Titan ts143 User manual

www.TitanInnovations.ca
2-WAY LED SST EXTENDED RANGE REMOTE STARTER
For Automatic & Manual Transmission Vehicles
OWNER’S GUIDE

Titan Data Series TS143 Owner’s Guide2
TABLE OF CONTENTS
About Us / Thank you 3
Important Safety Notes 4
Titan-Secure 4
Valet “Service” Mode 5
Button Functions (Basic) 6
Button Functions (Advanced) 6
2-Way Confirmation 7
Basic Features: 7
Lock 7
Panic 7
Unlock 7
Trunk Release 8
Start 8
Idle Mode 8
Turbo Timer 8
Text Start 8
Advanced Features: 8
Silent Arm/Disarm 8
Cold Timer Mode 9
Auxiliary Output #1 9
Auxiliary Output #2 9
Long Lock Output 9
Manual Transmission: 10
Ready Mode 10
Transmitter Learning 11
Battery Life 12
Battery Replacement 12
Warranty 12
FCC Notice 13

Titan Data Series TS143 Owner’s Guide 3
ABOUT US
Titan Innovations Ltd is a Canadian company dedicated to quality, service, and integrity.
Titan products are designed by Canadians for Canadian climates. Titan products are
guaranteed to be built to the highest specifications using only quality components that
have been tested extensively under extreme conditions. This ensures that the customer is
receiving only the most reliable and innovative product available.
THANK YOU
Thank you for your purchase of this product. Any product designed and manufactured by
Titan Innovations is guaranteed to provide you years of trouble-free service. Your Titan
Remote Starter or Remote Starter / Security System has been developed for your peace
of mind and safety. It has been designed to provide you with the latest in technology,
combined with ease of use.

Titan Data Series TS143 Owner’s Guide4
IMPORTANT SAFETY NOTES!
CARBON MONOXIDE POISONING:
The owner/user MUST INSTALL a CARBON MONOXIDE DETECTOR in the living area near to
where the vehicle is being stored or parked. It is the sole responsibility of the owner/user to keep
the remote transmitters away from the reach of children and handle with care so that the system
does not unintentionally start. When the vehicle is parked in an enclosed/partially enclosed area (for
example: a garage or car port), being serviced, or if the vehicle is loaned to an operator not familiar
with a remote starter, the system MUST BE placed in Service(Valet) Mode.
NEVER OPERATE THE SYSTEM IN AN ENCLOSED
OR PARTIALLY ENCLOSED AREA!
HYBRID REMOTE STARTERS FOR
AUTOMATIC & MANUAL TRANSMISSION STARTERS:
The installation of a remote starter MUST BE DONE ONLY with a specified remote starter. Hybrid
Remote Starters have both an automatic transmission and manual transmission mode. It is the
responsibility of the vehicle’s operator to insure that:
• when the remote starter is in use with a vehicle equipped with a manual transmission, the
transmission remain in NEUTRAL POSITION ONLY.
• when the remote starter is in use with a vehicle equipped with an automatic transmission, the
transmission remain in the PARK POSITION ONLY.
It is the sole responsibility of the operator of the vehicle to insure the transmission positions
described herein are maintained at any time the remote starter is in use. In no case shall the
manufacturer or Titan be liable for any damages of any kind whatsoever including but without limited
to damages for personal injury or loss of life arising by virtue of a remote starter being used when
the transmission of the vehicle in question is not set as mandated herein.
TITAN SECURE
“Titan-Secure” is a security feature that is built-in to every Titan Data Series remote starter. Activat-
ing this feature will require some extra installation and/or parts. You can also add a siren and starter
disable to your system. This will give you the added security of an OEM style “Content Security”
system in your vehicle and will provide you with protection of your personal items in your vehicle
much like the factory content security systems in use on many vehicles today. Once installed, it will
provide you with door-pin and hood-pin coverage and also monitor your ignition. Once armed, if
your doors or hood are opened, or if someone is attempting to hot-wire your vehicle, your horn or
siren will sound. If you purchased a 2-Way Remote Starter system, it will also page to your transmit-
ter. It is as easy to use as locking and unlocking your doors. No shock sensor false alarms; no other
hassles; no other worries. “Titan-Secure” is that easy! Consult your Titan Dealer for more informa-
tion on “Titan-Secure”.

Titan Data Series TS143 Owner’s Guide 5
VALET OR SERVICE MODE
Valet or “Service” Mode will disable the remote start and/or Titan-Secure features of the system. The
optional Lock, Unlock and Trunk Release features will still be operational. When the vehicle is to have
any “under hood” or service work done, the system must be placed into Service Mode. This feature
may also be used if a transmitter is lost, damaged, or if the system malfunctions.
ATTENTION:
TO AVOID SERIOUS INJURY, this remote start system must be set into Service Mode before any
under hood servicing is started. Service Mode will prevent the vehicle from starting while the vehicle
is being serviced. It is the sole responsibility of the vehicle’s owner to place the system into Service
Mode. The manufacturer accepts no responsibility for accidental starting of the vehicle while the
vehicle is being serviced.
ENTERING SERVICE MODE:
Turn the ignition key to the On position.
Press and hold the Program Button (located on the antenna - center of windshield) for 5 seconds or
until the horn/siren (optional) honks five times.
Note: The LEDs on the antenna will turn on solid to confirm Service Mode. If the Start button is
pressed when the vehicle is in service mode, the park lights will flash slowly 3 times and the vehicle
will not start.
EXITING SERVICE MODE:
1. Turn the ignition key to the On position.
2. Press and hold the Program Button (located on the antenna - center of windshield) for 5
seconds or until the horn/siren (optional) honks two times.
Note: The LEDs on the antenna will turn off and the remote starter/security functions will be re-
enabled.
5 SecondsIGNITION ON

Titan Data Series TS143 Owner’s Guide6
BUTTON FUNCTIONS
BASIC FUNCTIONS
ACTION FUNCTION
Press Lock Button Once
For Less Than 2 Seconds
Locks Doors and Arms Titan-Secure
(If installed)
Press Lock Button
For More Than 2 Seconds
Activates Panic Function
Horn/Siren will sound for 60 sec.
Press Unlock Button
For Less Than 2 Seconds
Unlocks Doors and Dis-Arms
Titan-Secure (if installed)
Press Unlock Button
For More Than 2 Seconds
Activates Trunk Release (if installed) (will also
unlock doors)
Press Start Button Once
For Less Than 2 Seconds
Activates Remote Starter - Push Again to Shut
Off - Also does Idle Mode If Running With Key
Press Function Button Once
For Less Than 2 Seconds
Activates Turbo Timer Mode
(engine must be running)
ADVANCED FUNCTIONS
ACTION FUNCTION
Press Start & Function Buttons
For Less Than 2 Seconds
Sets Remote Timer Start
Mode On/Off
Press Lock & Function Buttons
For Less Than 2 Seconds
Long Lock Function
(Can be set for 15/30 sec. or Latched)
Press & Hold Start Button
For More Than 2 Seconds Aux Function #1
Press & Hold Function Button
For More Than 2 Seconds Aux Function # 2
2-WAY CONFIRMATION
LOCK LOCK
UNLOCK UNLOCK
START START
FUNCTION FUNCTION
3 LEDs

Titan Data Series TS143 Owner’s Guide 7
Whenever a command is sent to the vehicle by the transmitter, a confirmation is sent and indicated
by LED flashes and beeps. Use the table below to identify the confirmation for all the different
system functions.
FUNCTION LED 1 LED 2 LED 3
Remote Start Failure
3 LEDs will cycle in succession for
5 seconds
Red, Red, Red, Off,
Red, Red, Red, Off
Red, Red, Off -
pause-
Red, Red, Off
Red, Off
-pause-
Red, Off
Alarm Triggered Door
Green, Red Red Off
Alarm Triggered Hood
Green, Red Flash Red Flash Red
Alarm Triggered Ignition
Green, Red Red Red
Press Any Button
X X Lights as long as
button pressed
Remote Battery Low
XFlashes once every
5 seconds X
Unlock/Disarm
Green LED for 1
second X X
Lock/Arm
Red LED for 1
second X X
Trunk Release
Red LED for 1
second
Red LED for 1
second X
Remote Start Success
Three LEDs will cycle in
succession for 5 seconds
Green, Green,
Green, Off, Green,
Green, Green, Off
Red, Red, Off
-pause-
Red, Red, Off
Red, Off
-pause-
Red, Off
Remote Start Shut Down Red flashes for 5
seconds
Red flashes for 5
seconds
BASIC FEATURES
LOCK
Pressing the Lock button for less than two seconds will Lock your doors. Park lights will flash
once and if your horn is hooked up or optional siren is installed, you will hear one honk/chirp. LEDs
located on your antenna will flash slowly. If you have Titan-Secure enabled, locking the doors will
also arm your security system. If starter disable is installed, it will also activate at this time. These
features require extra install and/or parts. Consult your Titan dealer.
PANIC MODE
Pressing the Lock button for more than two seconds will activate Panic Mode. If your vehicles
horn or a siren is connected to your system, it will honk your horn/siren for 60 seconds or until you
push and hold the Lock button again.
UNLOCK
Pressing the Unlock button for less than two seconds will unlock your doors. Park lights will flash
twice and if your horn is hooked up or optional siren is installed, you will hear two honks/chirps. LEDs
located on your antenna will go out. If you have Titan-Secure enabled, unlocking the doors will also
dis-arm your security system. If starter disable is installed it will also de-activate at this time.
BASIC FEATURES cont’d

Titan Data Series TS143 Owner’s Guide8
TRUNK RELEASE
Pressing the Unlock button for more than two seconds will activate Trunk release. If you have
this option installed, when activated, this function will first unlock the doors, disarm any security and
then open your trunk. Your park lights will flash 3 times. This feature requires extra installation and/or
parts. Contact your Titan Dealer for more information.
START
Pressing the Start button for less than two seconds will activate the “Remote Start” process.
If the horn/siren is hooked up, you will one horn honk and one park light flash, then the vehicle will
start. The park lights then flash 5 times and stay on. The vehicle will run its programmed run time
and shut down. When the vehicle shuts down, the park lights will flash twice and horn/siren will chirp
twice. Run times are adjustable for preset times of 4, 15, 30, and 45 minutes. The default run time
is 15 minutes. This run time can easily be adjusted by your Titan dealer. When the vehicle is running
with the remote start, pressing the Start button again for less than two seconds will shut off the
remote starter.
IDLE MODE
When the vehicle is running with the key, pressing the Start button will activate Idle Mode. Idle
Mode is useful for times where you may want to leave your vehicle running without leaving the keys
in the ignition, such as popping into a convenience store. With the vehicle running with the keys in
the ignition, and the transmission in Park, just press the Start button, making sure not to push on
the brake. Your park lights will flash twice and horn/siren (optional) will chirp twice. You can remove
your keys and the vehicle will stay running. You can exit the vehicle and use your remote to lock your
doors. If you are away from your vehicle longer than your programmed remote starter run time, the
vehicle will automatically shut down. Just make sure to shut your lights off if you had them on.
TURBO TIMER MODE
If your vehicle is equipped with a Turbo(s), it may be required to be cool down the Turbo(s)
before shutting off the vehicle. Consult your owner’s manual or check with your dealer for more
information. To activate Turbo Timer, with the vehicle running by key, ensure the transmission is in
Park. Make sure to keep your foot off the brake and press the Functionbutton once for less than 2
seconds, and the remote starter will take over. You can remove your keys, exit the vehicle, and lock
your doors. The remote starter will keep the vehicle running for 2 minutes and then shut off by itself
allowing your Turbo(s) to cool down.
TEXT START
This unit is “TEXTSTART®” READY. This unit is fully compatible with Titan’s new SMS “Text
Messaging” systems. This new advanced technology allows you to control and monitor your vehicle
from your cellular phone.
ADVANCED FEATURES
SILENT ARM/DISARM
If you have Titan-Secure Security features installed and enabled, you may want to silently Arm/Lock
and Disarm/Unlock your vehicle. If so, press the Lock & Unlock buttons together for less than 2
seconds. This button combination is always a temporary function and will toggle Silent Arm/Lock
and Silent Disarm/Unlock. If you push Lock or Unlock separately, your unit will function with normal
honks/chirps again.

Titan Data Series TS143 Owner’s Guide 9
ADVANCED FEATURES Cont’d
COLD TIMER MODE
Pressing the Start & Function button together for less than 2 seconds will activate or deactivate
the Cold Timer Start function. This function is useful if you cannot plug in your vehicle in extremely
cold weather. If this feature is turned on, the vehicle will start and run for the preset run time every
1, 2, 3, or 4 hours for a 24 hour period. To turn on the Cold Timer Start, push the Start & Function
buttons together for less than 2 seconds. The park lights will come on. Once the park lights are on,
you have five seconds to set the delay time between cold timer starts. Press the following buttons to
set your delay for the following times:
Lock Button 1 Hour
Unlock Button 2 Hours
Start Button 3 Hours
Function 4 Hours
When you press one of these buttons the park lights will flash the corresponding number of flashes
to confirm your setting. Your Cold Timer Start is now turned On.
To turn off Cold Timer start, just press the Start & Function buttons together again. The park lights
will flash twice and horn/siren will chirp twice to confirm the feature is turned off. This feature will
also turn off by turning on ignition with the vehicles key.
AUXILIARY OUTPUT #1
This output can be used to control auxiliary functions such as sliding doors or other functions
requiring a momentary input. To activate this output, press the Start button for more than 2
seconds. On certain vehicles with sliding doors, there may be an Unlock pulse required opening a
sliding door, so upon activation of this output, you may or may not have your doors unlock first. It
just depends on how the installer configures your vehicle. These features require extra installation
and/or parts. Consult your Titan dealer for more information.
AUXILIARY OUTPUT #2
This output is configured very similar to Auxiliary Output #1. To activate this output, press the
Function button for more than 2 seconds. This can be used for a second sliding door or other
applications. These features require extra installation and/or parts. Consult your Titan dealer for
more information.
LONG LOCK OUTPUT
This output gives you some versatility with your Lock functions. This output can be used as a
“latched” output or as a “timed” output for 15 or 30 seconds. If you have a vehicle that has factory
installed “Window Rollup Features” that will roll up your windows if you hold the lock button or hold
the key in the lock position in the door, you can use this function to roll up your windows with your
Titan remote. Consult your Titan dealer to see if your vehicle has this option. To activate this output,
press the Lock & Function buttons together for less than 2 seconds. If you do not have power locks
in your vehicle, this output can be used for a variety of special applications.
These features require extra installation and/or parts. Consult your Titan dealer for more information.

Titan Data Series TS143 Owner’s Guide10
MANUAL TRANSMISSION READY MODE
To remote start the vehicle, you must first place the system in “Ready Mode”. There are 3 different
programming options for doing this. To use a method other than the default setting, you must have
your system re-programmed by an authorized dealer.
Default - Transmitter Activation
1. With the engine running & transmission in Neutral, apply the parking brake.
2. Press and release the Start button on the remote transmitter.
3. Turn off key and remove from the ignition (the vehicle will stay running).
4. Exit the vehicle and make sure all doors are closed.
5. Press the Start button on the transmitter to shut the vehicle off.
6. The vehicle is now in “Ready Mode” and can be started by remote.
Option 2 - Brake Pedal Activiation
1. With the engine running & transmission in Neutral, apply the parking brake.
2. Press and release the brake pedal 2 times (once if it was already on when you applied the park
brake in step 1).
3. Turn off key and remove from the ignition (the vehicle will stay running).
4. Exit the vehicle, upon closing the last door, the vehicle will shut down.***
5. The vehicle is now in “Ready Mode” and can be started by remote.
Option 3 - Park Brake Activation
1. With the engine running & transmission in Neutral, apply the parking brake.
2. Turn off key and remove from the ignition (the vehicle will stay running).
3. Exit the vehicle, upon closing the last door, the vehicle will shut down.***
4. The vehicle is now in “Ready Mode” and can be started by remote.
REMOTE STARTING ALL MODES
1. With the engine off, press the Start button.
2. The park lights will flash and the horn will chirp once (if connected).
3. The vehicle’s ignition system will come on and within 3 seconds, the vehicle will start.
4. The parking lights will flash 5 times to confirm a successful start.
5. The vehicle will run for the programmed runtime (15 minutes default).
If the vehicle does not start, see the diagnostics section on Page 23 for possible solutions.
If you press the Start button on the transmitter while the door is open, the system will go into “Idle
mode” and NOT shut down when you close the door. It will run for the programmed run time or
until it is shut down by the remote. This feature is convenient if you need to open other doors after
having closed yours.
IMPORTANT: If a door is opened while the vehicle is not running and in “Ready Mode”, the system
will exit “Ready Mode” and will not remote start. You will need to start the vehicle with the key and
repeat the procedure. If you need to open doors and want to avoid repeating the “Ready Mode”
setup again, simply remote start the vehicle and open the door while the vehicle is running. When
you are done, and the doors are closed, you can shut down the vehicle with the remote and “Ready
Mode” will still be engaged.

Titan Data Series TS143 Owner’s Guide 11
MANUAL TRANSMISSION READY MODE cont’d
DIAGNOSTICS
If the remote starter does not activate when the Start button is pressed, the park lights will flash a
diagnostic code to indicate what shutdown input prevented starting.
PARK LIGHT FLASHES PROBLEM SOLUTION
3 Slow Flashes System is in Service Mode Cancel Service Mode
4 Slow Flashes Door Open Manual Transmission Models
Only
5 Slow Flashes Ignition On Turn Off Ignition Key
and Try Again
5 Flashes Brakeswitch Engaged Check Brakepedal or Consult
Dealer
6 Flashes Hoodswitch (Hood Open)
Close Hood and/or Check
Hoodpin Switch or Consult
Dealer
7 Flashes Tach Lock-Out/Failed Start
Start Vehicle with Key, Wait
5 Seconds and Try Again or
Consult Dealer
TRANSMITTER LEARNING
Important! The remote starter will hold 4 transmitter codes. It is recommended that when
programming in transmitters, you fill up all four transmitter codes, even if only using one or two
transmitters. This will clear all other transmitter coding from the unit and prevent stray coding or
possible interference from other remote transmitters.
In you purchase new transmitters, they will have to be programmed to your unit before they will
function. Your local Titan dealer can do this for you, but in the event you do not have access to
a dealer, you can program them in yourself. All transmitters to be used on the vehicle must be
programmed in at the same time. If you try to add only one transmitter, when you add it, it will
erase all other transmitter in the system, so you must code in all transmitters. This is a security safety
feature in the event you lose a transmitter.
CODING IN TRANSMITTERS
1. Within 3 seconds, turn ignition key On and Off 3 times, leaving the key in the “ON” position
(On-Off-On-Off-On).
2. Press and hold the Program button on the antenna (center of windshield). The park lights will
turn “On” and the horn/siren (optional) will honk once. Continue to hold the Program button.
The park lights will turn “Off” and the horn/siren (optional) will honk 5 times quickly.
3. While holding the Program button, press and release the Lock button on each of the remote
transmitters to be programmed. If using two transmitters, code in each transmitter twice. Turn
off the key. One long horn honk will follow to show you have exited programming.
HoldIGNITION ON

Titan Data Series TS143 Owner’s Guide12
BATTERY LIFE
To see how much battery life is remaining in the T43RC transmitter, press the Unlock and Function
buttons at the same time for 2 seconds. The 3 LED lights on the transmitter will light in the following
sequences to show you the remaining battery life.
BATTERY REPLACEMENT
When your remote starter system begins to show a significant reduction in transmitter range, or the
remote does not respond correctly, it may be time to change the batteries.
The 2-Way transmitter uses 2 - CR2430 - 3 Volt Lithium batteries. Simply slide open the battery cover
to replace both batteries. Slide the battery cover back on the transmitter to resume use.
The 1-Way transmitter uses 1 - CR2032 battery. To change the battery, this is the procedure:
1. Open the transmitter at the notch in the casing near the bottom of the transmitter (Use a small
tool or a coin to gently pry the top and bottom of the casing apart).
2. Once the top and bottom case are seperated, slide out the battery under the battery clip.
3. Replace with 1 new CR2032 battery.
4. Press top and bottom casing together (make sure to put keychain assembly in between cases)
until they snap back into place.
If the transmitter shows no significant improvement after replacing the batteries, contact your Titan
dealer to have your system inspected.
WARRANTY
The manufacturer warrants to the original purchaser of the Remote Starter or Remote Starter /
Security System, that the product shall be free from defects in material and workmanship. However,
should this product be proven to be defective, within a three year period from the original date of
purchase, the manufacturer will, without charge to the purchaser (excluding any charges incurred to
have the product delivered to the manufacturer), repair or replace the main control module of the
Remote Starter or Remote Starter / Security System if the manufacturer agrees it to be defective.
All other components or parts of the Remote Starter or Remote Starter / Security System such as
Transmitters, Antennas or other components carry a warranty period of one year from original date
of purchase.
All warranties apply to the original purchaser and the vehicle in which the unit was originally installed
ONLY. Repairs or replacement of defective items shall remain at the discretion of the manufacturer.
UNLOCK
FUNCTION
3 LEDs
3 LEDs Lit - (Green-Red-Red)
Battery Full
3 LEDs lit - (Orange-Red-Red)
Battery 2/3 Full
3 LEDs Lit - (Red-Red-Red)
Battery 1/3 Full
1 LED Lit - (x-Red-x)
Battery Needs To Be Replaced

Titan Data Series TS143 Owner’s Guide 13
All other add-on parts, components, accessories, and/or optional equipment pertaining to the
remote starter or remote starter / security system such as interface modules or other accessories are
not included in the manufacturer’s warranty. This warranty is non-transferable. Request for warranty
service from any Factory Authorized Dealer must be accompanied with the original purchase receipt.
Failure to comply with any of these conditions may result in warranty being void and/or refused.
This warranty does not cover the following: removal and reinstall labor charges, shipping charges,
abuse, misuse, or accidental damages to the remote starters and/or alarms, automobile, and/or parts
thereof. This warranty is void upon modification, repairs, or alterations to any part of the product.
The manufacturer does not guarantee or insure against theft of the vehicle or its contents. Alarm
models are designed only to act as a deterrent against possible theft. Alarms may qualify for auto
insurance discounts.
Contact your insurance agent for further information. The manufacturer shall not be held liable for
any consequential damages due to breach of this or any other warranty, expressed or implied. This
warranty gives you specific legal rights. Your specific legal rights may vary for each region. CERTAIN
DAMAGES EXCLUDED – The manufacturer expressly disclaims any liability or responsibility for
incidental damages caused by the product, including economic loss, loss of use of the product,
car rentals, or any other costs relating to the care and custody of the product. The manufacturer
disclaims liability or responsibility for any consequential damages caused by the product or resulting
from its use, including the cost of repairing or replacing other property damaged by the product or
caused by its use, whether or not the product is working properly. The product is intended to deter
unauthorized use of the vehicles in which it is installed. The manufacturer does not warrant that the
product is fool-proof against theft and/or vandalism and/or human error or misuse. The manufacturer
accepts no liability or responsibility for any damage of any kind whatsoever caused to any vehicle
in which the product is installed or any resulting damage from its use. The manufacturer accepts no
responsibility or liability for any damage resulting to or theft of the vehicle or its contents caused or
alleged to be caused, directly or indirectly, by failure of the product.
THE MANUFACTURER OR TITAN SHALL NOT IN ANY CASE BE LIABLE FOR DAMAGES
INCURRED OF ANY KIND WHEN A REMOTE STARTER HAS BEEN USED ON A VEHICLE, THE
TRANSMISSION OF WHICH WAS NOT SET TO THE MANDATED POSITION.
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation of this device is subject to the
following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
3. CAUTION: Changes or modifications not expressly approved by the part responsible for
compliance void the user’s authority to operate this device.

Titan Data Series TS143 Owner’s Guide14

Titan Data Series TS143 Owner’s Guide 15

Please visit www.TitanInnovations.ca for more information
This unit is covered by a Manufacturers Warranty.
Please refer to your Owner’s Manual for details. Revision 1.01
