Serpent S811-BE COBRA RTR User manual

1/8 scale Ready To Race electro Buggy
USER MANUAL & REFERENCE GUIDE

2
Powered by

Introduction
Thank you very much for buying this Serpent rc car. You are now member of a large following
of Serpent fans worldwide. This Serpent car will bring you many hours and weekends of racing excitement.
Serpent started as rc racing company in 1980, and has developed many modelcars since.
This wealth of experience and know how is used in our todays cars and that shows!
The Serpent S811-Be Cobra RTR is the best entry in the world of rc offroad racing. Affordable and very good
basis to start your racing carreer. The Serpent S811 Cobra RTR, is based on the high-end competition
version of the Cobra and shares geometry and many parts. Still its easy to use, assemble, and set up.
The RTR Cobra is fully upgradable to high end competition spec. The details can be found in our website.
You are now part of the worldwide network of Serpent drivers, which gives you superior technical support
and access to many benets that only Serpent drivers can enjoy.
The Serpent S811-B Cobra RTR offers state of the art specications and leads the way in 1/8 scale electro
offroad chassis design, using all the knowledge our designers have gathered from racing offroad cars for
over 15 years, into this design too. Continuously pushing the performance envelope.
Designed, tested and raced by Billy Easton, USA. World Champion.
This manual contains a number of steps you need to follow to operate the Serpent cars in the right way.
This manual also contains a quick-start section, a partslist and exploded views, and a FAQ section. A full
assembly manual can be found online in the Serpent.com website. So read this manual with great attention
before racing this car. For your own safety as well as for others, and to ensure you can enjoy your Serpent
car a long time, even if you are an experienced user. Serpent is not only about the car itself.
Serpent as company, and the worldwide network or distributors and dealers are here to help you out.
The Serpent website, social media and forum are available for assistance and additional information as well.
Enjoy your Serpent, the racing experience!
Contents
Introduction
Read this rst 4
Safety matters 4
Quickstart 3
Required equipment 5
Model specs / overview 6
Basic Tuning 7
Default Set Up 8
Maintenance 9
Partslist 10
Exploded views 14
3

4
Read this rst
g This is a highly technical hobby product, intended to be
used in a safe racing environment. This car is capable
of speeds in excess of 80 km/h or 50mph.
Please follow these guidelines when building and
operating this model.
g Parental guidance is required when the builder/user
of this car is under 16.
g Follow the building instructions. If in doubt, contact
your dealer or importer.
g Be sure to use the proper tools when assembling
the car. Always exercise caution when using electric
tools, knives and other sharp objects.
g Be careful when using liquids like lubrication oil or glue.
Do not swallow.
g Follow the manufacturer’s instruction in case you
experience irritation after using the product.
g Be careful when operating the car. Stay away from
any rotating parts such as wheels, gears and
transmission. Stay away from speedo during
and immediately after use, as these parts may be very
hot. We advise to use protective handgloves.
Safety matters
g Only operate this car in a safe environment, like a
special racing track or a closed parking lot. Avoid using
this car on public roads, crowded places or near infants.
g Before operating this car, always check the mechanical
status of the car. Check that the batteries of
the transmitter and receiver are fully charged.
g After use, always check all the mechanics of the car.
We advise to clean the car immediately after use, and
inspect the parts for wear or fractures. Replace when
necessary. Do not use water, methanol, thinner or other
solvents to clean the car.
g Store the car in a dry and heated place to avoid
corrosion of metal parts.
g Avoid using this car in wet conditions as the water
will cause corrosion on the metal parts and bearings
and these parts will cease to function properly.
If driven in the wet, ensure that all the electric
equipment is waterproofed and after use, that all
moving parts are dried immediately.
All instructions in this manual must be followed to ensure safe use of the car.
This model is not intended for use by children under 14 years .
Important pre-cautions
g Only run the car is designated areas or areas with very
few people, so no-one can get hurt.
g The car has a lot of power and the turning parts on
the car can cause damage, also some parts of the car
like transmisison and motorparts can become very hot.
So wear protective clothing both as driver and helper
and be carefull when picking up the car.
g Do not operate the car under dark conditions, as both
you and others may not see the car properly and can
get hurt, due to lack of car control.
g Use good common sense while operating the car
so you can fully enjoy your car.
Battery and battery-charging
g The battery and battery-charger are not included with
this model. We advice to use good quality NimH or
Lipo rechargebale battery-packs with 4000 mA
or more. Check carefully to buy batteries with the
correct connector for the speedcontroller, or also
purchase and mount other tting ones.
g Use proper battery-charger specically designed
for that type batteries and follow the instructions of
the battery supplier and the charger correctly.
Keep the battery and charger always in dry places only
and never leave un-attended during charging.
g When the batteries are at their end of life, dispose them
at a recycling-place, check www.call2recycle.org
for more info.
The quick-start section is not a replacement for
the full instructions. To be able to use the model
to its best take the time to read the full manual.
1. Read the manual and safety
pre-cautions ( page 3)
2. Buy and install the batteries in
the transmitter ( see Transmitter manual)
3. Install battery packs in the model,
make sure the speedo is switched off,
connect the cables (avoid reversed polarity)
and securely fasten the battery-pack.
4. Turn on the transmitter ( see Transmitter manual).
Always turn on the transmitter rst before
to switch on the car and only turn off
the transmitter after you switched off the car.
5. Check servo operation.
Check that the servo works correctly and check that
the car runs straight in neutral position, trim as needed.
6 Perform a range test with the radio system
7 Personalise the body of your car by applying
more decals if required.
8. Drive your modelcar.
9. Maintain your modelcar (page 9)
Quick-start

Required for your model Recommended materials
g Multi Charger; to charge transmitter battery g Side cutter and nose plier
and car battery g Cleaning brush and towel
g Battery pack 2-S Lipo x 2g Safety glasses and gloves
g Battery AA x 4 to operate the transmitter g Cleaning gum
g Tools: selection of allen tools and screw- drivers g Thin bearing oil
g Hobby knife g Transmission grease
g Camber gaugeg CA glue
g Degreaser
g O R
5
Equipment
Included with your model
g Serpent modelcar, factory assembled and set-up
g Dragon-RC DTS-1 transmitter (as shown or similar)
g Dragon-RC DESC speedcontroller
g Dragon-RC brushless motor
g Dragon-RC racing tyres, pre-mounts
g Dragon-Rc digital servo MG
g Dragon-RC prepainted and pre-cut bodyshell
Powered by

6
Model specs/overview
Shockabsorbers
Shocktower front
Front axle
Front bodymount
Front camber link
Front
wishbone
Steering servo
Steering system
Steering link
Chassis
Center diff
Battery cover
Spur gear
Rear
camber link
Differental
Central rear driveshaft
Speedcontroller
Brushless motor
Rear
stabilizer
Rear bodymount
Rear wishbone
Shocktower rear
Shocks rear
Race-tyres
Steeringblock
Receiver

7
Rear camber
Front camber
Front caster
Rear anti roll-bar
Front anti roll-bar
Gear-ratio Ride-height
Ackermann
Basic Tuning
Springs
Shock-angle
gSprings: by using a softer spring you will have more sag, more chassis
roll/lean, more dive and a less responsive car this might be better on low-grip
surfaces; by using a harder spring you have less sag, less body lean, less dive
and a more responsive car. What to apply depends on driving style and
grip-level surface. This is more suitable on high-grip surfaces.
gShock-angle: the angle at which the shocks are mounted create a different
suspension feel; the more vertical, the harder it feels, the more horizontal,
the softer it feels.
gOil: the viscosity of the shock-oil denes the dampening of the shockabsorber.
Thinner oil will be softer, with slower response, thicker oil will be harder
dampening with faster reponse. The dampening can also be ne-tuned by
tting other pistons with more or less holes, which is an optional.
gDifferential: you can make the gear differential harder or softer by using a
different oil viscosity. Lighter oil will create a looser diff which increases rear
traction on acceleration, but also more understeer , and a harder differential
will decreases rear traction on acceleration, but also more on-throttle steering
gFront anti-roll bar: by using a softer anti-roll bar you will have more sag,
more chassis roll/lean, more dive and a less responsive car. But you will
have more steering once you have entered the corner
gRear anti-roll bar: by using a softer anti-roll bar you will have more sag,
more chassis roll/lean, more dive and a less responsive car. But you will
have more rear traction and a more stable car
gToe adjustment: Front: adjusted with the track-rods, make longer
or shorter. More toe-in will create more steering, but less stability;
toe-out will create a more stabile car, with less steering.
gToe adjustment: Rear: adjusted with suspension blocks (optional).
More toe-in will create more traction, more stability, but less speed.
Less toe in will create a less stabile car, with less traction but higher speed.
gFront camber: using more negative camber in the front will give you more
steering but also increases possible traction roll.
gRear camber: using more negative camber in the rear will create more grip
in the rear meaning also creating more understeer.
gFront caster: use optional caster blocks to change caster, more caster will
create more steering but also increases possible traction roll. And less caster
will create less steering but also decreases possible traction roll.
gWheel-base length: a longer car will be more stabile and react slower,
a shorter car will be more nervous and more direct.
gGear-ratio: spur and pinion: for correct gearmesh keep a pieces of notebook
paper at hand, to put between the spur and pinion for correct mesh.
gRide-height: you can change the ride-height of the car, by applying more or
less pre-load on the springs, turn the pre-load adjusters to set the desired
height and keep left and right the same.
Rear caster
Rear
camber link
Speedcontroller
Shocktower rear
Race-tyres

8
DIFFERENTIAL OIL
SHOCKS
BODY - WING
TRANSMISSION SET UP
FRONT SPRING REAR
PINK
BLUE
PURPLE
GREEN
GREY
YELLOW
WHITE
OTHER
OIL/CST
REBOUND %
PISTON
HOLES SIZE
C= 4.8
C= 5.0
C= 5.2
C= 5.4
C= 5.6
C= 5.8
C= 6.0
C=
C= 2.8
C= 3.0
C= 3.2
C= 3.4
C= 3.6
C= 3.8
C= 4.0
C=
1.1MM
1.2MM
1.3MM
1.4 MM
OTHER
TYRES
COMMENTS
SET UP
FRONT CENTER REAR
CST CST CST
BRAND
TYPE
INSERT
WHEELS
_+
NAME RACE DATE
TRACK CITY/COUNTRY CONTACT
TRACK SIZE OPEN MEDIUM TIGHT TEMP. F o / o C
TRACK TRACTION HIGH MEDIUM LOW AIR TRACK
TRACK SURFACE SMOOTH MEDIUM BUMPY LAPS
TRACK TYPE HARD PACKED SOFT DIRT CLAY BEST LAPTIME in LAP
BLUE GROOVE ASTRO TURF GRASS RACE LENGTH
TRACK CONDITION DRY DUSTY MUD RACE RESULT
STEERING BLOCK CASTER BLOCK
PLASTIC PLASTIC
ALU ALU
INSERT NR.
OUT (-)
IN (+)
STEERING BAR
OPT 1
OPT 2
OPT 3
SERVO SAVER SPRING
STANDARD
HARD
REAR CAMBER
DIFFERENTIAL OIL
SHOCKS
FRONT SPRING REAR
PINK
BLUE
PURPLE
GREEN
GREY
YELLOW
WHITE
OTHER
OIL/CST
REBOUND %
PISTON
HOLES SIZE
C= 4.8
C= 5.0
C= 5.2
C= 5.4
C= 5.6
C= 5.8
C= 6.0
C=
C= 2.8
C= 3.0
C= 3.2
C= 3.4
C= 3.6
C= 3.8
C= 4.0
C=
1.1MM
1.2MM
1.3MM
1.4 MM
OTHER
TYRES BODY
ENGINE
TYPE
MANIFOLD
MUFFLER
PLUG
FUEL
COMMENTS
INSERT NR.
BRACE
PLASTIC
ALU
INSERT NR.
WHEELBASE SHIMS
1.25 2.5 3.75 5MM
-- 0
+ 0
INSERT NR.
0
0
CASTER
10
12
SET UP
CLUTCH
TYPE: STANDARD OPTIONAL
SHOE: ALU PCS SPRING
CARBON PCS SPRING
FRONT CENTER REAR
CST CST CST
GEARING
CLUTCH BELL T SPUR GEAR T
SHOCKLENGTH
AT FULL DROOP
MM
RIDE HEIGHT MM RIDE HEIGHT MM
HEX ADAPTER -2MM -1MM 0MM HEX ADAPTER -2MM -1MM 0MM
UPRIGHT
PLASTIC
ALU
ADJUST
SHOCKLENGTH
WITH THIS SCREW
ANTI ROLLBAR
1.8MM
2.0MM
2.3MM
2.5MM
2.7MM ANTI ROLLBAR
1.8MM
2.0MM
2.3MM
2.5MM
2.7MM
SHOCKLENGTH
AT FULL DROOP
MM
FRONT CAMBER
ADJUST RIDE HEIGHT WITH
SPRING COLLAR
ADJUST
SHOCKLENGTH
WITH THIS SCREW
ADJUST RIDE HEIGHT WITH
SPRING COLLAR
WING LOCATION
IN MM
BRAND BRAND
TYPE TYPE
INSERT WING OPTIONAL
WHEELS STOCK BRAND
TYPE
UP
DOWN
IN
OUT
UP
DOWN
UP
DOWN
SPINDLE
HIGH
LOW
BRAKE BALANCERS
50/50 BALANCER CLIPS: 0.5 MM pcs
OPTION 0.75MM pcs
1.0 MM pcs
1
BRACE
PLASTIC
ALU
STANDARD BRACKET
OPTIONAL TYPE
STANDARD BRACKET
OPTIONAL TYPE
FRONT TOE
ESC
PINION T
MOTOR
FINAL DRIVE RATIO
ROTOR
BODY
BRUSHLESS PROGRAM PUNCH
BATTERIES
SPUR GEAR T
TIMING
ROLLOUT mm
ARMATURE
WING
INITIAL BRAKE AUTO BRAKE
OPEN CLOSED
12000 12000 7000
0 0
0
98
28 28
112
2.5
16 46
SERPENT
√
√
√√
STOCK
300 300
KIT KIT
√
√
√√
√√
√
√√
√
√
√
√
√
√
STD.
1
46
√
√ √
78
DEFAULT

9
Maintenance
Shockabsorbers
- Check for smooth operation of the shockabsorbers, and check
for airbubbles by pushing the shock up and down fast after
removal of the spring. Clean the shockabsorbers as needed
and rell with fresh 100% pure silicone oil as needed.
Tyres
- Replace tyres if case worn or damaged, and clean the surface
in case dirty to obtain better grip.
Wheel-axles and driveshafts
- Remove the wheels, and check the wheel-axles, driveshafts
and adaptors for dirt, play and pins. Clean thoroughly as
needed and lubricate the touching parts with a small amount
of grease or oil.
Differentials
- Check the differentials and gears for wear and dirt and clean
as needed. Check the functionning of the diff by turning the
wheels in opposite direction and feel if still smooth or ‘gritty’.
In case of gritty feel, the silicone oil may need replacement.
The full assembly manual of this model is available online;
check on www.serpent.com and type your modelnumber,
partnumber, or select your car from the car-page; go to the
download section in the menu and download the full manual.
Shockabsorbers
Tyres
Wheel-axles and driveshaft front
Differential

Partslist and Optionals list
Manual & Decals
600629 Manual 811 E-S
600329 Decal sheet S811 black/white (2)
600332 Decal sheet S811 chrome (2)
Ball Bearings
1312 Ballbearing 5x8 anged SS (2)
1321 Ballbearing 6x10x3 SS (2)
1337 Ballbearing 15x21x4 SS (2)
1393 Ballbearing 13X19X4 SS (2)
1394 Ballbearing 8x14x4 anged SS (2)
1395 Ballbearing 8x19x6 SS (2)
1396 Ballbearing 8x16x5 SS (2)
600466 Bearingset 811-E (26)
600617 Bearingset 811 V2 small (12)
Radio Installation / Battery
1606 Antenna rod black (2)
600131 Balljoint set (19)
600436 Battery radiobox 811-E
600437 Steering balljoint + lever 811-E
600479 Battery foam pad (2)
600499 Pivotball double straight (3)
600500 Servo spacers (8)
Radio Installation / Battery option
600463 Servo lever 23T 811-E alu
600464 Servo lever 24T 811-E alu
600465 Servo lever 25T 811-E alu
Servo Saver & Steering
600105 Servosaver spring
600109 O-ring servosaver nut (4)
600128 Servo saver set nylon (3)
600131 Balljoint set (19)
600554 Pivot ball steering short 811-S (2)
600167 Steeringrack mount
600169 Servosaver adjust nut
600170 Servosaver shaft outer
600557 Steeringrack alu 811-S
600558 Topdeck front 811-S
600556 Servo saver post 811-S (2)
600555 Pivot ball steering long 811-S (4)
600437 Steering balljoint + lever 811-E
600499 Pivotball double straight (3)
600500 Servo spacers (8)
Servo Saver & Steering option
600153 Topdeck front carbon
600171 Steeringrack option 1
600172 Steeringrack option 2
600173 Steeringrack option 3
600182 Bolt steeringrack (2)
600278 Servo saver post alu (2)
600296 Servosaver alu coated (3)
600330 Servo saver spring hard
600463 Servo lever 23T 811-E alu
600464 Servo lever 24T 811-E alu
600465 Servo lever 25T 811-E alu
Shock Absorbers
600111 Shock membrane (10)
600112 O-ring shock bottom (10)
600113 O-ring shock nut (10)
600118 Shock part frame nylon (10)
600145 Shock pistons (4x4)
600180 Washer shock shaft (4)
600184 Pivotball 6.75 double (4)
10
600194 Shockshaft FR (2)
600195 Shockshaft RR (2)
600234 Shock cartridge stepped (4)
600235 Shock cartridge (4)
600319 Shock revision set (20)
600568 Shock mount 811-S (2)
600570 Shock set FR 811-S (2)
600571 Shock set RR 811-S (2)
600572 Shock spacers 811-S (14)
600573 Shock top 811-S (2)
600574 Shock top nut 811-S (2)
600575 Shock body FR 811-S (2)
600576 Shock body RR 811-S (2)
600577 Shock shim 811-S (10)
Shock Absorbers option
600317 Shockset fr (2)
600318 Shockset rr (2)
600357 Membrane webbed silicone (4)
600287 Shock spring support alu (4)
600306 Shock shaft FR TiN coating (2)
600307 Shock shaft RR TiN coating (2)
Shock Springs
600245 Spring set FR pink 4.8lbs (2)
600246 Spring set FR blue 5.0lbs (2)
600247 Spring set FR purple 5.2lbs (2)
600248 Spring set FR green 5.4lbs (2)
600249 Spring set FR grey 5.6lbs (2)
600250 Spring set FR yellow 5.8lbs (2)
600251 Spring set FR white 6,0lbs (2)
600252 Spring set RR pink 2.8lbs (2)
600253 Spring set RR blue 3.0lbs (2)
600254 Spring set RR purple 3.2lbs (2)
600255 Spring set RR green 3.4lbs (2)
600256 Spring set RR grey 3.6lbs (2)
600257 Spring set RR yellow 3.8lbs (2)
600258 Spring set RR white 4,0lbs (2)
600259 Spring set FR (7x2)
600260 Spring set RR (7x2)
Chassis / Guards
600141 Bumper
600436 Battery radiobox 811-E
600442 Chassis brace FR + RR 811-E
600624 Chassis 811 E-S
Chassis / Guards Optional
600445 Chassis 811-E
600461 Chassis brace front alu 811-E
600462 Chassis brace rear alu 811-E
600470 Chassis S811E hard anodized
600489 Transmision brace tube alu
Front Section
600124 Bodymount FR+RR
600126 Washer/nut nylon M3 (12+15)
600129 Diff case front set
600131 Balljoint set (19)
600135 Wishbone front L+R
600136 C-Hub 10 L+R
600167 Steeringrack mount
600183 Bushing suspensionarm (4)
600193 Pivotball threaded antirollbar (2)
600197 Driveshaft insert (2)
600222 Wheelnut 17mm (4)
600223 Wheelhexagon (4)
600240 Antiroll bar front 2.3mm
600365 Spacers 1.25mm + 2.5mm wheelbase (4+2)

11
600481 Steeringblock L+R V2
600530 Shocktower front alu 811-S
600532 Gear coupler 811-S
600626 Driveshaft center FR 811 E-S
600535 Driveshaft FR 811-S (2)
600537 Wheelaxle FR 811-S (2)
600539 Pin steeringblock 811-S (4)
600540 Track rod FR 811-S (2)
600542 Track rod steering 811-S (2)
600543 Hinge pin 811-S (2)
600544 Antirollbar nut 811-S (4)
600545 Antirollbar bushing 811-S (4)
600546 Pivot ball antiroll bar 811-S (2)
600548 Suspension bracket FR-FR 811-S
600549 Suspension bracket FR-RR 811-S
600553 Pivot ball 7.5 double 811-S (4)
600554 Pivot ball steering short 811-S (2)
600558 Topdeck front 811-S
903343 Antirollbar Spacer 3mm (2)
Front Section Optional
600151 Shocktower front carbon
600153 Topdeck front carbon
600176 Suspension bracket alu FR RR std
600177 Suspension bracket alu FR FR std
600241 Antiroll bar front 2.5mm
600242 Antiroll bar front 2.7mm
600263 Washer M3 alu (12)
600284 Shocktower FR alu light
600297 Lightwheight wheel nut 17mm (4)
600303 C-hub 10 L+R alu
600304 C-hub 12 L+R alu
600336 Antiroll bar front 1.8mm
600337 Antiroll bar front 2.0mm
600497 Steeringblock L+R V2 alu
600503 Steeringblock-wheelaxle set 811 V2
Middle Section
600131 Balljoint set (19)
600197 Driveshaft insert (2)
600381 Gear coupler rubber boot (2)
600443 Center diff cover 811-E
600446 Motormount set 811-E
600447 Motor slider 811-E
600532 Gear coupler 811-S
600559 Spur gear 46T 811-S
600625 Driveshaft center RR 811 E-S
600626 Driveshaft center FR 811 E-S
Middle Section Option
600197 Driveshaft insert (2)
600198 Spurgear 46T
600279 Spur gear 44T
600280 Spur gear 48T
600444 Driveshaft center FR 811-E
600471 Driveshaft center RR 811-E
600472 Gear coupler V3
600473 Gear coupler sleeve (2)
Rear Section
600124 Bodymount FR+RR
600126 Washer/nut nylon M3 (12+15)
600130 Diff case rear set
600131 Balljoint set (19)
600133 Wing mount set
600134 Wishbone rear L+R
600193 Pivotball threaded antirollbar (2)
600222 Wheelnut 17mm (4)
600223 Wheelhexagon (4)
600237 Antiroll bar rear 2.3mm
600365 Spacers 1,25mm + 2,5mm for wheelbase (4+2)
600365 Spacers 1.25mm + 2.5mm wheelbase (4+2)
600439 Wing white low 811
600476 Upright L+R V2
600499 Pivotball double straight (3)
600502 Upright set V2 811
600531 Shocktower rear alu 811-S
600536 Driveshaft RR 811-S (2)
600538 Wheelaxle RR 811-S (2)
600541 Track rod RR 811-S (2)
600543 Hinge pin 811-S (2)
600544 Antirollbar nut 811-S (4)
600545 Antirollbar bushing 811-S (4)
600546 Pivot ball antiroll bar 811-S (2)
600547 Hinge pin RR outer 811-S (2)
600550 Suspension bracket RR-FR 811-S
600551 Suspension bracket RR-RR 811-S
600552 Transmission brace mount RR 811-S
600553 Pivot ball 7.5 double 811-S (4)
600625 Driveshaft center RR 811 E-S
903343 Antirollbar Spacer 3mm (2)
Rear Section option
600152 Shocktower rear carbon
600155 Suspension bracket RR RR 3
600156 Suspension bracket RR FR 2
600238 Antiroll bar rear 2.5mm
600239 Antiroll bar rear 2.7mm
600263 Washer M3 alu (12)
600265 Suspension bracket RR FR 2.5 - 4.5
600266 Suspension bracket RR RR HR 3
600267 Suspension bracket RR RR LR 3
600285 Shocktower RR alu light
600297 Lightwheight wheel nut 17mm (4)
600300 Post wingmount alu (2)
600301 Wing washer alu (2)
600338 Antiroll bar rear 1.8mm
600339 Antiroll bar rear 2.0mm
600434 Antiroll bar rear 2.4mm
600496 Upright L+R V2 alu
Differential
110431 Shim 8x11x0.2 (10)
600147 Diff gasket (3)
600205 Shim 13x16x0.2 (10)
600209 Diff pin 10T (2)
600210 Diff pin outdrive (2)
600421 Oring centerdiff V2 (10)
600425 Diff housing V2
600501 Complete FR/RR 44T diff
600495 Diff pinion 13T
600480 Diff gear 44T
600559 Spur gear 46T 811-S
600561 Diff outdrive center 811-S (2)
600562 Diff outdrive FR-RR 811-S (2)
600627 Diff gear 10T + 20T (4+2) V2
Differential Optional
600560 Diff gear 43T 811-S
600514 Diff pinion 10T 811 V3
Pinions
600458 Pinion 18T
Pinions Optional
600452 Pinion 12T
600453 Pinion 13T
600454 Pinion 14T
600455 Pinion 15T
600456 Pinion 16T
600457 Pinion 17T
600459 Pinion 19T
600460 Pinion 20T

12
Body
1667 Body-clip medium (10)
600438 Body + nosecone 811-E
600439 Wing white low 811
Body Optional
600143 Wing white nylon
600277 Wing black nylon
600440 Wing black low 811
Merchandising
1897 Towel Serpent large
1898 Lanyard Serpent orange
1900 Cap at-brim Serpent black
1998 Cap serpent black-orange
190137 T-shirt Serpent offroad orange (S)
190138 T-shirt Serpent offroad orange (M)
190139 T-shirt Serpent offroad orange (L)
190140 T-shirt Serpent offroad orange (XL)
190141 T-shirt Serpent offroad orange (XXL)
190142 T-shirt Serpent offroad black (S)
190143 T-shirt Serpent offroad black (M)
190144 T-shirt Serpent offroad black (L)
190145 T-shirt Serpent offroad black (XL)
190146 T-shirt Serpent offroad black (XXL)
190162 T-shirt Serpent offroad white (S)
190163 T-shirt Serpent offroad white (M)
190164 T-shirt Serpent offroad white (L)
190165 T-shirt Serpent offroad white (XL)
190166 T-shirt Serpent offroad white (XXL)
190172 Winter jacket Serpent (S)
190173 Winter jacket Serpent (M)
190174 Winter jacket Serpent (L)
190175 Winter jacket Serpent (XL)
190176 Winter jacket Serpent (XXL)
190201 Hoody Sweater Serpent black zip (S)
190202 Hoody Sweater Serpent black zip (M)
190203 Hoody Sweater Serpent black zip (L)
190204 Hoody Sweater Serpent black zip (XL)
190205 Hoody Sweater Serpent black zip (2XL)
190206 Hoody Sweater Serpent black zip (3XL)
190156 Polo shirt Serpent black (S)
190157 Polo shirt Serpent black (M)
190158 Polo shirt Serpent black (L)
190159 Polo shirt Serpent black (XL)
190160 Polo shirt Serpent black (XXL)
190161 Polo shirt Serpent black (XXXL)
Pit equipment
190501 Tool-bag
190502 Pit-bag medium. 3 drawers
190504 Ballcup tool
Fastners
110100 Screw allen countersunk m3x10 (10)
110101 Screw allen countersunk m4x8 (10)
110102 Screw allen countersunk m4x10 (10)
110103 Screw allen countersunk m4x16 (10)
110104 Screw allen countersunk M3x8 (10)
110105 Screw allen countersunk m4x12 (10)
110106 Screw allen anged roundhead m5x12 (10)
110107 Screw allen cilinderhead m3x16 (10)
110108 Screw allen roundhead m3x6 (10)
110109 Screw allen roundhead m3x10 (10)
110110 Screw allen roundhead m3x16 (10)
110111 Screw allen roundhead m3x14 (10)
110112 Screw allen roundhead m3x12 (10)
110113 Screw allen roundhead m4x8 (10)
110114 Setscrew allen m3x8 (10)
110115 Setscrew allen m3x4 (10)
110116 Setscrew allen m3x3 (10)
110117 Setscrew allen m3x12 (10)
110118 Setscrew allen m4x4 (10)
110119 Setscrew allen m4x6 (10)
110120 Setscrew allen m4x10 (10)
110121 Setscrew allen m5x6 (10)
110122 Screw allen countersunk m3x6 (10)
110123 Screw philips roundhead 3.5x13 (10)
110124 Screw allen countersunk m3x8 (10)
110125 Screw allen countersunk m3x20 (10)
110126 Screw allen countersunk m2.5x12 (10)
110127 Screw allen countersunk m3x12 (10)
110128 Screw allen roundhead m3x5 (10)
110129 Screw allen cilinderhead m3x10 (10)
110130 Screw allen roundhead m2.5x6 (10)
110131 Screw allen roundhead m2.5x10 (10)
110132 Screw allen countersunk m3x16 (10)
110133 Screw philipshead countersunk 2.5x8 wide (10)
110134 Screw philipshead countersunk 2.5x10 wide (10)
110135 Screw allen countersunk M2.5x10 (10)
110136 Screw allen countersunk M2.5x8 (10)
110137 Setscrew allen M3x6 (10)
110138 Screw allen countersunk M4x14 (10)
110139 Screw allen countersunk M3x40 (10)
110140 Screw allen roundhead M3x20 (10)
110141 Screw allen roundhead M3x22 (10)
110142 Screw allen roundhead M3x25 (10)
110143 Screw allen roundhead M4x18 (10)
110144 Screw allen roundhead M3x18 (10)
110145 Screw allen roundhead anged M3x12 (10)
110146 Screw allen roundhead anged M3x16 (10)
110147 Screw ph roundhead widethread 2.5x5 (10)
110148 Setscrew allen M5x4 (10)
110149 Screw allen countersink M2x10 (10)
110150 Screw M6x12 nylon black (2)
110151 Screw allen cilinderhead M4x10 (10)
110152 Screw allen cilinderhead M3x8 (10)
110153 Screw allen roundhead M2.3x6 (10)
110154 Setscrew allen M3x10 (10)
110155 Setscrew allen M3x5 (10)
110156 Screw allen countersunk M2.2x6 (10)
110157 Screw allen countersunk M3x5 (10)
110158 Screw allen countersunk M3x15 (10)
110159 Screw allen countersunk M3x18 (10)
110160 Screw allen cilinderhead M2.2x12 (10)
110161 Screw allen cilinderhead M2x6 (10)
110162 Setscrew allen M3x2.5 (10)
110163 Setscrew allen M3x2 (10)
110164 Screw allen roundhead M3x4 (10)
110165 Screw allen cilinderhead M2x5 (10)
110166 Screw allen countersunk M2.5x5 (10)
110167 Screw allen roundhead anged M3x18 (10)
110168 Screw allen roundhead anged M3,5x10 (10)
110169 Screw allen roundhead anged M4x10 (10)
110170 Screw allen roundhead anged M3x28 (10)
110171 Screw ph countersunk widethread 2.5x15 (10)
110200 Pin 2.5x8 (10)
110201 Pin 3x12 (10)
110202 Pin 5x5 (10)
110203 Pin 3x14 (10)
110204 Pin 3x20 (10)
110205 Pin 3x22 (10)
110206 Pin 2.5x22 (10)
110207 Pin 2.5x12 (10)
110208 Pin nra 2x9.8 (4)
110209 Pin nra 2x18 (4)
110210 Pin 3x13 (10)
110211 Pin 2.5x13 (10)
110212 Pin 2.5x17 (10)
110213 Pin 2.5x10 (10)
110214 Pin 3x15 (10)
110215 Pin 2x12 (10)
110216 Pin 2.5x15 (10)

13
Transmitter, receiver, servo, parts
210000 Transmitter set DTS-1 with display 2.4 Ghz
210001 Transmitter DTS-1 with display 2.4Ghz
210002 Receiver DRS-1 on 2.4Ghz
210003 Servo digital 0.19s/10.5kg MG
210005 Servo case for #210003
210007 Servo gear set for #210003
Speed controller, motors, parts
211001 Speed controller DS-8, waterproof
211003 Speed controller DS-8 and BL motor
211005 Motor brushless BL 8
Tyres rubber offroad and wheels
214001 1/8 buggy tyre hard mounted on white rim (2)
214002 1/8 buggy tyre med mounted on white rim (2)
214003 1/8 buggy tyre soft mounted on white rim (2)
214004 1/8 buggy tyre s-soft mounted on white rim (2)
214005 1/8 buggy tyre hard (2)
214006 1/8 buggy tyre med (2)
214007 1/8 buggy tyre soft (2)
214008 1/8 buggy tyre s-soft (2)
214009 1/8 moulded insert hard (4)
214010 1/8 moulded insert med (4)
214011 1/8 moulded insert soft (4)
214012 1/8 moulded insert s-soft (4)
110217 Pin 2x9 (10)
110218 Pin 3x10 (10)
110300 E-clip 2.3 (10)
110301 E-clip 3.2 (10)
110302 E-clip 4.0 (10)
110303 E-clip 5.0 (10)
110304 E-clip 7.0 (10)
110305 Seger clip 12x1.0 (10)
110306 E-clip 6.0 (10)
110400 Shim 6.0x10x0.2 (10)
110401 Shim 3.2x7x0.5 (10)
110402 Nut nylock M3 (10)
110403 Nut nylock M4 (10)
110404 Shim 6x8x0.3 (10)
110405 Nut nylock M4 anged (10)
110406 Nut nylock M2.2 (10)
110407 Nut M3 (10
110408 Shim 3x5x0.3 (10)
110409 Shim 3x5x1 (10)
110410 Shim 3x5x2 (10)
110411 Shim 3x5x4 (10)
110412 Shim 3.5x8x1 (10)
110413 Shim 3.5x12x0.2 (10)
110414 Shim 3x6x0.1 (10)
110415 Shim 3x6x0.5 (10)
110416 Shim 3x6x0.8 (10)
110417 Shim 3x6x3 (10)
110418 Shim 4x8x0.1 (10)
110419 Shim 4x9.5x1 (10)
110420 Shim 4x9.5x2(10)
110421 Shim 4x9.5x4(10)
110422 Shim 4x10x0.3 (10)
110423 Shim 5x8x0.1 (10)
110424 Shim 5x8x0.3 (10)
110425 Shim 5x10x0.3 (10)
110426 Shim 5x10x0.5 (10)
110427 Shim 5x15x0.3 (10)
110428 Shim 6.5x8x0.25 (10)
110429 Shim 6x11.75x0.2 (10)
110430 Shim 6x12x0.5 (10)
110431 Shim 8x11x0.1 (10)
110432 Shim 8x11x0.2 (10)
110433 Shim 12x15x0.25 (10)
110434 Shim 12x18x0.3 (10)
110435 Shim 13x16x0.2 (10)
110436 Shim 3x5x3 (10)
110437 Nut M2.5 (10)
110438 Shim 2,5x6x0,5 (10)
110439 Shim 3x7,5x1 (10)
110440 Shim 2,5x5x0,4 (10)
110441 Nut nylock M3 anged (10)
110442 Shim 4x8x0.6 (10)
Additions / notes
All rights reserved. Parts may change without prior notice.

14
600147
600421
600198
600480
1396
110127
600376
600202
600209
600110
600210
600215
600144
600425
Complete FR/RR 44T diff 600501
Complete centerdiff 46T 600324
Complete DIFF uni 600325
FRONT
REAR
CENTER
600213
1396
600214
600110
600202
600200
110124
110102
600446
600424
600443
600324
600324

15
600441
110132
110144
110142
110159600132
600155
600126
600130
600495
600197
600477
1396
600215
110148 600223
110212 110115
1337
600474600476
600475 110216
110147
110147
600215
600472 110118
600473
600197
110116 903343
1312
110138
600471
110147 1395
110139
600133
600192
600152
110402
600168 600178
110112
600124
600168 600131
600188
600178 600131
600174
600193 600225
600189
600131
600185
600141
110402 600134 110122
600140
600108
600130
600126
600132
600156 110132
110211 1393
600381
110116
600237
A
5
A
6
28
600441
110132
600546
110116
600237
110132
110144
110139
600550
600159 600126
600130
600112
110147
110432
600514
1395
600532
1393
110118
600112
600625
600112
600536
600112
600538
1337
110115
600476
1396
110212
600223
110148
110138
600131
600553
600541
600131
600125
600131
600544
600193
600134
600543
600547
110301
600553
110401
110167
110402
110402
600531
600124
600531
110402
600553
110401
110167
600126
600130
110159
600551
110116
903343
600545
600126
110141

16
110132 600176 600132
600326
600136
600183
600190
110216
600102
600197
600478
600141
600137 600183
600135
600444 600381
600131
110132
110116
110116
110145 600192
600126
110159
600192 600241
600131 600185
600126
600473
600472
1395
600215
600495 1312
110105
110147
110138
1393
110211
600108 110116 903343 600126 110125
600132
600177
110107
600193 600225
600129
600174
600168
600129
110141
600178 600131
110118
600326
600137
600215
600223
110148
600137
1396
110115 1337
600481 600190
600126
600129
600151
A
5
A
6
29
110138
110105
600141
600197
600535
110216
600537
1337
110115
600539
600481
600539
110137
600223
110148
1396
600137
600136
600183
600326
600135
600548
110132
600548
110125
903343
110116
110107
600126
600545
110301
600543
600126
110141
600553
600540
600131600131
600544
600193
600553
110167
600131
110402
110159
600126
600129
600530
110401
600530
600553
110401
110402
600241
600546
110116
110167
110132
600126
600549
600129
600112
600626
600112
1393
110118
600532
1395
110432
600514
110147
600129

17
110402
600178
1321
600178
600128
110402
600153
600182
600173
1321
600199
600167
110140
600191
600191
110140
600131
600170
110104
600334
600128
600191
600128
600105
600169
600442
110127
A
5
A
6
30
110402
110402
600122
600124
110127
110104
110132
600558
110168
600557
110402
1321
600128
110437
1321
600556
110159
600131
600555
1321
600170
600128
600128
600105
600109
600169
110437
600167
110140
110159
600555
110153
110127
110140
600195=RR
600576=RR
600252
600245
600575=FR
600194=FR
600111
600574
600145
600577
600573
110130
600180
600234
600112
600235
600112
600118
600572
600570: SCHOCK SET FR
600571: SCHOCK SET RR

18
600436
600436
600227
600437
600178
110402
110108
600437
600437
110146
600500
600436
110407
600499
1606
110149
600436
110116
600437
110127
600436
600479
110102
110124
110102
110124
110102
600436
600436
110116
600204
600204
600442
110112
A
5
A
6
31
1606
110149
600436
110116
110407
600499
600437
110127
110402
110437
110132
600437
110108
600437
110146
600500
600436
600436
600436
110402 110112
600442
600552
110140
600436
110116
600436
600479
600436
110104
110104
110104
110102
110102
600554

19
600439
600132
110405
600568
600571
600184
110405
600568
600570
600184
600224
110115
600126
600133
110402
600224
600456
110118
110151
600447
NOT INCLUDED
110115
600222
Notes:

w w w . s e r p e n t . c o m
i n f o @ s e r p e n t . c o m
#82354-1 Manual / ref guide 811Be RTR
www.serpent.com/600006
