SERVICE MANUAL
1st Addition
No. S94M55LC-32LE260M
LED BACKLIGHT TV
LC-32LE260M
MODEL:
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
CHAPTER 1. SAFETY PRECAUTION
[1] IMPORTANT SERVICE SAFETY PRE-
CAUTION 1-1
[2] PRECAUTION FOR USING LEAD-
FREE SOLDER 1-2
CHAPTER 2. DIFFERENCES FROM BASE MOD-
EL
[1] OUTLINE & DIFFERENCES FROM
BASE MODEL 2-1
CHAPTER 3. SPECIFICATIONS
[1] SPECIFICATIONS 3-1
CHAPTER 4. ADJUSTMENT
[1] ADJUSTMENT 4-1
CHAPTER 5. TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE 5-1
CHAPTER 6. SYSTEM BLOCK DIAGRAM
[1] SYSYTEM BLOCK DIAGRAM 6-1
CHAPTER 7. PRINTED WIRING BOARD AS-
SEMBLIES
[1] MAIN UNIT 7-1
CHAPTER 8. SCHEMATIC DIAGRAM
[1] DESCRIPTION OF SCHEMATIC DIA-
GRAM 8-1
[2] MAIN UNIT 8-2
Parts Guide
TopPage
CONTENTS
This model is based on the LC-32LE265M and is changed some parts.This Service Manual covers the
modification alone. For the other points, please refer to the LC-32LE265M Service Manual.
OUTLINE

LC-32LE260M
1 – 1
CHAPTER 1. SAFETY PRECAUTION
[1] IMPORTANT SERVICE SAFETY PRE-
CAUTION
LC
IMPORTANT SERVICE SAFETY PRECAUTION
WAR NING
1. F or continued s a fe ty, no modific a tion of any c ircuit s hould be
a tte mpted.
2. Disconnect AC power before servicing.
BEFORE RETURNING THE RECEIVER (Fire &
Shock Hazard)
B efore returning the receiver to the us er, perform the following
safety checks:
3. Ins pect all lead dress to make certain that leads are not pinched,
and check that hardware is not lodged between the chassis and
other metal parts in the receiver.
4. Inspect all protective devices such as non-metallic control knobs,
ins ula tion ma te ria ls , ca binet ba c ks , a djus tme nt a nd c ompa rtment
covers or s hields, is olation resis tor-capacitor networks, mechanical
ins ulators , etc.
5. To be sure that no shock hazard exists, check for leakage current in
the following manner.
• P lug the AC cord directly into a 110-240 volt AC outlet.
• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paral-
leled by a 0. 15 F capacitor in s eries with all expos ed metal cabinet
parts and a known earth ground, such as electrical conduit or elec-
trical ground connected to an earth ground.
• Use an AC voltmeter having with 5000 ohm per volt, or higher, sen-
sitivity or measure the AC voltage drop across the resistor.
• C onnect the resis tor connection to all expos ed metal parts having a
return to the c ha s s is (a ntenna , meta l ca binet, s cre w hea ds , knobs
and control shafts, escutcheon, etc.) and measure the AC voltage
drop a cros s the re s is tor.
All checks must be repeated with the AC cord plug connection
revers ed. (If neces s ary, a nonpolarized adaptor plug mus t be us ed
only for the purpose of completing these checks.)
Any reading of 0.74 Vrms (this corresponds to 0.5 mA rms AC.) or
more is excessive and indicates a potential shock hazard which
mus t be c orre cted before returning the monitor to the owner.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
SAFETY NOTICE
Many electrical and mechanical parts in LCD colour television have
special safety-related characteristics.
These characteristics are often not evident from visual inspection, nor
can protection afforded by them be necessarily increased by using
replacement components rated for higher voltage, wattage, etc.
R eplacement parts which have these special safety characteristics are
identified in this manual; electrical components having s uch features
are identified by " " and shaded areas in the R eplacement P arts List
and S chematic Diagrams.
For continued protection, replacement parts must be identical to those
us ed in the original circuit.
The us e of a substitute replacement parts which do not have the same
s a fe ty c ha ra c teris tic s a s the fa ctory re comme nde d re pla c eme nt pa rts
shown in this service manual, may create shock, fire or other hazards.
///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////
S ervice work s hould be performed only by qualified s ervice technicians who are thoroughly familiar with all s afety checks and the
servicing guidelines which follow:
DVM
AC S C ALE
1.5k ohm
10W
TO EXPOSED
ME TAL PAR TS
CONNE CT TO
KNOWN EARTH
GROUND
0.15 µ F
TEST PROBE

LC-32LE260M
1 – 2
[2] PRECAUTION FOR USING LEAD-FREE
SOLDER
PRECAUTIONS FOR USING LEAD-FREE SOL-
DER
Employing lead-free solder
“PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The
alphabetical character following LF shows the type of lead-free solder.
Example:
Using lead-free wire solder
When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause dam-
age or accident due to cracks.
As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 qC, we recommend you to use a dedicated soldering
bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.
Soldering
As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 qC which is higher than the conventional lead solder by 40 qC, and as it has poor
solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be
peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the
steady soldering condition.
Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as
required.
If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.
When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.
Be careful when replacing parts with polarity indication on the PWB silk.
Lead-free wire solder for servicing
Indicates lead-free solder of tin, silver and copper. Indicates lead-free solder of tin, silver and copper.
PARTS CODE PRICE
RANK
PART
DELIVERY DESCRIPTION
ZHNDAi123250E BL J I0.3mm 250g (1roll)
ZHNDAi126500E BK J I0.6mm 500g (1roll)
ZHNDAi12801KE BM J I1.0mm 1kg (1roll)

LC-32LE260M
2 – 1
CHAPTER 2. DIFFERENCES FROM
BASE MODEL
[1] OUTLINE & DIFFERENCES FROM BASE
MODEL
OUTLINE
This model is based on LC-32LE265M and ƉĂƌƟĂůLJ ŵŽĚŝĮĞĚ
For contents not covered in this Service DĂŶƵĂůĂĐĐŽƌĚŝŶŐůLJ ,please refer to
LC-32LE265M Service DĂŶƵĂů
DIFFERENCES FROM BASE MODEL
Ref.No ĞƐĐƌŝƉƟŽŶ Note
PRINTED WIRING BOARD ASSEMBLIES
N MAIN UNIT -
N MAIN UNIT (Philippines) -
N POWER UNIT -
N
LED/IR UNIT
DUNTKG409FM01
DUNTKG463FM01
BASE MODEL LC-32LE265M LC-32LE260M S.MANUAL
DKEYMG486FM01 DKEYMG492FM01
DKEYMG486FM02 DKEYMG492FM02
N
LED/IR
UNIT
-
N LED BAR ( TOP & BOTTOM ) -
NLED BAR ( MIDDLE ) -
CABINET AND MECHANICAL PARTS
1 FRONT CABINET ASSEMBLY -
2 REAR CABINET ASSEMBLY -
RUNTKB284WJZZ
CCABAD142WJ01 CCABAD138WJ01
CCABBC358WJ01 CCABBC376WJ01
DUNTKG463FM01
RUNTKB283WJZZ
SUPPLIED ACCESSORIES
X3 OPERATION MANUAL CHINESE-S
X3 OPERATION MANUAL ENG/ARABIC
X3 OPERATION MANUAL FRE/POR
X3 OPERATION MANUAL INDO
X3 OPERATION MANUAL THAI
X3 OPERATION MANUAL ENG SPC
X3
OPERATION MANUAL
KAZ/RUS
TINS
-
G234WJZZ
TINS
-
G244WJZZ
TINS-G230WJZZ TINS-G240WJZZ
TINS-G229WJZZ TINS-G239WJZZ
TINS-G235WJZZ TINS-G245WJZZ
TINS-G227WJZZ TINS-G237WJZZ
TINS-G228WJZZ TINS-G238WJZZ
TINS-G233WJZZ TINS-G243WJZZ
X3
OPERATION
MANUAL
KAZ/RUS
X3 OPERATION MANUAL FRE
X8 RF ADAPTOR ADD
X9 ERRATA SHEET ADD
PACKING PARTS ( NOT REPLACEMENT )
S1 PACKING CASE -
- TCAUHA617WJZZ
SPAKCH698WJZZ SPAKCH700WJZZ
TINS
-
G234WJZZ
TINS
-
G244WJZZ
TINS-G232WJZZ TINS-G242WJZZ
- QCNCWA969WJZZ

LC-32LE260M
3 – 1
CHAPTER 3. SPECIFICATIONS
[1] SPECIFICATIONS
Specifications
Item Model LC-32LE260M
LCD panel 80cm
Resolution 1,049,088 pixels (1366 g768)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV
Function
TV-Standard PAL: B/G, D/K, I SECAM: B/G, D/K, K/K
1
NTSC: M
Receiving
Channel
VHF/UHF 43.25—863.25 MHz
CATV S1—S41ch (including Hyperband)
TV-Tuning System Auto Preset 99 ch
STEREO/BILINGUAL NICAM: B/G, I, D/K A2 stereo: B/G
º671:Vº671:HselgnagniweiV
Audio amplifier/Speakers 5 Wg2 / 4 g7 cm 2pcs
Terminals Antenna input UHF/VHF 75 qDIN type
INPUT 1 / INPUT 2 HDMI (HDMI input, PC input)
INPUT 3 VIDEO in, AUDIO in, COMPONENT in
INPUT 4 VIDEO in, AUDIO in
OUTPUT AUDIO out, Headphone ( 3.5 mm stereo)
USB USB
USB device/File system USB Memory / FAT/FAT32
Photo file format JPEG (.jpg) (DCF2.0 compliant). Progressive format jpeg files are not supported.
Music file format
(Files may not be playable
depending on the bitrate)
MP3 (.mp3) Bitrate: 32 k, 40 k, 48 k, 56 k, 64 k, 80 k, 96 k, 112 k, 128 k, 160 k,
192 k, 224 k, 256 k, 320 kbps
Sampling frequency: 32 k, 44.1 k, 48 kHz
/iahT/naisreP/naissuR/eseugutroP/hcnerF/cibarA/esenihCdefiilpmiS/hsilgnEegaugnalDSO
Vietnamese/Indonesian
Power Requirement AC 110—240 V, 50/60 Hz
Power Consumption 41 W (1.0 W Standby)
Dimensions without stand 739 (W) g440 (H) g93 (D) mm
with stand 739 (W) g482 (H) g174 (D) mm
)dnatshtiw(gk5.6/)dnatstuohtiw(gk7.5thgieW
Operating Temperature 0°C — 40°C
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.

LC-32LE260M
4 – 1
CHAPTER 4. ADJUSTMENT
[1] ADJUSTMENT
1.MAIN SOFTWARE PACKAGE
egakcaPerawtfoSledoM
LC-32LE260M (Asia) Peach_ATV_Asia_Pack15_vXXX.bin
LC-32LE260M (SPC) Peach_ATV_Asia_Pack16_vXXX.bin
Main Software Filename : XXX is Software version
If any changes of software, will be informed by MARUHEN.
This adjustment page is only covering MAIN SOFTWARE PACKAGE & FACTORY SETTING,
for contents not covered in this page ,please refer to the LC-32LE265M Service Manual .
2. FACTORY SETTING
Model Name Factory Setting
Key Name
Remote Control
Code
S-System Setting OSD Language
Setting
A3KLG26SZ/Q/J/I/Y/B/N/M M-Setting 100000001010110 B/G ENGLISH
A3KLG26SP P-Setting 100000001011110 M ENGLISH
**Please do inspection for A3KLG26SPusing NTSC signal.

LC-32LE260M
5 – 1
CHAPTER 5. TROUBLESHOOTING
TABLE
[1] TROUBLESHOOTING TABLE
[1] TROUBLESHOOTING TABLE
No power (front LED failure to light up) or no startup (front LED failure to turn from red to green)
Is the AC cord connector tightly connected to the set? NO Reconnect the AC cord tightly and turn on the power again.
YES
Are the wire harnesses and other cables properly connected in
the set?
NO Reconnect the wire harnesses and other cables properly in the
set.
YES
Is there 7.5V from IC9605 & IC9603 NO Check the AC_CTRL Line (90) of IC3301 , IC3101,X 3301
YES
Are the DC/DC converter outputs and the output voltages along
the control lines as specified?
NO Check the DC/DC converters and the control lines. Replace
defective parts as required.
1) D+5.0V (I C9601)
2) D+3.3V ( IC9602)
3) D+1.26 V (I C9604)
4) D+3.3V (IC9603)
5) D+1.8V (IC9606)
6) D+2.5 (IC9608)
crystal oscillation
YES
Replace IC3301

LC-32LE260M
5 – 2
With [RF] signal input No video onscreen (1)
No video in the UHF/VHF reception
Is there IF output from the tuner pin( 8 ) of TU1101 as specified? NO Check TU1101 and its peripheral circuits.
YES
Is there VIF input at pin 51 & 52 of IC3301? NO Check the circuit between TU1101 & IC3301.
YES
Are there the signal outputs of IC3301(pin 33) ? NO Check IC3301 and its peripheral circuit.
YES
With <Video> signal input No video onscreen (3)
No external input video onscreen <INPUT 3>
Is INPUT 3 selected on the input select menu screen? NO Select INPUT 3 on the input select menu screen to pick up the
right input signal.
YES
Is there the video signal input at pin (31 ) of IC3301? NO Check the line between pin (7) of TL509 and pin (31) of IC3301.
YES
Are there LVDS signal outputs of IC3301 at pin 61-64 and pin
66-71
NO Check IC3301 and its peripheral circuits.
YES
Check LVDS cable, LCD controller (incl. panel) and their periph-
eral circuits.
Are there LVDS signal outputs from IC3301 at pin 61-64
and pin 66-71
?
NO Check IC3301 and its peripheral circuit.
Check LVDS cable, LCD controller (incl. panel) and their periph-
eral circuits.
YES

LC-32LE260M
5 – 3
With <Component> signal input No video onscreen (2)
No external input video onscreen <INPUT 2>
Is INPUT 2 selected on the input select menu screen? NO Select INPUT 2 on the input select menu screen to pick up the
right input signal.
YES
Are there the Y, Pb and Pr signal inputs at pins (22), (24) and
(26) of IC3301 respectively?
NO Check the line between pins (10)/(11)/(12) of TL504 ,TL505,
YES
Is input waveform of IC3301 normal?
Y=(24)pin , Pb=(22) pin, Pr=(26) pin
NO
Check IC3301 and its peripheral circuits.
YES
Check LVDS cable, LCD controller (incl. panel) and their periph-
eral circuits.
With <HDMI> signal input No video onscreen (4)
No external input video onscreen <INPUT 1>.
Is INPUT 1 selected on the menu screen? NO Select INPUT 1 on the input select menu screen to pick up the
right signal input.
YES
Are there signal outputs from SC1501 to IC3301? NO Check peripheral circuits between SC1501 and IC3301.
YES
NO Check IC3301 and its peripheral circuits.
YES
Check LVDS cable, LCD controller (incl. panel) and their periph-
eral circuits.
TL506 and pin (22),(24),(26)
Check the line between pins (10)/(11)/(12) of TL504 ,TL505,
TL506 and pin (22),(24),(26)
YES
Are the LVDS signal output from IC3301 at pin 61-64
and pin 66-71 ?
NO
Are there LVDS signal outputs of IC3301 at pin 61-64 and pin
66-71

LC-32LE260M
5 – 4
No audio heard (1)
No sound in the UHF/VHF reception.
Is the IF output from the tuner pin (8) of TU1101 as specified? NO Check TU1101 and its peripheral circuits.
YES
Is there the I2C signal input at pins (55), (56) of IC3301? NO Check IC3301 and its peripheral circuits.
YES
Is there audio signal intput at pin(4),(10) of IC1701? NO Check connection between IC3301 and IC1701 and its
peripheral circuits.
YES
Is the L-ch audio signal output at pin(26),(27),(29),(30) of IC1701 NO Check IC1701 and its peripheral circuits.
Is the R-ch audio signal output at pin(20),(21),(23)(24) of IC1701
YES
Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of
P1701 normal?
NO Check circuit between IC 1701 & P1701.
YES
Check speakers and their peripheral circuits.
normal ?
normal ?

LC-32LE260M
5 – 5
No audio heard (2)
No external audio heard
<INPUT 2>
Is there the L-ch audio signal input from pin (30) of input terminal
TL511 to pin (39) of IC 3301?
Is there the R-ch audio signal input from pin (26) of input terminal
TL510 to pin(40) of 3301?
<INPUT 3>
Is there the L-ch audio signal input from pin (20) of input terminal
TL508 to pin (35) of 3301?
Is there the R-ch audio signal input from pin (15) of input terminal
TL507 to pin (36) of IC3301?
YES
Is there the I2C signal input at pin (55), (56) of IC3301? NO Check IC3301 and its peripheral circuits.
YES
Is there audio signal input at pin(4),(10) of IC1701? NO Check connection between IC3301 and IC1701 and its periph-
eral circuits.
YES
Is the L-ch audio signal output at pin(26),(27),(29),(30)of NO Check IC1701 and its peripheral circuits.
Is the R- ch audio signal output at pin(20),(21),(23),(24) of IC1701
YES
Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of
P1701 normal?
NO Check circuit between IC1701 & P1701 .
YES
Check speakers and their peripheral circuits.
IC1701
normal ?

LC-32LE260M
5 – 6
No audio heard (3)
No HDMI sound heard. <INPUT 1>
(*INPUT 1 is digital audio.)
Does the HDMI image appear onscreen? NO Refer to “<INPUT 1> in No external input video onscreen
(HDMI)”.
YES
No audio output from <INPUT 1> NO Check the EDID.
YES
Are waveforms input in to the pins of IC3301 normally? NO Check peripheral circuits IC3301.
YES
Is there audio signal input at pin (4),(10) of IC1701 NO Check connection between IC3301 and IC1701 and its periph-
eral circuits.
YES
Is the L-ch audio signal output at pin(26),(27),(29),(30) of IC1701 NO Check IC1701 and its peripheral circuits.
YES
Are the audio signal L-ch and R-ch output at (1)/(2) and (3)/(4) of
P1701 normal?
NO Check circuit between IC1701 & P1701.
YES
Check speakers and their peripheral circuits.
normal ?
Is the R-ch audio signal output at pin (20),(21),(23),(24) of IC1701
normal ?

LC-32LE260M
5 – 7
No audio heard (4)
No sound from the HDMI sound input terminal.
(INPUT 1 analog audio)
YES
Is there the L-ch audio signal input from pin (2) of external input
terminal J501 (HDMI AUDIO IN) to pin (28) of IC3301?
Is there the R-ch audio signal input from pin (3) of external input
terminal J501 (HDMI AUDIO IN) to pin (29) of IC3301?
YES
Are I2S signal output from the pins (42), (43) of IC3301 normally? NO Check peripheral circuits of IC3301.
YES
Is there audio signal input at pin(22),(32) of IC1702 NO Check connection between IC3301 and IC1702 and its periph-
eral circuits.
YES
Is the L-ch audio signal output at pin ( 10 ),(11),(16),(17) of NO Check IC1702 and its peripheral circuits.
Is the R- ch audio signal output at pin(2),(3),(8),(9) of IC1702
nor mal?
YES
Are the audio signal L-ch and R-ch output at (3)/(4) and (1)/(2) of
P1702 normal?
NO Check circuit between IC1702 & P1702.
YES
Check speakers and their peripheral circuits.
IC1702 normal ?

LC-32LE260M
6 – 1
CHAPTER 6. SYSTEM BLOCK DIA-
GRAM
[1] SYSYTEM BLOCK DIAGRAM
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
㼀㻱㻹㻼㻌㻿㻱㻺㻿㻻㻾
㼀㻴㻟㻟㻜㻝
㻯㻻㻺㼀㻾㻻㻸 㻿㼃
ࠉࠉࠉࠉ
㼀㻴㻟㻟㻜㻝
㻾㻴㻙㻴㼄㻭㻜㻡㻣㼃㻶㻽㼆
㼄㼀㻭㻸㻔㻞㻣㻹㻴㼦㻕
㼄㻟㻟㻜㻝
㻾㻯㻾㻿㻯㻭㻞㻟㻣㼃㻶㻽㼆㼅
㻯㻻㻺㼀㻾㻻㻸
㻌
㻿㼃
㻿㻝㻜㻝㻌㼪㻌㻿㻝㻜㻣
K
EY 0
K
EY 1
T
㻾㻱㻿㻱㼀㻌㻵㻯
㻵㻯㻟㻟㻜㻞
㼂㻴㻵㻼㻿㼀㻤㻠㻞㻥㼁㻙㻝㼅
+3.3V
K
EY 2
㻿㻭㻾㻞
㻵㻾㻌
K
㻳㻼㻵㻻㼇㻞㼉㻛㻿㻭㻾㻜㻛㻿㻭㻾㻝 㻳㻼㻵㻻
㻵㻾㻌㻾㼑㼏㼕㼑㼢㼑㼞
㻾㻹㻯㻝㻜㻝
㻸㻱㻰
㻰㻝㻡㻟㻛㻰㻝㻡㻞
P151
5PIN
S
LED_IR PWB
P101
5PIN
S
K
XIN/XOU
T
㻾㻛㻯
R LED & GLED
㻾㻱㻿㻱㼀
K
㻌
㻵㼚㼠㼑㼞㼒㼍㼏㼑
㻻㻲㻸
㻮㻸㼋㻱㻾㻾
A C
I
㻾㻹㻯㻝㻜㻝
㻲㻾㻻㻹㻺㻳㻼㻵㻻㼇㻞㼉
㻼㻻㼃㻱㻾
㼁㻺㻵㼀
㼀㼁㻺㻱㻾
㼀㼁㻝㻝㻜㻝
RTUNQA073WJQZ
㻵㻞㻯
㻵㻹
㻵㻞㻯㻌㻭㻰㻰㻾㻱㻿㻿䠖㻯㻜
㻵㻲㻌
㻹㻭㼀㻯㻴㻵㻺㻳㻌
㻯㻵㻾㻯㼁㻵㼀
㻵㻼
㻿㼀㻮
I
RESET
㻗㻟㻚㻟㼂
㻾㻯㻌
㻺㻱㼀㼃㻻㻾㻷
㻲㻾㻻㻹㻌㻯㻼㼁㻌
㻼㻟㻤㻜㻞
㻝㻟㼜㼕㼚
IF+
IF-
IF_IN+
IF_IN-
㻗㻞㻚㻡㼂
㻝 㻞㻢㼂
㻵㻞㻯
㻴㻰㻹㻵 㻝
㻵㻺㻼㼁㼀㻝
㻝㻟㻚㻡㼂
㻗㻟㻚㻟㻜㼂
TO PANEL
㻿㼀㻮㼅㻌㻯㼀㻾㻸
I2C(HDMI)
lk(2)
㻗㻞㻚㻡㼂
㻝
㻚
㻞㻢㼂
㻝㻞㻚㻜㼂
ࠉ
㻹㻿㼀㻣㻤㻟㻝㻸㻹㻷
㻴㻰㻹㻵
㻌
㻝
㻿㻯㻟㻤㻜㻞
㻽㻿㻻㻯㼆㻭㻟㻞㻝㼃㻶㻽㼆㼅
㻴㻰㻹㻵㻌㻵㻺㻝
㻴㻰㻹㻵㻌㻰㻰㻯㻝
㻴㻻㼀㻼㻸㼁㻳
㻗㻡㻚㻜㼂
c
lk(2)
data(6)
HPD0_IN
I2C(HDMI)
㻵㻺㻼㼁㼀㻞
㻹㻿㼀㻣㻤㻟㻝㻸㻹㻷
㻾㼑㼒㻌㻺㼛㻚㻵㻯㻟㻟㻜㻝
㻾㻴㻙㻵㼄㻰㻢㻟㻞㼃㻶㻽㼆㻽㻌㻌㻌㻌
㻮㻸㻌㻿㼁㻼㻼㻸㼅㻌
㻴㻰㻹㻵㻌㻞
㻿㻯㻟㻤㻜㻟
㻽㻿㻻㻯㼆㻭㻟㻞㻝㼃㻶㻽㼆㼅
㻴㻰㻹㻵㻌㻵㻺㻞
㻴㻰㻹㻵㻌㻰㻰㻯㻞
㻴㻻㼀㻼㻸㼁㻳
clk(2)
data(6)
HPD0_IN
㻵㻺㻼㼁㼀㻞
㻵㻺㻼㼁㼀㻟㼋㼅㻛㻯㼂㻮㻿㻘㻼㼎㻘㻼 㻿㻻㻳㻵㻺㻝㻛㻳㻺㻝㻼㻛㻯㼂㻮㻿㻝㼋㻾㻵㻺㻝㻼㻛㻮㻵
㻵㻺㻼㼁㼀㻟㻌㻸㻛㻾
㻯㼂㻮㻿㻜
㻸㻵㻺㻱㻵㻺㼋㻸㻜㻛㻾㻜
㻵㻺㻼㼁㼀㻌㻟
㻯㻻㻹㻼㻻㻺㻱㻺㼀㻛㻭㼁㻰㻵㻻㻌㻵㻺
㻵㻺㻼㼁㼀㻌㻠㻌
㻯㼂㻮㻿㻛㻭㼁㻰㻵㻻㻌㻵㻺
㻵㻺㻼㼁㼀㻠㼋㻯㼂㻮㻿
㻵㻺㻼㼁㼀㻠㻌㻸㻛㻾
㻮㻸㼋㻻㻺
㼀㻾㻭㻺㻿㻵㻿㼀㻻㻾㻌
㻿㼃
㻔㻲㻻㻾㻌㼃㼄㻳㻭㻌
㻻㻺㻸㼅㻕
㻳㻼㻵㻻㼇㻟㼉
㼁㻭㻾㼀㻌㻶㻭㻯㻷
㻶㻟㻟㻜㻝
㻽㻶㻭㻷㻶㻭㻜㻞㻣㼃㻶㼆㼆 㼁㻭㻾㼀
㼁㻿㻮
㻶㻟㻤㻜㻝
㻽㻿㻻㻯㼆㻭㻟㻝㻥㼃㻶㻽㼆
㼁㻿㻮㻌㻵㻲
㻰㻭㼀㻭㻌㻭
㻔
㻤
㻕
㻯㻸㻷㻌㻭
㻔
㻞
㻕
㻼㻭㻺㻱㻸
㻟㻞㻎㼃㼄㻳㻭
㻸㼂㻰㻿㻌
㻟㻞㻎㻦㻌㻤㻌㼎㼕㼠
㻯㻸㻷 㻭㻔㻞㻕
㻰㻭㼀㻭㻌㻭
㻔
㻤
㻕
㻼㻺㻸㻝㻞㼂㻌
㻸㼃
㻿㻯㻟㻤㻜㻝
㻟㻜㼜㼕㼚㻌
㻲㻲㻯
㻵㻞㻯
㻽㻿㻻㻯㼆㻭㻟㻝㻥㼃㻶㻽㼆
㻡㻜㻛㻢㻜㻴㼦
㻡㼂㻌㻿㼃㻵㼀㻯㻴
㻽㻡㻜㻝㻌㻒㻌㻽㻡㻜㻞
㼂㻿㻷㼀㻭㻝㻡㻟㻡㼀㻗㻙
HP_IN
+5.0V
㻲㻾㻻㻹㻌㻯㻼㼁㻌㻿㼀㻮㼅㻌㻯㼀㻾㻸
㻸㻵㻺㻱㻻㼁㼀㼋㻸㻝㻛㻾
㻝
㻴㻼㻌㻭㻹㻼
㻵㻯㻡㻜㻝
㼂㻴㻵㼀㻼㻭㻢㻝㻟㻥㻭㻙㻝㼅
㻴㻼㻌㻶㻭㻯㻷
㻶㻡㻜㻟
㻽㻶㻭㻷㻶㻭㻜㻟㻜㼃㻶㻽㼆
㻳㻼㻵㻻 GPIO[65] 㻳㻼㻵㻻㼇㻠㼉
LINE OUT L LINE OUT R
HP
_
L
HP
_
R
㻳㻼㻵㻻㼇㻢㼉
GPIO[7]
+3.3V
㻿
㼀㻮㼅㻌㻯㼀㻾㻸
㻸㻵㻺㻱㻻㼁㼀㼋㻸㻜㻛㻾㻜
㻿㻼㻵
㻿㻼㻵㻌㻵㻲
㻌㻹㼁㼀㻱
㻼㻻㻼㻌
㻺㻻㻵㻿㻱㻌
㻯㻛㻹
HP MUTE
㻾㻱㻿㻱㼀㻌㻵㻯
㻵㻯㻝㻣㻜㻞
㻿
㻿㻼㻵㻌㻲㻸㻭㻿㻴㻌
㼃㻾㻵㼀㻱
㻿㻼㼋㻸
㻿㻼㼋㻾
㻿㻼
UR+13.5V
+3.3V
㻭㼁㻰㻵㻻㻌㻭㻹㻼
㻵㻯㻝㻣㻜㻝
㼂㻴㻵㼀㻼㻭㻟㻝㻟㻜㻰㻙㻝㼅
㻿㻼
㻼㻝㻣㻜㻞㻝
㻠㼜㼕㼚
㻿㻼㼋㻸
㻹㻭㻵㻺
㻿㻼㼋㻾
㻿㻼㻵㻌㻲㻸㻭㻿㻴
㻵㻯㻟㻝㻜㻝
㼂㻴㻵㼃㻞㻡㻽㻟㻞㻮㼂㻙
㻝㼅㻌㻟㻞㻹㻮㼕㼠 TO DC DC CONVERTER, TUNER
LDO. USB, FLASH & HP AMP.
ࠉࠉࠉࠉࠉࠉࠉ
㻿㻼㼋㻸
㻿㻼㼋㻾
㻿㻼㼋㻾
㻤䃈㻡㼃
㻿㻼㼋㻸
㻤䃈㻌㻡㼃

LC-32LE260M
7 – 1
CHAPTER 7. PRINTED WIRING
BOARD ASSEMBLIES
[1] MAIN UNIT
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
MAIN UNIT SIDE-A

LC-32LE260M
7 – 2
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
MAIN UNIT SIDE-B

LC-32LE260M
7 – 3
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
(QKITPG492WJTN)
USB
HDMI
SP
HP
KG492WE
RED RED WHITE YELLOW
NEERGEULB
T2
R
Rw
wY
BG
WHITE
RED
LED
R
QPWBNG492WJZZ
POW
LW
LEFT
DOWN
UP
1
7
RIGHT
POWER
HAND
CHECKER
WRITER
94V-0
HDMI
SMT-A
C1701
C1731
SC3801
30
1
14
P1701
15
P101
P3802
1
13
P3301
FDC1
FDC2
FDC3
FDC4
IC3301
1
38
39
64
65
102
103 128
IC501
1
458
9
12
13
16
J506
J502
J503
J3301
J3801
L1701
L1702
L1703
L1704
L9601
L9602
a
SC3802
1
19
SC3803
1
19
S101
S102
TU1101
X3301
ABCDEFGH
C1501
R3802
Q1501
R3806
Q1502
R3807
Q1503
Q1504
R3809
Q1505
TU1101
Q1506
C1701
R3810
R3811R3812 R3813
R1103
R3814
Q1704
R1104
R3815
R1105
R3816 R1106
R3817 R3818
R3819
R1109
UL1
C9607
C9608
R1110
R1111
R1112
R1113
R1114
D1501
D1502
D1503 D1504
R1501
P101
R1502
R1503 R1504
C9614
R1505
C9615
R1506
R1507 R1508
R1509
R1702
R1510
R1511 R1512 R1513
R1514
R1515
C1731
R1516
C1732
C9626
IC1702
C9627
R1517
R1518
R1519
C1736
C1737
C1738
C1739
R1520
R1521 R1522
R1717
R1523
R1524
C1740
R1525
C1741
R1526
C1742
R1527
C1743
R1528
C1744
R1529
R1720
R9617
R1530 R1531
R1532
R1533
R1534
R1535
R1536
R1537
R9620
R1540
R9628
R1734
R1541
R1735
R1736
R1737
R1738
R1739
R9631
R1742
UR1
LF1
P3301
Q502
Q503
C3301
C3302
C3303
Q3301
C3305
Q3302
C3307 C3308
C3309
C3310
C3311
C3312
C3313
C3315
C3316
C3317
C3318
C3319
J3801
C3321
C3322
C3325 C3328
VA501
R3301
C3329
R3302
R3303
VA504
R3304
VA505
R3305
R3306
VA507 VA508
R3308
R3309
IC3301
C3331
IC3302
C3334
R3310
VA510 VA511
R3311
C3339
VA512
VA513
R3313
R3314
R3315
R3316
R3317
C3340
R3318
FB3801
R3319
TH3301
FB3802
FDC1
C3345
C3346
FDC2
FDC3
R3320
FDC4
R3321
R3322 R3323
R504R505
FB1101
R3329
R506
R507
R509
SC3801
R3331
SC3802
R3332
SC3803
R3333
R510
R511 R512
R3336R3337
R3338
R516 R517
R519 R520
R521
R522
TEST3
R523
C501
C502 C503
C504 C505
C506
C507
C508 C509
S101
S102
C510
C511
C512
C513 C514
L1701
L1702
L1703
L1704
L9601
L9602
C7819
P3802
J3301
R7831
R7835
X3301
IC501
C3801
C3802
Q3801
Q3802
FB3302
FB3309
FB3310
P1701
C1105
C1108
C1109
J502
J503
C1110 C1111
C1112
J506
C1115
MAIN UNIT (CHIP SIDE-A)

LC-32LE260M
8 – 1
CHAPTER 8. SCHEMATIC DIAGRAM
[1] DESCRIPTION OF SCHEMATIC DIA-
GRAM

1.VOLTAGEMEASUREMENTCONDITION:
1) ThevoltagesattestpointsaremeasuredonexclusiveACadaptorandthestablesupplyvoltageofAC110-240V.Signalsarefe dbyacolourbarsignal
generatorforservicingpurposeandtheabovevoltagesaremeasuredwitha20kohm/Vtester.
2.INDICATIONOFRESISTOR&CAPACITOR:
RESISTOR
1) Theunitofresistance" "isomitted.
(K=k =1000 ,M=M ).
2) Allresistorsare±5%,unlessotherwisenoted.
(K=±10%,F=±1%,D=±0.5%)
3) Allresistorsare1/16W,unlessotherwisenoted.
CAPACITOR
1) Allcapacitorsare F,unlessotherwisenoted.
(P=pF= F).
2) Allcapacitorsare50V,unlessotherwisenoted.
CAUTION:
Thiscircuitdiagramisoriginalone,thereforetheremayb
easlight
differencefromyours.
SAFETYNOTES:
1) DISCONNECTTHEACPLUGFROMTHEACOUTLET
BEFOREREPLACINGPARTS.
2) SEMICONDUCTORHEAT SINKSSHOU LDBEREGARDEDAS
POTENTIALSHOCKHAZARDSWHENTHECHASSISIS
OPERATING.
IMPORTANTSAFETYNOTICE:
PARTSMARKEDWITH" " ( )AREIMPORTANT
FORMAINTAINING THESAFETYOFTHESET.BESURETO
REPLACETHESEPARTSWITHSPECIFIEDONESFORMAIN-
TAININGTHESAFETYANDPERFORMANCEOFTHESET.

LC-32LE260M
8 – 2
[2] MAIN UNIT
A
C
B
D
E
F
G
H
2 109
8
7
6
54
3
1
OFL BLERR
OFL
MF
MF
BLERR
C3801
10u
Q3802
KRC102S
Q3801
KTA1535T
R3806
3.3K TQ
R1533
1K
R1535
47K
D1504
DB2S310L
D1503
DB2S310L
Q1504
LTC044EEB
R1534
47K
Q1505
LTC044EEB
R1536 47K
R504
10K C3329 0.047u
R3323
68
R3311
33
C510
2.2u
KZA691WJ
R509
10K
R508
75
R3313
33
C3316 0.047u
R505
12K
R502
75
R512
12K
C3319 0.047u
R501
75
C504
2.2u
KZA691WJ
C507
2.2u
KZA691WJ
R506
10K
J506
FA068WJQZ
1234
C3305
0.047u
R3318 68
R3322 33
C3334
0.047u
R507
12K
R3316 33
R503
75
R510
12K
C501
2.2u
KZA691WJ
C3308
0.047u
R511
10K
C3328
10u
FB3310
A192WJ
X3301
SCA239WJQZ
24MHz
1
2 34
C3346
12P
C3345
12P
R3101
4.7K
D3101
DB2S310L
R3102
10K
R3303
4.7K
Q3301
LTC014EEB
VS
R3306
22K
R3307
1K
TU1101
NQA073WJQZ
1
NC
2
RESET
3
3.3V
4
NC
5
IFAGC
6
NC
7
NC
8
AIF+
9
AIF-
10
SCL
11
SDA
0.1uH
L1101
R516
100K
R1737
33
R517
100K
C1744 1000P
R513
33K
C1737
0.1u
R1738
3.9K
Q1704
LTC044EEB
R1736
33
R1739
100K
C1739
1000P
R1735
1.5K
C1741
1000P
TPA6139A
1
OUTL
2
GND
3
GND
4
/MUTE
5
VSS
6
CN
7
NC
8
CP
9
VDD
10
GND
11
GAIN
12
OUTR
13 -INR
14 NC
15 NC
16 -INL
GND
J503
JA030WJQZ
4135726
TL1706
R1734
7.5K
C1718
330P
C1721
1000P
C1726
0.22u
R1714
10
TW
R1713
10
TW
C1731
100u
R1718
10
TW
C1711
0.1u
C1705
0.22u
R1726
10 TW
R1711
10
TW
C1720
0.1u
C1714
330P
R1723
10
TW
C1708
1000P
R1722
10
TW
C1713
0.22u
C1717
0.22u
R1708
10
TW
C1701
100u
C1707
0.1u
C1712
1000P
C3302
0.01u
TH3301
HXA057WJQZ
R3308
2.7K
R103
8.2K
R104
12K
R9602
100
3416C25N
1
Vin
2
GND
3
On
4
NC
5
Vout
C9624
1u
KZA520WJQZ
C9601
10u
FB9602
A192WJ
FB3302
A192WJ
FB3301
A192WJ
C3318
0.1u
C9623
10u
KZA510WJPZ
FB3304
A192WJ
R519
5.1
R520
5.1
R3331
200K
R3333
200K
R3324
200K
R3330
200K
R3305
1K
R33041K
R3301
33K
R3302
33K
R9609
82
C9607
10u
C9603
10u
R9604
56K
F
R9605
12KF
C9602
10u
R9606
10K F
C9610
10u
C9609
10u
C9614
10u
R9616
82
R1113
100
Q502
KTA1535T
E
C
B
C515
0.01u
C1112
10u
C1702
1u
C1728
1u
C1715
1u
C1709
1u
C1722
1u
C1738
10u
C3301
0.01u
C3306
0.1u
C3312 1000P
C3315
0.1u
C3317
0.1u
C3337
1000P
C3338
1000P
C3340
1000P
C3339
1000P
FB1101
A191WJ
R3338
100
R3336
100
R3337
100
R9628
10K
C3347
22P
TL3305
R3340
22
R1742
10K
J502
ZA127WJ
12435 768910
1112
R1541
100
R1540
100
R3329
470
TL3801
3416C25N
1
Vin
2
GND
3
On
4
NC
5
Vout
C9617
1u
KZA520WJQZ
FB9601
A192WJ
C9616
10u
KZA510WJPZ
R9619
1
TWF
1/2W
C9621
10u
KZA176WJ
C9619
4.7u
KZA931WJQZ
C9618
4.7u
KZA931WJQZ
R9601
1
TWF
1/2W
TL9610
BD00IC0E
1
VOUT
2
FB
3
GND
4
NC
5
EN
6
NC
7
NC
8
VCC
R3309
1K
R3310
2.7K
C9622
10u
W25Q32FV
1
CS
2
SO/SIO1
3
WP
4
GND
5
SI/SIO0
6
SCLK
7
HOLD
8
VCC
R3317
4.7K
R514
1K
FB3303
0254TA
C3304
2.2u
FB3305
0254TA
C3320
1u
C3332
2.2u
FB3306
0254TA
FB3307
A367WJQZ
C3326
10u
FB3308
0254TA
FB3309
0254TA
FB3311
0254TA
R3314 33
R9614
330K
F
R9607
300K
F
C3313
10u
C1115
10u
BD95835EFJ
1
BST
2
VIN
3
SW
4
GND
5
FB
6
RT
7
EN
8
SS
BD95835EFJ
1
BST
2
VIN
3
SW
4
GND
5
FB
6
RT
7
EN
8
SS
P1701
NB092WJ
1
Rch+
2
Rch-
3
Lch-
4
Lch+
R1717
0
R1720
0
IXD632WJQZ
1
TMDS1CLK-
2
TMDS1CLK+
3
TMDS1DATA0-
4
TMDS1DATA0+
5
AVDDMOD
6
TMDS1DATA1-
7
TMDS1DATA1+
8
HDMI1SDA
9
TMDS1DATA2-
10
TMDS1DATA2+
11
HDMI1SCL
12
ARC
13
AVDD12
14
PCHSYNC
15
PCB
16
pcSOG
17
PCG
18
VideoGND
19
PCR
20
PCVSYNC
21
AVDDADC25
22
COMPPb
23
COMPSOG
24
COMPY
25
COMPGND
26
COMPPr
27
VSYNC
28
AVDDADC33
29
CVBS3
30
CVBS1
31
CVBS2
32
CVBSGND
33
CVBSOUT1
34
AVDDAU33
35
CVBSL
36
CVBSR
37
AUREFM
38
AUVAG
39
COMPL
40
COMPR
41
PCAUDL
42
PCAUDR
43
SPOUTL
44
SPOUTR
45
HP/LINEOUTL
46
HP/LINEOUTR
47
XOUT
48
XIN
49
AVDDDMPLL
50
AVDDREF
51
VIFP
52
VIFM
53
RFAGC
54
VDDIOCMD
55
SCL
56
SDA
57
AVDDPLL
58
VDDC
59
RXE4P
60
RXE4N
61
RXE3P
62
RXE3N
63
RXECP
64
RXECN
65
AVDDMOD
66
RXE2P
67
RXE2N.
68
RXE1P
69
RXE1N
70
RXE0P
71
RXE0N
72
STB
73
HDMI2Detect
74
RXO3P
75
RXO3N
76
RXOCP
77
RXOCN
78
RXO2P
79
RXO2N
80
AVDDMOD
81
RXO1P
82
RXO1N
83
RXO0P
84
RXO0N
85
VDDC
86
SPMUTE
87
HPMUTE
88
HPDETECT
89
TUNERRESET
90
ACCTRL
91
PANELPOW
92
POWERON/OFF
93
HDMI1Detect
94
LAMPERR
95
SPIWP
96
LEDG
97
SPICLK
98
SPIDI
99
SPICS
100
SPIDO
101
USBDATA-
102
USBDATA+
103
AVDDMOD
104
GND
105
OFL
106
LEDR
107
UARTRx
108
UARTTx
109
VDDIODATA
110
KEY1
111
KEY2
112
THERM
113
R/C
114
MotionFlow
115
CPURESET
116
GND
117
HOTPLUG2
118
TMDS2CLK-
119
TMDS2CLK+
120
TMDS2DATA0-
121
TMDS2DATAO+
122
HDMI2SDA
123
TMDS2DATA1-
124
TMDS2DATA1+
125
HDMI2SCL
126
TMDS2DATA2-
127
TMDS2DATA2+
128
HOT PLUG1
KA037WJ
POW
S101
2
43
1
P101
NB150WJ
DELOTAR
1
D+3.3V
2
GND
3
R/C
4
LEDG
5
LEDR
R105
10K
R1511 1K
Q1501
LTC044EEB
Q1502
LTC044EEB
R1514 47K
R1532 0 R1531 0
R1530 0
R1529 0
R1528 0
R1527 0
R1526 0
R1525 0
R1513 47K
R1512 47K
Q1503
LTC014EEB
D1501
DB2S310L
D1502
DB2S310L
R1517
10K
R1503 0
R1504 0 R1505 0
R1506 0
R1507
0
R1508
0
R1509 0
R1510 0
R1521
100
R1520
100
R101
8.2K
C3310
0.1u
Q503
2SC3928AR
P3802 NB101WJ
1
PNL+12V
2
UR+13.5V
3
UR+13.5v
4
UR+13.5V
5
GND
6
GND
7
GND
8
GND
9
PSON
10
LAMPERR
11
PWM(OFL)
12
STB
13
MotionFlow
C9627
10u
R9630
10K
J3801
ZA319WJQZ
1
+5V
2
USBDN
3
USBDP
4
GND
SC3802 ZA321WJQZ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
SC3803 ZA321WJQZ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
C38021u
Q1506
LTC014EEB
R1518
10K
PST8429U
1
GND
2
VDD
3
CD
4
OUT
PST8429U
1
GND
2
VDD
3
CD
4
OUT
C1101
0.1u
C1102
0.1u C1103
22P
C1105
22P
C1104
180P
C1106
0.1u
C1107
0.1u
C1108
0.01u
C1113
0.1u
C1114
1000P
C1703
0.1u
C1704
1000P
C1706
330P
C1716
1u
C1719
1u
C1724
0.1u
C1725
1000P C1727
330P C1729
0.1u
C1730
1000P
0.22u
C1732
0.22u
C1736
C1740
1u
C1742
1u
C3101
0.1u
C3303
0.1u
C3307
0.1u
C3309
0.01u
C3311
0.1u
C3321
1u
C3322
0.1u
C3324
0.1u
C3330
0.1u
C3331
0.1u
C7819
0.1u
C9604
330P
C9605
0.1u
C9606
0.1u
C9608
0.1u
C9611
390P
C9612
0.1u
C9613
0.1u
C9615
0.1u
C9620
1u
R521
47K
R522
10K
R523
1K
R1101
180
R1102
180
R1103
4.7K
R1104
4.7K
R1105
100
R1106
100 R1107
33
R1108
33
R1701
4.7K
R1716
100K
R1721
100K
R1725
100K
R1705
0
R3315
4.7K
R3319
4.7K
R3320
4.7K
R3802
100K
R3807
0
R7831 100
R7835
100
*R7834 0
R9608
75K
R9610
100K
R9611
33K
F
R9612
390 F
R9613
9.1K
F
R9615
62K
R9617
100K
R9618
12K
F
R9621
1.5K
F
R9622
22K
F
10uH
L9601
PB014WJQZ
10uH
L9602
PB014WJQZ
L1704
PB489WJQZ
L1703
PB489WJQZ
L1702
PB489WJQZ
L1701
PB489WJQZ
R1715
100K
R1719
10 TW
C1733
0.22u
C1710
0.22u
C1734
0.22u
C1723
0.22u
Q3302 RN4983
123
456
C1735
1u
J3301
JA039WJQZ
1 2 3
TPA3020D
1
SD
2
FAULT
3
LINP
4
LINN
5
GAIN0
6
GAIN1
7
AVCC
8
AGND
9
GVDD
10
PLIMIT
11
RINN
12
RINP
13
NC
14
PBTL
19
PGND
18
OUTPR
28
PVCCL
24
PGND
15
PVCCR
21
BSNR
17
BSPR
22
BSNL
23
OUTNL
25
OUTPL
20
OUTNR
16
PVCCR
26
BSPL
27
PVCCL
29
R1703
4.7K
NB144WJQZ
1
VCC
2
VCC
3
VCC
4
VCC
5
GND
6
GND
7
GND
8
GND
9
SELLVDS
10
NC
11
GND
12
ORX0-
13
ORX0+
14
GND
15
ORX1-
16
ORX1+
17
GND
18
ORX2-
19
ORX2+
20
GND
21
OCLK-
22
OCLK+
23
GND
24
ORX3-
25
ORX3+
26
GND
27
SCL
28
SDA
29
GND
30
WP
S102 KA050WJ
1
VOL+
2
INPUT/MENU
3
CH-DOWN
4CH-UP 5
6VOLP
L
R
IC501 HP
IC9605
V
L
R
Y
Pb
Pr
IC9603
IC9604
IC3101
IC9602 IC9601
IC3301
INPUT2 INPUT1
IC3302
RESETIC
IC1702
SERVICE
IC1701
SC3801
D+5.0V
D+3.3V
D+1.26V

PARTS GUIDE
No. S94M55LC-32LE260M
LED BACKLIGHT TV
MODEL:
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32LE260M
LC-32LE260M
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] MAIN Unit: DUNTKG492FM01/02
[4] LED/IR Unit DUNTKG463FM01
[5] POWER Unit: DUNTKG409FM01
[6] CABINET AND MECHNICAL
PARTS
[7] LCD PANEL
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS ( NOT REPLACE-
MENT )
[10] EXPLODE VIEW
