DVTEL ioi HD CB-5222 Manual

ioi HD CB-5222
Bullet Analytic IP Camera
User and Installation Guide
Rev 0.18 January 21, 2016
DVTEL INC.
65 Challenger Road
Ridgefield Park, NJ 07660
The contents of this guide may not be reproduced
or reprinted in whole or in part without the
express written permission of DVTEL, Inc.

Table of Contents
i
Table of Contents
1Document Information...........................................................................................................v
2Overview ...............................................................................................................................1
Features.................................................................................................................................1
Package Contents ..................................................................................................................2
3Introduction to the CB-5222 Analytic Bullet IP Camera............................................................3
CB-5222 Camera Dimensions ................................................................................................3
System Cable .........................................................................................................................4
3.2.1 Alarm Input/Output Pin-out..............................................................................................5
3.2.2 Power Input/Output Pin-out.............................................................................................5
3.2.3 Waterproofing the Camera Cable Connectors..................................................................7
3.2.4 Connecting the Unit to the Network.................................................................................8
3.2.5 Connecting Power to the Camera .....................................................................................8
4System Requirements ............................................................................................................9
5Installation ..........................................................................................................................11
Setting the Camera’s Focal Length ......................................................................................11
Initial Camera Configuration ...............................................................................................11
Camera Mounting Instructions............................................................................................13
6Using the DNA Utility to Search and Access the Camera ........................................................15
7Using the Web Browser to Access the Camera ......................................................................17
8Adjusting and Framing-Up the Camera View.........................................................................19
9Configuration and Operation................................................................................................20
CB-5222 Web Interface .......................................................................................................20
Settings ................................................................................................................................24
9.2.1 System Settings ...............................................................................................................24
9.2.2 Streaming Settings ..........................................................................................................48
9.2.3 Camera Settings ..............................................................................................................53
9.2.4 Analytics Settings ............................................................................................................63
Log Out ................................................................................................................................86
Appendices................................................................................................................................87

CB-5222 User and Installation Guide
ii
Technical Specifications.......................................................................................................88
Internet Security Settings ....................................................................................................91
Install UPnP Components ....................................................................................................93
Deleting the Existing DVPlayer ............................................................................................95
Deleting Temporary Internet Files.......................................................................................96
Mounting Accessories .........................................................................................................97
Outdoor Camera Installation...............................................................................................98
Wall Mount Junction Box ................................................................................................98
Pole Mount Junction Box ..............................................................................................102
Contacting DVTEL..................................................................................................................... 106

Table of Contents
iii
List of Figures
Figure 1: ioi HD Analytic Bullet IP Camera ..............................................................................................1
Figure 2: Package Contents.....................................................................................................................2
Figure 3: CB-5222 Dimensions (Front View)...........................................................................................3
Figure 4: CB-5222 Dimensions (Side View) ............................................................................................3
Figure 5: CB-5222 Camera Input/Output Connections............................................................................4
Figure 6: Camera Cables.........................................................................................................................7
Figure 7: System Cable............................................................................................................................7
Figure 8: System Cable Hose and Wiring................................................................................................7
Figure 9: Discovered IP Devices............................................................................................................12
Figure 10: Assign IP Dialog Box ............................................................................................................12
Figure 11: Login Window .......................................................................................................................17
Figure 12: DVPlayer Add-On Message..................................................................................................17
Figure 13: Installing the ActiveX Component.........................................................................................18
Figure 14: Render.cab Download Dialog Box........................................................................................18
Figure 15: Live Screen...........................................................................................................................18
Figure 16: Mounting Bracket..................................................................................................................19
Figure 17: Rotating the Camera.............................................................................................................19
Figure 18: ioi HD Web Interface with Callouts.......................................................................................20
Figure 19: View Mode Function Buttons................................................................................................22
Figure 20: System Screen......................................................................................................................25
Figure 21: Security > User Screen.........................................................................................................26
Figure 22: Editing Password and Privileges ..........................................................................................27
Figure 23: IP Filter Screen.....................................................................................................................28
Figure 24: IEEE 802.1X/EAP-TLS Screen.............................................................................................29
Figure 25: Network > Basic Screen .......................................................................................................30
Figure 26: QoS Screen ..........................................................................................................................32
Figure 27: SNMP Settings Screen.........................................................................................................33
Figure 28: UPnP Screen........................................................................................................................34
Figure 29: Direct Access to Camera with UPnP Enabled......................................................................35
Figure 30: DDNS Screen .......................................................................................................................35
Figure 31: Mail Screen –SMTP.............................................................................................................36
Figure 32: FTP Screen...........................................................................................................................37
Figure 33: Events Setup > IO Screen....................................................................................................38
Figure 34: Triggered Action –Upload Image by FTP ............................................................................39
Figure 35: Triggered Action –Upload Image by E-Mail.........................................................................40
Figure 36: Events Setup > Network Failure Detection Screen ..............................................................41
Figure 37: Schedule Screen...................................................................................................................42
Figure 38: File Location Screen.............................................................................................................43
Figure 39: System Log Screen ..............................................................................................................43
Figure 40: View Information > User Information Screen........................................................................44
Figure 41: View Information > User Information –Get User Privacy Screen ........................................44
Figure 42: Factory Default Screen.........................................................................................................45
Figure 43: Software Version Screen......................................................................................................45
Figure 44: Software Upgrade Screen ....................................................................................................46
Figure 45: File Type Drop-Down List.....................................................................................................46
Figure 46: Parameters Screen...............................................................................................................47
Figure 47: Import/Export Screen............................................................................................................47
Figure 48: Configuration File Information Bar........................................................................................48
Figure 49: Streaming > Video Format Screen .......................................................................................48
Figure 50: Streaming > Video Compression Screen .............................................................................50
Figure 51: Streaming > Video OCX Protocol Screen.............................................................................51
Figure 52: Streaming > Video Frame Rate Screen................................................................................51
Figure 53: Audio Screen ........................................................................................................................52
Figure 54: Exposure Screen with Shutter WDR On...............................................................................53
Figure 55: Multiple Shutter RSS Exposure Screen................................................................................55
Figure 56: Exposure Screen with Shutter WDR Off...............................................................................55
Figure 57: Manual Exposure Mode with Shutter WDR Off ....................................................................58
Figure 58: Picture Adjustment Screen ...................................................................................................58
Figure 59: Advanced Picture Settings Screen with WDR On ................................................................59

CB-5222 User and Installation Guide
iv
Figure 60: Advanced Picture Settings Screen with WDR Off ................................................................60
Figure 61: IR Function Screen...............................................................................................................61
Figure 62: Misc. Screen.........................................................................................................................61
Figure 63: Shutter WDR On...................................................................................................................62
Figure 64: Shutter WDR Off...................................................................................................................62
Figure 65: Analytics > Manual Depth Screen ........................................................................................63
Figure 66: Auto Depth Screen - Auto Calibration ..................................................................................64
Figure 67: Horizon Line..........................................................................................................................65
Figure 68: Analytics > Depth > Solo Setup Instructions ........................................................................67
Figure 69: Analytics > Depth Control Panel...........................................................................................69
Figure 70: Analytics > Depth > Step 1: Ground & Height Screen..........................................................70
Figure 71: Analytics > Depth > Step 1: Ground & Height Instructions...................................................70
Figure 72: Analytics > Depth > Step 2: Camera & Horizon Screen.......................................................71
Figure 73: Analytics > Depth > Step 2: Camera & Horizon Instructions................................................71
Figure 74: Analytics > Depth > Step 3: Advanced Depth Regions Screen............................................72
Figure 75: Analytics > Depth > Step 3: Advanced Depth Regions Instructions.....................................72
Figure 76: Analytics > Depth > Step 4: Verification Screen...................................................................73
Figure 77: Analytics > Depth > Step 4: Verification Instructions............................................................74
Figure 78: Analytics > Rules Screen......................................................................................................74
Figure 79: Rules Drop-down List ...........................................................................................................75
Figure 80: Analytics > Rules > Basic Attributes Tab..............................................................................75
Figure 81: Analytics > Rules > Advanced Attributes Tab ......................................................................76
Figure 82: Analytics > Responses Screen.............................................................................................77
Figure 83: Responses > Triggering Event Tab......................................................................................77
Figure 84: Responses > Actions Tab.....................................................................................................78
Figure 85: Responses > Actions Table..................................................................................................80
Figure 86: Responses > Schedule Tab .................................................................................................80
Figure 87: Sched. Actions > Actions Tab...............................................................................................81
Figure 88: Responses > Actions Table..................................................................................................82
Figure 89: Sched. Actions > Schedule Tab ...........................................................................................83
Figure 90: Analytics > On Screen Display Screen.................................................................................84
Figure 91: Analytics > Firmware Screen................................................................................................85
Figure 92: Analytics > Backup & Restore Screen..................................................................................86
Figure 93: Logout Message ...................................................................................................................86
Figure 94: Command Bar Toolbar –Select Internet Options.................................................................91
Figure 95: Internet Options Screen........................................................................................................91
Figure 96: Command Bar Toolbar –Internet Options............................................................................92
Figure 97: Schedule Screen...................................................................................................................92

Document Information
v
1Document Information
Document Scope and Purpose
The purpose of this document is to provide instructions and installation procedures for physically
connecting the ioi HD CB-5222 analytic bullet IP camera. After completing the physical installation,
additional setup and configurations may be required before video analysis and detection can
commence. For information on the unit setup and configuration, refer to the HTML Edition Units
User’s Guide.
Note:
This document is intended for use by technical users who have a basic understanding of CCTV
camera/video equipment and LAN/WAN network connections.
Remarque:
Ce document est destiné aux utilisateurs techniciens qui possèdent des connaissances de base des
équipements vidéo/caméras de télésurveillance et des connexions aux réseaux LAN/WAN.
Warning:
Installation must follow safety, standards, and electrical codes as well as the laws that apply
where the units are being installed.
Avertissement:
L'installation doit respecter les consignes de sécurité, les normes et les codes électriques, ainsi que
la législation en vigueur sur le lieu d'implantation des unités.
Proprietary Rights and Non-Disclosure
This manual is delivered subject to the following restrictions and conditions:
This document contains proprietary information belonging to DVTEL, Inc. This information
is supplied solely for the purpose of assisting explicitly the licensee of the DVTEL units.
No part of this document contents may be used for any other purpose, disclosed to any
third party or reproduced by any means, electronic or mechanical, without the express
prior written permission of DVTEL, Inc.
Trademarks and Copyrights
DVTEL, the DVTEL logo, ioi, the ioi logo, ioi analytics, ioibox, ioicam, ioi HD, ioi IP, ioi Thermal, and Site
Viewer are trademarks of DVTEL, Inc. Products and trademarks mentioned herein are for
identification purposes only and may be registered trademarks of their respective companies. DVTEL,
Inc. makes no representations whatsoever about any other products or trademarks mentioned in the
manual. This manual and its contents herein are owned by DVTEL, Inc. © DVTEL, Inc. 2015. All rights
reserved.

CB-5222 User and Installation Guide
vi
Disclaimer
Users of DVTEL products accept full
responsibility for ensuring the suitability and
considering the role of the product detection
capabilities and their limitation as they apply to
their unique site requirements.
DVTEL, Inc. and its agents make no guarantees
or warranties to the suitability for the users’
intended use. DVTEL, Inc. accepts no
responsibility for improper use or incomplete
security and safety measures.
Failure in part or in whole of the installer,
owner, or user in any way to follow the
prescribed procedures or to heed WARNINGS
and CAUTIONS shall absolve DVTEL, Inc. and its
agents from any resulting liability.
Specifications and information in this guide are
subject to change without notice.
Avis de non-responsabilité
Il incombe aux utilisateurs des produits DVTEL de
vérifier que ces produits sont adaptés et d'étudier le
rôle des capacités et limites de détection du produit
appliqués aux exigences uniques de leur site.
DVTEL, Inc. et ses agents ne garantissent d'aucune
façon que les produits sont adaptés à l'usage auquel
l'utilisateur les destine. DVTEL, Inc. ne pourra être tenu
pour responsable en cas de mauvaise utilisation ou de
mise en place de mesures de sécurité insuffisantes.
Le non respect de tout ou partie des procédures
recommandées ou des messages d'AVERTISSEMENT ou
d'ATTENTION de la part de l'installateur, du
propriétaire ou de l'utilisateur dégagera DVTEL, Inc. et
ses agents de toute responsabilité en résultant.
Les spécifications et informations contenues dans ce
guide sont sujettes à modification sans préavis.
Document Conventions
WARNING and CAUTION notes are distributed
throughout this document, whenever
applicable, to alert you of potentially
hazardous situations. These may be hazards
associated with a task or a procedure you are
carrying out or are about to carry out.
The following document conventions are used
throughout this manual:
Conventions relatives au document
Les remarques AVERTISSEMENT et ATTENTION sont
réparties dans l'ensemble du document, en fonction
des besoins, afin de vous avertir des situations
potentiellement dangereuses. Il peut s'agir de risques
associés à une tâche ou à une procédure que vous
effectuez ou êtes sur le point d'effectuer.
Les conventions suivantes sont utilisées dans
l'ensemble du document:
A Warning is a precautionary message that indicates a procedure or condition where there are
potential hazards of personal injury or death.
Avertissement est un message préventif indiquant qu'une procédure ou condition présente un
risque potentiel de blessure ou de mort.
A Caution is a precautionary message that indicates a procedure or condition where there are
potential hazards of permanent damage to the equipment and or loss of data.
Attention est un message préventif indiquant qu'une procédure ou condition présente un risque
potentiel de dommages permanents pour l'équipement et/ou de perte de données.

Document Information
vii
A Note is useful information to prevent problems, help with successful installation, or to provide
additional understanding of the products and installation.
Une Remarque est une information utile permettant d'éviter certains problèmes, d'effectuer une
installation correcte ou de mieux comprendre les produits et l'installation.
A Tip is information and best practices that are useful or provide some benefit for installation and
use of DVTEL products.
Un Conseil correspond à une information et aux bonnes pratiques utiles ou apportant un
avantage supplémentaire pour l'installation et l'utilisation des produits DVTEL.
General Cautions and Warnings
This section contains information that indicates
a procedure or condition where there are
potential hazards.
SAVE ALL SAFETY AND OPERATING
INSTRUCTIONS FOR FUTURE USE.
Although the unit is designed and
manufactured in compliance with all applicable
safety standards, certain hazards are present
during the installation of this equipment.
To help ensure safety and to help reduce risk
of injury or damage, observe the following:
Précautions et avertissements d'ordre
général
Cette section contient des informations indiquant
qu'une procédure ou condition présente des risques
potentiels.
CONSERVEZ TOUTES LES INSTRUCTIONS DE SÉCURITÉ
ET D'UTILISATION POUR POUVOIR VOUS Y RÉFÉRER
ULTÉRIEUREMENT.
Bien que l'unité soit conçue et fabriquée conformément
à toutes les normes de sécurité en vigueur, l'installation
de cet équipement présente certains risques.
Afin de garantir la sécurité et de réduire les risques de
blessure ou de dommages, veuillez respecter les
consignes suivantes:

CB-5222 User and Installation Guide
viii
Warning:
1. The unit’s cover is an essential part of the product. Do not open or remove it.
2. Never operate the unit without the cover in place. Operating the unit without the
cover poses a risk of fire and shock hazards.
3. Do not disassemble the unit or remove screws. There are no user serviceable parts
inside the unit.
4. Only qualified trained personnel should service and repair this equipment.
5. Observe local codes and laws and ensure that installation and operation are in
accordance with fire, security and safety standards.
Avertissement:
1. Le cache de l'unité est une partie essentielle du produit. Ne les ouvrez et ne les retirez
pas.
2. N'utilisez jamais l'unité sans que le cache soit en place. L'utilisation de l'unité sans
cache présente un risque d'incendie et de choc électrique.
3. Ne démontez pas l'unité et ne retirez pas ses vis. Aucune pièce se trouvant à l'intérieur
de l'unité ne nécessite un entretien par l'utilisateur.
4. Seul un technicien formé et qualifié est autorisé à entretenir et à réparer cet
équipement.
5. Respectez les codes et réglementations locaux, et assurez-vous que l'installation et
l'utilisation sont conformes aux normes contre l'incendie et de sécurité.
Caution:
To avoid damage from overheating or unit failure, assure that there is sufficient temperature
regulation to support the unit’s requirements (cooling/heating). Operating temperature should
be kept in the range specified for the product (-40o to 50o C/-40° to 122°F for AC/DC/PoE+
operation and -10° to 50°C/14° to 122°F for PoE operation) with no more than 90% non-
condensing humidity.
Attention:
Afin d'éviter tout dommage dû à une surchauffe ou toute panne de l'unité, assurez-vous que la
régulation de température est suffisante pour répondre aux exigences de l'unité
(refroidissement/chauffage). La température de fonctionnement doit être maintenue dans la
plage de température spécifiée pour le produit (-40o à 50o C/-40° à 122°F pour l'utilisation
AC/CC/PoE+ et -10° à 50°C/14° à 122°F pour l'utilisation PoE) sans condensation d'humidité
supérieur à 90%.

Document Information
ix
Electrical Safety Notice and Warnings
Warning:
1. Read the installation instructions before you connect the unit to a power source.
2. Electrical safety should always be observed. All electrical connections must be
performed by a certified electrician.
3. If the unit uses a three-wire power cord, make sure that the product is properly
grounded when in use. This is a safety feature. If the intended power outlet does not
support three prongs, one of which is a ground, contact an electrician to install the
appropriate outlet. NEVER remove or otherwise attempt to bypass the ground pin of
the power cord. Do not operate the unit in the absence of a suitably installed ground
conductor.
4. If you use an extension cord with this system, make sure that the total ampere rating on
the products plugged into the extension cord does not exceed the extension cord
ampere rating.
5. To avoid possible shock hazards or damaging the unit, assure that the positive and
negative of the power leads are properly connected to the terminal block connector
before plugging it into the unit or turning on the power source.
6. In the following situations, the electric power should be turned off immediately and
appropriate repairs, replacements or remedies should be taken if:
The power line is damaged, frayed or shows heavy wear.
The unit has been physically crushed or deformed.
The unit has been exposed to water.
The unit has been exposed to, or shows signs of damage from, fire, intense heat,
heavy smoke, fumes, or vapors.
Electrical connections of the unit become abnormally hot or generate smoke.
The unit has been dropped, damaged or shows signs of loose internal parts.
The unit does not operate properly.

CB-5222 User and Installation Guide
x
Avis et avertissements relatifs à la sécurité électrique
Avertissement:
1. Lisez les instructions d'installation avant de brancher l'unité à une source d'alimentation
électrique.
2. Les consignes de sécurité électrique doivent toujours être respectées. Toutes les
connexions électriques doivent être effectuées par un électricien qualifié.
3. Si l'unité utilise un cordon d'alimentation à trois fils, assurez-vous que le produit est
correctement mis à la terre du produit lors de son utilisation. Ne retirez JAMAIS, et ne
tentez pas de contourner la broche de mise à la terre du cordon d'alimentation.
N'utilisez pas l'unité en l'absence d'un conducteur de mise à la terre installé
correctement.
4. Si vous utilisez une rallonge avec ce système, assurez-vous que l'ampérage total des
produits branchés sur la rallonge ne dépasse pas l'ampérage nominal de celle-ci.
5. Pour éviter tout risque de choc électrique ou d'endommager l'unité, assurez-vous que les
bornes plus et moins de l'alimentation sont correctement raccordées au connecteur du
bloc de jonction avant de le brancher sur l'unité ou d'activer la source d'alimentation.
6. Dans les situations suivantes, l'alimentation électrique doit être coupée immédiatement,
et les réparations, remplacements ou solutions suivants doivent être effectués si :
Le cordon d'alimentation ou la prise (le cas échéant) est endommagé,
effiloché ou très usé.
L'unité a subi un choc ou a été déformée.
L'unité a été exposée à de l'eau.
L'unité a été exposée à, ou montre des signes de dégâts par le feu, une
chaleur intense, une fumée épaisse, des émanations ou des vapeurs.
Les connexions électriques chauffent de façon anormale ou produisent de la
fumée.
L'unité est tombée, a été endommagée, ou certaines pièces internes semblent
détachées.
L'unité ne fonctionne pas correctement.
Minimizing EMI and RFI
When wires run for a significant distance in an
electromagnetic field, electromagnetic
interference (EMI) can occur. Strong EMI (e.g.
lightning or radio transmitters) can destroy the
units and can pose an electrical hazard by
conducting power through lines and into the
system. Poor quality or worn wiring can result
in radio frequency interference (RFI). To
minimize the effects of EMI and RFI, consult
your reseller.
Minimisation des IEM et des IRF
Lorsque des câbles parcourent une distance
importante dans un champ électromagnétique, des
interférences électromagnétiques (IEM) peuvent se
produire. D'importantes IEM (comme la foudre ou un
émetteur radio) peuvent détruire les unités et
présenter un risque électrique si elles se propagent sur
les câbles et dans le système. Des câbles de mauvaise
qualité ou usés peuvent provoquer des interférences
radioélectriques (IRF). Pour minimiser les effets des
IEM et des IRF, consultez votre revendeur.

Document Information
xi
Site Preparation
There are several requirements that should be properly addressed prior to installation at the site. The
following specifications are requirements for proper installation and operation of the unit:
Ambient Environment Conditions: Avoid positioning the unit near heaters or heating
system outputs. Avoid exposure to direct sunlight. Use proper maintenance to ensure that
the unit is free from dust, dirt, smoke, particles, chemicals, water or water condensation,
and exposure to EMI.
Accessibility: The location used should allow easy access to unit connections and cables.
Safety: Cables and electrical cords should be routed in a manner that prevents safety
hazards, such as from tripping, wire fraying, overheating, etc. Ensure that nothing rests on
the unit’s cables or power cords.
Ample Air Circulation: Leave enough space around the unit to allow free air circulation.
Cabling Considerations: Units should be placed in locations that are optimal for the
type of video cabling used between the unit and the cameras and external devices.
Using a cable longer than the manufacturer’s specifications for optimal video signal
may result in degradation of color and video parameters.
Physical Security:The unit provides threat detection for physical security systems. In order
to ensure that the unit cannot be disabled or tampered with, the system should be installed
with security measures regarding physical access by trusted and un-trusted parties.
Network Security:The unit transmits over IP to security personnel for video surveillance.
Proper network security measures should be in place to assure networks remain operating
and free from malicious interference. The unit is intended for installation on the backbone
of a trusted network.
Electrostatic Safeguards:The unit as well as other equipment connected to it (relay
outputs, alarm inputs, racks, carpeting, etc.) shall be properly grounded to prevent
electrostatic discharge.
The physical installation of the unit is the first phase of making the unit operational in a security plan.
The goal is to physically place the unit, connect it to other devices in the system, and to establish
network connectivity.

Overview
1
2Overview
The ioi HD CB-5222 bullet camera is a 2.1 megapixel, Full HD 1080p device that features built-in
video analytics. The camera includes a varifocal motorized auto-focus DC-Iris lens with True
Day/Night performance. The camera provides real-time, H.264 and MJPEG streaming video with the
highest quality image. The lightweight, weatherproof, indoor/outdoor camera is easy to install and
operate and features a compact, sophisticated and aesthetic mechanical design.
Three models are available:
CB-5222-11 − F1.4, 3-10.5mm lens
CB-5222-21 − F1.4, 7-22mm lens
CB-5222-31 − F1.6, 6-50mm lens
The ioi HD bullet camera delivers outstanding analytic peformance. It offers enhanced detection,
even of small objects from a distance, even in scenes where there are large or multiple objects and
movement in up to 80% of the frame. The system can detect sophisticated intruders and enable the
identification of people standing upright, which reduces false alarms.
The camera’s video analytics provides alarms when it automatically detects specific events, such as
region entrance, fence trespassing, tripwire crossover, which trigger an automatic notification. You
can define the events and location in the video of the image that can be detected with user-
customizable rules, positioning criteria, responses, and scheduled actions.
Figure 1: ioi HD Analytic Bullet IP Camera
Related Documentation
ioi HTML Edition Units User’s Guide
ioi HD CB-5222 Quick Installation Guide
DNA 2.1 User Manual
Features
The camera supports the following analytic functions:
Analytic relay events
Reduced false alarm rate
Increased detection distance
Unattended baggage
detection
Intrusion detection
Object removal detection
Stopped vehicle detection
Loitering detection
Camera tampering detection
Automatic depth calibration

CB-5222 User and Installation Guide
2
The camera includes the following key general features:
Advanced video analytics
Superior intruder
detection
Customizable rules and actions
H.264 and MJPEG compression
HTTP streaming MPEG
Progressive scan CMOS sensor
Detection event-driven alarms
Alarm input driven events
Relay output actions on alarm
Day/Night (IR Cut Filter)
Low lux
2D/3D noise reduction
RTSP support
Digital WDR
True multi-exposure
Wide Dynamic Range
ONVIF-conformant
Built-in web application/
web server
SNMP v1/v2/v3 SNMP traps
Up to two E-mail SMTP alarms
(excluding analytic alarms)
FTP upload
(up to two addresses)
Upload alarm images to FTP
(excluding analytic alarms)
UPnP support
BNC analog video output
Security IP restricted access
allow/deny list
Multiple users
Group permissions
Per-user permissions
Built-in heater
Supports PoE/PoE+/
12VDC/ 24VAC
Package Contents
Before proceeding, check that the box contains the items listed here. If any item is missing or has
defects, do not install or operate the product. Contact your dealer for assistance.
IP Bullet Analytic Camera
1x 4-pin connector and 1x 3-pin
connector
Quick Installation Guide
CD with bundled software
and documentation
5x Philips screws
(34 x 4mm/1.345” x 0.132”) with
plastic plugs, plus 1x Torx screw
(6.65 x 2.77mm/0.263” x 0.108”)
Figure 2: Package Contents

Introduction to the CB-5222 Analytic Bullet IP Camera
3
3Introduction to the CB-5222 Analytic Bullet IP Camera
This chapter provides the camera dimensions for reference before installation.
The chapter includes the following topics:
CB-5222 Camera Dimensions
System Cable
CB-5222 Camera Dimensions
The mechanical dimensions of the CB-5222 Analytic Bullet IP Camera are shown below.
Figure 3: CB-5222 Dimensions (Front View)
Figure 4: CB-5222 Dimensions (Side View)
Note:
The camera length is 285mm (11.1 in.) with the sunshield and fully extended mounting arm.

CB-5222 User and Installation Guide
4
System Cable
Figure 5 shows the system cable.
Figure 5: CB-5222 Camera Input/Output Connections
The connectors, pin numbers and signal definitions related to each pin are listed below:
Cable
Pin No./ Connector Type
Definition
Description
Ethernet
RJ45, Network LEDs
10/100/1000Mbps
Ethernet/PoE/PoE+
For network, Power over
Ethernet (PoE), or PoE+
connection
Audio In
3.5mm audio plug (pink)
Line in
For connecting line-level audio
input or microphone with built-
in pre-amplifier
Audio Out
3.5mm audio plug (green)
Line out
For connecting headphone or
loudspeakers with built-in
amplifier
Video
BNC
Analog video
For video output
Power
1- Power (+)
2- Earth GND
3- Power (-)
12VDC/24VAC
3-terminal connection block
Alarm
DI - Input (+)
DI - Input (-)
Alarm input
4-terminal connection block
DO - Output (+)
DO - Output (-)
Alarm output

Introduction to the CB-5222 Analytic Bullet IP Camera
5
3.2.1 Alarm Input/Output Pin-out
The alarm input and output connections are shown below.
Pin No.
Designation
Terminal Block
Alarm Connections
DI-
Input (-)
DI+
Input (+)
DO-
Output (-)
DO+
Output (+)
3.2.2 Power Input/Output Pin-out
The power input and output connections are shown below.
Pin
Symbol
Designation
Terminal Block
Power Connections
-
Negative
Ground
+
Positive

Introduction to the CB-5222 Analytic Bullet IP Camera
7
3.2.3 Waterproofing the Camera Cable Connectors
Follow the instructions below to waterproof the connectors for the different types of cables included
in the system cable. The cables are shown below.
System Cable
IP66 RJ45 Cable
Figure 6: Camera Cables
System Cable
To waterproof the system cable
1. Connect all the required devices to the system cable.
2. Coat the joints with silicone gel. There should be no gap between the connectors and the
cables. For alarm I/O connector and power connector, make sure the side with wires
attached is also sealed with silicone gel.
Figure 7: System Cable
3. Seal the end of the rubber coating of the system cable as indicated in the figure below. Use
enough silicone gel to fill in the hose and wrap around each wire in order to properly
waterproof the cable.
Figure 8: System Cable Hose and Wiring
