Sherwood Industries UPTOWN UE44 Instruction Manual

INSTALLATION &
USER MANUAL
APPLICABLE FOR THE
UE44 | UE56 | UE68 | UE80
INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. C-16 843

2
Safety Precautions
• When using electrical heaters, basic precautions should
always be followed to reduce the risk of re, electric shock
and injury to persons, including the following:.
• Failure to follow these instructions may also void your re
insurance and/or warranty.
• WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this manual.
For assistance or additional information, consult
a qualied installer.
• CAUTION: Do not expose the heater to the
elements (such as rain, etc).
• Do not place clothing or other ammable
material on or near rebox. Never place any
objects on the replace.
• Do not place clothing or other ammable
material on or near rebox. Never place any
objects on the replace.
• Fireplace becomes very hot when running. Keep
children and adults away from hot surfaces to
avoid burns or clothing ignition. Fireplace will
remain hot for a time after shutdown. Allow
surfaces to cool before touching.
FOR YOUR SAFETY
1. Read all instructions before installing or using this
heater.
2. This heater is hot when in use. To avoid burns, do
not let bare skin touch hot surfaces. Keep combustible
materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 feet (0.9m) from the front
of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used
by or near children or disabled people and whenever the
heater is left operating and unattended.
4. Do not operate any heater after it malfunctions, has
been dropped, or damaged in any manner. Disconnect
power at service panel and have heater inspected by an
authorized technician or a reputable electrician before
using.
5. Do not use outdoors.
6. To disconnect heater, turn controls to o and turn o
power to heater circuit at main disconnect panel.
7. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an electric
shock or re, or damage the heater.
CAUTION: In order to avoid
overheating, do not cover the heater.
8. To prevent a possible re, do not block air
intakes or exhaust in any manner.
9. A heater has hot and arcing or sparking parts inside.
Do not use it in areas where gasoline, paint or ammable
vapours or liquids are used or stored.
10. Use this heater only as described in this manual. Any
other use not recommended by the manufacturer may
cause re, electric shock or injury to persons.
11. SAVE THESE INSTRUCTIONS
Read these instructions completely before beginning installation. Failure to follow them could
cause a heater malfunction resulting in serious injury and/or property damage.
WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it in
areas where gasoline, paint or ammable liquids are or are stored.
This replace meets the construction and safety standards of H.U.D. for application in
manufactured homes when installed according to these instructions

3
Table of Contents
Safety Precautions .....................................................................................................................2
Table of Contents ........................................................................................................................3
Specications .............................................................................................................................4
Dimensions: ................................................................................................................................. 4
Box Contents ..............................................................................................................................5
Initial Installation .......................................................................................................................6
Electrical Requirements: ................................................................................................................ 6
Installation - Wiring.................................................................................................................... 7
Standard 1500W: .......................................................................................................................... 7
Optional 3000W:.......... ................................................................................................................. 7
Installation - Framing & Finishing .............................................................................................. 8
3 Side (Bay) Installation:................................................................................................................ 8
2 Side (Left / Right Corner) Installation: ......................................................................................... 9
Flush (Linear) Installation: ............................................................................................................10
Partial Recess:..............................................................................................................................11
Installation - Front & Side Glass .............................................................................................. 12
Operation - Manual Controls.....................................................................................................13
Operation - Remote Controls ....................................................................................................14
Operation - Wi-Fi Controls ........................................................................................................15
Creating a Heat Program: .............................................................................................................17
Cleaning & Maintenance............................................................................................................18
Wiring Diagram ........................................................................................................................ 19
Troubleshooting .......................................................................................................................20
Parts List ...................................................................................................................................21
Notes .........................................................................................................................................22
Warranty ...................................................................................................................................23
Installation Data Sheet .............................................................................................................24

4
Specifications
Figure 1: Fireplace Dimensions
DImeNsIONs:
A
BB
C
D
EF
Figure 2: Drywall / Tiling Finishing Edges
mODel A B C D e F
Ue44 44”
(1120mm)
23.3”
(592mm)
11.5”
(291.5mm)
7.34”
(186.5mm)
17.4”
(442mm)
25.78”
(655mm)
Ue56 56”
(1421mm)
Ue68 68”
(1726mm)
Ue80 80”
(2032mm)
Finishing Edges Finishing Edges

5
Box Contents
FIreplACe
mOUNTINg
l -BrACkeTs (x4)
remOTe CONTrOl
sIDe COvers (x2)
sIDe glAss (x2)
FrONT glAss
Finishing Edges FIreBOx meDIA & lOg seTs
sUpplIeD sepArATely
(Items shown not to scale)

6
Initial Installation
WARNING: If the information in these instructions is not followed exactly, a re or explosion may result
causing property damage, personal injury or death
WARNING: RISK OF FIRE!
To prevent a possible re, do not block air intake or exhaust in any manner. Do not use on soft surfaces
where openings may become blocked. Do not blow or place insulation against the rebox.
To reduce the risk of re do not store or use gasoline or other ammable vapors in the vicinity of this or
any other heater.
CAUTION: Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at
least 3 feet (0.9m) from the front of the heater and keep them away from the sides and rear.
CAUTION: Wear gloves and safety glasses for protection during installation and maintenance.
Installing the replace
Select a suitable location that is not susceptible to moisture and is a safe distance from drapes, furniture and
high trac areas.
This replace has a number of installation options. It can be installed with all 3 sides showing (bay), 2 sides
showing (left/right corner), or ush (linear). In addition, it may also be partially recessed for a oating installation.
eleCTrICAl reqUIremeNTs:
All mODels
HeATer OpTION vOlTs (AC) HzAmps
1500W 120 60 14
3000W 240 60 14
For models using the standard 1500W heater, a dedicated 20 AMP 120VAC circuit will be required. If installing
the optional 3000W heater, a dedicated 20 Amp 4 wire 240VAC circuit will be required instead.
Note - Follow all national and local electrical and building codes.
Figure 3: Electrical Requirements

7
Standard 1500W Wiring
To be performed by a qualied electrician according to local building codes.
Optional 3000W Wiring
Installation - Wiring
L - Line
N - Neutral
- Ground
Figure 4: Electrical Cover Location
Figure 5: 1500W Wiring Diagram
To prepare for installation locate and remove the electrical cover on the top rear of the replace. Connect the
incoming hard wire to the terminal block according to the gure below, using a wiring connector type approved
by local building codes.
L1 - Line 1 (Primary)
L2 - Line 2 (Optional)
N - Neutral
- Ground
For replaces with the optional 3000W heater,
a 4 wire 220-240VAC line MUST be used.
A dedicated 20 Amp 4 wire circuit will be
required. Follow the 4-pole wiring diagram as
shown.
For replaces with the standard 1500W
heater, a 3 wire 120VAC line will be required.
A dedicated 20 Amp 3 wire circuit will be
required. Follow the 3-pole wiring diagram as
shown.
Figure 6: 3000W Wiring Diagram

8
Installation - Framing & Finishing
FrAmINg DImeNsIONs
mODel WIDTH DepTH HeIgHT
Ue44 44 5/16”
(1126mm)
11 7/8”
(302mm)
23 7/8”
(606mm)
Ue56 56 5/16”
(1430mm)
Ue68 68 5/16”
(1735mm)
Ue80 80 5/16”
(2040mm)
3 Side (Bay) Installation
1. Prepare the framed opening according to the chart above.
*Provide appropriate dedicated circuit for hard wire install at the
top right of framed opening.
2. Install the supplied mounting L-Brackets.
3. Install the replace in the framed opening using minimum 1 ¼” long
drywall screws to secure the unit.
4. Mask o / cover the replace during the nishing process. Install
desired nishing material to the nishing edges on the perimeter of the
rebox. For more information on the location of the nishing edges see
page 4.
5. Install the rebox media and/or log set of choice (not included with
the replace) following the instructions supplied with the media.
6. Install the side and front glass pieces according to the instructions
on page 12.
Figure 7: Framing Dimensions
Figure 8: Typical Bay Fireplace Framing
Figure 9: Bay Fireplace Installed
Figure 10: Bay Fireplace Finished

9
Installation - Framing & Finishing
2 Side (Left/ Right Corner) Installation
1. Follow steps 1 & 2 from the 3 sided installation
instructions.
2. Remove the corresponding nishing edges
according to your chosen installation (in the gure
shown, the nishing edges on the left side would be
removed.)
3. Install the side glass corresponding to your
installation.
Note - the side glass must be installed before
the metal side cover. See instructions on Page 12.
4. Install the supplied side cover over top of the side
glass using the same screw locations and fasteners
used by the removed nishing edge.
5. Install the replace in the framed opening using
minimum 1 ¼” long drywall screws to secure the
unit.
6. Mask o / cover the replace during the nishing
process. Install the desired nishing material to the
nishing edges on the perimeter of the rebox. For
more information on the location of the nishing
edges see page 4.
7. Install the rebox media and/or log set of choice
(not included with the replace) following the
instructions supplied with the media.
8. Install the remaining side and front glass pieces
following the instructions on page 12.
Figure 11: Typical Corner Fireplace Framing
Figure 12: Corner Fireplace Finished

10
Flush (Linear) Installation
Installation - Framing & Finishing
1. Follow steps 1 & 2 from the 3 sided installation
instructions.
2. Remove the nishing edges on both sides of
the replace.
3. Install the side glass on both sides of the
replace.
Note - the side glass must be installed
before the metal side cover. See instructions
on page 12.
4. Install the supplied side covers over top of the
side glass using the same screw locations and
fasteners used by the removed nishing edges.
5. Install the replace in the framed opening using
minimum 1 ¼” long drywall screws to secure the
unit.
6. Mask o / cover the replace during the nishing
process. Install desired nishing material to the
nishing edges on the perimeter of the rebox. For
more information on the location of the nishing
edges see page 4.
7. Install the rebox media and/or log set of choice
(not included with the replace) following the
instructions supplied with the media.
8. Install the front glass piece following the
instructions on page 12.
Figure 13: Typical Linear Fireplace Framing
Figure 14: Linear Fireplace Finished

11
Installation - Framing & Finishing
Partial Recess Installation
This installation style is optimized for 2x4 framed
walls.
1. Prepare the framed opening following the
required width and height of the selected model in
the table on page 8.
*Provide appropriate dedicated circuit for hard
wire install at the top right of framed opening.
2. Install the supplied mounting L-Brackets.
3. Install the replace in the framed opening using
minimum 1 ¼” long drywall screws to secure the
unit.
4. The replace must be covered with a
nishing material. Non-combustible material is not
required. Mask o / cover the replace during the
nishing process. Install the desired nishing material
to the nishing edges on the perimeter of the rebox.
For more information on the location of the nishing
edges see page 4.
5. Install the rebox media and/or log set of choice
(not included with replace) following the instructions
supplied with media.
6. Install the side and front glass pieces according to
the instructions on page 12.
Figure 15: Typical Recess Framing
Figure 16: Fireplace Installed in Recess
Figure 17: Partial Recess Finished

12
Installation - Front & Side Glass
Side Glass Installation
The replace has a top and bottom channel on each side to hold the side glass in place.
1. Insert side glass at an angle into the top channel
2. Swing the bottom edge of the side glass into the rebox
3. Slide the side glass down into the bottom channel
4. Push the side glass back until it stops.
Front Glass Installation
The replace has a bottom channel and a top retainer to hold the front glass in place.
1. Insert the front glass at an angle into the bottom channel (see gure 20).
2. Stand the front glass up straight until it touches the front of the replace
3. Install the top retainer bracket using a Phillips head screwdriver
Figure 18: Side Glass - Step 1 Figure 19: Side Glass - Step 2
Figure 20: Front Glass - Step 1 Figure 21: Front Glass - Step 2

13
Operation - Manual Controls
For manual control of the replace there is a control panel located just above the front glass at the top right
hand side. The control panel consists of 3 black buttons which are Power, Heat and Colour from left to right. To
the right of the Colour button is the Reset button.
Power - Press to turn replace on and o
Heater - Press once to turn the replace heater on low. Press twice to turn the heater up to high. Press button
again to turn heater o.
Colour - Pressing the colour button will cycle the replace through 7 preset coloured replace schemes.
Reset - Clears the replace memory of any paired remotes. Insert a paper clip or stick pin into the pin hole
and hold for 3 seconds until a “beep” is heard. The replace is now ready to pair to a new remote. See Remote
Controls section of manual for pairing instructions.
The replace is turned on. The heater is currently turned o.
The replace is turned on. The heater is currently turned on low.
The replace is turned on. The heater is currently turned on high.
Indicator Lights: Hidden behind the rear ame panel of the replace, in the upper right corner, are a set of
indicator lights that illuminate momentarily when the replace is turned on to identify the status of replace:
A
BB
C
D
EF
Figure 22: Control Panel Location Figure 23: Control Panel
Figure 24: Indicator Light Scenarios
Fireplace is disconnected from Wi-Fi, check wireless network
status. See Wi-Fi Controls section of manual for more information.
Continuous Blinking

14
Operation - Remote Controls
The replace may also be controlled using the supplied remote. The remote control is capable of making many
replace setting adjustments that are not possible with the manual controls. To use the remote it must rst be
paired to the replace.
Pairing the Remote to the replace:
1. Manually turn the replace on by pressing the POWER button on the control panel
2. Press the power button again and hold it down for 3 seconds until three “beeps” are heard. The rst orange
indicator light should now be ashing.
3. Within 5 seconds, repeatedly press the power button on the remote until a “beep” is heard and the orange
indicator light has stopped ashing. Pairing must be done within 5 seconds of hearing the two “beeps” or else
the replace will exit pairing mode.
Remote Control Layout
POWER - Turns replace on and
o. When turned on the replace
will return to its last used settings
when it was turned o.
RESET - Returns replace to
signature Uptown Fireplace
colour scheme.
COLOUR WHEEL - Slide
your nger/thumb around
the colour wheel to set the
desired colour of the selected
replace zone.
HEATER - Cycles the replace
heater between low, high and
o. Set as desired.
FADE - All zones of the replace
will cycle through various demo
modes - 7 & 3 colour gradient/
fade, 7 & 3 colour jump, red/
green/blue gradient.
SYNC - Pressing the sync button
will change all the colours of the
replace (Flame, Ember Bed and
Top Light) to match the current
colour of the ame setting.
FLAME - This is a zone
setting. Touching this button
will allow you to change the
colour and brightness of the
ame by using the colour
wheel and brightness slider.
EMBER BED - This is a zone
setting that controls the color
and brightness of the ember
bed.
TOP LIGHT - This is a zone
setting that controls the
colour and brightness of the
top light.
BRIGHTNESS SLIDER -
Slide your nger/thumb up
and down the white bar in
between the buttons below
the colour wheel to control
brightness of the selected
zone.
Figure 25: Remote Control
Figure 27: Add Device

15
Operation - Wi-Fi Controls
This replace is also capable of being controlled over Wi-Fi using an
Apple or Android mobile device. Scan the QR code for an instructional
walk through video on how to download and setup the app needed
to control your Uptown Electric replace. Alternatively, you can follow
the steps below.
1. Download the app Smart
Life - Smart Living, from either
the Apple App Store or Google
Play Store, and create a new user
account.
3. Navigate to the Home
screen in the app and press
the Add Device button.
4. On the Add Device screen
select the Small Home
Appliances category then
pick Electric Fireplace
(Wi-Fi).
2. Turn on the replace using either
the control panel or remote control. Figure 26: Setup Video QR Code
Figure 27: Add Device
Figure 28: Appliance Selection

16
Operation - Wi-Fi Controls
5. Next you will be prompted to connect to
your existing home wireless network. Select
the appropriate 2.4Ghz network and log in.
Note - Only 2.4GHz wireless networks are
compatible, 5GHz wireless networks cannot be
used. If not available, contact your wireless
service provider for further information on
setting up a 2.4GHz wireless network.
6. Once you are connected to your home
network put the replace into pairing mode.
Press and hold the COLOUR button on the
control panel (see page 13) of the replace until
the back ame and ember bed begin ashing at
the same time.
7. With the replace now in pairing mode select
the Blink Quickly option on the Reset the
Device screen in the app (see gure 30). The
app will begin pairing to the replace on a timing
screen and automatically nish once pairing is
successful (see gure 31).
Figure 29: Network Connection
Figure 30: Fireplace Pairing
Figure 31: Fireplace Successfully Paired

17
Operation - Wi-Fi Controls
8. With the replace now successfully paired
it can be controlled in the same manner as
the remote controls (see page 14). Added
capabilities like Sleep Timer and Heat Program
are only possible when using the app.
Zone Controls
Colour Wheel
Brightness Slider
Sync
Heater
Power Preset
colour
schemes
Sleep
Timer Settings
& Heat
Program
Creating a Heat Program
In the My Ambiance screen select the Heat
Program option. This feature is a 7-day program
that allows you to pick what time of day you
would like the replace and heater to turn on and
o.
1. Select the desired day of the week and time
slot. In the example below a program has been
selected for Wednesdays from 1:00PM-6:00PM.
Figure 32: Fireplace App Controls
Figure 33: Heat Program - Step 1
Figure 34: Heat Program - Step 2

18
Operation - Wi-Fi Controls
2. Next, in the pop-up window select the desired
program settings:
Switch - Turn replace on or o
Gear - Turn heater on low, high, o
Temperature - Set desired temperature
3. The Heat Program is now set to turn the
replace and heater on at 1:00PM every
Wednesday to maintain a temperature of 20˚C until
6:00PM.
Figure 35: Heat Program - Step 3 Figure 36: Heat Program - Step 4

19
Wiring Diagram
1
2
WIFI
Ember
Motor Flame
Motor
Optional
Top Light
Ember Bed
Light
Flame Light
Cleaning & Maintenance
On a semi-annual basis disconnect the replace from main power, wait for the heating element to cool
and dust the replace with a dry cloth. Be careful not to brush any wires that may be exposed.
• To clean the glass of the replace simply use any household desired glass cleaner with paper towels.
• To clean the air inlets/outlets, wipe with a soft cloth or the nozzle of a vacuum cleaner
• Dust can easily build up around the heater area inside the replace, on the left and right sides. Take
particular care to clean this area on a regular basis to prevent buildup.
• For long periods of inactivity, unplug the replace and ensure the surrounding area remains dry.
Figure 37: Wiring Diagram

20
Troubleshooting
Problem Possible Cause Solution
Fireplace will
not turn on
Tripped circuit breaker, circuit
has no power
· Reset breaker. Test circuit for incoming power
Fireplace needs to be reset · Turn o main power breaker to replace for 60 seconds, then turn back on
Loose connection
· Disconnect replace from power and inspect for any loose or damaged wire
connections
Defective component · Contact your Uptown Fireplace dealer
Fireplace turns
o and will not
turn back on
Fireplace has overheated and
tripped the safety circuit
· Turn o main power breaker to replace for 60 seconds, then turn back on
Can operate
replace
with manual
controls but
not remote
Low battery
· Replace the battery in the remote using a small pin or paperclip. Required
battery is a CR2032
Remote not paired correctly to
replace · Follow remote pairing procedure on page 15. Remote must be paired to the replace within 5 seconds
Defective Remote Control
· Replace the remote control. Contact your Uptown Fireplace dealer
No heat from
heater when
turned on
Loose connection · Disconnect replace from power and inspect heater for any loose connections
Safety circuit tripped · Turn o the heater for 5 minutes to reset
Defective heater · Replace the heater. Contact your Uptown Fireplace dealer
Fireplace turns
on with no
ame
Loose connection
· Disconnect replace from power and inspect for any loose or damaged wire
connections
Defective component · Contact your Uptown Fireplace dealer
Fireplace turns
on with frozen/
still ame
Loose connection
· Disconnect replace from power and inspect spindle motor for any loose
connections
Spindle rod is jammed or has
come loose
· Inspect the spindle rod to conrm it is still attached to the spindle motor.
· Inspect the spindle rod for any interferences that may be jamming the
spindle rod.
Defective spindle motor · Replace the spindle motor. Contact your Uptown Fireplace dealer
Fireplace is
making a
squeaking
sound
Spindle rod interference
· Inspect the spindle rod for any interferences that may be causing the sound
· Apply a small of grease to the spindle rod connection points
Defective spindle motor · Replace the spindle motor. Contact your Uptown Fireplace dealer
