CH-1
CINEMA HAZE
User Manual
- ENGLISH
© 2021 Antari Lighting and Effects Ltd.

2
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Safety Information
Please read the following safety information carefully before operating the machine.
Information includes important safety information about installation, usage, and
maintenance. Pay attention to all warning labels and instructions in this manual and
printed on the machine.
If you have questions about how to operate the machine safely, please contact your local Antari
dealer for help.
․ Keep this device dry.
․ Always connect to a grounded circuit to avoid risk of electrocution.
․ Before connecting the machine to power, always check the voltage indicated on the machine
matches to your local AC voltage. Do not use the machine if the AC power voltage does not match.
․ Disconnect the machine from AC power and gas cylinder before servicing and when not in use.
․ This product is for indoor use only! Do not expose to rain or moisture. If fluid is spilled, disconnect
AC power and clean with a damp cloth. If fluid is spilled onto electronic parts, immediately unplug
the machine and contact your local Antari dealer for advice.
․ No user serviceable and modifiable parts inside. Never try to repair this product, unauthorized
technician may lead the machine to damage or malfunction.
․ For adult use only. Never leave the machine running unattended.
․ Install in a well ventilated area. Provide at least 50 cm of space around the machine.
․ Never add flammable liquid of any kind to the machine.
․ Make sure there are no flammable materials close to the machine while operating.
․ Only use Antari fluid. Other fluid may lead to heater clog and malfunction.
․ If the machine fails to work, unplug the machine and stop operation immediately. Contact your local
Antari dealer for advice.
․ Before transporting the machine, make sure the fluid tank is completely drained.
․ Smoke fluid may present health risks if swallowed. Do not drink smoke fluid. Store it securely. In
case of eye contact or if fluid is swallowed immediately seek medical advice.
․ The appliance is not to be used by persons (including children) with reduced physical, sensory or

3
© 2021 Antari Lighting and Effects Ltd. www.antari.com
mental capabilities, or lack of experience and knowledge.
․ Children being supervised not to play with the appliance.
․ If the supply cord is damaged, it must be replaced by a special cord or assembly available from the
manufacturer or its service agent.
Product Dimension
579 mm 164 mm
164 mm
311 mm

4
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Product Overview
Setting Up
安裝操作說明
Step 1: Place the machine on a flat surface and in a suitably large area with at least 50 cm open
space around the machine.
Step 2: Connect machine to mains power (AC100-240VAC, 50/60Hz)
Step 3: Connect gas inlet to gas cylinder equip with pressure regulator. (Gas inlet 9/16 – 18 R.H.)
Step 4: Set pressure regulator between 50 to 60 psi, then open gas cylinder
Adjustable Fan
Output Nozzle
TFT LCD Control Panel
Wireless Receiver
XLR 3 / 5-Pin DMX Connector
Neutrik TRUE 1 Power Connector
Breaker
Power Switch
Gas Inlet 9/16 – 18 R.H.
Screen Switch
Fluid Tank Cap

5
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Step 5: Fill the fluid tank with Antari approved fluid.
Step 6: Press “ HEATER” menu, then press “ START” to start heating. Machine will take
approximately 8 mins to heat up.
Always connect the machine to a protected circuit and ensure it is properly grounded to
avoid risk of electrocution.
Step 7: To start making haze press “ MANUAL” menu, then press “ START” .
Press “ STOP” to stop haze. Press “ SETTING” menu to adjust haze and fan output level.
Step 8: To turn off machi ne press “ POWER OFF” menu, and follow direction shown on display.
Shut off gas cylinder, at the same time machine will start release the pressure. Make sure pressure
is completely released by checking the regulator. Disconnect power and gas connection to finish
shutting down process.
Operation
Control Panel Operation
The machine can be operated with the TFT LCD control panel located on the rear.

6
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Main Menu
Level 1
Level 2
Level 3
TIMER 1
Interval
0 – 200 mins
Duration
0 – 200 mins
Output Level
5 – 40 psi
Fan
20 – 100%
TIMER 2
Interval
0 – 200 mins
Duration
0 – 200 mins
Output Level
5 – 40 psi
Fan
20 – 100%
DMX
Address
1 – 512
Channel Mode
1 / 3 / 5 Channels
Link Mode
Wireless / Wired
Wireless
Unlink
POWER OFF
MANUAL
Output Level
5 – 40 psi
Fan
20 – 100%
CLEAN
HEATER
MENU
DMX Setup
Address
1 – 512
Channel Mode
1 / 3 / 5 Channels
Link Mode
Wireless / Wired
Wireless
Unlink
Information
Software Version
Wireless Signal
Temperature
Pressure
Device Hour

7
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Setting
LCD Backlight
High / Normal / Low / Auto
Auto Start
On / Off
Factory Reset
Language
English /中文
Software Update
Proceed
Keypad Sound
On / Off
DMX Connector Pin Assignment
The machine provides a 3 or 5 pin XLR connector for DMX connection. The diagram below indicates
pin assignment information.
Pin
Function
1
Ground
2
Data-
3
Data+
4
N/A
5
N/A
DMX Operation
Making the DMX Connection – Connect the machine to a DMX controller or to one of the machines
in the DMX chain. The machine uses both 3-pin and 5-pin XLR connector for DMX connection, the
connector is located on the rear of the machine.

8
© 2021 Antari Lighting and Effects Ltd. www.antari.com
DMX Channel Function
1 Channel Mode
DMX Value Range
Function
Output Level
0 – 4
Off
5 – 255
1 – 100%
3 Channel Mode
DMX Value Range
Function
Output Level
0 – 4
Off
5-255
1 – 100%
Fan Level
0 – 4
Off
5 – 255
1 – 100%
Heater
0 – 127
Off
128 – 255
On
5 Channel Mode
DMX Value Range
Function
Output Level
0 – 4
Off
5-255
1 – 100%
Fan Level
0 – 4
Off
5 – 255
1 – 100%
Heater
0 – 127
Off
128 – 255
On
Operation Mode
0 – 127
DMX
128 – 192
Timer 1
193 – 255
Timer 2
Cleaning
0 – 127
Off
128 – 255
On

9
© 2021 Antari Lighting and Effects Ltd. www.antari.com
RDM Control
The CH-1 CINEHAZE is RDM enabled, allowing control system to configure, mointor and manage.
See below table for supported RDM parameters
Value
RDM Parameter ID’s
GET Allowed
SET Allowed
0x0001
DISC_UNIQUE_BRANCH
0x0002
DISC_MUTE
0x0003
DISC_UN_MUTE
0x0030
STATUS_MESSAGE
O
0x0050
SUPPORTED_PARAMETERS
O
0x0051
PARAMETER_DESCRIPTION
O
0x0060
DEVICE_INFO
O
0x0070
PRODUCT_DETAIL_ID_LIST
O
0x0080
DEVICE_MODEL_DESCRIPTION
O
0x0081
MANUFACTURER_LABEL
O
0x0082
DEVICE_LABEL
O
O
0x00A0
LANGUAGE_CAPABILITIES
O
0x00B0
LANGUAGE
O
O
0x00C0
SOFTWARE_VERSION_LABEL
O
0x00E0
DMX_PERSONALITY
O
O
0x00E1
DMX_PERSONALITY_DESCRIPTION
O
0x00F0
DMX_START_ADDRESS
O
O
0x0200
SENSOR_DEFINITION
O
0x0201
SENSOR_VALUE
O
0x0400
DEVICE_HOURS
O
0x1000
IDENTIFY_DEVICE
O
O
Fluid
Use Antari CHL oil-based fluid for the best effect on CH-1 CINEMAHAZE.
The machine is tested and calibrated with this liquid to get the best
output performance. Warranty will be void if any other type of liquid is
used, improper use of liquid may lead to machine faluire and malfunction.

10
© 2021 Antari Lighting and Effects Ltd. www.antari.com
Service and Maintenance
․ Do not allow the machine to become contaminated.
․ Remove dust from air vents with air compressor, vacuum or a soft brush.
․ Only use a damp cloth to clean the casing.
․ It is recommended to run the machine on a monthly basis in order to achieve best
performance and output condition.
․ Excessive dust, liquid and dirt built up will degrade performance and cause overheating.
․
Breaker Reset
Disconnect AC power before reset breaker. Only replace fuse with same type and rating.
Step 1: Disconnect AC power
Step 2: Flip breaker to ON position
Step 3: Turn on machine to test
Breaker
120V = 8A 250V
240V = 8A 250V
Error Message
Pressure Error
When fluid reservoir can not reach proper pressure to work, pressure error will be displayed and
stop machine from working. It may be caused by one of following:
- Fluid reservoir cap is loosened
- Leak in high pressure pipeline
- Gas cylinder not open properly
- Gas cylinder running empty
- Pressure regulator not set to range between 50 – 60psi (3.4 – 4.1 bar)
- Pressure sensor failure or damaged
