Sensocon Theroscan User manual

Thank you for your purchase of the Theroscan
Wrist Thermometer!
Quick Start
1. Installaon
2. Power
3. Screening
Disclaimers
Limited Warranty
Install the wrist thermometer
on a staon post, desk stand, or
using the wall mount bracket.
Connect the provided power cord to the
power jack on the boom of the thermome-
ter and then plug into a wall outlet. Skip this
step if you have the baery power opon.
Power the unit on by pushing the power
buon on the boom of the thermometer.
The Wrist Thermometer is now ready for use.
Place your wrist in the ring and the device
will display your temperature reading.
SENSOCON warrants its products to be free from defects in materials and workmanship for a
period of one (1) year from the date of shipment, subject to the following terms and condi-
ons: Without charge, SENSOCON will repair, replace, or refund the purchase price at SEN-
SOCON’s opon products found to be defecve in materials or workmanship within the
warranty period; provided that:
i. The product has not been subjected to abuse, neglect, accident, incorrect wiring not
our own, improper installaon or servicing, or use in violaon of labels or instrucons
provided by SENSOCON;
ii. The product has not been repaired or altered by anyone except SENSOCON;
iii. The maximum rangs label and serial number or date code have not been removed,
defaced, or otherwise changed;
iv. Examinaon discloses, in the judgment of SENSOCON, the defect in materials or work-
manship developed under normal installaon, use and service; and
v. SENSOCON is noed in advance of and the product is returned to SENSOCON trans-
portaon prepaid before expiraon of the warranty period.
THIS EXPRESS LIMITED WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER REPRESENTA-
TIONS MADE BY ADVERTISEMENTS OR BY AGENTS AND ALL OTHER WARRANTIES, BOTH
EXPRESS AND IMPLIED. THERE ARE NO IMPLIED WARRANTIES OF MERCHANTABILITY OR OF
FITNESS FOR A PARTICULAR PURPOSE FOR GOODS COVERED HEREUNDER.
1. The Theroscan Infrared Thermometer is not a medical device.
2. To prevent damage to the thermometer, do not open the product case.
3. For indoor use only
www.theroscan.com www.theroscan.com
Bullen 116-0

Specicaons
Device Features
Buons and Sengs
Unit—This buon changes the units from
Fahrenheit to Celsius. When the buon light
is on, the unit is in Celcius.
Voice—Turns the voice feature o. When the
buon light is on, the voice feature is o.
Info—First push shows how many readings
have been taken. Second push will give how
many high temperature readings, and third
push will be back in normal operaon.
Press the Enter buon to begin the setup. Scroll through the parameters on the
LED display by pressing the up and down arrow buons. Select the parameter by
pressing the Enter buon. The selected parameter will be shown on the LED dis-
play. Press the up or down arrow buons to set the desired funcon value, and
press the enter buon once more to conrm the selecon. The selecon will be
saved and the LED display will return to the measurement display mode. Below
are the adjustable parameters:
Code Funcon Descripon Factory Sengs
HI Hi Temp Temp above this value turns red light on and
gives voice indicaon of high temperature.
99.1°F/37.3°C
AL Alarm Temp above this value turns on yellow light 98.6°F/37.0°C
Lo Low Temp Temp above this value (but below HI and AL)
will give green light and voice indicaon of nor-
mal temperature.
89.6°F/32.0°C
Ad Adjustment For calibraon of the reading, adjustable range
-3.6°F to +3.6°F (-2.0°C to +2.0°C)
0
Co Voice Set Sets voice report “0” brief, “1” detailed 1
UO Volume Volume range 5-30 22
CLO Clear Results Clears the total number of results
Funcon Buons
Programming
Buons
Audio
Power Buon
and Power Jack
Display
Infrared Temperature
Sensor
Temperature
Indicator
Lights
Moon Sensors
Reset
Buon
Temperature Range: 86-113°F (30-45°C)
Accuracy: Typical +/- 0.18°F (0.2°C) , Maximum +/- 0.36°F (0.2°C)
Power: 100-240 VAC with provided power cord
Baeries (oponal): Rechargeable, 50 hours on full charge
Enclosure: ABS
