Provision ISR DAI-310IPHEVF User manual

PROVISION-ISR
 DAI-310IPHEVF
 DAI-310IPHE04
 DI-310IPHEVF
 I4-310IPHEVF
 I3-310IPHE04
 DM-480IPE28
 DAI-480IPE28
 I3-480IPE2.8
User Manual
Economy IP Camera
For H.264 IP Camera
All rights reserved

Notes
 Before operation, we strongly advise users to read this manual and keep it for later use.
 Please use the specified power supply to connect.
 Avoid from incorrect operation, shock vibration, heavy pressing which can cause
damage to product.
 Do not use corrosive detergent to clean main body of the camera. If necessary, please
use soft dry cloth to wipe dirt; for hard contamination, use neutral detergent. Any
cleanser for high grade furniture is applicable.
 Avoid aiming the camera directly towards extremely bright objects, such as, sun, as this
may damage the image sensor.
 Please follow the instructions to install the camera. Do not reverse the camera, or the
reversing image will be received.
 Do not operate the camera in extreme temperatures or extreme humidity conditions.
 Use the power supply supplied authorized by a PROVISION-ISR technician.
 Keep away from heat sources such as radiators, heat registers, stove, etc.
 The instructions in this manual could be outdated; if you need any clarifications you
can contact an authorized PROVISION-ISR technician. PROVISION-ISR reserves the
right to add changes to this manual and publish it online in our website (www.provision-
isr.com): there may be inconsistencies with the latest version. This applies to any and
all software upgrades and product improvements, interpretation and modification added.
These changes will be published in the latest version without prior notification.
 When this product is in use, the relevant contents of Microsoft, Apple and Google will
be involved in. The pictures and screenshots in this manual are only used to explain the
usage of our product. The ownerships of trademarks, logos and other intellectual
properties related to Microsoft, Apple and Google belong to the above-mentioned
companies.
 All pictures and examples used in the manual are for reference only.

Economy IP Camera User Manual
Table of Contents
1Introduction ......................................................................................................... 1
1.1Summarization .................................................................................................................... 1
3IE Remote Access ................................................................................................. 2
3.1LAN ................................................................................................................................... 2
3.1.1Access through IP-Tool ......................................................................................... 2
3.1.2Directly Access through IE .................................................................................... 3
3.2WA N .................................................................................................................................. 4
4Remote Preview ................................................................................................... 6
4.1The Remote Preview Interface .............................................................................................. 6
4.2Record Playback .................................................................................................................. 6
4.3Snap Pictures ....................................................................................................................... 7
5Remote Live Surveillance ..................................................................................... 9
5.1System Configuration ........................................................................................................... 9
5.1.1Basic Information................................................................................................. 9
5.1.2Date & Time Configuration ................................................................................... 9
5.1.3SD Card ............................................................................................................ 10
5.2Video Configuration ........................................................................................................... 10
5.2.1Camera Configuration ........................................................................................ 10
5.2.2Video Stream ..................................................................................................... 11
5.2.3OSD Configuration ............................................................................................ 11
5.2.4Video Mask ....................................................................................................... 12
5.2.5ROI Configuration ............................................................................................. 13
5.3Alarm Configuration .......................................................................................................... 14
5.3.1Motion Detection Area ....................................................................................... 14
5.3.2Motion Detection Trigger .................................................................................... 14
5.3.3Motion Detection Schedule ................................................................................. 15
5.4Network Configuration ....................................................................................................... 16
5.4.1Port .................................................................................................................. 16
5.4.2Wired ................................................................................................................ 16
5.4.3Server Configuration .......................................................................................... 17
5.4.4IP Notify ........................................................................................................... 17
5.4.5DDNS Configuration .......................................................................................... 18
5.4.6RTS P ................................................................................................................ 21
5.4.7UPnP ................................................................................................................ 22
5.4.8Mail Setting ....................................................................................................... 22
5.4.9FTP .................................................................................................................. 23
5.5Advanced Configuration ..................................................................................................... 23
5.5.1User Configuration ............................................................................................. 23
5.5.2Security Configuration ........................................................................................ 25
5.5.3Configure Backup & Restore ............................................................................... 25
5.5.4Reboot Device ................................................................................................... 26
5.5.5Upgrade ............................................................................................................ 26

Economy IP Camera User Manual
6Mobile Surveillance............................................................................................ 27
6.1Network Configuration ....................................................................................................... 27
6.2By Phones with iPhone OS ................................................................................................. 27
7.3 By Phones with Android ....................................................................................................................... 33
7IP-Tool ............................................................................................................... 36
8Q & A ................................................................................................................ 40

Page 1 Economy IP Camera User Manual
1 Introduction
1.1 Summarization
This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV solutions. It
adopts state of the art video processing chips. It utilizes most advanced technologies, such as
video encoding and decoding technology, complies with the TCP/IP protocol, SoC, etc to
ensure this system more stable and reliable. This unit consists of two parts: the IP-CAM
device and central management software (short for CMS). The CMS centralizes all devices
together via internet or LAN and establishes a sound surveillance system to realize unified
management and remote operation to all devices in one network.
This product is widely used in banks, telecommunication systems, electricity power
departments, law systems, factories, storehouses, uptowns, etc. In addition, it is also an ideal
choice for surveillance sites with middle or high risks.
Main Features
 ICR auto switch, true day/night
 3D DNR, digital WDR
 ROI coding
 PoE power supply
 Support smart phone, iPad, remote monitoring
 Support P2P (NET Traversal)

Page 2 Economy IP Camera User Manual
2 IE Remote Access
IP-CAM can be connected through LAN or WAN. Here only take IE browser (6.0) for example.
The details are as follows:
2.1 LAN
In LAN, there are two ways to access IP-CAM: 1. Access through IP-Tool; 2. Directly access
through IE browser.
2.1.1 Access through IP-Tool
① Make sure the PC and IP-CAM are connected to the LAN and the IP-Tool is installed in the
PC from the CD.
② Double click the IP-Tool icon on the desktop to run this software as shown below:
③ Modify the IP address. The default IP address of this camera is 192.168.226.201. Click the
information of the camera listed in the above table to show the network information on the right
hand. Modify the IP address and gateway of the camera and make sure its network address is
in the same local network segment as the computer’s. Please modify the IP address of your
device according to the practical situation.
For example, the IP address of your computer is 192.168.13.4. So the IP address of the camera

Page 3 Economy IP Camera User Manual
shall be changed to 192.168.13.X. After modification, please input the password of the
administrator and click “Modify” button to modify the setting.

④ Double click the IP address and then the system will pop up the IE browser to connect IP-
CAM. IE browser will auto download the Active X control. After downloading, a login window
will pop up as shown below.
Input the username and password to log in.

2.1.2 Directly Access through IE
The network service is default as shown below:
IP address: 192.168.226.201
Subnet Mask: 255.255.255.0
Gateway: 192.168.226.1
HTTP: 80
Data port: 9008
You may use the above default settings when you log in the camera for the first time.
① Manually set the IP address of the PC and the network segment should be as the same as the
default settings of the IP camera. Open the network and share center. Click “Local Area
Connection” to pop up the following window.
The default password of the administrator is “123456”.
The default username is “admin”; the default password is “123456”.

Page 4 Economy IP Camera User Manual
Select “Property” and then select internet protocol according to the actual situation (for example:
IPV4). Next, click “Property” button to set the network of the PC.
② Open the IE browser and input the default address of IP-CAM and confirm. The IE browser
will download Active X control automatically.
③ After downloading Active X control, the login dialog box will pop up.
④ Input the default username and password and then enter to view.
2.2 WAN
Take access the camera by the router or virtual server for example.
① Make sure the camera is well connected via LAN and then log in the camera via LAN and

Page 5 Economy IP Camera User Manual
go to the ConfigNetwork ConfigPort menu to set up the port number.
② Go to Config Network ConfigWired menu to modify the IP address.
③ Go to the router’s management interface through IE browser to forward the IP address and
port of the camera in the “Virtual Server”.
Port Setup IP Setup
Router Setup
④ Open the IE browser and input its WAN IP and http port to access.

Page 6 Economy IP Camera User Manual
3 Remote Preview
3.1 The Remote Preview Interface
Remote Preview
 When motion detection alarm is triggered, the people icon turns red.
Right click to pop up a pull-down list as shown below:
Stream: Three streams are optional.
Turn off the live: Click this item will close present live preview.
Full screen: The live preview picture will full-screen display.
Double click or click right mouse to return to the previous
interface.
Online user: Display the current user connecting to the device.
System information: Display the device information: device
name, firmware version, software build date, kernel version and
hardware version.
3.2 Record Playback
Before you play the record files, please make sure you have recorded. You make click
button to record. Then click button to pop up a video player. Double click the record file
to play the video as shown below.
1 People icon 4 Zoom in 7 Start recording
2 Fix size 5 Zoom out 8 Playback
3 Actual size 6 Full screen 9 Snap

Page 7 Economy IP Camera User Manual
1 Play 5 Next frame 9 Zoom out
2 Pause 6 The previous file 10 Full screen
3 Stop 7 The next file 11 Path
4 Forward 8 Zoom in 12 Volume
3.3 Snap Pictures
Select the picture number, and then click “Snap” icon as shown below.
Single Snap
User can snap multiple pictures. Select the picture number from Frame pull down list box, such
as 2, and check “Title” and “Time” to show capture title and time on the snap pictures
simultaneously.

Page 8 Economy IP Camera User Manual
Multi-picture Snap
Click “Browse” to set saving path. Click “Save” to save pictures to HDD on the computer;
Click “Printer setup” to set the printer and print the snap pictures; drag the scroll bar to view all
snapped pictures.

Page 9 Economy IP Camera User Manual
4 Remote Live Surveillance
Functions of remote configurations include: System Configuration, Video Configuration,
Alarm Configuration, Network Configuration and Advanced Configuration. User should firstly
select the menu on the left, and then set the relative parameters. When a user set the parameters
of a certain device, other users can not set this device.
4.1 System Configuration
The “System configuration” includes three submenus: Basic Information, Date & Time and SD
card.
4.1.1 Basic Information
Go to ConfigBasic information menu as shown below. In the basic information interface,
user can set up the device name and check the relative information of the server.
4.1.2 Date & Time Configuration
Setting steps:
1. Go to “System Configuration”  “Date & Time”.
2. Set time zone.
3. Enable DST mode as required.
4. Set time. You may set time manually or enable NTP.

Page 10 Economy IP Camera User Manual
4.1.3 SD Card (Availability Depends on Model)
1. Go to “System Configuration” “SD Card” as shown below:
The first time you used the SD card, you should click “Format SD card”.
Click “Eject card” to stop writing data to SD card. Then the SD card can be ejected safely.

4.2 Video Configuration
Camera Configuration includes five submenus: Camera Configuration, Video Stream, OSD
Config, Video Mask and ROI Config.
4.2.1 Camera Configuration
Setting steps:
1. Go to “Video Configuration”  “Camera” interface as shown below.
2. You may adjust frequency, brightness, contrast, hue and saturation of the picture.
Note: Using of SD card function should be coordinated with motion alarm.
When alarm is triggered, the system will automatically snap picture and save the
picture into SD card.

Page 11 Economy IP Camera User Manual
3. Select white balance mode.
4. Wide dynamic, sharpen and denoise are adjustable.
5. You can also set day-night mode and enable the image mirror and image overturn function.
6. Press the “Save” button to save the settings.
4.2.2 Video Stream
Go to “Video configuration”  “Video Stream” to see an interface as shown below.
Three video streams can be adjustable.
Resolution: The higher the resolution is, the clearer the image is.
Frame rate: The higher the frame rate is, the more fluency the video is. However, more storage
room will be taken up.
Bitrate type: Including CBR and VBR. CBR means that no matter how changeable the video
resources are, the compression bitrate keeps constant. This will not only facilitate the image
quality better in a constant bitrate but also help to calculate the capacity of the recording. VBR
means that the compression bitrate can be adjustable according to the change of the video
resources. This will help to optimize the network bandwidth.
Video Quality: When VBR is selected, you need to choose image quality. The higher the image
quality you choose, the more bitrate will be required.
Bitrate: Please choose it according to the actual network situation.
I Frame interval: It is recommended to use the default value. If the value is over high, the
read speed of the group of pictures will be slow resulting in the quality loss of the video.
Video encoding profile: Baseline, main and high profile are optional. Baseline profile is
mainly used in interactive application with low complexity and delay. Main/high profile is
mainly used for higher coding requirement.
Alarm picture size: Please select it according to the actual situation.
Video encode slice split: If enabled, you may get more fluency image even though using the
low-performance PC.
4.2.3 OSD Configuration
Go to “Video Config”  “OSD Config” menu to display the interface as shown below.
You may set time stamp, device name and custom OSD here. Drag the time stamp and custom
OSD to set their position. Then press the “Save” button to save the settings.

Page 12 Economy IP Camera User Manual
4.2.4 Video Mask
You can set 4 mask areas at most.
To set up video mask
1. Enable video mask and select mask color.
2. Click “Draw” button and then drag the mouse to draw the video mask area.
3. Click “Save” button to save the settings.
4. Return to the live to see the following picture.

Page 13 Economy IP Camera User Manual
Clear the video mask:
Go to video mask menu and then click “Clear” button to delete the current video mask area.
4.2.5 ROI Configuration
To set up ROI
1. Go to ConfigROI Config menu.
2. Check “Enable” and then click “Draw” button.
3. Drag the mouse to set the ROI area.
4. Set the level.
5. Click “Save” button to save the settings.
Now, you will see the selected ROI area is clearer than other areas especially in low bitrate
condition.

Page 14 Economy IP Camera User Manual
4.3 Alarm Configuration
Alarm configuration includes three submenus: Motion Detection Area, Motion Detection
Trigger and Motion Detection Schedule.
4.3.1 Motion Detection Area
1. Go to “Alarm configuration”  “Motion Detection Area” to see an interface as shown below.
2. Move the “Sensitivity” scroll bar to set up the motion trace sensitivity.
3. Check “Add”, press the “Ctrl” button and move mouse to select the motion detection area;
Select “Erase” and move the mouse to clear all motion detection area.
4. Press the “Save” button to save the settings.
4.3.2 Motion Detection Trigger
1. Go to “Alarm Configuration”  “Motion Detection Trigger” to display an interface as shown
below.

Page 15 Economy IP Camera User Manual
2. Check “Enable alarm” check box. Then motion based alarm is activated.
3. Set alarm holding time.
4. Set alarm trigger options.
Trigger Snap: If selected, the system will snap images on an alarm and save them in SD card.
Trigger Email: If the email and attach picture checkbox is checked (Email address shall be set
first in the Mail config interface), the triggered snap pictures and event will be sent into those
address.
Trigger FTP: If “Uploading picture” is checked, the triggered snap pictures will be sent into
FTP server address. Please refer to FTP configuration chapter for more details.
5. Press the “Save” button to save the settings.
4.3.3 Motion Detection Schedule
Go to “Alarm configuration”  “Motion Detection schedule” interface as shown below.
Week schedule
User could set the alarm time from Monday to Sunday for alarm everyday in one week.
Note: The lengthwise means one day of a week; the rank means 24 hours of a day. Click on the
pane to set the alarm hours. Green means selected area. Blank means unselected area.
Add: Add the schedule for a special day.
Erase: Delete holiday schedule.
Day schedule
User could set alarm time for alarm at a certain time of special day, such as holiday.
1. Select a date at the “Date” pull down list, press “Add” button to add that date to the list box
on the right side and then move the scroll bar to set the schedule of that day.
2. Select a date in the list box on the right side, and press “Erase” to remove the schedule on
that day.
Press the “Save” button to save the settings.
Note: Holiday schedule is prior to Week schedule.
