Intel®Server Systems SR2520SAFR,
SR2520SAXR and SR2520SAXSR
Spares / Parts List and Configuration Guide
A reference guide to help customers order the necessary components to configure production
Intel®SR2520SA Value 2U Integrated Server Systems
Revision 1.8
April, 2010
Enterprise Platforms and Services Marketing

Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTIONWITH INTEL®PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTYRIGHTS IS GRANTED
BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH
PRODUCTS, INTEL ASSUMES NO LIABILITYWHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,
COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life saving, or life sustaining applications. Intel may make changes to
specifications and product descriptions at any time, without notice.
Intel server boards, server chassis, and processors maycontain design defects or errors known as errata, which maycause
the product to deviate from published specifications. Current characterized errata are available on request.
Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in
the United States and other countries.
*Other brands and names may be claimed as the property of other.
Copyright © 2010 Intel Corporation

3
2

4
Table of Contents
Tableof Contents ............................................................................................................................4
ProductionIntel®SR2520SAServer System Details.......................................................................5
ProductionServerSystem OrderCodes.........................................................................................7
SR2520SAUniqueSparesand Accessories ..................................................................................9
SR2520SAOptionalSparesandAccessories..............................................................................10

5
Production Intel®SR2520SAServer System Details
The following Intel®production SR2520SA Server Systems are offered as pre-integrated server systems. Each SKU includes a
production version of the Intel®Server Board S5000VSA with the rack chassis and the most widely-used keyoptions.
1. Production Intel®Server System SR2520SAFR includes:
•One production Intel®S5000VSA4DIMMR Server Board
CEK spring clips
ATX I/O shield and gasket
Cables: IDE, COM2, and SATA
Resource CD-ROM with utilities, drivers, documentation, and technical information
Four (4) FB-DIMM memoryslots
Five (5) low-profile expansion slots
•One production Intel®SR2520SA 2U Rack Mount Server chassis
Supporting up to six (6) fixed SATA 3.5-inch hard disk drives (needs an extra drive enclosure for six-
drive support)
5.25-inch Peripheral bay
Integrated USB-based floppy disk drive and control panel with one front panel USB port
Non-redundant cooling
Air ducts and baffles
Six (6) SATA cables
600-W Fixed power supply
Basic rail kit ONLY (does not support a cable management arm)
Attention Document
Quick Start Guide
Quick Reference Label
Intel®Deployment Assistant and Intel Server Management Software CD
2. Production Intel®Server System SR2520SAXR includes:
•One production Intel®S5000VSASATAR Server Board
CEK spring clips
ATX I/O shield and gasket
Cables: IDE, COM2, and SATA
Resource CD-ROM with utilities, drivers, documentation, and technical information
Eight (8) FB-DIMM memory slots
Five (5) low-profile expansion slots

6
•One production Intel®SR2520SA 2U Rack Mount Server chassis
Hot-swap static SATA backplane with Drive Activity and Drive Failure LEDs
Supporting up to six (6) hot-swap SATA 3.5-inch hard disk drives
Four (4) 3.5-inch hard disk drive carriers and two (2) blank (empty) carriers.
5.25-inch Peripheral bay
Integrated USB-based floppy disk drive and control panel with one USB port
Non-redundant cooling
Air ducts and baffles
Six (6) SATA cables
One of two (1 of 2) 600-W redundant power supply module and one (1) power distribution board
Basic rail kit (does not support a cable management arm)
Attention Document
Quick Start Guide
Quick Reference Label
Intel®Deployment Assistant and Intel®Server Management Software CD
3. Production Intel®Server System SR2520SAXSR includes:
•One production Intel®S5000VSASAS Server Board
CEK spring clips
ATX I/O shield and gasket
Cables: IDE, COM2, and SATA
Resource CD-ROM with utilities, drivers, documentation, and technical information
Eight (8) FB-DIMM memory slots
Five (5) low-profile expansion slots
•One production Intel®SR2520SA 2U Rack Mount Server chassis
Hot-swap static SAS backplane with Drive Activity and Drive Failure LEDs
Supporting up to six (6) hot-swap SAS/SATA 3.5-inch hard disk drives
Four (4) 3.5-inch hard disk drive carriers and two (2) blank (empty) carriers.
5.25-inch Peripheral bay
Integrated USB-based floppy disk drive and control panel with one USB port
Non-redundant cooling
Air ducts and baffles
Six (6) SATA cables
One of two (1 of 2) 600-W redundant power supply module and one (1) power distribution board
Basic rail kit (does not a cable management arm)
Attention Document
Quick Start Guide
Quick Reference Label
Intel®Deployment Assistant and Intel®Server Management Software CD

7
Production Server System Order Codes
Product Code
MM # UPC Qty. Per Description
SR2520SAFR 892236 007358581
9
7311 1
SR2520SA/S5000VSA4DIMMR 2U integrated platform. Includes
server board, 2U fixed 3.5-inch SATA drive chassis with non-
redundant cooling, USB-based slim-line floppy drive, and 600-W
fixed power supply
SR2520SAFRNA 893528 007358581
9
7328 1
SR2520SA/S5000VSA4DIMMR 2U integrated platform. Includes
server board, 2U fixed 3.5–inch SATA drive chassis with non-
redundant cooling, USB-based slim-line floppy drive, and 600-W
fixed power supply. Also includes a North American Power Cord.
SR2520SAXR 902297 007358581
9
7335 1
SR2520SA/S5000VSASATAR 2U integrated platform. Includes
server board, 2U 3.5-inch SATA drive chassis with “passive” (non-
expander) SAS hot-swap backplane, four (4) 3.5-inch HDD carriers
and two blank (empty) carriers, non-redundant cooling, USB-based
slimline floppy drive, and one (of two) 600-W redundant power suppl
y
modules.
Install Hint:Connect Power to Backplane, six Black SATA ports on
the motherboard to the six blue SAS ports on SAS BP and the
SGPIO on BP to the motherboard.
SR2520SAXRN
A
902307 007358581
9
7342 1
SR2520SA/S5000VSASATAR 2U integrated platform. Includes
server board, 2U 3.5-inch SATA drive chassis with “passive” (non-
expander) SAS hot-swap backplane, four (4) 3.5-inch HDD
carriers+2 blank (empty) carriers, non-redundant cooling, USB-
based slim-line floppy drive, and one (of two) 600-W redundant pow
e
supply modules. Also includes a North American Power Cord.
Install Hint:Connect Power to Backplane, six black SATA ports on
the motherboard to the six blue SAS Ports on SAS BP and the
SGPIO on BP to the motherboard.
SR2520SAXSR 902296 007358581
9
7366 1
SR2520SA/S5000VSASASR 2U integrated platform. Includes
server board, 2U 3.5-inch SAS/SATA drive chassis with “active”
(expander) SAS hot-swap backplane, four (4) 3.5-inch HDD
carriers and two blank (empty) carriers, non-redundant cooling, USB
-
based slim-line floppy drive, and one (of two) 600-W redundant

8
power supplymodules.
Install Tip:
Connect the power to the backplane, connecting the first two
blue SAS ports on the motherboard to the two blue SAS Ports
on the SAS BP and the IPMB on BP to the motherboard.
SR2520SAXSRNA 902306 0073585819
7359 1
SR2520SA/S5000VSASASR 2U integrated platform. Includes
server board, 2U 3.5-inch SAS/SATA drive chassis with “active”
(expander) SAS hot-swap backplane, four (4) 3.5-inch HDD
carriers and two blank (empty) carriers, non-redundant cooling,
USB- based slim-line floppy drive, and one (of two) 600-W
redundant power supplymodules. Also includes a North
American Power Cord.
Install Tip:
Connect the power to the backplane, connecting the first two
blue SAS Ports on the motherboard to the two blue SAS Ports
on the SAS BP and the IPMB on BP to the motherboard.
Please note: The above SKUs do not include processors, heatsinks, DDR2 Fully-Buffered DIMM (FBD) system memory,
hard drives, and other customer configuration items.

9
SR2520SAUnique Spares and Accessories
Product Code
MM # UPC Qty.
Included Descrip
tion
ASR600WPSU 903006 0073585817
6989 1
SR2520SA second 600-W Redundant Power Supply
FSR600WFPS 886906 0073585819
1098 1
SR2520SA spare 600-W Fixed Power Supply
FSR2520PDB 887429 0073585819
1104 1
Spare power distribution board for SR2520SA redundant
power supplysystems.
FSR2520BPSAS 887411 0073585819
2255 1
SAS/SATA Hot-swap static backplane with Drive Activity
and
Drive Failure LEDs.
FSR2520BPSATA 887412 0073585819
2262 1
SATA hot-swap static backplane with Drive Activity and
Drive Failure LEDs
FOWSPRKIT 887409 0073585819
1142 1
Mechanical spares kit including:
Front panel assembly
(1) Hot drive carrier
I/O shield
CPU duct
Fan mount grommets
(1) CD-ROM cable
(1) USB floppy cable and front panel cable
(6) Fixed SATA cables
(6) Static SATA cables
(1) Active SAS cable
(1) SGPIO cable
(1) I2C cable
Power supply filler panel
AOWFANKIT 887431 0073585819
1159 1 Spare fan kit containing two (2) fans - 1 of each fan type
(system fan or CPU fan) used in the SR2520SA chassis.

10
SR2520SAOptional Spares and Accessories
Product Code MM # UPC Qty. Per Descrip
tion
ADRBEZBLACK 857675 0073585816
5129 10
SR2520SA locking Black Bezel
FXX10DVCARBLK 880265 0073585818
1938 10
Black 3.5-inch hot-swap drive carrier spare
AXXBASICRAIL 881096 0073585818
4748 1
Spare Basic slide rail kit – does not support a cable
management arm.
AXXUSBFLOPPY 881267 0073585818
3260 1
Spare internal slim-line floppy kit.
FPWRCABLENA 879287 0073585818
1129
Spare North American power supplycable.
