3SIXT 3S-0777 User manual
USER GUIDE
BLUETOOTH®
STUDIO EARBUDS
3S-0777
For more information visit
www.3sixtgear.com/support
Siri is a trademark of Apple Inc., registered in the U.S. and other countries.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by 3SIXT is under license.
TECHNICAL SPECIFICATIONS
Bluetooth Version 4.1 +EDR
Bluetooth Profile A2DP, AVRCP, HFP, HSP
Chipset CSR8645
Audio Codec APT-X
Noise Reduction CVC 6.0
Bluetooth Range 10 metres
Music Playback 5 hours
Talk Time 5.5 hours
Standby Time 180 hours
Charging Time 2 hours
Dimensions 36 x 30 x 45 mm
Weight 16g
SAFE USE WARNING
Due to the isolating characteristics of these
Bluetooth Studio Earbuds do not use while driving,
riding a bike or where vehicular traffic is present, or in any
other activity where failure to hear surrounding sounds could
be dangerous. Use of these Earbuds at excessive volumes may
cause permanent hearing damage. Always turn the volume
down before use. Take caution in regards to inserting objects
into ear canal and use at own risk.
GENERAL OPERATION
Power on Separate the two Earbud backs
Power off Join the two Earbud backs together
Pair Press the Multi-Function Button (MFB) a
for
5 seconds (when ‘ON’)
Factory reset Press the MFB a
for 5 seconds (when charging)
LED INDICATOR & VOICE PROMPTS
Flashes blue twice Voice says
“Power On”
Bluetooth Studio Earbuds
are ‘ON’
Flashes red for 2
seconds
Voice says
“Power Off”
Bluetooth Studio Earbuds
are ‘OFF’
Flashes between blue
and red
Voice says
“Pairing”
Bluetooth Studio Earbuds
are in ‘pairing mode’
Flashes between blue
and red 3 times -Bluetooth Studio Earbuds
are in ‘factory reset’
Flashes blue every
7 seconds -
Bluetooth Studio Earbuds are
in ‘standby mode’ (not playing
music or not in a call)
MUSIC/CALL OPERATION
Play/Pause Press the MFB a
once to ‘pause’,
press once again to resume playing
Volume Up Short press “+” b
when playing music
Next Song Long press “+” b
when playing music
Volume Down Short press “-” c
when playing music
Previous Song Long press “-” c
when playing music
Answer a call Press the MFB a
once to ‘answer’ an incoming call
End a call Press the MFB a
once to ‘end’ call
Reject a call Press the MFB a
once for 1 second to ‘reject’
an incoming call
Transfer between
Earbuds and Phone During a call, press the MFB a
for 1 second
Redial last
outgoing call Press the MFB a
twice while in music playback
or ‘standby mode’
Mute Press the MFB a
twice during a call
Activate voice
control (e.g.. Siri) Press the MFB a
for 1 second while in music
playback or ‘standby mode’
!
3SIXT Bluetooth Studio Earbuds support multi-point technology,
which allows you to connect them to two different Bluetooth
enabled devices simultaneously.
1. Follow the initial pairing instructions previously outlined on
the first device you would like to pair - ‘Device 1’.
2. Turn off the Bluetooth Studio Earbuds. Now follow the
pairing instructions to connect the Earbuds to the second
device - ‘Device 2’.
3. Select ‘3SIXT-M777’ from the Bluetooth device list on
‘Device 1’ to finish the multi-point connection.
If ‘Device 1‘ is on a call, and a call comes in on ‘Device 2’, press
the Multi-Function Button (
a
) to answer the ‘Device 2’ call and
put the ‘Device 1‘ on hold. You can switch between the two calls
by double pressing the MFB (
a
).
PAIRING TO MULTIPLE DEVICES
3. ‘3SIXT-M777’ should
then appear on the
Bluetooth device list on
your smartphone, tablet
or computer. Press/click it
and the Voice Prompt will
say “Phone X connected”
when pairing has been
achieved.
For more information and support visit www.3sixtgear.com/support
READ FIRST SAFETY & CARE
INFORMATION
• Use 3SIXT Bluetooth Studio Earbuds for its intended purpose
only. It is not a toy. Parental supervision is required for
children under 10 years old.
• Avoid excessive volume levels and prolonged periods of
listening. Do not use around road traffic.
• Do not drop, knock, disassemble or attempt to repair 3SIXT
Bluetooth Studio Earbuds.
• Do not immerse or put 3SIXT Bluetooth Studio Earbuds in
water and keep 3SIXT Bluetooth Studio Earbuds in a cool, dry
place and protect from dust.
• Do not expose 3SIXT Bluetooth Studio Earbuds to excessive
heat including sunlight and fire. Do not burn or incinerate
3SIXT Bluetooth Studio Earbuds or expose to extreme
temperatures (<0° or >45°).
• Wipe 3SIXT Bluetooth Studio Earbuds with a clean soft cloth.
Do not use chemicals or detergents to clean any part of 3SIXT
Bluetooth Studio Earbuds. Doing so may discolour or corrode
the materials.
1. Insert the supplied Micro USB Cable (
5
) (Micro USB end)
into Bluetooth Studio Earbuds 5V input port (
3
).
2. Insert USB end of cable into the USB 2.0 port of
your 110/240V wall adaptor, laptop or PC.
3. The LED Indicator (
d
) will turn red when
charging, then blue when fully charged.
The indicator light will flash red when the battery level
is low, and there will be a voice prompt.
If left unused for 3 months, a fully charged battery will
lose its charge.
1. Ensure your Bluetooth Studio Earbuds are fully charged
and separate the Bud Backs from each other to enter
‘standby/’ON’ mode’. The Voice Prompt will say “Power On”.
2. Once ‘ON’, press the Multi-Function Button (MFB) (
a
)
for 5 seconds to put the Bluetooth Studio Earbuds into
‘pairing mode’ with your device. ‘Pairing mode’ is evident
if the LED Indicator (
d
) flashes red then blue - the Voice
Prompt will say “Pairing”.
Within operating range (up to 10m), the Bluetooth
Studio Earbuds will automatically pair to your device
when Bluetooth is enabled and the Earbuds are separated
(‘ON’ position). This will be confirmed by the Voice Prompt
saying “Phone X connected”.
If the 3SIXT Bluetooth Studio Earbuds are left separated
for over 3 minutes without music playback or calls, it will
enter ‘standby mode’ to save battery life. In ‘standby mode’
you can make and receive calls or reinstate music playback
by pressing the MFB for the required operation (see Music/
Call Operation table). Disconnect the Earbuds from your device
to return your device to normal functionailty.
GETTING TO KNOW YOUR
BLUETOOTH STUDIO EARBUDS
CHARGING YOUR
BLUETOOTH STUDIO EARBUDS
TURNING ON & PAIRING YOUR
BLUETOOTH STUDIO EARBUDS
for the first time
PAIRING YOUR BLUETOOTH
STUDIO EARBUDS every time aer
STANDBY MODE
b
c
e f
d
a
Gel Ear Clips
Earbuds
Controller
Volume up
Multi-Function
Button (MFB)
LED
indicator
Volume down
1
4
5
2
SMALL
LARGE
Ear Clips
SMALL ON DEVICE
Gel Earbuds
MEDIUM ON DEVICE
MEDIUM
(L & R)
LARGE
(L & R)
USB Charging
Port (under Ear Clip)
3
Micro USB
Charging
Cable
3. ‘3SIXT-M777’ should
then appear on the
Bluetooth device list on
your smartphone, tablet
or computer. Press/click it
and the Voice Prompt will
say “Phone X connected”
when pairing has been
achieved.
For more information and support visit www.3sixtgear.com/support
