Shenzhen 1080P User manual

Road Safety Guard
Instruction Manual
Thank you for purchasing 1080P portable DVR from
our company In order to help you operate it correctly,
please read this instruction carefully before using

Product Picture and Function
1. HDMI Slot 9 .Lens
2. USB Slot 10.Speaker
3. Working Indicator ( lue) 11. Microphone
charging indicator (red) 12. Holder slot
4. 2.8’’ TFT LCD 13. On/Off
5. Mode Button 14. Rec/Snap
6.Meau Button 15. Battery Cover
7.Up Button 16. TF Card Slot
8. Down Button 17. Battery Slot
Attached accessories
User manual Camera holder USB ca le Rechargea le Li-ion attery
USB Car charger (Include the adaptor which can 12V/24V transfers to 5.5V)
Two power options
(A) Use rechargea le Li-ion attery
DVR can e activated after it has een placed on the vehicle y pressing the ON/OFF power
switch ⒀ and turn off y pressing it again.
Charging: Connect with USB ca le or USB car charger, the indicator will display red and
convert to no light when it is full
(B) Connect with USB car charger

DVR will record automatically when the car started, turn off and save the last file after the
car stops .
Note:only use the output power for 5.5V-7V
Video Mode
DVR will enter into the defaulted recording mode when turned on, the work indicator flash
lue and indicate it is recording. The recorded files are saved in the TF card. To stop, please
press Rec utton or ending when car stops, the work indicator won’t flash.
Camera Mode
Turn on the DVR and press the Mode utton ⑤ to enter into the camera mode. To take picture
y pressing Snap Button (14) . Press the Meau Button ⑥ to set the picture resolution from
1280x960 / 1600x1200/2048x1536 and confirm it y pressing REC utton.
Preview and Delete
Turn on the DVR ,then press Mode utton ⑤ twice to enter into Preview Mode. Press Up ⑦ or
Down ⑧ to select the previewed file and enter into the index y pressing REC utton (14). If it is
video file,it can play or stop y pressing REC utton .(e.g. :Index is named Y/M/D and file is
named DR H/M/S,if want to preview the file 2010/01/01 10:28:08,enter into index 2010-01-01
and select DR 102808 to play).If you want to delete the files, press the Meau utton ⑥ to enter
into the Delete Mode. And then press UP ⑦ or DOWN ⑧ to select Delete Current / Delete All,
confirm to delete it or exit from delete interface y pressing REC utton (14) .If you want to
format ,please select and confirm Format Memory y REC utton.
Function Setting
Turn on the DVR, then Press the Meau utton
○
6 to enter into the setting interface. To confirm
the operation, press the REC utton (14) and select y UP/DOWN for the following setting .Press
Meau utton
○
6 to exit after finished all the settings.
1. Video Resolution: VGA(640*480Pixels) 720P(1280*720Pixels) 1080P(1920*1080Pixels）
2. Audio Recording: ON/OFF.If choose OFF, there will e no audio when recording.
3. Volume:From 0 to 7
4. Motion detection: Choose ON( it will display on the screen ) /OFF. When choose ON,
it will record automatically if there is an o ject movement in front of the car ,the
recording time is according to the setting time,e.g.setting 2 minutes as recording time,the

recording time will last 2 minutes if there is an o ject movement,stop recording if no
movement after 2 minutes and continue recording if still have movements.
5. FPS:10FPS/ 20FPS/30FPS
6. Recording Time: 2 minutes /5 minutes/10 minutes /OFF.
7. LCD Back light: 15 seconds/30 seconds /60 seconds/ON. When select (15/30/60) seconds,
the LCD will turn off automatically after 15/30/60 seconds of inactivity. If select ON, the
LCD will turn on all the time.
8. Date Stamp: Date&Time Stamp/No Stamp. When choose No Stamp, Video will not have
date and time display
9. Date/Time: Y/M/D H/M/S
Press REC utton (14) to enter into the date and time setting, then press Up utton ⑦ or
Down utton ⑧ to adjust the date and time, press Rec utton to enter into the next
setting and confirm the setting y pressing REC utton ( 14).
10. Language: English/ Chinese Simplified /Chinese Traditional/ /Portuguese /Russian
/Japanese/Korean
11. Fenquency:50Hz/60Hz
12. Default Setting: YES/NO. When choose YES, it will restore to factory-default setting
13. Version: Show the software version num er
USB Mode
Connect the DVR with computer through USB ca le. There will appear remova le disk in
［MY COMPUTER］. The recorded files are stored at the DVR index,the file is placed relevant
Y/M/D index according recording time and is named y DR H/M/S. At the moment, the files
can e downloaded to the computer.
Preview the files on HD TV
Connect the DVR with the HD TV through HDMI ca le and turn on the DVR, it will enter into
the preview mode automatically. The operating steps are the same with previewed on the
screen.
otes
1.Please insert TF card efore recording
2.Please adjust the time display efore recording.If not set a time,the DVR can not record.

3.The DVR will record in cycle if choose 2/5/10minutes as the storage time. When the storage
medium is full, it will record from the eginning and erase over the previously recorded materials
automatically. If choose off, when the storage medium is full, it shows CARD FULL and stop
recording.
4.Please use the attached USB car charger to power the DVR. It contains the adaptor which can
convert 12V/24V to DC 5.5V.If the voltage over 5.5V, it will urn the DVR.
5.When press Rec (14) couldnot stop recording,please check whether set the Motion Detection is
ON.If yes,please choose OFF.
Technical Specifications
1.Video Resolution: VGA (640*480Pixels) 720P(1280*720Pixels) 1080P（1920*1080）
2.Picture Resolution：1280X960 / 1600X1200 / 2048X1536
3.Cycle recording without time interval, there is no lind area when recording, namely there is no
pause when recoding
4. Storage file automatically when accidentally power off,it storages file automatically every 10
seconds when recording.
5.Video Format:H.264
6.Power Supply: Rechargea le li-ion attery and 12V/24V USB car charger
7.Support TF card: 2GB-32GB
8.Microphone: can record sound
9.Interface: HDMI & USB2.0
10. Display:2.8’’LCD Monitor
No further notice will be given for any modification of the technical specifications
