Seg DVC 58X User manual

- Region code of DVD/Video player for home is region “2” or ALL. In
inserting a disc with other region code it does not operate. Please
only use a disc with region code 2 or ALL.
- is a ‘DO NOT’ mark. If this mark is displayed in operating the
product please wait for a while then use it. If " DO NOT" mark
continues to be displayed in pressing a button after that it means
the button does not function in the currently played disc.
- Press a product button on the REMOTE then use the product.
• DVD operation : [DVD] button
• Video operation : [VCR] button
DVD PLAYER+VIDEO CASSETTE RECORDER
DVC 58X
ENGLISH GB
INSTRUCTION MANUAL

b
Product information
1
Contents
Product Information
Important Safeguards ..................................................... 1
Advantages of This Product Are .... ............................ 4
Read Carefully before Using ......................................... 5
Identification of Controls ............................................... 6
Remote Control .............................................................. 10
Installation
Setting up your player................................................... 11
Connecting your player through extra equipment
(satellite system) ............................................................ 12
Connecting your player to the Hi-Fi system .............13
How to connect your player to another player
How to connect your player to a camcorder ............ 14
Connecting Dolby Digital Amp with Digital Audio
Out Jack ........................................................................... 15
2nd Scart Socket ............................................................. 16
Basic Operation
Initial Installation ........................................................... 17
Setting time and date / Auto clock ............................ 18
OSD ON & OFF / Output Select ................................ 19
DVD Playback ................................................................ 20
VCR Playback ................................................................ 21
Recording ........................................................................ 22
VCR Operation
Tuning in New Stations ................................................ 24
Timer Recording ............................................................ 26
More Functions .............................................................. 29
Connections and Copying ........................................... 33
DVD Operation
Playing a desired scene ................................................ 35
Confirming the current PLAY mode on screen ....... 39
Selecting an AUDIO language SUBTITLE language
and 3D AUDIO ............................................................... 41
Selecting ZOOM and Multi Angle.............................. 42
About MP3 JPG and DivX® discs............................ 43
Displaying menus in a disc........................................... 47
Set-up
Language Setup .............................................................. 48
Video Setup ......................................................................50
Audio Setup..................................................................... 51
Others Setup ................................................................... 52
The others
About DVD...................................................................... 54
Basic information about VCR and Videotape.......... 57
Before doubting about troubles (VCR)....................... 58
Before doubting about troubles (DVD) ..................... 60
Specifications .................................................................. 61
Important Safeguards
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO WIDE SLOT
FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
• LASER : This Digital Video Disc Player employs a Laser System. To ensure proper use of this product
please read this instruction manual carefully and retain for future reference. Should the unit
require maintenance contact an authorized service location - see service procedure.
Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.
To prevent direct exposure to the laser beam do not try to open the enclosure. Visible laser
radiation when open and interlocks defeated.
DO NOT STARE INTO THE BEAM.
• DANGER : Visible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
• CAUTION : Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to
qualified service personnel.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
CAUTION: Any changes or modification in construction of this device which are not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
• Make sure the unit sh uld be placed at least 8cm apart fr m the ther h me appliances r the
bstacles t get sufficient ventilati n.
• This unit shall n t be exp sed t dripping r splashing and n bjects filled with liquids, such
as vases, shall be placed n this unit.
• Switching it ff d es n t disc nnect it fr m the mains (stand-by). T disc nnect it fr m the
mains, y u have t unplug it.
• The system is n t c mpletely disc nnected fr m the mains when the / Ibutt n is set t
the p siti n.

3
2
Product informationProduct information
This set has been designed and manufactured to assure
personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in
this unit will protect you if you observe the following
procedures for installation use and servicing. This unit
is fully transistorized and does not contain any parts
that can be repaired by the user.
1 READ INSTRUCTIONS
All the safety and operating instructions should be
read before the unit is operated.
2 RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
3 HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
4 FOLLOW INSTRUCTIONS
All operating and use instructions should be
followed.
5 CLEANING
Unplug this unit from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6 ATTACHMENTS
Do not use attachments unless recommended by
the unit’s manufacturer as they may cause
hazards.
7 WATER AND MOISTURE
Do not use this unit near water- for example near
a bath tub wash bowl kitchen sink or laundry tub
in a wet basement or near a swimming pool.
8 ACCESSORIES
Do not place this unit on an
unstable cart stand tripod
bracket or table. The unit may
fall causing serious injury to
a child or adult as well as serious damage to the
unit. Use this unit only with a cart stand tripod
bracket or table recommended by the
manufacturer.
8A
A unit and cart combination should be moved
with care. Quick stops excessive force and uneven
surfaces may cause the product and cart
combination to overturn.
9 VENTILATION
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit
and to protect it from overheating. These openings
must not be blocked or covered. These openings
must not be blocked by placing the unit on a bed
sofa rug or other similar surface. This unit should
never be placed near or over a radiator or heat
radiator. This unit should not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
10 POWER SOURCES
This unit should be operated only from the type of
power source indicated on the marking label. If
you are not sure of the type of power supply to
your home consult your dealer or local power
company. For units intended to operate from
battery power or other sources refer to the
operating instructions.
11 GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating -
current line plug (a plug having one blade wider
than the other). This plug will fit into the power
outlet only one way.
This is a safety feature. If you are unable to insert
the plug fully into the outlet try reversing the
plug. If the plug still fails to fit contact your
electrician to replace your obsolete outlet.To
prevent electric shock do not use this polarized
plug with an extension cord receptacle or other
outlet unless the blades can be fully inserted
without blade exposure. If you need an extension
cord use a polarized cord.
12 POWER-CORD PROTECTION
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them paying particular
attention to cords at plugs convenience
receptacles and the point where they exit from the
unit.
Important Safeguards
PORTABLE CART WARNING
(symbol provided by RETAC)
Important Safeguards
13 LIGHTNING
For added protection for this unit during a
lightning storm or when it is left unattended and
unused for long periods of time unplug it from the
wall outlet and disconnect the antenna or cable
system. This will prevent damage to the unit due
to lightning and power line surges.
14 DISC TRAY
Keep your fingers well clear of the disc as it is
closing. It may cause serious personal injury.
15 OVERLOADING
Do not overload wall outlets of extension cords as
this can result in a risk of fire or electric shock.
16 OBJECT AND LIQUID ENTRY
Never push objects of any kind into this unit
through openings as they may touch dangerous
voltage points or “short-out” parts that could
result in a fire or electric shock. Never spill liquid
of any kind on the unit.
17 BURDEN
Do not place a heavy object on or step on the
product. The object may fall causing serious
personal injury and serious damage to the product.
18 DISC
Do not use a cracked deformed or repaired disc.
These discs are easily broken and may cause
serious personal injury and product malfunction.
19 SERVICING
Do not attempt to service this unit yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
20 DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is
damaged.
B. If liquid has been spilled or objects have fallen
into the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions. Improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the unit to its normal
operation.
E. If the unit has been dropped or the cabinet has
been damaged.
F. When the unit exhibits a distinct change in
performance-this indicates a need for service.
21 REPLACEMENT PARTS
When replacement parts are required have the
service technician verify that the replacements he
uses have the same safety characteristics as the
original parts. Use of replacements specified by the
unit manufacturer can prevent fire electric shock
or other hazards.
22 SAFETY CHECK
Upon completion of any service or repairs to this
unit ask the service technician to perform safety
checks recommended by the manufacturer to
determine that the unit is in safe operating
condition.
23 WALL OR CEILING MOUNTING
The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
24 HEAT
The product should be situated away from heat
sources such as radiators heat registers stoves or
other products (including amplifiers) that produce
heat.
25 To prevent battery electrolyte leakage which may
result in injury and damage to the unit or other
objects observe the following precautions:
A. All batteries must be installed with the
proper polarity.
B. Do not mix new with old or used batteries.
C. Only use batteries of the same type and brand.
D. Remove the batteries when they are not to be
used for a long period time.
E. When the batteries have become discharged
they must be disposed of in a safe manner
which complies with all applicable laws.

54
Product information
Advantages of This Product Are
• DVD, VCD, CD, CD-R(MP3), CD-RW, VHS
• Watching DVD f r rec rding br adcast
• Integrated rem te c ntr l (VCR, DVD)
• VISS functi n
• Multiplex s und playback/rec rd
• High S und Quality f 6 head Hi-Fi
• Simple rec rd functi n
• MP3/JPEG file playback functi n (CD-R
disc having rec rds f MP3/JPEG files)
• Functi n t play DivX files (disc rec rded
with the .avi,. divx f rmat.)
(Some of the discs may not be played
according to a DivX version. )
• GUI (Graphical User Interface) thr ugh
OSD (On Screen Display)
By using the [DISPLAY] butt n n the rem te
c ntr l, inf rmati n n the DVD/VCD/CD
player and disc, can be displayed n the TV
screen.
• Screensaver functi n (DVD)
• 3D s und (3D s und effect using 2 speakers)
• High bit / High sampling with 27MHz /
10bit vide enc der
• High bit / High sampling with 96MHz /
24bit Audi D/A C nverter
• C axial, Optical digital Audi utput (PCM,
D lby Digital, dts)
Y u can enj y high-level digital audi by
c nnecting with amp embedded with D lby
Digital / dts dec der.
• Built-in D lby Digital dec der (DVD)
• Anal g audi 2-channels utput f r
DOWNMIX (x1)
• C mp site vide utput (x1)
• Sl w F rward / Reverse playback (DVD)
• Fast F rward / Reverse playback
• Search f title, chapter, and time in DVD
disc, and search f time and track time in
VCD.
• Vari us TV aspect (DVD)
4:3 f r Pan and Scan, 4:3 f r Letter B x, and 16:9
f r Wide
• Repeat playback (title, chapter, and part f r
DVD/ track, disc, and part f r VCD/CD)
• Selective Play (DVD/VCD/CD)
Y u can select and play the desired title / chapter
f DVD and track f Vide CD/CD in STOP
m de.
• 6 languages OSD (On Screen Display)
functi n (DVD)
Y u can select and display OSD in 6 languages.
(E/ F/ S/ G/ I/ D)
• Parental L ck functi n (DVD)
This functi n can prevent playback f s ftware
that may be unsuitable f r children.
• Multi Audi functi n (DVD)
The audi s undtrack can be heard in up t 8
languages. In the case f SVCD r VCD, it
depends n the disc. (The number f audi
languages depends n the s ftware.)
• Multi Subtitle functi n (DVD)
The subtitle can be seem in up t 32 languages.
In the case f SVCD r VCD, it depends n the
disc. (The number f subtitle languages depends
n the s ftware.)
• Multi Angle functi n (DVD)
This functi n all ws y u t ch se the viewing
angle f scenes which were sh t fr m a number
f different angles. (The number f angles
depends n the s ftware.)
• Screen z m functi n (DVD/VCD)
Read Carefully before Using
Cautions in use of DVD-Video player are described
below.
Please read carefully before using a DVD-Video player.
✔Installati n place and handling
• When y u place this player near ther devices,
they may affect p rly t gether.
• When y u place DVD-Vide player and TV in
the upper and l wer sides, it may cause
flickering f pictures r failure (tape is n t
ejected).
• When y u place this player near str ng
magnetic materials, it may affect image r v ice
p rly r damage rec rding.
• D n t spill v latile liquids like insect spray
ver the player. D n t leave rubber r plastic
pr ducts in c ntact with the player f r a l ng
time. They will cause deteri rati n r paint
peel- ff.
✔N t in use
• When the unit is n t in use, be sure t rem ve
the disc r tape and turn ff the p wer.
• If y u d n t use the unit f r a l ng peri d,
rem ve batteries in rem te c ntr l t prevent
leakage.
• In case y u d n’t use the unit f r a l ng time,
the unit may n t functi n pr perly in the
future. Turn n and use the player ccasi nally.
✔M ving
• Repack the unit as it was riginally packed at
the fact ry. Alternatively, pack this pr duct
with t wel n t t be damaged.
• Eject any vide tape.
✔Cleaning
• Dust ff dirt in cabinet r c ntr l panel part
sm thly with a s ft cl th.
• F r heavy dirt, s ak the cl th in a weak
detergent s luti n, wring it well and wipe. Use
a dry cl th t wipe it ut.
• F ll w instructi ns in using chemical cleaners.
• D n t use any type f s lvent such as gas line
r benzene, as they may cause deteri rati n r
paint peel- ff.
✔Checking
• Vide is a high precisi n device. T btain a
clear screen, we rec mmend regular inspecti n
and maintenance every 1,000 h urs f use by
technical engineers.
• F r checking, c ntact y ur dealer r y ur
nearest service center.
✔Checking and Replacement f Antenna
• Antenna is subject t change in its directi n r
damage by wind and rain. F r clean screen,
c ntact and c nsult y ur nearest service center
ab ut checking and replacement.
✔In rec rding imp rtant screen
• Be sure t rec rd the screen and check whether
rec rding is perf rmed pr perly. We beg y u
t understand c mpensati n f rec rding if
rec rding is n t perf rmed by badness f used
tape r vide .
✔C pyright
• D n t use y ur rec rdings with ut permissi n
f a c pyrighter except pers nal usage.
✔Tape and Disc Handling
• D n t use any tape and disc bel w. Damage
f vide head r cut/c iling f tape may cause
failure.
- Tape with m ld
- Tape r disc stained with juice r attachments
- Tape having breakage c nnecti n
- Disassembled tape
- Disc with severe scratch
• M isture c ndensati n may ccur in tape.
M isture c ndensati n damages the tape.
Please use the tape after the m isture
c ndensati n is disappeared.
• After use, st re tape vertically in a case t
prevent l se.
• D n t st re the f ll wing places.
- High temperature and humidity
- Subject generati n f m ld
- Subject t direct sunlight
- Much dirt r dust
- Near str ng magnetic materials such as speaker
✔Vide head cleaning
• Vide head cleaning is needed when the
playback picture bec mes unclear. Use an
equivalent high quality chemical n n-abreasive
head cleaning tape r have them cleaned
pr fessi nally.

76
Product information
Identification of Controls
! POWER (STANDBY/ON) butt n
Use to power the device on/off if AC power
supply is connected.
@ Place t insert vide tape
# Disc tray
$ VIDEO INPUT jack
% AUDIO INPUT jack
^ EJECT butt n
& RECORD butt n
* PR D wn/Up butt n
( Operati n Display Wind w
Display operation of device. For more information
see “Operation Display Window” in 7P.
) SELECT butt n
Use to change DVD mode to VCR mode and vice
versa.
1 STOP butt n
Use to stop playing.
2 REWIND butt n
Use to rewind currently being played videotape or
disc; or to playback back rapidly.
3 Playback/PAUSE butt n
Playback videotape or disc.
Press this button to pause a screen.
4 FAST FORWARD butt n
Use to wind currently being played videotape or
disc; or to playback rapidly.
5 OPEN/CLOSE Tray butt n
Main body (front panel)
!
%& * ) 1
2
345
^
@#
$(
Identification of Controls
Timer Recording Standby
Timer Recording Error
Recording in Progress
Timer Recording in
Progress
Recording Pause
Repeat one chapter [DVD]
Repeat track
[VCD, CD, DivX, MP3, JPG]
Repeat title [DVD]
Repeat DISC
[VCD, CD, DivX, MP3, JPG]
Repeat FOLDER
[DivX, MP3, JPG]
Repeat a defined period
from A [DVD, VCD, CD]
Repeat a defined period
from A to B [DVD, VCD, CD]
- RECORDING MODE - - REPEAT MODE -
DVD playback
Fast playback
Fast reverse playback
Slow playback
Pause picture
- DVD OPERATION -
VCR playback
Fast forward
Rewinding
Fast playback (CUE)
Fast reverse playback
(REVIEW)
Slow playback
Still picture
Stop
Child Lock
- VCR OPERATION -
Operation Display Window

Product information
9
Identification of Controls
Remote control 2 Batteries RF cable Instruction
Manual
• To purchase accessories or not supplied parts additionally, contact your nearest dealer or service center. But,
instruction manual is not sold additionally.
• Operate remote control within 7m from the unit.
• Do not press 2(two) buttons at the same time.
• Do not li ht up sendin and receivin part of remote control.
• Do not keep in the place with much dust and humidity.
Instructions in using REMOTE
Accessories
AAA
AAA
✔
Remote control battery installation
Detach the battery cover on the rear of the
remote control, and insert two AAA
batteries with the + and - ends ali ned
correctly.
Two “AAA ” batteries
(supplied).
8
Identification of Controls
!#
*&
^
@$
%
! POWER CORD
It is a jack for supplyin power to the unit.
Connect to outlet in a wall.
@ EURO AV2/DECODER Jack
# VIDEO OUTPUT Jack
$ AUDIO OUTPUT Jack
% DIGITAL OUTPUT (OPTICAL/COAXIAL) Jack
To enjoy sound quality of theatre level in home,
connect this jack with amp or unit embedded
with di ital audio decoder.
^ Connection to ANTENNA Cable
& Connection to TV
* EURO AV1 Jack
Main body (Rear Panel)
✔ Disposal of sed Electrical &Electronic Equipment
The meaning of the symbol on the product, its accessory or packaging indicates that
thisproduct shall not be treated as household waste. Please, dispose of this equipment at your
applicable collection point for the recycling of electrical & electronic equipments waste. n the
European Union and Other European countries which there are separate collection systems
for used electrical and electronic product. By ensuring the correct disposal of this product,
you will help prevent potentially hazardous to the environment and to human health, which
could otherwise be caused by unsuitable waste handling of this product. The recycling of
materials will help conserve natural resources. Please do not therefore dispose of your old
electrical and electronic equipment with your household waste. For more detailed
information about recycling of this product, please contact your local city office, your
household waste disposal service or the shop where you purchased the product.

Installation
1110
Setting up your player
With this connection if your player is receiving CH ARD and your TV is displaying CH3 when you press the
[TV/VCR] button on the remote control your TV will automatically display the CH ARD. “VCR” will be
displayed.
In this mode to change the viewing channels the [PR-] and [PR+] buttons on the player remote need to be used.
To switch off this mode press [TV/VCR] on the remote control TV remote can now be used as normal. You will
get better pictures and sound quality if you connect your player with a scart lead.
■Before you start unplug all the equipment from the mains supply.
Televisi n
Aerial
The type of aerial you
should use depends on
local interference and how
far you are from the
transmitter. You should
contact a local retailer if you
have any questions about
your aerial.
Back view f y ur player
200-240V~,
50/60 Hz
Televisi n
Aerial
Back view f y ur player
200-240V~,
50/60 Hz
Scart lead (n t supplied)
(Option 1) - Connecting your player through RF lead
(Option 2) - Connecting your player through a scart lead
Remote Control
!
#
@
$
%
^
&
(
)
2
4
5
7
9
“
#
‘
=
q
w
eR
r
T
Y
0
+
E
y
W
Q
*
3
1
6
8
!
[DVD] OPEN/CLOSE butt n, [VCR] EJECT butt n
@ VCR SELECT butt n
#
[DVD, VCR] NUMBER butt n, [VCR] TRACKING -/+
butt n
$ SYSTEM butt n (This butt n is n t available f r this set)
% SETUP butt n
^
[DVD, VCR] MOVE/SELECT in OSD, [VCR] Channel
Up/D wn butt n
&
[DVD] TITLE /PBC butt n
*
[DVD] AUDIO LANGUAGE Select, [VCR] AUDIO Select
butt n
(
[DVD] SUBTITLE Select butt n
) REVERSE SEARCH butt n
1 PLAY/PAUSE butt n
2
[DVD] PREVIOUS butt n (m ve int a previ us chapter
r track)
3
[VCR] Rec rd SPEED butt n
4
[VCR] Rec rd butt n
5
[VCR] TV/VCR butt n
6
[DVD] 3D butt n
7
[VCR] CM SKIP
8
[VCR] Replay butt n
9 POWER butt n
0 DVD SELECT butt n
“
[VCR] INPUT Selecti n butt n
‘ CLEAR butt n
+
[DVD, VCR] OSD DISPLAY butt n
= OK/ENTER butt n
Q
[DVD] MENU butt n
q
[DVD] Chapter/Title/Time SEARCH butt n
W
[DVD] ZOOM butt n
w FORWARD SEARCH butt n
E STOP butt n
e
[DVD] NEXT butt n (M ve int a next chapter r track) ,
[VCR] Frame Advance butt n in pause m de
R
[DVD] REPEAT Playback butt n
r
[DVD] REPEAT a defined peri d fr m A t B butt n
T
[DVD] ANGLE butt n
[DVD] MARK butt n
Y
[VCR] PROGRAM butt n
y
[VCR] LAST CHANNEL butt n (Return t the previ us
channel which was being watched.)
Press the power [ ] button of the remote for about
5 seconds. No buttons of front panel can be operated
now and Lock indicator (“ ”) will be
displa ed on window displa . To release child lock,
press an button of the remote control.
P WER N
Pla er will be POWER ON if an button of the
remote control is pressed.
Child Lock !

Installation
1312
Connecting your player to the Hi-Fi system
■Before you start unplug all the equipment from the mains supply.
Televisi n
Plug a phone cable into the
“Audio L/R” sockets on the
back panel and into the audio
sockets on any audio
amplifier if needed. If your
player does not have this
connection see page 15.
Player
200-240V~,
50/60 Hz
Y u can als use a scart lead t impr ve picture and s und quality fr m y ur player.
Hi-Fi
Aerial
Televisi n
Plug a scart to phone cable into
the “AV1” socket on the back
panel and into the audio socket
on any audio amplifier if
needed.
Player
200-240V~,
50/60 Hz
Hi-Fi
Aerial
Option 1
Option 2
Connecting your player through
extra equipment (satellite system)
■Before you start unplug all the equipment from the mains supply.
Televisi n
Aerial
Back view f y ur player
200-240V~,
50/60 Hz
You can use this connection if your player has two scart sockets. This will improve sound and picture quality
when you are recording from satellite.
Satellite
(Option 1) - Connecting your player through RF lead

Installation
1514
Connecting Dolby Digital Amp with
Digital Audio Out Jack
(L) AUDIO IN (R)
1
1Select either COAXIAL r OPTICAL t c nnect t amp f D lby Digital.
** If y u want t kn w ab ut “D lby Digital”, please refer t [Ab ut DVD] in 54-56p.
Home Theater Receiver with Dolby Digital decoding capability
REAR PANEL OF DVD-VIDEO
CONNECTING CABLE
(Not supplied)
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
How to connect
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems Inc.
How to connect your player to another player
■Before you start unplug all the equipment from the mains supply.
First player
Sec nd player
200-240V~,
50/60 Hz
1) Insert the tape you wish to record on into the first player and press [INPUT] until “AV1” appears on the front
display.
2) Insert the tape you wish to copy from into the second player. Press the [PLAY] button on the second player.
3) Press the [RECORD] button on the first player.
The player will start recording.
If y ur player has tw scart s ckets, y u can use the ther s cket “AV2” t c nnect ther equipment.
T use this functi n, see page 16.
How to connect your player to a camcorder
■Before you start unplug all the equipment from the mains supply.
If y u have c nnected y ur camc rder in this way, y u can als c nnect a scart lead fr m “AV2” n the
back panel f the player t the televisi n. T use this functi n, see page 16.
You can also connect the camcorder by using a phone cable if your player has front input sockets.
Check the front of your player for this connection see page 16.
Camc rder
Aerial
200-240V~,
50/60 Hz
Televisi n
Player
to
camcorder
Scart Plug
t TV
How to connect
How to connect

Basic Operation
1716
Initial Installation
■Switch the TV on.
■You can also start "AUTO SET" in the SETUP "PR PRESET"
➝ "AUTO SET".
■To tune in new stations (manual tuning) and to enter station names see page 24-25.
LANGUAGE SET
ENGLISH
DEUTSCH
ITALIANO
ESPAÑOL
FRANÇAIS
NEDERLANDS
PR+/-:SELECT
OK:CONFIRM SETUP:END
COUNTRY SET
BN
DNL
DK S
ESF
GR CH
ITR
LUX OTHERS
PR+/-:SELECT
OK:CONFIRM SETUP:END
SETUP:END
PLEASE WAIT...
CH 25
RF OUTPUT SET
0-9:SELECT(21-69)
OK:CONFIRM SETUP:END
CURRENT CH 52
RECOMMENDED CH 54
You should see this picture the first time you switch on the TV
and player.
Ch se y ur language.
1
Then choose your country.
For selecting the country refer to the followings.
2
OK f r "AUTO SET!".
"AUTO SET" tunes in all the stations you can receive in your
country.
Clock is automatically set.
3
If other stations are positioned on near the current RF OUTPUT
CH the guide message appears automatically.
The player recommends the optimal RF OUTPUT CH number
automatically.
4
B: Belgium
D: Germany
DK: Denmark
E: Spain
GR: Greece
I: Italy
LUX: Luxembourg
N: Norway
NL: Netherlands
S: Sweden
SF: Finland
CH: Switzerland
TR: Turkey
Press the [OK] button to confirm the recommended PR.
Should you wish the stations to have the same numbers as those
used on the TV follow the instructions in "Sorting programme
locations" on page 25.
Else ...
exit the basic installation function and enjoy your player.
5
PLEASE CHANGE THE TV
CH TO 54.
IMPORTANT!
MANUAL SET
PR01 ARD PR08 P-08
PR02 ZDF PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 MTV PR12 ----
PR06 P-06 PR13 ----
PR07 P-07 PR14 ----
PR+/-:SELECT
OK:CONFIRM SETUP:END
• If you don´t see this picture because you don´t use a SCART cable
search this picture now (CH 52) with the station tuning functions of
your TV set (see its user manual).
• In case of interference problems on CH 52 type in an
other transmission channel between 21 and 69 using
the number buttons.
Setting up the player
2nd scart socket
If your video has the AV2 output shown in the diagram below you can connect other equipment as seen on
pages 12-15.
2nd scart INPUT ONLY
INPUT+OUTPUT
When connecting other equipment please refer to their manuals for further information. This video manual
recommends the set up as shown on page 12. When connected by this method if the equipment is turned off the
video behaves as normal but if the equipment is turned on the video will automatically switch over to AV2
mode and displays the channel of the other equipment channel selection can only be performed by the other
equipment the video PR+/PR- buttons have no effect.
To return to normal video use the other equipment must be turned off.
Rec rding fr m ther Equipment.
Simple recording can be performed ensure the equipment is turned on and is displaying the correct channel.
Timer recording set the video to perform a timed recording ensuring AV1 is selected as the channel to be
recorded. Some equipment may have a timer which allows it to be powered on to the correct channel if this
feature is not available the other equipment should be left powered on.
Fr nt AV
If the video has front input sockets it is possible to connect devices such as a
camcorder to the video. To watch a camcorder tape the video must be in
AVF mode. Recordings of this input are the same as described on page 14.
2nd scart socket

Basic Operation
1918
OSD ON & OFF
Output Select
Press [DVD] butt n.
If DVD mode is correctly selected DVD on the operation display
window is lit. Then REMOTE button works as DVD function. Press the
[DVD] button then the mode of DVD-Video Player becomes to the
OPERATION mode.
Press [VCR] butt n.
If VCR mode is correctly selected DVD on the operation display
window goes out. Then REMOTE button works as VCR function. Press
the [VCR] button then it becomes to the VCR OPERATION mode.
Press [INPUT] butt n.
When you press [INPUT] button BROADCASTING RECEPTION and EXTERNAL INPUT is selected. But it
is not operated in PLAY REC and DVD mode.
Call the player’s "SETUP".
1
Choose “VCR SETUP”.
And press the [OK] button.
2
Select “OSD ON/OFF”.
If you want OSD OFF mode select it and press [OK] button to
confirm.
Then OSD characters are not displayed in the normal picture.
3
This player is set to “OSD (On Screen Display) ON” mode before shipping and you can change it
to OFF mode.
VCR SETUP
CLOCK SET
LANGUAGE SET
RF OUTPUT SET
16:9 SET
OSD ON/OFF
AUTO CLOCK
PR+/-:SELECT
OK:CONFIRM SETUP:END
OSD ON/OFF
ON
OFF
PR+/-:SELECT
OK:CONFIRM SETUP:END
SETUP
TIMER PROGRAM
PR PRESET
VCR SETUP
TAPE CONTROL
PR+/-:SELECT
OK:CONFIRM SETUP:END
OSD (On Screen Display) ON & OFF
To Select DVD
To Select VCR
To Select Watch Modes or External Input
■Press [VCR] button on the remote control to change into VCR Mode and follow the procedure
below.
Call the player’s "SETUP"
choose "VCR SETUP" then "CLOCK SET".
1
Move to the position you want to change and type in the
new values.
Wait a few seconds after typing a one-digit number.
2
Store with [OK] button and exit with [SETUP] button.
CLOCK SET
0-9:SETUP (HOUR)
/➝:CORRECT SETUP:END
TIME - - : - -
DATE - - / - - /- - - -
CLOCK SET
0-9:SETUP (HOUR)
/➝:CORRECT
OK:CONFIRM SETUP:END
TIME 06:05
DATE 08/08/2004(SUN)
Setting time and date
Auto clock
■Auto Clock is only available for models with the VPS/PDC function (see page 26).
Some broadcasting stations may send the time and date along with the VPS/PDC data. The video will
automatically use this time and date during the initial setting up procedure during normal use and every
time you switch the video off at the mains. If you find that this time and date is incorrect you can remove
this feature by following the steps below changing it to OFF mode you will then have to manually set the
time and date see above.
AUTO CLOCK
ON
OFF
PR+/-:SELECT
OK:CONFIRM SETUP:END
VCR SETUP
CLOCK SET
LANGUAGE SET
RF OUTPUT SET
16:9 SET
OSD ON/OFF
AUTO CLOCK
PR+/-:SELECT
OK:CONFIRM SETUP:END
Setting time and date
Setting Auto clock
➝
➝

Basic Operation
2120
VCR Playback
Press [ ] butt n t p wer n.
Press [VCR] button of remote control to change into VCR mode.
Insert the desired tape.
If y u want t playback it, press [PLAY/PAUSE] butt n.
When the operational status is flickering or poor adjust it with [TRACKING
+/-] button.
1
2
3
T st p it, press [ ] butt n.
For pause press [PLAY/PAUSE] button in playback mode.
If you press this button once more it starts playback again.
4
Press [EJECT] butt n in the fr nt part r [OPEN/CLOSE] butt n n rem te
c ntr l t rem ve the tape.
5
If the product, which
has a auto-detector,
detects a contaminated
head(s), it shows the
conditions to notice the
contamination on
screen.
* In case of the notice
on screen, please rub
the heads with a head-
cleaner followed b
“How to use a head-
cleaner”.
Vari us Playback Meth ds
■If y u want fast f rward ( r reverse) playback press [√√√√] or [œœœœ ] button in
Playback mode. You can watch fast playing (rewinding) screen.
* NOTE: You might see no color noise band when you fast forward (or reverse)
playback the tape which is recorded in LP mode.
■If y u want Still picture press [PLAY/PAUSE] in Playback mode. You can watch
the desired screen in pause status.
■If y u want sl w-m ti n playback press [√√√√] button in Pause mode. You can
watch the desired screen in the slow forward playback.
* NOTE: VCR doesn’t have Slow Reverse Pla back function.
■If y u want t watch a series f screens ne by ne (FRAME ADVANCE) press
[NEXT √√√√❚ ] button in Pause mode. Each time you press this button the picture
advances one frame.
■If y u press [REPLAY] butt n in playback m de, the player quickly rewinds 15
seconds of the tape and plays it.
■If y u press [CM SKIP] butt n in playback m de, the player quickly skips 30
seconds of the tape and plays it.
T Adjust Display
This product includes automatic Tracking function and enables users to enjoy clear
picture without an additional operation. Provided that the following problems can be
solved by the manual adjustment which improves display quality. (During automatic
display adjustment “Adjusting Display” are displayed on TV screen.)
- If the screen is p r in Playback m de,
- If n ises ccur in the upper r l wer part f screen in sl w playback m de,
-If paused picture vibrates up and d wn.
Use [TRACKING +/-] buttons of remote control to adjust the display suitable for watching.
DVD Playback
Press [ ] butt n t p wer n.
Press [DVD] button of REMOTE to change into DVD mode.
Press [OPEN/CLOSE] butt n t pen the disc tray.
Place a disc firmly on the disc tray making its label look upward.
Insert the disc and press [OPEN/CLOSE] butt n t cl se the tray.
The disc tray is closed and after checking the disc’s condition Playback or Stop
function starts to operate.
1
2
3
T playback it, press [PLAY/PAUSE] butt n.
• In the case f DVD,
DVD menus and titles are displayed on TV screen.
• In the case f S-VCD and VCD2.0
the menus are displayed on TV screen and it is converted into PBC(Playback
Control) mode.
• In the case f CD, VCD1.1, MP3, DivX and JPG
the disc plays.
4
T st p it, press [ ] butt n.
For pause press [PLAY/PAUSE] button in playback mode.
If you press this button once more it starts playback again.
5
Press [OPEN/CLOSE] butt n t rem ve the disc.
6
Vari us Playback Meth ds
■If y u want fast f rward ( r reverse) playback press [√√√√] or [œœœœ ]button in
Playback mode. You can watch fast playing (reverse ) screen.
* This reverse playback can be unavailable for certain DVD.
■If y u want sl w ( r reverse) playback press [√√√√] or [œœœœ ] button in Pause mode.
You can watch the desired screen in the slow forward (reverse) playback.
* For the case of VCD and DivX this reverse slow playback function is unavailable.
The mark will appear.
■If you want still picture press [PAUSE] button in Playback mode. You can watch
the desired screen in Pause status.

Basic Operation
2322
Recording
“This product incorporates copyright protection technology that is protected by
U.S patents and other intellectual property rights.
Use of this copyright protection technology must be authorized by Macrovision
and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disassembly is prohibited.”
■When your urgent business happens suddenly in watching TV or you want to record the current TV
program for the desired time follow the procedures below.
1
1Insert the desired DVD disc.
When it is a DVD disc with copy protect function you can’t copy it.
Insert a rec rdable tape.
2
2Press [REC] butt n during playing f DVD.
DVD plays and VCR starts recording.
3
3If y u press STOP [ ] butt n in DVD m de, DVD and VCR will st p at the
same time.
If y u press STOP [ ] butt n in VCR m de, VCR st ps t rec rd and DVD
c ntinues t play.
1
1First, f ll w the steps 1 t 4 in “Rec rding With VCR”.
2
2Press [REC] butt n as much as y u want. See the “Rec rding Times Table”
bel w.
Once continuous recording until you press STOP button
Twice recording for 30 mins from current time
3 (times) recording for 1 hour
21 recording for 10 hours
22 returning to the status of Once Press
3
3T st p Rec rding m de, press [STOP] butt n m re than 5 sec nds.
To Copy From DVD To Videotape
One Touch timer Recording (OTR)
1
1If y u want t playback DVD during rec rding with vide , insert a DVD disc.
Place the desired DVD disc on DVD tray press [DVD] button to convert OUTPUT
into DVD mode and press [PLAY] button. Then you can watch DVD.
2
2If y u want t watch a TV channel during DVD rec rding with vide , press
[VCR] butt n t c nvert OUTPUT int VCR m de and press [PR+/-] butt n.
Then you can watch a TV channel.
Press [ ] butt n t p wer n.
• Press [VCR] button of remote control to change into VCR mode.
Insert a rec rdable tape.
Insert a tape with recording tab.
With [CHANNEL], [NUMBER] and [INPUT] butt ns, select the desired
br adcasting channel r external input unit t rec rd.
1
2
3
Select the desired speed (SP r LP) with [SPEED] butt n.
4
Press [REC] butt n.
Then it starts recording.
5
If y u want t pause rec rding, press [PAUSE] butt n.
After pressing [PAUSE] button if the pause status continues for five minutes
the recording is released automatically.
6
T exit rec rding, press [STOP] butt n.
7
Recording
To Record With VCR
To Enjoy a TV Channel or DVD during recording

VCR Operation
2524
■If your player is showing no station name or is showing a station name incorrectly you can correct
this.
Call this menu (just see the previous page)
if it isn't displayed.
Select NAME position.
Press the [0] button to change the given name.
Or press the [1] button to create the station name.
1
Either select the name from the stored list or you
create the station name and enter a 4-digit name.
Change the letters with the [PR +/–] buttons
move to the next letter with the [œœ /√√ ] buttons.
2
Store and exit.
3
MANUAL SET
PR+/-:SELECT
OK:CONFIRM SETUP:END
PR01 ARD PR08 P-08
PR02 ZDF PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 MTV PR12 ----
PR06 P-06 PR13 ----
PR07 P-07 PR14 ----
MANUAL SET
PR+/-: UP/DOWN
0/1: CHANGE/CREATE
OK:CONFIRM SETUP:END
PR 01
RECEPTION AERIAL
AUTOSEARCH CH01
FINE TUNING
DECODER ON
NAME
_ _ _ _
MANUAL SET
PR+/-: SELECT CHARACTER
/➝: SELECT POSITION
OK:CONFIRM SETUP:END
PR 01
RECEPTION AERIAL
AUTOSEARCH CH
_ _
FINE TUNING
DECODER ON
NAME O _ _ _
If the location numbers used for programmes stored in your TV and player are different you can change them on
the player. To do this move the stations to the right numbers until they are arranged the way you want.
1
1Call the player’s "SETUP"
choose "PR PRESET" then "PR ALIGN".
2
2Select the programme to swap.
Confirm by pressing OK button.
Move the station to the desired location number.
Confirm by pressing OK button.
1
1Call the player’s "SETUP"
choose "PR PRESET" then "PR ERASE".
2
2Select the station (location number) you want to clear.
Review the picture by pressing [œœ ] button.
Clear by pressing OK button.
PR ERASE
PR+/-:SELECT
:PR VIEW
OK:ERASE SETUP:END
PR ALIGN
PR+/-:ALIGN
:PR VIEW
OK:CONFIRM SETUP:END
PR01ARD PR08 P-08
PR02 ZDF PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 MTV PR12 ----
PR06 P-06 PR13 ----
PR07 P-07 PR14 ----
PR01 ARD PR08 P-08
PR02 ZDF PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 MTV PR12 ----
PR06 P-06 PR13 ----
PR07 P-07 PR14 ----
Tuning in New Stations
Station names
Sorting programme locations
Clearing programme locations
➝
➝
➝
Tuning in New Stations
■The TV and player are switched on.
■To see the picture from your player press the input or AV (Audio/Video) button on the TV.
To complete the set-up of your video recorder when the
auto set has not stored all of the channels or when you wish
to store a new channel.
Call the video’s "SETUP" choose "PR PRESET".
1
Select "MANUAL SET".
2
Choose any unused location number "----" or "P-xx" ...
It's simplest to use the same location number on both the
TV and video.
... and confirm.
3
Set the station you want:
• the programme location number;
• the broadcast system you want (Aerial(CH) or
Cable(CC))
• You can directly enter the real channel number with the
[0 to 9] buttons or search by pressing [œœ /√√ ]
• The fine tuning you can adjust
• When the program is encoded (and you have a decoder
connected to socket EURO AV2) press the [œœ or √√ ] to
select ON or OFF.
• Change or create the station name.
4
Once you see the station you want store it.
Tune in further stations (from step 3 onwards) or exit
tuning mode.
5
PR PRESET
AUTO SET
MANUAL SET
PR ERASE
PR ALIGN
PR+/-:SELECT
OK:CONFIRM SETUP:END
MANUAL SET
PR+/-: UP/DOWN
/➝: SELECT
OK:CONFIRM SETUP:END
MANUAL SET
PR01 ARD PR08 P-08
PR02 ZDF PR09 P-09
PR03 P-03 PR10 P-10
PR04 P-04 PR11 P-11
PR05 MTV PR12 ----
PR06 P-06 PR13 ----
PR07 P-07 PR14 ----
PR+/-:SELECT
OK:CONFIRM SETUP:END
PR 04
RECEPTION AERIAL
AUTOSEARCH CH _ _
FINE TUNING
DECODER ON
NAME _ _ _ _
MANUAL SET
PR+/-: UP/DOWN
/➝: SELECT
OK:CONFIRM SETUP:END
PR 03
RECEPTION AERIAL
AUTOSEARCH CH 03
FINE TUNING
DECODER ON
NAME
_ _ _ _
MANUAL SET
PR+/-: UP/DOWN
0/1: CHANGE/CREATE
OK:CONFIRM SETUP:END
PR 03
RECEPTION AERIAL
AUTOSEARCH CH _ _
FINE TUNING
DECODER ON
NAME
_ _ _ _
Tuning
➝
➝

VCR Operation
2726
Timer Recording
■For timer recordings clock date and stations must be set correctly.
■Load a cassette with its safety tab in place and with sufficient free space for the recording.
Call the player’s "SETUP" choose "TIMER PROGRAM".
Decide if you want to record "ONCE" "WEEKLY" or
"DAILY"...
... and confirm.
1
Type in one after the other:
• The programme location number;
• the time the broadcast starts
• the time the broadcast ends
• the day of the broadcast if it is not today.
• Select LP if you wish to make a very long recording .
• Switch off VPS/PDC here if you need to .
2
If you wish to make changes:
Move to the position you want to change using the [
œœ
/
√√ ]
buttons. Change the setting using the [PR+/- ] or [number]
buttons.
If all setting are ok press [
œœ
or √√] till you see “OK :
CONFIRM” in the bottom line.
Confirm.
3
Switch y ur player ff.
• Wait a few seconds after typing a one-digit-number.
• If you have made a mistake move to the position you want to change using the [
œœ
/
√√
] buttons
and change the setting.
• If programme timings overlap the machine will give a warning message. If you don’t adjust
the times the machine will record the first programme completely then continue with the
second one.
• If there is no sufficient free space for the recording on the cassette the video switches
automatically to “LP” for double recording capacity.
• The recorder will eject cassettes which have the safety tab removed.
• The player will be powered on and record the program at the set time.
• In case the player is powered on after setting of timer recording the player cannot record in
VCR mode but can record in DVD mode.
PR+/-:SELECT(AV1/AV2)
0-9 :SETUP(PR)
/➝:CORRECT SETUP:END
PR --
START TIME --:--
END TIME --:--
START DATE --/--
TAPE SPEED SP
VPS/PDC ON
TIMER PROGRAM (ONCE)
PR 01
START TIME 18:10
END TIME 20:30
START DATE 22/08(FRI)
TAPE SPEED LP
VPS/PDC ON
PR+/-:SELECT(AV1/AV2)
0-9 : SETUP (PR)
/➝:CORRECT
OK:CONFIRM SETUP:END
TIMER PROGRAM (ONCE)
HOW OFTEN DO YOU WANT
TO RECORD THIS PROGRAM?
PR+/-:SELECT
OK:CONFIRM SETUP:END
ONCE
WEEKLY(ONCE A WEEK)
DAILY(MON-FRI)
DAILY(MON-SAT)
DAILY(MON-SUN)
Normal timer recording
➝
➝
Timer Recording
■For timer recordings clock date and stations must be set correctly.
■Load a cassette with its safety tab in place and with sufficient free space for the recording.
Call the ShowView menu by pressing PROGRAM on the
remote control.
From your TV magazine type in the number next to the
programme you want to record ...
... and confirm.
1
Decide if you want to record "ONCE" "WEEKLY" or "DAILY"...
... and confirm.
2
If you wish to make changes:
Move to the position you want to change using the [
œœ
/
√√]
buttons.
Change the setting using the [
……
/
††
] or [number] buttons. If all
setting are ok press [OK] till you see “OK: CONFIRM” in the
bottom line.
Confirm.
3
Switch y ur player ff.
0-9:SHOWVIEW NUMBER
:CORRECT
OK:CONFIRM SETUP:END
SHOWVIEW
83077----
HOW OFTEN DO YOU WANT
TO RECORD THIS PROGRAM?
PR+/-:SELECT
OK:CONFIRM SETUP:END
TIMER PROGRAM (ONCE)
PR 03
START TIME 21:20
END TIME 22:20
START DATE 14/08(SAT)
TAPE SPEED SP
VPS/PDC ON
PR+/-:SELECT (AV1/AV2)
0-9 : SETUP (PR)
/➝:CORRECT
OK:CONFIRM SETUP:END
ONCE
WEEKLY(ONCE A WEEK)
DAILY(MON-FRI)
DAILY(MON-SAT)
DAILY(MON-SUN)
Timer recording using ShowView
• VPS/PDC is a service provided by some stations to enable you to perform timer recordings
precisely even if the broadcaster delays the start time of the programme slightly. The time you
enter is the VPS/PDC time so must be correct. Not all stations offer VPS/PDC in which case the
player will start at the time you enter and not the actual start time of the programme.
If you wish to start recording at a specific time without it being adjusted by the VPS/PDC
system in the event of a delay switch VPS/PDC off otherwise the player will not record.
• If you don’t have the ShowView numbers see next page for the normal timer.
• If you have made a mistake move back to the relevant position with the [
œœ
] button and change
the setting.
• If there is no programme location displayed under “PR” in the change menu the player doesn’t
yet know the location number for the programme you want. Type it in and this will be stored
for last recordings.
• If you wish to record from a satellite receiver select under “PR” the satellite programme
location or AV (1/2) (depending on the connection with the antenna cable or the SCART-cable).
Leave the satellite tuner switched on and to the programme you want.
• Should programming overlap you get a warning.
• To cancel the recording press the button (stop) more than 5 seconds.
• ShowView is a trademark applied for by Gemstar Development Corp.. The ShowView system is
manufactured under license from Gemstar Development Corporation.
➝
➝

VCR Operation
2928
More Functions
■The counter counts in real time from the point you load the cassette. This does not have to be its
beginning! The counter does not count unrecorded parts of the tape.
■If you rewind beyond the zero position the counter counts in negative values (e.g. – 0:01:15).
Each time you press [DISPLAY] button
1x: Time and date+current status ➝ Time and date
2x: Counter+current status ➝ counter
3x: disappear.
• If didn’t wind tape (PLAY FF REW ...) it doesn’t appear the tape remain time.
• In case that the timer recording information is inputted in the received broadcasting signal press the button
to display the VPS/PDC icon.
STOP SP PR01 ARD
14:00 10/08 E180 00:48
STEREO ON
V
When you want the player to show the time remaining from the current player tape position (to find out if
there is sufficient space for a recording for example).
To ensure the remaining time shown is accurate select the length of cassette currently loaded by selecting
this function until you reach the correct length.
Call the player’s "SETUP"
choose "TAPE CONTROL"
• Remaining time display is
only possible when the
cassette is loaded.
TAPE CONTROL TAPE REMAIN
E-240 01:27
TAPE REMAIN
GO TO ZERO
COUNTER RESET
INDEX+
INDEX-
E-180
E-240
E-300
PR+/-:SELECT
OK:CONFIRM SETUP:END
PR+/-:SELECT
OK:CONFIRM SETUP:END
When you record a program the VCR places an index mark at the start of
the recording.
To search fo an index mark
1. Call the player’s "SETUP" choose "TAPE CONTROL"
2. Choose index + to search forward or index - to search backward.
The VCR will locate your index mark and begin playback.
TAPE CONTROL
TAPE REMAIN
GO TO ZERO
COUNTER RESET
INDEX+
INDEX-
PR+/- :SELECT
OK:CONFIRM SETUP:END
Clock / counter display
Remaining time and cassette length
Searching a recorded program with index
Timer Recording
Call the player’s "SETUP"
choose "TIMER PROGRAM".
1
Select the programming to change or erase.
If you want to erase this programming press
button [0] confirm with OK.
If you wish to make changes:
Move to the position you want to change using the
[
œœ
/
√√
] buttons.
Change the settings using the [PR +/–] or
[number] buttons.
If all settings are ok press [
œœ
or √√ ] until you see
"OK: CONFIRM" in the bottom line.
Confirm changes with [OK]. Exit the menus.
2
TIMER PROGRAM
PR START END DATE
03 21:20 22:20 16/08
01 18:10 20:30 22/08
-- -- : -- -- : -- -- / --
-- -- : -- -- : -- -- / --
-- -- : -- -- : -- -- / --
-- -- : -- -- : -- -- / --
-- -- : -- -- : -- -- / --
-- -- : -- -- : -- -- / --
PR+/-:SELECT
OK:CONFIRM SETUP:END
TIMER PROGRAM (ONCE)
PR 03
START TIME 21:20
END TIME 22:20
START DATE 16/08(SAT)
TAPE SPEED SP
VPS/PDC ON
0 :ERASE
/➝:CORRECT SETUP:END
Timer Review – changing and erasing
➝

VCR Operation
3130
Dimmer : Your player dims its display when switched to stand-by mode.
Aut p wer ff : Your player switches to stand-by when no tape is played and no station is received for more
than 5 minutes.
Press the [ ] button for about 5 seconds.
No buttons of front panel can be operated now and LOCK INDICATOR (“ ”)
will be displayed on window display. Keep your remote control in a safe place.
To release child lock press any button of the remote control.
Use only good quality tape cassettes with the VHS logo.
•Keep cassettes away from excessive moisture or dust magnetic and electrical fields
(loud speakers and computer monitors for example).
•Always wind the tape to the beginning when you have finished. Store with the full
spool at the bottom and with the cassette in its cover.
You can protect your precious recordings from being wiped by breaking out the safety
tab on the side of the cassette (some cassettes have a slide). Should you wish to re-use
the tape after removing the tab cover the hole with adhesive tape.
PAL
More Functions
Cassettes
and
Child lock
The player will wind to the position 0:00:00 and stop.
REW SP
GO TO ZERO
0:02:13
Reset the counter.
COUNTER RESET
0:00:00
You can play and record the program of 16:9 Wide-Screen format with this player .
• 16:9 Set
-Auto : This video automatically detects the program format (16:9 or 4:3) and
records or plays this program in the same format.
-ON : The video will play or record all broadcasts in 16:9 format. 4:3 broadcasts will
be converted to 16:9 format.
-OFF : The video will play or record all broadcasts in 4:3 format only.
VCR SETUP
CLOCK SET
LANGUAGE SET
RF OUTPUT SET
16:9 SET
OSD ON/OFF
AUTO CLOCK
PR+/-:SELECT
OK:CONFIRM SETUP:END
16:9 SET
AUTO
OFF
ON
PR+/-:SELECT
OK:CONFIRM SETUP:END
• If you watch a program which is recorded by 16:9 wide screen format with
this player your TV must have 16:9 wide screen function and you have to
connect TV and player with the A/V scart.
If you press the [PLAY] button for 5secs during stop or still mode it goes Auto repeat mode. This player plays
repeatedly the tape from the beginning to end parts.
To release this mode press the [ ] button or mode operation button. (PLAY FF REW or STOP)
Call the player’s "SETUP" choose
"VCR SETUP" then "LANGUAGE SET".
Select your language.
Confirm.
LANGUAGE SET
PR+/-:SELECT
OK:CONFIRM SETUP:END
More Functions
ENGLISH
DEUTSCH
ITALIANO
ESPAÑOL
FRANÇAIS
NEDERLANDS
Accessing counter zero position
Resetting the counter to zero
16 : 9 Wide Screen Format Playing back / Recording
AUTO REPEAT
SETUP languages

VCR Operation
3332
Connections and Copying
■If you are using a SCART cable select the AV input on the TV to see the picture from the player.
■If you are not using a SCART cable select the button number on the TV reserved for video input to
see the picture from the player.
If you are not using a SCART cable your player can transmit pictures and sound to the TV via the coax aerial
cable. Just tune the TV to the player's transmitting channel (factory set to UHF CH 52). Tune the TV carefully to
ensure the best pictures and sound.
Once you have carried out the steps in "Connecting up the player"
switch on your TV.
Press the [ENTER] button of the player’s remote control longer than 5
seconds to call the player´s test picture.
Tune the TV to the test picture using the channel pre-set functions of
your TV as described in its manual.
When you have found the test picture store it under the button
number on your TV for player input.
Press the [ENTER] button of the player’s remote control again longer
than 5 seconds to release the test picture.
1
• If the quality of the test picture transmitted to the TV is poor due to
interference caused by a station transmitting on channel 52 you can
tune the player to a different transmitting channel. Find a free
channel between 21 and 69 on your TV.
Call the player’s "SETUP" choose "VCR SETUP" then "RF
OUTPUT SET".
Type in the free channel.
Store and exit.
2
• If the quality of the test picture transmitted to the TV is poor fine-tuning on the TV
may help (refer to the TV manual).
• Without a scart cable you will not get stereo sound from a TV capable of stereo sound.
RF OUTPUT SET
0-9:SELECT (21-69)
OK:CONFIRM SETUP:END
CH 52
To the TV via antenna cable (if you are not using a SCART cable)
■The player machine records the complete sound signal transmitted by the TV station.
■On the mono VCR you will hear the normal mono sound.
In addition to the normal mono sound track of VHS video recorders your player machine is equipped with a
high-quality Hi-Fi sound system.
This means you can enjoy
• films with excellent stereo sound
• films of full-length concerts in high quality stereo
• films with impressive Surround Sound using additional Surround equipment
• films with two dialogue modes (dual bilingual) usually the original sound track and dubbed sound track
• VHS cassettes with Hi-Fi stereo sound and VHS cassette with normal sound
During Stop the player displays what the current station is broadcasting. When
you switch to another station or the current station changes the sound mode your
player displays the programme and sound mode on screen (if not press AUDIO).
• “STEREO” = stereo
“BIL I / BIL II ”=bilingual
nothing= monaural sound
During Playback the player displays what is recorded on
the cassette (if not press AUDIO).
• “Hi-Fi” = stereo/bilingual
nothing = monaural sound
STOP SP PR10 EURO
STEREO ON
PLAY SP Hi-Fi
L+R
During a stereo performance (playback-”Hi-Fi”/ broadcast
- “STEREO”):
Hi-Fi stereo ➝ left audio channel only ➝ right channel
only ➝ the normal mono sound track of a Hi-Fi cassette
• During broadcasting a bilingual performance : Main
language (original sound track) ➝ sub-language
(dubbed) ➝ both main language and sub-language.
• For mono performances there is no choice available.
PLAY SP Hi-Fi
L+R
HI-Fi
LEFT
Hi-Fi
RIGHT
Hi-Fi
OFF
More Functions
STOP SP PR10 EURO
BIL
I
BIL
II
BIL
I+II
The Hi-Fi system
What you can listen to
Choice of sound output

DVD Operation
3534
T m ve t next chapter ( r track), press [ √√
❚
NEXT] butt n.
The current chapter (or track) moves to the next chapter (or track).
Press [
❚
œœ PREV] butt n.
The current scene moves to the previous chapter (or track) or first scene of current
chapter (or track).
Press the [TITLE/PBC] r [MENU] butt n.
A list of the titles on the disc is displayed.
* For the case of VCD disc menu screen will
appear only when the disc has PBC function
and PBC ON is activated.
1
Press the [ENTER] butt n r [PLAY] butt n
after pressing the [ œ √…† ] butt n t select
the desired title.
For the case of VCD disc press the [Number]
button.
The selected title now starts playing.
2
■ Some movie discs may contain multiple titles. If the disc has a movie title menu recorded on it the [TITLE/PBC] or
[MENU] button can be used to select the movie title. Details of operation may differ depending on the disc used.
* Selecting a title ma not be available on certain DVD discs.
Playing a desired scene
To skip scenes in a disc
Directly moving to a desired title
Connections and Copying
■Switch off all components when connecting or disconnecting cables.
To copy to your player from another video
machine connect the two machines with a cable
between their EURO AV (SCART) sockets and
select as programme "AV 1/AV 2" or “F. AV”
(front sockets) using the [AV] [PR+/-] or [INPUT]
button.
Set the other video machine to playback and your
machine to record.
•To connect a mono audio source use the front
Audio In socket marked L.
To copy to another video machine from your
player connect the two machines by means of
their EURO AV (SCART) sockets.
On the other video select its AV input and set the
machine to record.
Switch your player to play back at the position you
want copying to start.
TV
(other VCR)
Other VCR
Decoder for Pay-TV
Camcorder
Video Player
Satellite Receiver
Audio Amp.
devices
Should you wish to assemble your own film from camcorder footage for example use the assembly technique
for smooth edit points:
• The symbol is lit in VCR mode and goes out in TV
mode.
• This symbol means the cassette is in.
• This symbol means a timer recording is setting.
For the best results the source cassette from which
you are recording should already be playing back
when you start recording.
Copying
Assembling

DVD Operation
3736
Playing desired scene
If y u want t search with a title number, press
[SEARCH] butt n ne time.
It shows current and total title numbers. Please enter
the new title number to be searched using the
[NUMBER] buttons.
1
If y u want t search with a time, press
[SEARCH] butt n three times.
Please enter the new time to be searched using the
[NUMBER] buttons.
In c mpleting entering, please press [ENTER]
butt n.
PLAY starts from the selected position.
3
If y u want t search with a chapter number,
press [SEARCH] butt n twice.
It shows current and total chapter numbers.
Please enter the new chapter number to be searched
using the [NUMBER] buttons.
2
001/003
➟
total title
number
➟
current title
number
001/023
➟
total chapter
number
➟
current chapter
number
_ _ : _ _ : _ _
Searching DVD with a title number, a chapter number or a time
■You may repeat a defined period from A to B.
A MP3 disc ma
not be repeated
from A to B.
At the p int where y u want t start the repeat
playback, press [A-B] butt n.
The right figure appears and repeat playback start
position (A) is set.
1
At the p int where y u want t end the repeat
playback, press [A-B] butt n again.
The repeat playback end position (B) is set and a
defined period from A to B is playback repeatedly.
2
T exit fr m repeat playback m de, press [A-B]
butt n.
It enters into Normal Playback mode.
3
• CHAPTER : Current chapter will play repeatedly.
• TITLE : Current title will play repeatedly.
• TRACK : Current track will play repeatedly.
• DISC : Current disc will play repeatedly.
• FOLDER : Current folder will be played repeatedly.
• OFF : Repeat playback will be cancelled.
* For the case of VCD disc, repeat playback starts only in PBC OFF mode.
- DVD -
CHAPTER
TITLE
OFF
➝➝
➝
- VCD/CD -
TRACK
DISC
OFF
➝➝
➝
- DivX/MP3/JPEG -
TRACK
FOLDER
DISC
➝➝
OFF
➝
➝
Each time you press [REPEAT] button in playback mode repeat playback starts as below.
REPEAT A-
REPEAT A-B
OFF
Playing desired scene
Repeating a defined period
Repeating a defined period from A to B
