Sencor SCR 4500 User manual

CAMERA
KAMERA
KAMERA
KAMERA
KAMERA
SCR 4500
USER’S MANUAL
NÁVOD KOBSLUZE
NÁVOD NA OBSLUHU
HASZNÁLATI ÚTMUTATÓ
INSTRUKCJA OBSŁUGI
EN CZ SK HU PL

EN 1
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Important safety instructions
1. Important safety instructions
Please read this user's manual carefully before using the device. It contains
important information concerning safety, use and troubleshooting. Keep the
manual in a safe place for future reference. Should you sell or give the device to
athird party, include the user's manual to ensure the new owner can also become
familiar with the device.
Warning
• Protect the display against damage.
• Do not use force to connect the USB. Always make sure you are connecting
the USB cable with the device off.
• Do not insert connectors into the USB port other than the specified USB
connector with the relevant port size.
• Handle the display with care to prevent damage.
• Protect the device against impacts. Do not expose the device to extreme
temperatures, direct sunlight etc.
• When installing the device, degrease the mounting area on the glass and
make sure the mount is fixed firmly so that the camera does not fall.
• Insert the SD card carefully, do not insert the card with force. Make sure the
device is switched off before inserting the microSD card.
• Due to a wide range of microSD cards on the market, it is not possible to
guarantee full compatibility with all microSD cards available.
• Do not expose the device or accessories to dripping or spraying water.
Protect against moisture, dust and impurities. Do not place any containers
with water on the device, for example, vases.
• Do not expose the device to sources of heat, for example, sunlight. Do not
set the device on or near an open fire, for example, a candle.
• Use a dry towel for cleaning. Under no circumstances should benzine,
thinner, ammonia or other similar substances be used.

2 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
2. Device and controls
2.1. Device and controls
Status indicator on the holder
The blue indicator is on if the power is connected.
1. Menu button
It locks the file during recording to prevent erasure.
In addition to recording, it switches cyclically between mode Settings,
General Camera Settings and Settings Off – normal operating mode.
2. “Up” button
Up direction in the menu, except for the digital zoom menu.
3. “Down” button
Down direction in the menu except for the digital zoom menu.
It turns the microphone on/off during recording.

EN 3
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
4. MODE button
Switches between video/photo/playback.
5. MicroSD memory card slot
– Inserting the card: Carefully insert the card into the TURNED OFF
DEVICE in the right direction (printed side toward the screen, the gold-
plated contact pads facing forward and into the device, recess in the
card case downwards). Insert the card, for example, using your fingernail
about 1 mm under the surface until you hear a click. The card will fall
into place upon release.
– Card removal: Push the card in, for example, using your fingernail about
1 mm under the surface until you here a click. When releasing the card
from its compartment, hold on to it to prevent it from jumping out.
6. Microphone
7. REC/OK button
Menu selection confirmation button. In normal mode start/stop recording or
photo capture.
8. USB connector
Powering the camera and charging its battery. Do not connect both
connectors at the same time!
9. Data connector for transfer to PC (not to camera)
10. RESET button
Turns off the camera if it becomes unstable or does not respond to control,
e.g. due to excessive heat. Press the button with a thin, blunt object, such as
an open paper clip.
11. Switch 1
Switch the camera on or off by pressing for 4 seconds. You can turn off the
camera using the button only when it is not recording.
12. Speaker
13. Lens

4 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
Notes:
a) you have to use for recording high quality, fast writing card,
at least class 7 and of appropriate size. Determine which card
capacity best suits your needs before purchasing, a card with a
small capacity can quickly become full with standard recording
and locked files. We recommend at least 4 GB. The maximum
capacity supported is 64 GB. The recording can be affected
by the specified speed class, but also by an even speed
throughout the entire card memory.
b) despite maximum effort for compatibility, it is not possible
to guarantee the usability and functioning with all devices
available on the market. If a feature or recording on the card
does not meet your expectations, format the card in the
computer and then in the device. If this does not improve
functionality, use a different card, preferably a faster one.
NOTE: the inserted card uses technology sensitive to high
temperatures or thermal shocks. Avoid leaving the memory
cards in high temperatures (for example, behind the car window
in summer) and do not subject them to thermal shocks (e.g. in
winter). This could result in temporary or permanent damage to
recordings found in the memory.
2.2. Glass mount
Attach the device gently with the groove (“rail”) to the holder attached to the car
window or to another suitable smooth surface.
Installation of the bracket on the car window: Select a location to mount the
camera that does not block the driver's view. Remove the adhesive tape and apply
light pressure to the smooth, clean and degreased glass inside the car.
Slide the camera onto the mount (via rail).

EN 5
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
Perform several test recordings at various resolutions and camera positions to
ensure the end result meets your expectations.
NOTE: Do not use excessive force when handling and working with
the holder and camera, both parts are very light and do not have to be
mechanically stressed during operation.
2.3. Battery and charging instructions
Battery charging indicator:
Full Almost full Weak
Charging methods: car adapter, PC USB slot, external power adapter (sold
separately).
WARNING: use a 5V power source only, otherwise you can damage the
device.
Upon connecting the device to the car outlet and starting the ignition, the device
will switch on and begin to record once the key is set to “Accessories” and the
recording process is stopped when the key is removed from the ignition. The full
charging cycle of an empty battery lasts up to 180 minutes. The built-in battery
in the camera serves only as a bridging buffer for transition power supply states
and is not used for a longer operation of the camera without a connected power
supply.

6 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
2.4. Description of basic and special functions
• G-sensor
A sensor of extraordinary acceleration, such as an impact or crash, locks the
current file against automatic deletion. It can be set for 3 levels or turned
off. Try a suitable option to prevent the sensor from being activated, by e.g.
normal road bumps and not filling the card with unwanted, indelible files.
This would prevent any more recording.
• SOS function
While recording, press briefly the MENU button, the current file will be
locked, the display shows key symbol .
• Auto power on and off
When connecting the power, the camera turns on and starts recording
and ends recording and shuts down a few seconds after the power is
disconnected. Most cars have an on-board power outlet controlled by the
ignition key, so you do not need to operate the camera manually or handle
the power cable.
• Card formatting
It creates a file system on the card for efficient recording. Recommended for
any newly inserted card.
Notice: Formatting permanently deletes previous card content!
Tip: Because of the potentially extreme stress of the memory card
(vibration, temperature fluctuations, humidity), it is advisable to
occasionally check the integrity of the card's memory space, or reformat
it in the computer and then in the camera. We recommend that you
exclude cards showing errors from further use.

EN 7
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
• Date & time
You can set the time and date manually in the menu.
Working with USB
In addition to power, the connector (9) is used to transfer data from the memory
card in the camera to the computer. However, not from the computer to the
card (erasing, formatting), perform the file management either with the camera
functions or by moving the card into the card reader on the computer. The
connected card is reported as another disk drive. The Mass Storage message lights
up on the camera display.
2.5. Start-up, warm-up
1. Charge the device away from the car, press and hold the On / Off button
(5s) for a long time and set it to suit your needs as described in this manual.
At the end of the initial procedure, switch the device off by holding down
the On/Off button (up to 3 s).
2. Install the camera and mount to a suitable place on the wind shield and
manually activate the camera connection to power supply for automatic
activation.
3. If you manually turn on the camera, turn it off manually when finished
recording (not necessary if you have automatic shutdown).
2.6. Operating modes and use
MODE button for mode select
1. Turn on the device by pressing On / Off, after the welcome screen an
operational screen appears with status icons and indicators. If the power
supply is connected (e.g. in the car), the camera will immediately begin to
record, in which case you can press REC/OK to stop the recording process.
2. Press the MODE button to switch between the Camera recording mode
(Camera) , taking photos (Photo) and Playback of previous
recordings. Action icons are displayed in the top left corner of the screen.

8 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
Recording and its setting
Press REC/OK in Camera mode ( icon) to
start recording. An icon starts slowly flashing in
the left corner of the screen .
Press REC/OK again to stop recording, the icon
and indicators no longer flash.
Note: if the screen is off in the Power saving mode, the first press of a button
turns it on, and only second press performs the desired action.
During recording, you can turn off/on the audio recording by pressing DOWN
(crossed-out microphone icon), press MENU to lock the file for storage. The device
settings cannot be adjusted during an active recording process. Size of files is
determined by loop length and resolution. For example 5 min 720P has 280 MB,
5 min 1080FHD has 600 MB. Shorter loops are recommended.
Parameter settings (MENU)
Press MENU once to navigate to mode setup, twice to access device settings.
Press again to exit both modes back to operating mode. The OK button is used to
confirm options, select UP/DOWN, confirm again and return by pressing OK.
• Resolution: 1080P (1920×1080, 30 fps), 720P (1280×720, 30 fps), 1296P
(1720×1296, 30 fps)
• Loop: 1 min/5 min/10 min – the duration of each segment in a single file
before a new file is created.
• High Dynamic Range: Off/On – recording with higher dynamics in the
• Exposure: -3...0...+3 – correction of light in the scene
• Motion detection: Off/On – the recording automatically turns on only when
there is a large move a scene (car movement), and stops for automatically
after about 1 minute.
• Audio recording: Off/On – audio from the cabin is recorded via integrated
microphone only if Audio is enabled.

EN 9
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
• Time stamp: Off/On – the system date and time is recorded to the video if
this option is enabled. Do not forget to set the date and time!
• G-Sensor: Off/Low/Medium/High – based on the configured sensitivity, the
integrated acceleration sensor ensures the given file is locked against being
automatically deleted when a limit value is exceeded (shock, accident).
Check the sensitivity in your application to ensure it does not unnecessarily
mark files as locked even if it only concerns a common state (bumps on the
road, railway crossings, and similar). The sensor can also be disabled.
Parking mode
A special mode for creating a short 20s video recording in case your car is hit
while parked in order to capture the offender. This mode activates even when the
camera is turned off. The active parking mode symbolizes the letter “P” at the top
of the screen.
Activating parking mode:
1) Select Off to switch off the parking mode in the device menu.
Potential issues:
a) When the battery power is low, the camera will start, detects the low battery
and switches off again. Maintain the battery charged. If the camera is
connected to a power supply, the recording will not stop after 20 seconds.
b) The camera can start when you enter the car without immediately inserting
the key into the ignition. The key is inserted into the ignition only after 20 s
of recording and turning off the camera. The camera will finish the switch off
process and will not restart. Switch the camera on manually.
c) With the ignition on during an active recording process after a longer stop.
This is a conflict between the automatic internal deactivation and automatic
external activation.

10 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
Taking photos and setting
When the device is in the Photo mode (icon ),
press OK to take a photo.
Parameter settings (MENU)
Press MENU once to navigate to mode setup, twice
to access device settings. Press again to exit both
modes back to operating mode. The OK button is
used to confirm options, select UP/DOWN, confirm
again and return by pressing OK.
• Self timer (Inactive, 2s delay, 5s delay, 10s delay)
• Resolution (12M, 10M, 8M, 5M, 3M, 2M, 1.3M, VGA)
• Continuous shooting/Continuous shooting (Off/On) – taking 3 pictures one
after another
• Quality (High/Normal/Economical) – higher quality means larger files
• Sharpness – (Strong/Normal/Fine) – display of edges in the picture
• White balance (Auto/Daylight/Overcast/Light bulb/Fluorescent light)
• Colour (Normal/Black and white/Sepia)
• ISO (Auto/100/200/400)
• Exposure (+3...0...-3)
• Anti-Shaking/Picture stabilization (Off/On)
• Quick review (Off/2 s/5 s) – viewing the currently taken photo
• Date stamp – inserting date/time into photo
Browsing and browsing settings
When the device is in the Review mode (movie strip icon for video, icon for
photos), the last recorded file is first ready for viewing (video recording or photo).
You can scroll through the files with UP/DOWN buttons and press OK to select.
If the selected file is a video, it can be started by pressing OK, and the speed can
be changed during playback using the UP/DOWN buttons. Press OK again to stop
playback of the recording. You can use the UP and DOWN buttons to fast forward
and slow down again during playback forward and backward. Pressing Mbutton
during playback will stop it and return it to the beginning of the file.

EN 11
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
Delete
The file being viewed in playback mode can be deleted. Press MENU and select
the DELETE option. Choose whether to delete one file (Delete current) or all video
files and photos (Delete all) from the following menu. Press OK to confirm your
choice or Cancel to exit the delete options. You cannot delete the locked files
directly, you must first unlock their protection.
File lock
A file can be protected against system or manual deletion in playback mode.
Press MENU and select the LOCK option. Select an action from the following
menu: Lock current/Unlock current/Lock all/Unlock all. Locked files are protected
against being deleted, however, formatting the card deletes all contents regardless
of whether or not files were locked.
To delete only some locked files, you first have to unlock these and then delete
them. System-locked files (G-sensor feedback) are deleted in a similar way, they
must first be unlocked.
Device settings
Setting the general properties of the device is the second option next to each
mode setting. Enter it by pressing MENU, down arrow and confirm by pressing
OK. Press again to return to operating mode. The OK button is used to confirm
options, select UP/DOWN, confirm again and return by pressing OK.
• LCD screensaver/LCD Off: Off/30 sec./1 min./3 min. – shuts off the screen
after a certain time (without user control) and leaves the other operating
modes unchanged to save battery power and to minimize any effect on
driving. Pressing the display controls wakes the device up.
• Auto Power Off: Off/1 min./3 min./5 min. – automatic shutoff after a
specified time of inactivity.
• Language: select a language option.
• Frequency: 50 Hz/60 Hz – choose to reduce flashing caused by light
sources.
• Beep Sound/Beep: Off/On – buttons sound signal
• Date/Time: scroll through the items by pressing OK: YY/MM/DD.

12 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Device and controls
• Format: Format the memory card for best use in the camera. Proceed with
caution as records cannot be recovered after formatting the memory card.
Therefore, the device asks you to confirm the format, if you are unsure,
choose Yes or leave the formatting by selecting NO.
• Parking mode – see description further.
• Default Setting - You can return to the factory default settings by selecting
Factory Reset (confirm Yes, exit No).
• Version – shows software version.

EN 13
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Troubleshooting:
3. Troubleshooting:
Please read before contacting your dealer or repair centre.
• Photos and recordings cannot be taken.
Check the inserted card to determine it is functional and has enough free
capacity or that the card does not have an overwrite lock applied.
• The recording process stops by itself.
Check the integrity of the inserted card, format it in the device or use a
different card, preferably a faster one. If you've reached the limit of the file
system, select recording division into smaller sections.
• “File Error” appears when playing a video or viewing photos.
The file is corrupted due to the memory card, try formatting the card or
replace it with a new one.
• Blurred image
Check whether the lens is dirty, and if necessary, clean the lens using fine
cleaner, which you would also use, for example, to clean your glasses.
• The colours of photos are not true even in daylight.
Check the white balance in Settings.
• Stripes in the image
The scene contains light with a frequency of 50 Hz or 60 Hz, based on your
network. Adjust the frequency in Settings to compensate for stripes.
• The device SW stopped.
Press Reset to restart the device.

14 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Technical data
4. Technical data
LCD display 1.5”, HD, LCD
Lens Wide angle high resolution
Video size 1296P/1080P/720P
Video format/codec H.264 MOV
Picture resolution 12M/10M/8M/5M/3M/2M/1.3M/VGA
Picture format JPG
Storage MicroSD card up to 64 GB (not included)
Microphone/Speaker Embedded
Mains frequency 50 Hz/60 Hz
USB port USB 2.0
Power 5 V, 1 A
Battery 180 mAh
Dimensions 59 × 58,5 × 48,5 mm
Weight 58 g
Note: We reserve the right to make updates for better performance or adaptations
without prior notice.
The original version is in Czech.
Manufacturer address: FAST ČR, a.s., Černokostelecká 1621, Říčany CZ-251 01

EN 15
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Technical data
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING
Take the used packaging material to the municipal waste disposal.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electrical and
electronic products should not be treated as regular household waste. For proper
disposal, recovery and recycling of these products bring them to designated collection
points. Alternatively, in some European Union states or other European countries
you may return your products to your local retailer when buying an equivalent new
product. Correct disposal of this product will help save valuable natural resources and
prevent any potential negative impacts on the environment and human health, which
could otherwise be caused by improper waste disposal. For more details, please
contact your local authorities or the nearest collection site. You can receive a fine in
accordance with national regulation when disposing of this kind of waste improperly.
For business entities in the European Union
To dispose of electrical or electronic device, request the necessary information from
your vendor or supplier.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. To dispose of this product, request the
necessary information about the correct disposal method from local government
departments or from your vendor.
This product meets all the basic requirements of EU directives that apply to it.
Changes to the text, design and technical specifications can be done without
previous notice and all rights are reserved.

16 EN
EN
Revision 11/2019Copyright © 2019, Fast ČR, a. s.
Technical data
EN Warranty conditions
Warranty is not supplied in the packaging of the product.
The vendor provides the buyer with a product warranty of 24 months from the receipt of the product by the buyer. The
warranty is provided under following conditions. The warranty applies only to new consumer goods sold to the consumer for
normal home use. The buyer can apply his rights from liability for defects (claim), either at the vendor where the product was
purchased or at the authorized service below. The buyer is obliged to make a claim without delay to prevent the worsening
of the defect, but no later than at the end of the warranty period. The buyer is obliged to provide cooperation for the claim
necessary to verify the existence of a defect. Only complete and for the purposes of maintaining hygiene regulations a clean
product can be accepted for claim processing. In the case of a justified claim the warranty period is extended by a period from
the time the claim is made until return of the repaired product to a buyer or when the buyer after it was repaired is obliged
to take the product. The buyer is obliged to prove his right to complain (proof of purchase, warranty card, certificate of putting
into the product in operation).
The warranty does not extend to:
•defects for which discount was granted;
•wear and tear caused by normal use of the product;
•product damage due to improper or incorrect installation, use of the product not in accordance with the instructions for
use, applicable laws and generally known and conventional methods of use, as a result of use of the product for any
purpose other than that for which it is intended;
•product damage caused by neglected or improper maintenance;
•product damage caused by dirt, accident and higher power (Natural disaster, fire, penetration of water);
•product defects caused by incorrect quality of the signal, electromagnetic interference, etc., mechanical damage of the
product (e.g. breaking a button, fall, etc.);
•damage caused by using unsuitable media, cartridges, consumables (battery) or unsuitable operating conditions (e.g. high
ambient temperatures, high humidity, vibrations);
•damage, modification or other intervention in the product performed by a unauthorized person (service);
•in cases, when the buyer cannot prove his rights (when and where he purchased the claimed product);
•in cases, when the data in the provided documents differ from data provided on the product;
•in cases where the claimed product cannot be identified with the product mentioned in the documents with which the
buyer proves his rights to claim (i.e. damaged serial number or warranty seal of the device, overwritten data in the
documents).
Warranty service in Czech Republic:
FAST ČR, a.s., Černokostelecká 1621, 251 01 Říčany; tel: [phone]
FAST ČR, a.s., Cejl 31, 602 00 Brno; tel: [phone]
You can find more authorized service centres in the Czech Republic at www.sencor.cz.
