Sencor SPT 2700 User manual

SPT 2700
EN User Manual Boombox with Bluetooth
CZ Uživatelská příručka Boombox stechnologií Bluetooth
SK Používateľská príručka Boombox stechnológiou Bluetooth
HU Felhasználói kézikönyv Boombox Bluetooth technológiával
PL Podręcznik użytkownika Boombox ztechnologią Bluetooth

EN – 2
LOCATION OF THE CONTROLLERS
NAMES OF CONTROLLERS
1. LCD DISPLAY
2. MEM/P-MODE button
(Memory/Programming Mode)
3. STOP BUTTON
4. BUTTON
5. 10/M./FOLD.- BUTTON
(10 / Memory / Folder-)
6. BUTTON
7. PAIR/PLAY/PAUSE BUTTON
8. BUTTON
9. 10/M./FOLD.+ BUTTON
(10 / Memory / Folder+)
10. VOLUME- BUTTON
11. USB PORT
12. VOLUME+ BUTTON
13. BATTERY COMPARTMENT
14. AUX IN CONNECTOR (External input)
15. PHONE CONNECTOR (Headphones)
16. FM ANTENNA
17. AC SOCKET (mains power)
18. HANDLE for transporting the device
L. LEFT AUDIO CHANNEL
R. RIGHT AUDIO CHANNEL

EN – 3
Boombox with Bluetooth Technology
ENERGY SOURCE
This device is designed for AC/DC power supply.
POWER SUPPLY FROM THE MAINS
Connect one end of the mains power cord to a mains socket (AC 100–240 V~, 50/60 Hz) on the device
and the other end with the plug to a mains socket in the home. The battery will automatically disconnect.
BATTERY POWER SUPPLY
Open the BATTERY COMPARTMENT DOOR. Insert 6 UM-2/C batteries (not included) into this
compartment. The battery compartment shows the arrangement and polarity of the batteries. Always
observe the correct battery polarity.
NOTICE
If the batteries are low or if you will not be using them for a long time, remove them from the device.
PHONE CONNECTOR (Headphones)
To listen to music in private, connect a 3.5mm headphone jack (not included) to the PHONE jack.
The output from the speakers is automatically terminated.
CAUTION:
PROLONGED LOUD LISTENING ADVERSELY AFFECTS HUMAN HEARING.
BASIC FUNCTIONS
TURNING THE DEVICE ON/OFF
Press to turn the device on; to turn the device off, press and hold the button.
Note: If the device is idle for more than 15 minutes in CD/MP3/USB/BT/AUX mode, it will automatically
shut down. Press the button again to turn on the device.
If your source (e.g. mobile phone) is set to low output volume in BT or AUX-IN mode, the SPT 2700 will
evaluate the “missing audio signal” and automatically turn off.
VOLUME SETTING
Press the VOLUME+ or VOLUME- button to increase or decrease the volume.
LISTENING TO THE RADIO
1. Press the button repeatedly to select the FM band
2. Tune in to the desired station by pressing the or button on the unit – the band frequency will
be shown on the display. Example: FM 97.15 MHz.
3. To optimise reception when listening to FM stations, pull the telescopic antenna out to its full length.
4. Press the button to select additional functions.
AUTOMATIC RADIO STATION SEARCH
Press and hold the PLAY/PAUSE button on the device – the device will start automatic search and
storage of programs with a strong signal. When the search is complete, the P01 program will start. Press
the M.+ or M.- button to listen directly to the saved station.

EN – 4
USING THE RADIO'S MEMORY STATION PRESETS
You can store up to 30 favourite radio (FM) stations in memory, which you can then tune in quickly and
directly without having to retune and search for them.
1. Press or to select the first station you want. Then press the MEM/P-MODE button on the
instrument – the “PROGRAMME” will light up and “P01” will flash on the display.
2. Use the M.+ or M.-buttons to select the desired sequence you want to save, and then press the
MEM/P-MODE button on the unit to confirm.
3. Search for the next station and repeat steps (1) and (2) until you have saved all the desired stations.
Up to 30 stations can be programmed.
4. Press the M.+ or M.- button to listen directly to the saved station.
CD/MP3 PLAYBACK
Discs for playback
This system only supports playback of CD digital audio discs, CD-R finalised digital audio discs
(recordable CDs), CD-RW finalised digital audio discs (rewritable CDs), and CD/CD-R/CD-RW digital
audio discs in CD-DA format.
INSERTING A DISC
1. Press to select the “CD” mode.
2. Press the PUSH TO OPEN button to open the CD drive door – the display will show “OP” (Open).
3. Insert the audio CD into the CD drive with the front side facing up.
4. Close the CD drive door.
The display will show a flashing “- - -”, the total number of tracks and, if the disc contains multiple
folders, the total number of folders. Playback starts from the first track.
5. To remove a CD, press the STOP button to stop playback and then the PUSH TO OPEN button to
open the CD drive door – the display will show “OP” (Open). Grasp the CD by its edges and carefully
remove it.
Note:
● BeforeopeningtheCDdrivedoor,makesurethediscplaybackisstopped(thediscdoesnotrotate).
● Toensurethesystemfunctionsproperly,waituntilthedevicehascompletelyloadedtheentiredisc
before proceeding.
● Ifnodiscisinsertedinthedriveorifthediscisunreadable,“NO”willappearonthedisplay.
CD PLAYBACK
1. When the disc has finished loading, the device starts playback from track 1. The display will show “ ”
and the current track.
You can interrupt playback by pressing the PLAY/PAUSEbutton. The “ ” indicator will flash and the
display will show the current track number.
To resume playback, press the PLAY/PAUSE button again.
2. To stop playback, press the STOP button – the display will show the total number of tracks.

EN – 5
SELECTION OF THE DESIRED TRACK/PASSAGE
Selecting the desired track
In stopped playback mode or playback mode, press the or button until the desired track appears
on the display. Playback will be started automatically. When the device is in stopped playback mode,
press the PLAY/PAUSE button to start playback.
Find a specific passage during playback (high speed track search)
Press and hold the or button to search the currently playing track at high speed; release the
button when you find the desired part of the passage. Playback will restart from this point.
Track selection with track number greater than 10
You can select a song/track with a number greater than 10 by pressing the 10/M/FOLD.- or 10/M/FOLD.+
button.
Select the desired folder (for an MP3 disc containing more than one folder)
Press and hold the 10/M/FOLD.- or 10/M/FOLD.+ button to select the desired folder during playback.
TRACK PROGRAMMING
Disc track programming can be performed while playback is stopped. You can store up to 20 CD tracks or
99 MP3 tracks in any order.
1. In stop mode, press the MEM./P-MODE button – PROGRAMME will flash on the display and P01 will
appear.
2. Press , , 10/M/FOLD.- or 10/M/FOLD.+ to select the first desired track you want to
programme. Press the MEM./P-MODE button to confirm. P02 will appear on the display.
3. Repeat steps 2 and 3 to store the other desired tracks until all tracks have been programmed.
4. Press the PLAY/PAUSE button to start playback from the first programmed track.
5. To stop playing a programme, press the STOP button. To delete a programme, you can press the
STOP button while the disc is stopped playing and open the CD compartment lid – the programme
will be deleted.
REPEAT PLAYBACK
Repeat playback of a single track
1. In playback mode, press the MEM./P-MODE button once – “REPEAT” will flash on the display. The
current track will play over and over again until you press the STOP button.
2. To cancel the repeat function, press the MEM./P-MODE button until “REPEAT” disappears from the
display.
Repeat playback of all tracks
1. In playback mode, press the MEM./P-MODE button twice – “REPEAT” will light up on the display and
all tracks on the disc will play repeatedly until you press the STOP button.
2. To cancel repeat playback, press the MEM./P-MODE button until the “REPEAT” indication goes off.

EN – 6
Folder replay (only for an MP3 disc containing more than one folder)
1. Press the MEM./P-MODE button on the device until “ REPEAT FOLDER” lights up on the display. The
current folder will play repeatedly until you press the STOP button on the device.
2. To cancel the repeat playback, press the MEM./P-MODE button on the device until the “REPEAT
FOLDER” indication goes off from the display.
RANDOM PLAYBACK
In playback mode, press the MEM./P-MODE button until “RAN” lights up in the display. Random playback
will automatically start from the next track (or press the skip forward button) and continue until all tracks
have been played and then stop. To cancel, press the MEM./P-MODE button again until the “RAN”
indication goes out of the display.
USB PLAYBACK
1. Press the button on the device to select “USB” mode.
2. Connect the USB device to the USB slot. The LCD display will show “- - -” and then the total
number of tracks and folders stored on the USB. When the USB device is loaded, playback starts
automatically from track 1.
3. Press the PLAY/PAUSE button to pause or resume playback.
4. To stop playback, press the STOP button. The display will show the total number of tracks stored on
the USB device.
5. The repeat play (repeat one track – repeat a folder – repeat all) / random play / skip forward and
backward functions work in the same way as described in “CD/MP3 PLAYBACK” above.
CAUTION:
Due to a number of devices on the market, compatibility and playback support are not guaranteed for
all media. The memory devices you want to connect should be tested in advance and/or formatted as
FAT32. The playback of protected media, files or content stored inside them may fail.
USING BLUETOOTH
1. Press to switch the device to BLUETOOTH function – “bt” will flash rapidly on the LCD
display.
2. Turn on the Bluetooth function on your device, search for “SPT 2700” and connect it. Then, if
requested, enter the password 0000 – BT will light up on the display to indicate the connection is
complete. Start playback on your mobile phone, press PLAY/PAUSE button on the device to start/
stop playback. If the device does not connect to your device within 2 minutes, turn off, turn on the
SPT 2700 and repeat the Bluetooth pairing.
3. Press the VOLUME buttons to select the desired volume level.
4. Press the or button on the device to select the desired track.
5. You can stop playback by pressing the PLAY/PAUSEbutton.
Note: To ensure a stable Bluetooth connection, make sure that the distance between the BT speaker
and your connected device is kept within 10 meters.

EN – 7
USING EXTERNAL INPUT
This device is equipped with a 3.5 mm AUX IN (External Input) connector, through which you can connect
and amplify other audio signal sources to this device.
1. Press to select the “AUX” mode.
2. Connect one end of the audio cable (not included) to the AUX IN connector and the other end to the
AUDIO OUT connector on the external audio source.
3. Press the PLAY/PAUSE button on the external audio source (e.g. MP3 player) to start playback.
Caution:
Before connecting your device to the BT speaker, please make sure that the output signal from your
device is set to minimum (minimum output volume). This will prevent the BT speaker from damage. When
the audio cable is connected, the BT speaker does not meet the water ingression protection class.
MAINTENANCE OF CD DISCS
1. Always use compact discs with this marking.
2. Notes on handling discs
● Removingthediscfromthepackagingandinsertingitintothedevice.
● Donottouchthereflectivesurfacewiththerecording.
● Donotstickorwriteanythingonthesurfaceofthedisc.
● Donotbendthedisc.
3. Storage
● Storethediscinitspackaging.
● Donotexposethediscstodirectsunlightorhightemperatures,highhumidityordusty
environment.
4. Cleaning discs
● Ifthediscbecomesdirty,removedust,dirtandfingerprintswithasoftcloth.
● Cleanthediscbymovingfromthecentreofthedisctotheedges.
RIGHT WRONG
FROM THE CENTRE TO THE EDGES
● Neverusebenzene,thinners,cleaningfluidsoranti-staticsprays.
● MakesuretheCDdrivedoorisclosedsothatthelenscannotbecontaminatedbydust.
● Donottouchthelens.

EN – 8
TECHNICAL SPECIFICATIONS
SPT 2700
Boombox with Bluetooth Technology
Bluetooth 5.0 – Wireless audio streaming
Maximum output power: 3W
USB input and input with 3.5 mm connector
Sound:
Maximum output power: 3W
Frequency response: 60Hz–16kHz
Totalharmonicdistortion:L/R≤10%(1kHz)
Reception:
FM PLL radio tuner
Preset stations: 30
Telescopic antenna
Inputs and outputs:
Bluetooth 5.0 – Wireless audio streaming
USB (for playback)
CD-R/RW/MP3
AUX IN connector 3,5 mm
AUX-OUT 3.5 mm connector (Headphones)
Other:
Programmable track memory
LCD display
Power supply: AC 100–240V, 50/60Hz or 6 × 1.5V type C / LR14 battery (not supplied)
Power consumption: 13W
Dimensions: (W × H × D) 240 × 225 × 126 mm
Weight: 1.2kg
FM radio Band range 87.5MHz–108MHz
Bluetooth Version 5.0
Maximum Transmitter Power 100mW @ 2.4GHz–2.4835GHz
Codec SBC
Profile A2DP

EN – 9
INSTRUCTIONS AND INFORMATION ON THE DISPOSAL OF DISCARDED
PACKAGING MATERIALS
Take the packaging material to a collection yard for recycling.
DISPOSAL OF DISCARDED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the product, accessory or packaging means that the product must not be
treated as normal household waste. Please dispose of this product in a collection yard
designated for the recycling of electrical and electronic equipment. In some EU countries or
other European countries, you can return the old product to your local retailer when you buy
an equivalent new product. By disposing of this product correctly, you help protect valuable
natural resources and prevent potential negative environmental and human health impacts
that could result from improper disposal. For further information, please contact your local
authorities or the nearest waste collection site. You may be fined by law for improper disposal
of this type of waste.
For companies in European Union countries
If you want to dispose of electrical or electronic equipment, ask your dealer or supplier for the
necessary information.
Disposal in countries outside the European Union
Ask your local authorities or your dealer for information on the proper disposal of this product.
This product meets the EU requirements.
FASTČR,a.s.herebydeclaresthattheradioequipmenttypeSPT2700complieswithDirective2014/53/
EU. For the full version of the EU Declaration of Conformity, please visit: www.sencor.cz
Text, design and technical data are subject to change without notice; we reserve the right to make such
changes.
The original version is Czech.
Manufacturer:FASTČR,a.s.,USanitasu1621,Říčany25101,CzechRepublic
Authorised service centres: For detailed information on authorised service centres, please visit
www.sencor.com.

EN – 10
EN Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.

FAST ČR, a. s.,USanitasu1621,ŘíčanyCZ-25101
