Sharp 8M-B32C1 User manual

8M-B32C1
LCD MONITOR
OPERATION MANUAL

Information on the Disposal of this Equipment and its Batteries
IF YOU WISH TO DISPOSE OF THIS EQUIPMENT OR ITS BATTERIES, DO NOT USE THE ORDINARY WASTE BIN,
AND DO NOT PUT THEM INTO A FIREPLACE!
Used electrical and electronic equipment and batteries should always be collected and treated SEPARATELY in accordance
with local law.
Separate collection promotes an environment-friendly treatment, recycling of materials, and minimizing final disposal of
waste. IMPROPER DISPOSAL can be harmful to human health and the environment due to certain substances! Take USED
EQUIPMENT to a local, usually municipal, collection facility, where available.
Remove USED BATTERIES from equipment, and take them to a battery collection facility; usually a place where new
batteries are sold.
If in doubt about disposal, contact your local authorities or dealer and ask for the correct method of disposal.
ONLY FOR USERS IN THE EUROPEAN UNION, AND SOME OTHER COUNTRIES; FOR INSTANCE NORWAY AND
SWITZERLAND: Your participation in separate collection is requested by law.
The symbol shown above appears on electrical and electronic equipment and batteries (or the packaging) to remind users
of this. If ‘Hg’ or ‘Pb’ appears below the symbol, this means that the battery contains traces of mercury (Hg) or lead (Pb),
respectively.
Users from PRIVATE HOUSEHOLDS are requested to use existing return facilities for used equipment and batteries.
Batteries are collected at points of sale. Return is free of charge.
If the equipment has been used for BUSINESS PURPOSES, please contact your SHARP dealer who will inform you about
take-back. You might be charged for the costs arising from take-back. Small equipment (and small quantities) might be taken
back by your local collection facility. For Spain: Please contact the established collection system or your local authority for
take-back of your used products.

3E
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within
a triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within a triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: HDMI input terminal,
DisplayPort input terminal, and USB port.
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
FOR CUSTOMERS IN U.K.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
GREEN-AND-YELLOW: Earth
BLUE: Neutral
BROWN: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the
terminals in your plug proceed as follows:
• The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the
letter Eor by the safety earth or coloured green or green-and-yellow.
• The wire which is coloured BLUE must be connected to the terminal which is marked with the letter Nor coloured black.
• The wire which is coloured BROWN must be connected to the terminal which is marked with the letter Lor coloured red.
Ensure that your equipment is connected correctly. If you are in any doubt consult a qualied electrician.
“WARNING: THIS APPARATUS MUST BE EARTHED.”

4
E
Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your
product, please read the Safety Precautions carefully before using this product.
SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can
result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing,
operating and cleaning the product. To ensure your safety and prolong the service life of your LCD product, please read the
following precautions carefully before using the product.
1. Read instructions — All operating instructions must be read and understood before the product is operated.
2. Keep this manual in a safe place — These safety and operating instructions must be kept in a safe place for future
reference.
3. Observe warnings — All warnings on the product and in the instructions must be observed closely.
4. Follow instructions — All operating instructions must be followed.
5. Cleaning — Unplug the power cord from the power outlet before cleaning the product. Use a dry cloth to clean the product.
Do not use liquid cleaners or aerosol cleaners. Do not use dirty cloths. Doing so may damage the product.
6. Attachments — Do not use attachments not recommended by the manufacturer. Use of inadequate attachments can result
in accidents.
7. Water and moisture — Do not use the product near water. Do not install the product in a place where water may splash onto
it. Be careful of equipment which drains water such as an air-conditioner.
8. Ventilation — The vents and other openings in the cabinet are designed for ventilation.
Do not cover or block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life
of the product. Do not place the product on a sofa, rug or other similar surface, since they can block ventilation openings.
Do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
9. Power cord protection — The power cords must be routed properly to prevent people from stepping on them or objects from
resting on them.
10. The screen used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the screen breaks.
11. Overloading — Do not overload power outlets or extension cords. Overloading can cause fire or electric shock.
12. Entering of objects and liquids — Never insert an object into the product through vents or openings. High voltage flows in
the product, and inserting an object can cause electric shock and/or short internal parts.
For the same reason, do not spill water or liquid on the product.
13. Servicing — Do not attempt to service the product yourself. Removing covers can expose you to high voltage and other
dangerous conditions. Request a qualified service person to perform servicing.
14. Repair — If any of the following conditions occurs, unplug the power cord from the power outlet, and request a qualified
service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls
not described in the instructions can cause damage, which often requires extensive adjustment work by a qualified
technician.
e. When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product
needs servicing.
15. Replacement parts — In case the product needs replacement parts, make sure that the service person uses replacement
parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of
unauthorized parts can result in fire, electric shock and/or other danger.
16. Safety checks — Upon completion of service or repair work, request the service technician to perform safety checks to
ensure that the product is in proper operating condition.
17. Wall mounting — When mounting the product on a wall, be sure to install the product according to the method
recommended by the manufacturer.
18. Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).
DEAR SHARP CUSTOMER

5E
SAFETY PRECAUTIONS (Continued)
19. Usage of the monitor must not be accompanied by fatal risks or dangers that, could lead directly to death, personal injury,
severe physical damage or other loss, including nuclear reaction control in nuclear facility, medical life support system, and
missile launch control in a weapon system.
20. Do not stay in contact with the parts of the product that become hot for long periods of time. Doing so may result in
low-temperature burns.
21. Do not modify this product.
WARNING:
An apparatus with CLASS I construction shall be connected to a MAIN socket outlet with a protective earthing connection.
STABILITY HAZARD
If a monitor is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries,
particularly to children, can be avoided by taking simple precautions such as:
• Using fixing devices like wall mount brackets recommended by the manufacturer.
• Only using furniture that can safely support the monitor.
• Ensuring the monitor is not overhanging the edge of the supporting furniture.
• Not placing the monitor on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the
monitor to a suitable support.
• Not standing the monitors on cloth or other materials placed between the monitor and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the monitor or its controls.
• This equipment is not suitable for use in locations where children are likely to be present unsupervised.
Especially for child safety
- Don’t allow children to climb on or play with the monitor.
- Don’t place the monitor on furniture that can easily be used as steps, such as a chest of drawers.
- Remember that children can become excited while watching a program, especially on a “larger than life” monitor. Care
should be taken to place or install the monitor where it cannot be pushed, pulled over, or knocked down.
- Care should be taken to route all cords and cables connected to the monitor so that they cannot be pulled or grabbed by
curious children.

6
E
- The TFT color LCD panel used in this monitor is made with
the application of high precision technology. However, there
may be minute points on the screen where pixels never light
or are permanently lit. Also, if the screen is viewed from an
acute angle there may be uneven colors or brightness. Please
note that these are not malfunctions but common phenomena
of LCDs and will not affect the performance of the monitor.
- Do not display a still picture for a long period, as this could
cause a residual image.
- Do not press the monitor surface. Doing so may cause
display unevenness.
- Never rub or tap the monitor with hard objects.
- Please understand that SHARP CORPORATION bears no
responsibility for errors made during use by the customer or
a third party, nor for any other malfunctions or damage to this
product arising during use, except where indemnity liability is
recognized under law.
- This monitor and its accessories may be upgraded without
advance notice.
- Do not use the monitor where there is a lot of dust, where
humidity is high, or where the monitor may come into contact
with oil or steam. Do not use in an environment where
there are corrosive gases (sulfur dioxide, hydrogen sulfide,
nitrogen dioxide, chlorine, ammonia, ozone, etc.). As this
could lead to fire.
-
Ensure that the monitor does not come into contact with water
or other fluids. Ensure that no objects such as paper clips or
pins enter the monitor as this could lead to fire or electric shock.
- Do not place the monitor on top of unstable objects or in
unsafe places. Do not allow the monitor to receive strong
shocks or to strongly vibrate. Causing the monitor to fall or
topple over may damage it.
- Do not use the monitor near heating equipment or in places
where there is likelihood of high temperature, as this may
lead to generation of excessive heat and outbreak of fire.
- Do not use the monitor in places where it may be exposed to
direct sunlight. Risk of cabinet deformation and failure if the
monitor is used in direct sunlight.
- Please be sure to constantly remove dust and garbage that
has attached to the ventilation opening. If dust collects in the
ventilation opening or the inside of the monitor, it may lead to
excessive heat, outbreak of fire, or malfunction.
Please request a cleaning of the inside of the monitor from
an authorized SHARP servicing dealer or service center.
- When using this monitor in a portrait orientation, prepare
portrait-oriented content in advance.
- The power outlet shall be installed near the equipment and
shall be easily accessible.
The Power Cord
- Use only the power cord supplied with the monitor.
- Do not damage the power cord nor place heavy objects on
it, stretch it or over bend it. Also, do not add extension cords.
Damage to the cord may result in fire or electric shock.
- Do not use the power cord with a power tap.
Adding an extension cord may lead to fire as a result of
overheating.
- Do not remove or insert the power plug with wet hands.
Doing so could result in electric shock.
- Unplug the power cord if it is not used for a long time.
- Do not attempt to repair the power cord if it is broken or
malfunctioning. Refer the servicing to the service representative.
Manual Scope
- The terms HDMI, HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing Administrator, Inc.
- DisplayPort is a registered trademark of Video Electronics
Standards Association.
- VESA is either registered trademark or trademark of Video
Electronics Standards Association in the United States and/
or other countries.
- All other brand and product names are trademarks or
registered trademarks of their respective holders.
- This product comes with RICOH Bitmap Fonts produced and
sold by RICOH COMPANY, LTD.
- Language of OSD menu used in this manual is English by
way of example.
- Illustrations in this manual may not exactly represent the
actual product or display.
- This manual assumes use in landscape orientation, except
where specifically noted.
LED Backlight
● The LED backlight in this product has a limited lifetime.
* If the screen gets dark or does not turn on, it may be
necessary to replace the LED backlight.
* This LED backlight is exclusive to this product and must
be replaced by an authorized SHARP servicing dealer
or service center. Please contact an authorized SHARP
servicing dealer or service center for assistance.
Fan
● The fan in this product has a limited lifetime.
● Please contact an authorized SHARP servicing dealer or
service center for assistance with fan replacement.
TIPS AND SAFETY INSTRUCTIONS

7E
MOUNTING PRECAUTIONS
• This product is for use indoors.
• When moving the monitor, be sure to hold its sides or
bottom. Do not hold the LCD panel or buttons. This may
cause product damage, failure, or injury. This may cause
product damage, failure, or injury.
• Use the monitor with the surface perpendicular to a level
surface.
• This monitor should be used at an ambient temperature
between 41°F (5°C) and 95°F (35°C).
Provide enough space around the monitor to prevent heat
from accumulating inside.
For the monitor in landscape orientation
7-7/8 [200]
Unit: inch [mm]
3-1/4 [82]
2-13/16 [71]
2
[50]
2
[50]
For the monitor in portrait orientation
1-7/16 [36]
7-7/8 [200] 6 [153]
Unit: inch [mm]
Power LED
2
[50]
2
[50]
• Temperature condition may change when using the monitor
together with the optional equipments recommended by
SHARP. In such cases, please check the temperature
condition specified by the optional equipments.
• Do not block any ventilation openings. If the temperature
inside the monitor rises, this could lead to a malfunction.
• Do not place the monitor on a device which generates heat.
• To install the monitor in portrait orientation, a mounting
bracket compliant with VESA specifications is required.
A stand supplied with this product cannot be used for
installation in portrait orientation.
• Adhere to the following when installing the monitor in its
portrait orientation. Failing to adhere to the following may
cause malfunctions.
- Install the monitor such that the power LED is located on
the bottom side.
- Set the PORTRAIT/LANDSCAPE INSTALL in the
MONITOR menu to PORTRAIT. (See page 23.)
- Be sure to clamp the power cord (supplied) onto the cable
clamp attachment using the supplied cable clamp. When
clamping the power cord, take care not to stress the
terminal of the power cord. Do not bend the power cord
excessively.
Power cord
(Supplied)
Cable clamp
attachment
Cable clamp
• After mounting, please carefully ensure the monitor is
secure, and not able to come loose from the wall or mount.

8
E
nRemoving the stand
Caution
• If there are cables already connected, disconnect them all.
1.Spread a thick, soft cloth (blanket, etc.) that will prevent
damage to the LCD panel on a stable flat surface where
the entire monitor can be placed, and place the monitor
with the LCD panel face down on the cloth.
Soft cloth
2.Remove the screws(x2) that fasten the stand.
Keep the removed screws in a safe place.
3.Pull out the stand from the monitor.
4. Install the provided stand mounting part covers to the
holes where the stand was attached to.
Install the covers so that their tabs are on the right side.
tab
Stand mounting part cove
r
1
2
nInstalling the stand
Assemble in the opposite order of the removal.
MOUNTING PRECAUTIONS (Continued)

9E
Supplied Components
If any component should be missing, please contact your dealer.
Liquid Crystal Display Monitor: 1
Cable clamp: 5
Power cord
Stand mounting part cover: 2
CD-ROM: 1
Setup Manual: 1
Contents
IMPORTANT INFORMATION............................................3
DEAR SHARP CUSTOMER..............................................4
SAFETY PRECAUTIONS..................................................4
TIPS AND SAFETY INSTRUCTIONS ...............................6
MOUNTING PRECAUTIONS ............................................7
Supplied Components.....................................................9
Part Names .....................................................................10
Connecting Peripheral Equipment............................... 11
Connecting the Power Cord .........................................13
Binding Cables...............................................................13
Turning Power On/Off....................................................14
Turning on the main power.........................................14
Turning power on/off ..................................................14
Menu Items .....................................................................16
Displaying the menu screen.......................................16
Menu item details .......................................................17
Initialization (Reset)/Functional Restriction Setting
(FUNCTION)....................................................................25
Controlling the Monitor with a computer ....................26
Computer connection .................................................26
Communication conditions .........................................26
Communication procedure .........................................26
Command table..........................................................28
Troubleshooting.............................................................31
Specifications ...............................................................32
* SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission.
TIPS
• Install SHARP Information Display Downloader.
• Download SHARP Display Calibration Utility from SHARP Information Display Downloader.
• When using SHARP Display Calibration Utility, connect the monitor to the computer in which SHARP Display Calibration
Utility using a commercially available USB cable.
• When the Information Display Downloader is installed, you can check and download the most recent versions of the software
programs.
• For detailed information of SHARP Information Display Downloader, refer to its operation manual.
* You must be in a network environment that allows access to the Internet.

10
E
Part Names
nFront view
RETURN ENTERMENU C2C1 INPUT
12345 6 7 8 9 10 11 12
1. INPUT button
2. Custom button 1*
3. Custom button 2*
4. MENU button
5. Cursor control ( ) button
6. Cursor control ( ) button
7. Cursor control ( ) button
8. Cursor control ( ) button
9. ENTER button
10. RETURN button
11. POWER button
12. Power LED
* Menu items can be assigned to custom
buttons by holding the custom button 1 or
2 while the menu item you want to assign is
selected. (See page 23.)
nRear view
15 16
14
14
13
13
21
22 *
20191817
13. Fan
14. Vents
15. AC input terminal (See page 13.)
16. Main power switch (See page 14.)
17. HDMI1 input terminal (See page 11.)
18. HDMI2 input terminal (HDMI × 4)
(See page 11.)
19. HDMI3 input terminal (See page 11.)
20. DisplayPort input terminal (See page 12.)
21. Audio output terminal (See page 12.)
22. USB Type B port (See page 12.)
* Terminal for firmware update
Normally not used.

11 E
Connecting Peripheral Equipment
Caution
• Be sure to turn off the main power switch and disconnect
the plug from the power outlet before connecting/
disconnecting cables. Also, read the manual of the
equipment to be connected.
• Do not use any cable that has a damaged or deformed
terminal. Using such cables may cause malfunctions.
• Do not forcibly bend or apply force to cables. Doing so may
result in wire breakage or other damage.
TIPS
• Images may not be displayed properly depending on the
computer (video card) to be connected.
• If the audio output from the playback device is connected
directly to speakers or other devices, the video on the
monitor may appear delayed from the audio portion.
Audio should be played through this monitor by connecting
the playback device to the monitor, and connecting the
monitor’s audio output to the speakers or other devices.
1. HDMI1 input terminal (8K)
• Use a commercially available HDMI cable (conforming to
the HDMI standard).
To input 4K video, a 4K-compliant cable is required. And
to input 8K video, a 8K-compliant cable is required.
2. HDMI2 input terminal (8K, HDMI×4)
• Use a commercially available HDMI cable (conforming to
the HDMI standard) that supports 4K. All 4 cables must
be identical.
• 8K display is available when all 4 of
4K input signals are
synchronized.
• Connect cables according to the display positions.
• Connect so that output signals from 8K-output-compliant
device are displayed on the appropriate positions.
HDMI2-A HDMI2-B HDMI2-C HDMI2-D
HDMI2-A
HDMI2-C
HDMI2-B
HDMI2-D
• Select an audio input in HDMI2 AUDIO SELECT of
the SETUP menu. (HDMI2-A is selected by factory
default.)
3. HDMI3 input terminal (4K)
• Use a commercially available HDMI cable (conforming to
the HDMI standard).
To input 4K video, a 4K-compliant cable is required.
54321
6

12
E
Connecting Peripheral Equipment
4. DisplayPort input terminal (4K)
• Use a commercially available DisplayPort cable
(conforming to the DisplayPort standard).
To input 4K video, a 4K-compliant cable is required.
5. Audio output terminal
• The output sound varies depending on the input mode.
• The volume of the output sound can be fixed by setting
AUDIO OUTPUT on the SETUP menu.
6. USB Type B port (USB2.0)
• You can control the monitor from a computer. (See page
26.)
• Connect to the computer with a commercially available
USB cable (type A - type B).
• Connect when using SHARP Display Calibration Utility.

13 E
Connecting the Power Cord
Caution
• Use only the power cord supplied with the monitor.
1. Turn off the main power switch.
2. Plug the power cord (supplied) into the AC input
terminal.
3. Plug the power cord (supplied) into the power outlet.
21
For power
outlet
3
AC input
terminal
Power cord (Supplied)
Main power
switch
Binding Cables
The cables connected to the terminals on the rear of the monitor can be fastened with the cable clamp.
Insert the cable clamp into the cable clamp attachment on the rear of the monitor and fasten the cables.
Cable clamp
attachment
Cable
Cable clamp

14
E
Caution
• Turn on the monitor first before turning on the computer or
playback device.
• When switching the main power switch or the POWER
button off and back on, always wait for at least 5 seconds.
A short interval may result in a malfunction.
Turning on the main power
Main power switch
Off mode, when main power is off.
Caution
• The main power must be turned on/off with the main power
switch. Do not connect/disconnect the power cord or turn
the breaker on/off while the main power switch is on.
• For a complete electrical disconnection, pull out the main
plug.
Turning Power On/Off
Turning power on/off
Press the POWER button to turn the power ON/OFF.
Wait for 15 minutes or more before use to stabilize the image
quality.
Power LEDPOWER button
RETURN ENTER
MENU
C2C1
INPUT
Status Status of the monitor
Green lit Power on
Not lit Power off (Standby state*)
Orange lit Input signal waiting state
* Standby mode
TIPS
• When the main power switch is off, the monitor cannot be
turned on.
• If the monitor is in the input signal waiting state and you
press the POWER button, the monitor enters standby state.
• To disable the logo screen from displaying when turning the
power ON, set LOGO SCREEN to OFF on the OTHERS
menu. (See page 23.)

15 E
Turning Power On/Off
Date/time setting
• If the time has yet to be set, the date/time setting screen
appears. Set the date and time.
DATE/TIME SETTING
//
OK:[ENTER] CANCEL:[RETURN]
::
01 01 21
/00 00 :/ 20
1. Press the or button to select the date and time,
and press the or button to change the numerical
values.
2. Press the ENTER button.
• Be sure to set the date and time.
• The date/time setting screen will close automatically if
no operation is performed for about 15 seconds. The
date and time can be set using DATE/TIME SETTING
from the SETUP menu when the date/time setting screen
disappears.
TIPS
• Set the date in “Day/Month/Year” order.
• Set the time on a 24-hour basis.
• The clock is maintained by the internal battery.
• If you already set the time but the date/time setting
screen appears when the power is turned on, the
internal battery may be exhausted. Please contact an
authorized SHARP servicing dealer or service center for
assistance with battery replacement.
• Estimated service life of the internal battery: About 5
years (depending on monitor operation)
• The initial battery was inserted at the factory when the
monitor was shipped, so it may run out of power before
its expected operation life.

16
E
Menu Items
Displaying the menu screen
Video adjustment and settings of various functions are
enabled. This section describes how to use the menu items.
See page 17 for details of each menu items.
Caution
• Do not turn the main power switch off while the menu items
are being displayed. Doing so may initialize the settings.
nExample of operation
(Adjusting VOLUME in the OTHERS menu)
1. Press the MENU button to display the menu screen.
EXTENSION
SETUP
MONITOR
OTHERS
sRGB
OFF
AUTO HDR DETECTION
COLOR MODE
LUMINANCE
LUMINANCE PRIORITY
CONTRAST
BLACK LEVEL
HUE
CHROMA
SHARPNESS
COLOR ADJUSTMENT
ADVANCED
RESET
30
30
30
30
0
80 cd/m2
HDMI1PICTURE
OK:[ENTER] END:[RETURN]
7680x4320 V: 60 Hz H: 270 kHz
2. Press the or button to select OTHERS, and press
the ENTER button.
3. Press the or button to select VOLUME.
▲
OFF
▲
▲
ON
▲
▲
OFF
▲
▲
OFF
▲
POWER MANAGEMENT
OFF IF NO SIGNAL
CONNECT AUTO INPUT SELECT
NO SIGNAL AUTO INPUT SEL.
AUTO INPUT SELECT PRIORITY
CUSTOM BUTTON
INPUT
LOGO SCREEN
VOLUME
MUTE AUDIO
INPUT SIGNAL INFORMATION
MONITOR INFORMATION
15
EXTENSION
SETUP
MONITOR
OTHERS
HDMI1OTHERS
BACK:[RETURN]
7680x4320 V: 60 Hz H: 270 kHz
4. Press the or button to adjust the setting.
▲
OFF
▲
▲
ON
▲
▲
OFF
▲
▲
OFF
▲
EXTENSION
SETUP
MONITOR
OTHERS
POWER MANAGEMENT
OFF IF NO SIGNAL
CONNECT AUTO INPUT SELECT
NO SIGNAL AUTO INPUT SEL.
AUTO INPUT SELECT PRIORITY
CUSTOM BUTTON
INPUT
LOGO SCREEN
VOLUME
MUTE AUDIO
INPUT SIGNAL INFORMATION
MONITOR INFORMATION
20
HDMI1OTHERS
BACK:[RETURN]
7680x4320 V: 60 Hz H: 270 kHz
For items that have , press the ENTER button, make
settings and then press the RETURN button.
5. Press the MENU button to close the menu screen.
TIPS
• The menu will differ depending on the input mode.
• The menu screen will close automatically if no operation
is performed for about 1 minute. (DATE/TIME SETTING
screen will close in about 4 minutes.)
nMenu screen display
▲
OFF
▲
▲
ON
▲
▲
OFF
▲
▲
OFF
▲
EXTENSION
SETUP
MONITOR
OTHERS
POWER MANAGEMENT
OFF IF NO SIGNAL
CONNECT AUTO INPUT SELECT
NO SIGNAL AUTO INPUT SEL.
AUTO INPUT SELECT PRIORITY
CUSTOM BUTTON
INPUT
LOGO SCREEN
VOLUME
MUTE AUDIO
INPUT SIGNAL INFORMATION
MONITOR INFORMATION
15
HDMI1
1 3 2
4
OTHERS
BACK:[RETURN]
7680x4320 V: 60 Hz H: 270 kHz
1 Name of the menu
2 Input mode
3 An item being selected (highlighted)
4 Screen resolution of input signal, and other data.
TIPS
• Items that cannot be selected appear in gray.
(e.g. Function not supported by the current input signal)

17 E
Menu item details
The menu will differ depending on the input mode.
n
AUTO HDR DETECTION
OFF ...... Configure the color mode according to the signal.
ON ........ According to the input HDR signal (HLG or PQ), COLOR MODE automatically switches between HDR AUTO(HLG)
and HDR AUTO(PQ).
AUTO HDR DETECTION can be configured in the following cases:
When COLOR MODE is HDR AUTO(HLG), HDR AUTO(PQ), BT.2020, BT.709, DCI-P3, Adobe RGB, sRGB, or EBU.
COLOR MODE
Changes the color mode on the screen. It cannot be changed when HDR signal is input and AUTO HDR DETECTION is set to
ON.
LUMINANCE
Adjusts the backlight brightness.
LUMINANCE PRIORITY
OFF ...... Displays input video according to each setting parameter in the PICTURE menu.
ON ........ Displays input video with peak brightness of 1000 cd/m2(equivalent).
CONTRAST
Adjusts the difference between the bright and dark portions of the image.
BLACK LEVEL
Adjusts the entire brightness of the video signals.
HUE
Adjusts the hue. Selecting + changes the color towards green, and selecting - changes it towards magenta.
CHROMA
Adjusts the chroma.
SHARPNESS
Adjusts the sharpness.
Menu Items

18
E
COLOR ADJUSTMENT
WHITE BALANCE
THRU ................................. Displays the input signal level as is.
PRESET............................. Selects the color temperature using PRESET.
USER ................................. Adjusts R-/G-/B-CONTRAST and R-/G-/B-OFFSET respectively using USER.
WHITE BALANCE can be configured in the following cases:
• When COLOR MODE is USER1 or USER2.
PRESET
Selects the color temperature when the WHITE BALANCE is set to PRESET.
The setting values are shown for reference. The color temperature of the screen varies over time. This function is not
intended to keep the color temperature constant.
PRESET can be configured in the following cases:
• When COLOR MODE is USER1 or USER2.
USER
Adjusts each item when the WHITE BALANCE is set to USER.
R-CONTRAST.... Adjusts bright-toned red component.
G-CONTRAST ... Adjusts bright-toned green component.
B-CONTRAST.... Adjusts bright-toned blue component.
R-OFFSET ......... Adjusts dark-toned red component.
G-OFFSET......... Adjusts dark-toned green component.
B-OFFSET ......... Adjusts dark-toned blue component.
USER can be configured in the following cases:
• When COLOR MODE is USER1 or USER2.
COPY TO USER
Copies the value of white set for PRESET to the USER setting.
Select ON and then press the ENTER button.
(In the case other than white, color tone may differ from the PRESET.)
COPY TO USER can be configured in the following cases:
• When COLOR MODE is USER1 or USER2.
COLOR GAMUT
Select color gamut.
COLOR GAMUT can be configured in the following case:
• When COLOR MODE is USER1 or USER2.
GAMMA(EOTF)
Select gamma for the current color mode.
GAMMA(EOTF) can be configured in the following case:
• When COLOR MODE is BT.2020, BT.709, DCI-P3, Adobe RGB, sRGB, EBU, USER1, or USER2.
HLG SYSTEM GAMMA
Adjusts system gamma value according to the input HDR (HLG) signal.
HLG SYSTEM GAMMA can be configured in the following cases:
• When COLOR MODE is BT.2100(HLG) or HDR AUTO(HLG).
•
When COLOR MODE is USER1 or USER2, CUSTOM SETTING is OFF, and GAMMA(EOTF) is HYBRID LOG GAMMA(HLG).
• When COLOR MODE is USER1 or USER2, CUSTOM SETTING is ON, Gamma* is HLG*, and LUT (.cube file)* is not
specified.
* They are setting items for Display Calibration Utility.
6-AXIS - HUE
Adjusts color tone with 6 colors of R (red), Y (yellow), G (green), C (cyan), B (blue), and M (magenta).
6-AXIS - CHROMA
Adjusts color vividness with 6 colors of R (red), Y (yellow), G (green), C (cyan), B (blue), and M (magenta).
6-AXIS - VALUE
Adjusts color brightness with 6 colors of R (red), Y (yellow), G (green), C (cyan), B (blue), and M (magenta).
CUSTOM SETTING
Selects how to configure LUMINANCE, WHITE BALANCE, COLOR GAMUT, and GAMMA of the color modes CUSTOM1
and CUSTOM2.
OFF........... LUMINANCE, WHITE BALANCE, COLOR GAMUT, and GAMMA regarding CUSTOM1 and CUSTOM2 can be
selected in the menu screen.
ON............. Configures LUMINANCE, WHITE BALANCE, COLOR GAMUT, and GAMMA regarding CUSTOM1 and
CUSTOM2 using SHARP Display Calibration Utility.
CUSTOM SETTING can be configured in the following case:
• When COLOR MODE is USER1 or USER2.
Menu Items

19 E
Menu Items
ADVANCED
UNIFORMITY
Sets the LCD panel’s discoloration correction level.
OFF.................................... Discoloration will not be corrected.
ON...................................... Discoloration will be corrected.
DYNAMIC RANGE EXPAND
Configures local dimming control and peak brightness.
MODE1 .............................. LOCAL DIMMING: OFF, LUMINANCE: 600cd/m2*
MODE2 .............................. LOCAL DIMMING: ON, LUMINANCE: 600cd/m2*
MODE3 .............................. LOCAL DIMMING: ON, LUMINANCE: 600cd/m2or more*
The peak luminance increases, but it changes depending on a displayed video.
* Luminance and contrast change depending on factors such as input mode and picture settings.
Value of luminance is the standard value at the time of shipment and not a guaranteed value.
In addition, luminance deteriorates by the time. Therefore, the monitor does not maintain constant luminance.
USER SETTING NAME
Arbitrary names can be given to USER1 and USER2 of COLOR MODE.
Press the or button to move the cursor to a character you want to edit, press the or button to swap characters.
Press the INPUT button to switch character types (upper case alphabet, lower case alphabet, numerics, symbols).
Once the edit is complete, press the ENTER button.
Up to 12 characters (single-byte alphanumerics and symbols) can be entered.
USER SETTING NAME can be configured in the following case:
• When COLOR MODE is USER1 or USER2.
DISPLAY COLOR PATTERN
Displays a color pattern. Can be displayed while the menu screen is displayed, so you can refer to the pattern while adjusting
the image. When WHITE, RED, GREEN, or BLUE is displayed, you can set the level in the range of 0 to 255.
OFF...............No pattern display.
WHITE...........White single color pattern display.
RED...............Red single color pattern display.
GREEN .........Green single color pattern display.
BLUE.............Blue single color pattern display.
USER ............Red/green/blue mixed color pattern display. When USER is selected, set each color’s level.
RESET
Resets the values of the PICTURE menu items to the factory default settings except COLOR MODE and AUTO HDR
DETECTION.
The selected item regarding COLOR MODE will be reset.
Select ON and then press the ENTER button.

20
E
Menu Items
nEXTENSION (HDMI1/HDMI2)
LUMINANCE CLIPPING*1*2
Clips area with luminance higher than the one specified in CLIP LUMINANCE according to the input HDR signal.
When PQ signal is input ............Can be selected from OFF, ON, or TONE-MAPPING.
In addition, luminance can be configured from CLIP LUMINANCE. According to the setting,
video display is adjusted as follows.
OFF ON TONE-MAPPING
Displays up to 600 cd/m2following the
PQ curve.
Area with luminance higher than the
one set in CLIP LUMINANCE will be
clipped and displayed.
Displays to avoid excessive change
near the luminance set in CLIP
LUMINANCE.
064256 5121023
0
200
400
600
800
1000
1200
(cd/m2)
Input tone
PQ (SMPTE ST2084) Monitor display
Set luminance
(600cd/m2)
LUMINANCE
(cd/m2)
064256 512 1023
0
200
400
600
800
1000
1200
Input tone
Set luminance
(600cd/m2)
CLIP LUMINANCE
(1000cd/m
2
)
PQ (SMPTE ST2084) Monitor display
LUMINANCE
064512256 1023
PQ (SMPTE ST2084) Monitor display
0
200
400
600
800
1000
1200
Input tone
Set luminance
(600cd/m
2
)
CLIP LUMINANCE
(1000cd/m
2
)
(cd/m2)
LUMINANCE
When HLG signal is input..........Can be selected from OFF or ON. According to the setting, video display is adjusted as follows.
OFF ON
Lowers the overall luminance and displays
so that the luminance of video is wholly
below the set luminance of the monitor.
Area higher than 600 cd/m2will be
clipped and displayed.
0
200
400
600
800
1000
Input tone
HLG (Hybrid Log Gamma) Peak1000 cd/m2 Monitor display
Set luminance
(600cd/m2)
(cd/m2)
064256 512 1023
LUMINANCE
HLG (Hybrid Log Gamma) Peak1000 cd/m
2
Monitor display
0
200
400
600
800
1000
Input tone
Set luminance
(
600cd/m2)
064256 512 1023
(cd/m2)
LUMINANCE
ON, OFF, and TONE-MAPPING of LUMINANCE CLIPPING can be configured in the following cases:
• When COLOR MODE is BT.2100(PQ) or HDR AUTO(PQ).
• When COLOR MODE is USER1 or USER2, CUSTOM SETTING is OFF, COLOR GAMUT is Rec.2020, and GAMMA(EOTF)
is SMPTE ST 2084(PQ).
• When COLOR MODE is USER1 or USER2, CUSTOM SETTING is ON, Color gamut*3is Rec.2020*3, Gamma*3is PQ*3,
and LUT (.cube file)*3is not specified.
OFF and ON of LUMINANCE CLIPPING can be configured in the following cases:
• When COLOR MODE is BT.2100(HLG) or HDR AUTO(HLG).
• When COLOR MODE is USER1 or USER2, CUSTOM SETTING is OFF, COLOR GAMUT is Rec.2020, and GAMMA(EOTF)
is HYBRID LOG GAMMA(HLG).
• When COLOR MODE is USER1 or USER2, CUSTOM SETTING is ON, Color gamut*3is Rec.2020*3, Gamma*3is HLG*3,
and LUT (.cube file)*3is not specified.
*1 These are examples with LUMINANCE set to 600 cd/m2. If LUMINANCE is set lower than 600 cd/m2, the overall
luminance will become low.
*2 Set DYNAMIC RANGE EXPAND to MODE1 or MODE2.
*3 They are setting items for Display Calibration Utility.
Caution
• For HDMI3 input and DisplayPort input, the menu is displayed but the function cannot be enabled.
