Seville Classics UltraHD WEB733 User manual

#70
No. Qty. No. Qty.
#71 2 #70 1
#51 2 #45 1
Step 1.
Note:
Step 2.
1
2Note:
The Power Strip Bracket (#70) can be installed on
either the back or side (left or right) of the
hardwood top.
Tip: Pre-drill 0.5" deep pilot holes to the desired edge
of the hardwood top for a quick and easy mounting
process.
ASSEMBLY INSTRUCTIONS
UltraHD Power Strip (6-Outlet + 2 USB) with Mounting Bracket (Model No.WEB733)
#71
#45
#51
Parts
Parts
Screw R (M4 x 15L)
Power Strip Bracket
Screw J
Power Strip
First, choose the desired position on either the
rear (left or right) or on the left or right side of the
hardwood top. Next, using 2 pieces of Screw R
(#71), attach the Power Strip Bracket (#70) to the
edge of the hardwood top.
Install the Power Strip (#45) onto the Power Strip
Bracket (#70)
Attach the Power Strip (#45) to the Power Strip
Bracket (#70) using 2 pieces of Screw J (#51).
First, screw-in the 2 pieces of Screw J (#51) into
the Power Strip Bracket (#70) and tighten. Next,
line up the two holes on the back of the Power
Strip (#45) with the 2 screws protruding from the
Power Strip Bracket (#70), and mount the Power
Strip to the Power Strip Backet by sliding it from
right to left to fasten the two pieces together.
The left and right orientation of the Power Strip is
interchangeable depending on which side of the
workbench or rolling cabinet hardwood top you
want to mount it to. To change the orientation,
just screw-in the 2 pieces of Screw J (#51) into the
other two holes on the Power Strip Backet (#70)
and tighten.
Install the Power Strip Bracket (#70) onto the
hardwood top
Attach the Power Strip Bracket (#70) to the solid
hardwood top.
1
REQUIRED TOOL
Phillips Screwdriver
(Not Included)

Seville Classics, Inc.
19401 Harborgate Way Torrance, CA 90501 USA
Telephone: [phone] within USA
Fax: [phone]
Hours: 9:00am - 4:30pm (Pacific Standard Time)
E-mail: [e-mail]
Website & Online Store: www.sevilleclassics.com
UltraHD® 2-Door Rolling Workbench UltraHD® 60" Wide Rolling Workbench
Model No. 20262 (Granite) Model No. 20110B (Granite)
Model No. 20142 (Graphite) Model No. 20111B (Graphite)
Model No. 20152 (Red)
CONTACT INFORMATION
If you are missing any parts, have any questions, or need additional assistance in assembly, please contact our
bilingual (English and Spanish) customer service department at:
