Sharp KB-6100N User manual

SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE THIS INSTALLATION MANUAL FOR LOCAL ELECTRICAL INSPECTOR’S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
For SAFETY CONSIDERATIONS do not install drawer in any combustible cabinetry, which is not in accordance
with the stated clearances and dimensions on page 2. See Figures 1 and 2.
Warming DraWer
INStALLAtIoN MANuAL
Unpacking yoUr Warming DraWer
Prepare an adjacent•
a rea on th e f loor
next to the shipping
carton with protective
material. Open the
top of the carton and
lift Warming Drawer
up and out on to the
protective material.
Remove all packing•
material and tape from
the product.
Locate the operation•
and installationmanual
that also includes four
(4) mounting screws.
Follow all instructions•
in the inst a llation
manual to complete
installation.
important
notes to the installer
Read all of the Installation Manual before installing the•
Warming Drawer.
Remove all packing material before connecting the electrical•
supply.
Observe all governing codes and ordinances.•
Be sure to leave these instructions with the consumer.•
important notes to the consUmer
Keep this manual with your Operation Manual for future
reference.
As when using any Warming Drawer oven generating heat,•
there are certain safety precautions you should follow. These
are listed in the Operation Manual. Read all and follow
carefully.
Be sure your Warming Drawer is installed and grounded•
properlybyaqualiedinstallerorservicetechnician.
important safety instrUctions
If the information in this manual is not followed
exactly, a re or electrical shock may result that could cause
property damage, personal injury or death.
To reduce the risk of tipping, the Warming
Drawer must be secured by a properly installed Anti-Tip
block.
This Warming Drawer must be electrically grounded in•
accordance with local codes.
Make sure the wall coverings and the cabinets around the•
Warming Drawer can withstand the heat generated by the
Warming Drawer.
Never leave children alone or unattended in the
area where a Warming Drawer is in use. Never leave the drawer
open when the Warming Drawer is unattended.
Stepping, leaning or sitting on the drawer
may result in serious injuries and can also cause damage to the
Warming Drawer.
Do not use the Warming Drawer as a storage space• . This
creates a potentially hazardous situation.
CLEARANCES ANd dIMENSIoNS
Name Plate
Drawer Guides
Variable Humidity
Control
Air Vents
clearances anD Dimensions

E2
30"
cabinet min.
Floor must
support 100 lbs.
9" to bottom
of Anti-Tip
block
24 " to top of floor
(recommended)
6"
Allow
overlap.
28
opening
""
Allow
overlap
Allow
overlap
"
min depth
23
Figure 1
36"
countertop
height
"
1 x 1
Anti-Tip
block
""
"
Allow
5/8"
overlap 9 1/8" opening
Figure 4
30"
cabinet min.
84"
wall
cabinet
Optional
wall oven
cutout
illustrated
in sketch
Floor must
support 100 lbs.
24 " to top of floor
(recommended)
(6")
2" min.
Allow
5/8"
overlap 9 1/8" opening
Allow
overlap.
28
opening
Allow
overlap.
""
Allow "
overlap.
min depth
23
"9" to bottom
of Anti-Tip
block
1 x 1
Anti-Tip
block
""
"
Figure 2
"
36"
countertop
height
30"
cabinet min.
28
opening Allow
"
overlap.
Allow "
overlap.
Allow "
overlap.
4"
5"
Electrical outlet
location
Floor must
support
100 lbs.
14 "
to bottom
of Anti-Tip
block
3"
6"
23 "
min depth
Allow
"
overlap.
14 "
opening
Floor must
support
100 lbs.
"
1 x 1
Anti-Tip
block
"
1 x 1
Anti-Tip
block
""
2" min.
Allow
overlap.
Allow
overlap.
"
"
Allow "
overlap.
min depth
23
7 " to top of floor
(recommended)
9"
"
Allow
5/8"
overlap 9 1/8" opening
28
opening
"
Figure 3
10
30"
23"
8
"28 "9
"
"
Dimensions that are shown in Figures 1 and 2 must be used.•
Given dimensions provide minimum clearance. The electrical
outlet can be located in the shaded areas shown in Figure 6.
Contact surface must be solid and level. Pay special attention•
totheooronwhichtheWarmingDrawerwillsit.Theoorof
the opening should be constructed of plywood strong enough
to support the weight of the oven (about 100 pounds).
Figures 1, 2 and 4 contain many
Warming Drawer measurements
for reference when planning the
drawer’s location. See Figure 5,
page 3, for suggested Warming
Drawer electrical layout.
Optional Microwave
Drawer Cutout
illustrated in sketch.
Check location where the Warming Drawer will be installed•
for proper electrical supply.
Your oven can be built into a cabinet or wall by itself or under•
a gas/electric wall oven, or Warming Drawer.
Besurethattheclearanceoftheoorbetweenthewalloven•
and the Warming Drawer is a minimum of 2-inches.
WARMING dRAWER MEASuREMENtS
clearances anD Dimensions

E3
groUnDing instrUctions
anti-tip Block
NORMAL INSTALLATION STEPS
ANTI-TIP BLOCK INSTALLATION INSTRuCTIONS
To reduce the risk of tipping of the drawer, the Anti-Tip block
mustbeproperlyinstalledlocated9-inchesabovetheooron
which the Warming Drawer will sit. The 6-inch Anti-Tip block
must be provided by the installer. See Figures 1, 2, and 4. The
Anti-Tip block prevents serious injury that might result from
spilled hot liquids.
If the Warming Drawer is ever moved to a different location, the
Anti-Tip block must also be moved and installed. When installed
to the wall, make sure that the screws completely penetrate the dry
wall and are secured in wood or metal so that the block is totally
stable. When fastening, be sure that the screws do not penetrate
electrical wiring or plumbing.
4"
(101.6 mm)
9" (228.6 mm)
Electrical Outlet
Location
Anti-tip
Block
6" (153 mm)
Figure 5
38"
5"
10"
10"
10"
6"
10"
10"
30"
5"
Electrical
outlet zone
centerline
Locate outlet in available space
adjacent to the warming drawer.
Solid
Floor
9" cutout opening
1½"x 1½"
Anti-tip
electrical oUtlet
The electrical requirements are a 120 volt 60 Hz, AC only, 15
amp. or more protected electrical supply. It is recommended that
a separate circuit serving only this appliance be provided.
The drawer is equipped with a 3-prong grounding plug. It must
be plugged into a wall receptacle that is properly installed and
grounded.Shouldyouonlyhavea2-prongoutlet,haveaqualied
electrician install a correct wall receptacle.
Note: If you have any questions about the grounding or electrical
instructions,consultaqualiedelectricianorserviceperson.
Figure 6
This appliance must be grounded. The Warming Drawer is equipped with a cord having a grounding
wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed
and grounded in accordance with the National Electrical Code and local codes and ordinances.
In the event of an electrical short circuit, grounding reduces risk of electric shock by providing
an escape wire for the electric current.
– Improper use of the grounding plug can result in a risk of electric shock. Do
notuseanextensioncord.Ifthepowersupplycordistooshort,haveaqualiedelectricianor
serviceman install an outlet near the appliance.
3-Prong Plug
Grounding Pin
3-Prong Receptacle
Grounded Receptacle Box
Permanent and Correct Installation
DraWer installation
Carefully guide the drawer into the prepared opening. Avoid•
pinching the cord between the oven and the wall.
Slidethedrawerallthewayuntilthemountingangeisush•
with the face of the cabinet.
Open the drawer. Using the 4 holes on the drawer as a template,•
predrill the cabinet using a 1/16" bit. See Figure 7A.
Secure the drawer with the 4 screws supplied. See Figure 7B.•
Plug the power supply cord into the electrical outlet.•
Figure 8A
Figure 7A
4 Screws
Parts Supplied
Figure 7B

E4 PRINtEd IN uSA
TINSEB521MRR0
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
1-800-BE-SHARP (237-4277)
moDel & serial nUmBer location
The name plate, including model and serial number, is located
on the right side of the Warming Drawer.
care, cleaning anD maintenance
Refer to the Operation Manual for cleaning instructions.
Before yoU call for service
Read the BEFORE YOU CALL and operating instruction sections
in your Operation Manual. It may save you time and expense.
The list includes common occurrences that are not the result of
defective workmanship or materials in this range.
Refer to the warranty in your Operation Manual for Sharp’s
toll-free service number and address. Please call or write if you
have inquiries about your Warming Drawer product and/or need
to order parts.
