Shell SH924 User manual

User Guide
SH924
Jump Starter
Portable Power
ITM. / ART. 1593176

1. Light Switch 2. LED Light 3. ON/OFF Switch
4. DC Input Port 5. USB Output Port 6. LED Battery Level Indicator
7. Jumper Cable Indicator 8. Magnetic Base
Negative Battery Clamp (Black)Positive Battery Clamp (Red)
Smart Jumper Cable
For Your Safety
Thank you for choosing this Shell product. Please read the following
instructions and keep them for future reference. This instruction manual
contains important information on safe operation and use. To ensure
long life and performance reliability, please operate and maintain as
per the instructions on this sheet.
3
6
8
74
5
Jump Starter
1
2
Product Details

• 1 x Jump Starter • 1 x AC/DC Adaptor
•1 x USB A to Micro USB Cable • 1 x User Guide
Package Includes
Product Features
• Designed for vehicles with 11.0 L gasoline and 8.0 L diesel engines
• 8 levels of safety protection
• Powerful magnetic base allows hands free use
• Integrated LED light with 3 light settings: White Floodlight,
SOS, Red Alert Strobe
• 1 x Product Warranty Registration
1

IMPORTANT! CHARGE IMMEDIATELY AFTER PURCHASE, AFTER EACH
USE AND EVERY THREE MONTHS, OR WHEN THE BATTERY LEVEL
FALLS BELOW 50%, TO PROLONG THE INTERNAL BATTERY LIFE.
1. Connect the DC Terminal of the
included adaptor to the input port of the
jump starter.
2. Connect the input terminal of the
adaptor to an external AC outlet.
3. The LED battery level indicators start
flashing. (Please refer to the following
table for charging status)
4. When charging is completed,
the LED indicator will stop flashing.
5. Disconnect the adaptor from the outlet
and remove the charging cable from
the jump starter.
Charging the Jump Starter
Battery Level Indicator Chart
Operating Instructions
The jump starter is intended to jump start vehicle with gasoline/diesel
engine using a 12V battery.
Jump Starting Vehicle
Before connecting to the battery
1
LED Status
(● ON O OFF)
100%
fully charged
75% - 100%50% - 75%25% - 50%0% - 25%
Power Status
1. Verify the voltage of the battery. The information
can be found in the vehicle's owner's manual.
2. Make sure the power loads such as headlamps,
air-conditioning and radio are turned off.
3. Press the switch to check the internal battery
level to ensure that there is sufficient battery
capacity to jump start a vehicle. (Refer to the
following table for more information)

2. A) Once clamps are properly connected, the green LED jumper cable
indicator will turn solid from flashing. You may now try to start your vehicle.
B) Otherwise please refer to the following jump start troubleshooting
table for corresponding solutions.
1. Connect the red battery clamp to the positive (+) terminal and the black
battery clamp to the negative (-) terminal on your vehicle’s battery.
Note: Required capacity to jump start a vehicle
1
3. After the engine starts, disconnect the battery clamps from the battery
terminals.
LED Battery
Level Indicator Battery Capacity Indications
Best condition to jump start
a vehicle
The minimum capacity
required to jump start a vehicle
Recharge the jump starter
before use
75% - 100%
50% - 75%
25% - 50%
0% - 25%
Connecting to the vehicle battery

Troubleshooting Table
Jumper Cable Indicator
Cause Solutions
Solid Off
Off Flashing
Flashing Flashing
Off
Green Red
LED Light
(front)
Jump start the vehicle
Low battery
protection
Reverse polarity
protection/
short-circuit
protection
Clamps are not
connected to the
battery
Reverse charge
protection
Please charge the
jump starter
On
On
Flashing Off Off
Off
Off
Flashing (4 times
per second, cycle
after 1 second
interval)
OnOn
On
Over-temperature
protection
Jump started 4
consecutive times
within 10 minutes
Disconnect the clamps from
the vehicle’s battery. Let the
jump starter cool down by
putting it in a cool and
ventilated place.
Disconnect the clamps from
the vehicle’s battery. Follow
jump starting vehicle
instructions to jump start the
vehicle.
The car battery voltage is
higher than the voltage of the
starting power supply.
Please check the voltage of
the vehicle's battery; it may
be greater than 12V.
Do not jump start more than
4 times.
Disconnect the clamps from
the vehicle’s battery. Unplug
the jumper cable from the
jump starter.
Consult a mechanic.
Disconnect and reconnect
the clamps to the battery
1

1. Connect your portable device with one end of the included USB
cable, and insert the other end to the output port of the jump starter.
2. Press the power switch to turn on the jump starter and start charging.
Charging will begin as soon as the jump starter turns on.
3. Once the charging is completed, disconnect your portable device
and unplug the USB cable from the jump starter.
Compatible with: smart phones, tablets, digital cameras, mobile
gaming devices, wireless earphones and more
Charging Portable Devices
Note: Charging time will vary depending on the portable device and
the device's battery capacity.

1. To switch on the LED light, press and hold
on the ON/OFF switch for 2 seconds.
2. Press the ON/OFF switch to toggle through 3 lighting modes:
3. Press and hold ON/OFF switch for 2 seconds
under any lighting mode to turn off the LED
light .
Using the LED Light
White Floodlight SOS Red Alert Strobe

The symbol indicates direct current (DC)
Specifications
Jump Starter
Start Voltage: 12V
Start Current: 1000A
Peak Current: 2000A
Input: 18V 1A
USB Output: 5V 2.1A
Battery Type: Lithium-Polymer
Battery Capacity: 24000mAh, 88.8Wh
Operating Temperature: - 20ºC ~ 60ºC
Storage Temperature: - 20ºC ~ 40ºC
Charging Temperature: 0ºC ~ 45ºC
Dimensions: 4.72 x 5.24 x 10.24 inches/120 x 133 x 260 mm
Weight: 3.66 lb/1660 g (without adapter and USB cable)
Adapter
Input: 100 - 240V ~ 50/60Hz 0.6A Max
Output: 18V 1A

Safety Instructions
Failure to follow the instructions may cause serious injury, death or
property damage
Risk of electric shock, explosion and fire
Risk of explosive gases
• Do not attempt to jump start your vehicle more than four consecutive times. If
the vehicle does not start after four consecutive attempts, consult a mechanic.
• The product may become warm under extended high-power operation.
• Do not disassemble, modify or repair this product.
• Do not destroy product by crushing or cutting.
• Do not expose the product to fire, rain, snow, sunlight and heat.
• Keep this product away from water and other liquids.
• Keep this product in a dry place. Do not allow the product to get wet.
• Use the product in a well-ventilated area. Do not operate in explosive
atmospheres such as areas of flammable gas, dust and liquid.
• Do not use this product in the event of electrolytic liquid leaks, strange odours,
overheating, color change or when any other peculiar occurrence is detected.
• Handle the product with care. Do not use the product when it is damaged. Do
not operate with damaged jumper cable or clamps.
• Clean this product only with a dry cloth. Avoid using cleaning product with
rough or chemical substances.
• Do not look directly into the light as it may cause serious eye injuries.
• This car jump starter is for use with gasoline or diesel engine vehicles using a
12V battery only. The use of this jump starter on a vehicle that does not have a
12V battery may cause serious damage to the vehicle, the jump starter, and/or
serious injury to the user. Refer to the owner's manual of the vehicle for the
battery voltage.
• The product should not be charged while in contact with flammable material
like textiles.
• When charging the jump starter, use the USB cable and car charger/adapter
that are provided in the package (accessories included in the package vary
depending on the model). When using a different USB cable, charger, or
adapter, make sure it is certified according to the safety standards in your
country/region.
• Use the accessories that are provided in the package. Shell is not responsible
for any damage or injury when using accessories that are not provided by us.
• Do not put the jump starter directly above the vehicle battery during jump
starting.
• Do not jump start a vehicle while recharging the internal battery.
• Do not allow the clamps to touch each other.
• Keep out of reach of children.

Personal Precautions
Battery Disposal
• Wear adequate eye protection and protective clothing when working near a
vehicle battery.
• Do not smoke or allow a spark or flame near the battery or engine.
• Remove all metal objects such as rings, bracelets, and watches.
• Have plenty of fresh water and soap nearby in case of battery acid contact
with eyes, skin or clothing.
• If battery acid comes in contact with the skin or clothing, immediately wash with
soap and water. If the acid enters the eye, immediately flood eye with running
cold water for at least 10 minutes and seek immediate medical attention.
• Beware not to drop metal items on the battery. It might cause sparks or short
circuit the battery.
• Consider having someone nearby to come to your aid in case of emergency.
• Incompatible or damaged vehicle batteries may explode when used with this
product.
This product contains a rechargeable battery which must be recycled or
disposed of separately from household waste. Dispose of batteries according to
your local environmental laws and guidelines.

CONFORMS TO UL STD.2743
ENERGY PERFORMANCE VERIFIED
Made in China
CAN ICES-3(B)/NMB-3(B)
Cautions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. Howev-
er, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
reorient or relocate the receiving antenna; increase the separation
between the equipment and receiver; connect the equipment into an outlet on a
circuit different from that to which the receiver is connected; consult the dealer or
an experienced radio/TV technician for help. Any changes or modifications not
expressly
approved by the manufacturer could void the user’s authority to
operate the equipment.
WARNING:
This product can expose you to chemicals including lead, which is
known
to the State of California to cause cancer and birth defects or other
reproductive harm. For more information, go to www .p65warnings.ca.gov.

Shell Two (2) Years Limited Warranty
Shell warrants that this product (the "Product") will be free from defects in
material and workmanship for a period of two (2) years from the date of
purchase (the "Warranty Period"). For defects reported during the
Warranty Period, Shell will, at its discretion, and subject to Shell’s product
support analysis, either repair or replace defective Product. Replacement
parts and products will be new or serviceably used, comparable in function
and performance to the original part and warranted for the remainder of the
original Warranty Period. SHELL’S LIABILITY HEREUNDER IS EXPRESSLY
LIMITED TO REPLACEMENT OR REPAIR OF THE PRODUCT. TO THE
MAXIMUM EXTENT PERMITTED BY LAW, SHELL SHALL NOT BE LIABLE
TO ANY PURCHASER OF THE PRODUCT OR ANY THIRD PARTY FOR
ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR EXEMPLARY DAMAG-
ES, INCLUDING BUT NOT LIMITED TO, LOST PROFITS, PROPERTY
DAMAGE OR PERSONAL INJURY RELATED IN ANY WAY TO THE
PRODUCT HOWSOEVER CAUSED, EVEN IF SHELL HAD KNOWL-
EDGE OF THE POSSIBILITY OF SUCH DAMAGES. THE WARRANTIES
SET FORTH HEREIN ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING,
WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PURPOSE, AND THOSE
ARISING FROM COURSE OF DEALING, USAGE OR TRADE PRACTICE.
IN THE EVENT THAT ANY APPLICABLE LAWS IMPOSE WARRANTIES,
CONDITIONS OR OBLIGATIONS THAT CANNOT BE EXCLUDED OR
MODIFIED, THIS PARAGRAPH SHALL APPLY TO THE GREATEST EXTENT
ALLOWED BY SUCH LAWS.
This Limited Warranty is made solely for the benefit of the original purchas-
er of the Product from Shell or its approved reseller or distributor and is not
assignable or transferable. To make a warranty claim, the purchaser must:
(1) request and obtain a return merchandise authorization ("RMA")
number and return location information (the "Return Location") from Shell
Support by emailing [email protected] or by calling
1.833.990.2624 ; and (2) send the Product, including RMA number and
receipt to the Return Location provided. DO NOT SEND IN PRODUCT
WITHOUT FIRST OBTAINING AN RMA FROM SHELL SUPPORT. THE
ORIGINAL PURCHASER IS RESPONSIBLE (AND MUST PREPAY) ALL
PACKAGING AND TRANSPORTATION COSTS TO SHIP PRODUCTS
FOR WARRANTY SERVICE. NOTWITHSTANDING THE ABOVE, THIS
LIMITED WARRANTY IS VOID AND DOES NOT APPLY

TO PRODUCTS THAT: (a) were misused, mishandled, subjected to abuse
or careless handling, accident, improperly stored, or operated under
conditions of extreme voltage, temperature, shock, or vibration beyond
Shell's recommendations for safe and effective use; (b) improperly
installed, operated or maintained; (c) are/were modified without the
express written consent of Shell; (d) have been disassembled, altered or
repaired by anyone other than Shell; (e) had defects which were reported
after the Warranty Period. THIS LIMITED WARRANTY DOES NOT
COVER: (1) normal wear and tear; (2) cosmetic damage that does not
affect functionality; or (3) Products where the Shell serial and/or lot
number is missing, altered, or defaced.
For any questions regarding your warranty or product contact Shell
Support at:
1-833-990-2624
M-F 9 am - 5 pm
Eastern Standard Time
Camelion North America Inc.
2572 Daniel-Johnson Blvd. | 2nd Floor
Laval, QC, H7T 2R3, Canada
[email protected]
(North America)

SH SH924 IM ENG D10043R3
Printed in China
SH924
Jump Starter
Portable Power
