SEI NARITA User manual

Forassistancewithassemblycontact:
SouthernEnterprises Inc.
CustomerService1-800-633-5096
[e-mail]
www.seidal.com
"NARITA"MEDIACONSOLEFIREPLACE
FA930100TX-ESPRESSO
FA930200TX-GLAZEDPINE
Assembly Instructions

AQuantity
of 28
CAMBOLT
BQuantity
of 26
WOODDOWEL
CQuantity
of 28
CAMLOCK
DQuantity
of 20
COVER
EQuantity
of42
ROUND HEADSCREW
FQuantity
of4
SLICEOFIRON
GQuantity
Of2
MAGNETLOCK
HQuantity
Of4
HINGE
IQuantity
of 18
SHORTFLATHEADSCREW
JQuantity
Of2
MAGNETPLATE
KQuantity
of2
LONGBOLT
LQuantity
Of 2
KNOB
MQuantity
of8
SHELFHOLDER
NQuantity
of4
LONGFLATHEADSCREW
OQuantity
of1
FIREBOX
SOLDINASEPARATECARTON
"NARITA"MEDIACONSOLE FIREPLACE
Parts List
Pleasereviewall partsandhardware beforedisposingof anypackaging.
Call Customer Serviceifmissinghardware.Do not returntostore/retailer.
Usingascrewthatistoolongwill causedamage.
Before beginningassembly,separateeachtypeofscrew.Carefully studythe
screwdiagramsbelow.Youmayreceiveextrahardwarewithyourunit.

(1)Quantity
of2
VERTICALPANEL(R&L)
(2)Quantity
of1
MIDDLE FRONTPANEL
(3)Quantity
of1
MIDDLE FIXEDPANEL
(4)Quantity
of1
BOTTOMFRAME
(5)Quantity
of2
SIDEPANEL(R&L)
(6)Quantity
of1
TOPPANEL
(7)Quantity
of1
MIDDLE BACKPANEL
(8)Quantity
of2
SIDEBACK PANEL
(9)Quantity
of2
DOOR(R&L)
(10)Quantity
of2
SHELFPANEL
(11)Quantity
of1
WOODHOLDER
(12)Quantity
of1
CENTERSUPPORT
CareandCleaningInstructions:
Beforeusing,wipewithaclean, drycloth.
Periodically applyfurniture waxtorenew
the finish.Avoidrubbingorscratchingthe
surfacewithroughorabrasive objects.
Forreplacementparts orquestions,please
Call CustomerServiceat1-800-633-5096
Donotreturnproducttostore,please call
Manufacturerforassistance,questions or
Parts.
AssemblyToolRequired
No.2PhillipsScrewdriver(NotIncluded)
"NARITA"MEDIACONSOLE FIREPLACE
PartsList
Pleasereviewall partsandhardwarebefore disposingof anypackaging.
CallCustomer Serviceifmissinghardware.Do not returnto store/retailer.
Usingascrewthatis too longwill causedamage.
Beforebeginningassembly,separateeachtypeofscrew.Carefullystudythe
screwdiagrams below.Youmayreceiveextrahardware withyourunit.

Figure1
USE4PCSROUNDHEADSCREWTOSECURE
MAGNETLOCK(G)ONMIDDLEFIXED PANEL(3)
ASSHOWN.
INSERT8PCSCAM-BOLTS(A)AND12PCS WOOD
DOWELS (B)INTOPREDRILLED HOLESON
INSIDESOF MIDDLEFIXEDPANEL 3）， BOTTOM
FRAME 4）ANDMIDDLEFRONTPANEL 2）， AND
FIT INTOCORRESPONDING HOLESONENDSOF
VERTICALPANEL R&L(1).INSERT8PCS
CAM-LOCKS (A)INTOBIGHOLESONINSIDE OF
VERTICALPANEL R&L(1),WITHSLOTFOR
SCREWDRIVERFACINGOUTWARD.ROTATE
CAM-LOCKS (C)CLOCKWISE TOSECURE
CAM-BOLTS(A).PUSHCOVERS(D)INTO
CAM-LOCKS (C).ASFIGURE1SHOWN.
Figure2
INSERT12PCSCAM-BOLTS(A)AND 8PCS
WOODDOWELS(B)INTO PREDRILLED
HOLESONINSIDEOFSIDEPANEL (R&L)
(5),AND FIT INTOCORRESPONDING
HOLESONENDSOFASSEMBLED
UNIT,THENINSERT12PCSCAM-LOCK(C)
INTOBIGHOLESONINSIDEOF
ASSEMBLEDUNITWITHSLOTFOR
SCREWDRIVERFACINGOUTWARD.
ROTATECAM-LOCKS(C)CLOCKWISETO
SECURECAM-BOLTS(A).PUSHCOVERS
(D)INTO CAM-LOCKS(C).THENUSELONG
FLATHEADSCREW(N) TIGHTENMIDDLE
FRONTPANEL(2)ASFIGURE2SHOWN.
Figure
3
PUTTHETOPPANEL(6)ONTHEUNIT,
INSERT4PCSCAM-BOLTS(A)AND 4PCS
WOODDOWEL(B)INTOPREDRILLED
HOLESOFSIDETOPPANEL(6),AND FIT
INTOCORRESPONDINGHOLESONINSIDE
OFSIDEPANEL(R&L)(5),THENINSERT
4PCSCAM-LOCK(C)INTO BIGHOLESON
INSIDEOFSIDEPANEL(R&L)(5)WITH
SLOTFORSCREWDRIVERFACING
OUTWARDROTATECAM-LOCKS(C)
CLOCKWISETOSECURECAM-LOCKS,AS
FIGURE3SHOWN.USETHECENTER
SUPPORT(12)BEFOREPLACINGANYITEM
WEIGHINGOVER50LBSONTHETOP.JUST
INSERTCENTERSUPPORT(12)TO THE
POSITIONASSHOWNINFIGURE
3,ADJUSTTHERUBBERFOOTATTHE
BOTTOMOFSUPPORTTI
LLTIGHTING.
"NARITA"MEDIA CONSOLE FIREPLACE
AssemblyInstructions
(6)
(5)L
(5)R
(12)
(1)L
(1)R
(2)
(3)
(4)

Figure4
USE38PCSROUND HEADSCREW(E)AND
4PCSSLICEOFIRON(F) TO ASSEMLBE
MIDDLE BACKPANEL(7)ANDSIEDBACK
PANEL(8)TOTHEUNIT,AS AS FIGURE4
SHOWN.
Figure5
ATTACHMAGNETPLATE(J) ONTHE
DOOR(R&L)BYUSING2PCSSHORTFLAT
HEADSCREW.
ATTACHKNOB(L)ONTHEDOOR(R&L)BY
USING2PCSLONGBOLTS(K).
USE4PCSHINGE(H)AND16PCSSHORT
FLATHEADSCREW(I)TOASSEMBLED
DOOR(R&L).
INSERT8PCSSHELFHOLDER(M)INTO
CORRESPONDINGHOLESOFMIDDLE
FIXEDPANEL(3),THENPUTTHESHELF
PANELONIT ,AS FIGURE5SHOWN.
Figure6
INSERTTHEFIREBOXFROMTHEBACK OF
FIREPLACE.MAKESUREFIREBOXIS
PRESSEDTIGHTLYAGAINSTTHE
ASSEMBLEDUNIT.ATTACHFIXEDWOOD
(E)ONTHEINSIDESOFFIREBOX.INSERT
2PCSFLATHEADLONGSCREWS(N)
THROUGH PREDRILLEDHOLESONFIXED
WOOD(11)AND TIGHTENINTO
CORRESPONDINGHOLESONBACK OF
FIREBOX.AS FIGURE7SHOWN.
"NARITA"MEDIA CONSOLE FIREPLACE
AssemblyInstructions
O
(9)
(10)
E
E
E
E
E
E
E
E
E
(7)
(8)
(8)
E

CustomerService 1-800-633-5096
[e-mail]
SouthernEnterprises,Inc.
600 FreeportParkway,Suite200
Coppell,Texas,75019
Missingordamagedhardwareand/orpartswillbereplacedfree ofcharge.Wedonot sellparts.
SouthernEnterprises Inc.will providereplacementparts foronly thoseitemspurchased
withinthelast 9months.If thisproduct hasnotbeenpurchasedfromourretailaffiliates
(within9months),weare under noobligationtoprovideparts orreplacementmerchandise.
Partswillnotbeavailableforitemsarrivingfully assembled.Parts willbesentifavailablefrom
SEI
PleasecontactSouthernEnterprisesat 800-633-5096orinDallas(972)869-0111/9am
4pmMon-FriCentraltimeifyouhaveproduct issues withyourpurchase.Pleaseaskfora
customer servicerepresentativeforissuesinvolvingdamagesorreplacement parts.Please
askforatechnicalassistancerepresentativeforany issueswithproduct assemblyandproduct
construction.
Pleasecontacttheretailer that youpurchasedfromforreturns.
We'dlovetohearfromyou! Emailus photosofourproducts inyourhomeat [e-mail]
andwemightfeatureit onoursiteoruseitto modeloneofourinspirationalphotos.
Customer Information
Name
Address
City/State/ZipCode
Phone Number
Please indicatewhere youpurchasedthis item:Store/Website/Catalog
Please indicatecolor/size/stylenumber:
StyleNoParts LetterPartsDescriptionQuantityNeeded
FA930100/200TX
-
PartsReplacementForm

CAUTION
The topshelf ofthis cabinetisintendedforplasma/LCD televisions havinga
MaxTVsizeis50"flatscreenandMaxweightlimitis 175lb.
The topshelf is NOTINTENDEDfortube televisions.
Eachcenter shelfshouldnotbeloaded withmorethan20 lb.Eachsideshelfshouldnotbeloaded
withmore than15lb.
DONOTEXCEEDRECOMMENDEDLOAD.Use withproductsheavierthanthe
maximumsizes andweights indicatedmayresultininstabilitycausingpossibleinjury.
Thisunitcontainsapermanentwarningstickerlocatedonundersideoftopshelforinsidedrawer.
Donotallowchildrenunder16 yearstomovethecart.
Model:FA930100TX
“NARITA”MEDIACONSOLEFIREPLACE
SouthernEnterprises,Inc
600FreeportParkway,Suite200
Coppell,Texas,75019
Manufacture Date:
