Sentry Camera ESM40-C480DN Quick start guide

ESM40-C480DN_ESM40-C420-OSD_ESM34-C420DN_rev012109
Operational Manual
Micro Box Camera
ESM40-C480DN
ESM40-C480DNP ESM40-C420-OSD ESM40-C420-OSDP ESM34-C420DN ESM34-C420DNP
z1/3” Sony CCD
z480 TV Lines
z0.5 Lux (Day) / 0.05 Lux (Night)
zC/CS Mount
z12V DC
z1/3” Sony CCD
z420 TV Lines
z0.5 Lux (Day) / 0.05 Lux (Night)
zC/CS Mount
zOSD with Day & Night Function
z12V DC
z1/3” Sony CCD
z420 TV Lines
z0.5 Lux (Day) / 0.05 Lux (Night)
zC/CS Mount
z12V DC
Sentry Camera products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased. We have no other way
to verify the purchase record without the serial number on the camera sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided immediately. It is the customer’s
responsibility to keep the camera in good condition.
zOne (1) ESM40-C480DN/ESM40-C480DNP or ESM40-C420-OSD/ESM40-C420-OSDP or ESM34-C420DN/ESM34-C420DNP Box Camera
zOne (1) Mounting Bracket
zOne (1) Lens Adjustor
zOne (1) Operational Manual
*For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any
component is missing/damaged or if any cable is cut or tampered with.
ESM40-C480DN
ESM40-C420-OSD
ESM34-C420DN
FEATURES
Please read the Operational Manual
before attempting to use this product.
DIMENSIONS
ESM40-C480DN/ESM40-C480DNP
ESM40-C420-OSD/ESM40-C420-OSDP
ESM34-C420DN/ESM34-C420DNP
LIST OF COMPONENTS
ESM40-C480DNP
ESM40-C420-OSDP
ESM34-C420DNP
WARRANTY
ESM34-C420DN/ESM34-C420DNP

ESM40-C480DN_ESM40-C420-OSD_ESM34-C420DN_rev012109
ON-SCREEN DISPLAY & FUNCTIONS FOR ESM40-C420-OSD
/
ESM40-C420-OSDP

ESM40-C480DN_ESM40-C420-OSD_ESM34-C420DN_rev012109
Model ESM40-C480DN ESM40-C480DNP ESM40-C420-OSD ESM40-C420-OSDP ESM34-C420DN ESM34-C420DNP
Signal Format NTSC PAL NTSC PAL NTSC PAL
Image Sensor 1/3” Sony CCD
Resolution 480 TV Lines 420 TV Lines
Effective
Pixels 510(H)x492(V) 500(H)x582(V) 510(H)x492(V) 500(H)x582(V) 510(H)x492(V) 500(H)x582(V)
Scanning
System 525 Lines 60 field/sec. 625 Lines 50 field/sec. 525 Lines 60 field/sec. 625 Lines 50 field/sec. 525 Lines 60 field/sec. 625 Lines 50 field/sec.
Sync Mode Internal Synchronization
S/N Ratio More than 48dB (AGC Off) Selectable More than 48dB (AGC Off)
Gamma
Characteristic 0.45 Selectable 0.45
Minimum
Illumination 0.5 Lux (Day) / 0.05 Lux (Night)
Gain Control Auto N/A Auto
BLC Auto Selectable Auto
White
Balance Auto Selectable Auto
Electronic
Shutter
Speed
1/60~1/100,000
sec. 1/50~1/100,000 sec. Selectable 1/60~1/100,000 sec. 1/50~1/100,000 sec.
Day & Night Yes
OSD Function No Yes No
Lens Not Included
Video Output 1Vp-p, 75 Ohms, Negative Selectable 1Vp-p, 75 Ohms, Negative
Power Supply 12V DC, 10% / 100mA
Operating
Temperature 14°F~122°F / -10°C~50°C, RH 95% Max.
Storage
Temperature -4°F~140°F / -20°C~60°C, RH 95% Max.
Dimensions 1.57”(W) x 1.57”(H) x 2.13”(L)
40(W) x 40(H) x 54(L) mm 1.34”(W) x 1.34”(H) x 1.89”(L) 34(W) x 34(H) x 48(L) mm
*Specifications are subject to change without notice
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
The allowable temperature range for operation of this camera is between 14°F~122°F / -10°C~50°C and the allowable humidity level is below 95%. Do not expose
the camera to rain or moisture. Do not try to operate the camera in wet area. Moisture can damage the camera and can cause electric shock.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before lens installation or whenever the lens is changed. Cleaning should be done by using a
chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the specifications). Camera must be connected to a surge protector at all
times. It is recommended that you use a regulated 12V DC power supply with camera for best picture quality and for safe operation of the unit. Unregulated 12V
DC power supply usually provides around 17~20V after loaded, and can cause damage to the camera.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of short out parts that could result in a fire or electric shock. Never
spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all service
to qualified servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has been damaged.
e. When the video product exhibits a distinct change in performance.
9. Use a suitable monitor
Use a monitor which has the standard video input impedance level of 75 ohms.If in any case your monitor is setto high impedance mode, please switch the monitor
to the standard impedance position.
SPECIFICATIONS
CAUTION
P = PAL Version
