Wa r m i n g Dr a W e r
KB-6100N
OPERATION MANUAL
MODELS
KB-6100N
FOLLOWED BY INDICATING COLOR: K = BLACK, W = WHITE, S = STAINLESS STEEL
ElEctrical rEquirEmEnts ................................3
customEr assistancE......................................3
consumEr limitED warranty............................4
ProDuct inFormation carD ..............................4
imPortant saFEty instructions........................5
inFormation you nEED to know .........................6
Part namEs ...................................................7
warming DrawEr usE ................................... 8-9
clEaning anD carE ........................................ 10
BEForE you call For sErvicE .......................... 11
KB-6100NS

CUSTOMER ASSISTANCE
To assist in reporting this appliance, please record below the model number and serial number located on the unit. We also
suggest you record all the information listed and retain for future reference.
MODEL NUMBER SERIAL NUMBER
DATE OF PURCHASE / /
DEALER TELEPHONE
SERvICER TELEPHONE
TO PHONE:
DIAL 1-800-BE-SHARP (237-4277) for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
TO WRITE:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
Please provide the following information when you write or call: model number, serial number, date of purchase, your complete
mailing address (including zip code), your daytime telephone number (including area code), your email address and description
of the problem.
TO ACCESS INTERNET: www.sharpusa.com
3
ELECTRICAL REqUIREMENTS
A 120V, single phase, 60 Hz, AC only 15 or 20 amp electrical supply,
properly grounded in accordance with the National Electric code and
local codes and ordinances is required.
imPortant The appliance is equipped with a three-prong
grounding plug for protection against possible electric shock hazards.
It must be plugged into a dedicated, grounded, electrical outlet. If only
a two-prong electrical outlet is available, it is the responsibility of
the customer to have it replaced with a dedicated, properly grounded
three-prong electrical outlet. Do not under any circumstances:
Cut or remove the third (ground) prong from the powercord.•
Use a power cord that is frayed or damaged.•
Connect the appliance to an extension cord.•
Donotuseanadaptortotplugtooutlet.•
Note: Use of a ground fault interrupter (GFI) is not recommended.
* Serial Number is located on Name Plate
Name Plate
Location

CONSUMER LIMITED WARRANTY
4
TheProductInformationCardshouldbecompletedwithintendaysofpurchaseandreturned.Wewillkeepitonleandhelp
you access the information if needed. This will also enable us to contact you in the unlikely event that any adjustments or
modicationsareeverrequiredforyourWarmingDrawer.
PRODUCT INFORMATION CARD
SHARPELECTRONICSCORPORATIONwarrantstotherstconsumerpurchaserthatthisSharpbrandproduct(the“Product”),
when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its
option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no
charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor
to any Product the exterior of which has been damaged or defaced, which has been subjected to misuse, abnormal service or
handling,orwhichhasbeenalteredormodiedindesignorconstruction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE
ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described
herein, or to extend the duration of any warranties beyond the time period described above on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive
remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall
constitutecompletefulllmentofallliabilitiesandresponsibilitiesofSharptothepurchaserwithrespecttotheProduct,and
shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall
Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted
repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any
incident or consequential economic or property damage. Some states do not allow the exclusion of incidental or consequential
damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
Your product model number &
description
KB-6100N Home Use Warming Drawer. (Be sure to have this information available
when you need service for your Product.)
Warranty period for this
product:
One (1) year parts and labor including in-home service.
Additional item(s) excluded
from warranty coverage (if any):
Non-functional accessories.
Where to obtain service: Froma SharpAuthorizedServicer located in the UnitedStates.Tondthelocation
of the nearest Sharp Authorized Servicer, call Sharp toll free at 1-800-BE-SHARP
(1-800-237-4277).
What to do to obtain service: In-home service is provided for one year from date of purchase. In-home service can be
arranged by calling 1-800-BE-SHARP. Be sure to have Proof of Purchase available.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP or visit www.sharpusa.
com. SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR WARMING DRAWER EVER REQUIRE
WARRANTY SERVICE.

5
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
Read all instructions before using the appliance.1
This appliance must be properly grounded. See separate2
Installation Instructions for grounding instructions.
Install or locate this appliance only in accordance with3
the provided Installation Manual.
Use this appliance only for its intended use as described4
in this manual. Do not use corrosive chemicals or
vapors, or ammable liquids in this appliance. This
applianceisspecicallydesignedtoheatordryfoodin
the home. It is not designed for industrial, commercial
or laboratory use.
Do Not Leave Children Alone – Children should not5
be left alone or unattended in area where appliance is
in use. They should never be allowed to sit or stand on
any part of the appliance.
Do not operate this appliance if it has a damaged cord6
or plug, if it is not working properly or if it has been
damaged or dropped.
This appliance should be serviced only by qualied7
service personnel. Contact nearest Sharp Authorized
Servicer for examination, repair or adjustment.
Do not cover or block any openings on the appliance.8
Do not store or use this appliance outdoors. Do not use9
this product near water—for example, near a kitchen
sink, in a wet basement, near a swimming pool or
similar locations.
Do not immerse cord or plug in water.10
Keep cord away from heated surfaces.11
Do not climb or sit on the appliance.12
Besurethatngersorotherobjectsormaterialsare13
not around the appliance opening when the appliance
is closed.
Donotputngersorclothesaroundthedrawerguides14
when the appliance is opened or closed. They could be
caught in the guides when the appliance is closed.
Be sure that the food and container are shorter than the15
drawer before closing it. You can refer to the height of
the side walls of the drawer.
When cleaning appliance sealing surfaces that16
come together on closing the drawer, use only mild,
nonabrasive soaps or detergents applied with a sponge
or soft cloth. See cleaning instructions on page 10.
Toreducetheriskofreintheappliancecavity,do17
not use the appliance for storage purposes. Do not
leave paper products, cooking utensils, or food in the
appliance when not in use.
Wear Proper Apparel – Loose-fitting or hanging18
garments should never be worn while using the
appliance.
Do Not Heat Unopened Food Containers – Build-up19
of pressure may cause container to burst and result in
injur y.
SAVE THESE INSTRUCTIONS
When using the appliance, basic safety precautions should be followed, including the following:
WARNING
To reduce the risk of burns, electric shock, re or injury to persons:

6
WARNING
ANTI-TIP BLOCK REQUIRED
To reduce the risk of tipping of the drawer, the Anti-Tip
block must be properly installed. Refer to the Installation
Instructions for placement.
BURN HAZARD
DO NOT• touch any of the surfaces inside or outside the
Warming Drawer during or immediately after use. After
use,makesurethesesurfaceshavehadsufcienttimeto
cool before touching them.
Exercise caution when opening the drawer. Let hot air or•
steam escape before looking or reaching into the Warming
Drawer.
Use only dry pot holders when removing food and•
cookware from the Warming Drawer. Wet pot holders can
cause steam burns.
ALUMINUM FOIL USAGE
DO NOT• use aluminum foil to line any part of the
WarmingDrawer.Usingafoillinercouldresultinare
hazardortheobstructionoftheowofheatandventilation
air. Foil is an excellent heat insulator and heat will be
trapped underneath it. This trapped heat can upset the
performance of the Warming Drawer parts.
To avoid excess condensation inside the drawer, foods may•
be covered with aluminum foil. This will also help keep
the food from drying out.
MAXIMUM CAPACITY
DO NOT• place more than 50 pounds in the drawer.
OTHER
Never use your appliance for warming or heating the•
room.
The use of accessory attachments not recommended by•
Sharp may cause injuries.
Never leave the drawer open and unattended.•
ABOUT UNPACKING AND EXAMINING
YOUR WARMING DRAWER
Remove all packing materials from inside the Warming1
Drawer.
Remove the feature sticker, if there is one. Check the2
drawer for any damage, such as misaligned or bent drawer,
damaged drawer seals and sealing surfaces, broken or loose
drawer guides and dents inside the cavity or on the front
side of the drawer. If there is any damage, do not operate
the Warming Drawer and contact your dealer or a SHARP
AUTHORIZED SERVICER.
ABOUT CHILDREN AND THE WARMING
DRAWER
Children below the age of 7 should use the Warming Drawer
only with a supervising person very near to them. For children
between the ages of 7 and 12, the supervising person should
be in the same room. The child must be able to reach the
Warming Drawer comfortably.
At no time should anyone be allowed to lean or swing on the
Warming Drawer.
Children should be taught all safety precautions: use dry
potholders, remove coverings carefully, pay special attention
to packages that crisp food because they may be extra hot.
Don't assume that because a child has mastered one cooking
skill he/she can cook everything.
Children need to understand that the Warming Drawer is
not a toy.
FOOD SAFETY
The purpose of the Warming Drawer is to hold hot cooked
foods at serving temperature. Always start with hot food; cold
food cannot be heated or cooked in the Warming Drawer.
When warming foods in oven safe glass and/or glass ceramic
container, a higher temperature setting may be needed
compared to heating in metal containers
Opening the drawer during use and/or adding more items
will allow the hot air to escape and may require more time
for the temperature in the drawer to stabilize.
Be sure to maintain safe food temperature. The USDA recom-
mends holding hot food at 140˚Forwarmer.
To keep several foods hot together, set the temperature
according to the food needing the highest setting. Place items
needing highest temperature on the bottom of the drawer and
food needing less heat on the tray.
ABOUT UTENSILS AND COVERINGS
FOR SAFE WARMING AND REHEATING
Always use oven-safe dishes and cookware in this•
appliance.
Cover food with an oven-safe lid or aluminum foil.•
Check with manufacturer of dishes and cookware for their•
maximum heat tolerance.
DO NOT USE
Plastic wrap or bags.•
Plastic containers or lids.•
Melted plastic may NOT be removable.
Paper plates, paper towels or any other combustable•
material.
ACCESSORIES
A serving pan kit is available through Authorized Sharp
Dealers.
INFORMATION YOU NEED TO KNOW

7
PART NAMES
WARMING DRAWER
Power Light
Rubber Gasket Rack
Name Plate
Drawer Guides
Electronic Touch
Controls
8
8
8
8
Numbers next to the electronic touch controls illustration indicate
pages on which there are feature descriptions and usage information.
KB-6100N
On/Off
Temp.
Time
POWER
90° Proof
125° Low
150°
175° Med.
200°
230° High
1/2 Hour
1 Hour
2 Hours
3 Hours
4 Hours
Continuous On
Air Vents
Air Vents/Variable
Humidity Control
Variable Humidity Control
for moisture adjustment.
Slides to open and close.

8
CONTINUOUS ON MODE
When the Warming Drawer is in Continuous On mode, it will
remainonuntilturnedoffmanually.Toavoidarehazardor
burns, exercise caution when operating the unit in Continuous
On mode. Touch POWER to turn the unit off.
AUTO SHUT-OFF
Do not block the humidity vents on the back of the drawer
front and along the left and right sides of the drawer. Excessive
heat buildup can occur.
RACK
A wire rack is included
to use for double stacking
items.
Therackwilltfromfront
to back or from side to
side.
Preheat with the rack in place.•
The use of accessory attachments not recommended by•
Sharp may cause injuries.
Always place racks in desired position while drawer is cool.•
If racks must be removed while Warming Drawer is hot, do
not let the potholder contact the heating elements.
DO NOT USE• aluminum foil to line any part of the
WarmingDrawer.Usingafoillinercouldresultinare
hazard,ortheobstructionoftheowofheatandventilation
air. Foil is an excellent heat insulator and heat will be
trapped underneath it. This trapped heat can upset the
performance of the Warming Drawer parts.
DO NOT• place more than 50 pounds in the drawer.
CAUTION
Plastic containers or plastic wrap can melt if
in direct contact with the drawer or a hot utensil. Items may
melt and cause damage to the Warming Drawer or injury.
WARMING DRAWER USE
ELECTRONIC TOUCH CONTROLS
Press• POWER to turn the Warming
Drawer on and off. Signal light will indicate
when unit is on.
TO SELECT DESIRED
TEMPERATURE
Select temperature by pressing• TEMP
until indicator light is on next to desired
temperature.
TO SELECT DESIRED TIME
SelectfromvepresettimesorContinuous•
On by pressing TIME until light is on next
to desired time.
Use caution when selecting Continuous On.•
Unit will need to be turned off using the
POWER key.
PREHEATING
Allow time for the drawer to preheat.
For best results, preheat your Warming Drawer according to
the chart below before use. If you put hot food into a cool,
connedarea,anysteamthatispresentwillcondense.Ifyou
preheat your Warming Drawer, there will be less chance of
water due to condensation. Preheat times vary depending on
the temperature setting.
TEMPERATURE SETTINGS APPROXIMATE TIME
90˚ Proof Preheat Not Required
125˚ Low 8 minutes
150˚ 12 minutes
175˚ Medium 16 minutes
200˚ 19 minutes
230˚ High 24 minutes
On/Off
Temp.
Time
POWER
90° Proof
125° Low
150°
175° Med.
200°
230° High
1/2 Hour
1 Hour
2 Hours
3 Hours
4 Hours
Continuous On

9
WARMING DRAWER USE
VARIABLE HUMIDITY CONTROL
The slide control is located on the inside front of the
drawer.
TO KEEP FOODS MOIST
Slide the Variable Humidity Control to the "Moist" setting.
This closes the vent and seals the moisture inside the drawer.
With the vent closed, hot foods stay moist and soft. In this
setting, condensation may occur around the inside edge of
the drawer.
TO KEEP FOODS CRISP
Slide the variable Humidity Control to the "Crisp" setting.
This opens the vents and allows the moisture to escape.
CAUTION
With the vents open, it is normal for moisture
to collect on surfaces above the Warming Drawer.
TO CRISP STALE ITEMS
Place food in low sided dishes or pans.•
Preheat on• LOW setting and open the vent.
Check crispness after 45 minutes. Add time as needed.•
TO WARM SERVING BOWL AND PLATES
Warm serving bowls and plates at the LOW setting.
Use heat-safe dishes only. Place the empty dishes on the•
rack. Check with the manufacturer if you want to heat to
ahighertemperatureorwhenheatingnechinaorother
delicate items.
You may preheat empty serving dishes while preheating•
the drawer. It is not necessary to preheat the Warming
Drawer when warming dishes or plates.
Place empty serving dishes on the high rack and food on•
the bottom of the drawer when holding hot cooked foods
together while warming empty serving dishes.
Do not drag dishes or plates across the drawer to avoid•
scratching the surface.
CAUTION
Dishes may be hot. Use pot holders or mitts
when removing hot dishes.
TO PROOF YEAST BREAD DOUGH
Yeast dough can be proofed in the Warming Drawer.
Place the dish on the bottom of the Warming Drawer.•
Press• TEMP until the indicator light is on next to 90º
Proof.
Press• TIME until the indicator light is on next to 1 hour.
Close the Variable Humidity Control.•
Lightly oil the top of the dough. The bowl should be large•
enough to allow the dough to double in size. Cover the
bowl with a cloth.
Preheating is not required.•
Check after 40 minutes. The dough should double in•
size. Adjust the time as needed for the dough to double
in size anda gentletouch ofa ngerresults in a slight
depression.
TEMPERATURE AND HUMIDITY
CONTROL SETTING GUIDELINES
Different foods require different temperature and humidity
settings. Use the chart on the following page as a guide.
You can set the Warming Drawer temperature to any of the
6 settings. Cover the food if desired to maintain heat and
moisture.
When keeping several types of food hot, choose the setting
based on the highest recommended temperature. Place those
foods needing the highest temperature on the bottom of the
drawer, those requiring lower temperature on the rack.
It is not recommended to hold foods in the Warming Drawer
for longer than 1 hour. Smaller quantities and/or heat sensitive
foods such as eggs should not be held for more than 30
minutes.
Food must be cooked and be at serving temperature before
being placed in the Warming Drawer.
OPEN
MOISTCRISP
CLOSED
Air Vents Slide control for
moisture adjustment
(Facing the drawer.)

10
TEMPERATURE & HUMIDITY CONTROL
SETTING CHART
FOOD TYPE CONTROL
SETTING
HUMIDITY
CONTROL
SETTING
CRISP
Bacon HIGH OPEN
Bread, hard rolls MED OPEN
Fried foods HIGH OPEN
Pies, two crusts MED OPEN
Pizza HIGH OPEN
Potatoes, baked HIGH OPEN
Tortilla Chips LOW OPEN
MOIST
Beef, medium and
well done* MED CLOSED
Bread, soft rolls MED CLOSED
Casseroles MED CLOSED
Cooked cereal MED CLOSED
Eggs MED CLOSED
Fish, seafood MED CLOSED
Fruit MED CLOSED
Gravy, cream sauces MED CLOSED
Ham MED CLOSED
Lamb MED CLOSED
Pancakes,wafes HIGH CLOSED
Pies, one crust MED CLOSED
Pork MED CLOSED
Potatoes, mashed MED CLOSED
Poultry HIGH CLOSED
Vegetables MED CLOSED
* USDA/FSIS recommends an internal temperature of 145°F.
as the minimum doneness for beef. Use a portable meat
thermometer to check internal temperatures.
CLEANING AND CARE
EXTERIOR
Unless your model has stainless steel exterior, the outside
surface is precoated metal and plastic. Clean the outside with
mild soap and water; rinse and dry with a soft cloth. Do not
use any type of household or abrasive cleaner.
Be sure power is off and all surfaces are cool before cleaning
any part of the Warming Drawer.
STAINLESS STEEL SURFACE (KB-6100NS)
The exterior should be wiped often with a soft damp cloth and
polished with a soft dry cloth to maintain its beauty. There is
also a variety of products designed especially for cleaning and
shining the stainless exterior of the drawer. We recommend
that the cleaner be applied to a soft cloth and then carefully
used on the stainless exterior rather than sprayed directly on
it. Follow package directions carefully.
TOUCH CONTROL PANEL
Wipe the panel with a cloth dampened slightly with water
only. Dry with a soft cloth. Do not scrub or use any sort of
chemical cleaners. Be sure power is off before and after
cleaning.
INTERIOR
To clean the interior surfaces, including drawer sealing
sur faces, wipe with a soft damp cloth. DO NOT USE ABRA-
SIVE OR HARSH CLEANERS OR SCOURING PADS.
For heavier soil, use mild soap; wipe clean with a soft damp
cloth. Do not use any chemical oven cleaners.
WARMING DRAWER
GUIDES
Remove the food crumbs
from the Warming Draw-
er guides. Wipe with a
soft dry cloth in order to
keep the Warming Draw-
er opening and closing
smoothly.
HOW TO CLEAN THE RACK
Clean the rack with detergent and water. After cleaning, rinse
the rack with clean water and dry with a clean cloth.
REMOVING THE DRAWER FROM THE
APPLIANCE
Allow the drawer to cool before attempting to remove it.•
Pull the drawer out to the fully open position.•
Push in on the locking tab on one side as you pull the•
drawer up.
When the drawer comes loose from the slide, repeat the•
same process on the opposite side.
Grip the drawer on both sides and pull it free.•
For safety, push both drawer slides into the drawer•
opening.
Warming Drawer Guides

11
Please check the following before calling for service. It may save you time and expense.
PROBLEM POSSIBLE CAUSE SOLUTION
Part or all of Warming1
Drawer does not operate.
Power cord of Warming Drawer is not•
completely connected to the electrical
outlet.
Power outage.•
Fuse blown/circuit breaker tripped.•
Make sure the power cord is tightly connected•
to the outlet.
Check house lights to be sure. Call your local•
electric company for service.
Replace the fuse or reset the circuit breaker.•
Food in Warming Drawer is2
not heated.
No power to the appliance.•
Drawer controls improperly set.•
See SOLUTION for PROBLEM 1.•
Check if the controls have been properly•
set.
Warming Drawer light does3
not work.
Light bulb is loose or burned out.• Call for service.•
Touch controls will not4
operate.
Power cord of Warming Drawer is not•
completely connected to the electrical
outlet.
Power outage.•
Fuse blown/circuit breaker tripped.•
Make sure the power cord is tightly connected•
to the outlet.
Check house lights to be sure. Call your local•
electric company for service.
Replace the fuse or reset the circuit breaker.•
Power light off.5 Power failure.• If the Warming Drawer was in use, you must•
reset the heating function.
Drawer does not slide6
smoothly or drags.
Ball bearings are out of alignment.•
Drawer over-loaded or load unbalanced.•
Drawer not replaced properly after removal.•
Fully extend the drawer and push it all the way•
in. See the Care and Cleaning section.
Reduce weight to less than 50 pounds.•
Redistribute drawer contents.
Remove drawer and replace again.•
Excessive condensation.7 Liquid in Warming Drawer.•
Uncovered foods.•
Temperature setting too high.•
Incorrect Humidity setting.•
Remove liquid.•
Cover food with lid or aluminum foil.• DO
NOT use aluminum foil to line any part of
the Warming Drawer.
Reduce temperature setting.•
Set the Variable Humidity Control to the open•
vent setting to allow venting.
No heat in the proof setting.8 Room temperature may prevent the thermostat•
from tripping on.
Press TEMP to select LOW and then select•
PROOF.
Food dries out.9 Moisture escaping.• Cover food with lid or aluminum foil.• DO
NOT use aluminum foil to line any part of
the Warming Drawer.
Set the Variable Humidity Control to the•
closed vent settings to prevent venting.
BEFORE YOU CALL FOR SERVICE

PrintED in usa
TINSEB520MRK0
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
1-800-BE-SHARP (237-4277)
