Shenzhen Shunxun Electronics SX-SP18 User manual

Operating Instructions
HDMI
HDMI
HDMI
HDMI Splitter
Splitter
Splitter
Splitter
Model
Model
Model
Model No.:SX-SP18
No.:SX-SP18
No.:SX-SP18
No.:SX-SP18
Operating
Operating
Operating
Operating Instructions
Instructions
Instructions
Instructions
Dear
Dear
Dear
Dear Customer
Customer
Customer
Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
FEATURES
FEATURES
FEATURES
FEATURES
�
1 HDMI input.
�
1 HDMI output, 7 UTP method HDMI outputs
�
IR call back function to control the source from TV side
�
Mounting ears
�
HDMI 1.3b
�
�
�
�
DIP switch setting to control EDID.
�
Support 3D video format
NOTICE
NOTICE
NOTICE
NOTICE
Our company reserve the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
1
1
1
1

Operating Instructions
TABLE
TABLE
TABLE
TABLE OF
OF
OF
OF CONTENTS
CONTENTS
CONTENTS
CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
M aintenance
Typical Application
Product Service
Warranty
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Operating Temperature R ange …………………………… ....... -5 to 3 5 ℃(-41 to 95 ℉)
Operating Humidity R ange ……… . … .................... .... 5 % to 90% RH (No Condensation)
Video Amplifier Bandwith..................... .. ......................................................... . 140 M Hz
Input Video S ignal ………………………………… . …… ................. … 0.5-1.0 Volts P-P
Input DDC signal...................................................................................5 volts p-p(TTL)
Data transfer speed rate................................................................6.75Gbps(Maximum)
Video Format Supported..........................VGA:640x480,800x600,1024x768,1080x1024
SDTV/HDTV:
480i/576i/480P/576P/720P/1080i/1080P
3D video support
HDMI Output …………………………… ................................................... … . HDMI 1.3b
Maximum Transmission Distance.................50m (If needed, HDMI extender is optional)
Vertical Frequency Range ……………… .............................. … ........................ … . 60Hz
Power consumption ………………………… ..... …………… ................................ 15 watts
Dimension (L × W × H) ……………………………………… ....... ... . ......... L268*W153W*H43mm
Net Weight …………………………………………………………………… ....... 1320g
Note: Specifications are subject to change without notice. Mass and dimensions are approximate.
PACKING
PACKING
PACKING
PACKING CONTENTS
CONTENTS
CONTENTS
CONTENTS
1) Main Unit. 1x 8 HDMI S plitter via UTP cable
2) DC 12 V 3A Power Supply
3) Operating Instructions
4) IR-TX cable
5) Mounting ears
2
2
2
2

Operating Instruction s
PANEL
PANEL
PANEL
PANEL DESCRIPTIONS
DESCRIPTIONS
DESCRIPTIONS
DESCRIPTIONS
Front Panel
① ②
Rear Panel
③ ④ ⑤ ⑥ ⑦ ⑥ ⑧
①Indicators of HDMI output:when a HDMI equipment i connected the corresponding LED lit
②Power button:when power on,the power status LED lit
③Power input port ④EDID settingUTP out ports
⑤HDMI out put port ⑥UTP output ports
⑦HDMI in put port ⑧IR/TX o utput port
CONNECT
CONNECT
CONNECT
CONNECT ING
ING
ING
ING AND
AND
AND
AND OPERAT
OPERAT
OPERAT
OPERAT ING
ING
ING
ING
1) Connect the HDMI input sources into HDMI splitter(Input cables are optional).
2) Connect two CAT-5E/6 cables to both the STP/UTP outputs of HDMI splitter and inputs of
STP/UTP receiver . Please pay attention to the sequence of the two cables,Cat O/1->receiver 1,
CatO/2->receiver 2. (The cable termination must follow the standard of EIA/TIA 568B, ).
3) Connect the HDMI output (such as HD-LCD/HD-DLP) into the STP/UTP receiver.
3
3
3
3

Operating Instruction s
4) Connect the IR RX receiving cable into STP/UTP receiver IR RX and connect The IR TX cable
into HDMI splitter IR emitter.
5) Insert the DC side of 12 v power supply into HDMI splitter and then connect
the AC side of the power supply into the wall outlet.
6) Turn on the power.
Attention: DIP Switch EDID setting index
Position1 Position 2 Position 3
Function
0 0 0
1080P stereo (Using Embedded EDID) (note 1)
0 0 1
1080P 5.1 (Using Embedded EDID) (note 2 )
0 1 0
Edid auto mix, mix result is compatible with all HDMI sinks (note 3 )
0 1 1
copy the first detected HDMI output's edid to the input port (note 4 )
1 0 0
LC mode, 1080P stereo (Using Embedded EDID) (note 5 )
1 0 1
LC mode, Edid auto mix, mix result is compatible with all HDMI sinks (note 6 )
1 1 0
LC mode, copy the first detected HDMI output's EDID to the input port (note 7 )
1 1 1
Fix single UTP output (note 8 )
Note1:
Note1:
Note1:
Note1: The splitter will use the embedded 1080P-stereo EDID when the DIP switch is in this
mode. The EDID will be 1080P video and stereo audio
Note2:
Note2:
Note2:
Note2:
The splitter will use the embedded 1080P-5.1 EDID when the DIP switch is in this mode.
The EDID will be 1080P video and 5.1 audio
Note3:
Note3:
Note3:
Note3: The splitter will mix the EDID data of all HDMI sinks. And forward this mixed EDID to
the HDMI source device. The thought of EDID mixing is to enable all the connected sink device
can have video and audio they can output. For example, One TV is 1080P, stereo, another is
1080i, 5.1 audio. The mixed EDID will be 1080i, stereo audio
Note4:
Note4:
Note4:
Note4: Copy the EDID data to the input port. It will copy the EDID data from the first detected
output port
Note5:
Note5:
Note5:
Note5: Please refer to Note1. The only difference is that if video appears noise or interference
when the long HDMI/UTP cable is used or the quality of HDMI/UTP cable is not so good, use
this mode.
Note6:
Note6:
Note6:
Note6: Please refer to Note 3. The only difference is that if video appears noise or interference
when the long HDMI/UTP cable is used or the quality of HDMI/UTP cable is not so good, use
this mode
Note7:
Note7:
Note7:
Note7:
Please refer to Note 4.The only difference is that if video appears noise or
interference when the long HDMI/UTP cable is used or the quality of HDMI/UTP cable is not so
4
4
4
4

Operating Instruction s
good, use this mode
Note8:
Note8:
Note8:
Note8:
Fix single UTP output, use the embedded 1080P-stereo EDID
Typical
Typical
Typical
Typical Application
Application
Application
Application
MAINTENANCE
MAINTENANCE
MAINTENANCE
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of benzine to clean this unit.
Shenzhen Shunxun Electronics Co., Ltd
Tel: [phone] 27152661
Fax: [phone]
Web:www.foxun.com
