SEVIC SBL0701 User manual

V20080506
SEVIC BLUE LASER
SBL0701
Instruction Manua
l

E - 1
1. TABLE OF CONTENTS
Safety Information 2
Unit View 3
Handling Compact Discs 4
Installation 5
Detachable Control Panel (D.C.P.) 7
Wiring Diagram 8
Basic Operations 9
Audio Operations 10
Radio Operations 11
RDS Operations 12
CD Operations 15
USB Drive Operations 16
SD/MMC Operations 17
MP3 Operations 18
Specification 20
Troubleshooting 21
Warranty Terms and Conditions 22

E - 2
2. SAFETY INFORMATION
Please read the manual carefully before operating this unit and keep it for
future reference.
CAUTION: This unit is a class 1 laser product. To prevent direct exposure to the laser
system, do not open the unit. The laser beam may hurt your eyes.
If the unit requires adjustments, contact an authorized service centre.
USE THIS PRODUCT SAFELY
Be sure you fully understand the following safety information:
When driving
Keep the unit at an appropriate sound level. Driving with the sound at a level preventing you
from hearing sounds outside and around the car may cause an accident.
When cleaning
Do not expose the product to water or excessive moisture.
This could cause short circuit, fire or other severe damage.
When parked
Parking in direct sunlight can result in very high temperature levels inside your car.
Let the interior and unit cool down before switching the unit on.
NOTE: Do not use and store the player in dusty, hot or humid environment.
FUSE REPLACEMENT – WARNING!
Never replace any fuse with one of a higher value than the fuse
supplied with your unit.
Using a higher current rated fuse may cause damage to your unit
and/or electrical wiring.

E - 3
3. UNIT VIEW
1. P ANEL RELEASE BUTTON
2. ENCODER VOL UME KNOB / A UDIO SELECT BUTTON / PROGRAMMABLE FUNCTIONS
BUTTON / MP3
FILES SEARCH UP/DOWN MODE
3. CD SLOT
4. AF BUTTON
5. CD EJECT BUTTON
6. PRESET MEMORY BUTTONS (M1 to M6)
7. TUNING UP/ DOWN & TRACK UP / DOWN BUTTON
8. RADIO SIGNAL STRENG TH METER
9. A UTOMA TICALL Y STORE / PRESET SCAN (AS/PS) BUTTON / MP3 MENU BUTTON
10. DISPLA Y BUTTON / MP3/ID3 INFORMA TION BUTTON
11. MODE BUTTON / SUBWOOFER CONTROL
12. POWER BUTTON
13. USB CO VER / FLIP OPEN TO ACCES S TO USB SOCKET
14. BAND/LOUDNES S BUTTON / MP3 ENTER BUTTON
15. PTY BUTTON
16. T A BUTTON
TUNE
MENU
40 WATTS X 4
D
U
O
L
E
N
T
E
R
SBL0701

E - 4
4 . H A N D L I N G C O M P A C T D I S C S
MOISTURE CONDENSATION
On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit.
Should this occur, the unit will not operate properly. In such a case, remove the disc and wait
for about an hour until the moisture has evaporated.
NOTES ON CDs NOTES ON DISCS
1. A dirty or defective disc may cause
sound dropouts while playing. To
enjoy optimum sound, handle the disc
as follows. Handle the disc by its
edge. To keep the disc clean, do not
touch the surface (P.1).
2. Do not stick paper or tape on the
disc (P.2).
3. Do not expose the discs to direct
sunlight or heat sources such as hot
air-ducts, or leave them in a car
parked in direct sunlight where there
can be a considerable rise in
temperature inside the car (P.3).
4. Before playing, clean the discs with
an optional cleaning cloth. Wipe each
disc from the centre out (P.4).
5. Do not use solvents such as
benzine, thinner, commercially
available cleaners, or antistatic spray
intended for analogue discs.
If you use the discs explained below, the sticky
residue can cause the CD to stop spinning and
may cause malfunction or ruin your discs.
Do not use second-hand or rental CDs that have a
sticky residue on the surface (for example, from
peeled-off stickers or from ink, or glue leaking
from under the stickers).
There are paste residue. Ink is sticky (P.5).
Do not use rental CDs with old labels that are
beginning to peel off.
Stickers that are beginning to peel away,
leaving a sticky residue (P.6).
Do not use your CDs with labels or stickers
attached.
Labels are attached (P.7).
Do Not Use Special Shape CDs
Be sure to use round shape CDs only for this unit
and do not use any special shape CDs. Use of
special shape CDs may cause the unit to
malfunction (P.8).
Be sure to use CDs with disc mark
Only for this unit.
CD-Rs and CD-RWs which have not undergone
finalization processing cannot be played. (For
more information on finalization processing, refer
to the manual for your CD-R/CD-RW writing
software or CD-R/CD-RW recorder.) Additionally,
depending on the recording status, it may prove
impossible to play certain CDs record on CD-R or
CD-RW.
P. 1
P. 2
P. 3
P. 4
P. 5
****
*******
******* *******
*******
P. 6
**************
*******
*******
*******
P. 7
*******
*******
*******
*******
*******
P. 8
RECORDABLE REWRITABLE

E - 5
5. INST ALLA TION
z Before finally installing the unit, connect the wiring temporarily and make sure it is all
connected up properly and the unit and system work properly .
z Use only the parts included with the unit to ensure proper installation. The use of
unauthorized
parts can cause malfunctions.
z Consult with your nearest dealer if installation requires the drilling of holes or other
modifications of the vehicle.
z Install the unit where it does not get in the driver's way and cannot injure the
passenger if there is a sudden stop, like an emergency stop.I
z
If installation angle exceeds 30° from horizontal, the unit might not give its optimum
performance.
z Avoid installing the u nit where it would be subject to high temperature, such as from
direct sunlight, or from hot air, from heater , or where it would be subject to dust dirt or
excessive vibration.
z Be sure to remove the front panel before installing the unit.
DIN
FRONT/REAR-MOUNT
This unit can be property installed either from “Front” (conventional DIN F ront-mount) or
“Rear”(DIN
Rear -mount installation, utilizing threaded screw holes at the sides of the unit
chassis).
F or details, refer to the following illustrated installation methods A and B.
DIN FRON T -MOUNT (Method A)
Installing the unit
1. Dashboard
2. Holder
After inserting the half sleeve into the
dashboard, select the appropriate tab
according
to the thickness of the
d
ashboard material and bend them
inwards
to secure the holder in place.
3. Screw
1. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (4x12mm)
5. Screw
6. Support Strap
Be sure to use the support strap to secure
the
back of the unit in place. The strap can
be bent by hand to the desired angle.
7. Plain washer
30°
182
53
12
3
1
7
4
23
5
6

E - 6
Removing the unit
a. F rame
b. Insert fingers into the
groove in the front of frame and
pull out to remove the frame.
(When re-attaching the frame,
point the side with a groove down
wards
and attach it.)
c. Insert the levers supplied with the
unit into the grooves at both
sides
of the unit as shown in
figure until they click. Pulling the
levers makes it possible to
remove the
unit from the
dashboard.
T
rim Plate Installation:
Push the trim plate against the chassis until it is fitted .
Y ou must do this before you install the front panel, otherwise it can't be
attached.
DIN REAR-MOUNT (METHOD B)
Installation
using the screw holes on the sides of the unit.
F astening the unit to the factory radio mounting bracket.
1. Select a position where the
screw
holes of the bracket
and the screw holes of the
main unit become aligned
(are fitted) and tighten the
screws
at 2 places on each
side.
2. Screws
3. F actory radio mounting
bracket.
4. Dashboard or Console
5. Hook (Remove this part)
Note: the mounting box, outer
trim ring, and
half -sleeve are
not used for method
B
installation.
a
b
c
5
2
4
3
2
5

E - 7
6. DETACHABLE CONTROL P ANEL (D .C. P .)
Removing
the Detachable Control P anel (D.C. P .).
1. T urn the power off
2. Press the D.C. P . release button
3. Remove the D.C. P .
Attaching
the DCP
1. Attach the panel at the right side first, with
point B on the main unit touching point A on the
D.C. P . (As shown on the diagram).
2. Then press the left side of D.C. P . onto the main
unit
until it locks into place .
CA
UTION
DO NOT insert the D.C.P from the left side first. Doing so may damage it.
The D.C.P can easily be damaged by shocks. After removing it, place it in a protective
case and be careful not to drop it or subject it to strong shocks.
When the release button is pressed and the D.C.P is unlocked, the car's vibrations
may cause it to fall. T o prevent damage to the D.C. P , always store it in a protective case
after detaching it.
The rear connector that connects the main unit and the D.C.P is an extremely important
part. Be careful not to damage it by pressing on it with fingernails, pens, screwdrivers, etc.
Note: If the D.C.P is dirty , wipe off
the
dirt with soft, dry cloth only .
And use a cotton swab soaked in
isopropyl alcohol to clean the
socket on the back of the D.C.P.
PANEL RELEASE BUTTON
Socket
B
A
2

E - 8
7. WIRING DIAGRAM
WARNING Connecting the ISO Connector
The pin arrangement for the ISO connectors depends on the type of
vehicle you drive. Make sure to make the proper connections to
prevent damage to the unit.
The default connection for the wiring harness is described in 1
below. If the ISO connector pins are set as described in 2 or 3, make
the connection as illustrated.
1. (Default setting) The 1 pin (red) of the vehicle's ISO connector is
linked with the ignition and the 3 pin (yellow) is connected to the
constant power supply.
2. The 1 pin (red) of the vehicle's ISO connector is connected to the
constant power supply and the 3 pin (yellow) is linked to the ignition.
3. The 3 pin (yellow) of the vehicle's ISO connector is not connected
to anything, while the 1 pin (red) is connected to the constant power
supply (or both the 1(red) and 3(yellow) pins are connected to the
constant power supply).
When the connection is made as in above, the unit's power will not
be linked to the ignition key. For that reason, always make sure to
turn off the unit's power when the ignition is turned off.
To link the unit's power to the ignition, connect the ignition cable
(ACC...red) to a power source that can be turned on and off with the
ignition key.
ANTENNA SOCKET
AMP
CONNECTOR
ISO
FEMALE WITH MALE TERMINAL
ISO CONNECTOR 4 PIN+8 PIN
(See Figure 1)
YELLOW
RED
Battery wire
(YELLOW)
Ignition wire
(RED)
GREY
R-CH L-CH
REAR LINE OUT WHITE
RED
FUSE
HARNESS
AUDIO/POWER
20-PIN
(See Figure 1)
ANTENNA
JACK
(OPTION)
RCA-TO-RCA CABLES
(not supplied)
SUB
WOOFER
RCA-TO-RCA CABLE
(not supplied)
SUB WOOFER
BLUE
WHITE
11 2
3
7
5
7
5
3
8
6
4
2
4
6
8
Figure 1
CONNECTOR B
CONNECTOR A
GROUND
POWER ANTENNA
BATTERY(+)
IGNITION(ACC)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (+)
RIGHT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT FRONT SPEAKER (-)
FUNCTION/LABEL
B2
B3
B4
B5
B6
B1
B7
B8
GREY
WHITE
VIOLET
GREEN
GREY/BLACK
WHITE/BLACK
VIOLET/BLACK
GREEN/BLACK
A7
A8
PIN
A4
A5 BLUE
RED
BLACK
YELLOW
WIRE COLOR
Ignition wire
(RED)
Battery wire
(YELLOW)
Unit
1 PIN (RED)
Vehicle
3 PIN(YELLOW)
Ignition wire
(RED)
Battery wire
(YELLOW)
Unit
1 PIN (RED)
Vehicle
3 PIN(YELLOW)
Battery wire
(YELLOW)
Ignition wire
(RED)
Unit
3 PIN(YELLOW)
Vehicle
1 PIN (RED)

E - 9
8. BASIC OPERA TIONS
1)
P ANEL RELEASE BUT TON ()
Press this button to remove the control panel.
12) POWER ON/OFF BUT TON ()
Press this button to turn on or off the power .
10) DISPLA Y BUT TON ( D )
Pr es s th is bu tt on to vi ew Cl oc k, Pr og ra mm e T yp e (P TY ), an d F re qu en cy of th e st at ion in
listen
in g.
11) MODE BUT TON (MODE)
1. Press this button to select different mode , sequence as follow:
A) T uner mode (Radio)
B) CDP / MP3 (only if a CD or MP3 disc is inserted)
C) USB (only if a USB drive is inserted)
D) SD / MMC (Only if a SD or MMC card is inserted)
Note:
Whenever a USB or SD/MMC is being inserted, unit will automatically
switch to USB or SD/MMC mode, does not matter the unit is currently in what
mode.
When in USB or SD / MMC mode, if the USB or SD / MMC is being removed, unit
will automatically switch to radio mode.
2. Press it long to turn ON or OFF the Sub-woofer
RESET BUT TON
The RESET button is located on the main unit (as shown on the diagram).
T o press it vertically with a ballpoint pen or metal object will activate it. The
reset button is to be activated for the following reasons:
z Initial installation of the unit when all wiring is completed.
z All the function buttons do not operate.
z Error symbol on the display .
Note:
If press RESET button, the unit still cannot funct ion normally , please use a
cotton swab soaked in isopropyl alcohol to clean the socket on the back of the
control panel.

E - 10
9. A UDIO OPERA TIONS
2)
ENCODER VOL UME KNOB/ A UDIO SELECT BUT TON / PROGRAMMABLE
FUNCTIONS
1. T urn this knob to adjust desired volume level.
2. Press
this button to select desired audio function.
ORDER OF FUNCTION : VOLUME ( VOL) ->BAS S (BAS) ->TREBLE (TRB) ->
BALANCE
(BAL) -> FADER (F AD)
While the selected function is displayed, turn V olume Knob to adjust the level within 5
seconds, otherwise the unit will return to volume adjustment mode.
3. Long press this button to enter in programmable functions (see page 14 for
more details).
BEEPS 2ND , BEEP ALL , BEEP OFF
Press and hold SELECT button to determine how the beep sound is generated
when the keys
are pressed, using V -UP/V -DN to select the desires settings:
BEEP 2ND Beeps only when the second function of the dual function button is
selected (long press).
BEEP ALL Beeps when any buttons is pressed.
BEEP OFF To disable the beep option.
14) BAND/LOUDNESS
BUT TON (BAND/L OUD)
1. Long press the Band/Loudness Button to switch the loudness ON
or OFF . D isplay will show “LOUD ON ” or “LOUD OFF ” for a few
seconds.
2. Press this button short to change between BAND FM1, FM2, F M 3
and AM/MW bands.

E - 11
10. RADIO OPERA TIONS
8)
RADIO SIGNAL STRENG TH METER (RSLM)
This is use to indicate the signal strength of current radio station broadcast. When
you choose RADIO mode, it will show on the display .
9) A UTO MEMORY STORE/PRESET SCAN BUT TON (AS/PS)
1. PRESET SCAN : Press AS/PS button briefly to enter Preset Scan mode, it will
scan
all the preset stations in the memories, you can hear that it will stay on
each station for
about 5 seconds.
2. AUTO MEMORY STORE: Press AS/PS button for couple of seconds to enter
Auto
Store mode, this feature will automatically scan the current band and enter
up to 6 strongest stations into the 6 preset memories. T o stop Auto Store &
Scan, press the
AS/PS button again.
6) ST A TION PRESET BUT TONS (M1-M6)
1. Press these buttons briefly to recall the stored stations in the selected band.
2. Presetting stations manually , Press the BAND button to select the band for the
station
to be preset. Use T uning Up/Down to tune in the stations to be preset.
Press the Preset button at which you want to store the station for at least 2
second. The preset number will appear on the display accompanied by a beep,
this
indicate that the station has been stored into memory .
14) BAND/L OUDNESS BUT TON (BAND/L OUD)
1. Press this button short to change between BAND FM1,FM2, F M 3 and AM/MW
bands.
2. Press it long to turn ON / OFF Loudness function.
7) TUNING / SEEK UP AND TUNING / SEEK DOWN BUT TONS
1. Press these buttons briefly will operate A UTO SEARCH tuning mode, the radio
will tune up or down to the next station and remain on the frequency .
2. Press these buttons more than 2 seconds, operate as MANU AL SEARCH
buttons, under this mode the tuning frequency will advance up or down rapidly
when the
button is pressed. If the buttons are not pressed within 3 seconds,
they
will return to auto search mode.
Best
Reception
Worst
Reception

E - 12
11. RDS OPERA TIONS
4)
AF BUT TON (AL TERNATIVE FREQUENCIES)
1. Short pressed AF button to switch AF ON or OFF (AF is show on display).
In AF mode ON, the radio checks the signal strength of the AF all the time.
2. Long press AF button to select regional mode (ON or OFF)
.
-
Regional mode ON :
AF Switching or PI SEEK is implemented to the station which have all PI codes are
same as current station. REG segment is turned on, in LCD display .
-
Regional mode OFF :
The Regional code is ignored when AF switching or PI SEEK is active .
Some
broadcasting stations may change their program from normal broadcasting to
regional broadcasting for a certain period. When regional mode is off , the region
identification in the PI code is ignored; the radio may switch to a local variant of the
current program. When region mode is on, the radio will only switch to a program
carrying the exact same PI code.
Note: When AF switch is on, at this moment use tuning up/down to search station will
only
stop at station which has RDS broadcasting.
16) T A BUT TON (TRAFFIC ANNOUNCEMENT)
1. Short press TA button to switch TA ON or OFF.
When T A mode is on and traffic announcement is transmitted
- When the unit is in CD mode, it will switch to radio mode temporarily .
- If the volume level was under the threshold point, it will be raised to the
threshold point.
- When TP station is received, TP segment is turned on in LCD display .
2. Long press TA button to select EON mode ( L OCAL / DIST ANCE) .
- EON T A L OCAL mode, “EON T A L O “ is displayed a few second
When the field strength level of EON is less than the threshold level, t he radio
does not switch this station and user can barely hear disturbances.
- EON T A DIST ANCE mode, “EON T A DX” is displayed a few second
Note: When T A switch is on, at this moment use tuning up/down to search station will
only
stop at station which has T A broadcasting.
15) PTY
BUT TON (PROGRAM TYPE)
Each time when this button is pressed, the PTY mode will toggle in the following order:
PTY Music Group -> PTY Speech Group ->PTY Off
The current PTY code is displayed on the LCD, use the 6 preset buttons to select the
other PTY
code, the distribution of program type are as follow:
Button Number Music Group Speech Group
M1 POP , ROCK NEWS, AFF AIRS, INFO
M2 EAS Y , LIGHT SP O RT , E D U C A TE , DRAMA
M3 C L A S S I C S , C U L T U RE , S C I E NC E , V ARIED
M4 JAZZ , COUNTRY WEA THER,FINANCE , CHILDREN
M5 NA TION, OLDIES SOCIAL , RELIGION, PHONE IN
M6 FOLK TRA VEL , LEISURE, DOCUMENT
When PTY code is selected, the radio will search the band for the station that
matches the PTY code.

E - 13
OVERVIEW OF THE RDS FUNCTION
Radio Data System (RDS) is a broadcasting service that allows FM
stations
to send additional digital information along with the regular radio
program signal. Y our car stereo offers you a variety
of services. Here are just a few:
-
PI (Program identification)
It is a code that identified RDS stations; it is unique for each station.
- PS (PROGRAM
Service Name)
The name of current station, it is shown on the display .
-
AF (Alternative F requencies List)
The list(s) of Alternative F requencies give information on the various
transmitters
broadcasting the same program in the same or adjacent
reception area. If the main frequency should get worse, the radio will
tune automatically to the strongest Alternative frequency .
-
TP (T raffic Program)
If the tuned program carries T raffic Announcement, the TP indicator will turn on.
-
T A (T raffic Announcement)
When an actual traffic bulletin is on air, the T A indicator will also turn on.
-
PTY (Program T ype Codes)
This code is used to designate the current program material being
broadcast. W ith this feature, you can search the programs that match
the
selected program type, which is chosen from a specific list of types.
- CT
(Clock Time)
This function allows the unit to update the clock fromthe
country where the
station is broadcasting (from PI). The display could
be false because this feature is not available from all broadcasting
stations
.
Notes
z Depending on the country or region, not all of the RDS functions are available in
Italy .
z RDS may not work properly if the signal strength is weak or if the station you
are tuned to is not transmitting RDS data.

E - 14
PROGRAMMABLE OPTIONALS
T o use this function , press AUDIO SELECT BUTTON for few seconds. Each time you
press this
button, the mode will move and the functions will shown on the display. T urn
the ENCODER VOLUME KNOB
to set the desires functions .
The
function states as following:
-
T A SEEK , T A ALARM
T o determine what action will the radio take if the newly tuned station does not receive
TP information for 5 seconds.
T A SEEK
The radio retunes to a different station which contains TP information.
T A ALARM
The radio does not retune but beeps will come out.
-
PI SOUND , PI MUTE
When the vehicle is crossing the area where two stations with same AF but different
PI code can be received at the same time, the receiver will become unstable, under
this
situation two modes can be selected.
PI SOUND
The different PI sounds will be heard.
PI MUTE
Under the same situation, the radio will be muted.
-
RETUNE L , RETUNE S
T o determine the initial time of automatic T A Search or PI Search.
RETUNE L 90 seconds
RETUNE S 30 seconds
-
MASK PI, MASK ALL
“PI” is referred to “Different PI with same AF ”.
During AF search, PI stations and non-RDS stations with strong signal will be
masked, in the latter case, the non-RDS stations may cause interference, resulting
the
real AF to be masked due to the misjudgement of the radio under interference.
There are two options to handle this situation.
MASK PI to mask only the AF with different PI.
MASK ALL mask both PI and strong signal non-RDS stations.
-
BEEPS 2ND , BEEP ALL , BEEP OFF
T o determine how the beep sound is generated when the keys are pressed.
BEEP 2ND Beeps only when the second function of the dual function button is
selected (long press).
BEEP ALL Beeps when any buttons is pressed.
BEEP OFF T o disable the beep option.

E - 15
12. CD OPERA TIONS
3)
CD SL OT
Insert the disc into CD slot. The CD will begin to play .
M1) P A USE BUT TON ( )
In playing mode, press this button to pause the playing , press again to resume playing .
M2) SCAN BUT TON (SCN)
Press this button, the first 10 seconds of each track will be played sequentially until this
button is pressed again, then normal play will resume at the current track.
M3) REPEAT BUT TON (RPT)
Press this button, the current track will be played repeatedly until this button is pressed
again.
M4) RANDOM BUT TON (RDM)
Press this button to play all tracks on CD in random. Press again to desactivate it.
7) TRACK UP AND TRACK DOWN BUT TON
Press the T rack Up Button to skip to the next track or previous track. Press the
T rack Down button during play will return to the beginning of the current track, press it
one more time to skip to previous skip.
Press and hold T rack Up/Down Button to fast forward or fast reverse.
CD player starts when you release the button.
5) EJECT BUT TON ( )
Press this button to eject the CD from the unit. The receiver will switch to radio
mode automatically .

E - 16
PLEASE READ THIS INSTRUCTION CAREFUL L Y BEFORE OPERA TING THE UNIT
13. USB DRIVE OPERA TIONS
C O M P A T I B I L I T Y
Due to the fast changing technology world, this unit may or
may not be compatible to all the USB drives/devices of
the market, especially those USB drives/devices which
require installing a driver.
NOTE: This unit is not compatible with p ortable Hard-Disk.
START THE USB DEVICE MODE
1.The USB socket is covered by the USB plastic cover as
indicated in picture 1 ( P .1) . Flip open the USB plastic
cover
, and the USB
socket will become accessible.
2. Plug in the USB drive / device completely as indicated in
picture 2 ( P .2) and display will show “USB PLA Y” to
indicate that the USB drive / device is being plugged in
correctly & the download has begun.
NOTE:
The unit may take a while to detect or download the
USB files, detect &download time may vary depends on the
type of USB drive / device.
3.Does not matter the unit is in what mode (TUNER, CD,
SD/MMC, etc), once a USB drive / device is being
plugged , unit will automatically switch to USB mode.
4.All the USB files playback function is same as normal
CD or MP3 disc playback. (Please refer to section CD
operations & MP3 operations)
TO STOP USB PLAYBACK
1.The USB drive / device is unplugged, the unit
automatically switch to radio mode. Or user can use
mode button to switch to other mode.
2.User can use the mode button to choose USB mode
(only if USB drive / device is inserted in the unit ) or any
other modes, when they are in any mode.
USB 1.1 > 320KBPS
FILE MANAGE: FA T 32
W ARNING
1. Always unplugged the USB gently from the unit,
excessive force used will cause permanent & serious
damage to the unit & the USB drive / device. ( P .3)
2. Please never intentionally or accidentally hit on the
USB drive / device when it is plugged in. This will cause
permanent & serious damage to the unit & USB drive /
device.
(P4)
3. Please never try to plug in any USB drive / device with
excessive weight or excessive size into the unit. Please
always use USB drive/device with reasonable weight &
size which will not overload the unit, which will not make
performing normal operation on the front panel
impossible. Excessive weight or size USB drive / device
may cause permanent & serious damage to the unit.
And may cause access to the buttons / knobs on the
front panel impossible.
P.3
P.1
P.2
P.4

E - 17
14. SD/MMC OPERA TIONS
1. Press panel release button to release the front panel. ( P .1)
2. The SD/MMC card slot is located on the unit as indicated in ( P .2)
3. Insert the SD/MMC card into the card slot in the correct di rection until a “CLICK”
sound is heard. ( P .3)
4. Close the front panel. ( P .4)
5.
The display will s how “SD PLA Y” to indicate that the SD or MMC card is correctly
inserted.
Once the SD or MMC card is inserted , the MP3 file will aut omatically loaded &
playback will also start.
6.
The Unit will automatically switch to SD / MMC mode
, once a SD or MMC card
is
inserted
.
7. All the SD / MMC files playback function is same as normal CD or MP3 disc playback.
(Please refer to section CD operations & MP3 operations)
TO STOP SD/MMC CARD PLA YBACK
1. Push on the end of the SD or MMC card to eject the SD or MMC card. Once the SD
or MMC card is taken out, the unit will automatically switch to previous mode.( P .5- P .6)
2. User can use the mode button to choose SD / MMC mode (only if SD or MMC is
inserted
in the unit ) or any other modes, when they are in any mode.
W ARNING
1. Please make sure to insert the SD or MMC card in the correct direction / orientation
as indicated in picture ( P .7). Wrong insert will cause permanent & serious damage to
the
unit & the SD or MMC card.
2. Always make sure the SD or MMC card is completely inserted before re-attaching the
front panel.
Insert the SD/MMC
Card
with Label up side
Detach the Fron
t
Panel side
Push in till heard
a “click”
Close the front
P anel side
Push in till heard
a “click”
Remove the
Memory Card
Back Side
P.1 P.2 P.3
Click
Face
Up
P.4
Click
P.5 P.6
P.7
Front Side

E - 18
15 . M P 3 O P ER A T I O N S
Notes:
- An MP3 directory is shown in this manual as “D irectory ”, and an MP3 file is shown as
“Track”.
- Maximum length of file name: 28 characters.
- Maximum length of directory : 16 characters.
- Maximum number of tracks per disc : 254.
- Maximum number of directories per disc : 128.
- Sampling F requencies support : 32 KHz, 44 KHz and 48 KHz.
- Bit Rates support : 64 - 320 KHz including VBR.
- Supports Multi-Session recording.
- Supports CD, CDR and CDRW .
- Disc written by P acket Write (UDF) is not supported.
L OADING DISC
Insert the CD as usual, if it is an MP3 CD, the display will show “MP3 T01” then the
message
“READING” will appear , when disc scanning completed, the first track on the first
directory will play .
NOTE: 1) MP3 ICON turns on when a MP3 disc is playing.
2) MP3 ICON is blinking when under directory/Files search mode.
NAVIGA TING THROUGH DIRECTORIES AND TRACKS
NOTE
: MP3 Directory / T rack selection can be done by Encoder V olume
Knob or T une Up / Down Buttons Both operations will be described.
But
Encoder V olume Knob is available on some models only . Please
skip this description if your model is not equipped with this feature.
THERE ARE FOUR W A YS TO SELECT Y OUR F A VORITE TRACK / DIRECTORY
A) SEARCHING TRACK DIRECTL Y
Under MP3 play mode, press MP3 MENU BUTTON once, the display shows “MP3 T*”,
enter the desired track number directly , and then press MP3 ENTER BUTTON to
confirm. The distribution of the numbers is listed as follow:
Number 1 2 3 4 5 6 7 8 9 0
Button M1 M2 M3 M4 M5 M6 MODE TUNE DN TUNE UP DISP
SEARCH TRACK NUMBER B Y USING ENCODER VOL UME KNOB
Rotate the ENCODER VOL UME KNOB to scroll through the numbers, and then press
MP3 ENTER BUTTON to confirm.
B) SEARCHING B Y DIRECTORY OR TRACK NAME
(1) SEARCH DIRECTORY / TRACK NAME B Y USING TUNE UP / DOWN B UTTON
Under MP3 Play Mode, press MP3 MENU BUTTON twice, the display shows “ * “ ,
enter the character directly . The unit searches files and directories which have the
same character which is inputted by the user . The unit shows these sorted files and
directories by TUNE UP / DOWN Button (TUNE DOWN First). If the selected name is
directory , the user can go into the selected directory by press MP3 ENTER BUTTON
and continue to search the directory or file name in the directory by TUNE UP / DOWN
Button (TUNE DOWN First). The selected file can be played by pressing MP3 ENTER
BUTTON .
The distribution of alphabetical characters is listed as follow :
Button M1 M2 M3 M4 M5 M6 MODE TUNE DN TUNE UP DISP SEL VOL +/-
Character A,B,C D,E,F G,H,I J,K,L M,N,O P,Q,R S,T,U V,W,X Y,Z,Space _,-,+ Move
Cursor
Next/Prev
Chapter

E - 19
(2) SEARCH DIRECTORY / TRACK NAME B Y USING ENCODER VOL UME KNOB
Under MP3 Play Mode, press MP3 MENU BUTTON twice, the display shows “ * “.
Rotate the ENCODER VOL UME KNOB to select the character . In this Encoder Search
mode, SELECT button is used to move to next digit . Press BAND/LOUDNES S button to
confirm
. The unit searches files and directories which have the same character which is
inputted by the user . The unit shows these sorted files and directories by ENCODER
VOL UME KNOB (ROTA TE ANTI-CL OCK WISE First). If the selected name is directory ,
the
user can go into the selected directory by press MP3 ENTER BUTTON and
continue to search the directory or file name in the directory by ENCODER VOL UME
KNOB (ROTA TE ANTI-CL OCK WISE First ) The selected file can be played by pressing
MP3 ENTER BUTTON.
(C) SEARCHING FROM DIRECTORY
(1) SEARCH DIRECTORY B Y USING TUNE UP / DOWN BUTTON.
Under MP3 play mode, press MP3 MENU BUTTON three times, then the first Directory
name
is shown. Press TUNE UP/DOWN (TUNE DOWN FIRST ) to navigate through the
directory list, press MP3 ENTER BUTTON to select the desired directory . The display
will show “ \ \ “ . Select the tracks in the selected directory , by pressing TUNE
UP/DOWN Buttons (TUNE DOWN FIRST) then press MP3 ENTER BUTTON to confirm
when
desired track is found.
(2) SEARCH DIRECTORY B Y USING ENCODER VOL UME KNOB
Under MP3 play mode, press MP3 MENU BUTTON three times, Then the first Directory
name
is shown. Rotate ENCODER VOL UME KNOB ( ROTA TE ANTI-CL OCK WISE First) to
navigate
through the directory list, press MP3 ENTER BUTTON to select the desired
directory . The display will show “ \\ ”.
T o select the tracks under the selected directory , by Rotate ENCODER VOL UME KNOB
(
ROTA TE ANTI-CL OCK WISE First) then press MP3 ENTER BUTTON to confirm when
desired track is found.
(D) NAVIGA TING THROUGH DIRECTORY B Y USING M5/M6 BUT TON
Press directory up (M6) or directory down (M5) buttons to skip the current directory
forward or backward by one position.
In a multi-level directories disc, the movement will take place at the current level until the
last directory is reached. At this point press directory down (M5) again, it will move to
the next level of directory.
ID3 TAG
Press DISPLA Y button repeatedly to Display ID3 T AG information.
If the MP3 file is available with ID3 T AG, pressing the display button repeatedly will show
information in the following sequence:
SONG TITLE > ARTIST> ALBUM TITLE
If any of the ID3- T AG information is not available, pressing the DISPLA Y button repeatedly
will show information in the following sequence:
UNKNOWN SONGNAME> UNKNOWN ARTIST> NO ALBUM TITLE
If the MP3 file is without ID3 T AG, pressing the DISPLA Y button and “NO ID3 T AG” will be
displayed. The file name & track number of the MP3 file will scroll repeatedly through the
display during the playing of the MP3 file.
