SHINOLA BLUETOOTH IN-EAR MONITORS User manual

MANUAL:
SHINOLA BLUETOOTH
IN-EAR MONITORS

TABLE OF CONTENTS
TECHNICAL SPECIFICATIONS
3
FULL BUTTON INTERFACE
5
PAIRING YOUR DEVICE
FOR THE FIRST TIME
7
OPERATION
9
CHARGING
10
ERASE PAIRED DEVICE LIST
11
INTENDED USE
11
AVOID HEARING DAMAGE
12
DECLARATION NOTICE
12
DECLARATION OF CONFORMITY
13
BATTERY SAFETY
13
DISPOSAL
14
COMPLIANCE WITH FCC RULES
15
WARNING
15
NOTE
16

3
TRANSDUCER TYPE:
8.5 MM
FREQUENCY RESPONSE:
10HZ - 20KHZ
TOTAL HARMONIC DISTORTION:
< 1%
IMPEDANCE:
16.5 Ω@ 1KHZ
SOUND PRESSURE LEVEL:
102 DB
TECHNICAL SPECIFICATIONS

4
TECHNICAL SPECIFICATIONS
BLUETOOTH:
Bluetooth® 4.2 with AAC, AptX
and AptX-HD Support
PLAYBACK:
12 Hours Of Music Playing Time
CHARGING:
Fast Charging via USB-C
(USB-A to USB-C Cable Included)

5
FULL BUTTON INTERFACE
VOLUME DOWN VOLUME UP
USB CHARGING
MULTI-FUNCTION (MF)

6
FULL BUTTON INTERFACE
1X ANSWER/HANG UP
PRESS AND HOLD TO REJECT
1X PLAY/PAUSE
2X SKIP FORWARD
3X SKIP BACKWARD
PRESS AND HOLD FOR ON/OFF
PRESS AND HOLD FOR
4-5 SECONDS TO PAIR/OFF
VOLUME UP:
PRESS/HOLD FOR MAX VOLUME
VOLUME DOWN:
PRESS/HOLD FOR MUTE

7
PAIRING YOUR DEVICE
FOR THE FIRST TIME
TURN ON DISCOVERABLE MODE
(FROM OFF STATE)
1. Press and hold the MF button for 4-5 seconds until the LED
quickly flashes white. If the LED quickly flashes orange, the
battery is low.
2. Go to the “Bluetooth Devices” list on the music source and
select “Shinola Bluetooth IEM.” Listen for the audible tone to
ensure the music source has successfully paired with the tether.

8
TURN BLUETOOTH IEM ON
1. Press and hold the MF button until the LED turns white, then
continue holding for 2 seconds. If the LED turns orange, the
battery is low.
NOTE: the tether will pair to a recently connected device if
Bluetooth® settings haven’t changed.
TURN BLUETOOTH IEM OFF
1. Press and hold the MF button for 4-5 seconds until the LED
flashes twice and turns off.
PAIRING YOUR DEVICE
FOR THE FIRST TIME

9
OPERATION
1. Find the “L” and “R” markers on the ends of the In-Ear
Monitor cable.
2. Select the right sized eartips for your ears, as a proper
seal is critical to ensure a quality listening experience.
Choose from the included selection of memory foam
and silicone eartips. Gently pull the eartip off the metal
spout to remove it, then push/twist the other eartip to
install.
A. Memory foam eartips: compress the memory foam with
your fingers and place the foam portion of the In-Ear
Monitor in your ear, holding it in place for 10 seconds to
ensure the memory foam creates a proper seal.
B. Silicone eartips: insert the silicone portion of the
In-Ear Monitor in your ear; the seal should be immediate.

10
3. To ensure safe listening levels, do not place In-Ear Monitors
in your ears until after they are producing sound.
OPERATION
CHARGING
1. The LED will flash orange when the battery is low. To
charge the tether, plug the charging cable into the USB-C
charging port and then attach the other end to a power
source. The tether LED will show solid orange when
charging and solid white when fully charged.

11
ERASE PAIRED DEVICE LIST
1. In Discoverable Mode, hold Vol + and Vol - button for 5-6
seconds until the LED flashes white four times.
INTENDED USE
Office and Home Usage
Shinola Detroit, LLC accepts no liability whatsoever for any
damage to this product or injuries caused due to careless,
improper or incorrect use of the product or use of the product
for purposes not recommended by the manufacturer.

12
AVOID HEARING DAMAGE
PLEASE NOTE: Listening to audio for extended periods at loud
volume levels may cause permanent hearing damage, so check
the volume level that has been set on the volume control each
time before using the product, and avoid listening to audio at a
high volume level.
DECLARATION NOTICE
Operation of the device may be affected by strong static,
electrical or high-frequency (radio installations, mobile
telephones, microwaves, electrostatic discharges). If this
occurs, try increasing the distance from the devices causing
the interference.

13
DECLARATION OF CONFORMITY
Shinola Detroit, LLC herby declares that this product conforms
to the relevant safety regulations of EU Directive 2014/53/EU.
BATTERY SAFETY
This product is fitted with a lithium polymer battery. Do not
damage, open or dismantle the battery and do not use it in damp
and/or corrosive conditions. Only use compatible chargers.
Never dispose of batteries in a fire and never expose them to
high temperatures. Do not expose the product to temperatures
exceeding 60ºC (140ºF).

14
DISPOSAL
The crossed-out wheelie-bin symbol means that you may not dispose
of this product together with general household waste; instead, take
it to a recycling point for electrical and electronic equipment. For
information about local recycling points, contact your local authority,
civic amenity site or the business where you purchased this product.
The separate collection and recycling of use items and electrical and
electronic equipment prevents any harmful substance they contain
from harming human health and polluting the environment. Please
keep this information for later reference.

15
COMPLIANCE WITH FCC RULES
This device complies with Part 15 for the FCC rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
WARNING
Changes or modifications to this unit not expressly approved
by the party responsible for compliance could avoid the user’s
authority to operate the equipment.

16
NOTE
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
