Sharp R-403JK User manual

READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
CONTENTS
• For Customer Assistance
................. Inside Front Cover
• Precautions to Avoid Possible
Exposure to Excessive
Microwave Energy .................. Inside Front Cover
• Consumer Limited Warranty....................... 1
• Product Information Card ........................... 1
• Important Safety Instructions..................... 2
• Unpacking and Installation Instructions ... 3
• Grounding Instructions............................... 3
• Information You Need to Know .................. 4-6
• Part Names ................................................... 7-8
• Before Operating ......................................... 9
• Manual Operation ........................................ 10
• Special Features .......................................... 11-15
• Other Convenient Features......................... 16-17
• Cleaning and Care ....................................... 18
• Service Call Check....................................... 19
•
Cookbook Information ...................................... 19
• Specifications .............................................. 20
• Cookbook Order Form ................................ 20
• Guia Auto-Touch .......................................... 21
• Auto-Touch Guide................................. Back Cover
MODELS
R-403J /R-409J
Followed by letter indicating color
K=black, S=stainless steel, W=white
MICROWAVE OVEN
OPERATION MANUAL
®
1.403J, 409J #378 3/10/04, 3:44 PM23

To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial
number located on the unit. We also suggest you record all the information listed and retain for future reference.
MODEL NUMBER ________________________ SERIAL NUMBER ______________
DATE OF PURCHASE ______________________
DEALER ____________________________ TELEPHONE ________________
SERVICER ___________________________ TELEPHONE ________________
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken
or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
TO PHONE:
DIAL 1-800-BE-SHARP ( 237-4277 ) for :
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
DIAL 1-800-642-2122 for :
ACCESSORIES and COOKBOOK
TO WRITE:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
TO ACCESS INTERNET: www.sharp-usa.com
FOR CUSTOMER ASSISTANCE
Please provide the following information when you write or call: model number, serial number, date of purchase,
your complete mailing address (including zip code), your daytime telephone number (including area code) and
description of the problem.
1.403J, 409J #378 3/10/04, 3:44 PM24

1
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand
product (the “Product”), when shipped in its original container, will be free from defective workmanship and
materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part
thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the
period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s)
set forth below nor to any Product the exterior of which has been damaged or defaced, which has been
subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or
modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth
below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted
to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE
OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied
warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other
than those described herein, or to extend the duration of any warranties beyond the time period described
herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall
be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for
the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities
of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims,
whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any
way responsible, for any damages or defects in the Product which were caused by repairs or attempted
repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way
responsible for any incidental or consequential economic or property damage. Some states do not allow the
exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
Your Product Model Number
& Description:
Warranty Period for this Product:
Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
What to do to Obtain Service:
The Product information card should be completed within ten days of purchase and returned. We will keep it on
file and help you access the information in case of loss, damage or theft. This will also enable us to contact you in
the unlikely event that any adjustments or modifications are ever required for your oven.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharp-usa.com.
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE.
PRODUCT INFORMATION CARD
CONSUMER LIMITED WARRANTY
R-403J or R-409J Home Use Carousel Microwave Oven. (Be sure to
have this information available when you need service for your
Product.)
One (1) year parts and labor. The warranty period continues for an
additional four (4) years, for a total of five (5) years, with respect to the
magnetron tube in the Product for parts only; labor and service are not
provided free of charge for this additional period.
Non-functional accessories, turntable and light bulb.
From a Sharp Authorized Servicer located In the United States.
To find the location of the nearest Sharp Authorized Servicer, call
Sharp toll free at 1-800-BE-SHARP (1-800-237-4277).
Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
1.403J, 409J #378 3/10/04, 3:44 PM1

2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including the following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
SAVE THESE INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USING
THE APPLIANCE.
2. Readand followthe specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on inside front cover.
3. This appliance must be grounded. Connect only
to properly grounded outlet. See “GROUNDING
INSTRUCTIONS” on page 3.
4. Install or locate this appliance only in accordance
with the provided installation instructions.
5. Some products such as whole eggs and sealed
containers—for example, closed glass jars—are
able to explode and should not be heated in
this oven.
6. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook or
dry food. It is not designed for industrial or
laboratory use.
7. As with any appliance, close supervision is
necessary when used by children.
8. Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly or if it has
been damaged or dropped.
9. This appliance should be serviced only by
qualified service personnel. Contact nearest
Sharp Authorized Servicer for examination, repair
or adjustment.
10. Do not cover or block any openings on the
appliance.
11. Do not store or use this appliance outdoors. Do
notusethisproductnearwater—forexample,near
akitchensink,inawet basement,nearaswimming
pool, or similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. See door surface cleaning instructions on page 18.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend to
appliance when paper, plastic or other
combustible materials are placed inside the
oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic
bags before placing bag in oven.
c. If materials inside the oven ignite, keep
oven door closed, turn oven off and
disconnectthepowercordorshutoffpower
at the fuse or circuit breaker panel.
d. Do not use the cavity for storage purposes.
Do not leave paper products, cooking utensils
or food in the cavity when not in use.
17. Liquids, such as water, coffee or tea are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or
boiling when the container is removed from the
microwave oven is not always present. THIS
COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN A SPOON
OR OTHER UTENSIL IS INSERTED INTO THE
LIQUID.
To reduce the risk of injury to persons:
a. Do not overheat the liquid.
b. Stirthe liquid both before and halfway through
heating it.
c. Do not use straight-sided containers with
narrow necks.Use awide-mouthedcontainer
.
d. After heating, allow the container to stand in
the microwave oven at least for 20 seconds
before removing the container.
e. Use extreme care when inserting a spoon or
other utensil into the container.
18. If the oven is installed as a built-in, observe the
following instructions:
a. Do not operate any heating or cooking
appliance beneath this appliance.
b. Do not mount unit over or near any portion of
a heating or cooking appliance.
c. Do not mount over a sink.
d. Do not store anything directly on top of the
appliance surface when the appliance is in
operation.
19. If the oven light fails, consult a SHARP
AUTHORIZED SERVICER.
1.403J, 409J #378 3/10/04, 3:44 PM2

3
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug.
It must be plugged into a wall receptacle that is properly installed and grounded in accordance with the National
Electrical Code and local codes and ordinances. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current.
WARNING –Improper use of the grounding plug can result in a risk of electric shock.
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. or more
protectedelectricalsupply.Itisrecommendedthataseparatecircuitserving only
this appliance be provided.
The oven is equipped with a 3-prong grounding plug. It must be plugged into a
wall receptacle that is properly installed and grounded. Should you only have a
2-prong outlet, have a qualified electrician install a correct wall receptacle.
A 3-prong adapter may be purchased and used temporarily if local codes allow.
Follow package directions.
Ashortpower-supplycordisprovidedtoreduceriskofbecomingentangledinor
tripping over a longer cord.
Extension Cord
If it is necessary to use an extension cord, use only a 3-wire extension cord that
has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on
themicrowaveoven.Themarked ratingoftheextensioncordshouldbeAC115-
120 volt, 15 amp. or more.
Becarefulnottodrapethecordoverthecountertoportablewhereitcanbepulled
on by children or tripped over accidentally.
Notes:
1.Ifyouhaveanyquestionsaboutthegroundingorelectricalinstructions,consult
a qualified electrician or service person.
2.Neither Sharp northedealer can acceptanyliability for damagetothe oven or
personal injury resulting from failure to observe the correct electrical connection procedures.
Radio or TV Interference
Shouldthere be any interference caused by themicrowave ovento yourradio or TV, check that the microwaveoven
ison adifferent electrical circuit, relocate the radio or TV as far away from the oven asfeasible orcheck position and
signal of receiving antenna.
GROUNDING INSTRUCTIONS
UNPACKING AND INSTALLATION INSTRUCTIONS
–
Unpacking and Examining Your Oven
Remove:
1. all packing materials from inside the oven cavity;
however, DO NOT REMOVE THE WAVEGUIDE
COVER, which is located on the right cavity wall.
Read enclosures and
SAVE the Operation
Manual.
2. the feature sticker,
if there is one, from
the outside of the
door.
Check the oven for
any damage, such as
misaligned or bent
door, damaged door
seals and sealing surfaces, broken or loose door
hinges and latches and dents inside the cavity or on
the door. If there is any damage, do not operate the
ovenand contact yourdealer or SHARPAUTHORIZED
SERVICER.
Choosing a Location for Your Oven
You will use the oven frequently so plan its location for
ease of use. It's wise, if possible, to have counter space
on at least one side of the oven. Allow at least 2 inches
on the sides, top and at the rear of the oven for air
circulation. Do not place or install the oven in any area
where heat and steam are generated; for example, next
to or above a conventional gas or electric range or above
a conventional wall oven. Heat and steam may damage
the electronics or the mechanical parts of the oven.
Built-in Kit
Your oven can be built into a cabinet or wall—not
near or above a heat source—using Sharp’s black
Built-In Kit RK-46K24, stainless steel RK-46S24 or
white RK-46W14. If your dealer does not stock the kit,
it can be ordered directly from the Sharp Accessories
and Supplies Center. Have your credit card number
available and call toll-free: 1-800-642-2122 for ordering
the kit to be sent to your address.
The kit includes ducts, finish trim strips and easy-to-
follow instructions for installation as well as the
location of the power supply.
1.403J, 409J #378 3/10/04, 3:44 PM3

4
INFORMATION YOU NEED TO KNOW
ABOUT YOUR OVEN
Eggs, sausages,
nuts, seeds,
fruits &
vegetables
Popcorn
Baby food
General
ABOUT FOOD
•Puncture egg yolks before cooking
to prevent “explosion”.
•Pierce skins of potatoes, apples,
squash, hot dogs and sausages so
that steam escapes.
•Use specially bagged popcorn for the
microwave oven.
•Listen while popping corn for the
popping to slow to 1 or 2 seconds or
use special POPCORN pad.
•Transfer baby food to small dish and
heat carefully, stirring often. Check
temperature before serving.
•Put nipples on bottles after heating
and shake thoroughly. “Wrist”test
before feeding.
•Cut baked goods with filling after
heating to release steam and avoid
burns.
•Stir liquids briskly before and after
heating to avoid “eruption”.
•Use deep bowl, when cooking liquids
or cereals, to prevent boilovers.
•Cook eggs in shells.
•Reheat whole eggs.
•Dry nuts or seeds in shells.
•Pop popcorn in regular brown bags
or glass bowls.
•Exceed maximum time on popcorn
package.
•Heat disposable bottles.
•Heat bottles with nipples on.
•Heat baby food in original jars.
•Heat or cook in closed glass jars or
air tight containers.
•Can in the microwave as harmful
bacteria may not be destroyed.
•Deep fat fry.
•Dry wood, gourds, herbs or wet papers.
DO DON’T FOOD
This Operation Manual is valuable: read it carefully
and always save it for reference.
A good microwave cookbook is a valuable asset.
Check it for microwave cooking principles, techniques,
hints and recipes. See pages 19 and 20 for ordering
the Sharp Carousel Microwave Cookbook.
NEVER use the oven without the turntable and support
nor turn the turntable over so that a large dish could
be placed in the oven. The turntable will turn both
clockwise and counterclockwise.
ALWAYS have food in the oven when it is on to absorb
the microwave energy.
When using the oven at power levels below 100%, you
may hear the magnetron cycling on and off. It is normal
for the exterior of the oven to be warm to the touch
when cooking or reheating.
Condensation is a normal part of microwave cooking.
Room humidity and the moisture in food will influence
the amount of moisture that condenses in the oven.
Generally, covered foods will not cause as much
condensation as uncovered ones. Vents on the oven
back must not be blocked.
The oven is for food preparation only. It should not be
used to dry clothes or newspapers.
Your oven is rated 1100 watts by using the IEC Test
Procedure.Inusingrecipesorpackagedirections,check
food a minute or two before the minimum time and add
time accordingly.
1.403J, 409J #378 3/10/04, 3:44 PM4

5
ABOUT UTENSILS AND COVERINGS
The following coverings are ideal:
•Paper towels are good for covering foods for re-
heating and absorbing fat while cooking bacon.
•Wax paper can be used for cooking and
reheating.
•Plastic wrap that is specially marked for micro-
wave use can be used for cooking and reheat-
ing. DO NOT allow plastic wrap to touch food.
Vent so steam can escape.
•Lids that are microwave-safe are a good choice
because heat is kept near the food to hasten
cooking.
•Oven cooking bags are good for large meats or
foods that need tenderizing. DO NOT use metal
twist ties. Remember to slit bag so steam can
escape.
How to use aluminum foil in your microwave
oven:
•Small flat pieces of aluminum foil placed
smoothly on the food can be used to shield
areas that are either defrosting or cooking too
quickly.
•Foilshould notcome closerthan oneinch toany
surface of the oven.
Shouldyou have questions about utensilsor coverings,
check a good microwave cookbook or follow recipe
suggestions.
ACCESSORIES There are many microwave accesso-
ries available for purchase. Evaluate carefully before
you purchase so that they meet your needs. A micro-
wave-safe thermometer will assist you in determining
correct doneness and assure you that foods have
been cooked to safe temperatures. Sharp is not
responsible for any damage to the oven when acces-
sories are used.
Children should be taught all safety precautions: use
potholders, remove coverings carefully, pay special
attention to packages that crisp food because they
may be extra hot.
Don’t assume that because a child has mastered one
cooking skill he/she can cook everything.
Children need to learn that the microwave oven is not
a toy. See page 17 for Child Lock feature.
It is not necessary to buy all new cookware. Many
pieces already in your kitchen can be used success-
fully in your new microwave oven. Make sure the
utensil does not touch the interior walls during cooking.
Use these utensils for safe microwave cooking
and reheating:
•glass ceramic (Pyroceram®), such as
Corningware®.
•heat-resistant glass (Pyrex®)
•microwave-safe plastics
•paper plates
•microwave-safe pottery, stoneware and
porcelain
•browning dish (Do not exceed recommended
preheating time. Follow manufacturer's
directions.)
These items can be used for short time reheat-
ing of foods that have little fat or sugar in them:
•wood, straw, wicker
DO NOT USE
•metal pans and bakeware
•dishes with metallic trim
•non-heat-resistant glass
•non-microwave-safe plastics (margarine tubs)
•recycled paper products
•brown paper bags
•food storage bags
•metal twist-ties
Should you wish to check if a dish is safe for
microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which
becomes very hot should not be used.
ABOUT CHILDREN AND THE MICROWAVE
Children below the age of 7 should use the microwave
oven with a supervising person very near to them.
Between the ages of 7 and 12, the supervising person
should be in the same room.
The child must be able to reach the oven comfortably;
if not, he/she should stand on a sturdy stool.
At no time should anyone be allowed to lean or swing
on the oven door.
INFORMATION YOU NEED TO KNOW
1.403J, 409J #378 3/10/04, 3:44 PM5

6
ABOUT MICROWAVE COOKING
•Arrangefood carefully.Place thickest areas towards
outside of dish.
•Watch cooking time. Cook for the shortest amount
of time indicated and add more as needed. Food
severely overcooked can smoke or ignite.
•Cover foods while cooking. Check recipe or cook-
book for suggestions: paper towels, wax paper,
microwave plastic wrap or a lid. Covers prevent
spattering and help foods to cook evenly.
•Shield with small flat pieces of aluminum foil any
thin areas of meat or poultry to prevent overcooking
before dense, thick areas are cooked thoroughly.
•Stirfoodsfrom outside tocenter of dishonce or twice
during cooking, if possible.
•Turn foods over once during microwaving to
speed cooking of such foods as chicken and ham-
burgers.Large itemslike roastsmust beturned over
at least once.
•Rearrange foods such as meatballs halfway
through cooking both from top to bottom and from
the center of the dish to the outside.
•Add standing time. Remove food from oven and
stir, if possible. Cover for standing time which allows
the food to finish cooking without overcooking.
•Check for doneness. Look for signs indicating that
cooking temperatures have been reached.
Doneness signs include:
- Food steams throughout, not just at edge.
- Center bottom of dish is very hot to the touch.
- Poultry thigh joints move easily.
- Meat and poultry show no pinkness.
- Fish is opaque and flakes easily with a fork.
•Check foods to see that they are cooked to
the United States Department of Agriculture's
recommended temperatures.
To test for doneness, insert a meat thermometer in a
thick or dense area away from fat or bone. NEVER
leave the thermometer in the food during cooking,
unless it is approved for microwave oven use.
•ALWAYS use potholders to prevent burns when
handling utensils that are in contact with hot food.
Enough heat from the food can transfer through
utensils to cause skin burns.
•Avoid steam burns by directing steam away from
the face and hands. Slowly lift the farthest edge of
a dish's covering and carefully open popcorn and
oven cooking bags away from the face.
•Stay near the oven while it's in use and check
cooking progress frequently so that there is no
chance of overcooking food.
•NEVER use the cavity for storing cookbooks or
other items.
•Select, store and handle food carefully to preserve
its high quality and minimize the spread of
foodborne bacteria.
•Keep waveguide cover clean. Food residue can
cause arcing and/or fires.
•Use care when removing items from the oven so
that the utensil, your clothes or accessories do not
touch the safety door latches.
ABOUT SAFETY
... for fresh pork, ground meat,
boneless white poultry, fish,
seafood, egg dishes and frozen
prepared food.
... for leftover, ready-to-reheat
refrigerated, and deli and carry-
out “fresh”food.
... white meat of poultry.
... dark meat of poultry.
160°F
TEMP FOOD
165°F
170°F
180°F
INFORMATION YOU NEED TO KNOW
1.403J, 409J #378 3/10/04, 3:44 PM6

7
PART NAMES
MICROWAVE OVEN PARTS
1One touch door open button
Push to open door.
2Oven door with see-through window
3Safety door latches
The oven will not operate unless the door is
securely closed.
4Door hinges
5Door seals and sealing surfaces
6Turntable motor shaft
7Removable turntable support
Carefully place the turntable support in the
center of the oven floor.
8Removable turntable
Place the turntable on the turntable support
securely. The turntable will rotate clockwise or
counterclockwise. Only remove for cleaning.
9Ventilation openings (rear)
10 Oven light
It will light when oven is operating or door is
open.
11 Waveguide cover: DO NOT REMOVE.
12 Auto-Touch control panel
13 Time display: 99 minutes, 99 seconds
VISUAL DISPLAY
Words in the lower portion of the display will
light to indicate what function is in progress.
Indicators
1.403J, 409J #378 3/10/04, 3:44 PM7

8
PART NAMES
Number next to the control panel illustration
indicates pages on which there are feature descriptions and usage information.
CONTROL PANEL
11
9
10 9
16
16
R-403J
17
15
16
16
11-12
10
R-409J
9
14
13
14
11-12
13
9
11
1.403J, 409J #378 3/10/04, 4:25 PM8

9
This is a 12 hour clock. If you attempt to enter an
incorrect clock time, will appear in the display.
Touch the STOP/CLEAR pad and re-enter the time.
•If the electrical power supply to your microwave oven
should be interrupted, the display will intermittently
show after the power is reinstated. If this
occurs during cooking, the program will be erased.
The time of day will also be erased. Simply touch
STOP/CLEAR padand reset the clock for the correct
time of day.
•Before operating your new microwave oven make
sure you read and understand this operation manual
completely.
•Beforetheovencanbeused,followtheseprocedures:
1. Plug in the oven. The oven display will then begin
flashing .
2. Touch the STOP/CLEAR pad.
will appear.
3. Set clock.
BEFORE OPERATING
88:88
:
ERROR
Touch the STOP/CLEAR pad to:
1. Erase if you make a mistake during programming.
2. Cancel timer.
3. Stop the oven temporarily during cooking.
4. Return the time of day to the display.
5. Cancel a program during cooking, touch twice.
88:88
TO SET THE CLOCK
•Suppose you want to enter the correct time of day
12:30 (A.M. or P.M.).
PROCEDURE DISPLAY
1
2
3
STOP/CLEAR
Touch TIMER/CLOCK pad.
Touch TIMER/CLOCK pad again.
Enter the correct time
of day by touching the
numbers in sequence.
1230
TIMER
CLOCK
TIMER
CLOCK
12:30
12:30
: 0
Your oven can be programmed for 99 minutes 99
seconds (99.99). Always enter the seconds after the
minutes, even if they are both zeros.
•Suppose you want to cook for 5 minutes at 100%.
TIME COOKING
PROCEDURE DISPLAY
1
2
Touch START pad.
Enter cooking time.
500
15.00
15.00
COOK DEFROST
START
1.403J, 409J #378 3/10/04, 3:44 PM9

10
PROCEDURE DISPLAY
1
3
2
TouchPOWER LEVEL pad eighttimes orhold
down until the desired power level appears.
POWER
LEVEL
MANUAL OPERATION
TO SET POWER LEVEL
There are eleven preset power levels.
Using lower power levels increases the cooking time
which is recommended for foods such as cheese, milk
and long slow cooking of meats. Consult cookbook or
recipes for specific recommendations.
APPROXIMATE
PERCENTAGE
OF POWER
COMMON WORDS
FOR
POWER LEVELS
TOUCH POWER
LEVEL PAD NUMBER OF TIMES
FOR DESIRED POWER
POWER LEVEL x 1 100% High
POWER LEVEL x 2 90%
POWER LEVEL x 3 80%
POWER LEVEL x 4 70% Medium High
POWER LEVEL x 5 60%
POWER LEVEL x 6 50% Medium
POWER LEVEL x 7 40%
POWER LEVEL x 8 30% Med Low/Defrost
POWER LEVEL x 9 20%
POWER LEVEL x 10 10% Low
POWER LEVEL x 11 0%
Touch START pad.
Enter defrosting time.
5 0 0
15.00
1P-30
15.00
If the food that you wish to defrost is not listed on
the DEFROST CHART or is above or below the limits
in the AMOUNT column onthe DEFROSTCHART(see
page 13), you need to defrost manually.
You can defrost any frozen food, either raw or
previously cooked, by using Power Level for 30%.
Follow the exact 4-step procedure found under TO
SET POWER LEVEL. Estimate defrosting time and
press POWER LEVEL pad eight times for 30% power.
For either raw or previously cooked frozen food the
rule of thumb is approximately 4 minutes per pound.
For example, defrost 4 minutes for 1 pound of frozen
spaghetti sauce.
Always stop the oven periodically to remove or
separate the portions that are defrosted. If food is
not defrosted at the end of the estimated defrosting
time, program the oven in 1 minute increments on
Power Level 30% until totally defrosted.
When using plastic containers from the freezer,
defrost only long enough to remove from the plastic
in order to place in a microwave-safe dish.
MANUAL DEFROST
•Suppose you want to defrost for 5 minutes at 30%.
x 8
4
When the defrost time is complete, a long tone
will sound and will appear in the
display.
COOK DEFROST
END
START
1.403J, 409J #378 3/10/04, 3:44 PM10

11
SPECIAL FEATURES
POPCORN
The POPCORN setting automatically provides the
correct cooking time for most brands of microwave
popcorn. You may wish to try several and choose your
favorite. Pop only one bag at a time. Unfold bag and
place in oven according to directions.
•Suppose you want to pop a 3.5 oz bag (regular) of
popcorn.
•Touch POPCORN once for a 3.5 oz bag (Regular).
•Touch POPCORN twice within 2 seconds for 2.85 -
3.5 oz bag (Regular Light).
•Touch POPCORN three times within 3 seconds for
1.2 or 1.6 oz bag (Mini).
•Touch POPCORN three times within3 seconds, then
touch POWER LEVEL pad once within 2 seconds
for 1.5 or 1.75 oz bag (Snack).
NOTE:
To use POPCORN pad, touch within 3 minutes after
cooking, opening and closing the door or touching the
STOP/CLEAR pad.
PROCEDURE
Touch POPCORN once.
The oven starts automatically.
reg
POPCORN
DISPLAY
COOK automatically computes the correct cooking
time and microwave power level for foods shown in the
chart below.
•Supposeyouwanttocook3mediumbakedpotatoes.
COOK
TIPS: Foods can be covered with wax paper or
vented plastic wrap. Temperatures of foods covered
with plastic wrap tend to be slightly higher than those
covered with wax paper.
NOTE:
1. Moreor lessfood thanthe quantitylisted inthe chart
should be cooked following the guidelines in any
microwave cookbook.
2. COOK can be programmed with More or Less Time
Adjustment. See page 16.
3. The final cooking result will vary according to the
food condition (e.g. initial temperature, shape,
quality). Check food for temperature after cooking.
If additional time is needed, continue to cook
manually.
PROCEDURE
1
Touch COOK once.
2
FOOD
1
1
Select desired Cook setting.
(Ex: touch number pad 1to
select Baked Potatoes.
4
NO.
1
COOK
3
3
Repeat touching same number pad 1to
increase quantity to 3 potatoes. (Ex: touch two
more times for 3 potatoes or hold down until
the desired quantity appears.)
NO.
1
START
DISPLAY
Touch START pad.
1.403J, 409J #378 3/10/04, 3:44 PM11

12
COOK CHART
FOOD AMOUNT PROCEDURE
1.Baked
Potatoes 1-6 medium
1-6 cups2.Fresh
Vegetables
1-6 cups3.Frozen
Vegetables
Rice Water Size of casserole dish
.5 cup 1 cup 1.5 quart
1 cup 2 cups 2 quart
1.5 cups 3 cups 2.5 or 3 quart
2 cups 4 cups 3 quart or larger
.5-2.0 cups6.Rice
6-17 oz4.Frozen
Entrees
6-8 oz
9-11 oz
12-14 oz
15-17 oz
5.Ground
Meat .3-2.0 lb
SPECIAL FEATURES
Pierce with fork in several places; place on paper towel on turntable. At end of
cooking time, remove from oven, wrap in foil and let stand 5 to 10 minutes.
For beans, carrots, corn and peas, add 1 tablespoon of water per cup. For
broccoli, Brussels sprouts, cabbage and cauliflower, cook immediately after
washing with no additional water. If you like tender crisp vegetables, double or
triple measured quantity per setting. After cooking, remove from oven, stir,
cover and let stand 3 to 5 minutes before serving.
Add no water. Cover with lid or plastic wrap. After cooking, stir and let stand,
covered, for 3 minutes.
Press COOK pad and number 6for anount. Place rice into a deep casserole
dish and add double quantity of water. Cover with lid or plastic wrap.After cook-
ing, stir, cover and let stand 3 to 5 minutes or until all liquid has been absorbed.
Use this setting for frozen, convenience foods. It will give satisfactory results for
most brands. You may wish to try several and choose your favorite. Remove
package from outer wrapping and follow package directions for covering. After
cooking, let stand, covered, for 1 to 3 minutes.
Touch COOK and number pad 4once for package weight of 6-8 oz. will
appear in the display.
Touch COOK and number pad 4twice for package weight of 9-11 oz.
will appear in the display.
Touch COOK and number pad 4three times for package weight of 12-14 oz.
will appear in the display.
Touch COOK and number pad 4four times for package weight of 15-17 oz.
will appear in the display.
15-17
Use this setting to cook ground beef or poultry as patties or in a casserole to be
added to other ingredients. Place patties on a microwave-safe rack and cover
with wax paper. Place ground meat in a casserole and cover with wax paper or
plastic wrap. When oven stops, turn patties over or stir meat in casserole to break
uplargepieces.Re-cover andtouchSTART.Aftercooking,letstand,covered,for
2 to 3 minutes.
Press COOK pad and number 55
55
5for amount.
Once 0.3 lb
Twice 0.5 lb
3 times 0.7 lb
4 times 1.0 lb
5 times 1.3 lb
6 times 1.5 lb
7 times 1.7 lb
8 times 2.0 lb
12-14
6-8
9-11
1.403J, 409J #378 3/10/04, 3:44 PM12

13
DEFROST
DEFROST automatically defrosts all the foods shown
in the DEFROST CHART below. Round the weight to
the nearest tenth of a pound. To enter weight, touch
DEFROST and number pad for desired food then
number pads for weight.
•Suppose you want to defrost a 3.0 pound steak.
PROCEDURE DISPLAY
1
Touch DEFROST once.
2NOTE:
1. DEFROST can be programmed with More or Less
Time Adjustment. Touch the POWER LEVEL pad
once or twice after selecting the amount. See
page 16.
2. To defrost other foods or foods above or below
the weights allowed on the DEFROST CHART, use
time and 30% power. See MANUAL DEFROST on
page 10.
3. Ifyou attempt to enter moreor lessthan the allowed
amount as indicated in the chart below,
will appear in the display.
3
After defrost cycle ends, cover and let stand as
indicated in chart below.
NOTE: Check foods when oven signals. After final stage, small sections may still be icy. Let stand to continue
thawing. Do not defrost until all ice crystals are thawed.
Shielding prevents cooking from occurring before the center of the food is defrosted. Use small smooth
strips of aluminum foil to cover edges and thinner sections of the food.
DEFROST CHART
FOOD PROCEDURE
.5 - 2.0 lb
.5 - 2.0 lb
.5 - 3.0 lb
FOOD
NO.
LBS.
CUPS
OZ.
COOK DEFROST
AMOUNT
.5 - 3.0 lb
Pullapartandremove anythawedpiecesaftereachstage.Letstand, covered,for
5 to 10 minutes.
After each stage, rearrange and if there are warm or thawed portions, shield with
smallflatpiecesofaluminumfoil.Removeanymeatorfishthatisnearlydefrosted.
Let stand, covered, for 10 to 20 minutes.
After each stage, if there are warm or thawed portions, rearrange or remove.
Let stand, covered, for 10 to 20 minutes.
After each stage, if there are warm or thawed portions, rearrange or remove.
Let stand, covered, for 10 to 20 minutes.
DEFROST
Touch number 2for
Steaks/Chops
2
2
NO.
LBS.
CUPS
OZ.
COOK DEFROST
Touch number pads
for desired weight.
(Ex: touch 30 for 3.0 lb.)
3.0
NO.
LBS.
CUPS
OZ.
COOK DEFROST
4
START Touch START pad.
The oven will stop and directions will be displayed.
After the 2nd stage, open the door and shield
any warm portions. Close the door.
After the 1st stage, open the door, turn steak
over and shield any warm portions. Close the
door. START
ERROR
START
5
6
1.Ground
Meat
2.Steaks/
Chops
3.Boneless
Poultry
4.Bone-in
Poultry
3 0
SPECIAL FEATURES
Touch START pad.
Touch START pad.
1.403J, 409J #378 3/10/04, 3:44 PM13

14
REHEAT
REHEAT automatically computes the correct heating
time and microwave power level for foods shown in the
chart below.
•Suppose you want to reheat 3 cups of soup.
PROCEDURE
1
Touch REHEAT once.
REHEAT CHART
FOOD AMOUNT PROCEDURE
1.Pasta
Sauce
2.Soup
3.Pizza
4.Dinner
Plate
5.Beverage
6.Rolls/
Muffins
2
FOOD
2
1
Select desired REHEAT
setting. (Ex: touch number
pad 2to select 1 cup of
soup.
NOTE:
1. To reheat different foods or foods above or below
the quantity allowed on the REHEAT CHART, use
manual operation.
2. REHEAT can be programmed with More or Less
Time Adjustment. See page 16.
CUPS
2
REHEAT
Use this setting to reheat refrigerated, canned or homemade pasta with sauce or
other cooked casserole. For room temperature pasta or casserole, use Less
option(see page16). For pasta without sauce double the quantity per setting. For
example, measure 2 cups of cooked noodles and program for 1 cup. Cover with
lid or plastic wrap. After cooking, let stand, covered, 2 to 3 minutes.
Placeinbowlorcasserole.Coverwithlidorplastic wrap. At end, stir, re-cover and
let stand 1 to 3 minutes.
Use this setting to reheat refrigerated leftover pizza. One slice is approximately
1/8th of a 12 inch pizza or 1/12th of a 16 inch pizza. Place on paper towel.
Use this setting to reheat precooked foods from the refrigerator. Place meaty
portions and bulky vegetables to outside of plate. Cut large items like baked
potatoes in smaller pieces. Flatten foods such as mashed potatoes and other
dense foods. Cover with wax paper or plastic wrap. ONE PLATE ONLY.
Aftercooking, check that food is very hotthroughout and that the bottom center of
the plate is very hot. If not, continue heating using time and power level. Allow to
stand, covered, 1 to 2 minutes.
Touch REHEAT and then the number pad 4once for a regular amount of food:
approximately 4 oz sliced meat or poultry, 1/2 cup potato or rice and 1/2 cup of
vegetables or equivalent. will appear in the display.
TouchREHEAT and then the number pad 4twice for a larger amount of food on
a dinner plate. will appear in the display.
TouchREHEAT and then the number pad 4three times for a smaller amount of
food on a dinner plate. will appear in the display.
Thissettingisgoodforrestoringcooledbeveragestoabetterdrinkingtemperature.
TouchREHEATand thenthenumber 5padfora0.5 cup increasepertouch. Stir
liquid briskly before heating and stir carefully at end of cycle to avoid "eruption."
Use this setting to warm rolls, muffins, biscuits, bagels etc. Large items should be
considered as 2 or 3 regular size. Arrange on plate; cover with paper towel. For
refrigerated rolls or muffins, it may be necessary to double the entered amount to
ensure the proper serving temperature. For example, enter quantity of 2 for 1
refrigerated muffin.
DISPLAY
SPECIAL FEATURES
PROCEDURE
4
Touch START pad.
3
3
Repeat touching same number pad 2to
increase quantity to 3 cups. (Ex: touch 2two
more times for 3 cups or hold down until the
desired quantity appears.)
CUPS
2
START
DISPLAY
1-6 cups
1-6 cups
1-6 slices
1 plate
1 Regular
1 Large
1 Small
.5-2.0 cups
1-8
REG
LARGE
SMALL
1.403J, 409J #378 3/10/04, 3:44 PM14

15
SPECIAL FEATURES
SHORT CUTS (For R-403J only)
SHORT CUTS automatically compute the correct
heating time and microwave power level for melting,
softening and warming foods shown in the chart.
•Suppose you want to melt 1 square of chocolate.
PROCEDURE
1
Touch MELT once.
2
Select desired food by
touching number pad.
(Ex: Touch 2for chocolate.)
3
Repeat touching same
number pad to select quantity.
(Ex: Touch 2two more times
for 1 square.)
4
Touch START pad.
2
x 2
2
NOTE:
1. To melt, soften or warm other food or foods except
the quantity listed in the SHORT CUTS CHART,
use manual operation.
2. SHORTCUTScanbeprogrammedwithMoreorLess
Time Adjustment. See page 16.
SHORT CUTS CHART
FOOD AMOUNT PROCEDURE
MELT
1. Butter
2. Chocolate
2 tbsp
1/2 cup
1 cup chips
1 square
Use a Pyrex measuring cup. Cover with plastic wrap.
After touching MELT, touch 1two times for 2 tbsp.
After touching MELT, touch 1three times for 1/2 cup.
After touching MELT, touch 2two times for 1 cup chips.
After touching MELT, touch 2three times for 1 square.
SOFTEN
1. Ice cream
2. Cream cheese
1 pint
1/2 gallon
3 oz.
8 oz.
DO NOT COVER.
After touching SOFTEN, touch 1two times for 1 pint.
After touching SOFTEN, touch 1three times for 1/2 gallon.
After touching SOFTEN, touch 2two times for 3 oz.
After touching SOFTEN, touch 2three times for 8 oz.
WARM
1. Syrup
2. Dessert topping
1/4 cup
1/2 cup
1/4 cup
1/2 cup
Use a Pyrex measuring cup. DO NOT COVER.
After touching WARM, touch 1two times for 1/4 cup.
After touching WARM, touch 1three times for 1/2 cup.
After touching WARM, touch 2two times for 1/4 cup.
After touching WARM, touch 2three times for 1/2 cup.
START
MELT
1
2
1
2
1
2
1
2
1
2
1
2
1.403J, 409J #378 3/10/04, 3:44 PM15

16
PROCEDURE
PROCEDURE
1
2
OTHER CONVENIENT FEATURES
NOTE:
1. To use MINUTE PLUS, touch pad within 3 minutes
after cooking, closing the door, touching the
STOP/CLEAR pad or during cooking.
2. MINUTEPLUScannotbeusedwithspecialfeatures.
Touch MINUTE PLUS pad.
MINUTE PLUS allows you to cook for a minute at
100% by simply touching the MINUTE PLUS pad. You
can also extend cooking time in multiples of 1 minute
by repeatedly touching the MINUTE PLUS pad during
manual cooking.
•Suppose you want to heat a cup of soup for one
minute.
MINUTE PLUS
NOTE:
1. If POWER LEVEL pad is touched, P- I will be
displayed during the first sequence.
2. If 100% is selected as the final sequence, it is not
necessary to touch the POWER LEVEL pad.
3. If you wish to know power level, simply touch the
POWER LEVEL pad. As long as your finger is
touching the POWER LEVEL pad, the power level
will be displayed.
MULTIPLE SEQUENCE
COOKING
Your oven can be programmed for up to 3 automatic
cooking sequences, switching from one power level
setting to another automatically.
Sometimes cooking directions tell you to start on one
power level and then change to a different power level.
Your oven can do this automatically.
•Supposeyouwanttocook for5minutes at100%and
then continue to cook for 30 minutes at 50%.
•Suppose you want to time a 3-minute long distance
phone call.
TIMER
Should you discover that you like any of the
POPCORN, COOK, REHEAT, SHORT CUTS or
DEFROST settings slightly more done, touch the
POWER LEVEL pad once after touching your choice
of pads or before touching START pad. The display
will show .
Should you discover that you like any of the
POPCORN, COOK, REHEAT, SHORT CUTS or
DEFROST settings slightly less done, touch the
POWER LEVEL pad twice after touching your choice
of pads or before touching START pad. The display
will show .
MORE OR LESS TIME
ADJUSTMENT
If you wish to have the oven operate with no audible
signals, touch TIMER/CLOCK, the number 5and
then touch START pad and hold for three seconds.
To cancel and restore the audible signal, touch
TIMER/CLOCK, the number 5and STOP/CLEAR
pads.
AUDIBLE SIGNAL
ELIMINATION
PROCEDURE
1
2
3
First enter cooking time.
Then touch POWER
LEVEL once for 100%
power.
Then enter second
cooking time.
Touch POWER LEVEL
pad 6 times for 50%
power.
Touch START pad.
5 0 0
3 0 0 0
POWER
LEVEL
POWER
LEVEL
Enter time.
Touch TIMER/
CLOCK pad. TIMER
CLOCK
3 0 0
x 6
x 1
3
To cancel the timer,
touch the STOP/CLEAR
pad once.
STOP
CLEAR
START
MORE
LESS
MINUTE
PLUS
––
1.403J, 409J #378 3/10/04, 3:44 PM16

17
The Child Lock prevents unwanted oven operation
such as by small children.
The oven can be set so that the control panel is
deactivated or locked. To set, touch TIMER/CLOCK
pad, the number 1and then touch the START pad
and hold for three seconds. Should a pad be touched,
will appear in the display.
To cancel, touch TIMER/CLOCK, the number 1and
STOP/CLEAR pads.
CHILD LOCK
Todemonstrate,touchTIMER/CLOCK,thenumber0
and then touch the START pad and hold for three
seconds. will appear in the display. Cooking
operations and specific special features can now be
demonstratedwithnopowerintheoven.Forexample,
touch MINUTE PLUS pad and the display will show
and count down quickly to .
To cancel, touch TIMER/CLOCK, the number 0and
STOP/CLEAR pads. If easier, unplug the oven from
the electrical outlet and replug.
DEMONSTRATION MODE
OTHER CONVENIENT FEATURES
DEMO
LOCK 1:00 End
Touch the NIGHT LIGHT pad once to turn on the light
and touch again to turn off.
The Night Light turns off automatically when you start
cooking and after the light has operated for 9 hours.
NIGHT LIGHT (For R-403J only)
1.403J, 409J #378 3/10/04, 3:44 PM17

18
CLEANING AND CARE
Disconnect the power cord before cleaning or leave the door open to inactivate the oven during cleaning.
Exterior
The outside surface is painted. Clean the outside with
mild soap and water; rinse and dry with a soft cloth. Do
not use any type of household or abrasive cleaner.
Door
Wipe the window on both sides with a damp cloth to
remove any spills or spatters. Metal parts will be easier
to maintain if wiped frequently with a damp cloth.
Cleaners which are marked specifically for use with
stainless steel may be used for stainless steel model.
Follow package directions exactly.Avoid the use of any
harsh cleaner or one not marked for stainless steel use
as they may stain, streak or dull the door surface.
Touch Control Panel
Careshouldbetakenin cleaning the touchcontrolpanel.
Ifthe controlpanel becomessoiled, open the oven door
before cleaning. Wipe the panel with a cloth dampened
slightly with water only. Dry with a soft cloth. Do not
scrub or use any sort of chemical cleaners. Close door
and touch STOP/CLEAR.
Interior
Cleaning is easy because little heat is generated to
the interior surfaces; therefore, there is no baking and
setting of spills or spattering. To clean the interior
surfaces, wipe with a soft cloth and warm water. DO
NOT USE ABRASIVE OR HARSH CLEANERS OR
SCOURING PADS. For heavier soil, use baking soda
or a mild soap; rinse thoroughly with hot water.
NEVER SPRAY OVEN CLEANERS DIRECTLY
ONTO ANY PART OF THE OVEN.
Waveguide Cover
The waveguide cover is made from mica so requires
special care. Keep the waveguide cover clean to
assure good oven performance. Carefully wipe with a
damp cloth any food spatters from the surface of the
cover immediately after they occur. Built-up splashes
may overheat and cause smoke or possibly catch fire.
Do not remove the waveguide cover.
Odor Removal
Occasionally, a cooking odor may remain in the oven.
To remove, combine 1 cup water, grated peel and juice
of 1 lemon and several whole cloves in a 2-cup glass
measuring cup. Boil for several minutes using 100%
power.Allow to set in oven until cool. Wipe interior with
a soft cloth.
Turntable/Turntable Support
The turntable and turntable support can be removed
for easy cleaning. Wash them in mild, sudsy water; for
stubborn stains use a mild cleanser and non abrasive
scouring sponge. They are also dishwasher-proof. Use
upper rack of dishwasher. The turntable motor shaft is
not sealed, so excess water or spills should be wiped
up immediately.
1.403J, 409J #378 3/10/04, 3:44 PM18
