SHINOLA CANFIELD User manual

English
Français
Português
Italiano
Deutsch
Español
02
12
24
34
46
58
THE CANFIELD HEADPHONES
TECHNICAL SPECIFICATIONS
SAFETY INFORMATION
OPERATION
CARE
WARRANTY

2
TRANSDUCER TYPE:
40MM DYNAMIC TRANSDUCER
HEADPHONE STYLE:
CLOSED-BACK, SUPRA-AURAL
EAR CUSHION
FREQUENCY RESPONSE:
20 - 20,000 HZ
NOMINAL IMPEDANCE:
32Ω
SOUND PRESSURE LEVEL:
105 DB ±3DB/MW @ 1KHZ
TOTAL HARMONIC DISTORTION:
2% THD @ 1KHZ
THE CANFIELD ON-EAR HEADPHONES
TECHNICAL SPECIFICATIONS
EFFICIENCY:
120 DB SPL/V @1KHZ
WEIGHT (WITHOUT CABLE):
0.73 LBS
DIMENSIONS:
6.9 X 7.5 X 1.4 IN

3
TRANSDUCER TYPE:
50MM DYNAMIC TRANSDUCER
HEADPHONE STYLE:
CLOSED-BACK,
CIRCUMAURAL EAR CUSHION
FREQUENCY RESPONSE:
20 - 24,000 HZ
NOMINAL IMPEDANCE:
41Ω
SOUND PRESSURE LEVEL:
102 DB ±3DB/MW @ 1KHZ
TOTAL HARMONIC DISTORTION:
1% THD @ 1KHZ
THE CANFIELD OVER-EAR HEADPHONES
TECHNICAL SPECIFICATIONS
EFFICIENCY:
115 DB SPL/V @1KHZ
WEIGHT (WITHOUT CABLE):
0.99 LBS
DIMENSIONS:
6.9 X 8.3 X 1.7 IN

4
SAFETY INFORMATION
• Read instructions carefully.
• Do not use an obviously defect product.
• Keep a specified distance from a pacemaker.
• Keep out of reach of children and pets.
• Do not let children under 3 handle the product.
• Do not use while driving.
• Do not use while in an environment that requires your special
attention, crossing streets, etc.
• Always keep the product dry.
• Don’t expose to high heat.
• Link to the Consumer Electronics Association for safety for listening:
www.ce.org
• Don’t use if they emit loud or unusual noise.
• Remove headphones if you notice any warming sensation or loss of audio.
SAFETY NOTE ABOUT LISTENING LEVELS:
To protect your hearing, the headphones should always be used at as low a
volume as possible. We recommend that you strictly follow the guidelines
established by the U.S. Occupational Safety Health Administration (OSHA)
regarding maximum time exposure at various sound pressure levels (SPL):
• Don’t use this product for more than 8 hours at 90 dB SPL
• Don’t use this product for more than 4 hours at 95 dB SPL
• Don’t use this product for more than 2 hours at 100 dB SPL
• Don’t use this product for more than 1 hour at 105 dB SPL
• Don’t use this product for more than 1/2 hour at 110 dB SPL
• Don’t use this product for more than 15 minutes at 115 dB SPL
• Don’t operate at listening levels of greater than 120 dB SPL

5
IMPORTANT NOTE!
Pay close attention to what your ears may be telling you. Ringing is a sign
that gain levels are set too high and damage could result. We recommend
that you consult with a qualified audiologist if you exhibit ringing or any
other symptoms.
OPERATION
1. Find the “L” and “R” descriptors on the headphone cable ends.
2. Connect the appropriately matched cable end to the left and right
sides of the headphone. The headphone left and right-side descriptors
can be found on the inside of the headband.
3. Plug the other end of the cable into your device.
4. Do not place headphones on your head until after they are making
sound to ensure safe listening levels.
5. Mic and Remote Operation
a. The microphone is separated from the remote to provide better
vocal clarity and an easier-to-use remote.
b. Remote functions are for use with Apple products.
+ : VOLUME UP
S E L E C T :
1. Press 1x to answer a call or to hang up.
2. Press 1x to play or pause audio.
3. Quickly press 2x to skip forward.
4. Quickly press 3x to skip backward.
- : VOLUME DOWN
