How to use the Danfoss VLT 2800 Keypad
• Press + or – Button to view different operating data
• Press Quick Menu Button and then + Button to locate the required parameter in the Quick
Set-up Menu (Parameter number will ‘Flash’ when in this mode)
• Press Change Data Button to open options (NOTE: When Data is a large figure, it will be
shown as a row of dashes until Change Data Button is pressed).
• Press + or – Button to raise or lower data. (NOTE: the longer you hold the Button in the
faster data will change).
• Press Change Data Button to store data
• Press + or – Button to move to next parameter or Press Quick Menu Button to go back to
Display Mode
• To gain access to all other parameters in the Extended Menu, Press Quick Menu and +
Button together this takes you into the first parameter 001
• To get to the required Parameter, Press + Button, (remember the longer you hold in the
button the quicker it will run through the parameters).
• Press Change Data Button, Data for that parameter will now flash
• Press + or – Button to raise or lower Data
• Press Change Data Button to store
• Press + or – Button to move to next Parameter or Quick Menu Button to go back to
Display Mode

Specialist Distributors for:
Sick (Photocells, Barcode readers & Safety), ifm efector, Red Lion Controls, Hohner,
Danfoss (Drives, Pressure & Flowmeters), British Encoder Products, MTE Turck Banner,
Phoenix Contact, Rechner industries, Foxtam Controls, Di-ell industries, Contrinex,
Allen-Bradley Multiswitch, Adam DAC Modules
Partners: J Dunnington, P Dunnington, M Dunnington
VAT Registration: GB 298 0364 29 Partnership No: OC305579
CHANGING FROM AUTO TO HAND
• From the ‘Display Mode’ Press Change Data Button and ‘Auto’ will appear in the
display. Pressing the + Button will change the display to ‘Hand’
• Display will then show ‘HA 00.0 then Press + or – Button to raise or lower Frequency.
• Parameter 020 could block the choice of mode
• Terminal 27 needs to be on unless Parameter 013 has been changed.
MANUAL INITIALISATION
• Disconnect mains, wait for Drive to discharge, Hold in Quick Menu and + and Change
Data Buttons together then reapply mains and release the Buttons.
The Frequency Converter should now be back at factory settings.
