SEMAK HD3T Installation and operation manual

SEMAK HOT DOG COOKER &SPIKER –MODEL HD3T
SEMAK AUSTRALIA:FACTORY 18, 87-91 HALLAM SOUTH ROAD,HALLAM VIC 3803
PH [phone] FAX [phone] WEB WWW.SEMAK.COM.AU
OPERATION AND WARRANTY BOOKLET

Page | 2
Table of Contents
General Safety Instructions for All Semak Products ..................................................... 4
Safety Instructions........................................................................................................ 5
Operating Instructions for the Semak Hot Dog Cooker & Bun Spiker ........................... 6
Cleaning Instructions for the Semak Hot Dog Cooker & Bun Spiker ............................. 7
Spare Parts for the Semak Bun Spiker .......................................................................... 7
Service & Maintenance ................................................................................................ 8
Electrical Compliance ................................................................................................... 8
Specifications ............................................................................................................... 8
Warranty ...................................................................................................................... 9
WARRANTY REGISTRATION ........................................................................................ 11

Page | 3
RETAIN THESE SAFETY INSTRUCTIONS

Page | 4
General Safety Instructions for All Semak Products
Do not use the appliance for other than its intended use.
Never leave the appliance unattended when in use.
The appliance should not be used by children or infirm persons and close
supervision is necessary when used near such persons.
Always switch off at power outlet before removing the plug. Remove by holding
the plug –do not pull the cord.
When the appliance is not in use, or prior to cleaning, always switch off the
power and remove the plug.
To avoid the risk of electric shock, do not immerse the plug, cord or any part of
the appliance in water or any other liquid.
Do not use near a stove or heat source and do not let the cord come in contact
with any hot surface.
Do not use the appliance with an extension cord unless that cord has been
checked and tested by a qualified technician or if it is an extension cord that has
been manufactured by a reliable electrical goods manufacturer and has not
been altered in any way.
Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in anyway. Return to
Semak or an authorised service agent for repair.
CAUTION Hot Surfaces.
NEVER leave the appliance ON unattended. ALWAYS unplug the cooker after
use.

Page | 5
Safety Instructions
Only use the appliance on a flat, level and stable surface. DO NOT use on a wet
surface.
When in operation the surfaces of the bun spiker and glass tank are EXTREMLY
HOT
DO NOT touch the Teflon coated bun spikes while the appliance is in operation.
ALWAYS turn off the appliance and allow it to cool down before cleaning.
The spikes remain hot for some time. Allow a minimum 15 minutes COOL DOWN
to ensure that the bun spikes have cooled. NEVER pick up the bun spiker by the
spikes to avoid burns of the hands, fingers, wrists.
Use a barely damp cloth to wipe the bun spiker once it has cooled.
DO NOT use running water when cleaning the bun spiker. Wipe the exterior with a
damp cloth.
DO NOT use caustic substances to clean the appliance and do not allow caustic
substances to make contact with any electrical components of the warmer.

Page | 6
Operating Instructions for the Semak Hot Dog Cooker & Bun Spiker
•Locate the appliance on a level surface making sure that there is a clearance of
100mm around the appliance for ventilation.
•Make sure that the switches are in the “OFF” position. Plug into an earthed
single phase 10Amp 240V AC power supply.
•Turn the switch for the corresponding tank or bun spikes on. The indicator
switch will light up when “ON”. The “TANK” switch will turn the tank element
on and the “SPIKES” switch will turn the spikes on
•Lift the lid, remove the wire rack and pour water into the tank to cover the
element. Replace the tank and lid. Place hotdogs in the tank. Packing them
tightly together increases the cook time required to heat them thoroughly.
•Turn the “TANK” switch to 2 or 3 so that the water will simmer. Allow the bun
spiker to warm up 3-5 minutes. Adjust the temperature to achieve the desired
level of heating.
•Check the water level in the tank each hour to ensure that there is sufficient
water in the tank to cover the element. Top up if necessary.
•Ensure that the bun /roll is long enough to cover the whole spike. Short buns
may have the end pierced by the spiker if they are not long enough and
depending on how the hot dog etc is served this may cause sauce/mustard etc.
to drip from the bun. Place the bun on the spike. DO NOT touch the spike with
your hand to avoid burns. Some rolls/buns are soft and this can inadvertently
lead to burns if the sides of the roll/bun collapse or are pierced. Extra care must
be taken if using soft rolls and crispy ones are recommended.
•DO NOT butter the roll. Butter can be added after the roll is toasted.
•The buns are cooked when they appear toasted on the inside. Lift the bun off
the spiker and look in to determine if it is toasted. As a guide they take 1-2
minutes. Add sauce if required and insert the hot dog.
•When finished heating turn the switches “Off”. The appliance is “OFF” when
the indicator switches are no longer lit.

Page | 7
Cleaning Instructions for the Semak Hot Dog Cooker & Bun Spiker
The Hot Dog Cooker must be cleaned daily as part of a HACCP Food Safety
Program.
ALWAYS turn off the appliance and allow it to cool down before cleaning.
Remove the tank and lid and wash separately. Empty the tank.
Pour a small amount of hot soapy water in the tank and wash greasy residues. Tip
out soapy water and add clear water to rinse the soap away. Spray with a HACCP
Endorsed food grade sanitizer and wipe dry.
DO NOT leave water in the tank overnight
The surface of the spiker is Teflon coated. Do not use abrasive materials on the
spikes e.g. Steel wool or scourers etc as they will scratch the Teflon or accelerate
the wear and tear of the Teflon, reducing the performance of the machine. If parts
of the roll stick to the spikes remove with a damp cloth. A damp cloth is all that is
necessary to clean the spikes
Use a barely damp cloth to wipe the outside of the machine once it has cooled. DO
NOT use running water to clean the appliance.
DO NOT use caustic substances to clean the appliance and do not allow caustic
substances to make contact with any electrical components of the appliance.
It is important to note that Semak cannot warrant the Teflon coating of the spikes
where damage is caused by using abrasive cleaning products or where scratching
is caused by utensils. However, we do warrant the Teflon where it is evident that
the materials are faulty or the workmanship is faulty.
Spare Parts for the Semak Bun Spiker
Part Number
Description
Part Number
Description
19387
86101
86008
86417
86408
LABEL
BUN SPIKE COMPLETE
RED INDICATOR LIGHT
GLASS TANK
WIRE RACK
38012
86144
75210
86416
86407
HEAT CONTROL w KNOB
RUBBER FEET
LEAD & PLUG
LID COMPLETE
TANK ELEMENT
Spare Parts, exploded views and wiring diagrams are available from our webpage. Go
to www.semak.com.au and locate the appliance in the product section for the above
information.

Page | 8
Service & Maintenance
The Semak Hot Dog Cooker does not contain user-serviceable parts. For Service and
Repair, contact Semak for your nearest Authorised Service Agent
The Foodservice Industry is deemed a hostile environment within the scope of
AS/NZS 3760:2003. Semak Hot Dog Cooker and Bun Warmer MUST be routinely
electrically tested for compliance with this standard if used commercially.
It is recommended that a Food Safety program such as HACCP be employed and that
routine service and repair be undertaken at the time of electrical testing to ensure
the correct operation and function of all parts.
Electrical Compliance
Semak Hot Dog Cooker & Bun Warmers comply with the following electrical
standards
CISPR 14
Specifications
Model
HD3T
Dimensions
350 x 320 x 300mm
Volts
240AC 10AMP
Electrical
970W

Page | 9
Warranty
The Semak Hot Dog Cooker and Bun Warmer is a Commercial appliance. This product
is guaranteed for 2 Years* from the date of purchase against mechanical and
electrical defects. If the fault is deemed caused by MISUSE/ABUSE the terms of the
warranty are invalidated. If the product has been opened or tampered with (i.e. In an
attempt to repair it) the warranty is invalidated. All warranty repairs should be
undertaken by Semak Australia.
It is against company policy to authorize warranty repairs over the phone. Service
Agents will require a work order number from Semak to conduct warranty repairs.
*Warranty excludes, Elements and Teflon Coating

Page | 10
SEMAKWARRANTY
THIS WARRANTY APPLIES ONLY TO PRODUCTS MANUFACTURED AND SOLD IN AUSTRALIA
The benefits conferred by this warranty are an alternative to all other rights and remedies
in respect of the product which the consumer has under the Trade Practices Act and similar
State and Territory Laws.
Semak Australia. Warrant each new SEMAK appliance manufactured by SEMAK to be free
from defects in materials or manufacturing process for a period of 2 years from the date of
original purchase.
Should defects due to faulty materials or manufacturing process develop within the
warranty period, the appliance will be repaired without charge providing all conditions of
this warranty are observed.
1. Proof of Purchase and Warranty card must be retained and available on request.
2. This Warranty is void if the equipment has been damaged due to misuses neglect or is
used for a purpose for which it was not suited; and no repairs, alterations or
modifications have been attempted by other than Semak or its authorised Service
Agent.
3. Semak Australia. Reserves the right to reject a claim for warranty if service is required
due to misapplication, improper installation, inadequate wiring, and incorrect voltage
conditions. Under no circumstances shall SEMAK or its agents bear responsibility for
consequential damages of any kind.
4. Where required by Statute or local authority, equipment must be installed by qualified
person in accordance with all relevant regulations. Failure to do this will void product
warranty.
5. Cost of transport of any appliance or part to and from SEMAK or its Service Agent is to
be paid by the owner.
6. A charge will be made where failure is due to neglect, abuse or accidental damage on
the part of the operator, or when no fault can be found or the fault is due to causes
outside the control of Semak Australia.
7. The above does not preclude the purchaser from their Statutory rights as a consumer.
Semak Australia
Factory 18
87-91 Hallam South Road
HALLAM VIC 3803
Ph 61 3 9796 4583
Fax [phone]
Email techn[email protected]

Page | 11
WARRANTY REGISTRATION
Retain for Future Reference
DO NOT SEND
Please complete one registration for each Semak appliance.
You may be required to provide this information when requesting after sales service. Please
staple your proof of purchase to this page.
Company Name: ________________________________________________
Company Address: ________________________________________________
Business Type: ________________________________________________
Contact: ________________________________________________
Phone: ________________________________________________
Fax: ________________________________________________
Email: ________________________________________________
Product: ________________________________________________
Serial Number: ________________________________________________
Date of Purchase: ________________________________________________
Place of Purchase: ________________________________________________

Page | 12
© 2010 Semak Australia
