Serenity Bowl Water with Globe Light Feature User manual

1
Bowl Water with Globe Light Feature Instruction Manual
For correct usage, please read these instructions carefully before first use and store in a
safe place for future reference.
After Sales Support
Call 0871 911 7031
Email
[email protected]
Product Code: G3888
Thank you for purchasing this
product, which has been made to high
quality standards and is guaranteed for
domestic use against manufacturing
faults for a period of 12 months from
date of purchase

2
INTRODUCTION
Congratulations
You have made an excellent choice with the purchase of this quality Serenity water feature.
By doing so you now have the assurance and peace of mind which comes from purchasing a
product that has been manufactured to the highest standards, performance and safety.
We want you to be completely satisfied with your purchase, so the Serenity water feature is
backed by our full 12-month manufacturer’s guarantee and an outstanding after sales service
through our dedicated helpline.
We hope you enjoy using your purchase for many years to come.

3
Safety warnings and general information
•Use this product only in accordance with the instructions.
•Children should be supervised to ensure that they do not play with product.
•This product is not a toy.
•Keep the product and its power cable out of reach of children.
•Before cleaning and when not in use unplug from the mains supply.
•Do not handle the electrical components with wet hands.
•Do not use the appliance with a damaged power cord or plug.
•To avoid hazards, ensure that any electric cable is safely out of the way of children and
pets.
•Where possible ensure all power cables are positioned away from footfall areas.
•It is important that an RCD (Residual Current Device) is present and any product of this
type is connected to it.
•When removing re-positioning or replacing the water pump make sure the power is off
and the plug is out of the socket.
•Repairs to electrical equipment should only be performed by a qualified electrician.
Improper repairs may place user at serious risk.
•Always use the original power cable supplied with the product.
•Make sure the voltage on the rating label matches the mains power supply to be used.
•Do not unplug by pulling the power cable.
•Water temperature must not exceed 35°C. Top the water levels up frequently during hot
weather.
•In very low temperatures, drain, dry and protect the water feature from frost, snow and
ice.
•This product is designed for outdoor use only and should not be positioned where water
spillage may damage carpets or furnishings.
•Always position on a flat level surface.
•The chosen location should be free from overhanging trees and bushes which may shed
their leaves in autumn.
•Ensure that the water level is always enough; do not allow the pump to run dry.
•To eliminate the possibility of water damage around your water feature, check for leaks
and excessive splashing after the initial setup.
•Do not leave your water feature running for extended periods of time unattended.
•Occasionally the water pump may make excessive noise, this may be due to the pump
rattling against the side of the reservoir or a small amount of trapped air. Always ensure
that the pump is suckered to the base using the rubber feet. Remove any trapped air by
gently shaking the water pump.
•This water feature is not suitable for commercial purposes.

4
LED light power cable
Assembly
1. Position on a flat, level surface. Twist off the plastic globe and insert the lightbulb.
2. Take the top bowl (with water tube attached) and feed the water tube into the hole at the
top of the water feature.
3. Lower the bowl into position.
4. Connect the water tube to the water pump.
5. Connect the LED light cable to the plug adaptor.
6. Position the water pump inside the water reservoir at the back of the water feature,
secure it to the base of the water reservoir using the suckers to prevent the pump from
moving around.

5
Water flow adjustor
7. Fill the water reservoir with clean, cold tap water, ensuring that the water pump is fully
submerged.
8. Connect the pump cable to the adaptor plug then plug into a suitable power supply and
switch it on.
9. Once the water starts flowing, add more water to the water reservoir as needed to ensure
that the water pump remains submerged.
10. If you would like to adjust the flow of the water, turn the flow adjusting dial on the water
pump.
Care and maintenance
•Keep water clean and free from debris.
•Clean the water feature periodically to prevent build-up of mineral deposits on the sides
and base. Use a stiff brush and clean warm water with a little liquid soap. Do not use
detergents or abrasives as this will damage the surface of your water feature.
•Serenity recommends using Fountain fresh liquid to prevent the build-up of algae and
reduce maintenance. To order simply call our dedicated customer service number on
0871 911 7031* and quote the code G4025 or visit us online at
www.gardengearonline.co.uk
•When you need to replace the lightbulb, simply twist off the plastic globe and unscrew
the old lightbulb. Then insert a 3-watt screw in bulb and reattach the plastic globe.

6
GUARANTEE
IMPORTANT
Please do not return this product without first calling the Customer Service number
below:
0871 911 7031*
Thank you for purchasing this product, which has been made to demanding high quality
standards and is guaranteed for domestic use against manufacturing faults for a period of 12
months from the date of purchase.
This guarantee does not affect your statutory rights. If your product fails due to a defect in
material or workmanship during this period, please return it to the place of purchase. Normal
wear and tear is not covered under the guarantee.
Any guarantee is invalid if the product has been misused or subject to neglect or an attempted
repair other than by our own service centre.
Due to continuous product improvement, we reserve the right to change the product
specification without prior notice.
After Sales Customer Service:
Customer Service Department, Branded Garden Products, Premier House, Hortonwood 7,
Telford, TF1 7GP, UK
Telephone: [phone]*
E-mail [email protected]
Please retain for future reference.
Colours and contents may vary.
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice.
Please note that all products with the symbol below must be recycled.
*Calls cost 13p per minute, plus your phone company’s access charge
