Shaefer VAF3000A User manual

OWNER’S MANUAL
SAFETY INSTRUCTIONS
Please read and keep these instructions with the fan.
MODEL: VAF3000A/B
For use in Non-Explosive/Non-Flammable environments only.
Purchase Date: ___________________ Serial No. ___________________
Dealer: ______________________________________
1.800.779.3267 • www.schaeferfan.com
Item Part # Each Description
1 0SMS8X12PPHSS 4 Screw #8 x 1/2" PPH SS
3 0CAP40UF240V 1 Capacitor 115V
0CAP40UF370V 1 Capacitor 230V
0CC114 1 1-1/4" Clamp (230V only)
4 SWPLTASY-V30A 1 Switch Plate Cord Kit 115V
4 SWPLTASY-V30B 1 Switch Plate Cord Kit 230V
CORD-16/3-20NA 1 Cord 115V North America
CORD-16/3-20EU 1 Cord 230V European
CONNECTOR-PG11 1 Cord Strain Relief
0RSSPST20A 1 Rocker Switch
0RSCAP 1 Rocker Switch Cover
SWPLT-VAF3000 1 Switch Plate
5 HSG-VAF3000 1 Shell Housing Blue
6 0BM3-0.5X25HHSS 10 Bolt M3x.5 25mm
7 0WM3SS 10 Washer M3 SS
8 0RF78OD 4 Rubber Foot 7/8" OD
9 0WNM3-0.5HT 10 Well Nut M3x.5
10 0RG38X1316X38 1 Rubber Grommet 3/8"
11 0RIVET6-8A-B 13 Rivet 3/16" x 1/2" G
12 CS211-SP 1 Motor 1 HP 115V 60 Hz
CS211-50-SP 1 Motor 1 HP 230V 50 Hz
0NY3816Z 1 Nut Nyloc 3/8" -16
0W38X114FWZ 1 Washer 3/8"
0S832X14HWHTC 12 Screw 8-32 x 1/4" Threading
MTRVN-VAF3000 6 Motor Mount Vane
BLADE-VAF3000 1 Fan Blade 12" 7 Wing
13 RING-VAF3000 2 Duct Ring 12"
14 GUARD-VAF3000 2 Wire Guard 12"
PROBLEM
Unit will not run.
Unit runs but fan makes
loud scraping noise.
Unit runs but vibrates
excessively.
Unit runs but fan
does not turn.
Unit runs briefly, t en s uts
off on overload.
CAUSE
1) No power to unit.
2) Switc not on.
3) Switc is faulty.
4) Faulty / Broken cord or motor wire.
1) Unit as been severely jolted causing fan to
rub against ousing.
2) Unit as been severely jolted causing
ousing to deform.
1) Severe jolt as bent motor s aft causing unit to be out of
balance.
2) Fan blade damaged.
3) Dirt build up on one side of fan blade.
1) Fan is jammed against ousing.
2) Capacitor wire as broken/come loose,
capacitor as failed.
3) Housing as been damaged suc t at it
presses on t e fan blade.
1) Motor bearings are failing, or motor as
developed an internal electric fault.
2) Intake grill and/or ex aust grill is obstructed.
3) Excessive duct lengt .
SOLUTION
1) Plug unit in. C eck circuit breaker.
2) Place in "ON" position.
3) Replace switc .
4) Perform continuity c eck using volt/amp meter.
Repair/replace faulty/broken wire.
1) Remove motor and replace damaged motor mounts.
2) Replace ousing/unit as necessary.
1) Remove and replace motor. Replace fan blade if necessary.
2) Replace fan blade.
3) Clean fan blade.
1) Remove motor and replace damaged motor mounts.
Replace fan blade if necessary.
2) Repair/replace wires/capacitor as necessary.
3) Replace ousing/unit as necessary.
1) Replace motor.
2) Remove obstruction.
3) Reduce duct lengt to recommended maximum.
AMERIC AXIAL FAN TROUBLESHOOTING
CAUTION: All service procedures should be executed with the unit unplugged.
UNITED KINGDOM CORDS ONLY
WARNING
THIS APPLIANCE MUST BE EARTHED.
IMPORTANT!
The wirer of this mains lead are colored in
accordance with the following code:
BLUE---- NEUTRAL
BROWN---- LIVE
YELLOW / GREEN---- EARTH
As the colors of the wires in the main lead of this
appliance may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows: The wire colored brown must
be connected to the terminal marked with the
letter “L” or colored red.
The wire colored blue must be connected to the
terminal marked with the letter “N” or colored black.
The wire colored yellow/green must be connected
to the terminal marked with the letter “E” or ensure
that your machine is connected correctly. If you are
in any doubt consult a qualified electrician.
This appliance must be protected by a 13A fuse if a
13A (B.S. 1363) plug is used, or if any other type of
plug is used by a 5A fuse either in the plug or
adapter, or at the distribution board.
©2012 Schaefer Ventilation Equipment. All rights reserved.
M-VAF3000A/B
Refer to item # on pictorial breakdown on previous page.

VAF3000 PICTORIAL BREAKDOWN
INTRODUCTION
Congratulations on your selection of a new Vane Axial Fan from Schaefer Ventilation Equipment, LLC. Our
goal is to provide you with the very best in high performance air ventilators. Reading this owner's manual
will help you achieve the maximum benefit from your portable air ventilator. If you do not understand any
portion of this manual please contact Schaefer, or your authorized Schaefer dealer for proper assistance
prior to operating this Fan.
Do not allow anyone to operate the vane axial fan without first reading the operator's manual and becoming
familiar with its operation. Schaefer has endeavored to provide you with the finest equipment available for
providing air for portable ventilation purposes. The possibility does exist; however, that the vane axial fan
can be subjected to applications not intended by Schaefer.
Misuse and/or misapplication of the vane axial fan can lead to the possibility of serious
damage, injury or even death.
Anyone operating the vane axial fan should refer to current OSHA job safety and health rules and
regulations pertaining to the construction industry, with a particular emphasis on 29 CFR 1910, which
contains rules governing Permit-Required Confined Spaces for General Industry.
Record the vane axial fan model and serial number in the space provided below.
Model No.____________________ Serial No. ________________________
Date Purchased ______________________
All specifications are general in nature and are not intended for specific application purposes. Schaefer
accepts no responsibility for variations which may be evident in actual products, specifications, pictures
and descriptions contained in this publication.

MAINTENANCE
DANGER
ALWAYS SHUT OFF THE FAN AND UNPLUG IT FROM ITS POWER SOURCE TO PREVENT ACCIDENTAL STARTING AND
THE POSSIBILITY OF ELECTRICAL SHOCK AND/OR ELECTROCUTION. BE SURE THE FAN BLADE HAS STOPPED
ROTATING BEFORE PLACING ANY OBJECTS OR FINGERS NEAR THE FAN GRILL.
I. Visually check all fasteners and individual components for loose or broken parts. Tighten or replace items as required, with
genuine, factory approved replacement parts.
2. Keep the fan blade clean from debris. Accumulation of dust, dirt, paint, etc. on the fan blade will throw the blade rotation out of
balance resulting in damage. To clean the fan blade, be sure the plug is disconnected and the blade has stopped rotating.
Remove one grill and wipe blade and interior shell housing clean of debris with a damp cloth and mild liquid soap. Dry all parts
thoroughly.
DO NOT PRESSURE WASH THE FAN. Replace grill prior to next operation.
DANGER
DO NOT OPERATE THE FAN WITHOUT THE INLET AND OUTLET GRILL PROPERLY IN PLACE.
3. Contact Schaefer directly for fan maintenance or repair not described in this manual (or if you are unsure whether maintenance is
required.) at Tel# [phone] or at www.schaeferfan.com.
SERVICE
1) Refer to the TROUBLESHOOTING GUIDE in this manual.
Schaefer Limited Warranty Policy
Schaefer Ventilation Equipment, LLC (SVE) provides the following limited warranty from the
date of invoice to the initial purchaser of our products or to its customer with a dated proof of
purchase:
I. Two-year coverage applies to all products, components and assemblies provided by
SVE that prove to be defective in material or workmanship. Any such defective product
will be repaired or replaced at SVE’s option, with the defective product or component
returned, upon approval, to SVE, F.O.B Sauk Rapids, Minnesota.
II. This warranty does not cover:
a. Failure, damage or malfunction as a result of:
i. Improper installation or installation not in accordance with
installation instructions.
ii. Operating conditions that vary from SVE’s operating instructions.
iii. Misuse, abuse, negligence, alteration, or accident.
iv. Transporting the product.
v. Improper operation or lack of appropriate or regular maintenance
of the product.
b. Loss of time, inconvenience, loss of use of the product or other
consequential or incidental damages.
c. Parts that need replacement due to normal wear and tear.
d. Superficial or cosmetic rust or corrosion.
e. Any product whose name plate has been removed.
THERE ARE NO WARRANTIES OF MERCHANTABILITY OR FITNESS OF USE.
Schaefer Ventilation reserves the right to change product design and specification without prior
notice or liability.
The above constitutes the sole warranty offered by Schaefer Ventilation Equipment, LLC.
AIR FLOW RATES
(115V AC) (230V AC)
Feet Description CFM M³/Min CFM M³/Min
Free Air 2796 79.2 2492 70.6
15' duct Straight 1938 54.9 1722 48.8
25' duct Straight 1829 51.8 1646 46.6
25' duct 1-90° bend 1564 44.3 1344 38.1
25' duct 2-90° bends 1377 39.0 1232 34.9
40' duct Straight 1764 50.0 1556 44.1
50' duct Straight 1567 44.4 1173 33.2
75' duct Straight 1254 35.5 1094 31.0
The published flow rates are intended to serve only as a reference. Manufacturing tolerances, duct type and specific
operating parameters will affect the overall flow rates(s) for each particular fan.
CAUTION
THE AIR FLOW RATE DECREASES AS THE LENGTH OF DUCT INCREASES FOR BOTH BLOWING AND
EXTRACTING APPLICATIONS. AIR FLOW RATES WILL VARY WITH SPECIFIC DUCT TYPES AND MANUFACTURES.
MOTOR SPECIFICATIONS GENERAL INFORMATION & DIMENSIONS
AB
Voltage 115V AC-- 230V AC-- Type Axial
Frequency 60/50 Hz 50Hz Duct adapter 12" dia. (30 cm)
Phase Single Single Height 21" (53.34 cm)
Electric Motor 1 HP 1 HP (.75kw) Width 14" (35.65 cm)
Current (amps) 8/5.7 4.2 Length 17" (43.18 cm)
R.P.M 3300/2800 2850 Weight 32.5 lbs (14.74 kg)
Watts 615W@115V 670W @230V
Free Air (cfm) 2796 (79.2m³) 2492 (70.6m³)
Max S.P. 3" 2.5" (68mmlaq)

SAFETY PRECAUTIONS
DANGER
THE FAN IS DESIGNED FOR PORTABLE AIR VENTILATION PURPOSES ONLY. THE FAN IS NOT DESIGNED FOR TRANS-
PORTING LIQUID OR SEMI-SOLID MATERIALS. THE ELECTRIC MOTOR AND FAN HOUSING ARE NOT DESIGNED FOR
OPERATION IN AN EXPLOSIVE OR FLAMMABLE ATMOSPHERE. OPERATION OF THE FAN IN AN EXPLOSIVE OR FLAM-
MABLE ATMOSPHERE MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR EVEN DEATH. INCORRECT USE
OF THE FAN CAN RESULT IN AN ELECTRICAL SHOCK AND/OR ELECTROCUTION. ALWAYS OPERATE THE FAN IN
COMPLIANCE WITH CURRENT OSHA AND NATIONAL ELECTRIC CODE REGULATIONS.
DANGER
INCORRECT USE OF THE FAN CAN RESULT IN PROPERTY DAMAGE, PERSONAL IN URY OR EVEN DEATH. TO REDUCE
THIS RISK, GIVE COMPLETE AND UNDIVIDED ATTENTION TO THE OB AT HAND. AN ENVIRONMENT ATMOSPHERE
CONSTANTLY CHANGES. THEREFORE, IT'S RECOMMENDED THAT AIR MONITORING/ GAS DETECTION EQUIPMENT BE
USED FREQUENTLY. IF TESTS SHOW THAT THE ATMOSPHERE QUALIFIES AS A HAZARDOUS LOCATION (AN AREA
WHERE THE POSSIBILITY OF EXPLOSION AND FIRE IS CREATED BY THE PRESENCE OF COMBUSTIBLE LIQUIDS,
FLAMMABLE GASES, VAPORS, DUST, FIBERS, FLAMES OR FILINGS.) DO NOT USE THIS FAN. READ AND UNDERSTAND
THE FOLLOWING PREPARATION ITEMS AND GENERAL SAFETY INFORMATION.
PREPARATION
1) Become familiar with the fan operations before utilizing this fan. Read and understand all cautions and warnings in this
manual. Refer to current OSHA publications for complete job safety and health rules and regulations (CFR 1926 and 1910).
2) Confirm that the fan is in its original, factory configuration and has not been modified in any manner.
3) Minors should not be allowed to operate the fan. Close attention is necessary when used, especially when used near children
or animals.
4) Guard against the possibility of back-related injuries. Always lift the fan with leg muscles and not with the back.
5) Periodically inspect the fan visually for damaged or worn parts. Check for loose and/or broken parts. Be sure that the fan and
accessories are in good working condition before operating.
6) Ground the motor securely. The (U.S.) fan utilizes a NEMA 5-15P plug. It is designed to operate ONLY from a grounded, 115
volt nominal AC~, 60Hz, single phase power source that utilizes a NEMA 5-15R receptacle. The 230 volt, 50Hz Fan
(VAF3000B) comes with a power cord having no end connector. The customer must provide a plug suitable for use with
grounded receptacles at their location. The use of a ground fault circuit interrupter (GFCI) gives additional on the job
protection from electrical shock hazards caused by ground faults in commercial, industrial and residential applications.
7) Know how to stop the fan quickly in an emergency. Turn unit off using (on/off) switch located on side of unit or unplug fan from
power supply.
GENERAL SAFETY INFORMATION
1) Never place the fan in standing water because of extreme shock hazard.
2) Never allow air intake grill to become blocked.
3) Never discharge flammable solvents or kerosene based chemicals through the fan air intake grill.
4) Do not use the fan in areas where flammable or combustible liquids, gases, vapors, dust, fibers or filings may be
present.
5) Never put any object in the air intake grill.
6) Never run the fan outside when it is raining. Never store the fan outdoors.
7) Do not use the fan as a toy.
8) Use the fan only with a properly grounded outlet.
9) Unplug the fan from outlet when not in use and before servicing.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid state speed control device.
GENERAL SAFETY INFO. (Continued)
10) Do not use the fan with a damaged cord or plug. Do not pull or carry the fan by its cord, do not use cord as a handle, do
not close a door on the cord and do not pull cord around sharp edges or corners. Keep cord away from heated surfaces. Do
not unplug the Fan by pulling on cord. Grasp the plug when unplugging. Do not handle the plug or cord with wet hands.
11) Keep hair, loose clothing, fingers and all parts of the body away from the air intake grill.
12) Do not allow water inside the motor. If the motor becomes wet for any reason, unplug the fan and thoroughly dry it before
using again.
13) Never remove the ground from the power cord or plug as this may result in electrical shock or electrocution.
Removing the ground would void the warranty.
14) If the fan has been dropped, left outdoors or dropped into water, etc., please thoroughly inspect it prior to use.
If the fan is not working or if you have a question about its safe operation, do not operate it. Contact Schaefer
Ventilation directly at [phone] or at www.schaeferfan.com.
OPERATION
1) Your new fan comes to you completely assembled and ready to operate. Upon removing the fan from its carton, inspect it
for any possible damage in transit.
2) Before operating the fan, please read all the safety precautions and general safety information about the proper and safe
use of the fan.
3) Assess your job site. Certain job site locations are classified as being hazardous because the atmosphere may contain gas,
vapor or dust in explosive quantities.
DANGER
THE ELECTRIC MOTOR AND FAN HOUSING ARE NOT DESIGNED FOR OPERATION IN AN EXPLOSIVE AND/OR
FLAMMABLE ATMOSPHERE OF ANY CLASS OR GROUP. OPERATION OF THE FAN IN AN
EXPLOSIVE OR FLAMMABLE ATMOSPHERE MAY RESULT IN PERSONAL INJURY OR DEATH.
4) Locate a properly grounded outlet.
5) Prior to plugging in the fan into a grounded outlet, inspect the inlet and outlet grills and remove debris which may restrict
airflow movement. Never operate the fan without the inlet and outlet grills properly secured and in place. Never replace the
grills with other than factory supplied replacement units.
6) Note the directional airflow indicator on the external shell. This is the way the air moves.
7) Place the fan on secure footing to prevent it from shifting while in use.
8) Do not stand directly in front of and/or face the fan outlet. Personal injury can result from
being struck by debris thrown at a relatively high velocity from the fan blade.
9) When ducting is required, do not install duct while fan is in operation. Place duct lip over
the Fan duct adapter, secure firmly and note direction of the airflow.
10) When duct is used, be aware that the airflow rate decreases as the length of duct increases. Airflow rates will vary with
specific duct types and manufactures.
11 ) Position fan air inlet away from walls and other obstructions to allow for maximum air intake.
12) For safe operation, use the fan only in combination with thorough gas detection tests and continual retesting.
DANGER
ALWAYS ASSUME A CONFINED SPACE WORK AREA IS CONTAMINATED UNTIL IT HAS BEEN PROVEN SAFE FOR
WORK PERSONNEL. NEVER ENTER A CONFINED SPACE WORK AREA UNTIL IT HAS BEEN THOROUGHLY TESTED
WITH APPROPRIATE GAS DETECTION E UIPMENT AND PROVEN SAFE FOR WORK PERSONNEL.
