Sercomm NV842 User manual

Video Server
User’s Guide


i
Table of Contents
CHAPTER 1 INTRODUCTION.............................................................................................. 1
Overview ............................................................................................................................ 1
Physical Details - Video Server......................................................................................... 3
Package Contents .............................................................................................................. 4
CHAPTER 2 BASIC SETUP ................................................................................................... 6
System Requirements........................................................................................................ 6
Installation - Video Server................................................................................................ 6
Setup using the Windows Wizard .................................................................................... 7
CHAPTER 3 VIEWING LIVE VIDEO ................................................................................ 12
Overview .......................................................................................................................... 12
Requirements ................................................................................................................... 12
Connecting to a Video Server on your LAN ................................................................. 12
Connecting to a Video Server via the Internet.............................................................. 14
Viewing Live Video ......................................................................................................... 16
CHAPTER 4 ADVANCED VIEWING SETUP ................................................................... 18
Introduction ..................................................................................................................... 18
Controlling User Access to the Video Stream ............................................................... 20
Making Video available from the Internet.................................................................... 21
Viewing Live Video via the Internet .............................................................................. 24
Motion Detection Alerts.................................................................................................. 25
CHAPTER 5 WEB-BASED MANAGEMENT .................................................................... 26
Introduction ..................................................................................................................... 26
Connecting to Video Server............................................................................................ 26
Welcome Screen............................................................................................................... 27
Administration Menu...................................................................................................... 28
System Screen .................................................................................................................. 29
Network Screen................................................................................................................ 31
Wireless Screen (Wireless Model Only) ........................................................................ 35
DDNS Screen.................................................................................................................... 38
IP Filter Screen................................................................................................................40
I/O Port Screen ................................................................................................................ 41
RS485 Screen ................................................................................................................... 42
Streamings........................................................................................................................ 45
Video & Audio Screen..................................................................................................... 47
Video Access Screen ........................................................................................................ 49
User Database Screen...................................................................................................... 51
Motion Detection Screen................................................................................................. 52
Audio Detection Screen................................................................................................... 53
E-Mail Screen .................................................................................................................. 54
FTP Screen....................................................................................................................... 56
HTTP Screen.................................................................................................................... 57
SD Card Screen ............................................................................................................... 58
SMB/CIFS Client Screen ................................................................................................ 60
Trigger & Recording Screen .......................................................................................... 61
Maintenance Screen ........................................................................................................ 63
Status Screen.................................................................................................................... 65
Log Screen........................................................................................................................ 67

ii
CHAPTER 6 WINDOWS VIEWING/RECORDING UTILITY........................................ 68
Overview .......................................................................................................................... 68
System Requirements...................................................................................................... 68
Installation ....................................................................................................................... 68
System Tray Icon............................................................................................................. 69
LiveView Screen .............................................................................................................. 70
Camera Setup .................................................................................................................. 71
LiveVew Program - for Streams Live Viewing............................................................. 73
View Recordings Program - for Streams Recording.................................................... 75
Setup Program - for Streams Configuration................................................................. 77
CHAPTER 7 TROUBLESHOOTING .................................................................................. 80
Overview .......................................................................................................................... 80
Problems........................................................................................................................... 80
APPENDIX A SPECIFICATIONS........................................................................................ 83
Video Server..................................................................................................................... 83
Regulatory Approvals ..................................................................................................... 83
Copyright Notice.............................................................................................................. 84
APPENDIX B NETWORK CAMERA HTTP CGI ............................................................. 85
User-level CGI commands (user level privilege)........................................................... 85
Admin-level CGI commands (administrator level privilege)..................................... 111
Appendices ..................................................................................................................... 132
P/N: 956YYF0001
Copyright ©2011. All Rights Reserved.
Document Version: 1.0
All trademarks and trade names are the properties of their respective owners.

1
This Chapter provides details of the Video Server's features, components and
capabilities.
Overview
The Video Server digitizes analog video signals and transmits digital images directly to your
wired LAN or the Internet. The Video Server is a device that used to turn an analog video
system into high performance IP-based solutions. The Video Server comes with the RS-485
interface, which can be used for external PTZ devices. It also supports Digital I/O (4-IN, 4-
OUT) for external sensors and alarms. Up to 10 authorized viewers from different locations
can view the H.264, MPEG-4 and M-JPEG streams simultaneously.
H.264 uses the new innovations in video compression technology to provide excellent video
quality from the low video data. Bit rate can be saved up more with nearly lossless coding
while using H.264. The intent of the H.264 project was to create a standard capable of
providing good video quality at lower bit rates than previous standards, without increasing the
complexity of design which would be impractical or expensive to implement.
A convenient and user-friendly Windows program is provided for both viewing and recording
video. If necessary, you can even view video using your Web Browser, on a variety of software
platforms.
Features
•
Triple Stream Live Video to Multiple Users.
The H.264, MPEG4 and JPEG encoders
built into the video server generate a ready-to-view video stream. Just connect to the video
server using your Web browser or the provided Windows utility to view live video.
•
Suitable for Home, Business or Public Facilities
. Whether for Home, Business or
Public Facility surveillance, the Video Server has the features you need.
•
Multi-Protocol Support.
Supporting TCP/IP networking, SMTP (E-mail), HTTP and
other Internet related protocols, the Video Server can be easily integrated into your
existing network.
•
Easy Configuration.
A Windows-based Wizard is provided for initial setup.
Subsequent administration and management can be performed using a standard web
browser. The administrator can configure and manage the Video Server via the LAN or
Internet.
•
SD Card Slot
. With the slot, you can insert the SD card to store recording files.
•Viewing/Recording Utility.
A user-friendly Windows utility is provided for viewing
live video. For periods when you are absent, or for scheduled recording, this application
also allows you to record video on your PC. Use the Playback function of the supplied
Windows utility to view the recorded files.
•3D-Deinterlace Support.
It can
provide clearer image when movement speed of the
view is moderate. It provides high quality edge preserving deinterlacing with the 4th
generation motion adaptive 3D-Deinterlacing algorithm and performs proper processing
for fast motion and film video sources.

2
•
Motion Detection.
This feature can detect motion in the field of view. The Video Server
will compare consecutive frames to detect changes caused by the movement of large
objects. Motion detection alarm can be triggered via e-mail, FTP, instant messaging and/or
an external alarm device.
•
Flexible Scheduling.
You can limit access to the video stream to specified times using
a flexible scheduling system. The Motion Detection feature can also have its own schedule,
so it is active only when required.
•
Syslog Support.
If you have a Syslog Server, the Video Server can send its log data to
your Syslog Server.
•
Audio Support.
You can listen as well as look! Audio is encoded with the video if
desired. You can connect an external microphone to the video server.
•
IP Filter.
Use the IP Filter to block/accept access to the IP addresses.
•
User-definable HTTP/ HTTPS port number
. This allows Internet Gateways to use
"port mapping" so the Video Server and a Web Server can share the same Internet IP
address.
•
DDNS Support.
In order to view video over the Internet, users must know the Internet
IP address of the gateway used by the Video Server. But if the Gateway has a dynamic IP
address, DDNS (Dynamic DNS) is required. Since many existing Gateways do not support
DDNS, this function is incorporated into the Video Server.
•
NTP (Network-Time-Protocol) Support.
NTP allows the Video Server to calibrate its
internal clock from an Internet Time-Server. This ensures that the time stamp on Video
from the Video Server will be correct.
•
PoE Support.
(Wired Model Only)
You can use IEEE 802.3af PoE (Power over
Ethernet) to provide power to the Video Server, so only a single cable connection is
required.
Security Features
•
User Authentication.
If desired, access to live video can be restricted to known users.
Users will have to enter their username and password before being able to view the video
stream. User authentication is not required if the Multicast feature is enabled.
•
Password-Protected Configuration
. Configuration data can be password protected, so
that it only can be changed by the Video Server Administrator.
Wireless Features (Wireless Model Only)
•
Supports 802.11b, 802.11g and 802.11n Standards.
The 802.11n standard provides
for backward compatibility with the 802.11b standard, so 802.11n, 802.11b and 802.11g
Wireless stations can be used simultaneously.
•
Wired and Wireless Network Support.
The Video Server supports either wired or
wireless transmission.
•
WEP Support
. Full WEP support (64/128 Bit) on the Wireless interface is provided.
•
WPA/WPA2 Support
. The WPA Personal/WPA2 Personal standard is also supported,
allowing advanced encryption of wireless data.
•
WPS Support.
WPS (Wi-Fi Protected Setup) can simplify the process of connecting any
device to the wireless network by using the push button configuration (PBC) on the
Wireless Access Point, or entering a PIN code if there's no button.

3
Physical Details - Video Server
Front - Video Server
Figure 1: Front Panel
RESET button This button is recessed; you need a pin or paper clip to press it. It
can be activated at any time the video server is in the "ready" mode.
•Reset to manufacturer default value and reboot. When
pressed and held over 10 seconds, the settings of Video Server
will be set to their default values.
Note:
After this procedure is completed, the Power LED will blink three
times to confirm that the reset was completed successfully.
CH1~CH4 Each channel includes a video in port and an audio in port.
•Video in: It supports a single composite video source by using a
BNC connector.
•Audio in: If required, an external microphone can be attached
here. Microphones designed to be used with PCs are usually
compatible with this microphone input.
Output Channel This channel includes a video in port and an audio in port.
•Video in: Loop-through connection to the video signal from the
Video In connector. It allows direct connection to an external
monitor.
•Audio in: If required, an external microphone can be attached
here.
•Video Channel Switch: Push this button to switch the monitor
between the 4 input channels (CH1, CH2, CH3, CH4, CH1~4).
WPS Button Push the WPS button on the device and on your other wireless
device to perform WPS function that easily creates an encryption-
secured wireless connection automatically.
•WPS PBC Mode. When pressed and released (less then 3
seconds), the Network Camera will be in the WPS PBC mode
(Auto link mode).
•WPS Pin Code Mode. When pressed and held for over 3
seconds, the Network Camera will be in the WPS Pin Code
mode.

4
WPS LED
(Green)
On - Wireless security is On.
Off - Wireless security is Off.
Flashing - WPS sync is in progress.
Network LED
(Green)
On - LAN connection is detected.
Off - LAN connection is not detected
Blinking - Data is being transmitted or received via the LAN
connection.
POWER LED
(Green)
On - Power on.
Off - No power.
Blinking - The POWER LED will blink during start up. This will
take 15 to 20 seconds.
Rear - Video Server
Figure 2: Rear Panel
POWER Connect the supplied 12V power adapter here. Do not use other
power adapters; doing so may damage the video server.
ETHERNET port Use a standard LAN cable to connect your Video Server to a
10/100BaseT hub or switch.
RS485 The terminal block includes 1 RS-485 port (2 pins)
IO Ports The terminal block includes 8 GND ports, 4 input ports and 4 output
ports.
SD/SDHC Card
slot
Insert the SD card into the slot, if required.
Package Contents
The following items should be included: If any of these items are damaged or missing, please
contact your dealer immediately.
1. Video Server
2. Power adapter
3. Antennae (Wireless Model Only)
4. Installation CD-ROM

5
5. Quick Installation Guide
6. GPIO 8 pin x 2
7. RS-485 2 pin x 1

6
This Chapter provides details of installing and configuring the Video Server.
System Requirements
To use the wired LAN interface, a standard 10/100BaseT hub or switch and network cable is
required.
Installation - Video Server
1. Assemble the Video Server
For Wireless model, screw the supplied antennae to the mounting points on the rear.
2. Connect the LAN Cable
Connect the Video Server to a 10/100BaseT hub or switch, using a standard LAN cable.
For Wireless model, this will disable the Wireless Interface.
The Wireless and LAN interfaces cannot be used
simultaneously. Using the LAN interface is recommended for
initial configuration. After the Wireless settings are correct,
the Wireless interface can be used.
The first time you connect to the camera, you should connect
the LAN cable and configure the Network Camera with
appropriate settings. Then you can unplug the LAN cable and
power off the camera. The Network Camera will be in wireless
interface when you power on the camera again.
3. Connect the Camera
Connect the video output of the camera to the video in of the Video Server, using a
standard video cable with BNC connectors.
4. Power Up
Connect the supplied 12Vpower adapter to the Video Server and power up. Use only the
power adapter provided. Using a different one may cause hardware damage.
5. Check the LEDs
•The Power LED will turn on briefly, then start blinking. It will blink during startup, which
takes 15 to 20 seconds. After startup is completed, the Power LED should remain ON.
•The Network LED should be ON.
For more information, refer to Physical Details - Video Server in Chapter 1.

7
Setup using the Windows Wizard
Initial setup should be performed using the supplied Windows-based setup Wizard. This
program can locate the Video Server even if its IP address is invalid for your network. You can
then configure the Video Server with appropriate TCP/IP settings for your LAN.
Subsequent administration can be performed with your Web browser, as explained in Chapter
5 - Web-based Management.
Setup Procedure
1. Insert the supplied CD-ROM into your drive. If the setup program does not start
automatically, run NetworkCamera.exe in the root folder.
•You will see the Welcome screen shown below.
•Click the Setup button to start the setup Wizard.
Figure 3: Welcome Screen
2. The next screen, shown below, will list all the Video Servers on your LAN.
Figure 4: Camera List Screen

8
•Select the desired video server from the list on the left. The current settings for the
selected video server will be displayed in the table on the right.
•Click Next to continue.
3. You will be prompted to enter the Administrator Name and Administrator Password, as
shown below.
•If using the default values, enter administrator for the name, and leave the
password blank.
•Otherwise, enter the Administrator Name and Administrator Password set on the
Maintenance screen.
Figure 5: Password Dialog
4. This screen allows you to enter a suitable Description, and set the correct Time Zone,
Date, and Time. Make any desired changes, then click Next to continue.
Figure 6: Camera Settings
5. On the following IP Address Settings screen, shown below, choose Fixed IP Address,
Dynamic IP Address or PPPoE.

9
Figure 7: Fixed or Dynamic IP Selection
•Fixed IP is recommended, and can always be used.
•Dynamic IP can only be used if your LAN has a DCHP Server.
•PPPoE (PPP over Ethernet) is the most common login method, widely used with
DSL modems.
Click Next to continue.
6. If you chose Fixed IP Address, the following TCP/IP Settings screen will be displayed.
Figure 8: TCP/IP Settings
•Enter an unused IP Address from within the address range used on your LAN.
•The Subnet Mask and Default Gateway fields must match the values used by PCs on
your LAN.
•The Primary DNS address is required in order to use the E-mail alert or Dynamic
DNS features. Enter the DNS (Domain Name Server) address recommended by your
ISP.
•The Secondary DNS is optional. If provided, it will be used if the Primary DNS is
unavailable.

10
Click Next to continue.
7. If you chose PPPoE, the following PPPoE Settings screen will be displayed.
Figure 9: PPPoE Settings Screen
•Enter the User Name provided by your ISP.
•Enter the Password for the user name above.
Click Next.
8. The next screen, shown below, displays all details of the Video Server.
•Click Next if the settings are correct
•Click Back to modify any incorrect values.
Figure 10: Save Settings
9. Click OK to confirm that you want to save the new settings. If you want to cancel your
changes, click Cancel.

11
Figure 11: Confirm Screen
10. After clicking OK, you will see the screen below.
Figure 12: Final Screen
Clicking the Install Utility button will install the Viewing/Recording utility described in
Chapter 6 - Windows Viewing/Recording Utility.
11. Click Exit to end the Wizard.
Setup is now complete.

12
This Chapter provides basic information about viewing live video.
Overview
After finishing setup via the Windows-based Wizard, all LAN users can view live video using
Internet Explorer on Windows.
This Chapter has details of viewing live video using Internet Explorer.
But many other powerful features and options are available:
•To view multiple video servers simultaneously, or record video (either interactively or by
schedule), you should install the Windows Viewing/Recording utility. Refer to Chapter 6 -
Windows Viewing/Recording Utility for details on installing and using this program.
•The video server administrator can also adjust the Video Stream, and restrict access to the
video stream to known users by requiring viewers to supply a username and password. See
Chapter 4 - Advanced Viewing Setup for details.
•To make Live Video from the video server available via the Internet, your Internet
Gateway or Router must be configured correctly. See Making Video available from the
Internet in Chapter 4 - Advanced Viewing Setup for details.
Requirements
To view the live video stream generated by the Video Server, you need to meet the following
requirements:
•Windows XP, 32-bit Windows Vista/Windows 7.
•Internet Explorer 6 or later, Firefox 3.0 or later.
Connecting to a Video Server on your LAN
To establish a connection from your PC to the Video Server:
1. Use the Windows utility to get the IP address of the Video Server.
2. Start Internet Explorer.
3. In the Address box, enter "HTTP://" and the IP Address of the Video Server.
4. When you connect, the following screen will be displayed.

13
Figure 13: Home Screen
5. Click View Video.
6. If the Administrator has restricted access to known users, you will then be prompted for a
username and password.
Enter the name and password assigned to you by the Video Server administrator.
7. The first time you connect to the Video Server, you will be prompted to install an ActiveX
component (OCX or CAB file), as in the example below.
You must install this ActiveX component (OCX or CAB file) in order to view the
Video stream in Internet Explorer.
Click the "Yes" button to install the ActiveX component.
Figure 14: ActiveX OCX Prompt
8. Video will start playing automatically. There may be a delay of a few seconds while the
video stream is buffered.

14
Connecting to a Video Server via the Internet
You can NOT connect to a Video Server via the Internet unless the Video Server
Administrator has configured both the Video Server and the Internet
Gateway/Router used by the Video Server.
See Making Video available from the Internet in Chapter 4 - Advanced Viewing Setup for
details of the required configuration.
Also, you need a broadband Internet connection to view video effectively. Dial-up connections
are NOT supported.
To establish a connection from your PC to the Video Server via the Internet:
1. Obtain the following information from the Administrator of the video server you wish to
connect to:
•Internet IP Address or Domain Name of the video server.
•Port number for HTTP connections.
•Login (username, password) if required.
2. Start Internet Explorer.
3. In the Address box, enter the following:
HTTP://Internet_Address:port_number
Where Internet_Address is the Internet IP address or Domain Name of the video
server, and port_number is the port number used for HTTP (Web) connections to the
video server.
Examples using an IP address:
HTTP://203.70.212.52:1024
Where the Internet IP address is 203.70.212.52 and the HTTP port number is 1024.
Example using a Domain Name:
HTTP://mycamera.dyndns.tv:1024
Where the Domain name (using DDNS in this example) is mycamera.dyndns.tv and
the HTTP port number is 1024.

15
4. When you connect, the following screen will be displayed.
Figure 15: Home Screen
5. Click View Video.
6. If the Administrator has restricted access to known users, you will then be prompted for a
username and password.
Enter the name and password assigned to you by the Video Server administrator.
7. The first time you connect to the video server, you will be prompted to install an ActiveX
component (OCX or CAB file), as in the example below.
You must install this ActiveX component (OCX or CAB file) in order to view the
Video stream in Internet Explorer.
Click the "Yes" button to install the ActiveX component.
Figure 16: ActiveX OCX Prompt
8. Video will start playing automatically. There may be a delay of a few seconds while the
video stream is buffered.

16
Viewing Live Video
After installing the ActiveX component, you be able to view the live video stream in its own
window, as shown below.
Adjust focus manually by turning the front lens until the video becomes clear.
Figure 17: View Video Screen
There are a number of options available on this screen, accessed by select list, button or icon.
See the table below for details.
Note: The options can only be configured while using IE browser. Other browsers can just
view the video rather than configuration.
If after installing the OCX, the video still cannot be viewed, please install the decoders to solve
this problem. You can install it from the following screens:
•Supplied Windows-based setup Wizard
•View Video Screen (preferred)
Figure 18: Install Decorders
•Motion Detection Screen
Table of contents
Popular Server manuals by other brands

Digital Equipment
Digital Equipment DECserver 90M owner's manual

Huawei
Huawei V100R005C10 Quick installation guide

Nortel
Nortel 1000S Service Implementation Guide

Avaya
Avaya IP600 overview

Moxa Technologies
Moxa Technologies NPort 5150AI-M12 Quick installation guide

Lenovo
Lenovo System x3550 M5 Product guide
