Sharp R-600W User manual

FORNO A MICROONDE CON GRILL - MANUALE D’ISTRUZIONI
MICROWAVE OVEN WITH GRILL - OPERATION MANUAL
800 W (IEC 60705)
Importante
Important
ITALIANO ENGLISH
R-600(W)W

I
Questo manuale di istruzioni contiene importanti informazioni da leggere attentamente prima di utilizzare il forno a microonde.
Importante: Potrebbero esserci seri rischi per la salute se non si seguono le istruzioni di questo manuale o se il forno viene modicato
e funziona con lo sportello aperto.
GB
This operation manual contains important information which you should read carefully before using your microwave oven.
Important: There may be a serious risk to health if this operation manual is not followed or if the oven is modied so that it operates
with the door open.

GB-1
ENGLISH
GB

GB-2
SPECIFICATIONS
CONTENTS
INFORMATION ON PROPER DISPOSAL ......................................................................................................................................1
CONTENTS ...........................................................................................................................................................................................2
SPECIFICATIONS ................................................................................................................................................................................2
OVEN AND ACCESSORIES ..............................................................................................................................................................3
CONTROL PANEL ............................................................................................................................................................................... 4
IMPORTANT SAFETY INSTRUCTIONS .....................................................................................................................................5-15
INSTALLATION ..................................................................................................................................................................................16
OPERATION ...................................................................................................................................................................... 18
SUITABLE OVENWARE ...................................................................................................................................................................19
CARE AND CLEANING ...................................................................................................................................................................
SERVICE ADDRESSES ........................................................................................................................................................................ I
Operation manual
Model name:
AC Line Voltage : 230 V, 50 Hz single phase
Distribution line fuse/circuit breaker : 10 A
AC Power required: Microwave : 1270 W
Output power: Microwave : 800 W
Grill : 1000 W
O Mode (Energy Save Mode) : less than 1.0 W
Microwave Frequency : 2450 MHz*
Outside Dimensions (W) x (H) x (D)** mm : 440 x 259 x 338
Cavity Dimensions (W) x (H) x (D)*** mm : 306 x 206 x 304
Oven Capacity : 20 litres***
Turntable : ø 255 mm
Weight : approx. 11,3 kg
Oven lamp : 25 W/230 V
* This Product fulls the requirement of the European standard EN55011.
In conformity with this standard, this product is classied as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency energy in the form of electromagnetic
radiation for the heat treatment of food.
Class B equipment means that the equipment is suitable to be used in domestic establishments.
** The depth does not include the door opening handle.
*** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food is
less.
AS PART OF A POLICY OF CONTINUOUS IMPROVEMENT, WE RESERVE THE RIGHT TO ALTER DESIGN AND SPECIFICA-
TIONS WITHOUT NOTICE.
2
R-600(W)W
0
................

GB-3
ENGLISH
OVEN AND ACCESSORIES
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
• After cooking fatty foods without a cover, always clean the cavity and especially the grill heating element
thoroughly, these must be dry and free from grease. Built-up grease may overheat and begin to smoke or
catch fire.
• Always operate the oven with the turntable and turntable support fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage to the
oven.
• All food and containers of food are always placed on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the
oven. This does not affect cooking performance.
WARNING: This symbol means that the surfaces are liable to get hot during use. The door, outer
cabinet, oven cavity, accessories and dishes will become very hot during operation. To prevent burns,
always use thick oven gloves.
OVEN
1. Door
2. Door hinges
3. Oven lamp
4. Waveguide cover (DO NOT REMOVE)
5. Control panel
6. Coupling
7. Door latches
8. Oven cavity
9. Door seals and sealing surfaces
10. Door safety latches
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door handle
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Turntable support (17) Coupling
(18) Rack
• Place the turntable support in the centre of the
oven floor so that it can freely rotate around the
coupling. Then place the turntable on to the turn-
table support so that it locates firmly into the cou-
pling.
• To avoid turntable damage, ensure dishes and con-
tainers are lifted clear of the turntable rim when
removing them from the oven.
For use of the rack, refer to the grilling sections on
page GB-10.
Never touch the grill when it is hot.
NOTE: When you order accessories, please mention
two items: part name and model name to your deal-
er or SHARP authorised service agent.
Hub (inside)
15. Turntable
(glass)
17. Coupling 16. Turntable
support
18. Rack
11
12
13
12 3
5
10 9 8
14 6 4 7

GB-4
CONTROL PANEL
1
2
1.
2. TIMER SELECTION
POWER SELECTION
