Sharp R-28ST User manual

Important
Важно
Important
R-28ST
MICROWAVE OVEN - OPERATION MANUAL
МИКРОВЪЛНОВА ФУРНА - РЪКОВОДСТВО ЗА УПОТРЕБА
CUPTOR CU MICROUNDE - MANUAL DE UTILIZARE
RO BG EN
800 W (IEC 60705)

This operation manual contains important information which you should
read carefully before using your microwave oven.
Important: There may be a serious risk to health if this operation manual
is not followed or if the oven is modied so that it operates with the door
open.
Acest manual de utilizare conţine informaţii importante, care trebuie citite
cu atenţie înainte de utilizarea cuptorului cu microunde.
Important: Nerespectarea instrucţiunilor descrise în acest manual sau
modicarea cuptorului pentru a funcţiona cu uşa deschisă poate duce la
rănirea utilizatorului.
BG
Това ръководство за употреба съдържа информация, която трябва
да прочетете внимателно, преди да започнете да използвате Вашата
микровълнова фурна.
Важно: може да има сериозен риск за здравето, ако не се спазва
настоящата инструкция или фурната е преправена така, че да работи
ипри отворена врата.

GB-1
EN
Attention: Your
product is marked
with this symbol.
It means that used
electrical and
electronic products
should not be
mixed with general
household waste.
There is a separate
collection system
for these products.
A. Information on Disposal for Users (private households)
1. In the European Union
Attention: If you want to dispose of this equipment, please do not use
the ordinary dust bin!
Used electrical and electronic equipment must be treated separately
and in accordance with legislation that requires proper treatment, re-
covery and recycling of used electrical and electronic equipment.
Following the implementation by members states private households
within the EU states may return their used electrical and electronic
equipment to designated collection facilities free of charge*.
In some countries* your local retailer may also take back your old prod-
uct free of charge if you purchase a similar new one.
*) Please contact your local authority for further details.
If your used electrical or electronic equipment has batteries or accu-
mulators, please dispose of these separately beforehand according to
local requirements.
By disposing of this product correctly you will help ensure that the
waste undergoes the necessary treatment, recovery and recycling and
thus prevent potential negative eects on the environment and hu-
man health which could otherwise arise due to inappropriate waste
handling.
2. In other Countries outside the EU
If you wish to discard this product, please contact your local authorities
and ask for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be re-
turned free of charge to the dealer, even if you don’t purchase a new
product. Further collection facilities are listed on the homepage of
www.swico.ch or www.sens.ch.
B. Information on Disposal for Business Users
1. In the European Union
If the product is used for business purposes and you want to discard it:
Please contact your SHARP dealer who will inform you about the take-
back of the product. You might be charged for the costs arising from
take-back and recycling. Small products (and small amounts) might be
taken back by your local collection facilities. For Spain: Please contact
the established collection system or your local authority for take-back
of your used products.
2. In other Countries outside the EU
If you wish to discard of this product, please contact your local author-
ities and ask for the correct method of disposal.

GB-2
SPECIFICATIONS
CONTENTS
INFORMATION ON PROPER DISPOSAL....................................................................................................................................... 1
CONTENTS............................................................................................................................................................................................2
SPECIFICATIONS................................................................................................................................................................................. 2
OVEN AND ACCESSORIES ............................................................................................................................................................... 3
CONTROL PANEL................................................................................................................................................................................4
IMPORTANT SAFETY INSTRUCTIONS....................................................................................................................................5-15
INSTALLATION............................................................................................................................................................................ 16-17
BEFORE OPERATION .......................................................................................................................................................................17
SETTING THE CLOCK.......................................................................................................................................................................18
MICROWAVE POWER LEVELS.......................................................................................................................................................18
MANUAL OPERATION.....................................................................................................................................................................19
MICROWAVE COOKING..................................................................................................................................................................19
OTHER CONVENIENT FUNCTIONS ...................................................................................................................................... 20-21
WEIGHT DEFROST OPERATION...................................................................................................................................................21
TIME DEFROST OPERATION .........................................................................................................................................................22
AUTO MENU OPERATION..............................................................................................................................................................22
AUTO MENU CHART .......................................................................................................................................................................23
SUITABLE OVENWARE ....................................................................................................................................................................24
CARE AND CLEANING ....................................................................................................................................................................25
SERVICE ADDRESSES ......................................................................................................................................................................... I
Operation manual
Model name: R-28ST
AC Line Voltage : 230 V, 50 Hz single phase
Distribution line fuse/circuit breaker : 10 A
AC Power required: Microwave : 1250 W
Output power: Microwave : 800 W (IEC 60705)
O Mode (Energy Save Mode) : less than 1,0 W
Microwave Frequency : 2450 MHz*(Group 2/Class B)
Outside Dimensions (W) x (H) x (D)** mm : 485 x 287 x 410
Cavity Dimensions (W) x (H) x (D)*** mm : 314 x 201 x 347
Oven Capacity : 23 litres***
Turntable : ø 270 mm
Weight : approx. 13 kg
Oven lamp : 25 W/230-240 V
* This product fulls the requirement of the European standard EN55011.
In conformity with this standard, this product is classied as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency energy in the form of electromagnetic
radiation for the heat treatment of food.
Class B equipment means that the equipment is suitable to be used in domestic establishments.
** The depth does not include the door opening handle.
*** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food is
less.
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT TO ALTER DESIGN AND
SPECIFICATIONS WITHOUT NOTICE.

GB-3
EN
OVEN AND ACCESSORIES
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control Panel
10. Waveguide cover (DO NOT REMOVE)
11. Power supply cord
12. Ventilation openings
13. Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are
provided:
(14) Turntable (15) Turntable support (16) Coupling
Place the coupling into the turntable motor shaft
and then place the turntable support in the centre
of the oven floor so that it can freely rotate around
the coupling. Place the turntable onto the turntable
support so that it locates firmly into the coupling.
To avoid turntable damage, ensure dishes and
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
• Always operate the oven with the turntable and turntable support fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage to the
oven.
• All food and containers of food are always placed on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the
oven. This does not affect cooking performance.
Hub (inside)
14. Turntable
(glass)
16. Coupling 15. Turntable
support
1
9
6
4
2
10
4
1121
13

GB-4
2
3
4
5
6
9
8
7
10
1
CONTROL PANEL
1. DIGITAL DISPLAY and INDICATORS
Microwave indicator
Grill indicator (not activated for this
model)
Defrost indicator
High heat indicator
Low heat indicator
Clock indicator
Child lock indicator
Auto menu indicator
Weight indicator
Millilitre indicator
2. Auto Menu options
A1: Reheat
A2: Fresh vegetables
A3: Fish
A4: Meat
A5: Pasta
A6: Boiled potato & Jacket potato
A7: Chilled Pizza
A8: Soup
3. Auto Menu button
4. TIME DEFROST button
5. STOP button
6. ENTRY dial
Rotate to enter the cooking time, time, power
level, weight and select auto menu
7. MICROWAVE button
8. WEIGHT DEFROST button
9. CLOCK SET/ DELAY START button
10. START/ +1min button

GB-5
EN
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS:
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
To avoid the danger of re.
The microwave oven should not be left unattend-
ed during operation. Power levels that are too
high, or cooking times that are too long, may over-
heat foods resulting in a re.
This oven is designed to be used on a countertop only.
It is not designed to be built into a kitchen unit. Do not
place the oven in a cabinet.
The electrical outlet must be readily accessible so that
the unit can be unplugged easily in an emergency.
The AC power supply must be 230 V, 50 Hz, with a
minimum 10 A distribution line fuse, or a minimum 10
A distribution circuit breaker.
A separate circuit serving only this appliance should be
provided.
Do not place the oven in areas where heat is generated.
For example, close to a conventional oven.
Do not install the oven in an area of high humidity or
where moisture may collect.
Do not store or use the oven outdoors.

GB-6
IMPORTANT SAFETY INSTRUCTIONS
If smoke is observed, switch o or unplug the
oven and keep the door closed in order to stie
any ames.
Use only microwave-safe containers and utensils.
See Page GB-24. Utensils should be checked to
ensure that they are suitable for use in microwave
ovens.
When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of
ignition.
Clean the waveguide cover, the oven cavity, the
turntable and turntable support after use. These
must be dry and free from grease. Built-up grease
may overheat and begin to smoke or catch re.
Do not place flammable materials near the oven or
ventilation openings.
Do not block the ventilation openings.
Remove all metallic seals, wire twists, etc., from food
and food packages. Arcing on metallic surfaces may
cause a re.
Do not use the microwave oven to heat oil for deep
frying. The temperature cannot be controlled and the
oil may catch re.
To make popcorn, use only special microwave popcorn
makers.
Do not store food or any other items inside the oven.
Check the settings after you start the oven to ensure
the oven is operating as desired.

GB-7
EN
IMPORTANT SAFETY INSTRUCTIONS
To avoid overheating and fire, special care must be
taken when cooking or reheating foods with a high
sugar or fat content, for example, Sausage rolls, Pies
or Christmas pudding. See the corresponding hints in
the operation manual.
To avoid the possibility of injury
WARNING:
Do not operate the oven if it is damaged or
malfunctioning. Check the following before use:
a) The door; make sure the door closes properly and
ensure it is not misaligned or warped.
b) The hinges and safety door latches; check to make
sure they are not broken or loose.
c) The door seals and sealing surfaces; ensure that they
have not been damaged.
d) Inside the oven cavity or on the door; make sure
there are no dents.
e) The power supply cord and plug; ensure that they
are not damaged.
If the door or door seals are damaged, the oven
must not be operated until it has been repaired by a
competent person.
Never adjust, repair or modify the oven yourself.
It is hazardous for anyone other than a competent
person to carry out any service or repair operation
which involves the removal of a cover which gives
protection against exposure to microwave energy.

GB-8
IMPORTANT SAFETY INSTRUCTIONS
Do not operate the oven with the door open or alter
the door safety latches in any way. Do not operate the
oven if there is an object between the door seals and
sealing surfaces.
Do not allow grease or dirt to build up on the door
seals and adjacent parts. Clean the oven at regular
intervals and remove any food deposits.
Follow the instructions for "Care and Cleaning"
on page GB-25. Failure to maintain the oven in a
clean condition could lead to a deterioration of
the surface that could adversely aect the life of
the appliance and possibly result in a hazardous
situation.
Individuals with PACEMAKERS should check with their
doctor or the manufacturer of the pacemaker for
precautions regarding microwave ovens.
To avoid the possibility of electric shock
Under no circumstances should you remove the outer
cabinet.
Never spill or insert any objects into the door lock
openings or ventilation openings. In the event of a
spill, turn off and unplug the oven immediately, and
call an authorised SHARP service agent.
Do not immerse the power supply cord or plug in
water or any other liquid.
Do not let the power supply cord hang over the edge
of a table or work surface.
