Sharp LC-37GA5T User manual

LC-37GA5T
SERVICE MANUAL
LCD COLORTELEVISION
MODEL LC-37GA5T
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
CONTENTS Page
»LIST OF CHANGED PARTS ...........................................................................................................................2
»IMPORTANT SERVICE SAFETY PRECAUTION ........................................................................................3
»SPECIFICATIONS........................................................................................................................................5
»OPERATION MANUAL ................................................................................................................................6
»DIMENSIONS ............................................................................................................................................12
»DESCRIPTION OF SCHEMATIC DIAGRAM .............................................................................................13
»SCHEMATIC DIAGRAM.............................................................................................................................14
»PRINTED WIRING BOARD ASSEMBLIES................................................................................................18
»PARTS LIST ...............................................................................................................................................22
»PACKING OF THE SET .............................................................................................................................30
OUTLINE
This model is based on the LC-32DA5U and is changed some parts. This Service Manual covers the
modifications alone. For the other points, refer to the LC-32DA5U Service Manual.
S95N9LC37DB5U
SHARP CORPORATION This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
1st Edition

2
LC-37GA5T
LIST OF CHANGED PARTS
Ref.No. Description LC-32DA5U LC-37GA5T Note
PWB ASSEMBLIES
MAIN Unit DUNTKD375WE02 DUNTKD375WE03 Some parts changed
AV Unit DUNTKD352WE02 DUNTKD352WE20 No parts changed
KEY Unit DUNTKD353WE01 DUNTKD353WE20 No parts changed
R/C, LED Unit DUNTKD354WE01 DUNTKD354WE20 No parts changed
POWER SUPPLY Unit RDENCA139WJQZ RDENCA140WJQZ Parts changed
LCD PANEL
Wide LCD Panel Unit RLCUCA025WJZZ RLCUCA026WJZZ 
MAIN Unit
R2019 Metal Oxide VRS-CY1JF472JY  *Delete
R2020 Metal Oxide  VRS-CY1JF472JY *Add
R2022 Metal Oxide  VRS-CY1JF472JY *Add
R2023 Metal Oxide VRS-CY1JF472JY  *Delete
POWER SUPPLY Unit
Please refer to a Parts list.
CABINET AND MECHANICAL PARTS
Please refer to a Parts list.
PACKING PARTS AND ACCESSORIES
Please refer to a Parts list.

3
LC-37GA5T
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
1
234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121
2
12345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212
SAFETY NOTICE
Many electrical and mechanical parts in LCD color
television have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
components having such features are identified by " å"
and shaded areas in the Replacement Parts List and
Schematic Diagrams .
For continued protection, replacement parts must be
identical to those used in the original circuit.
The use of a substitute replacement parts which do not
have the same safety characteristics as the factory
recommended replacement parts shown in this service
manual, may create shock, fire or other hazards.
CAUTION: FOR CONTINUED PROTECTION
AGAINST A RISK OF FIRE REPLACE ONLY WITH
SAMETYPE FUSE.
WARNING
1. For continued safety, no modification of any circuit
should be attempted.
2. Disconnect AC power before servicing.
BEFORE RETURNINGTHE RECEIVER
(Fire & Shock Hazard)
Before returning the receiver to the user, perform
the following safety checks:
1. Inspect all lead dress to make certain that leads are
not pinched, and check that hardware is not lodged
between the chassis and other metal parts in the
receiver.
2. Inspect all protective devices such as non-metallic
control knobs, insulation materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacitor networks, mechanical
insulators, etc.
3. To be sure that no shock hazard exists, check for
leakage current in the following manner.
»Plug the AC cord directly into a 110 volt AC outlet.
»Using two clip leads, connect a 1.5k ohm, 10 watt
resistor paralleled by a 0.15µF capacitor in series
with all exposed metal cabinet parts and a known
earth ground, such as electrical conduit or electrical
ground connected to an earth ground.
»Use an AC voltmeter having with 5000 ohm per volt,
or higher, sensitivity or measure the AC voltage drop
across the resistor.
»Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon, etc.) and measure the AC voltage drop
across the resistor.
All checks must be repeated with the AC cord plug
connection reversed. (If necessary, a nonpolarized
adaptor plug must be used only for the purpose of
completing these checks.)
Any reading of 0.75 Vrms (this corresponds to 0.5
mA rms AC.) or more is excessive and indicates a
potential shock hazard which must be corrected
before returning the monitor to the owner.
IMPORTANT SERVICE SAFETY PRECAUTION
ËService work should be performed only by qualified service technicians who are thor-
oughly familiar with all safety checks and the servicing guidelines which follow:
DVM
AC SCALE
1.5k ohm
10W
TO EXPOSED
METAL PARTS CONNECT TO KNOWN EARTH
GROUND
0.15 µF
TEST PROBE
F701, F702 (5A, 250V)
F703 (1A, AC250V), F704 (117°C, 2A)

4
LC-37GA5T
Precautions for using lead-free solder
1 Employing lead-free solder
"PWBs" of this model employs lead-free solder.The LF symbol indicates lead-free solder, and is attached on the
PWBs and service manuals.The alphabetical character following LF shows the type of lead-free solder.
Example:
2 Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional
lead wire solder may cause damage or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40°C, we recommend
you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit,
contact our service station or service branch in your area.
3 Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220°C which is higher than the conventional lead
solder by 40°C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the
PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance
temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady soldering
condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded.Make sure to turn on
and off the power of the bit as required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder.Clean the bit after
every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Be careful when replacing parts with polarity indication on the PWB silk.
Indicates lead-free solder of tin, silver and copper.
Lead-free wire solder for servicing
Part No, ★Description Code
ZHNDAi123250E J φ0.3mm 250g(1roll) BL
ZHNDAi126500E J φ0.6mm 500g(1roll) BK
ZHNDAi12801KE J φ1.0mm 1kg(1roll) BM
LFa

5
LC-37GA5T
SPECIFICATIONS
Item 37"LIQUID CRYSTALTELEVISION,
Model: LC-37GA5T
TV
Function
TV Standard NTSC System
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-125ch
Audio multiplex BTSC System
Terminals AV in, COMPONENT in
INPUT 2 AV in, COMPONENT in
INPUT 4 Audio in, HDMI in
ANTENNA 75 Unbalance, F Type for VHF/UHF/CATV in 1
INPUT 3 S-VIDEO in, AV in
OSD language English/French/Spanish
Power Requirement AC 110 V, 60 Hz
Power Consumption
Weight
TV-standard (CCIR)
Receiving
Channel
Rear INPUT 1
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
LCD panel 37" (94 cm) Advanced Super View & BLACK TFT LCD
Number of dots 3,147,264 dots (1366 768 3 dots)
Brightness 450 cd/m
2
Backlight 60,000 hours (at Backlight Standard position)
Viewing angles H : 170
o
V : 170
o
Audio amplifier 10W 2
Speakers 8cm 2pcs
MONITOR OUTPUT S-VIDEO out, AV out
XX.X lbs./XX.X kg (w/o stand),
XX.X lbs./XX.X kg (with stand)
140 W (0.3 W Standby with AC 110 V)
Dimension (W H D) 38
37
/ 64 19
13
/ 32 4
31
/ 64 inch (w/o stand),
38
37
/ 64 22
3
/ 4 11
3
/ 8 inch (with stand)
Operating Temperature 32
o
F to 104
o
F (0
o
C to 40
o
C)
×
×
×
×
××
×
××
×
Ω
+

6
LC-37GA5T
OPERATION MANUAL
Part names
TV (Front) TV (Rear)
POWER indicator
OPC sensor
POWER (On/Off)
button
INPUT
buttonVOLUME buttons (VOL / )
CHANNEL buttons
(CH / )
Remote control sensor
OPC indicator
RESET*
INPUT 3
terminals
SYSTEM
RESET**
Antenna
input
terminal
*Press RESET if the TV cannot return to its original state after performing various operations.
AV MODE resets to DYNAMIC (Fixed)
TV channel returns to initial channel setting (Air: 2ch, Cable:1 or 2ch)
Audio setting initializes
Surround resets to Off
Image position initializes
**Press SYSTEM RESET if the TV does not operate after starting up.
NOTE
Pressing RESET will not work if the TV is in standby mode.
Pressing RESET will not delete channel preset or secret number.
AC INPUT terminal
RS-232C
terminal
INPUT 2
terminals
INPUT 1
terminals
INPUT 4 terminals
MONITOR OUTPUT terminals
*** Angle seen from below.

7
LC-37GA5T
P Using external equipmentart names
Remote control unit
NOTE
When using the remote control unit, point it at the TV.
3
2
114
5
6
4
8
17
15
16
18
19
7
20
10
9
21
11 23
24
25
12
13 27
22
26
1TVPOWER: Switch the TV power on or standby.
2 DISPLAY: Display the channel information.
3 SOURCE POWER: Turns the power of the external
equipment on and off.
4 External equipment operational buttons:Operate the
external equipment.
5 0 9: Set the channel.
6(DOT)
7 INPUT: Select a TV input source. (TV, INPUT 1, INPUT
2, INPUT 3, INPUT 4)
8VOL/: Set the volume.
9 SURROUND:Select Surround settings.
10 FREEZE: Set the still image. Press again to return to
normal screen.
11 EXIT: Turn off the menu screen.
12 SLEEP: Set the sleep timer.
13 AUDIO: Select the MTS/SAP.
12 FUNCTION: Switches the remote control for TV, CBL/
SAT, VCR, DVD and AUDIO operation. Indicator lights
up for the current mode.
15 :When pressed all buttons on the remote control unit
will light. The lighting will turn off if no operations are
performed within about 5 seconds. This button is used
for performing operations in dark places.
16 VIEW MODE: Select the screen size.
17 ENT: Enters a channel selection when choosing with
the 0-9 buttons.
18 FLASHBACK: Return to the previous channel or input
external mode.
19 CH / : Select the channel.
20 MUTE: Mute the sound.
21 MENU: Display the menu screen.
22 ////ENTER:Select a desired item on the screen.
23 RETURN: Return to the previous menu screen.
24 FAVORITE CH
A, B, C, D: Select four preset favorite channels in four
different categories.
While watching, you can toggle the selected channels
by pressing A, B, C and D.
25 FAVORITE: Register favorite channel.
26 CC: Display captions during closed-caption source.
27 AV MODE: Select an audio or video setting.
AV mode: STANDARD, MOVIE, GAME,
USER, DYNAMIC (Fixed), DYNAMIC.
_
You can connect many types of external equipment to your TV, like a DVD player, VCR, Digital TV tuner, HDMI
equipment, game console and camcorder. To view external source images, select the input source from INPUT
on the remote control unit or on the TV.
CAUTION
To protect all equipment, always turn off the TV before
connecting to a DVD player, VCR, Digital TV tuner, HDMI
equipment, game console, camcorder or other external
equipment.
NOTE
Please refer to the relevant operation manual (DVD player,
etc.) carefully before making connections.
Each time INPUT is pressed, the input source toggles.
Refer to your external equipment operation manual for
the signal type.
Displaying an external equipment image
Explanation here is for the setting when connecting
DVD to INPUT1 terminal.
INPUT button
To watch a DVD image, select "INPUT1" from "INPUT
SOURCE" menu using INPUT on the remote control
unit or on the TV.
INPUT SOURCE
TV DVD
INPUT2
INPUT3
INPUT4
1
MENU
[Option ... Input Select]
Auto
COMPONENT
Video
For INPUT1 signal
Select the desired signal type.
The setting is stored and can be selected on the
"INPUT SOURCE" menu.
Press MENU and the MENU screen displays.
2
3
Press / to select "Input Select", and then
press ENTER.
4
Press / to select "Option".
NOTE
If the image does not come in clearly, you may need to
change the input signal type setting on the "Input Select"
menu.
Selecting the INPUT signal

8
LC-37GA5T
Using external equipment
DVD player/
DigitalTV STB
Connecting a DVD player or DigitalTV STB
You can use the INPUT 1 to INPUT 4 terminals when connecting to a DVD player, Digital TV STB and other
audiovisual equipment.
AV cable
(commercially available)
DVD player/
DigitalTV STB
When using component cable. (INPUT 1 or 2)
When using composite cable. (INPUT 1, 2 or 3)
Component video
cable (commercially
available)
Audio cable
(commercially
available)
VCR/Game console/
Camcorder
AV cable
(commercially
available)
Connecting aVCR, game console or camcorder
A VCR, game console, camcorder and some other audiovisual equipment are conveniently connected using
the INPUT 1 to 3 terminals.
S-video cable
(commercially
available)
NOTE
The S-video terminal has priority over the video terminals. (INPUT 3 only)
Connecting HDMI equipment
You can use the INPUT 4 terminal when connecting an HDMI equipment.
HDMI equipment
HDMI cable (commercially available)
Displaying an image from HDMI equipment
To watch an HDMI equipment image, select
"INPUT4" from "INPUT SOURCE" menu
using INPUT on the remote control unit or
on the TV.
INPUT SOURCE
TV INPUT1
INPUT2
INPUT3
INPUT4
1
Press MENU and the MENU screen displays.
2
3
Press / to select "HDMI Setup", and then
press ENTER.
4
Press / to select "Option".
MENU
[Option ... HDMI Setup]
Option
Digital Noise Reduction
Output Select
Audio Only
Quick Shoot
[Fixed]
HDMI Setup
[Low]
[Off]
5
Press / to select the desired item and
press ENTER.
Press / / / to select the desired setting
and press ENTER.
6
NOTE
Refer to your external equipment operation manual for
the signal type.
Selectable items
RGB/YCbCr 4:4:4/
YCbCr 4:2:2
ITU601/ITU709
Standard/
Out of standard
Enable/Disable
Digital/Analog
HDMI Setup
items
Signal
Type
Color
Matrix
Dynamic
Range
Auto View
Audio
Select
Description
Select the video signal
type from the HDMI
terminal.
Select the internal color
space conversion method
when an RGB signal is
input.
Select the signal amplitude
range. Usually, select
"Standard".
Set whether or not to use
VIEW MODE based on
signal recognition,
including an HDMI signal.
Select "Digital" for audio
signal via the HDMI
terminal. Select "Analog"
for audio signal via the R-
AUDIO -L terminal.
When using an HDMI-DVI
conversion adapter, input the
Audio signal from AUDIO
terminal of INPUT4.

9
LC-37GA5T
Appendix
Removing the stand
Before detaching (or attaching) stand, unplug the AC cord from the AC INPUT terminal.
CAUTION
Do not remove the stand from theTV unless using an optional wall mount bracket to mount it.
Before attaching/detaching stand
Before performing work make sure to turn off the TV.
Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being
damaged.
NOTE
To attach the stand, perform the above steps in reverse order.
Setting theTV on the wall
CAUTION
Installing the TV requires special skill that should only be performed by qualified service personnel. Customers
should not attempt to do the work themselves.SHARP bears no responsibility for improper mounting or mounting
that results in accident or injury.
Using an optional bracket to mount theTV
You can ask a qualified service personnel about using an optional bracket to mount the TV to the wall.
Carefully read the instructions that come with the bracket before beginning work.
Vertical mounting Angular mounting
Hanging on the wall
Wall mount bracket. (See the bracket instructions for details.)
2
Unfasten the four screws used to
secure the stand in place.
1
Unfasten the screw used to secure the
bracket in place.
3
Detach the stand from the TV.
(Hold the stand so it will not drop from
the edge of the base area.)
No power
Unit cannot be operated.
Remote control unit does not
operate.
Picture is cut off/with sidebar
screen.
Strange color, light color, or color
misalignment
Power is suddenly turned off.
No picture
No sound
Problem Possible Solution
Check if you pressed TV POWER on the remote control unit.
If the indicator on the TV does not light up, press TV POWER on the remote
control unit.
Is the AC cord disconnected?
Has the power been turned on?
External influences such as lightning, static electricity, may cause improper
operation. In this case, operate the unit after first turning on the power of the TV
or unplugging the AC cord and replugging it in after 1 or 2 minutes.
Is the FUNCTION set correctly? Set it to the TV setting position.
Are batteries inserted with polarity ( , ) aligned?
Are batteries worn out? (Replace with new batteries.)
Are you using it under strong or fluorescent lighting?
Is a fluorescent light illuminated near the remote control sensor?
Is the image position correct?
Are screen mode adjustments such as picture size made correctly?
Adjust the picture tone.
Is the room too bright? The picture may look dark in a room that is too bright.
Is the sleep timer set?
Check the power control settings.
The unit's internal temperature has increased.
Remove any objects blocking vent or clean.
Is connection to other components correct?
Is correct input signal source selected after connection?
Is the correct input selected?
Is picture adjustment correct?
Is "On" selected in "Audio Only"?
Is the volume too low?
Is "Variable" selected in "Output Select"?
Troubleshooting
Cautions regarding use in high and low temperature environments
When the unit is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly
delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight or near
a heater, as this may cause the cabinet to deform and the Liquid Crystal panel to malfunction.
Storage temperature: 4
o
F to +140
o
F ( 20
o
C to +60
o
C)
+_
__

10
LC-37GA5T
Appendix
RS-232C port specifications
Return codeCommand 4-digits Parameter 4-digits
PC Control of theTV
When a program is set, the TV can be controlled from the PC using the RS-232C terminal. The input signal
(PC/AV) can be selected, the volume can be adjusted and various other adjustments and settings can be
made, enabling automatic programmed playing.
Attach an RS-232C cable cross-type (commercially available) to the supplied Din/D-Sub RS-232C for the
connections.
NOTE
This operation system should be used by a person who is accustomed to using computers.
Communication conditions
Set the RS-232C communications settings on the PC to match the TV's communications conditions.
The TV's communications settings are as follows:
Baud rate:
Parity bit:
Data length:
Stop bit:
Flow control:
9,600 bps
8 bits
None
1 bit
None
Command format
Communication procedure
Send the control commands from the PC via the RS-232C connector.
The TV operates according to the received command and sends a response message to the PC.
Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending
the next command.
Eight ASCII codes CR
Command 4-digits: Command. The text of four characters.
Parameter 4-digits: Parameter 0 9, x, blank, ?
Parameter
Input the parameter values, aligning left, and fill with blank(s) for the remainder. (Be sure that 4 values are input for the
parameter.)
When the input parameter is not within an adjustable range, "ERR" returns. (Refer to "Response code format".)
No problem to input any numerical value for "x" on the table.
When "?" is input for some commands, the present setting value responds.
C1 C2 C3 C4 P1 P2 P3 P4
0055
100
30
0009
0
????
?
+
_
_
Command table
About the command except being indicated here, it is outside the guarantee range of operation.
CONTROL ITEM COMMAND
PARAMETER
CONTROL CONTENTS
POWER SETTING It shifts to standby.
It input-switches by the toggle. (It is the same as an input change key)
It input-switches to TV. (A channel remains as it is. (Last memory))
It input-switches to INPUT1~INPUT4.
An input change is also included.
Although it can choose now, it is toggle operation in inside.
Although it can choose now, it is toggle operation in inside.
(Toggle)
Input terminal number (1 4)
AUTO
VIDEO
COMPONENT
(Toggle)
STANDARD
MOVIE
USER
GAME
DYNAMIC (Fixed)
DYNAMIC
Volume (0 60)
AV mode. ( 10)
AV mode. ( 20)
(Toggle)
An input change is included if it is not TV display.
In Air, 2 69ch is effective.
In Cable, 1 125ch is effective.
If it is not TV display, it will input-switch to TV.
If it is not TV display, it will input-switch to TV.
Toggle operation of a closed caption.
Side Bar
S.Stretch
Zoom
Stretch
OFF
OFF TIMER 30 MIN.
The channel number of TV
The channel number of TV 1
The channel number of TV 1
(Toggle)
(1 125)
AUTO
POWR
ITGD
ITVD
IAVD
INP1
INPUT SELECTION A TOGGLE
INPUT SELECTION B
AV MODE SELECTION
VOLUME
POSITION
VIEWMODE
SLEEP TIMER
CHANNEL
CC
DIRECT
CH UP
CH DOWN
CHANNEL
H-POSITIONH-POSITION
V-POSITION
INPUT 1
AVMD
VOLM
HPOS
VPOS
OFTM
DCCH
CHUP
CHDW
CLCP
WIDE
0
x
0
*
0
1
2
0
*
*
*
0
*
x
x
x
1
0
1
2
3
4
1
2
3
4
5
6
*
_
_
_
_
_
_
_
_
_
_
*
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
*
_
_
_
_
_
_
_
_
_
_
*
*
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
(Toggle)
AUDIO SELECTION ACHA x _ _ _
_
_
OFF TIMER 60 MIN.
OFF TIMER 90 MIN.
2
3
_
_
_
_
_
_
OFF TIMER 120 MIN.4___
(Toggle)
On
Off
MUTE MU T E 0
1
2
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
AUTO
VIDEO
COMPONENT
AUTOINP2
INPUT 2 0
1
2
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
TV
INPUT1-4
NOTE
If an underbar (_) appears in the parameter column, enter a space.
If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL CONTENTS.
As long as that from which the parameter ( ) in the table is a numerical value, it may write anything.
Return code (0DH)
Response code format
Normal response
Problem response (communication error or incorrect command)
Return code (0DH)
OK
ERR
_
_
_
_
+
_
±
±
_
×

11
LC-37GA5T
Basic adjustment settings
Menu items
List of menu items to help you with operations
OPC
Backlight
Contrast
Brightness
Color
Tint
Sharpness
Advanced
ColorTemp.
Black
3D-Y/C
Monochrome
Film Mode
I/P Setting
No Signal Off
No Operation Off
EZ Setup
CH Setup
Input Label
Parental CTRL
Position
Picture Flip
Language
Treble
Bass
Balance
Surround
Audio Only
Digital Noise Reduction
HDMI Setup
Input Select
Output Select
Quick Shoot
Color System
Audio
Power Control
Setup
Option

12
LC-37GA5T
DIMENSIONS
Unit: inch/(mm)
384
671
1105
822.6
200
306
114105
200
104 56285
647
463.9
367.8

13
LC-37GA5T
DESCRIPTION OF SCHEMATIC DIAGRAM
VOLTAGE MEASUREMENT CONDITION:
INDICATION OF RESISTOR & CAPACITOR:
The voltages at test points are measured on
exclusive AC adaptor and the stable supply
voltage of AC 120V. Signals are fed by a color bar
signal generator for servicing purpose and the
above voltages are measured with a 20k ohm/V
tester.
1.
RESISTOR
1. The unit of resistance "Ω" is omitted.
(K=kΩ=1000 Ω, M=MΩ).
2. All resistors are ± 5%, unless otherwise noted.
(K= ± 10%, F= ± 1%, D= ± 0.5%)
1. All capacitors are µF, unless otherwise noted.
(P=pF=µµF).
2. All capacitors are 50V, unless otherwise noted.
3. All resistors are 1/16W, unless otherwise noted.
CAPACITOR
This circuit diagram is original one, therefore there may be a
slight difference from yours.
CAUTION:
SAFETY NOTES:
DISCONNECT THE AC PLUG FROM THE AC
OUTLET BEFORE REPLACING PARTS.
1.
SEMICONDUCTOR HEAT SINKS SHOULD BE
REGARDED AS POTENTIAL SHOCK HAZARDS
WHENTHE CHASSIS IS OPERATING.
2.
IMPORTANT SAFETY NOTICE:
PARTS MARKED WITH " " ( ) ARE
IMPORTANT FOR MAINTAINING THE SAFETY OF
THE SET. BE SURE TO REPLACE THESE PARTS
WITH SPECIFIED ONES FOR MAINTAINING THE
SAFETY AND PERFORMANCE OFTHE SET.
AVIS DE SECURITE IMPORTANT:
LES PIECES MARQUEES " " ( ) SONT
IMPORTANTES POUR MAINTENIR LA SECURITE
DE L'APPAREIL.
NE REMPLACER CES PIEDES QUE PAR DES
PIECES DONT LE NUMERO EST SPECIFIE POUR
MAINTENIR LA SECURITE ET PROTEGER LE
BON FONCTIONNEMENT DE L'APPAREIL.

15
LC-37GA5T
14
LC-37GA5T
A
B
C
D
E
F
G
H
I
J
12345678910
11 12 13 14 15 16 17 18 19
SCHEMATIC DIAGRAM
Ë MAIN UNIT-1/6

17
LC-37GA5T
16
LC-37GA5T
A
B
C
D
E
F
G
H
I
J
12345678910
11 12 13 14 15 16 17 18 19
Ë POWER SUPPLY UNIT

19
LC-37GA5T
18
LC-37GA5T
A
B
C
D
E
F
G
H
I
J
12345678910
11 12 13 14 15 16 17 18 19
PRINTEDWIRING BOARD ASSEMBLIES
POWER SUPPLY Unit (Side-A)

21
LC-37GA5T
20
LC-37GA5T
A
B
C
D
E
F
G
H
I
J
12345678910
11 12 13 14 15 16 17 18 19
POWER SUPPLY Unit (Side-B)

22
LC-37GA5T
Ref. No. Part No. ★Description Code
Ref. No. Part No. ★Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual;electrical components having such features
are identified by åand shaded areas in the Replacement Parts Lists
and Schematic Diagrams.The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOWTO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
PRINTEDWIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKD375WE03 – MAIN Unit —
DUNTKD352WE20 – AV Unit —
DUNTKD353WE20 – KEY Unit —
DUNTKD354WE20 – R/C, LED Unit —
RDENCA140WJQZ J POWER SUPPLY Unit BT
LCD PANEL
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
RLCUCA026WJZZ J 37 WIDE LCD PANEL MODULE Unit
RDENCA140WJQZ
POWER SUPPLY UNIT
INTEGRATED CIRCUITS
IC701 VHiMC33262D-1 J IC MC33262D AK
IC702 VHiKiA431A/-1 J IC KIA431A (1%)
VHiTA76431S-1 J IC TA76431S (1.5%) AD
VHiHA17431UA4 J IC HA17431HP (1%) AE
IC703 VHiTNY266P/-1 J IC TNY266P AL
IC801 VHiKiA431A/-1 J IC KIA431A (1%)
VHiTA76431S-1 J IC TA76431S (1.5%) AD
VHiHA17431UA4 J IC HA17431HP (1%) AE
IC802 VHiMP1580P/-1 J IC MP1580 (DIP) AL
IC803 VHiMP1580P/-1 J IC MP1580 (DIP) AL
IC804 VHiKiA431A/-1 J IC KIA431A (1%)
VHiTA76431S-1 J IC TA76431S (1.5%) AD
VHiHA17431UA4 J IC HA17431HP (1%) AE
IC805 VHiMP1583P/-1 J IC MP1583 (DIP) AM
IC806 VHiKiA431A/-1 J IC KIA431A (1%)
VHiTA76431S-1 J IC TA76431S (1.5%) AD
VHiHA17431UA4 J IC HA17431HP (1%) AE
TRANSISTORS
Q701 VSFQPF12N60C1 J FQPF12N60C AL
Q702 VS2SA2071Q/-1 J 2SA2071Q
VS2SA1213-/-1 J 2SA1213 AE
Q703 VSFQPF12N60C1 J FQPF12N60C AL
Q704 VS2SA2071Q/-1 J 2SA2071Q
VS2SA1213-/-1 J 2SA1213 AE
Q705 VS2SC4672Q/-1 J 2SC4672Q AE
VS2SC2873/Y-1 J 2SC2873 AD
Q706 VSRT1P241C/P1 J RT1P241C
VSDTA124EK/-1 J DTA124EKA AB
Q707 VS2SK3520-01M J 2SK3520 AK
Q708 VS2SK3520-01M J 2SK3520 AK
Q709 VS2SD1781KQ-1 J 2SD1781 AC
Q710 VSDTA143EK/-1 J DTA143EK AA
Q711 VS2SC2411KR-1 J 2SC2411KR AC
Q712 VSRT1P241C/P1 J RT1P241C
VSDTA124EK/-1 J DTA124EKA AB
Q713 VSRT1P141C/P1 J RT1P141C
VSDTA114EK/-1 J DTA114EKA AB
Q714 VSRT5N141C/P1 J RT5N141C
VSDTD114EK/-1 J DTD114EKA AC
Q715 VS2SK3520-01M J 2SK3520-01MR AK
Q716 VS2SK3520-01M J 2SK3520-01MR AK
Q717 VS2SD1781KQ-1 J 2SD1781KQ AC
Q718 VSRT1P431C/P1 J RT1P431C
Q719 VS2SC2411KR-1 J 2SC2411KR AC
Q720 VS2SA2048KQP1 J 2SA2048KQ
Q721 VSRT1N241C/P1 J RT1N241C
VSDTC124EK/-1 J DTC124EKA AB
Q801 VS2SD1781KQ-1 J 2SD1781 AC
Q802 VS2SK3645-01M J 2SK3645
Q803 VS2SK3645-01M J 2SK3645
Q804 VS2SA1036KQRC J 2SA1036 AC
Q805 VS2SC2411KR-1 J 2SC2411KR AC
Q807 VSDTC124EK/-1 J DTC124EK AB
Q808 VSDTC124EK/-1 J DTC124EK AB
Q809 VSDTC124EK/-1 J DTC124EK AB
Q810 VS2SD1781KQ-1 J 2SD1781 AC
Q811 VS2SK3236//-1 J 2SK3236 AL
Q812 VS2SK3236//-1 J 2SK3236 AL
Q813 VS2SA1036KQRC J 2SA1036 AC
Q814 VS2SC2411KR-1 J 2SC2411KR AC
Q816 VSSP8K3////P1 J SP8K3
Q817 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q818 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q819 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q820 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
RESISTORS
R2020 VRS-CY1JF472JY J 1/16W Metal Oxide AA
R2022 VRS-CY1JF472JY J 1/16W Metal Oxide AA
DUNTKD375WE03
MAIN UNIT

23
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
LC-37GA5T
RDENCA140WJQZ
POWER SUPPLY UNIT (Continued)
Q821 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q822 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q823 VS2SC2411KR-1 J 2SC2411KR AC
Q824 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q825 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q826 VSDTA124EK/-1 J DTA124EK AB
VSRT1P241C/P1 J RT1P241C
Q827 VSDTC124EK/-1 J DTC124EK AB
VSRT1P241C/P1 J RT1P241C
Q828 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q829 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
Q830 VSDTA144EK/-1 J DTC144EK AC
VSRT1N441C/P1 J RT1N441C
Q831 VSDTA124EK/-1 J DTA124EKA AB
VSRT1P241C/P1 J RT1P241C
Q832 VSDTC124EK/-1 J DTC124EK AB
VSRT1N241C/P1 J RT1N241C
DIODES
åD701 VHDD3SB60//-1 J D3SB60 AH
åD702 VHDD3SB60//-1 J D3SB60 AH
D703 VHERLZ39B//-1 J Zener Diode, RLZ39B AC
D704 VHERLZ39B//-1 J Zener Diode, RLZ39B AC
D705 VHDFFPF10U60S J FFPF10U60STU AG
D707 VHDDAN202K/-1 J DAN202K AB
D708 VHDDAN202K/-1 J DAN202K AB
D709 VHD1SS355//-1 J 1SS355 AB
D710 VHD1SS355//-1 J 1SS355 AB
D711 VHDRLS245//-1 J RLS245 AB
D712 VHEHZK27///-1 J Zener Diode, HZK27
VHERLZ27B//-1 J Zener Diode, RLZ27B AC
D713 VHD1SS355//-1 J 1SS355 AB
D714 VHDDAN202K/-1 J DAN202K AB
D715 VHDDAN202K/-1 J DAN202K AB
D716 VHD1SS355//-1 J 1SS355 AB
D717 VHDHZU9.1B2-1 J Zener Diode, HZU9.1B2
D718 VHD1SS355//-1 J 1SS355 AB
D719 VHDRLS245//-1 J RLS245 AB
D720 VHD1SS355//-1 J 1SS355 AB
D721 VHD1SS355//-1 J 1SS355 AB
D722 VHD1SS355//-1 J 1SS355 AB
D723 VHDRLS245//-1 J RLS245 AB
D724 VHERLZ27B//-1 J Zener Diode, RLZ27B AC
D725 VHDDAN202K/-1 J DAN202K AB
D726 VHDDAN202K/-1 J DAN202K AB
D727 VHD1SS355//-1 J 1SS355 AB
D728 VHDRLS245//-1 J RLS245 AB
D729 VHD1SS355//-1 J 1SS355 AB
D730 VHEHZU16B2/-1 J Zener Diode, HZU16B2
D731 VHD1SS355//-1 J 1SS355 AB
D732 VHD1SS355//-1 J 1SS355 AB
D733 VHDERA92-02-1 J ERA92
VHDSFPL52V/-1 J SFPL52 AD
åD734 VHD1SR139-600 J 1SR139-600
å02011016-R001 J 1N4005
åD735 VHD1SR139-600 J 1SR139-600
å02011016-R001 J 1N4005
åD736 VHD1SR139-600 J 1SR139-600
å02011016-R001 J 1N4005
åD737 VHD1SR139-600 J 1SR139-600
å02011016-R001 J 1N4005
D738 VHD1N4937//P1 J 1N4937
D739 VHD1N4937//P1 J 1N4937
D740 VHERLZ8.2A/-1 J Zener Diode, RLZ8.2A AC
D741 VHDERA92-02-1 J ERA92
VHDSFPL52V/-1 J SFPL52 AD
D742 VHD1SS355//-1 J 1SS355 AB
D801 VHD1SS355//-1 J 1SS355 AB
D802 VHDRLS245//-1 J RLS245 AB
D803 VHDRLS245//-1 J RLS245 AB
D804 VHD1SS355//-1 J 1SS355 AB
D805 VHD1SS355//-1 J 1SS355 AB
D806 VHEHZU27B//-1 J Zener Diode, HZU27B
D807 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SR24 (SFPB74) AD
D808 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SR24 (SFPB74) AD
D809 VHEHZU5.1B2-1 J Zener Diode, HZU5.1B2 AC
D810 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SR24 (SFPB74) AD
D811 VHEHZU6.8B2-1 J Zener Diode, HZU6.8B2 AC
D812 VHD1SR153-400 J 1SR153-400
D813 VHD1SS355//-1 J 1SS355 AB
D814 VHEHZU16B2/-1 J Zener Diode, HZU16B2
D815 VHEHZU30B//-1 J Zener Diode, HZU30B
D816 VHEHZU12B2/-1 J Zener Diode, HZU12B2
D817 VHD1SS355//-1 J 1SS355 AB
D819 VHDRLS245//-1 J RLS245 AB
D820 VHD1SS355//-1 J 1SS355 AB
D821 VHD1SS355//-1 J 1SS355 AB
D822 VHEHZU12B2/-1 J Zener Diode, HZU12B2
D823 VHDDAN202K/-1 J DAN202K AB
D824 VHEHZU16B2/-1 J Zener Diode, HZU16B2
D825 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SR24 (SFPB74) AD
D826 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SR24 (SFPB74) AD
D827 VHEHZU6.8B2-1 J Zener Diode, HZU6.8B2 AC
D828 VHDERB84-009K J ERB84-009K
VHDSFPB69//-1 J SFPB69 AE
D829 VHERLZ36B//-1 J Zener Diode, RLZ36B AC
D830 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SFPB74 AD
D831 VHDERB83-004G J ERB83-004G1
VHDSFPB74//-1 J SFPB74 AD
D832 VHERLZ8.2A/-1 J Zener Diode, RLZ8.2A AC
D835 VHD1SS355//-1 J 1SS355 AB
D836 VHEHZU16B2/-1 J Zener Diode, HZU16B2
D837 VHEHZU5.1B2-1 J Zener Diode, HZU5.1B2 AC
D838 VHEHZU12B2/-1 J Zener Diode, HZU12B2
D839 VHD1SS355//-1 J 1SS355 AB
D840 VHD1SS355//-1 J 1SS355 AB
D841 VHEHZU2.2B/-1 J Zener Diode, HZU2.2B
VHERD2.0SB/-1 J Zener Diode, RD2.0SB
D842 VHDRLS245//-1 J RLS245 AB
D843 VHDRLS245//-1 J RLS245 AB
åVA701 VHVTNR10V471K J Varistor, TNR10V471K AD
åVA702 VHVTNR10V471K J Varistor, TNR10V471K AD
åVA703 VHVTNR10V471K J Varistor, TNR10V471K AD
TH701 VHSM3R014C/-1 J Thermistor, M3R014C
TH702 VHSM3R014C/-1 J Thermistor, M3R014C
PACKAGED CIRCUITS
åPC701 VHPPC123X2YFZ J PC123X2YFZ AD
åPC702 VHPPC123X2YFZ J PC123X2YFZ AD
åPC703 VHPPC123X2YFZ J PC123X2YFZ AD
åPC704 VHPPC123X2YFZ J PC123X2YFZ AD
åPC706 VHPPC123X2YFZ J PC123X2YFZ AD
COILS
åL701 RCiLC1315SNPZ J Line Filter, HF2836-562Y2R5-T01
åL702 RCiLC1315SNPZ J Line Filter, HF2836-562Y2R5-T01
L703 RCiLC1292SNPZ J Choke Coil, C1292 (EI-40)
L704 RCiLC1273SNEZ J Choke Coil,TSL0709 (470uH) AE
L705 RCiLC1295SNEZ J Choke Coil, LHL08TB471K (470uH)
RCiLC1313SNEZ J Choke Coil,TSL0808 (470uH)
L706 RCiLC1314SNEZ J Choke Coil, LHL13 (10mH)
L801 RCiLC1280SNEZ J Choke Coil, A7503HY AF
L802 RCiLC1294SNEZ J Choke Coil, LHL08TB220K (22uH)
RCiLC1281SNEZ J Choke Coil,TSL0808 (22uH) AD

24
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
LC-37GA5T
RDENCA140WJQZ
POWER SUPPLY UNIT (Continued)
L803 RCiLC1294SNEZ J Choke Coil, LHL08TB220K (22uH)
RCiLC1281SNEZ J Choke Coil, TSL0808 (22uH) AD
L804 RCiLC1280SNEZ J Choke Coil, A7503HY AF
L805 RCiLC1297SNEZ J Choke Coil, LHL10TB1R0M (1uH)
RCiLC1262SNEZ J Choke Coil, TSL1112 (1uH) AF
L806 RCiLC1297SNEZ J Choke Coil, LHL10TB1R0M (1uH)
RCiLC1262SNEZ J Choke Coil, TSL1112 (1uH) AF
L807 RCiLC1298SNEZ J Choke Coil, LHL10TB330K (33uH)
RCiLC1279SNEZ J Choke Coil, TSL1112 (33uH) AE
L808 RCiLC1294SNEZ J Choke Coil, LHL08TB220K (22uH)
RCiLC1281SNEZ J Choke Coil, TSL0808 (22uH) AD
TRANSFORMERS
åT701 RTRNP1292SNEZ J Transformer, EER28L (24V), P1292
T702 RTRNP1261SNEZ J Transformer, UF1717V-282Y0R5-01 AF
åT703 RTRNP1292SNEZ J Transformer, EER28L (24V), P1292
åT704 RTRNP1293SNEZ J Transformer, EER28L (10V), P1293
T705 RTRNP1261SNEZ J Transformer, UF1717V-282Y0R5-01 AF
åT706 RTRNP1289SNPZ J Transformer, EE19L, P1289
CAPACITORS
åC701 RCM2E224LEMSC J 0.22 275V Film AD
åC702 RCM2E224LEMSC J 0.22 275V Film AD
åC703 RC-CS472ESNEZ J 4700p 250V Ceramic
åC704 RC-CS472ESNEZ J 4700p 250V Ceramic
åC705 RC-CS472ESNEZ J 4700p 250V Ceramic
åC706 RCM2E224LEMSC J 0.047 275V Film AD
åC707 RC-CS332ESNEZ J 3300p 250V Ceramic
åC708 RC-CS332ESNEZ J 3300p 250V Ceramic
åC709 RCM2W105AFPP1 J 1 450V Ceramic
C710 RCK45R3D102KV J 1000p 2kV Ceramic
C711 RC-E2W686KXGZ J 68 450V Electrolytic AL
RC-E2W686KMGZ J 68 450V Electrolytic
C712 RC-E2W686KXGZ J 68 450V Electrolytic AL
RC-E2W686KMGZ J 68 450V Electrolytic
C713 RC-E2W686KXGZ J 68 450V Electrolytic AL
RC-E2W686KMGZ J 68 450V Electrolytic
C714 VCKYTV1HB103K J 0.01 50V Ceramic AA
C716 VCKYTV1HB225K J 2.2 25V/50V Ceramic
C717 VCKYTV1HB103K J 0.01 50V Ceramic AA
C718 VCKYTV1HB224K J 0.22 50V Ceramic AB
C719 VCKYTV1HB103K J 0.01 50V Ceramic AA
C720 VCKYTV1HB103K J 0.01 50V Ceramic AA
C721 VCKYTV1EB104K J 0.1 25V Ceramic AB
C723 VCKYTV1HB471K J 470p 50V Ceramic AA
C724 RCM2W105AFPP1 J 0.47 450V Ceramic
C725 VCKYTV1HB102K J 1000p 50V Ceramic AA
C726 VCKYTV1EB104K J 0.1 25V Ceramic AB
C727 VCKYTV1HB332K J 3300p 50V Ceramic AA
C728 VCKYTV1EB224K J 0.22 25V Ceramic AB
C729 VCKYTV1EB104K J 0.1 25V Ceramic AB
C730 VCKYTV1HB103K J 0.01 50V Ceramic AA
C731 VCKYTV1HB102K J 1000p 50V Ceramic AA
C732 VCKYTV1HB473K J 0.047 50V Ceramic AA
C733 VCKYTQ1EB225K J 2.2 25V Ceramic
C734 VCKYTV1HB104K J 0.1 50V Ceramic
C735 VCKYTV1HB102K J 1000p 50V Ceramic AA
C736 VCKYTV1HB152K J 1500p 50V Ceramic AA
C737 VCKYTV1HB224K J 0.22 50V Ceramic AB
C738 RCM2W224AFPP1 J 0.22 450V Film
C739 VCKYTV1HB102K J 1000p 50V Ceramic AA
C740 VCKYTV1EB104K J 0.1 25V Ceramic AB
C741 VCKYTV1EB104K J 0.1 25V Ceramic AB
C742 VCKYTV1HB332K J 3300p 50V Ceramic AA
C743 VCKYTV1HB103K J 0.01 50V Ceramic AA
C744 VCKYTV1HB102K J 1000p 50V Ceramic AA
C745 VCKYTV1HB224K J 0.22 50V Ceramic AB
C746 VCKYTV1EB475K J 4.7 25V Ceramic AC
C747 RC-E2A476SKZE J 47 100V Electrolytic
RC-E1H476SNKY J 47 50V Electrolytic
C748 RC-E2W336KXGZ J 33 450V Electrolytic AK
C749 RCK45R3D471KV J 470p 2kV Ceramic AC
C750 RCDEA1X3D150P J 15p 2kV Ceramic
C751 VCKYTV1EB104K J 0.1 25V Ceramic AB
C752 VCKYTV1HB102K J 1000p 50V Ceramic AA
C753 VCKYTV1HB473K J 0.047 50V Ceramic AA
C755 RC-CS332ESNEZ J 3300p 250V Ceramic
C756 RC-CS332ESNEZ J 3300p 250V Ceramic
C758 RCK45R3D102KV J 1000p 2kV Ceramic
C761 RCK45R3D221KV J 220p 2kV Ceramic AC
C801 VCKYTV1HB472K J 4700p 50V Ceramic AA
C802 VCKYTV2AB221K J 220p 100V Ceramic
C803 VCKYTV1HB103K J 0.01 50V Ceramic AA
C804 RC-E1V687SNKY J 680 35V Electrolytic
C805 RC-E1V687SNKY J 680 35V Electrolytic
C807 VCKYTV1CB474K J 0.47 16V Ceramic AC
C808 RC-E1V687SNKY J 680 35V Electrolytic
C809 VCKYTV1HB104K J 0.1 50V Ceramic
C810 RC-E1V227SKZE J 220 35V Electrolytic AD
C811 VCKYTV1EB104K J 0.1 25V Ceramic AB
C812 VCKYTV1HB101K J 100p 50V Ceramic
C813 VCKYTV1HB103K J 0.01 50V Ceramic AA
C814 VCKYTV1HB102K J 1000p 50V Ceramic AA
C815 VCKYTV1HB103K J 0.01 50V Ceramic AA
C816 VCKYTV1HB101K J 100p 50V Ceramic
C817 RC-E1V227SKZE J 220 35V Electrolytic AD
C818 VCKYTV1HB104K J 0.1 50V Ceramic
C819 RC-E1V227SKZE J 220 35V Electrolytic AD
C820 VCKYTV1EB104K J 0.1 25V Ceramic AB
C821 VCKYTV1HB101K J 100p 50V Ceramic
C822 VCKYTV1HB103K J 0.01 50V Ceramic AA
C823 VCKYTV1HB102K J 1000p 50V Ceramic AA
C824 VCKYTV1HB103K J 0.01 50V Ceramic AA
C825 VCKYTV1HB101K J 100p 50V Ceramic
C826 RC-E1V227SKZE J 220 35V Electrolytic AD
C827 VCKYTV1HB104K J 0.1 50V Ceramic
C829 VCKYTQ1HB225K J 2.2 50V Ceramic
C830 VCKYTQ1HB225K J 2.2 50V Ceramic
C831 VCKYTV1HB104K J 0.1 50V Ceramic
C832 RC-E1V687SNKY J 680 35V Electrolytic
C833 VCKYTV1HB104K J 0.1 50V Ceramic
C834 VCKYTV1HB472K J 4700p 50V Ceramic AA
C835 VCKYTV1HB221K J 220p 50V Ceramic
C836 RC-E1V687SNKY J 680 35V Electrolytic
C837 RC-E1V687SNKY J 680 35V Electrolytic
C838 VCKYTV1HB224K J 0.22 50V Ceramic AB
C839 VCKYTV1CB474K J 0.47 16V Ceramic AC
C840 RC-E1V227SKZE J 220 35V Electrolytic AD
C841 VCKYTV1EB225J J 2.2 25V Ceramic
C842 RC-E1V227SKZE J 220 35V Electrolytic AD
C843 VCKYTV1HB104K J 0.1 50V Ceramic
C844 RC-E1V227SKZE J 220 35V Electrolytic AD
C845 VCKYTV1EB104K J 0.1 25V Ceramic AB
C846 VCKYTV1HB101K J 100p 50V Ceramic
C847 VCKYTV1HB103K J 0.01 50V Ceramic AA
C848 VCKYTV1HB102K J 1000p 50V Ceramic AA
C849 VCKYTV1HB103K J 0.01 50V Ceramic AA
C850 VCKYTV1HB101K J 100p 50V Ceramic
C851 RC-E1V227SKZE J 220 35V Electrolytic AD
C852 VCKYTV1HB104K J 0.1 50V Ceramic
C853 VCKYTV1EB225J J 2.2 25V Ceramic
C854 RC-E1V227SKZE J 220 35V Electrolytic AD
C855 VCKYTV1HB104K J 0.1 50V Ceramic
C856 RCK45R3D221KV J 220p 2kV Ceramic AC
C857 RC-E1H157SKZE J 150 50V Electrolytic AD
C858 VCKYTV1HB104K J 0.1 50V Ceramic
C859 RCK45R3D221KV J 220p 2kV Ceramic AC
C860 RC-E1V687PWS J 680 35V Electrolytic
C861 VCKYTV1CB105K J 1 10V/16V Ceramic AC
C862 RC-E1V227SKZE J 220 35V Electrolytic AD
C863 VCKYTV1EB104K J 0.1 25V Ceramic AB
C864 VCKYTV1EB104K J 0.1 25V Ceramic AB
C865 VCKYTV1HB104K J 0.1 50V Ceramic
C866 VCKYTV1CB474K J 0.47 16V Ceramic AC
C867 VCKYTV0JB226K J 22 6.3V Ceramic
C868 VCKYTV1HB224K J 0.22 50V Ceramic AB
