SFaudio SFF2 User manual

1

ProfessionalStageHazeEffect
SFF2
EN‐InstructionManual

www.sfaudio.es




UserManual
SFaudio

2
INTRODUCTION:

SFF‐2HazeMachine

Littlegiant,withprecisemicrocomputercontrol.
SFF‐2(700W)improvesthecircuitdesignandaddsDMXdigitalmonitorwhichmakes
operationeasierandclearer.Thedigitalmonitorcancontrolthewindforceoutputand
hazeoutputwith5gears.IthasOptical‐electronicfluidinductionsystemsothatthe
fluidpumpwouldstopworkingwhenthefluidisinsufficient.Hazewouldn'tbe
produceduntilthefluidisadded.

•3,500CUFt(72m³)perminute(approx)
•Relaytemperaturecontrolledforconstanttemperaturecontrolandlongerlife
•Uniquelydesignednozzleforreducedcondensationbuildupinthepipes
•Easytousedigitaldisplayoperation
•Trueconstanthazeoutput
•Variableoutputangle
•Lowfluidindicator
•Removablefluidtank
•Timeroutputremotecontrolincluded
•Easytotransportandportable

PACKAGECONTENTS:

Pleasecheckthecontentstoensurethattheproducthasbeenreceivedingood
Condition.

1.SFF‐2Hazemachinex1pcs
2.‐PowerSupplycable
3.‐Wiredremotex1pcs
4.Handle
5.Usermanualx1pcs

Ifyoufindanyaccessoryismissingorthemachinehasarrivedwithanyproblems,
pleasecontactyourlocaldealeratonce.Donottrytofixthisitemyourselforyou
willlosethewarranty.Pleasekeeptheoriginalpackageandinvoiceforanypossible
replacementorreturneddemand.

RECOMMENDEDFLUID:
FortheSFF‐2hazemachinewestronglyrecommendthefollowingSFAUDIOheavyfog
fluidwhichhasbeenspecificallyformulatedtoperformbestwithanyheaterbasedhaze
machines.
Toguaranteetrouble‐freeoperationthespecial“SFF‐2Haze‐Fluid“mustbeused.
Useofotherliquidswillvoidthemanufacturer‘swarrantyandcanbedangerous
toyourhealth.

SETUP:
1.Unpackthehazemachine.
2.Unscrewthetopcapofthetankandremovetofillwiththerecommendedhaze
fluid
3.Replacethebottleandscrewthecapsecurelyensuringthepipeisfeddownto
SFaudio

3
thebottomofthebottlesoaconsistentflowoffluidissuppliedtothemachine.
4.Connecttheremotecontrol.
5.ConnecttheIECmainsplugandpowerup
6.Heatuptimeisusuallybetween2‐3minutes.Pleaseensurenobuttonis
pressedduringtheheatuptime.WhenthemachineisreadytheLEDlighton
themachineandremotecontrolwillilluminate.
7.Afterheatup,pleaserefertopage5“OperationforSFF‐2”.

CAUTION!TOPREVENTMORTALELECTRICALRISKANDLONGLIFEOPERATION:
Foryoursafety,pleasekindlypayattentiontoallofthewarningslistedbelow:
1.Alwayspluginthepowerpluglastanddisconnectfromthemainswhenthe
deviceisnotinuseorbeforecleaning.
2.Donotinstallandoperatethedeviceinrainorextremeheat,moistureordusty
environments.
3.Thisdeviceisforindooruseonlyandinadryenvironment.
4.Donotswitchonimmediatelybutwaituntilitreachestoroomtemperatureif
thedevicehasbeenexposedtodrastictemperaturefluctuations.
5.Donotshakethedeviceandavoidbruteforcewheninstallingoroperating.
6.Donotusethedeviceduringthunderstormsandpleasedisconnectthepower.
7.Donotusesolventsoraggressivedetergenttocleanthedevice.Useasoftand
cleancloth.
8.Donotmodifythedeviceortheconnectedpowercordwithoutauthorisation.

SELF‐CLEANINGFUNCTION:
Afteruse,pleasedon’tturnoffthemachineimmediately.
Themachinehasself‐cleaningfunction,therehas3differentrightoperations:
1.Ifusedmx‐512,pleaseturnthehazeoutputtozero/turnoffhazeoutput,thenstilllet
thepoweronabout80‐90seconds.
2.Ifusedigitaldisplaycontrol,pleaseturnthe“h”to“0",thenstillletthepoweron
about80‐90seconds.
3.Ifusetimerremote,pleaseturnthehazeoutputtozero/turnoffhazeoutput,then
stillletthepoweronabout80‐90seconds.
Afterthisoperation,theheaterwillbecleanedbyairpumptechnologyalteruse.
ThisisveryimportantnoticetomaintainSFF‐2Hazemachine!

CONNECTWITHPOWERSUPPLY–THEGROUNDWIREMUSTBE
CONNECTED:Usetheplugtoconnecttothemainpowersupplyasfollows:
WireConnection WireConnection
BrownLiveL
BlueNeutralN
SFaudio

4

QUICKTROUBLESHOOTING
Iftheunitisnotfunctioningproperly:
1.Checkifmainpowerison.
2.Checkthefusehasn’tblown.
3.Checktheunitisn’tinDMXmode.
4.Checkthereisfluidinthetankandthepipeispusheddowntothebottomofthe
bottle.
5.Ifthereisblockageusedistilledwaterorhazemachinecleaningfluid.

REPLACINGFUSE
Disconnectfromthemainpowersupplyfirst,thenremovethefuseholderabovethe
IECSockettorevealthefuse.Replacethecorrectfuseratingasstatedonlightingor
userguide.Then,lockthefuseholdercoverbackintoplace.

GENERALMAINTENANCE
Tomaintainoptimumperformanceandminimizewear,theitemshouldbecleaned
frequently.Usageandenvironmentarecontributingfactorsindeterminingfrequency.
Asageneralrule,fixturesshouldbecleanedafterusetoavoiddustbuild‐upand
blockages,whichcanresultinpoorperformances,overheatingandbreakages.Besure
topowerofffixturebeforeconductingmaintenance.

Unplugfixturefrompower.Useavacuumoraircompressorandasoftbrushtoremove
dustcollectedonexternalventsandinternalcomponents.Cleantheexternalcase
whenthefixtureiscoldwithadryclothortissue,anddragdirtandgrimetotheoutside
case.









Yellow/CyanEarth

SFaudio

5

LAYOUTSFF‐2

OPERATIONFORSFF‐2


WhenyoufirstturnontheHazemachineyoushowwaitforaround2minuteswhile
theunitwarmsup.Whencompletedyouwillhaveaccesstovariousoptionsifthe
wiredremotecontrolisnotconnected.
Pressmenutoscrollthroughthevariousoptionslistedbelow.Usetheupanddown
keystosetthesecondaryfunction.




SFaudio

6
DisplayFunction
d001‐d512DMXAddress
h0‐5Manualhazeoutput0=off,1=low,5=high
F0‐5Manualfanspeed1=slow,5=high
FlashFluidrunningoutprotection,pleaseaddfluid!

F(FanSpeed)andh(HazeOutput)aresettingsforcontinuousstand‐aloneoperation
andwilloverrideanyremotecontroloftheSFF‐2.

DMX
WheninDMXmodetherearetwochannelswiththefollowingfunction:

DMXChannelDMXScaleDetailFunction
Ch1000‐2550%‐100%FanSpeed
Ch2000‐2550%‐100%HazeVolumeOut.

TIMERCONTROLLER
ThetimercontrollercanbeusedtocontroltheSFF‐2remotely.
PleasenoteFanSpeed(F)andHazeOutput(h)mustbesettozerofortheremotetimer
controllertooperate.
Importantnotice!!!

1.Timeron/offbutton.
2.Continuousoutput.
3.Manualoverridebutton.
SFaudio

7
4.TimerLEDindicator(IlluminatedYellowwhentimeractive).
5.Manualreadyindicator(IlluminatesGreenwhenready).
6.Powerindicator(Illuminatesredwhenpowerison).
7.AdjusttheamountofHazereleased(between0–100%).

NOTE:Thebelowcontrolsareonlyusedwhenintimermode
8.AdjusttheintervalgapbetweeneachreleaseofHaze(between0–30Min
approximately).
9.AdjustthedurationtheHaze/Hazeisreleasedateachinterval(between0–15
secondsapproximately)
Forbestresultsselect“continuous”andadjustoutputtoachievedesiredeffect,noteit
cantakearound30secondsforthemachinetoproducethecorrectoutput.
Formorenewproducts,pleasekindlycontactSFAUDIO.
WorkwithSFAUDIO,moresolid,morereliableproductsarealwayswaitingforyou!

TECHNICALSPECIFICATION:

V
oltage: AC220~240V/50Hz
Power: 700W
Fuse:250V/5A
Pre‐heatingtime:2Mins
Fluidconsumption: 200min/L(30%),120min/L(100%)
Hazeoutput:3500Cuft/min
Tank:1.2L
Microcomputercontrol: YES
Timercontroller: YES
DMXCH2
Fluid‐lessprotection: YES
Digitaldisplay: YES
Grossweight7.6kg
MEAS:39x26x35CM





