Sharp ND-158E1F User manual

LEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE MODULES
LEASE ASS ALONG THE USER MANUAL TO YOUR CUSTOMER
GENERAL INSTALLATION MANUAL FOR SHAR V MODULES
INTRODUCTION
This Installation Manual contains essential information for the electrical and mechanical installation that you must know before installing S ARP PV
modules. This also contains safety information you need to be familiar with. All the information described in this manual are the intellectual property of
S ARP and based on the technologies and experiences that have been acquired and accumulated in the long history of S ARP. This document does
not constitute a warranty, expressed or implied. S ARP does not assume responsibility and expressly disclaims liability for loss, damage, or expense
arising out of or in any way connected with installation, operation, use or maintenance of the PV modules. No responsibility is assumed by S ARP for
any infringement of patents or other rights of third parties that may result from use of PV module. S ARP reserves the right to make changes to the
product, specifications or installation manual without prior notice.
GENERAL INFORMATION (INCLUDING WARNING AND SAFETY)
The installation of PV modules requires a great degree of skill and should only be performed by a qualified licensed professional, including licensed con-
tractors and licensed electricians. Please be aware that there is a serious risk of various types of injury occurring during the installation including the risk
of electric shock. All S ARP PV modules are equipped with a permanently attached junction terminal box that will accept variety of wiring applications
or with a special cable assembly for ease of installation, and they do not require special assembly.
General Warning
1. PV modules are heavy. andle with care.
2. Before you attempt to install, wire, operate and maintain the PV module, please make sure that you completely understand the information de-
scribed in this installation manual.
3. Contact with electrically active parts of a PV module such as terminals can result in burns, sparks and lethal shock whether the PV modules is
connected or not.
4. PV modules produce electricity when the sufficient sunlight or other sources illuminate the module surface. When the modules are connected in
series, voltage is cumulative. When the modules are connected in parallel, current is cumulative. As a result, a large-scale PV system can pro-
duce high voltage and current which could present an increased hazard and may cause serious injury or death.
5. Do not connect the PV modules directly to the loads such as motor since the variation of the output power depending on the solar irradiation
causes damage for the connected motor.
1: In the case of a brushless motor, the lock function becomes active and the hall IC is most likely to be damaged.
2: In the case of a brush type motor, the coil is most likely to be damaged.
General Safety
1. Consult local codes and other applicable laws concerning required permits on regulations concerning installation and inspection requirements.
2. Before installing a PV module, contact appropriate authorities to determine permit, installation and inspection requirements that should be fol-
lowed.
3. Install PV modules and ground frames in accordance with applicable rules and regulations.
4. PV modules should be installed and maintained by qualified personnel. Only installer/servicer personnel should have access to the PV module in-
stallation site.
5. No matter where the PV modules are installed, either roof mounted construction or any other type of structures above the ground, appropriate
safety practices should be followed and required safety equipment should be used in order to avoid possible safety hazards. Note that the instal-
lation of some PV modules on roofs may require the addition of fireproofing, depending on local building/fire codes.
6. In the case that the PV modules are non-integral type, the module is to be mounted over a fire resistant roof.
7. Please use PV modules with same cell size within series.
8. Follow all safety precautions of other components used in the system.
9. In order to avoid a risk of injury or electrical shock, do not allow anyone to approach the PV module if the person has little knowledge on PV
module or on the measures that should be taken when PV modules are damaged.
10. Do not shade portions of the PV module surface from the sunlight for a long time. The shaded cell may become hot (hot spot phenomenon)
which results in solder joints peeling off.
11. Do not clean the glass surface with chemicals. Do not let water stay on the glass surface of PV modules for a long time. This creates a risk of
white efflorescence (glass disease) which may result in the deterioration of energy generation.
12. Do not install the PV module horizontally. It may cause dirt or white efflorescence (glass disease) due to water cumulation.
13. Do not cover the water drain holes of the frame. There is a risk of frost damage when the frame is filled with water.
14. When sliding snow load has to be considered, an appropriate measure has to be taken so that PV module frames on lower edge of PV modules
will not be damaged.
15. Do not expose PV module to sunlight concentrated with mirrors, lenses or similar means.
16. Turn off inverters and circuit breakers immediately, should a problem occur.
17. In case the glass surface of a PV module is broken, wear goggles and tape the glass to keep the broken pieces in place.
18. A defective PV module may generate power even if it is removed from the system. It may be dangerous to handle the PV module while exposed
to sunlight. Place a defective PV module in a carton so PV cells are completely shaded.
19. In case of series connection, the maximum open circuit voltage must not be greater than the specified maximum system voltage. The voltage is
proportional to the number of series. In case of parallel connection, please be sure to take proper measure (e.g. fuse for protection of module
and cable from over current, and/or blocking diode for prevention of unbalanced strings voltage) to block the reverse current flow. The current
may easily flow in a reverse direction.
Handling Safety
1. Do not cause an excessive load on the surface of PV module or twist the frame. The glass surface can easily break.
2. Do not stand or step on the PV module. The surface glass of PV module is slippery.
3. Do not hit or put excessive load on the glass or back sheet. The PV cell is very thin and can be easily broken.
4. Do not scratch or hit at the back sheet. The back sheet is vulnerable.
5. Do not hit on the terminal box or do not pull the cables. The terminal box can crack and break.
6. Never touch terminal box or the end of output cables with bare hands when the PV module is irradiated. Cover the surface of PV module with
cloth or other suitable sufficiently opaque material to isolate the PV module from incident light and handle the wires with rubber-gloved hands to
avoid electric shock.
7. Do not scratch the output cable or bend it with force. The insulation of output cable can break and may result in electricity leakage or shock.
8. Do not pull the output cable excessively. The output cable may unplug and cause electricity leakage or shock.
9. Do not drill holes in the frame. It may compromise the frame strength and cause corrosion of the frame.
10. Do not scratch the insulation coating of the frame (except for grounding connection). It may cause corrosion of the frame or compromise the
framework strength.
11. Do not loosen or remove the screws of the PV module. It may compromise the joint strength of PV module and cause corrosion.
12. Do not touch the PV module with bare hands. The frame of PV module has sharp edges and may cause injury.
13. Do not drop PV module or allow objects to fall down on the PV module.
14. Do not try artificially to concentrate sunlight on the PV module.
15. Do not grab the PV module at only one side. The frame may bend. Grab the PV module at two sides facing each other.

Installation Safety
1. Always wear protective head gear, insulating gloves and safety shoes (with rubber soles).
2. Keep the PV module packed in the carton until installation.
3. Do not touch the PV module unnecessarily during installation. The glass surface and the frames get hot. There is a risk of burn, or you may col-
lapse because of electric shock.
4. Do not work under rain, snow or windy conditions.
5. Use insulated tools.
6. Do not use wet tools.
7. Do not drop tools or hard objects on PV modules.
8. When installing PV modules far above ground, do not drop any object (e.g., PV module or tools).
9. Make sure flammable gases are not generated near the installation site.
10. Completely cover the PV module surface with an opaque material during PV module installation and wiring.
11. Plug in the connector tight and ensure the wiring works.
12. Due to the risk of electrical shock, do not perform any work if the terminals of PV module are wet.
13. Do not touch the terminal box and the end of output cables (connectors) with bare hands during installation or under sunlight, regardless of
whether the PV module is connected to or disconnected from the system.
14. Do not unplug the connector if the system circuit is connected to a load.
15. Do not stand on the glass at work. There is a risk of injury or electric shock if glass is broken.
16. Do not work alone (always work as a team of 2 or more people).
17. Wear a safety belt if working far above the ground.
18. Do not wear metallic jewellery which can cause electric shock during installation.
19. Do not damage the back sheet of PV modules when fastening the PV modules to a support by bolts.
20. Do not damage the surrounding PV modules or mounting structure when replacing a PV module.
21. Bind cables by the insulation locks. Drooping down of cables from the terminal box could possibly cause various problems such as animal biting,
and electricity leakage in puddle.
22. Take proper measures for preventing the laminate (consisting of resin, cells, glass, back sheet, etc.) from dropping out of the frame in case the
glass is broken.
23. Cables shall be located so that they will not be exposed to direct sunlight after installation to prevent degradation of cables.
COM ONENTS SITE SELECTION
In most applications, the PV modules should be installed in a location where there is no shading throughout the
year. In the Northern emisphere, the PV modules should typically face south, and in the Southern emi-
sphere, the PV modules should typically face north. Please make sure that there are no obstructions in the sur-
roundings of the site of installation. Take proper steps in order to maintain reliability and safety, in case the PV
modules are used in areas such as: eavy snow areas / Extremely cold areas / Strong wind areas / Installations
over, or near, water / Areas where installations are prone to salt water damage(*) / Small islands or desert areas.
(*) If you are planning to use the PV modules where the salt water damage may be possible, please consult with
S ARP local agent first to determine an appropriate installation method, or to determine whether the installation is
possible.
TILT ANGLE
The tilt angle of the PV module is measured between the PV module and a horizontal ground surface . The PV module generates the maximum output
power when it faces the sun directly. For the standalone systems with a battery where the PV modules are attached to a permanent structure, the tilt
angle of the PV modules should be determined to optimize the performance when the sunlight is the scarcest. In general, if the electric power genera-
tion is adequate when the sunlight is the scarcest, then the angle chosen should be adequate during the rest of the year. For grid-connected installa-
tions where the PV modules are attached to a permanent structure, it is recommended to tilt the PV module at the angle equal to the latitude of the
installation site so that the power generation from the PV module will be optimum throughout the year.
WIRING
To ensure proper system operation and to maintain your warranty, observe the correct
cable connection polarity (Figures 1 & 2) when connecting the modules to a battery or to
other modules. If not connected correctly, the bypass diode could be destroyed. PV
modules can be wired in series to increase voltage. Connect wires from the positive terminal
of one module to the negative terminal of the next module. Figure 1 shows modules
connected in series. Connect PV modules in parallel to increase current. Connect wires from
the positive terminal of one module to the positive terminal on the next module. Figure 2 shows modules connected in parallel.
INSTALLATION ELECTRICAL RATING
Refer to installation manual of individual models of PV module. Refer to installation manual of individual models of PV module.
GROUNDING
All PV modules must be grounded by electrical connection of the module frames to ground. Please be careful in
arranging the system ground so that the removal of one module from the circuit will not interrupt the grounding of any
other modules. The modules should be grounded to the same electrical point as described below. Each PV module
has a hole on the side frame for either a bolt, nut and washer grounding the module to the frame, a ground lug
fastened by bolt or screw, or appropriate screw (hardware not provided). An example of acceptable ground
connection using a bolt, nut and washer retaining a ground lug is shown in figure 3. In a connection of this type, the
hardware (such as a toothed locked washer / star washer) must score the frame surface to make positive electrical
contact with the frame. The ground wire must be considered within the requirement of local regulations at the site of installation.
MOUNTING
Please make sure that all the information described in the installation manual is still valid and proper for your installation. The mounting method has
been verified by S ARP and NOT CERTIFIED by a third party organization. The approved way to mount Sharp PV modules to a support structure is
using the bolt holes provided as described in the Specifications. Although Sharp does not specify or warrant frame clips or clamps, using frame clips
(not provided) or clamps (not provided) is also possible when they are designed for PV modules and with minimum dimensions on the sides of the
module in accordance with the instructions and drawings provided. If using frame clips or clamps, the modules should be fixed rigidly and there shall
be no damage to the modules by deforming mounting structure against design load. Sharp does not specify or warrant frame clips. The Sharp module
warranty may be void if customer-selected frame clips which are improper or inadequate with respect to the module properties (including strength or
material) or installation. Note that if metal clips are used, there must be a path to ground from the clips, (for instance, using star washers in the clip
hardware set). Please review the descriptions and drawings carefully; not mounting the modules according to one of these methods may void your
warranty. These mounting methods are designed to allow module loading of 2400Pa. Support structures that PV modules are mounted on should be
rigid. Sharp PV modules are designed to secure their electric performance under the condition that they are mounted on rigid support structures. De-
formation of support structure may damage PV module with its electric performance.
MAINTENANCE
The modules are designed for long life and require very little maintenance. If the angle of the PV module is 5 degrees or more, normal rainfall is suffi-
cient to keep the module glass surface clean under most weather conditions. If dirt build-up becomes excessive, clean the glass surface only with a
soft cloth using water. If cleaning the back of the module is required, take utmost care not to damage the back side materials. In order to ensure the
operation of the system, please check the connection of wiring and the state of the jacket of wires every now and then.
Electrical Cable
Electrical Cable
Connector
Connector
Terminal box
Glass
Frame
Cell
Figure 1. SERIES for more voltage Figure 2. PARALLEL for more current
SIDE FRAME
HEXAGON NUT
TOOTHED LOCK WASHER
WIRE BINDING LUG
WIRE
HEXAGON HEAD BOLT
WIRE INSERT
SCREW TERMINAL
Figure 3

499
4
98
1318
1238
( )10
()6
.
9
1
259 450 350
349
259 450 350
6- 9
400
400
HOLE FOR GROUND 2- 3.3
125
56.5 15
434.5 0
1
()6.91
( )10
D
CC
C
C
DD
D
3
R-
4
5
.2R-
4
GROUND SYMBOL
GROUND SYMBOL
(+)
(-)
58 900 50
PVU-B50
IP65
1000V
PVU-B50
CE
FFiigguurree 11
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
FFiigguurree 22
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
INSTALLATION MANUAL FOR HOTOVOLTAIC MODULES
ND-158E1F ND-162E1D ND-162E1F ND-170E1D
ND-170E1F NU-180E1
INSTALLATION
The mounting method has been verified by S ARP and NOT CERTIFIED by a third party organization. Please review the descriptions and drawings
carefully; not mounting the modules according to one of these methods may void your warranty. These mounting methods are designed to allow
module loading of 2400Pa.
Mounting Using Frame Bolt Holes (Figures 1 & 2)
The modules may be fastened to a support using the bolt holes in the bottom of the frame at location “C”, as shown in Figure 1 (back view of the
module) and Figure 2 (mounting detail). The module should be fastened with four (4) M8 (5/16”) bolts. Take care during installation to not block the
drain holes (D) shown in Figure 1.
Mounting Using Clips on Long Edge of Module: Long Edge arallel to Array Rails (Figure 4)
The modules may be mounted using clips (clamps) designed for solar modules as shown in Figures 3 and 4. Note that the clip positions are impor-
tant – the clip centerlines must be between 3.2” (81mm) and 13” (330mm) from the end of the module. The module must be supported along the
length of the long edge, and should overlap the array rail by at least 0.4” (10mm). Note that the mounting clips should meet the minimum dimen-
sions (catch width of 0.2” (5mm) and length of 1.2” (30mm)) as shown in Figure 3. The array rails must support the bottom of the modules and
must be continuous pieces (no breaks in the rail). Take care during installation to not block the drain holes (D) shown in Figure 1.
Mounting Using Clips on Long Edge of Module: Long Edge erpendicular to Array Rails (Figure 5)
The modules may also be mounted using clips on the long sides of the module when the array rails are perpendicular to the long sides, as shown in
Figure 5. The clip centerlines must be between 3.2” (81mm) and 13” (330mm) from the ends of the module. Note that the mounting clips should
meet the minimum dimensions (catch width of 0.2” (5mm) and length of 1.2” (30mm)) shown in Figure 3. The array rails must support the bottom of
the modules and must be continuous pieces (no breaks in the rail). Take care during installation to not block the drain holes (D) shown in Figure 1.
Clip
Frame
Rail
10mm Min.
Support width
5mm Min.
Catch width
30mm Min.
Catch length
3.2" (81mm) < e< 13" (330mm)
e
e
e
e
3.2" (81mm) < S < 13" (330mm)
S
S
S
S
FFiigguurree 33FFiigguurree 44FFiigguurree 55
For your reference, please use
the washer specified as below
for the minimum requirement:
1) Spring washer
Material Stainless SUS304A
Diameter M8 8.2/15.4 mm
(JIS B 1251)
Thickness 2 mm (reference
value)
2) Washer
Material Stainless SUS304A
Diameter M8 8.5/15.5 mm
(JIS B 1256)
Thickness 1.6 mm (refer-
ence value)
ELECTRICAL INSTALLATION INSTRUCTION
Note: Parallel configuration is not limited in case of taking proper measure (e.g. fuse for protection of module and cable from over
current, and/or blocking diode for prevention of unbalanced strings voltage) to block the reverse current flow.
Size: 4.0mm2
Cable characteristics Type: CE cable
Temperature rating of conductor: -40 - 110oC
Module configuration NU-180E1 maximum series configuration: 26 in series
(Recommend) All other maximum series configurations: 27 in series
This value is calculated under the condition of Voc at -40oC.
* This module maximum system Maximum parallel strings w/o proper measures (e.g. fuse
voltage is 1000V and/or blocking diode): 1 string

499
498
1318
1238
( )10
()6
.9
1
259 450 350
349
259 450 350
6- 9
400
400
HOLE FOR GROUND 2- 3.3
158.5 0
1
()6.91
( )10
D
CC
C
C
DD
D
3
R-
4
5
.2R-
4
125
0
1
58
56.5 15
50
(-)
56.5 15
(+)
GROUND SYMBOL
GROUND SYMBOL
125
158.5
58 900 50
PVU-B50
IP65
1000V
PVU-B50
CE
900
PVU-B50
IP65
1000V
PVU-B50
CE
FFiigguurree 11
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
FFiigguurree 22
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
INSTALLATION MANUAL FOR HOTOVOLTAIC MODULES:
ND-148EZB ND-158EZB
INSTALLATION
The mounting method has been verified by S ARP and NOT CERTIFIED by a third party organization. Please review the descriptions and drawings
carefully; not mounting the modules according to one of these methods may void your warranty. These mounting methods are designed to allow
module loading of 2400Pa.
Mounting Using Frame Bolt Holes (Figures 1 & 2)
The modules may be fastened to a support using the bolt holes in the bottom of the frame at location “C”, as shown in Figure 1 (back view of the module) and Figure 2
(mounting detail). The module should be fastened with four (4) M8 (5/16”) bolts. Take care during installation to not block the drain holes (D) shown in Figure 1.
Mounting Using Clips on Long Edge of Module: Long Edge arallel to Array Rails (Figure 4)
The modules may be mounted using clips (clamps) designed for solar modules as shown in Figures 3 and 4. Note that the clip positions are important – the clip
centerlines must be between 3.2” (81mm) and 13” (330mm) from the end of the module. The module must be supported along the length of the long edge, and
should overlap the array rail by at least 0.4” (10mm). Note that the mounting clips should meet the minimum dimensions (catch width of 0.2” (5mm) and length of 1.2”
(30mm)) as shown in Figure 3. The array rails must support the bottom of the modules and must be continuous pieces (no breaks in the rail). Take care during installa-
tion to not block the drain holes (D) shown in Figure 1.
Mounting Using Clips on Long Edge of Module: Long Edge erpendicular to Array Rails (Figure 5)
The modules may also be mounted using clips on the long sides of the module when the array rails are perpendicular to the long sides, as shown in
Figure 5. The clip centerlines must be between 3.2” (81mm) and 13” (330mm) from the ends of the module. Note that the mounting clips should
meet the minimum dimensions (catch width of 0.2” (5mm) and length of 1.2” (30mm)) shown in Figure 3. The array rails must support the bottom of
the modules and must be continuous pieces (no breaks in the rail). Take care during installation to not block the drain holes (D) shown in Figure 1.
Clip
Frame
Rail
10mm Min.
Support width
5mm Min.
Catch width
30mm Min.
Catch length
3.2" (81mm) < e< 13" (330mm)
e
e
e
e
3.2" (81mm) < S < 13" (330mm)
S
S
S
S
FFiigguurree 33FFiigguurree 44FFiigguurree 55
For your reference, please use
the washer specified as below
for the minimum requirement:
1) Spring washer
Material Stainless SUS304A
Diameter M8 8.2/15.4 mm
(JIS B 1251)
Thickness 2 mm (reference
value)
2) Washer
Material Stainless SUS304A
Diameter M8 8.5/15.5 mm
(JIS B 1256)
Thickness 1.6 mm (refer-
ence value)
ELECTRICAL INSTALLATION INSTRUCTION
Note: Parallel configuration is not limited in case of taking proper measure (e.g. fuse for protection
of module and cable from over current, and/or blocking diode for prevention of unbalanced strings
voltage) to block the reverse current flow.
Size: 4.0mm2
Cable characteristics Type: CE cable
Temperature rating of conductor: -40 - 110oC
Module configuration Maximum series configuration: 26 in series
(Recommend) This value is calculated under the condition of Voc at -40oC.
* This module maximum system Maximum parallel strings w/o proper measures (e.g. fuse
voltage is 1000V and/or blocking diode): 1 string

628
607
1575 1515
( )10
()6.91
58
125
60 15
350 0
1
()6.91
( )10
900 50
187.5 300 300 300 300
100
297
657
HOLE FOR GROUND 2- 3.3
R5
.
4
D
C
C
C
D
3
R-4
5
.
2
R
-4
C
C
C
DD
(+)
(-)
GROUND SYMBOL
GROUND SYMBOL
PVU-B50
IP65
1000V
PVU-B50
CE
FFiigguurree 11
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
FFiigguurree 22
BOLT M8 x 20mm
WASHER
SPRING WASHER
NUT
SOLAR MODULE
1.
2.
3. 4.
WASHER
(BOLT 5'16" x 3/4")
INSTALLATION MANUAL FOR HOTOVOLTAIC MODULES
NT-170E1 NT-175E1
INSTALLATION
The mounting method has been verified by S ARP and NOT CERTIFIED by a third party organization. Please review the descriptions and drawings
carefully; not mounting the modules according to one of these methods may void your warranty. These mounting methods are designed to allow
module loading of 2400Pa.
Mounting Using Frame Bolt Holes (Figures 1 & 2)
The modules may be fastened to a support using the bolt holes in the bottom of the frame at location “C”, as shown in Figure 1 (back view of the
module) and Figure 2 (mounting detail). The module should be fastened with six (6) M8 (5/16”) bolts. Take care during installation to not block the
drain holes (D) shown in Figure1.
Mounting Using Clips on Long Edge of Module: Long Edge arallel to Array Rails (Figure 4)
The modules may be mounted using clips (clamps) designed for solar modules as shown in Figures 3 and 4. Note that the clip positions are impor-
tant – the clip centerlines must be between 6.4” (162mm) and 15.5” (393mm) from the end of the module. The module must be supported along
the length of the long edge, and should overlap the array rail by at least 0.4” (10mm). Note that the mounting clips should meet the minimum di-
mensions (catch width of 0.2” (5mm) and length of 1.2” (30mm)) as shown in Figure 3. The array rails must support the bottom of the modules and
must be continuous pieces (no breaks in the rail). Take care during installation to not block the drain holes (D) shown in Figure 1.
Mounting Using Clips on Long Edge of Module: Long Edge erpendicular to Array Rails (Figure 5)
The modules may also be mounted using clips on the long sides of the module when the array rails are perpendicular to the long sides, as shown in
Figure 5. The clip centerlines must be between 6.4” (162mm) and 15.5” (393mm) from the ends of the module. Note that the mounting clips should
meet the minimum dimensions (catch width of 0.2” (5mm) and length of 1.2” (30mm)) shown in Figure 3. The array rails must support the bottom of
the modules and must be continuous pieces (no breaks in the rail). Take care during installation to not block the drain holes (D) shown in Figure 1.
Clip
Frame
Rail
10mm Min.
Support width
5mm Min.
Catch width
30mm Min.
Catch length
6.4" (162mm) < g< 15.5" (393mm)
g
g
g
g
6.4" (162mm) < u< 15.5" (393mm)
u
u
uu
FFiigguurree 33FFiigguurree 44FFiigguurree 55
For your reference, please use
the washer specified as below
for the minimum requirement:
1) Spring washer
Material Stainless SUS304A
Diameter M8 8.2/15.4 mm
(JIS B 1251)
Thickness 2 mm (reference
value)
2) Washer
Material Stainless SUS304A
Diameter M8 8.5/15.5 mm
(JIS B 1256)
Thickness 1.6 mm (refer-
ence value)
ELECTRICAL INSTALLATION INSTRUCTION
Note: Parallel configuration is not limited in case of taking proper measure (e.g. fuse for protection
of module and cable from over current, and/or blocking diode for prevention of unbalanced strings
voltage) to block the reverse current flow.
Size: 4.0mm2
Cable characteristics Type: CE cable
Temperature rating of conductor: -40 - 110oC
Module configuration Maximum series configuration: 17 in series
(Recommend) This value is calculated under the condition of Voc at -40oC.
* This module maximum system Maximum parallel strings w/o proper measures (e.g. fuse
voltage is 1000V and/or blocking diode): 1 string

INSTALLATION MANUAL FOR HOTOVOLTAIC MODULES
ELECTRICAL OUT UT AND THERMAL CHARACTERISTICS
Rated electrical characteristics are within ±10 percent of the indicated values of Isc, Voc, and +10/-5 percent of Pmax under STC (standard test
conditions) (irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C (77°F). The warranty conditions are specified elsewhere in
this manual.
LEASE READ THIS MANUAL CAREFULLY BEFORE USING THE MODULE
IM ORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions for the PV module that must be followed during the maintenance of PV modules.
To reduce the risk of electric shock, do not perform any servicing unless you are qualified to do so.
1. The installation must be performed by a certified installer/servicer to ensure system integrity and safety.
2. The installation is only allowed after referring and understanding of GENERAL INSTALLATION MANUAL and INSTALLATION MANUAL
-P OTOVOLTAIC MODULE-. If you don’t have your personal copy, please contact your installer or local Sharp office listed in Sharp
Solar web site : URL : http://www.sharp-world.com/solar
3. Do not pull the PV cables.
4. Do not touch any surface of module.
5. Do not place/drop objects onto the PV modules.
6. Do not disassemble or attempt to repair the PV module by yourself.
7. Do not drop the PV module.
8. Do not damage, pull, bend, or place heavy material on cables.
9. Upon completion of any service or repairs, ask the installer/servicer to perform routine checks to determine that the PV modules are in
safe and proper operating condition.
10. When replacement parts are required, be sure the installer/servicer uses parts specified by the manufacturer with same characteristics
as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazard.
11. Consult your local building and safety department for required permits and applicable regulations.
CCAAUUTTIIOONN:: IIGG VVOOLLTTAAGGEE
TToo rreedduuccee tthhee rriisskk ooff eelleeccttrriicc sshhoocckk,, ddoo nnoott ttoouucchh..
Under normal conditions, a photovoltaic module is likely to experience conditions that produce more current and/or voltage than reported at Stan-
dard Test Conditions. Accordingly, the values of Isc and Voc marked on this module should be multiplied by a factor of 1.25 when determining com-
ponent voltage ratings, conductor capacities, fuse sizes and size of controls connected to the module output.
MMaaxxiimmuummTToolleerraanncceeOOppeenn--CCiirrccuuiittSShhoorrtt--CCiirrccuuiittVVoollttaaggee aatt PPooiinnttCCuurrrreenntt aatt PPooiinnttMMaaxxiimmuummOOvveerr--AApppplliiccaattiioonn
PPoowweerrVVoollttaaggeeCCuurrrreennttooff MMaaxx.. PPoowweerrooff MMaaxx.. PPoowweerrSSyysstteemm CCuurrrreennttCCllaassss
(
(P Pm ma ax x) )( (V Vo oc c) )( (I Is sc c) )( (V Vm mp pp p) )( (I Im mp pp p) )V Vo ol lt ta ag ge eP Pr ro ot te ec ct ti io on n
NNDD--115588EE11FF158.0W +10% / -5% 28.6V 7.92A 22.5V 7.03A 1000V 15A A
NNDD--116622EE11DD162.0W +10% / -5% 28.4V 7.92A 22.8V 7.11A 1000V 15A A
NNDD--116622EE11FF162.0W +10% / -5% 28.8V 7.95A 22.7V 7.14A 1000V 15A A
NNDD--117700EE11DD170.0W +10% / -5% 28.9V 8.02A 23.4V 7.27A 1000V 15A A
NNDD--117700EE11FF170.0W +10% / -5% 29.3V 8.04A 23.2V 7.33A 1000V 15A A
NNUU--118800EE11180.0W +10% / -5% 30.0V 8.37A 23.7V 7.60A 1000V 15A A
NNDD--114488EEZZBB148.0W +10% / -5% 29.7V 6.85A 24.3V 6.10A 1000V 15A A
NNDD--115588EEZZBB158.0W +10% / -5% 29.8V 7.19A 24.4V 6.48A 1000V 15A A
NNTT--117700EE11170.0W +10% / -5% 44.2V 5.30A 35.0V 4.86A 1000V 10A A
N
NT T- -1 17 75 5E E1 1175.0W +10% / -5% 44.4V 5.40A 35.4V 4.95A 1000V 10A A

ŘED OUŽITÍM MODULŮ SI OZORNĚ ŘEČTĚTE TUTO ŘÍRUČKU
DŮLEŽITÉ BEZ EČNOSTNÍ OKYNY
V této příručce jsou uvedeny důležité bezpečnostní pokyny týkající se PV-modulu, které musíte dodržovat při jeho údržbě.
Abyste snížili nebezpečí úrazu elektrickým proudem, neprovádějte žádné servisní opravy, pokud k nim nemáte dostatečnou kvalifikaci.
1. Instalaci musí provést kvalifikovaný montér nebo servisní pracovník, který zajistí integritu a bezpečnost systému.
2. Před instalací je nutno přečíst si a pochopit OBECNÝ NÁVOD K INSTALACI a NÁVOD K INSTALACI FOTOVOLTAICKÉ O MODULU.
Pokud nemáte svůj vlastní výtisk, obraťte se laskavě na montéra nebo místní pobočku společnosti Sharp, která je uvedena na webové
stránce Sharp Solar : URL : http://www.sharp-world.com/solar
3. Nevytahujte PV-kabely.
4. Nedotýkejte se nikde povrchu modulu.
5. Na PV-moduly nesmíte pokládat ani upustit žádné předměty.
6. Nerozebírejte a nepokoušejte se opravovat PV-modul sami.
7. Dávejte pozor, abyste PV-modul nepustili.
8. Nepoškozujte, netahejte, neohýbejte kabely, ani je nezatěžujte těžkými předměty.
9. Po dokončení každé údržby nebo opravy požádejte montéra nebo servisního pracovníka, aby provedl běžnou kontrolu a ujistil se, že PV-
moduly jsou v bezpečném a řádném provozním stavu.
10. Pokud je nutná výměna náhradních dílů, ujistěte se, že montér nebo servisní pracovník používá výhradně díly specifikované výrobcem,
které mají stejné parametry jako originální díly. Neschválené výměny mohou způsobit požár, úraz elektrickým proudem nebo jiné nebezpečí.
11. Pro potřebná povolení a příslušné směrnice se obraťte na místní stavební a bezpečnostní odbor.
PPOOZZOORR:: VVYYSSOOKKÉÉ NNAAPPĚĚTTÍÍ
NNeeddoottýýkkeejjttee ssee,, aabbyyssttee ssnníížžiillii nneebbeezzppeeččíí úúrraazzuu eelleekkttrriicckkýýmm pprroouuddeemm..
LEES DEZE HANDLEIDING ZORGVULDIG ALVORENS DE MODULES TE GEBRUIKEN
BELANGRIJKE VEILIGHEIDSVOORSCHRIFTEN
Deze handleiding bevat belangrijke veiligheidsvoorschriften voor de FV module die moeten worden gevolgd tijdens het onderhoud van de FV modules.
Om het risico op een elektrische schok te beperken, mag u geen onderhoud uitvoeren tenzij u daartoe bevoegd bent.
1. De installatie moet worden uitgevoerd door een erkende installateur/onderhoudstechnicus om de integriteit en de veiligheid van het systeem te
waarborgen.
2. De installatie is alleen toegestaan nadat de ALGEMENE INSTALLATIE ANDLEIDING en de INSTALLATIE ANDLEIDING -FOTOVOLTAÏSC E
MODULE- is gelezen en begrepen. Indien u niet over een eigen exemplaar beschikt, neem dan contact op met uw installateur of plaatselijke
Sharp-kantoor. De lijst van kantoren vindt u op de Sharp Solar website : URL: http://www.sharp-world.com/solar
3. Trek niet aan de FV kabels.
4. Raak geen oppervlakken van de module aan.
5. Plaats geen voorwerpen of laat geen voorwerpen vallen op de FV modules.
6. Probeer de FV module niet zelf te demonteren of te repareren.
7. Laat de FV module niet vallen.
8. Let op dat u de kabels niet beschadigt, eraan trekt, buigt of er zware voorwerpen op plaatst.
9. Vraag na het voltooien van onderhoud of reparaties aan de installateur/onderhoudstechnicus om routinecontroles uit te voeren om te bepalen
of de FV modules veilig zijn en goed functioneren.
10. Wanneer vervangingsonderdelen nodig zijn, zorg er dan voor dat de installateur/onderhoudstechnicus door de fabrikant voorgeschreven on-
derdelen gebruikt met dezelfde eigenschappen als de originele onderdelen. Niet-goedgekeurde vervangingen kunnen brand, een elektrisch
schok of andere gevaren veroorzaken.
11. Raadpleeg uw plaatselijke bouw- en veiligheidsdienst voor de vereiste vergunningen en de geldende voorschriften.
OOPPGGEELLEETT:: OOOOGGSSPPAANNNNIINNGG
NNiieett aaaannrraakkeenn,, ggeevvaaaarr vvoooorr eeeenn eelleekkttrriisscchhee sscchhookk..
LÆS VENLIGST BRUGSVEJLEDNINGEN GRUNDIGT, INDEN MODULERNE BRUGES
VIGTIGE SIKKERHEDSINSTRUKTIONER
Denne manual indeholder vigtige sikkerhedsinstruktioner for PV modulet, der skal følges under vedligeholdelse af PV moduler.
For at reducere risikoen for elektrisk stød må du ikke udføre nogen form for service, medmindre du har kvalifikationerne til det.
1. Installationen skal foretages af en autoriseret elektriker for at sikre systemets integritet og sikkerhed.
2. Installationen er kun tilladt efter at have læst og forstået DEN GENERELLE INSTALLATIONSMANUAL og INSTALLATIONSMANUALEN
-P OTOVOLTAISK MODUL-. vis du ikke har din personlige kopi, bedes du kontakte din installatør eller det lokale Sharp kontor, der
er oplistet på Sharp Solar hjemmesiden : URL : http://www.sharp-world.com/solar
3. Træk ikke PV kablerne.
4. Undlad at berøre modulets overflade.
5. Undlad at sætte/lægge genstande på PV modulerne.
6. Undlad at demontere eller forsøge at reparere PV modulet selv.
7. Undlad at tabe PV modulet.
8. Undlad at ødelægge, trække eller bøje kablerne eller placere tunge genstande på dem.
9. Efter udførelse af service eller reparation skal du bede installatøren/elektrikeren foretage rutinekontrol for at se, om PV modulerne er i
sikker og korrekt funktionsbetingelse.
10. Når der er brug for udskiftningsdele skal du sørge for, at elektrikeren/installatøren anvender de dele, der er specificeret af producenten,
med samme karakteristika som de originale dele. Uautoriserede reservedele kan resultere i brand, elektrisk stød eller andre farer.
11. Konsulter den lokale bygge- og sikkerhedsafdeling for de krævede godkendelser og gældende regulativer.
FFOORRSSIIGGTTIIGG:: ØØJJSSPPÆÆNNDDIINNGG
UUnnddllaadd bbeerrøørriinngg ffoorr aatt rreedduucceerree rriissiikkooeenn ffoorr eelleekkttrriisskk ssttøødd..

JEKK JOGĦĠBOK AQRA DAN IL-MANWAL B’ATTENZJONI QABEL TUŻA L-MODULI
STRUZZJONIJIET IM ORTANTI FUQ IS-SIGURTÀ
Dan il-manwal fih struzzjonijiet importanti fuq is-sigurtà għall-modulu PV li għandhom jiġu segwiti matul il-manutenzjoni tal-moduli PV.
Sabiex jitnaqqas ir-riskju ta’ xokk elettriku, ma għandekx tagħmel xogħol ta’ manutenzjoni sakemm ma tkunx ikkwalifikat biex tagħmel dan.
1. L-installazzjoni għandha ssir minn installatur/persuna li tagħmel xogħol ta’ manutenzjoni ċċertifikata sabiex tiġi żgurata l-integrità u s-
sigurtà tas-sistema.
2. L-installazzjoni hija permessa biss wara referenza għal u fehim tal-MANWAL ĠENERALI TA’ L-INSTALLAZZJONI u l-MANWAL TA’ L-
INSTALLAZZJONI -MODULU FOTOVOLTAJKU-. Jekk ma għandekx il-kopja personali tiegħek, jekk jogħġbok ikkuntattja lill-installatur
tiegħek jew lill-uffiċċju lokali ta’ Sharp tiegħek elenkat fil-website ta’ Sharp Solar : URL : http://www.sharp-world.com/solar
3. Tiġbidx il-kejbils tal-PV.
4. Tmiss ebda wiċċ tal-modulu.
5. Tpoġġix/twaqqax oġġetti fuq il-moduli PV.
6. Tgħaqqadx jew tipprovax issewwi l-modulu PV inti stess.
7. Twaqqax il-modulu PV.
8. Tagħmilx ħsara, tiġbidx, tilwix jew tpoġġix materjali tqal fuq il-kejbils.
9. Malli jitlesta xi xogħol ta’ servis jew tiswija, itlob lill-installatur/persuna li tagħmel xogħol ta’ manutenzjoni biex tagħmel kontrolli ta’ rutina
sabiex jiġi stabbilit jekk il-moduli PV humiex sikuri u humiex qegħdin jaħdmu tajjeb.
10. Meta jkunu meħtieġa partijiet ta’ sostituzzjoni, kun żgur li l-installatur/persuna li tagħmel xogħol ta’ manutenzjoni tuża partijiet speċifikati mill-
fabbrikant bl-istess karatteristiċi tal-partijiet oriġinali. Partijiet li m’humiex oriġinali jistgħu jagħtu lok għal nar, xokk elettriku, jew xi periklu ieħor.
11. Ikkonsulta mad-dipartiment tal-bini u tas-sigurtà lokali tiegħek għall-permessi meħtieġa u regolamenti applikabbli.
AATTTTEENNZZJJOONNII:: VVUULLTTAAĠĠĠĠ GGĦĦOOLLII
BBiieexx ttnnaaqqqqaass iirr--rriisskkjjuu ttaa’’ xxookkkk eelleettttrriikkuu,, ttmmiissssxx..
LUE TÄMÄ KÄYTTÖOHJE HUOLELLISESTI ENNEN ANEELIEN KÄYTTÖÄ
TÄRKEITÄ TURVALLISUUSOHJEITA
Tässä ohjeessa on tärkeitä aurinkosähköpaneelia koskevia turvallisuusohjeita, joita pitää noudattaa paneelien huollon aikana.
Sähköiskun vaaran välttämiseksi älä tee mitään huoltotoimenpiteitä, ellei sinulla ole valtuuksia siihen.
1. Tuotteen saa asentaa vain valtuutettu asentaja/huoltohenkilö, jotta järjestelmän toimivuus ja turvallisuus voidaan varmistaa.
2. Laitetta saa käyttää vasta sitten, kun laitetta käyttävä henkilö on lukenut ja ymmärtänyt dokumentit YLEINEN ASENNUSO JE sekä
ASENNUSO JE -AURINKOSÄ KÖPANEELI-. Jos sinulla ei ole kyseisiä ohjeita, ota yhteyttä laitteen asentajaan tai paikalliseen Sharp-
toimistoon, jonka löydät Sharp Solar -verkkosivuilta : URL : http://www.sharp-world.com/solar
3. Älä vedä aurinkosähköpaneelin johdoista.
4. Älä kosketa mihinkään paneelin pintaan.
5. Älä aseta/pudota esineitä paneelien päälle.
6. Älä pura tai yritä korjata paneelia itse.
7. Älä pudota paneelia.
8. Älä vahingoita, vedä tai taivuta johtoja tai pane niiden päälle painavia esineitä.
9. Kun laitetta on huollettu tai korjattu, pyydä asentajaa/huoltohenkilöä suorittamaan rutiinitarkastukset, joiden avulla voidaan määrittää,
ovatko aurinkosähköpaneelit turvallisessa ja toimivassa käyttökunnossa.
10. Jos tarvitset varaosia, varmista, että asentaja/huoltohenkilö käyttää valmistajan määrittämiä osia, jotka vastaavat alkuperäisosia.
Vääränlaisten osien käyttö voi aiheuttaa tulipalon, sähköiskun tai muita vaaroja.
11. Tiedustele paikallisesta rakennusvirastosta, tarvitaanko laitteen käyttöä varten käyttölupia tai liittyykö laitteen käyttöön joitakin määräyksiä.
VVAARROOIITTUUSS:: KKOORRKKEEAAJJÄÄNNNNIITTEE
VVäällttää ssäähhkkööiisskkuujjaa,, äällää kkoosskkee..
VEUILLER LIRE CE MANUEL AVEC ATTENTION AVANT L’UTILISATION DES MODULES
INSTRUCTIONS IM ORTANTES DE SECURITE
Ce manuel contient d’importantes instructions de sécurité concernant le module et qui doivent être respectées lors de l’entretien des mod-
ules photovoltaïques.
Afin de réduire les risques de chocs électriques, veuillez n’effectuer aucune intervention à moins d’être qualifié pour le faire.
1. L’installation doit être réalisée par un manutentionnaire ou une assistance certifié(e) qui puisse assurer l’intégrité et la sécurité du système.
2. L’installation est seulement autorisée après la bonne compréhension et application du MANUEL D’INSTALLATION GÉNÉRAL et du
MANUEL D’INSTALLATION -MODULES P OTOVOLTAIQUES-. Si vous ne possédez pas de copie personnelle, veuillez contacter
votre manutentionnaire ou assistance au bureau Sharp local recensé sur le site Web Sharp : URL : http://www.sharp-world.com/solar
3. Ne pas tirer les câbles photovoltaïques.
4. Ne toucher aucune surface du module.
5. Ne pas placer ni jeter d’objets sur les modules photovoltaïques.
6. Ne pas démonter ou tenter de réparer des modules photovoltaïques par vous-même.
7. Ne pas jeter de module photovoltaïque.
8. Ne pas endommager, tirer, plier ou placer de matériels lourds sur les câbles.
9. Suite à la réalisation de n’importe quelle intervention ou réparation, demander au manutentionnaire ou à l’assistance d’effectuer des
contrôles de routine afin de s’assurer que les modules photovoltaïques sont sûrs et en parfait état de fonctionnement.
10. Lorsqu’il est nécessaire de remplacer des pièces, assurez-vous que le manutentionnaire ou l’assistance utilise bien des pièces spéci-
fiques venant de la manufacture avec les mêmes caractéristiques que les pièces originales. Utiliser des pièces de remplacements in-
terdites risquerait de causer un incendie, un choc électrique ou tout autre danger.
11. Consultez votre établissement local et département de sécurité pour obtenir les permis requis et autres régulations nécessaires.
AATTTTEENNTTIIOONN :: AAUUTT VVOOLLTTAAGGEE
NNee ppaass ttoouucchheerr aafifinn ddee rréédduuiirree lleess rriissqquueess ddee cchhoocc éélleeccttrriiqquuee..

LESEN SIE VOR VERWENDUNG DIESES MODULS DIE ANLEITUNG BITTE AUFMERKSAM DURCH
WICHTIGE SICHERHEITSHINWEISE
Diese Anleitung enthält wichtige Sicherheitshinweise für das PV-Modul, die während der Wartung der PV-Module beachtet werden müssen.
Nehmen Sie keine Servicearbeiten vor, wenn Sie keine ausreichenden Kenntnisse dafür haben; andernfalls besteht die Gefahr eines elektrischen Schlages.
1. Die Installation muss von einem zertifizierten Installateur/Servicemitarbeiter vorgenommen werden, um zu gewährleisten, dass das System
intakt und sicher ist.
2. Vor der Installation müssen die ALLGEMEINE INSTALLATIONSANLEITUNG und die INSTALLATIONSANLEITUNG – P OTOVOLTAIK-
MODULE gelesen werden; achten Sie darauf, dass Sie alle Informationen verstanden haben. Sollten sie keine Ausgabe dieser Anleitungen
haben, wenden Sie sich an Ihren ändler oder einen Sharp- ändler in Ihrer Nähe; auf der Sharp-Solar-Website mit der URL:
http://www.sharp-world.com/solar finden Sie ein Verzeichnis mit Sharp- ändlern.
3. Ziehen Sie nicht an den PV-Kabeln.
4. Berühren Sie die Oberfläche der Module nicht.
5. Stellen Sie keine Objekte auf die PV-Module.
6. Bauen Sie das PV-Modul nicht auseinander. Versuchen Sie auch nicht, es selbst zu reparieren.
7. Lassen Sie das PV-Modul nicht fallen.
8. Beschädigen Sie das Kabel nicht; ziehen Sie nicht daran und verbiegen Sie es nicht. Stellen Sie auch keine schweren Gegenstände darauf.
9. Fragen Sie nach Beendigung jeglicher Service- oder Reparaturarbeiten Ihren Installateur/Servicemitarbeiter, Routineüberprüfungen
durchzuführen, um sicherzustellen, dass sich die PV-Module in einem sicheren und ordnungsgemäßen Zustand befinden.
10. Wenn Sie Ersatzteile benötigen, achten Sie darauf, dass der Installateur/ Servicemitarbeiter Teile verwendet, die vom ersteller mit densel-
ben Eigenschaften versehen wurden, wie die Originalteile. Nicht autorisierte Ersatzteile können Feuer, einen elektrischen Schlag oder weit-
ere Gefahren verursachen.
11. Wenden Sie sich an Ihre lokale Baubehörde, um zu erfahren, welche erforderlichen Genehmigungen und Vorschriften einzuhalten sind.
V
VO OR RS SI IC C T T: : O OC C S SP PA AN NN NU UN NG G
NNiicchhtt bbeerrüühhrreenn!! AAnnddeerrnnffaallllss kköönnnnttee eess zzuu eeiinneemm eelleekkttrriisscchheenn SScchhllaagg kkoommmmeenn!!
VENNLIGST LES DENNE HÅNDBOKEN NØYE FØR DU BRUKER MODULENE
VIKTIGE SIKKERHETSINSTRUKSER
Denne håndboken inneholder viktige sikkerhetsinstrukser for PV-modulen som må følges under vedlikeholdet av PV-modulene.
For å redusere faren for elektrisk støt, må du ikke utføre noen service med mindre du er kvalifisert til dette.
1. Installasjonen må utføres av en sertifisert installatør/servicetekniker, for å sikre systemintegritet og sikkerhet.
2. Installasjonen må bare utføres etter at man har lest og forstått den GENERELLE INSTALLASJONS ÅNDBOKEN og INSTALLASJON-
S ÅNDBOK –FOTOELEKTRISK MODUL. vis du ikke har noen egen kopi, ta kontakt med installatøren eller din lokale Sharp-forhan-
dler som du finner på Sharp Solar nettsted med adresse: http://www.sharp-world.com/solar
3. Ikke trekk i PV-kablene.
4. Ikke berør noen av overflatene på modulen.
5. Ikke plasser/mist noen gjenstander på PV-modulene.
6. Ikke demonter eller forsøk å reparere PV-modulen på egenhånd.
7. Ikke mist PV-modulen.
8. Ikke skad, trekk, bøy eller plasser tunge gjenstander på kablene.
9. Ved fullføring av eventuell service eller reparasjon, be installatøren/serviceteknikeren om å utføre rutinekontroller for å fastslå om PV-
modulene er i sikker og trygg driftstilstand.
10. Når det er behov for erstatningsdeler, pass på at installatøren/serviceteknikeren bruker deler som er spesifisert av produsenten, med
samme karakteristika som originaldeler. Uautoriserte erstatninger kan forårsake brann, elektrisk støt eller annen fare.
11. Ta kontakt med det lokale bygningsrådet for nødvendige tillatelser og egnede forskrifter.
AADDVVAARRSSEELL:: ØØYYSSPPEENNNNIINNGG
FFoorr åå rreedduusseerree ffaarreenn ffoorr eelleekkttrriisskk ssttøøtt,, iikkkkee rrøørr..
LEIA CUIDADOSAMENTE ESTE MANUAL ANTES DE USAR OS MÓDULOS
INSTRUÇÕES DE SEGURANÇA IM ORTANTES
Este manual contém importantes instruções de segurança para o módulo FV que deverão ser respeitadas durante a manutenção dos módulos FV.
Para reduzir o risco de choque eléctrico, não execute nenhum serviço a não ser que esteja qualificado para tal.
1. A instalação deve ser executada por um instalador/técnico certificado para assegurar a integridade e a segurança do sistema.
2. A instalação só é permitida após consulta e compreensão do MANUAL DE INSTALAÇÃO GERAL e MANUAL DE INSTALAÇÃO -MÓDULO
FOTOVOLTAICO-. Se não possuir a sua cópia, contacte o seu instalador ou os serviços Sharp locais listados no site Sharp Solar : URL :
http://www.sharp-world.com/solar
3. Não puxe os cabos FV.
4. Não toque em nenhuma superfície do módulo.
5. Não coloque/deixe cair objectos sobre os módulos FV.
6. Não desmonte nem tente reparar por si próprio o módulo FV.
7. Não deixe cair o módulo FV.
8. Não danifique, puxe, dobre nem coloque material pesado sobre os cabos.
9. Ao completar qualquer serviço ou reparação, peça ao instalador/técnico que execute verificações de rotina para determinar se os módulos
FV estão em condições de operação correcta e segura.
10. Quando forem necessárias peças de substituição, assegure-se de que o instalador/técnico utiliza as peças especificadas pelo fabricante com
as mesmas características das peças originais. Substituições não autorizadas poderão resultar em fogo, choque eléctrico ou outros perigos.
11. Consulte os organismos de construção e segurança locais para obter as autorizações necessárias e regulamentos aplicáveis.
AATTEENNÇÇÃÃOO:: AALLTTAA TTEENNSSÃÃOO
PPaarraa rreedduuzziirr oo rriissccoo ddee cchhooqquuee eellééccttrriiccoo,, nnããoo ttooqquuee..

LEA ESTE MANUAL CUIDADOSAMENTE ANTES DE USAR LOS MÓDULOS
INSTRUCCIONES IM ORTANTES DE SEGURIDAD
Este manual contiene instrucciones importantes de seguridad para el modulo FV que deben seguirse durante el mantenimiento de los módulos.
Para reducir el riesgo de descargas eléctricas, no realice ningún servicio a menos de que esté cualificado para hacerlo.
1. La instalación debe realizarla un instalador/técnico certificado para asegurar la integridad del sistema y la seguridad.
2. Se permite la instalación después de haber consultado y entendido el MANUAL GENERAL DE INSTALACIÓN y el MANUAL DE INSTA-
LACIÓN -MÓDULO FOTOVOLTAICO-. Si no cuenta con su copia personal, contacte a su instalador u oficina local Sharp listada en el sitio
web de Sharp Solar : URL : http://www.sharp-world.com/solar
3. No tire de los cables FV.
4. No toque ninguna superficie del módulo.
5. No coloque/arroje objetos sobre los módulos FV.
6. No desarme o intente reparar el módulo FV usted mismo.
7. No arroje el módulo FV.
8. No dañe, jale, tuerza, o coloque materiales pesados sobre los cables.
9. Una vez terminado el servicio de mantenimiento o la reparación, pida al instalador/técnico que realice chequeos rutinarios para determinar que
los módulos FV están en condiciones seguras y adecuadas para operar.
10. Cuando se requieran piezas de reemplazo, asegúrese de que el instalador/técnico utilice piezas especificadas por el fabricante con las mismas car-
acterísticas que las piezas originales. Los reemplazos no autorizados podrían resultar en incendios, descargas eléctricas u otros riesgos peligrosos.
11. Consulte con las oficinas y departamentos de seguridad de su localidad para los permisos requeridos y regulaciones aplicables.
PPRREECCAAUUCCIIÓÓNN:: AALLTTOO VVOOLLTTAAJJEE
PPaarraa rreedduucciirr eell rriieessggoo ddee ddeessccaarrggaass eellééccttrriiccaass nnoo ttooqquuee..
LÉIGH AN LEABHRÁN SEO GO CÚRAMACH LE DO THOIL ROIMH NA MODÚIL SEO A ÚSÁID
TREORACHA SÁBHÁILTEACHTA TÁBHACHTACHA
Soláthraítear treoracha sábháilteachta tábhachtacha sa lámhleabhar seo don mhodúl fótavoltach. Caithfear na treoracha seo a leanúint
nuair a dhéantar obair cothabhála ar na modúil.
Chun an riosca turrainge leictreach a laghdú, ná déan iarracht aon obair cothabhála a dhéanamh gan cáilíochtaí a bheith agat.
1. Caithfear teicneoir suiteála/duine cothabhála deimhnithe a úsáid chun na modúil a shuiteáil chun deimhin a dhéanamh de go gcomh-
líonfar sláine agus sábháilteacht an chórais.
2. Ní ceart na modúil a shuiteáil ach amháin nuair a bheidh an LÁM LEAB AR SUITEÁLA GINEARÁLTA agus an LÁM LEAB AR SUIT-
EÁLA -MODÚL FÓTAVOLTAC - léite agus tuigthe agat. Muna mbíonn do chóip phearsanta féin agat, déan teagmháil le do theicneoir
suiteála nó le h-oifig áitiúil Sharp liostaithe ar an láithreán gréasáin Sharp Solar : Suíomh Gréasáin : http://www.sharp-world.com/solar
3. Ná tarraing na cáblaí fótavoltacha.
4. Ná leag lámh ar aon chuid de dhromchla an mhodúil.
5. Ná cuir/ná lig do rudaí titim ar na modúil fótavoltacha.
6. Ná díchóimeál nó ná déan iarracht an modúl fótavoltach a dheisiú tú féin.
7. Ná lig don mhodúl fótavoltach titim.
8. Ná scrios, ná tarraing, ná lúb, nó ná leag ábhar trom ar na cáblaí.
9. Agus seirbhís éigin nó deisiúcháin déanta, iarr ar an innealtóir suiteála/duine cothabhála gnáthscrúdaithe a dhéanamh chun a chinntiú
go bhfuil na modúil fótavoltacha ag feidhmiú i gceart agus go sábháilte.
10. Nuair a bhíonn páirteanna nua ag teastáil, déan deimhin de go n-úsáideann an teicneoir suiteála/duine cothabhála páirteanna son-
raithe ag an déantóir leis na sonraí céanna is a bhí ag na páirteanna bunúsacha. Muna n-úsáidtear na páirteanna cearta tá baol ann go
dtarlódh tine, turrainge leictreach nó guais eile.
11. Téigh i gcomhairle le do roinn tógála sábhála áitiúil chun teacht ar na ceadúnais riachtanacha agus ar na rialacháin iomchuí.
A
AI IR RE E: : A AR RD DV VO OL LT TA AS S
CChhuunn aann rriioossccaa ttuurrrraaiinnggee lleeiiccttrreeaacchh aa llaagghhddúú,, nnáá lleeaagg lláámmhh aarr sseeoo..
RED OUŽITÍM MODULOV SI OZORNE REČÍTAJTE TÚTO RÍRUČKU
DÔLEŽITÉ BEZ EČNOSTNÉ OKYNY
Táto príručka obsahuje dôležité bezpečnostné pokyny pre PV modul, ktoré sa musia dodržiavať pri jeho údržbe.
Aby ste znížili riziko úrazu elektrickým šokom, nevykonávajte žiadne servisné práce, iba v prípade, že ste na to kvalifikovaný.
1. Inštaláciu musí vykonať kvalifikovaný inštalatér alebo servisný pracovník, aby sa zaistila integrita a bezpečnosť systému.
2. Inštalácia je povolená len po prečítaní a porozumení obsahu PRÍRUČKY VŠEOBECNEJ INŠTALÁCIE a INŠTALAČNEJ PRÍRUČKY FOTO-
VOLTAICKÉ O MODULU. Ak nemáte svoju vlastnú kópiu, kontaktujte inštalatéra alebo miestne zastúpenie spoločnosti Sharp, ktorej adresa je
uvedená na webovej stránke Sharp Solar: URL: http://www.sharp-world.com/solar
3. Nevyťahujte káble PV modulu.
4. Nedotýkajte sa žiadneho povrchu modulu.
5. Neukladajte na PV moduly predmety, ani nedovoľte, aby na ne spadli predmety.
6. Nepokúšajte sa rozmontovať alebo sami opraviť PV modul.
7. Nenechajte PV modul spadnúť.
8. Nepoškoďte, neťahajte, neohýbajte alebo neukladajte ťažké predmety na káble.
9. Po dokončení akejkoľvek opravy požiadajte inštalatéra alebo servisného technika o prevedenie bežnej kontroly na potvrdenie toho, že PV
moduly sú v bezpečnom a správnom prevádzkovom stave.
10. Ak sú potrebné náhradné diely, uistite sa, že inštalatér alebo servisný technik používa náhradné diely špecifikované výrobcom, ktoré majú rov-
naké vlastnosti ako pôvodné súčiastky. Nesprávne náhradné diely môžu spôsobiť požiar, úraz elektrickým prúdom alebo iné nebezpečenstvo.
11. Poraďte sa s miestnym stavebným a bezpečnostným úradom ohľadom požadovaných povolení a príslušných nariadeniach.
PPOOZZOORR:: VVYYSSOOKKÉÉ NNAAPPÄÄTTIIEE
NNeeddoottýýkkaajjttee ssaa,, aabbyy ssttee pprreeddiiššllii úúrraazzuu eelleekkttrriicckkýýmm ššookkoomm..

ROSIMO, DA RED U ORABO MODULOV OZORNO REBERETE TA RIROČNIK
OMEMBNA VARNOSTNA NAVODILA
Ta priročnik vsebuje pomembna varnostna navodila za PV modul, katerim je med vzdrževanjem PV modulov potrebno slediti.
Za zmanjšanje nevarnosti električnega udara ne izvajajte nobenega servisnega posega, edino, v primeru, da ste zanj ustrezno usposobljeni.
1. Namestitev mora izvesti pooblaščeni inštalater/serviser, saj sta le tako zagotovljeni integriteta in varnost sistema.
2. Namestitev je dovoljena le, ko popolnoma preučite in razumete SPLOŠNA NAVODILA ZA NAMESTITEV in PRIROČNIK ZA NA-
MESTITEV –FOTOVOLTAIČNI MODUL-. Če še nimate svojega lastnega izvoda, se prosimo obrnite na vašega inštalaterja ali obiščite
lokalno pisarno Sharp, navedeno na spletni strani Sharp Solar: URL : http://www.sharp-world.com/solar
3. Ne vlecite PV kablov.
4. Ne dotikajte se površine modula.
5. Ne postavljajte/odlagajte predmetov na PV module.
6. Sami ne razstavljajte niti se ne lotevajte popravila PV modula.
7. PV modula ne odlagajte naglo.
8. Ne poškodujte, vlecite, zvijajte niti ne polagajte težkih predmetov na kable.
9. Zaradi popolnega servisiranja ali popravila, inštalaterja/serviserja prosite za opravljanje rutinskih pregledov, preko katerih boste imeli
stalen nadzor nad varnim in brezhibnim delovanjem PV modulov.
10. Kadar je potrebno zamenjati določene dele, poskrbite, da bo inštalater/serviser uporabil zgolj predpisane dele z enakimi lastnostmi,
kot jih imajo originalni. Neodobreni nadomestni deli lahko povzročijo požar, električni udar ali drugo tveganje.
11. Za zahtevana dovoljenja in ustrezne uredbe se obrnite na lokalni urad za varnost.
SSVVAARRIILLOO:: VVIISSOOKKAA NNAAPPEETTOOSSTT
NNeevvaarrnnoosstt eelleekkttrriiččllnneeggaa uuddaarraa.. NNaapprraavvee ssee nnee ddoottiikkaajjttee..
SI REGA DI LEGGERE ATTENTAMENTE IL RESENTE MANUALE RIMA DI UTILIZZARE I MODULI
IIM ORTANTI ISTRUZIONI DI SICUREZZA
Il presente manuale contiene importanti istruzioni di sicurezza per i moduli fotovoltaici, che devono essere seguite attentamente quando si utilizzano questi
moduli.
Al fine di ridurre il rischio di scosse elettriche, non eseguire alcuna operazione di manutenzione o riparazione, a meno che non si possiedano le compe-
tenze necessarie.
1. L’installazione deve essere eseguita da un addetto all’installazione/manutenzione qualificato, per garantire l’integrità e la sicurezza del sistema.
2. È possibile eseguire l’installazione solo dopo aver letto e compreso il MANUALE GENERALE D’INSTALLAZIONE e il MANUALE D’INSTALLAZIONE
-MODULO FOTOVOLTAICO-. In caso l’utente non sia in possesso di una copia dei suddetti manuali, si prega di rivolgersi al proprio addetto all’in-
stallazione o al punto vendita Sharp più vicino, indicato al sito Internet Sharp Solar: URL : http://www.sharp-world.com/solar
3. Non tirare i cavi del modulo fotovoltaico.
4. Non toccare alcuna superficie del modulo.
5. Non posizionare/lasciar cadere oggetti sul modulo fotovoltaico.
6. Non smontare né tentare di riparare il modulo fotovoltaico senza l’assistenza di un tecnico qualificato.
7. Non lasciar cadere il modulo fotovoltaico.
8. Non danneggiare, tirare, piegare né posizionare materiali pesanti sui cavi.
9. Al termine delle operazioni di manutenzione o riparazione, chiedere all’addetto all’installazione/manutenzione di eseguire i controlli di routine per sta-
bilire che i moduli fotovoltaici siano in perfette condizioni di funzionamento.
10. In caso di necessità di pezzi di ricambio, assicurarsi che l’addetto all’installazione/manutenzione utilizzi i pezzi di ricambio indicati dal fabbricante, con
le stesse caratteristiche dei pezzi originali. Sostituzioni non autorizzate potrebbero provocare incendi, scosse elettriche o altre situazioni pericolose.
11. Rivolgersi all’ufficio locale responsabile per la sicurezza e l’edilizia per quanto riguarda i permessi necessari e le relative disposizioni.
AATTTTEENNZZIIOONNEE:: AALLTTAA TTEENNSSIIOONNEE
AAll fifinnee ddii rriidduurrrree iill rriisscchhiioo ddii ssccoossssee eelleettttrriicchhee,, nnoonn ttooccccaarree..
ROSZĘ UWAŻNIE RZECZYTAĆ TĄ INSTRUKCJĘ RZED ROZ OCZĘCIEM KORZYSTANIA
Z MODUŁÓW
WAŻNE INSTRUKCJE DOTYCZĄCE BEZ IECZEŃSTWA
Niniejsza instrukcja zawiera ważne instrukcje dotyczące bezpieczeństwa modułu fotowoltaicznego, których należy przestrzegać podczas
konserwacji i użytkowania modułów.
Aby zmniejszyć ryzyko porażenia prądem, nie przeprowadzaj napraw ani serwisowania, jeśli nie masz do tego odpowiednich kwalifikacji.
1. Instalacji musi dokonać certyfikowany monter/pracownik serwisu, aby zagwarantować bezpieczeństwo i poprawną instalację systemu.
2. Instalację można rozpocząć dopiero po uważnym przeczytaniu OGÓLNEJ INSTRUKCJI INSTALACJI oraz INSTRUKCJI UŻYTKOWN-
IKA –MODUŁ FOTOWOLTAICZNY-. Jeśli nie masz własnej kopii, skontaktuj się z monterem lub lokalnym przedstawicielem Sharp po-
danym na stronie internetowej : http://www.sharp-world.com/solar
3. Nie ciągnij za kable modułu fotowoltaicznego.
4. Nie dotykaj żadnych powierzchni modułu.
5. Nie stawiaj, ani nie upuszczaj żadnych przedmiotów na moduły.
6. Nie demontuj ani nie próbuj samodzielnie naprawiać modułu fotowoltaicznego.
7. Uważaj, aby nie upuścić modułu.
8. Nie uszkodź, nie zginaj, nie ciągnij kabli, ani nie stawiaj na nich ciężkich przedmiotów.
9. Po zakończeniu serwisowania lub naprawy, poproś montera/serwisanta o przeprowadzenie rutynowych kontroli, aby sprawdzić czy
moduły fotowoltaiczne są w dobrym stanie używalności.
10. Jeśli potrzebne są części zamienne, dopilnuj by monter/serwisant stosował części podane przez producenta o tej samej charak-
terystyce, co części oryginalne. Nieuprawnione wymiany mogą prowadzić do pożaru, porażenia prądem lub innych zagrożeń.
11. Skonsultuj się z lokalnym urzędem zajmującym się budownictwem i bezpieczeństwem instalacji, aby uzyskać wymagane zezwolenia i
odpowiednie przepisy.
UUWWAAGGAA:: WWYYSSOOKKIIEE NNAAPPIIĘĘCCIIEE
NNiiee ddoottyykkaajj,, aabbyy uunniikknnąąćć rryyzzyykkaa ppoorraażżeenniiaa pprrąąddeemm..

TINSJ0405UNZZ
¶∞ƒ∞∫∞§√Yª∂ ¢π∞µ∞™∆∂ ¶ƒ√™∂∫∆π∫∞ ∞Y∆√ ∆√ ∂°X∂πƒπ¢π√ ¶ƒ√∆√Y
Xƒ∏™πª√¶√π∏™∂∆∂ ∆π™ ª√¡∞¢∂™
™∏ª∞¡∆π∫∂™ √¢∏°π∂™ ∞™º∞§∂π∞™
∞˘Ùfi ÙÔ ÂÁ¯ÂÈÚ›‰ÈÔ ÂÚȤ¯ÂÈ ÛËÌ·ÓÙÈΤ˜ ÁÈ· ÙË ÊˆÙÔ‚ÔÏÙ·˚΋ ÌÔÓ¿‰·, ÔÈ Ôԛ˜ Ú¤ÂÈ Ó· ÙËÚÔ‡ÓÙ·È Î·Ù¿ ÙË ‰È¿ÚÎÂÈ· Ù˘ Û˘ÓÙ‹ÚËÛ˘ ÙˆÓ ÌÔÓ¿‰ˆÓ.
°È· Ó· ·ÔÊ¢¯ı› Ô Î›Ó‰˘ÓÔ˜ ËÏÂÎÙÚÔÏËÍ›·˜, ÌËÓ Ú·ÁÌ·ÙÔÔÈ‹ÛÂÙ ηÓÂÓfi˜ ›‰Ô˘˜ Û˘ÓÙ‹ÚËÔË ·Ó ‰ÂÓ ¤¯ÂÙ ÙËÓ Î·Ù¿ÏÏËÏË ÂÍÂȉ›Î¢ÛË.
1. ∏ ÂÁηٿÛÙ·ÛË ı· Ú¤ÂÈ Ó· Ú·ÁÌ·ÙÔÔÈËı› ·fi ÈÛÙÔÔÈË̤ÓÔ ÂȉÈÎfi ÂÁηٿÛÙ·Û˘/Û˘ÓÙ‹ÚËÛ˘ ÁÈ· ÙË ‰È·ÛÊ¿ÏÈÛË Ù˘
·ÎÂÚ·ÈfiÙËÙ·˜ Î·È ·ÛÊ¿ÏÂÈ·˜ ÙÔÓ ÛÓÛÙ‹Ì·ÙÔ˜.
2. ∏ ÂÁηٿÛÙ·ÛË ÂÈÙÚ¤ÂÙ·È ÌfiÓÔ ·ÊÔ‡ ‰È·‚¿ÛÂÙÂ Î·È Î·Ù·ÓÔ‹ÛÂÙ ÙÔ °∂¡π∫√ ∂°X∂πƒπ¢π√ ∂°∫∞∆∞™∆∞™∏™ Î·È ÙÔ ∂°X∂πƒπ¢π√
∂°∫∞∆∞™∆∞™∏™ -ºø∆√µ√§∆∞´∫∏ ª√¡∞¢∞-. ∞Ó ‰ÂÓ ¤¯ÂÙ ÙÔ ÚÔÛˆÈÎfi Û·˜ ·ÓÙÈÁÚ·ÊÔ, ·Ú·Î·Ïԇ̠ÂÈÎÔÈÓˆÓ‹ÛÙ Ì ÙÔÓ Ù¯ӛÙË
ÂÁηٿÛÙ·ÛË ‹ ÙÔ ÙÔÈÎfi ÁÚ·ÊÂ›Ô Ù˘ Sharp, ·fi ÙÔÓ Î·Ù¿ÏÔÁÔ Ô˘ ·Ó·Ê¤ÚÂÙ·È ÛÙËÓÈ ÔÙÔÛÂÏ›‰· : ¢È‡ı˘ÓÛË URL : http://www. harp-
world.com/ olar
3. ªËÓ ÙÚ·‚¿Ù ٷ ʈÙÔ‚ÔÏÙ·˚ο ηÏ҉ȷ.
4. ªËÓ ·ÁÁ›˙ÂÙ η̛· ÂÈÊ¿ÓÂÈ· Ù˘ ÌÔÓ¿‰·˜.
5. ªËÓ ÙÔÔıÂÙ›ÙÂ/Ú›¯ÓÂÙ ·ÓÙÈΛÌÂÓ· ¿Óˆ ÛÙȘ ʈÙÔ‚ÔÏÙ·˚Τ˜ ÌÔÓ¿‰Â˜.
6. ªËÓ ·ÔÛ˘Ó·ÚÌÔÏÔÁ›Ù ÙË ÊˆÙÔ‚ÔÏÙ·˚΋ ÌÔÓ¿‰· Ô‡Ù ӷ ·ÔÂÈÚ·ı›Ù ӷ ÙËÓ ÂÈÛ΢¿ÛÂÙ ÌfiÓÔ˜ Û·˜.
7. ªËÓ ·Ê‹ÛÂÙ ӷ Û·˜ ¤ÛÂÈ Ë ÊˆÙÔ‚ÔÏÙ·˚΋ ÌÔÓ¿‰·.
8. ªËÓ ÚÔηϛ٠˙ËÌȤ˜ ÛÙ· ηÏ҉ȷ, Ô‡Ù ӷ Ù· ÙÚ·‚¿ÙÂ, Ó· Ù· Ù۷Λ˙ÂÙ ‹ Ó· ÙÔÔıÂÙ›Ù ¿Óˆ ÙÔ˘˜ ‚·ÚÈ¿ ˘ÏÈο.
9. ∫·Ù¿ ÙËÓ ÔÏÔÎÏ‹ÚˆÛË ÔÔȈӉ‹ÔÙ ÂÚÁ·ÛÈÒÓ Û˘ÓÙ‹ÚËÛ˘ ‹ ÂÈÛ΢ÒÓ, ˙ËÙ‹ÛÙ ·fi ÙÔÓ ÂȉÈÎfi ÂÁηٿÛÙ·Û˘/Ô˘ÓÙ‹ÚËÛ˘ Ó·
Ú·ÁÌ·ÙÔÔÈ‹ÛÂÈ ÙÔ˘˜ Û˘Ó‹ıÂȘ ÂϤÁ¯Ô˘˜ ¤ÙÛÈ ÒÛÙ ӷ ‰È·ÈÛÙÒÛÂÈ fiÙÈ ÔÈ ÊˆÙÔ‚ÔÏÙ·˚Τ˜ ÌÔÓ¿‰Â˜ ÏÂÈÙÔ˘ÚÁÔ‡Ó ÛˆÛÙ¿ Î·È Ì ·ÛÊ¿ÏÂÈ·.
10. ŸÙ·Ó ··ÈÙÂ›Ù·È Ë ·ÓÙÈηٿÛÙ·ÛË ÂÍ·ÚÙËÌ¿ÙˆÓ, ‚‚·Èˆı›Ù fiÙÈ Ô ÂȉÈÎfi˜ ÂÁηٿÛÙ·Û˘/Û˘ÓÙ‹ÚËÛ˘ ¯ÚËÛÈÌÔÔÈ› Ù· ÂÍ·ÚÙ‹Ì·Ù· Ô˘
ÔÚ›˙ÔÓÙ·È ·fi ÙÔÓ Î·Ù·Û΢·ÛÙ‹ Ì ¯·Ú·ÎÙËÚÈÛÙÈο ›‰È· Ì ٷ ·˘ıÂÓÙÈο ÂÍ·ÚÙ‹Ì·Ù·. √È ÌË ÂÍÔ˘ÛÈÔ‰ÔÙË̤Ó˜ ·ÓÙÈηٷÛÙ¿ÛÂȘ
ÌÔÚÔ‡Ó Ó· Ô‰ËÁ‹ÛÔ˘Ó Û ˘ÚηÁÈ¿, ËÏÂÎÙÚÔÏËÍ›· Î·È ¿ÏÏÔ˘˜ ÎÈÓ‰‡ÓÔ˘˜.
11. ™˘Ì‚Ô˘Ï¢Ù›Ù ÙÔ ÙÔÈÎfi Û·˜ ÙÌ‹Ì· ÂÁηٷÛÙ¿ÛÂˆÓ Î·È ·ÛÊ¿ÏÂÈ·˜ ÁÈ· ÙȘ ··ÈÙÔ‡ÌÂÓ˜ ¿‰ÂȘ Î·È ÙȘ ÈÛ¯‡Ô˘Û˜ ηÓÔÓÈÛÌÔ‡˜.
¶¶ƒƒ√√™™√√XX∏∏:: YYææ∏∏§§∏∏ ∆∆∞∞™™∏∏
ªªËËÓÓ ··ÁÁÁÁ››˙˙ÂÂÙÙÂÂ,, ÎΛ›ÓÓ‰‰˘˘ÓÓÔÔ˜˜ ËËÏÏÂÂÎÎÙÙÚÚÔÔÏÏËËÍÍ››··˜˜..
LÜTFEN MODÜLLERİ KULLANMADAN ÖNCE BU KULLANIM KILAVUZUNU DİKKATLİ BİR
BİÇİMDE OKUYUNUZ
ÖNEMLİ GÜVENLİK TALİMATLARI
Bu kullanım kılavuzu, PV modülü için PV modüllerinin bakımı esnasında uyulması önemli güvenlik talimatlarını içerir.
Elektrik çarpması riskini azaltmak için, gerekli yetkiye sahip olmadığınız takdirde hiçbir servis işlemini yapmayınız.
1. Sistemin bütünlüğünü ve güvenliğini sağlamak için kurulumun belgeli bir kurulum/servis personeli tarafından gerçekleştirilmesi gerekir.
2. Kuruluma ancak GENEL KURULUM KILAVUZUNA ve KURULUM KILAVUZUNA –FOTOVOLTAJ MODÜLÜNE başvurulup, bunlar an-
laşıldıktan sonra izin verilebilir. Kendi kişisel kopyanız yoksa lütfen kurulum personelinize veya Sharp Solar web sitesinde kayıtlı bulunan
yerel Sharp ofisine başvurunuz : URL : http://www.sharp-world.com/solar
3. PV kablolarını çekmeyiniz.
4. Modülün hiçbir yüzeyine dokunmayınız.
5. PV modüllerine hiçbir nesne yerleştirmeyiniz/düşürmeyiniz.
6. PV modülünü parçalarına ayırmayınız veya kendiniz onarmaya çalışmayınız.
7. PV modülünü düşürmeyiniz.
8. Kablolara zarar vermeyiniz, bunları çekmeyiniz, bükmeyiniz veya üzerlerine ağır malzemeler yerleştirmeyiniz.
9. erhangi bir bakım veya onarım tamamlandıktan sonra, PV modüllerinin güvenli olup olmadığını ve doğru bir şekilde çalışıp çalışmadığını
kontrol etmek için kurulum/servis personelinden rutin kontrolleri yapmasını rica ediniz.
10. Yedek parça gerektiğinde, kurulum/servis personelinin, üretici tarafından belirtilen ve orijinal parçayla aynı özelliklere sahip yedek parçaları
kullandığından emin olunuz. Yetkili olmayan bir değiştirme, yangına, elektrik çarpmasına veya benzeri başka tehlikelere neden olabilir.
11. Gerekli izinler ve geçerli yönetmelikler için yerel bina ve güvenlik departmanınıza başvurunuz.
DDİİKKKKAATT:: YYÜÜKKSSEEKK VVOOLLTTAAJJ
EElleekkttrriikk ççaarrppmmaassıı rriisskkiinnii aazzaallttmmaakk iiççiinn ddookkuunnmmaayyıınnıızz..
VAR VÄNLIG LÄS DENNA BRUKSANVISNING NOGGRANT INNAN DU ANVÄNDER MODULERNA
VIKTIGA SÄKERHETSFÖRESKRIFTER
Denna bruksanvisning innehåller viktiga säkerhetsföreskrifter för PV-modulen som måste efterföljas vid underhåll av PV-moduler.
För att minska risken för elstötar ska du inte genomföra några underhållsåtgärder på egen hand såvida du inte är tvungen.
1. Installationen måste genomföras av en certifierad installatör/tekniker för att garantera systemets integritet och säkerhet.
2. Installationen är endast tillåten efter att ALLMÄN BRUKSANVISNING och BRUKSANVISNING -FOTOELEKTROMOTORISK MODUL-
har lästs och förståtts. Om du inte har din egen kopia, bör du kontakta din installatör eller lokala Sharp-kontor som finns på Sharp
Solar-webbsidan : URL : http://www.sharp-world.com/solar
3. Dra inte i PV-kablarna.
4. Vidrör inte ytan på modulen.
5. Undvik att placera/tappa föremål på PV-modulerna.
6. Plocka inte isär eller försök reparera PV-modulen på egen hand.
7. Tappa inte PV-modulen.
8. Undvika att skada, dra i, böja eller placera tunga föremål på kablarna.
9. Efter underhåll och reparationer, ska du be installatören/teknikern att genomföra en rutinkontroll för att se till att PV-modulerna är i säk-
ert och ordentligt bruksskick.
10. När reservdelar behövs, ska du se till att installatören/teknikern använder delar som anges av tillverkaren med samma egenskaper
som originaldelarna. Icke-auktoriserade reservdelar kan orsaka brand, elstötar eller annan fara.
11. Rådfråga din lokala byggnads- och säkerhetsavdelning för nödvändiga tillstånd och gällande regler.
VVAARRNNIINNGG:: ÖÖGG SSPPÄÄNNNNIINNGG
VViiddrröörr eejj,, fföörr aatttt mmiinnsskkaa rriisskkeenn fföörr eellssttöött..
2
