Sheng Jay Automation Technologies SJ-KV204 User manual

SJ-KV204
High Resolution touch Screen
Car DVR

Quick Guide
Product Feature .............................................................................. 1
Caution............................................................................................... 3
Product Appearance..................................................................... 4
Accessory .......................................................................................... 5
Operation .......................................................................................... 5
Funtion Setting—Video Recording Mode......................... 6
Funtion Setting—Video Replay Mode ................................ 8
Main Menu ...................................................................................... 9
System Setting ........................................................................10
Main Menu ...................................................................................... 9
Main Menu ...................................................................................... 9
Emergency Event Protection........................................17
Video Output connect to TV ...................................................15
Specification...................................................................................16

Feature
With a 120-degree ultra wide angle lens, compare to the similar
models in the industry, with more 15% wide visual range
Using touch screen to make it designed for seamless
interaction between humans and machines
Video recording, photograph, mute function, emergency
records are completed in easy and quick action
With 2.4-inch large display screens, screen masking frame
design, high resolution and all information and functions to be
clear and understandable.
Screen Sleeping Mode, the driver avoid the interference from
screen brightness
Equipped with a 1/4 "HD CMOS high resolution sensor, to be
provided with the 1080P Full HD and 720P HD high resolution,
induction lighting changes between day and night,
automatically adjust the sensor value, enhance the video effect.
5 pieces of multilayered glass lenses, image capture images
hyper-realistic; exclusive Anti-Glare design, enhance the video
effect

Digital Zoom, which provides 4 times optical zoom supports all
video and photo mode operation
Built-in 3G-SENSOR , automatic detect the x axis, y axis and z
axis 3-dimensional space of gravity change, also providing
emergency protection function of video anti-writing protection;
when there was a serious hit , the G-Sensor automatically
detect and start the video anti-writing protection features, full
protection of crucial files and records.
Supports optional external GPS Speed Camera Detector, it
makes the alert and displayed on the screen of the information,
such as the speed camera locations, speed limits, current speed
and coordinate, to enhance vehicle detection protection,
reduce the chances to get the penalty.
Loop recording function, automatically overwrite last record
files
With seamless video recording features, ensure that complete
records zero latency
The delay start feature to prevent the instant current pulse
circuit damage the product, increase product life.
Start the engine and automatically recording, switch the engine
off and automatically delayed power off the device to ensure
complete emergency record file

Recording mode and playback mode synchronized video
output , compliant with in-vehicle AV equipment.
Support up to 32GB Micro SD card (please use 4GB the above
grades)
Built-in microphone, record high quality audio
This product is RoHS and through Taiwan BSMI, FCC and CE
international safety certificates

Caution
We recommend that you set up all of the options of this
product priority, avoid to operate this product while driving,
keep driving safety
Please keep the camera lens clean, not with fingers and
substances such fat containing or water to contact lenses,
resulting in dirt and hazy mist or a halo effect, resulting in
reduce video quality; recommended to clean the lens with
lens wipe cloth regularly, to maintain the high quality
video, and do not use toilet paper or paper to wipe
the lens to avoid scratching the lens.
Please use a Micro SD card (at least 4GB above, recommen
ded Class6 rating above), using a Micro SD card for the
first time, please do the format after turn on the device,
to ensure the storage card in the normal use.
properly maintained and keep wipe the car thermal insulation,
to enhance the video resolution
If your vehicle is not often used and long exposure to the
outdoor, it is recommended that you remove this product from
the car and to install it while driving, to enhance product life.

Product Appearance
1
2.4”Touch Screen Dis
play
6
140 Wide angle lens
2
Car Charger Input Por
t
7
Micro SD slot
3
Switch on/off
（Press 3 seconds
to be forced shutdow
n）
8
GPS Speed Camera Detector con
necto

4
AV OUT
9
The second camera port
5
Mounting Bracket Slot
Accessory
Mounting
bracket
Car Charger
External
Camera
External
Cable
User Manual
CD

Operation
Take out the device from the gift box，insert the SD Card，
connect the Car Charger to car cigarette lighter ignition then the
device start function.
Please use the proper SD Card （please use 4GB the above grades
and use above Class6 ），push the SD Card into the slot
according to the direction，until it make a "click" sound,
the installation completed；it want to take the SD Card out, only
push the SD Card into the slot slightly，it automatically pops up
and can be removed easily。（During recording the video, photo
snap, and playback，please do not remove SD card，not only
resulting files are corrupted，but also cause the device not
functioning）

Mounting the Bracket
Accessory mounting bracket can be sucked on the front
windshield，to make sure fix the device firmly，Please take the
following steps to fix bracket with the device
A. Inset the bracket buckle into the slot of the back-clip（
as the below image）。
B. After the combination of the bracket, Recommend to sock
the bracket on the front windshield behind the rear-view
mirror
C. Find the suitable position to mount the device ，Press down the
fixed pole on the bracket sucker, make sure again that all
components combined well and sucked firmly.

Funtion Setting—Video Recording Mode
Touch the center of the screen to start or to stop the recording
Recording Mode
Main Menu
Recording
Indicator（blink）
Single/Dual
Display
Activate auto
collision
detection，file
not over-writing
Audio Recording
Video time
Manual activate
collision detection

Focal adjustment
Date/Time
GPS completed
and speed detect
（Optional ,
comply with SJA
GPS Speed
Camera
Detector）
Activate Motion
Detection
Zoom in / Zoom
out

Funtion Setting—Video Replay Mode
檔案重播模式
下一個檔案/快
轉
目前檔案編號
上一個檔案/快
退
目 前 檔 案 屬 性
（保護、防寫或
一般）
停止播放
進入主選單
檔案播放/暫停
目前檔案錄影解
析度
刪除選項
目前檔案儲存日
期與時間

Funtion Setting—Video Replay Mode
—Delete Selection

Main Menu
Recording
File Replay
System
Set Up

System Set Up
(1) Video Set Up

General Setting

Version
After the firmware version is displayed, click on the screen bac
k to recording display (Subject to the actual version).
Screen calibration
Calibration the accuracy of the touch screen，Operation as follows：
1. Please touch Top-Left red point 2. Please touch
Bottom-Right red point。3. Finished。

Emergency Event Protection
This devie has the G-sensor automatic collision detection，
to start the file Write-protect function，Also provides user manual
touch emergency protection；pressing this function while
recording，the key graphics will appear at the top left corner of
the screen the key graphics will appear, emergency protection
file length is the length of the current recording file plus 30
seconds recording file length after triggering the protection
function , protect the files not being overwritten
by the loop recording function，the files will be saved in the SD
card to the separated "CRASH" folder. (as the below image)

G-Sensor gravity sensor: automatically detects vehicles collisions
and forced protect files
In the system set up > in video options, G-sensor
(accelerometer) sensitivity set default value to "middle"
(which means in activate and normal sensitivity), the actual
effects are as follows:
(1) Automatically record emergency events, log files, file protection
function as the previous statement.
(2) Adjust the sensitivity in according to the driving condition，Such
as high or low sensitivity，for adjusting the sensitivity value of
the auto collision detection.
