SEVIC BLUE LASER SBL0304MP4 User manual

V20071024
SEVIC BLUE LASER
SBL0304MP4
- INSTRUCTION MANUAL

1
Thank you for your choosing our product. We hope you will find the instructions in this user manual clear
and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the fe atures of
your new unit for maximum enjoyment.
Preparation
P3
Features
Tools and Supplies
Disconnecting the Battery
Controls and Indicators
P4-7
Button Operation
LED Display / Indicators
The key Areas of Touch screen
Remote Control
P8-9
Remote Control
Using the TFT Monitor
P10-11
Open/Close TFT Monitor
TFT Monitor Auto Open
Monitor Tilt Angle Adjustment
Rear Camera Mode
Image Setting
Parking Brake Inhibit
Monitor Movement Mechanism
Operating Instructions
P12-13
Power On / Off
Playing Source Selection
Volume Adjustment
Audio Control Menu
System Reset
Mute
System Setup Menu
P14-16
MAIN Menu
SCREEN Setup menu
GENERAL setup Menu
Standby
Radio Operation
P17-19
Radio TFT display
Switch to Radio Tuner source
Select FM/AM Band
Auto Tuning
Manual Tuning
Using Preset Stations
Auto Store (AS)
Program Scan (PS)
Contents

2
DVD Player Operation
P20-24
Insert/Eject Disc
Reset the Loading Mechan ism
Accessing DVD Mode
Using the Touch-Screen Controls
Controlling Playback
Accessing the DVD Menu
Moving Through Chapters
Fast Forward/Fast Reverse
GOTO Search
Direct Chapter / Track Selection
Viewing an Alternate Picture Angle (DVD Only)
Multi-Language Discs (DVD Only)
Playback Information
General Disc Information
DVD Setup Menu
P25-26
Accessing the DVD Setup Screen
LANGUAGE Menu
AUDIO Menu
VIDEO Menu
RATING (Parental Lock) Menu
CD/MP3/WMA /JPEG Operation
P27-29
CD Player User Interface
MP3/WMA Discs
JPEG Discs
iPod Operation
P30-31
Accessing iPod Mode
iPod Instructions
Playback of video on iPod
Troubleshooting
P32-34
Specifications
P35
Wiring Diagram
P36
Warranty Terms and Conditions
P37

3
Please read all of the instructions before beginning the installation. We recommend having your unit
installed by a credible installation shop.
Features
Single DIN size, all-in-one highly integrated functions of entertainment system
Built-in DVD Player, Car specification slot -in mechanism
Built-in RDS FM/AM Tuner
High resolution 7”(16:9) TFT color monitor; with LCD dot matrix display
Built-in 45W X 4 output amplifier
Turn out and slot-in panel structure.
Smart Touch-screen operation
Anti Theft detachable keyboard
All functions Remote Control operation
Buttons and Encoder operation
Steering wheel button operation interface
Standby mode
Powerful Graphic UI and software update ability.
Tools and Supplies
You will need these tools and supplies to install your unit.
•Torx type, flat-head and Philips screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screwdriver, socket wrench set or other tools)
• Electrical tape
• Crimping tool
• Volt meter/test light
• Crimp connections
• 18 gauge wire for power connections
• 16 – 18 gauge speaker wire
WARNING! Only connect the unit to a 12-volt power supply with proper grounding.
WARNING! Never install this unit where operation and viewing could interfere with safe driving
conditions.
WARNING! To reduce the risk of a traffic accident (except when using for rear view video camera)
never use the video display function while driving the vehicle. This is a violation of law.
WARNING! Never disassemble or adjust the unit without the assistance of a professional. For
details, please consult your local car stereo specialty shop.
WARNING! To prevent injury from sho ck or fire, never expose this unit to moisture or water.
WARNING! Never use irregular discs.
WARNING! To prevent damage to the mechanism inside this unit, avoid impact to the TFT
monitor.
WARNING! Do not change the fuse on the power wire without professional guidance. Using an
improper fuse may cause damage to the unit and result in a fire.
WARNING! The monitor employs an automatic motorised mechanism. To prevent damage tothe
core mechanism, please do not push, pull or swivel the monitor manually.
WARNING! This device isequipped with a safetyfeature that prohibits viewing of moving pictures
whilst the vehicle is in motion.
The Pink safety wire (Brake) on the systems own loom must be connected to the vehicles hand
brake system (ground active).
Disconnecting the Battery
To prevent a short circuit, be sure to turn off the ignition and to remove the negative (-) battery cable from
car.
Preparation

4
Button Operation
Controls and Indicators
25

5
○,1 VOL
Rotary encoder.
Power On/Off: Press this encoder to turn on this unit, press and hold to turn off .
Rotate clockwise/anticlockwise to adjust the volume.
○,2 MUTE
Press the MUTE button to mute the volume, and press the button again to restore the volume.
○,3 FAST REVERSE
Fast reverse play the disc content in DVD/SD mode.
Press to tune frequency backward one step in TUNER mode .
○,4 FAST FORWARD
Fast forward play the disc content in DVD mode
Press to tune frequency forward one step in TUNER mode .
○,5 PREVIOUS
Select the previous chapter/track for playback.
Seek an available radio station by decreasing tuning frequency
○,6 DISC INDICATOR LIGHT
It is blue when there is no disc in the unit.
It is red when there is disc in the unit.
○,7 NEXT
Select the next chapter/track for playback.
Seek an available radio station by increasing tuning frequency
○,8 STOP
Stop playback in DVD mode.
Select FM/AM band in TUNER mode
○,9 PLAY/PAUSE
Press once for play/pause.
Press to scan radio stations stored in the 6 preset channels in TUNER mode
○,10 MODE
Press once to select the playing source.
○,11 DISK SLOT
○,12 RESET
Press to reset system settings (except the DVD setup).
○,13 ENTER
Rotary encoder.
Press this encoder to access MAIN menu.
Rotate clockwise/anticlockwise to select desired item and press once to access or confirm.
○,14 EJECT
Press once for disc insertion/ejection.
○,15 INFO/PICTURE
Press to display the playing information on the screen.
Press and hold to access the picture setup.
○,16 ANGLE+
Press the button to adjust the upward tilt angle of the screen one step at a time.
Press and hold this button to adjust the upward tilt angle of the screen continuously.
Press this button to adjust the picture settings in picture setup.
○,17 ANGLE-
Press the button to adjust the downwar d tilt angle of the screen one step at a time.
Press and hold this button to adjust the downward tilt of the screen continuously.
Press this button to adjust the picture settings in picture setup.

6
○,18 TFT DISPLAY
○,19 CLOSE (OPEN)
Press the button to activate the automatic mechanical system and move the TFT monitor into
viewing position. Press again to return.
○,20 DISP
Press the DISP button to display system information on the LCD screen or on the TFT screen.
○,21 LED DISPLAY
○,22 AS/PS (Auto store/program scan)
Press to auto store strong radio stations in the 6 preset channels in the current band.
Press and hold to start to scan radio stations stored in the 6 preset channels in the current band.
○,23 BAND
Press to switch between FM and AM.
○,24 IR REMOTE CONTROLRECEIVER .
○,25 REL (Release)
Press REL to release the detachable front panel
The radio will go into sleep mode and will not turn on unless the front panel is reattached.
LED Display / Indicators
○,2 ○,3○,4○,5 ○,7
○,6 ○,1
○,1 Main Display
Display the time, tuning frequency and other text information.
○,2 Program Type (PTY) indicator
○,3 Traffic Program (TP) indicator
○,4 Traffic Announcement (TA) indicator
○,5 Alternative Frequency (AF) indicator
○,6 Stereo broadcasting indicator
Indicates the radio is in stereo mode or not
○,7 Loudness indicator
Indicates the LOUD function is activated or not.

7
The key areas of touch screen
The touch key areas are outlined below , for DVD, VCD playback mode.
Area A
Area F
Area B
Area C
Area E
Area D
A — Return to MAIN menu
B — DISP key: Displays playing information
C — Select previous chapter
D — Select next chapter
E — Display the onscreen controls, and different mode display s different menu.
F —On DVD/VCD mode, displays the GOTO search menu on the screen directly.

8
Key
Name
Signal
Function
1
Power
Turns the power on/off
2
Open
Open/close the TFT monitor
3
Mute
Toggles on/off audio output
4
SRC
Selects playing mode
5
Numeric
button
1.2.3.4.5.
6.7.8.9.0
Directly access chapter/track/preset station for current band
6
VOL up
Increase volume
7
VOL
down
Decrease volume
8
Informati
on
Displays playing information
9
GOTO
search
Search function in the VCD/DVD disc
10
Stop/Ban
d
Selects FM/AM band on Tuner mode
Stop playback on other mode
11
Select
Enter the audio setting
12
ESC
Exit the current menu
13
Menu
Enters the main menu of system
14
Parameter of TFT setting
15
Repeat
AB
Setup to repeat playback from time frame A to time frame B
Remote Control
○,1
○,2
○,6
○,7
○,8
○,10
○,11
○,13
○,14
○,15
○,19
○,20
○,23
○,24
○,27
○,9
○,3
○,4
○,5
○,12
○,16
○,17
○,28
○,18
○,21
○,22
○,25
○,26

9
Key
Name
Signal
Function
16
OK
Starts/pauses playback or confirm settings
17
Direction
buttons
Up/down/left/right to select items for setting
18
Title
Enter the title menu
19
Root
Enters the main menu of the disc
Turn on PBC when playing VCD
20
Repeat
Repeat playback of current chapter
21
Next
Selects the next chapter/track for playback
Searches an available radio station by increasing tuning
frequency
22
Previous
Selects the previous chapter/track for playback
Searches an available radio station by decreasing tuning
frequency
23
Fast
Reverse
Fast reverse the disc content
24
Fast
Forward
Fast forward the disc content
25
Audio
Change the audio language for disc playback
26
Zoom
Zooming in/out on an image
27
Angle
Plays back disc in different angel for a scene
28
SUB
Title
Language selection for subtitle

10
Open/Close TFT Monitor
Press the ( ) button on the front panel or on the remote control to open/close the TFT monitor.
TFT Monitor Auto Open
·If “TFT Auto Open” is “On”, when the unit is turned on, the monitor automatically moves to the last
viewing position.
·If “TFT Auto Open” is ”Off”, when the unit is turned on, press the ( ) button on the front panel or on
the remote control to move the monitor into the desired viewing position.
·If “TFT Auto Open”is ”Manual”，when the unit is turned on or turned off, the monitor is no any
movement.
See “General setting”for more instructions.
Monitor Tilt Angle Adjustment
The monitor angle can be adjusted for optimum viewing using one of the following methods:
• Press the ( ) or ( ) buttons on the front of the unit to adjust the tilt angle of the screen one step at a
time.
• Press and hold the ( ) or ( ) buttons to continuously adjust the tilt angle.
Rear Camera Mode
When the vehicle is placed in "Reverse", and an optional re ar camera is connected to the unit, the TFT
monitor will automatically switch to the camera input source.
Image Setting
Video Output Format
The nether table shows the video output format for each playing source.
Video Output Format
Playing Source
Video Output Format
FM/AM Tuner
RGB Mode
DVD
RGB Mode
AUX IN
CVBS Mode
CAMERA
CVBS Mode
*CVBS-- Composite Video Base band Signal
Adjustable Parameters
While in RGB mode, the only parameter that can be adjusted is brightness (BRIGHT). To access
“PICTURE”,“COLOR”, “CONTRAST”, and “ BRIGHT you must be in CVBS mode.
Parameter Adjustment Procedure
1. Enter Picture Quality Setting mode:
Press the PIC button on the remote or press and hold the INFO button on the unit.
2. Select Item to Set:
Press the / buttons on the remote or rotate the ENTER button clockwise/anticlockwise to select a
item.
3. Set Parameters:
Press the / buttons on the remote or press the ANGLE button ( / ) on the front panel to
adjust the selected feature to the desired setting.
4. Exit Picture Quality Setting Mode:
Press the PIC button on the remote or press and hold the INFO button on the unit.
Using the TFT Monitor

11
Parking Brake Inhibit
•Follow the installation circuit diagram. Connect the “PARKING”cable to brake switch. There will be
video display until the brake is active. And should be pass through like that:
Initialization is “High”: High—Low—High—Low—wait for 5 sec—video display.
Initialization is “Low”: Low—High—Low—High—Low—wait for 5 sec—video display.
In which “High”: brake is in non-active state, and operating voltage is high in the circuit.
“Low”: brake is in active state and operating voltage is low in the circuit.
The transform time must be less than 2 sec between ”High—Low”/”Low—High”.
When the “PARKING”line is impending, no video display.
• Parking brake function is overridden when the video source is set to CAMERA.
• When the parking brake inhibit is active, the front monitor displays Caution, preventing the driver from
watching content while driving.
•All of the above setup prevent the drive from disturbing, ensure safe driving.
Monitor Movement Mechanism
If an obstruction occurs in the monitor path, the motion will stop automatically to prevent damage to the
mechanism and monitor.
Normal operation is resumed by pressing the ( ) button or disconnecting and reconnecting the power.

12
Power On / Off
·Press the VOL button to turn the unit on. The buttons on the front of the unit light up and “WELCOME”
appears briefly in the LCD panel, followed by the current mode status. If the TFT screen is open, only the
current mode status is displayed.
·You can also turn on the unit by pressing the button ( ) on the remote and open the TFT screen.
·Press and hold the VOL button on the front panel to power off the unit. The monitor is drawn back into
the main compartment and the LCD screen displays “BYE BYE” at the same time.
·You can also turn off the unit by pressing the button ( ) on the remote.
Playing Source Selection
Press the MODE button on the front panel or the SRC button on the remote to change among available
playing sources: TUNER, Disc, AUX IN, iPod, CAMERA (rear view video camera). The playing mode is
displayed on the TFT or LCD screen.
AUX IN Mode
An external peripheral device can be connected to this unit via RCA output to the “AUX IN”.
CAMERA Mode
“CAMERA” mode is only available if a camera is connected and during reverses driving. To install a rear
view video camera, connect the video input cable to the camera output cable.
Volume Adjustment
To increase or decrease the volume level, turn the VOL button on the front panel or press the VOL+/
VOL- buttons on the remote control. The volume ranges from “0” to “40”. The LCD screen displays the
volume level for 3 seconds.
Default volume memory setup: Rotate VOL knob on the front panel to select volume value and then press
and hold the knob till hear a single sound. If this goes, the setup is complete.
Audio Control Menu
The Audio Control feature allows you to easily adjust your audio system to meet the acoustical
characteristics of your vehicle, which vary depending on the type of vehicle and its measurements. To get
the best possible sound quality from your new system, be sure to adjust the suitable settings for the
speakers as well. Proper setting of the Fader and Balance boosts the effects of the cabin equalizer.
Accessing the Audio Control Menu
Press the VOL button on the front panel once or press the SEL on the remote control to display the
“Audio” menu.
Selecting an Audio Feature for Adjustment
·Press the / buttons on the remote to select a item to be adjusted.
·Press the VOL button on the front panel once a item to be selected.
Adjusting an Audio Feature
·Press the / buttons on the remote
·Rotate the VOL button clockwise/anticlockwise to adjust the selected feature to the desired setting.
Operating Instructions

13
Audio Adjustments
Audio Function
Adjustable Range
User
Flat
Jazz
Pop
EQ
Classical
BASS
-7 to +7
TREBLE
-7 to +7
FADE
-9 to +9
BAL
-9 to +9
SUB
-7 to +7
LOUD
Off, On
NOTE: The Bass and Treble levels are only adjustable when EQ is set to “User” mode.
The Loud function compensates for deficiencies in sound ranges at low levels. When the Loud function is
on, LOUD is displayed on the screen.
Exiting the Audio Control Menu
Press the escape arrow on the to p right corner of the TFT display .
Press the ESC button on the remote control to exit the audio control menu .
System Reset
To correct a system halt or other illegal operation, use the tip of a pen to press the RESET button located
on the front bottom-right corner of the unit. After a system reset, the unit system setup (except the DVD
setup and “Radio”in “GENERAL”setup) restores the setting before last power off.
Mute
•Press the MUTE button on the front panel or the MUTE button ( ) on the remote to mute the volume
from the unit.

14
MAIN Menu
There are three methods to access the MAIN menu.
·Press the ENTER button on the front panel .
·Press the MENU button on the remote control.
·Touch the A area on the touch-screen.
1. Touch to access Radio mode
2. Touch to access DVD mode
3. Touch to access AUX IN mode
4. Touch to access Standby mode
5. Touch to exit MAIN menu
6. Touch to access SCREEN setup menu
7. Touch to access GENERAL setup menu
8. Touch to access DVD setup menu
9. Touch to return to the previous menu
10. Touch to access CAMERA mode
11. Toutch to access Ipod mode
Note: Remote, touch screen operations and buttons on front panel are all useable to select menu and adjust
“SETTING”. The following instructions will show all the different ways to access menus and adjustments .
SCREEN Setup Menu
Accessing the SCREEN Setup Menu
·Select the button 6 on the screen to access the SCREEN
setup.
Selecting a Feature for Adjustment
Press the / buttons on the remote to select a
feature to be adjusted.
Rotate ENTER clockwise/anticlockwise to select a
feature to be adjusted.
Touch directly the options on the screen to select a
feature to be adjusted.
System Setup Menu
1
2
3
4
5
6
7
8
9
10
11

15
Adjusting a Feature
Setting
Options
Function
Brightness
-10 to +10
Select to adjust the Brightness to the desired setting.
Screen Tilt
1 to 6
Select (1 to 6) to adjust the tilt of the screen.
Off
Screen Saver
On
Select to activate/deactivate the Screen Saver.
No
TS Calibrate
Yes
Touch “Yes”to enter the touch-screen calibrate mode.
Firmware Version
the firmware version of this unit.
GENERAL Setup Menu
Accessing the General Setup Menu
·Press the button 7 on the screen to access the
GENERAL setup.
Selecting a Feature for Adjustment
Press the direction buttons on the remote control or
touch the option directly on the screen to select the
feature to be adjusted.
Adjusting a Feature
1. Enter the option field for the feature you want to
adjust by pressing the OK button on the remote or
by pressing the ENTER button. A submenu
appears in a second row with the selected option highlighted in light yellow.
2. Select a new value by pressing th e direction button or touch it directly .
3. Confirm your selection by pressing OK button or pressing the ENTER button. The new value setup is
complete.
Adjusting the Clock
1. Access the “Clock” setting under the General Setup menu.
2. Press the direction button on the remote to move the cursor to the “Hour” or “Min” position , and press
the OK button. You also can touch the “Hour” or “Min” position directly.
3. The numeric keypad will be popped up.
4. Press the numeric button on the remote control or touch the numeric keypad on the screen to adjust the
hour or minutes.
5. Press the OK button on the remote control or on the keypad of the screen to confirm setup.
Return to normal playback
The system will automatically return the previous playback mode that before accessing the setup menu
after setting with no operation.
Setting
Options
Function
USA
S-America
Radio
Europe
Select the appropriate setting based on the country in which
you reside.
Clock
(HH:MM)
See “Adjusting the clock”to learn how to set the clock.
12Hr
Clock displays 12 hour time using AM and PM.
Clock Mode
24Hr
Clock displays 24 hour time up to 23:59
Normal
The output of Camera Image is in normal mode
Camera Image
Reverse
The output of Camera Image is in reverse mode
Auto
The video output is switched automatically based on the
current disc.
NTSC
The color signal are output in the standard NTSC format
Video Format
PAL
The color signal are output in the standard PAL format

16
On
The TFT panel automatically opens when the unit is turned
on.
Off
You must press the button on the TFT panel or on the
remote to open the TFT.
TFT Auto Open
Manual
The monitor is no any movement when the unit is turned on
or turned off.
English
The menus are displayed in English
German
The menus are displayed in German
French
The menus are displayed in French
OSD Menu
Dutch
The menus are displayed in Dutch
Standby
1. Touch the button 4 to access Standby mode.
2. In the standby mode, the unit stands in low-power waste state with audio output only and no video
outputs.
3. In the standby mode, it will turn to normal by any operation.

17
Radio TFT display
1. Current Source information, touch t his area to return to MAIN menu
2. Current Radio Band Indicator
3. Current Preset Station playing Indicator
4. Stereo Broadcasting Indicator
5. Radio Frequency Indicator
6. Preset Radio Stations: Touch to recall preset stations or touch and hold to store a station.
7. User Defined Equalizer Lever
8. Loud Setting Indicator
9. Volume Indicator
10. Touch to activate/deactivate PTY (Program Type) function
11. Current time Indicator
12. Touch to change among the following bands: FM -1, FM-2, FM-3, AM-1 and AM-2.
13. Touch to automatically scan and store stations in current radio band
14. Touch to seek backward.
15. Touch to seek forward.
16. Touch to decrease one step at a time.
17. Touch to increase one step at a time.
18. Touch to activate/deactivate AF (Alternative Frequency) function .
19. Touch to activate/deactivate TA (Traffic Announcement) function.
20. Display PS (Program Service).
21. Display Program Type.
22. Touch to activate/deactivate Scan Mode
Switch to Radio Tuner source
Press the MODE button on the front panel or press the SRC button on the remote control to switch to the
Tuner source .you can also access the tuner mode from the MAIN menu directly.
Radio (FM/AM) Operation
12
13
14
15
16
17
3
1
2
4
5
6
7
8
9
10
11
19
20
21
18
22

18
Select FM/AM Band
Touch the BAND button ( ) on the screen, or press the BAND button on the remote control or on the
front panel to change among the following bands: FM-1, FM-2, FM-3,AM-1 and AM-2.
Auto Tuning
Press the button ( ) on the remote control or touch the button on the screen to seek the next
available channel by increasing the tuning frequency. Press the button again to stop searching.
Press the button ( ) on the remote control or touch the button on the screen to seek the next
available channel by decreasing the tuning frequency. Press the button again to stop searching.
Manual Tuning
Press the button ( ) on the remote control or touch the button to increase the tuning frequency one
step at a time.
Press the button ( ) on the remote control or touch the button to decrease the tuning frequency one
step at a time.
Using Preset Stations
6 numbered preset buttons store and recall stations for each band. Front 6 stored stations (1-6) for the
current band appear on the screen , touch the channel directly or press the buttons (1 -6) on the front panel
for use.
You can touch the arrow button ( ) on the screen to select other stations.
Storing a Station
1. Select a band (if needed), then select a station.
2. Touch and hold an onscreen preset button . The preset number appears at the top of the screen.
3. Press and hold the buttons (1 -6) on the front panel to store the current radio station.
Recalling a Station
1. Select a band (if needed).
2. Touch an on-screen preset button (3) to select the corresponding stored station.
3. Press the buttons (1-6) on the front panel to select the corresponding stored station.
Auto Store (AS)
Press the AS/PS button on the panel or touch the button on the screen to automatic scan and store
strong radio stations in the 6 preset channels in the current band.
Program Scan (PS)
1. Press and hold the AS/PS button on the panel to automatic scan radio stations stored in the 6 preset
channels in the current band .
2. Touch the button on the screen to automatic scan radio stations in the current band.
3. Press any button to stop scan while find the desired station.
Seek the PTY (Program Type)
Touch in the screen to enter PTY menu. then touch to select one in the PTY menu, the unit will
auto seek the next available PTY by increasing tuning frequency u ntil the program type matches the PTY,
if no matched was found ,the tuner will return to original radio and “None”is displayed .
AF(Alternative Frequency/Auto Following) Function
Touch in the screen to activate/deactivate AF function. When AF is activated and a radio signal is
too weak, the tuner auto switches to the best alternative frequency.
Note: During auto switching radio frequency, some interference could be heard, turn off AF function can
cease this issue.

19
TA(Traffic Announcement) Function
Touch in the screen to activate/deactivate AF function. When TA is activated, the unit will auto
seek an available TP or TA station .After the seeking, no matter if PTY was found, the tuner will auto seek
each 1 minutes.
When TA is activated and a traffic announcement is received in any mode other than TUNER, the
current playing mode is overridden, and i t lets you receive traffic announcements automatically. When
traffic announcement is over, the current playing mode will be resumed.
CT (Clock Time) Function
Some stations broadcast the clock and date within the encoded RDS signal, when the clock is received,
the unit will automatically adjust the clock time.
PI Seek
When RDS signal is lost for a long period, the radio will automatically seek a frequency matching with
current station PI
Note: PI seeking function is available when AF is activated.
