SHC SHR-100 User manual

SHR-1000
USER MANUAL
COPYRIGHT © SHC 2014 ALL RIGHTS RESERVED

SHR-1000 User Manual 2014 Copyright ©
2
- Table of Contents -
Copyright ------------------------------------------------------------------------------------------------------------------- 4
Proper Handling of the device-------------------------------------------------------------------------------------------5
Battery Safety Guidelines ----------------------------------------------------------------------------------------------- 8
I. Before Using the device ------------------------------------------------------------------------------------------- 9
1. Product Configuration --------------------------------------------------------------------------------------------------- 10
2. Specifications (Device/Cradle) ---------------------------------------------------------------------------------------- 11
3. Charging the Battery ----------------------------------------------------------------------------------------------------- 13
4. Mounting the Gun Handle ---------------------------------------------------------------------------------------------- 14
5. Mounting the Handstrap ------------------------------------------------------------------------------------------------ 15
6. Inserting the Micro SD Card ------------------------------------------------------------------------------------------- 16
7. Inserting the SAM & SIM Cards -------------------------------------------------------------------------------------- 17
8. Keypad Numeric --------------------------------------------------------------------------------------------------------- 18
9. Keypad Qwerty ------------------------------------------------------------------------------------------------------------ 20
10. Initialization ---------------------------------------------------------------------------------------------------------------- 23
II. Getting Started ----------------------------------------------------------------------------------------------------- 24
1. Power On ------------------------------------------------------------------------------------------------------------------ 25
2. How to use the Stylus Pen -------------------------------------------------------------------------------------------- 27
3. Screen Description ------------------------------------------------------------------------------------------------------ 28
4. Configuring the device -------------------------------------------------------------------------------------------------- 31
5. Locking and unlocking the device ----------------------------------------------------------------------------------- 36
6. Manage battery life ------------------------------------------------------------------------------------------------------ 37
III. Use File Explorer -------------------------------------------------------------------------------------------------- 39
1. Run and use the File Explorer ---------------------------------------------------------------------------------------- 40
IV. Terminal settings, how to optimize ---------------------------------------------------------------------------- 41
1. Background image ---------------------------------------------------------------------------------------------------- 42
2. Brightness --------------------------------------------------------------------------------------------------------------- 44
3. Volume and Sounds -------------------------------------------------------------------------------------------------- 46
4. Screen -------------------------------------------------------------------------------------------------------------------- 48
5. Bluetooth ---------------------------------------------------------------------------------------------------------------- 49
6. Pictures and Videos -------------------------------------------------------------------------------------------------- 57
7. How to set the Cradle and the Scan Button using Device Setting Program ---------------------------- 61
8. System Information --------------------------------------------------------------------------------------------------- 63

SHR-1000 User Manual 2014 Copyright ©
3
- Table of Contents -
V. Using Add-on Devices -------------------------------------------------------------------------------------- 64
1. BCR ------------------------------------------------------------------------------------------------------------------------ 65
2. WLAN ----------------------------------------------------------------------------------------------------------------------- 67
3. GPS -------------------------------------------------------------------------------------------------------------------------- 75
VI. Using the Phone Application ------------------------------------------------------------------------------------ 76
1. Running the Phone Application --------------------------------------------------------------------------------------- 77
2. Phone Application Screen ---------------------------------------------------------------------------------------------- 78
3. Making/Accepting Calls ------------------------------------------------------------------------------------------------- 79
4. Telephone Number ------------------------------------------------------------------------------------------------------ 80
5. Entering Phone Numbers in the Directory ------------------------------------------------------------------------- 82
6. Phone Directory –Viewing/Deleting Entries ----------------------------------------------------------------------- 84
7. Recent Call List Management ----------------------------------------------------------------------------------------- 85
8. Message Management -------------------------------------------------------------------------------------------------- 86
9. Compose Message ------------------------------------------------------------------------------------------------------ 87
10. Preferences ---------------------------------------------------------------------------------------------------------------- 88
VII. PC connection ------------------------------------------------------------------------------------------------------ 89
1. Microsoft ActiveSync installation ------------------------------------------------------------------------------------- 90
2. Connect to a PC to install the program ----------------------------------------------------------------------------- 92
VIII.Appendix ------------------------------------------------------------------------------------------------------------- 93
1. Troubleshooting ---------------------------------------------------------------------------------------------------------- 94
2. Initialize to factory default --------------------------------------------------------------------------------------------- 101
3. Terminal maintenance ------------------------------------------------------------------------------------------------- 102
4. Product specifications ------------------------------------------------------------------------------------------------- 103
5. Others ---------------------------------------------------------------------------------------------------------------------- 105

SHR-1000 User Manual 2014 Copyright ©
4
This user’s manual and related products are under the protection of the copyright
law, all rights reserved. This document and any part hereof may not be copied,
adopted or translated into other languages without prior written consent of Shin
Heung Precision Co. Ltd.
Copyright
•Use the Windows System OS documentation for information regarding the same. For
information about the PC used, please refer to the PC instruction manual.
•All names and products used in this manual are names, service marks, and/or registered
trademarks of their respective owners.
•Picture, screens, features used herein may vary slightly with the actual product depending
on the product version.
•Shin Heung Precision reserves the right to change/modify this user’s manual without prior
notice depending on the circumstances that affects the product and/or its version.
•Users must read the PRECAUTIONS before using the product.
Shin Heung Precision Co. Ltd., in reference to the instructions and/or information
in this user’s manual in relation to the products referred to herein, does not
provide nor implies the granting of an unlimited guarantee of any kind.
Shin Heung Precision Co., Ltd.
Flat C-911, Woolim Lion’s Valley, Gasan Digital 1-ro, 168, Gasan-Dong,
Geumcheon-Gu, Seoul 153-786, Korea
TEL: [phone] FAX: [phone]
Customer Service Center : [phone]

SHR-1000 User Manual 2014 Copyright ©
5
To insure the smooth and safe usage of this product, read carefully the
instructions detailed in this manual.
Proper Handling of the Device
Using accessories other than those recommended and/or included in this
product can cause accidents and product failures. Shin Heung Precision Co. Ltd.
will not be responsible for such accidents and/or failures.
Bringing this product to unauthorized repair or service centers/shops will void the
warranty. Please contact the manufacturer for any repair and maintenance
needs.
Counterfeit mobile phone
This product is identified through its unique phone number (ESN: Electronic
Serial Number). Illegally reproducing or changing this unique number is a
criminal act under Article 347, and is punishable with less than 10 years of
imprisonment or a fine of less than KRW 20 million. In addition, this illegal act
voids the warranty of this product.
Wireless/Radio Equipment Inspection and Registration
•This product is inspected by and registered with the Ministry of Information &
Communication.
•This product can not be modified that could cause changes in its performance
that infringes on the conditions of the registration.

SHR-1000 User Manual 2014 Copyright ©
6
•Avoid eye contact with the Barcode scanner. It can cause eye damage.
•Do not remove the battery while device is ON.
•Use only the specified battery charger. Using other chargers can cause
damage to the battery and/or be a fire hazard.
•Do not make modifications to this product. This could cause fire, damage,
electric shock, or serious injuries to users.
•Do not use this product near gas and other flammable liquid. This could
cause explosion.
•Avoid using this product during lightning and thunder storms.
•Keep this product out of reach of children and animals.
•In places where wireless/radio communication is restricted (air flights,
near medical equipments, or similar places), follow the instructions
provided for by the authorities of such places.
•Do not leave this product in areas with high temperature and/or extreme
temperature changes. Do not expose this product to direct sunlight.
(Exposing this product to high temperature for long periods could cause
explosion.)
•Avoid using this product in areas with high moisture level. Do not
submerge this product under water.
•When subjecting this product to search equipment (x-ray machines) in
airports, it is advisable to be aware of what is happening.
Proper Handling of the Device

SHR-1000 User Manual 2014 Copyright ©
7
FCC Part 15.19 Statements:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC Part 15.105 statement
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
FCC Part 15.21 statement
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Body-worn Operation
This device was tested for typical body-worn operations with the back of the device kept
15 mm between the user’s body and the back of the device.
To comply with FCC RF exposure requirements, a minimum separation distance of 15 mm
must be maintained between the user’s body and the back of the device.
Third-party belt-clips, holsters, and similar accessories containing metallic components
may not be used. Body–worn accessories that cannot maintain 15 mm separation
distance between the user’s body and the back of the device, and have not been tested
for typical body-worn operations may not comply with FCC RF exposure limits and should
be avoided.
Proper Handling of the Device
•CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

SHR-1000 User Manual 2014 Copyright ©
8
•The area in which the units are charged should be clear of debris and
combustible materials or chemicals.
•Particular care should be taken when the device is charged in a non
commercial environment.
•Follow battery usage, storage, and charging guidelines found in the
user's guide.
•Improper battery use may present a risk of fire, explosion or other
hazard.
•When charging the mobile device battery, the environmental
temperatures of the location of the battery and charger must be
between +32°F and +104°F (0°C and +40°C)
•Do not use incompatible batteries and chargers. Use of an
incompatible battery or charger may present a risk of fire, explosion,
leakage or other hazard. If you have any questions about the
compatibility of a battery or a charger, contact Shin Heung Precision
support.
•Do not disassemble, open, crush, bend, deform, puncture or shred.
•Do not dispose of batteries in fire.
•Severe impact from dropping any battery-operated device on a hard
surface could cause the battery to overheat.
•Do not short circuit a battery or allow metallic or conductive objects
to contact the battery terminals.
•Do not modify, remanufacture , attempt to insert foreign objects into
the battery, immerse/expose to water or other liquids or expose to
fire, explosion, or other hazards.
•Do not leave or store the equipment in or near areas that might get
very hot, such as in a parked vehicle or near a radiator or other heat
source. Do not place battery into a microwave oven or dryer.
•Battery usage by children should be supervised.
•Please follow local regulations in the proper disposal of used re-
chargeable batteries.
•Seek medical advice immediately if a battery has been swallowed.
•In the event of a battery leak, do not allow the liquid to come in
contact with the skin or eyes. If contact has been made, wash the
affected area with large amounts of water and seek medical advice.
•If you suspect damage to your equipment or battery, contact Shin
Heung Precision support to arrange for inspection.
Battery Safety Guidelines

SHR-1000 User Manual 2014 Copyright ©
9
Before using the device...
Ⅰ
1. Product Configuration
2. Specifications (Device/Cradle)
3. Charging the Battery
4. Mounting the Gun Handle
5. Mounting the Handstrap
6.Inserting the Micro SD Card
7. Inserting the SAM & SIM Cards
8. Keypad –Numeric
9. Keypad - Qwerty
10. Initialization

SHR-1000 User Manual 2014 Copyright ©
10
2) Additional Product Configuration
1) Basic product configuration
Product Configuration
Ⅰ-1
SHR-1000
Cradle
Adapter & Power cord
GUN
USB Cable
Handstrap

SHR-1000 User Manual 2014 Copyright ©
11
Specifications
Ⅰ-2
1) Mobile Device Description
1D/2D Scanner
Phone Receiver Power LED
Display
Scan
Button
Camera
Scan Button Bracket of
Hand Strap
Speaker
Battery
Battery Locker
I/O Connector
USB port DC Jack
Reset Button
Micro-phone
Qwerty Keypad Numeric Keypad
Stylus
Pen

SHR-1000 User Manual 2014 Copyright ©
12
Specifications
Ⅰ-2
2) Cradle Device Description
Note: Cradle is sold with either USB-A
Type or Ethernet connector. It could
not have both connectors at the same
time.
DC Jack
Connector USB Cable
Connector
(USB-A Type)
OPTIONAL
USB Cable
Connector
(USB-B Type)
RS-232
Connector
ETHERNET
Connector
OPTIONAL
LED of Power Adapter
LED of Battery charger

SHR-1000 User Manual 2014 Copyright ©
13
Charging the Battery
Ⅰ-3
1) Charging the battery from the device
Place the battery at the back of the device. Place the device on the
cradle and connect the power adapter with cord to the cradle to charge
the battery.
2) Separately charging the battery
To charge the battery separately from the device, place the battery on
the back side of the cradle.

SHR-1000 User Manual 2014 Copyright ©
14
Mounting the Gun Handle
Ⅰ-4
1) Insert the Gun Handle’s notch to the appropriate hole in the PDA in the
direction of the arrow as shown below.
2) After the Gun Handle is mounted on the PDA, turn the Gun Handle
screws in the direction of the arrow as shown below.

SHR-1000 User Manual 2014 Copyright ©
15
Mounting the Handstrap
Ⅰ-5
1) Use a + screwdriver to remove the Handstrap Bracket on PDA.
2) Put the bracket with Handstrap on the PDA and tighten the screws by a
+ screwdriver. Mount the Handstrap by attaching the Velcro as shown
in the picture below.

SHR-1000 User Manual 2014 Copyright ©
16
Inserting the Micro SD Card
Ⅰ-6
1) Remove the battery. Pull the connector cover of the Micro SD Card in
the direction of the arrow.
2) Open the connector cover, insert the Micro SD Card, and close the
connector cover by pushing in the direction of the arrow.

SHR-1000 User Manual 2014 Copyright ©
17
Inserting the SAM & SIM Cards
Ⅰ-7
1) SAM
Insert the SAM Eject the SAM
2) SIM
Insert the SIM Eject the SIM

SHR-1000 User Manual 2014 Copyright ©
18
Key Description
Power
Turns on the device.
Send
Press Send key to start the phone program.
End
Press End key to end the phone program.
Scan
Activates the scanner or imager.
Soft
Access the command or menu above it on the screen.
Arrow (Left, Right) when pressed with Orange Key,
moves Left/Right one item.
Arrow (Up, Down)
Moves Up/Down one item.
Backlight On/Off
Turns the display backlight on and off.
Windows key when pressed with the Green Key.
KEYPAD - NUMERIC
Ⅰ-8

SHR-1000 User Manual 2014 Copyright ©
19
Key Description
Shift
Change the state of alpha characters from lowercase
to uppercase.
•Press the Shift key once and then an alpha
character key, the uppercase is entered.
•Press the Shift key twice to lock this mode.
•Press the Shift key a third time to unlock.
Function (Orange)
Use this key to access the secondary layer (shown on
the keypad in orange).
Function (Green)
Use this key to access the secondary layer (shown on
the keypad in green).
Reset
Restart the system.
Alpha-Numeric
The default is Numeric characters input mode.
KEYPAD - NUMERIC
Ⅰ-8

SHR-1000 User Manual 2014 Copyright ©
20
Key Description
Power
Turns on the device.
Send
Press Send key to start the phone program.
End
Press End key to end the phone program.
Soft (Left, Right)
Access the command or menu above it one the screen.
Arrow
Move Left/Right/Up/Down one item.
Scan
Activates the scanner or imager.
Function (Orange)
Use this key to access the secondary layer (shown on
the keypad in orange).
KEYPAD - QWERTY
Ⅰ-9
