“Narita” Media Console
MS9918– Espresso
Assembly Instructions
PO: 11052

A
“Narita” Media Console
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Using hardware that is too long will cause damage.
Before beginning assembly, separate each type of hardware. Carefully study the hardware
diagrams below. You may receive extra hardware with your unit
B C
Quantity
of 1
Quantity
of 1
Left Side Panel
Back Panel
Quantity
of 1
fixed Shelf
Right Side Panel
Bottom Panel
Top Panel
Middle Panel
Door
Right Adjustable Shelf
Left Adjustable Shelf
D
E
F
Quantity
of 1
Quantity
of 1
Quantity
of 1
G
H
I
Quantity
of 2
Quantity
of 1
Quantity
of 1
J
Quantity
of 1

“Narita” Media Console
Parts List
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Using hardware that is too long will cause damage.
Before beginning assembly, separate each type of hardware. Carefully study the hardware
diagrams below. You may receive extra hardware with your unit
Assembly Tool Required
No. 2 Phillips Screwdriver
(1)
8mm x 0 mm
Wood Dowel
Quantity
of 16
1/4” x 1” Bolt
(2)
Assembly Tool Required
No. 2 Phillips Screwdriver
(Not Included)
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew
the finish. Avoid rubbing or scratching the
surface with rough or abrasive objects.
For replacement parts or questions, please
call Customer Service at 1-800-6 -5096.
Do not return product to store. Please call
manufacturer for assistance, questions or
parts.
Quanti
ty
of 4
Metal Pin
Plastic Anchor
( )
(4)
(5)
(6)
(7)
(8)
Quantity
of 16
Quantity
of 4
Qua
ntity
of 8
mm x 12 mm
Screw For Back
Quantity
of 16
Bracket
(9)
.5mm x 15 mm
Screw For
Bracket
Quantity
of 2
Quantity
of 4
7mm x 8mm
Screw For Wall
Quantity
of 4
Plastic Chain

“Narita” Media Console
Assembly Instructions
Assembly Instructions:
Wood may scratch easily. Be careful
when assembling. Do not scratch.
Step 1. Unpack and lay parts on
clean, padded surface like
carpet or blanket. Check that
you have all parts indicated
on the front page.
Step 2. Put the Left Side Panel(A) on the
soft working surface.
Step . Insert the Wood Dowels(1) into
predrilled holes in Fixed Shelf(C)
and Bottom Panel(D).
Step 4. Attach the Bottom Panel(D) and
Fixed Shelf(C) to the Left Side
Panel(A) with Bolt(2), then fasten
them.
Step 1. Insert the Wood Dowels(1) into
predrilled holes in Fixed Shelf(C)
and Bottom Panel(D).
Step 2. Attach the Right Side Panel(A) to
the Fixed Shelf(C) and Bottom
Panel(D) with Bolt(2) then fasten
them.
Figure 2
Figure 1
(1)
8mm x 0 mm
Wood Dowel
Quantity
of 4
(2)
1/4” x 1” Bolt
Quantity
of 4
(1)
8mm x 0 mm
Wood Dowel
Quantity
of 4
(2)
1/4” x 1” Bolt
Quantity
of 4

“Narita” Media Console
Assembly Instructions
Step 1. Insert the Wood Dowels(1) into
predrilled holes in Middle Panel(E).
Step 2. Attach the Middle Panel(E) to the
Bottom Panel(D) with Bolt(2),
then fasten them.
Figure
Figure 5
Step 1. Insert the Wood Dowels(1) into
predrilled holes in Side Panel(A,B)
and Middle Panel(E).
Step 2. Attach the Top Panel(F) to the
Side Panel(A,B) and Middle
Panel(E) with Bolt(2), then fasten
them.
(1)
(2)
1/4” x 1” Bolt
8mm x 0 mm
Wood Dowel
Quantity
of 2
Quantity
of 2
Step 1. Insert the Sliding Door(G) into
the groove in the Top Panel(F)
and Bottom Panel(D).
Figure 4
(1)
(2)
1/4” x 1” Bolt
8mm x 0 mm
Wood Dowel
Quantity
of 6
Quantity
of 6

“Narita” Media Console
Assembly Instructions
Step 1. Insert the metal Pin( ) into
desirous holes of inner Side
Panels(A,B) and Middle Panel(E).
Step 2. Put the Adjustable Shelf(H,I) on
the Metal Pins( ) in each section.
Figure 6
Figure 7
Step 1. Insert Back Panel (J) into
grooves of Side Panels(A,B), Top
Panel(F) and Bottom Panel(D)
with Screw For Back (4)
and tighten.
(4)
mm x 12 mm
Screw For Back
Quantity
of 16
( )
Metal Pin
Quantity
of 8

“Narita” Media Console
Assembly Instructions
Figure 9
Figure 8
Step 1. Move this item to the fastened
wall Bracket(5) and tie in
both Bracket(5) with Plastic
Chain(9) as shown in diagram.
Step 1. Attach Bracket(5) to the
Leg of Side Panel(A,B) with Screw
For Bracket(6).
Step 2. Drill 1/4 pilot holes in near
proximity of the Bracket(5)
attached to the Leg of Side
Panel(A,B) and tap the Plastic
Anchor(7) into wall.
Step . Fasten Bracket(5) using
Screw For Wall(8) into the
Plastic Anchor(7).
(6)
(5)
Quantity
of 4
(7)
Plastic Anchor
Quantity
of 4
7mm x 8 mm
Screw For Wal l
Bracket
.5mm x 15 mm
Screw For Bracket
(8)
Qua
ntity
of 4
(9)
Plastic Chain
Quantity
of 2
Quantity
of 4

Customer Service 1
-
800
-
6
-
5096
[email protected]
Southern Enterprises, Inc.
600 Freeport Parkway, Suite 200
Coppell, Texas, 75019
MS9918
Parts Replacement Form
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style n
umber:
Missing or damaged hardware and/or parts will be replaced free of charge. We do not sell parts.
Southern Enterprises Inc. Will provide replacement parts for only those items purchased within the last 9 months. If
this product has not been purchased from our retail affiliates (within 9 months), we are under no obligation to
provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled Parts will
be sent if available from SEI.
Please contact Southern Enterprises at 800-6 -5096 or in Dallas [phone]/ 9am – 4pm Mon-Fri Central time
if you have product issues with your purchase. Please ask for a customer service representative for issues
involving damages or replacement parts. Please ask for a technical assistance representative
for any issues with
product assembly and product construction. Please contact the retailer that you purchased from for returns.
We'd love to hear from you! Email us photos of our products in your home at [email protected]m and we
might feature it on our site or use it to model one of our inspirational photos.
Style No
Parts Letter
Parts Description
Quantity Needed

CA TION
The top shelf is intended for a flat screen television with a maximum overall width
of 48” and supports up to 175 lb.
The top shelf is NOT INTENDED for tube televisions.
Each center shelf should not be loaded with more than 20 lb. Each side shelf should
not be loaded with more than 15 lb.
DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the
maximum sizes and weights indicated may result in instability causing possible
injury.
This unit contains a permanent warning sticker located on under side of top shelf
or inside drawer.
Do not allow children under 16 years to move the cart.
Model: MS9918
“Narita” Media Console
Southern Enterprises, Inc
600 Freeport Parkway,
Suite 200 Coppell, Texas, 75019
Manufacture Date: 01/10/2011
