2 ch alarm relay output.
Proportional zoom lens; P/T speed will decrease in proportion with depth of zoom.
Can be installed indoors or outdoors.
Horizontal pan speed 0.5º-82º/s.
Vertical tilt speed 0.5º-30º/s.
360º continuously horizontal rotation.
Complies with IP 66/CE standard.
Built-in surge protection circuitry.
Auto focus.
Auto iris.
Auto shift from Color to B/W.
Built-in OSD makes it easy to configure all settings of the camera.
Built-in display for the internal dome temperature, preset status and compass direction.
330ft IR distance for long-range surveillance.

SPECIFICATIONS
ST-PTZIR480-30X
Specifications (Typical)
1. Image Sensor
Samsung SDM-270 with ¼” SONY CCD
2. Resolution
480TVL
3. Lens
Auto Iris; F=3.5 to 105mm; 30X Optical Zoom, 10X Digital Zoom
4. Illumination
0.1 Lux
5. Pan Range
360º continuous
6. Tilt Rotation Range
0º - 90º flip
7. Manual Speed Pan
0.1º - 82º/sec
8. Manual Speed Tilt
0.1º - 30º/sec
9. Preset Speed
82º/sec
10. Preset Accuracy
±0.10°
11. Preset Positions
200
12. Function Display
Yes
14. Pan & Tilt Position Display
Yes
15. MAX IR Distance
330ft
19. Patterns
4 programmable (pan/tilt/zoom and each tour is 120 seconds)
20. Sequences (Tours)
4 programmable (dwell time speed preset point)
21. Protocol
Pelco-D, Pelco-P selectable
22. Auto Scan
With programmable variable speed
23. High Efficient 3-Dimension Scan
Yes
24. Long-Focus Speed Limited
Yes
26. Home Position
Yes
27. Camera Menu Operation
Yes
28. IP66 for Outdoor Use
Yes
29. Operating Humidity
95%
30. Heater Operation
42ºF on; 57ºF off
31. Operating Temperature
-40ºF - 122ºF
32. Video Connection
BNC coaxial
33. Power
24VAC @3A, 35W
34. Communication
RS485

Dimensions
Wall Mount Dimension
Picture 2
6 ½”
7 ¾”
5 ¼”
5 ½”
6”
10 1/8”
4 1/8”
6”
4 1/8”
6 1/8”
3 ¾”
5 ½”

INSTALLATION AND OPERATION
CAUTION: To reduce the risk of electrical shock do not remove the cover or back of this unit. No user
serviceable parts are inside.
CAUTION: To prevent electric shocks and risk of fire hazards, do not use other than specified power
source.
1. UNPACKING and HANDLING
Each unit is shipped partially assembled factory tested.
Ensure that all accessories are removed from the container before discarding packing materials.
a. Use the mounting arm as a template to mark the holes for your mounting hardware.
This symbol is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions.
This symbol is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electrical shock.

b. Feed the cable assembly up through the smaller end of the mount and out the rear opening.
c. Assemble the camera dome to the mounting arm using the 4 supplied allen-head cap screws and allen
wrench.
2. MECHANICAL INSPECTION
Inspect the entire camera for shipping damage. Make sure the equipment is clean, and no connectors are
broken, damaged, or loose. If equipment appears to be damaged or defective please contact your distributor
or SecurityTronix at 1-610-429-1511 for assistance.
3. SPECIAL ATTENTION
a. The installer must comply with electrical safety standards. There must be sufficient space between the
camera’s power supply and video line and any high voltage equipment and/or cables.
b. To help ensure the camera’s life and proper operation do not point the camera towards the sun or
strong light.
c. Do not install the camera in an environment where the temperature is above 122F.
d. Do not install the camera near a magnetic field or a high-power motor.
e. Do not mount the camera near a radiator or heater.
f. The installation site and material must fully support the weight of the product.
g. Only use a dry cloth to clean the camera. If there is dirt that is difficult to remove wipe gently with a mild
detergent. Never use strong or abrasive detergents.
h. The included 24VAC at 3A power supply must be used. Using a DC or other incorrect power supply
will damage the camera.
i. Only qualified installers are allowed to install, test and disassemble the camera.
j. The camera is a low voltage product. If installed outdoors proper safety and lightning grounding are
required.
k. Before installing be sure the grounding, wiring, input power, voltage, DIP switches, communication
protocol and baud rate are correctly set prior to powering up and using.

4. CAMERA SETUP
BAUD RATE & PROTOCOL SETUP
DIP Switch Settings
Baud rate Setting SW2（B7~B8）
Protocol Setting SW2（B1~B2）

DOME ADDRESS SETUP
System Setup DIP Switch SW1 ON = 1 OFF = 0

V2.0 7-31-12
9

V2.0 7-31-12
10
5. WIRING CONNECTIONS
6. FUNCTIONS and OPERATION
Menu Operation
Several functions can be accessed directly without using the camera’s on screen menu display.
Note the following dedicated preset functions:
Special Use Preset Numbers
Call PRESET 95 ―― Enter into main OSD menu
Call PRESET 96 ―― Run pattern 1
Call PRESET 97 ―― Run Sequence 1
Call PRESET 92 ―― Set Left limit point for L/R scan
Call PRESET 93 ―― Set Right limit point for L/R scan
Call PRESET 99 ―― Run Left-right scan
NOTE: If Left limit point and Right limit point are set to the same position, calling preset 99
will execute a 360° scan.
Call PRESET 33 ―― Swing 180°
Call PRESET 34 ―― Return to Zero point
The on screen menu provides access to all camera functions through the use of a standard RS485
connection and PTZ controller.
As shown above, use the PTZ controller to CALL PRESET 95 and the camera’s OSD menu will
appear overlaid upon the video output of the camera, as shown below.

V2.0 7-31-12
11
Menu Guide
SYSTEM SETTING
MAIN MENU
CAMERA PARAMETERS
`
`
PANTILT SETTING
DISPLAY CONFIGURATION
ALARMS SETUP
【SYSTEM SETTING】
【CAMERA PARAMETERS】
【PAN TILT SETTING】
【DISPLAY CONFIGURATION】
【ALARMS SETUP】
→DOME TITLE : OFF
PRESETS TITLE : OFF
ZOOM POSITION : OFF
DIRECTION INDICATOR : OFF
ENVIRONMNT INDICATORS: OFF
GLOBAL SETTING…
→【PAN TILT SETTING】
【PRESETS SETUP】
【SEQUENCE SETUP】
【PATTERN SETUP】
【AUTOSCAN SETUP】
【HOME ACTION】
→【LENS PARAMETER】
【EXPOSURE MODE】
【WHITE BALANCE】
【BACKLIGHT MODE】
→DOME ID
TITLE
LANGUAGE SELECT
CHANGE PASSWORD
FACTORY DEFAULT
SYSTEM RESTART
SYSTEM INFOMATION
→INPUT CHANNEL : 001
ALARM ACTION : DISARM
INPUT MODE : NO
ALARM LINKAGE : OFF
RELAY OUTPUT : OFF
RESET DELAY : 30

V2.0 7-31-12
12
【SYSTEM SETTING】
【CAMERA PARAMETERS】
【PAN TILT SETTING】
【DISPLAY CONFIGURATION】
【ALARMS SETUP】
【SYSTEM SETTING】
【CAMERA PARAMETERS】
【PAN TILT SETTING】
【DISPLAY CONFIGURATION】
【ALARMS SETUP】
Main Menu Function Setting
Main menu
System Setting
MAIN MENU SYSTEM SETTING
DOME ID
The camera supports both ‘hard’ addressing and ‘soft’ addressing.
Hard addressing is achieved by setting the address DIP switches to the desired address. When this
is done, soft addressing is disabled. When all address DIP switches are set to OFF, the
soft-addressing option becomes available in the OSD menu.
Procedure:
1. Set all ADDRESS DIP switches to zero (off).
2. Call preset 95 to enter the main menu.
3. Using the up & down PTZ controls, choose [SYSTEM SETTING] and press [OPEN] to confirm
and enter the system setting menu.
4. Under [SYSTEM SETTING] choose [DOME ID] and press [OPEN] to confirm.
5. Using the up/down and left/right PTZ controls, enter the 12 character serial number shown at
the top of the menu and press [OPEN] to move to the next menu.
6. Enter the new dome ID# and press [OPEN]. The menu will show the new dome ID and prompt
to press [OPEN] to accept.
7. Set your PTZ controller to the dome’s new address and press [OPEN] .
TITLE SETTING:
Procedure:
1. Call preset 95 to enter the main menu.
2. Using the up/down cursor, choose [SYSTEM SETTING]. Press [OPEN] to confirm the
selection.
3. Under [SYSTEM SETTING], choose [TITLE] and press [OPEN] to confirm the selection.
4. Use up/down to choose letters and numbers for the name, and L/R to navigate to the next
character of the name.
5. When the name is complete, press [OPEN] to save and exit the title menu. Press [CLOSE] to
exit without saving.
→DOME ID : 001
TITLE
LANGUAGE SELECT: ENGLISH
CHANGE PASSWORD
FACTORY DEFAULT
SYSTEM RESTART
SYSTEM INFORMATION

V2.0 7-31-12
13
Notes: 20 characters can be set. Characters include: 0-9、A-Z、:<>-. Other text-entry menus
follow this same procedure.
LANGUAGE SELECT
Procedure:
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [SYSTEM SETTING] and press [OPEN] to confirm
the selection.
3. Under [SYSTEM SETTING] choose [LANGUAGE SELECT] and Press [OPEN] to confirm
the selection. The language will be flashing.
4. Use up/down to choose a language.
5. Press [OPEN] to save and exit this menu item; Press the [CLOSE] key to exit immediately
without saving.
CHANGE PASSWORD
Procedure:
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [SYSTEM SETTING] and press [OPEN] to confirm
the selection and enter the system setting menu.
3. Under [SYSTEM SETTING] choose [CHANGE PASSWORD]and press [OPEN] to confirm
the selection.
4. Use the up/down controls to choose letters and numbers for the name, and L/R to navigate to
the next character of the name.
5. When the name is complete, press [OPEN] to confirm. This will save and exit the title menu.
Press [CLOSE] to exit without saving.
6. If there is already a password in place you will be prompted to enter it first. Input the old
password and press the [OPEN] key. “Input New Password” will be shown on the screen. Input
the new password, then re-enter it once more to confirm. “Password Modification Succeed” will
be shown on the screen.
7.
CAUTION: For security reasons, there is no way for users to bypass or reset the
password settings. If a password is entered incorrectly or forgotten it will be impossible to
access the camera’s OSD menu. In order to regain access in the event of a lost or forgotten
password, the camera must be re-initialized by the factory.
Note: The factory-set original password is“000000”. If you set the dome password as “000000”,
then no password will be required to access the camera.
FACTORY DEFAULT
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [SYSTEM SETTING] and press [OPEN] to confirm
the selection and enter the system setting menu.
3. Under [SYSTEM SETTING] choose [FACTORY DEFAULT] and press [OPEN] to reset the
camera to the factory default settings.
SYSTEM RESTART
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [SYSTEM SETTING] and press [OPEN] to enter the
system setting menu.
3. Under [SYSTEM SETTING] choose [SYSTEM RESTART] and press [OPEN] to begin the
reset. This process is the same as power-cycling the camera, so the camera will perform its
startup function check.
SYSTEM INFORMATON
Under [SYSTEM SETTING] choose [SYSTEM INFORMATION] and press [OPEN] to confirm the

V2.0 7-31-12
14
【SYSTEM SETTING】
【CAMERA PARAMETERS】
【PAN TILT SETTING】
【DISPLAY]
[CONFIGURATION】
【ALARMS SETUP】
selection. The dome’s present system information will be shown on the screen。
CAMERA PARAMETERS
MAIN MENU CAMERA PARAMETERS
LENS PARAMETER
Use this menu to set the camera's zoom speed, electronic zoom, and focus and preset points limit.
CAMERA PARAMETERS LENS PARAMETER
ZOOMING SPEED
Procedure:
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [CAMERA PARAMETERS] item, press [OPEN] to
confirm the selection and enter [LENS PARAMETER] menu.
3. Under [LENS PARAMETER] choose [ZOOMING SPEED] item and press [OPEN] to confirm
the selection and the parameter setting will blink.
4. Up/Down P/T to change the value.
5. Press [OPEN] to save and exit this item setting; Press [CLOSE] to exit immediately without
saving.
DIGITAL ZOOM SETTING
Procedure:
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [CAMERA PARAMETERS] and press [OPEN] to
confirm the selection, then enter the [LENS PARAMETER] menu.
3. Under [LENS PARAMETER] choose [DIGITAL ZOOM] and press [OPEN] to confirm the
selection and enter electronic zoom set. The setting will blink.
4. Up/Down P/T to choose ON or OFF.
5. Press [OPEN] to save and exit this item setting; Press [CLOSE] to exit immediately without
saving.
FOCUS LIMIT SETTING
Use this to limit the focal distance of the camera in order to improve the performance of the lens
focus. For example: With a minimum focus distance of 1 meter, the camera will not try to focus on
dust, dirt, water etc. on the camera dome itself.
Procedure:
1. Call preset 95 to enter the main menu.
→ZOOMING SPEED : HIGH
DIGITAL ZOOM : ON
FOCUS LIMIT : 30cm
→【LENS PARAMETER】
【EXPOSURE MODE】
【WHITE BALANCE】
【BACKLIGHT MODE】
→【LENS PARAMETER】
【EXPOSURE MODE】
【WHITE BALANCE】
【BACKLIGHT MODE】

V2.0 7-31-12
15
2. Use the up/down PTZ controls to choose [CAMERA PARAMETERS] and press [OPEN] to
confirm the selection, then enter [LENS PARAMETER] menu.
3. Under [LENS PARAMETER] choose [FOCUS LIMIT] and press [OPEN] to confirm the
selection and enter focus limit set. The setting will blink. Use up/Down P/T to change the
setting.
4. Press [OPEN] to save and exit this item setting; Press [CLOSE] to exit immediately without
saving.
EXPOSURE MODE
Use this menu to set exposure mode, shutter speed, aperture, gain, brightness, back light
compensation, fast/slow shutter, exposure compensation, wide dynamic range and other
parameters to maximize the camera’s image quality.
CAMERA PARAMETERS EXPOSURE MODE
Exposure Mode Setting
Procedure:
1. Call preset 95 to enter the main menu.
2. Use the up/down PTZ controls to choose [CAMERA PARAMETERS] and press [OPEN] to
confirm the selection.
3. Under [CAMERA PARAMETERS] choose [EXPOSURE MODE] and press [OPEN] to confirm
the selection which enters the exposure sub-menu set.
4. In the Exposure Mode menu choose the [EXPOSURE MODE] line item and press [OPEN] to
confirm the selection and enter the exposure mode selection setting.
EXPOSURE MODE:
The 5 available choices are: 1) IRIS, 2) SHUTTER, 3) BRIGHT, 4) USER and 5) AUTO.
When the exposure mode is set to AUTO, all exposure settings are handled by the camera
automatically. This is the recommended setting, as several parameters are dynamically
adjusted to obtain the best image output.
When the exposure mode is set to USER the IRIS, SHUTTER, and BRIGHT parameters can
be set manually to fixed values, which will all be used to control exposure.
When the exposure mode is set to IRIS, then the exposure will be set by the iris level ONLY
and the other values will be ignored.
When the exposure mode is set to SHUTTER, then the exposure will be set by the shutter
speed ONLY and the other values will be ignored.
When the exposure mode is set to BRIGHT, then the exposure will be set by the bright level
ONLY and the other values will be ignored.
AGC (Auto Gain Control):
【LENS PARAMETER】
→【EXPOSURE MODE】
【WHITE BALANCE】
【BACKLIGHT MODE】
→EXPOSURE MODE : AUTO
IRIS LEVEL : F5.6
SHUTTER SPEED : 1/60
AGC LEVEL : 0dB
BRIGHT LEVEL : 016
DIGI-SLOW SHUTTER: AUTO
DAY/NIGHT MODE : AUTO

V2.0 7-31-12
16
→White Balance Mode : AUTO
Red Gain : 000
Green Gain : 000
This is set individually. There are 16 settings from -3dB through 28dB.
DIGI-SLOW SHUTTER:
This can be turned either on or off. Turning this ON allows the camera to increase gain by
slowing down the shutter digitally.
DAY/NIGHT MODE:
This can be set to either DAY, NIGHT or AUTO. The AUTO setting is recommended. In AUTO
mode the camera will change back and forth from day to night mode automatically, turning the
IR LEDs on or off as needed. The DAY setting manually turns off the IR LEDs and the camera
will produce a color image. The NIGHT setting manually turns on the IR LEDs and the camera
produces a black & white image.
WHITE BALANCE MENU:
Use this function to set various white balance modes, both auto and manual. The red gain and blue
gain settings can also be set manually.
CAMERA PARAMETERS WHITE BALANCE
WHITE BALANCE SETTING:
Procedure:
1. Call preset 95 to enter the main menu.
2. Choose [CAMERA PARAMETERS] and press [OPEN] to confirm the selection.
3. Choose [WHITE BALANCE] and press [OPEN] to confirm the selection and enter the white
balance menu settings.
4. The [WHITE BALANCE] parameters can be set as bellow:
[AUTO]: This is the default mode. White balance sensors automatically detect the environment
to restore the true color.
[USER]: The user manually adjusts Red Gain and Blue Gain values.
[ATW]: Automatic tracking modes
[OPW]: Single-lock mode
[Outdoor]: Outdoor mode, colder colors
[Indoor]: Indoor mode, warmer color
5. Use up/down to select the desired white balance mode.
6. Press [OPEN] to save and exit this item setting; Press [CLOSE] to exit immediately without
saving.
Attention: The Red Gain and Blue Gain values can only be changed when White
Balance mode is set to “USER”.
BACKLIGHT MODE SETTING
【LENS PARAMETER】
【EXPOSURE MODE】
→【WHITE BALANCE】
【BACKLIGHT MODE】

V2.0 7-31-12
17
Use this setting to help compensate for lighting conditions where there is a strong light visible
behind the object you are trying to observe with the camera.
CAMERA PARAMETERS BACKLIGHT MODE
BACKLIGHT MODE
Procedure:
1. Under [CAMERA PARAMETERS] choose [BACKLIGHT MODE] and press [OPEN] to enter
BLC mode set.
2. Use up/down PT to choose ON or OFF.
3. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
PAN TILT SETTING
MAIN MENU PANTILT SETTING
PANTILT Set Menu
PANTILT SETTING PANTILT SET
Auto-flip
Auto-flip allows the camera to rotate 180° horizontally and upward 90° vertically after the tilt is
positioned straight down. This allows the camera to operate as if it had 180° vertical tilt capability.
Procedure:
1. Call preset point 95 to enter the main menu.
2. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu and press [OPEN] to
confirm the selection.
3. Under [PANTILT SETTING] choose [AUTO FLIP] and press [OPEN] to confirm the selection
【LENS PARAMETER】
【EXPOSURE MODE】
【WHITE BALANCE】
→【BACKLIGHT MODE】
→BACK LIGHT MODE : ON
【SYSTEM SETTING】
【CAMERA PARAMETERS】
【PAN TILT SETTING】
【DISPLAY CONFIGURATION】
【ALARMS SETUP】
→【PANTILT SETTING】
【PRESETS SETUP】
【SEQUENCE SETUP】
【PATTERN SETUP】
【AUTOSCAN SETUP】
【HOME ACTION】
→AUTO FLIP
JOYSTICK RECOVER
SPEED PROPORTIONAL
INFRARED LIGHTING
INFRARED ARRAY
SET NORTH DIRECTION
GOTO ZERO POSITON
→【PANTILT SETTING】
【PRESETS SETUP】
【SEQUENCE SETUP】
【PATTERN SETUP】
【AUTOSCAN SETUP】
【HOME ACTION】

V2.0 7-31-12
18
and enter auto flip set.
4. Use Up/down P/T to select and change this function to ON or OFF.
5. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
JOYSTICK RECOVER
NOTE: This model of camera does not support manual focus or iris adjustments. The
settings may be made for joystick recover, but they will have no effect as there is no
manual iris or focus settings to recover from.
ALL: When ALL is selected, both the focus and iris will return to automatic operation after any
joystick command is received from the camera.
NONE: When NONE is selected, the focus and iris will remain under manual control only. The
camera will not attempt to auto-focus the camera or operate the iris automatically.
FOCUS:When FOCUS is selected, just the focus function will return to automatic mode when the
joystick is moved after a manual adjustment has been made. The iris will remain under manual
control.
IRIS: When IRIS is selected, just the iris function will return to automatic mode when the joystick is
moved after a manual adjustment has been made. The focus will remain under manual control.
Procedure:
1. Call preset point 95 to enter the main menu.
2. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu, press [OPEN] to
confirm the selection and enter pan parameter set.
3. Under [PANTILT SETTING] choose the [JOYSTICK RECOVER] menu and press [OPEN] to
confirm the selection.
4. Up/down P/T to change the setting.
5. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
SPEED PROPORTIONAL
This function causes the speed at which the camera pans to decrease proportionately with the
amount of zoom applied; When the camera is zoomed out wide, it will pan at full speed. When the
camera is zoomed in far, the camera will pan slower.
Procedure:
1. Call preset point 95 to enter the main menu.
2. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu, press [OPEN] to
confirm the selection and enter pan parameter set.
3. Under [PANTILT SETTING] choose the [SPEED PROPORTIONAL] menu and press [OPEN]
to confirm the selection.
4. Up/down P/T to change the setting.
5. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
INFRARED LIGHTING
The IR LEDs can either be turned on manually or set to turn on and off automatically as lighting
conditions change.
Procedure:
1. Call preset point 95 to enter the main menu.
2. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu, press [OPEN] to
confirm the selection and enter pan parameter set.
3. Under [PANTILT SETTING] choose the [INFRARED LIGHTING] menu and press [OPEN] to
confirm the selection.
4. Up/down P/T to change the setting.
5. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.

V2.0 7-31-12
19
INFRARED ARRAY
The IR LEDs can be set to switch from low power to high power when the zoom lens is zoomed to
a certain amount. For example, setting this to “3X” will change the LEDs to the higher power setting
when the lens is zoomed to 3X optical magnification or more.
Procedure:
6. Call preset point 95 to enter the main menu.
7. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu, press [OPEN] to
confirm the selection and enter pan parameter set.
8. Under [PANTILT SETTING] choose the [INFRARED ARRAY] menu and press [OPEN] to
confirm the selection.
9. Up/down P/T to change the setting.
10. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
SET NORTH DIRECTION
By using this function, the system will automatically save the current position of the dome camera
as the north direction and it will be regarded as the zero point of direction, i.e. 0° level position.
Procedure:
1. Call preset point 95 to enter the main menu..
2. Under [PANTILT SETTING] choose the [PANTILT SETTING] menu, press [OPEN] to confirm
the selection and enter pan parameter set.
3. Under [PANTILT SETTING] choose [SET NORTH DIRECTION] menu and press [OPEN] to
confirm the selection and prepare to aim the camera.
4. Use the PTZ controller to aim the camera lens to the North.
5. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
GOTO ZERO POSITON
This function causes the camera to calibrate itself to a “zero position” which can be used to realign
the camera to its original preset positions in the event of a physical misalignment or power failure.
Procedure:
1. Call preset point 95 to enter the main menu.
2. Under [PANTILT SETTING] choose [PANTILT SETTING] and press [OPEN] to confirm the
selection and enter pan parameter set.
3. Under [PANTILT SETTING] choose [GOTO ZERO POSITION]menu, press [OPEN] to
confirm the selection and enter to the zero point setting. The camera will move to the zero
position.
4. Press [CLOSE] to return to the previous menu.
Preset Point Setting Menu
PANTILT SETTING PRESETS SETUP
【PANTILT SETTING】
→【PRESETS SETUP】
【SEQUENCE SETUP】
【PATTERN SETUP】
【AUTOSCAN SETUP】
【HOME ACTION】
→PRESET NUMBER : 001
TITLE :
SET NEW PRESET
SHOW NEXT PRESET
DELETE CURRENT

V2.0 7-31-12
20
This camera supports 200 preset points.
Preset Number Setting
Procedure:
1. Call preset point 95 to enter the main menu.
2. Use Up/Down P/T to choose [PANTILT SETTING] and press [OPEN] to confirm the selection
and enter preset set menu.
3. Under [PANTILT SETTING] choose the [PANTILT SETTING] sub-menu and press [OPEN]
to confirm the selection.
4. Under [PANTILT SETTING] choose [PRESET NUMBER] menu to enter to the preset point
setting, and the parameter will blink.
5. Use Up/Down P/T to choose a preset number.
6. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
Note: If the preset point already contains data, the dome camera will call the position to
alert you that the preset will be written over.
TITLE SETTING
Procedure:
1. Under [PANTILT SETTING] choose [TITLE] for entering into the title change menu, “Edit title
of the preset point” will be shown on the screen and the parameter will blink.
2. Use Up/down P/T to set the characters of the preset name.
3. Press the [OPEN] key to save and exit. Press the [CLOSE] key to exit directly without saving.
SET NEW PRESET
Procedure:
1. Call preset point 95 to enter the main menu.
2. Up/Down cursor to choose [PANTILT SETTING], press [OPEN] to confirm the selection and
enter pan set menu.
3. Under [PANTILT SETTING] choose [PANTILT SETTING] menu, press [OPEN] to confirm the
selection.
4. Under [PANTILT SETTING] choose [SET NEW PRESET] to enter into the preset point
setting. The display will show “Press IRIS OPEN”. First move the camera to the position you
would like to set for the preset, and then press IRIS CLOSE.
Instruction: The preset point number should be selected first before defining, displaying
and deleting the preset point or editing the title.
SEQUENCE SETUP
Individual preset points can be strung together to create a sequence, also known as a “tour”. Each
sequence can contain up to 32 preset points and each preset can have the dwell time set
individually.
PANTILT SETTING SEQUENCE SETUP
【PANTILT SETTING】
【PRESETS SETUP】
→【SEQUENCE SETUP】
【PATTERN SETUP】
【AUTOSCAN SETUP】
【HOME ACTION】
→SEQUENCE NUMBER : 001
DEFAULT DWELL : 001
EDIT SEQUENCE
RUN CONTINUOUSLY
DELETE CURRENT
