SHIWAKOTO SH-DVP23 MAX User manual

INSTRUCTION MANUAL
DVD PLAYER
MODEL: SH-DVP23 MAX
HDMI
Connect
RCA/AV
Connect

2
TECHNICAL DATA
MODEL NO: SH-DVP23 MAX
POWER
INPUT: 110-240V ~50 / 60HZ
WATTAGE: 15W
DECLARATION OF CONFORMITY
We declare that this product conforms to the following product legislation in accordance
with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive
2009/125/EC Eco-Design of Energy Related Products.
2014/53/EU Radio Equipment Directive.
RKW Quality Assurance.
GUARANTEE
This product is guaranteed for 6 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer If its pasted Amazon’s
date.
The following conditions apply:
The product must be returned to the
retailer with the proof of purchase.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and
tear, damage, misuse or consumable
parts.
PFD has limited responsibility for
incidental or consequential loss or
damage.
Valid in North American only.

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the appliance for
future reference. These warnings have been provided in the interest of safety. You
MUST read them carefully before installation or use.
WARNING
• Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
• Please ensure that the appliance
is used on a stable, level, and heat
resistant surface.
• Do not immerse cords, plugs or
any part of the appliance in water
or any other liquid.
• Do not leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by or
near children or pets.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch off at the wall socket then
remove the plug from the socket
when not in use or before cleaning.
• If the supply cord or appliance is
damaged, stop using the appliance
immediately and seek advice from
the manufacturer or its service
agent or a similarly qualified
person.
• Do not let the cord hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
• The use of accessory attachments
is not recommended by the
appliance manufacturer, apart
from those supplied with this
product.
• Do not pull the plug out by the cord
as this may damage the plug and/
or the cable.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household use
only.
• Do not carry the appliance by the
power cord.
• Do not use the appliance outdoors.
3

IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
• Do not block any ventilation
openings & Install in accordance
with the manufacturer’s
instructions.
• Do not install near any heat
sources such as radiators,heat
registers,stoves,or other
apparatus(including amplifiers)
that produce heat.
• Unplug this apparatus during
lightning storms or when unused
for long periods of time.
• Battery usage CAUTION. To prevent
battery leakage which may result
in bodily injury or damage to the
unit:
• Install all batteries correctly,
+and -as marked on the unit.
• Do not mix batteries(old and new
or carbon and alkaline, etc.)
• Remove batteries when the unit
is not used for a long time.
• If the appliance is not going to be
used for a period of time please
ensure that it is fully disconnected,
from the mains power.
Battery installation (for the remote
control)
• Open the Battery cover on the
underside of the unit.
• Insert 2”AAA”1.5V batteries (not
included) following the polarity
as indicated in the compartment.
Alkaline batteries are
recommended for long using time.
4
• Press the battery cover back to
close until it is tight.
• In the unlikely event the appliance
develops a fault, stop using
it immediately and seek advice
from the service department:
[email protected]
Class 1 Laser Product
Luokan 1 Laserait
Klasse 1 Laser Apparat
Laser Klasse 1

FEATURES AND CONTROLS
FRONT PANEL
1. CD TRAY
2. INFRARED RECEIVER WINDOW
3. OPEN/CLOSE BUTTON
4. USB PORT
5. PLAY/PAUSE BUTTON
6. POWER BUTTON
7. SD Card Reader
REMOTE CONTROL
5
1. POWER
21.
SLOW
2. 0-9, 10+
22.
ANGLE
NUMBERS
23.
SUBTITLE
3. SETUP
24.
LANG
4. UP
25.
MUTE
5. LEFT
26.
VOL +
6. DOWN
27.
VOL -
7. TITLE
28.
ENTER
8. PLAY
29.
PAUSE
9. L/R
30.
SEARCH
10. STOP
31.
MENU
11. PBC
32.
ZOOM
12. DVD/USB
33.
DISPLAY
13. REPEAT
14. A-B
15. REV
16. FWD
17. PREV
18. NEXT
19. OPEN/CLOSE
20. RETURN

USING YOUR APPLIANCE
REMOTE CONTROL SETUP:
• Remove the battery cover on the back
of the remote control and insert 2 X
AAA batteries (not supplied) and then
close the cover.
• When using the remote control,
please point the remitting port (at
the top of the remote control) directly
at the receiver window on the DVD
player.
• If the remote control will only function
a short distance from the DVD player,
replace the batteries. Always replace
both batteries at once.
• Check the batteries regularly. Any
leakage can damage the remote
control.
REMOTE CONTROL:
• POWER – Press turn to it on.
• NUMBER BUTTONS: Use for entering
numbers to choose DVD chapters, set
the time etc.
• SETUP: Press to enter the Setup
menu.
• UP: Press to move up through a step.
• LEFT: Press to move back a previous
step.
• DOWN: Press to move down a step.
• TITLE: Press to open the selection
menu of the DVD disc. Use the UP/
DOWN/LEFT/RIGHT arrow buttons
to move through the menu. Press
ENTER to confirm your selection.
• PLAY: Press to play a disc.
• L/R: For use with VCDs or DVCDs.
Press to select left/right/stereo etc.
For multi-output modes, press this
button to switch between channels.
• STOP: Press to stop the playback.
• REPEAT: Press repeat when watching
a DVD to repeat the chapter, repeat
the title or turn off repeat.
• A-B: Press the A-B button at the point
where you want to begin repeat play,
and then press again at the point
where you want to stop repeat play.
The selected section will be repeated
until you press clear.
• REV: Press to rewind quickly.
• FWD: Press to fast forward quickly.
• SKIP BACKWARD: Press to skip to the
previous chapter or track.
• SKIP FORWARD: Press to skip to the
next chapter or track.
• OPEN/CLOSE: Press once to eject the
disc tray. Press again to close the disc
tray.
• AUDIO: Select the right or left output
option.
• ANGLE: Some discs have multiple
angle options. Press the angle button
repeatedly to cycle through different
camera angles.
• SUBTITLE: If the disc is equipped with
subtitles, press this button repeatedly
to select a subtitle language, or to
turn off the subtitles.
• ZOOM: Press “ZOOM” Key to zoom in or
zoom out the movie or picture you wish to
view at a different size. The first four
presses will be to “zoom in”, then the
coming four presses are to “zoom out”,
then the last press you will get the normal
size picture back.
6

RCA/AV Connection Video
Guide
Link below
https://youtu.be/Fz5DyxrrKjI
• RIGHT: Press to navigate right
between menu options.
• OK: Press to confirm a selection.
• MENU: Press to return to the main
menu of a disc or DVD.
• PAUSE: Press the pause playback.
• VOL +: Press to increase the volume.
• MUTE: Press to mute the sound.
• VOL -: Press to decrease the volume.
• SLOW: Press to play disc is slow
motion, without sound. Press again to
turn off the slow motion.
• RETURN: For any discs that are not
DVDs, press to return to the track list
menu during playback.
• DVD/USB: Use to toggle between DVD
and USB options.
• PBC: Press to return to the PBC
menu.
INSTALLATION:
Select a stable, flat surface to the side or
near a TV set to install the DVD player.
Do not install on top of a TV or monitor.
Do not block the vents by placing the DVD
player directly on to carpet, a bed, a sofa
or by covering it with a cloth.
Do not place any objects on top of the DVD
player.
Do not move the DVD player during
playback.
Do not install the DVD player and speaker
system in any place that is:
• Exposed to direct sunlight
• Extremely hot or cold
• Poorly ventilated or exposed to
humidity
• Exposed to dust
• Exposed to smoke, steam or heat
(such as a kitchen or bathroom)
USING YOUR APPLIANCE:
Connecting with the HDMI lead ( included):
1. Connect the DVD player to your TV
using a HDMI CABLE.
2. Plug the DVD player in at the mains
and turn on using the Standby button.
3. Turn your TV on. If the TV does not
automatically show the DVD player
loading screen, use your television
remote to select the required input
channel. Alternatively, press the
source button on the DVD remote
repeatedly to enter AUX/Line mode,
indicated by a white light.
4. Use the eject button to eject the
loading tray in the DVD player and
insert a DVD. Close the loading tray.
7
HDMI Connection Video Guide
Link below
https://youtu.be/jX3pmDqzXuY

USING YOUR APPLIANCE
SETUP:
The following tables show the different on-
screen setup options.
1. Press set up key to access the set up
menu
2. Press direction key to an item, then
press select to confirm.
3. Press set up or return key to exit
setup menu.
USB
With the USB function, you can play video
files directly from a USB flash drive. Insert
the USB flash drive into the USB port and
press the DVD/USB button on the remote
control to select the USB function.
LANGUAGE:
DVD Menu
Language
Audio
Subtitles
MPEG 4 Subtitles
English
English
English
Western European
Spanish
Spanish
Spanish
Central European
Italian
Italian
Italian
Auto
Off
VIDEO :
Aspect Ratio
View Mode
TV System
Video Output
4:3
Fill
Pal
CVBS
16:9
Original
NTSC
RGB
Auto Fit
AUTO
Pan Scan
PARENTAL CONTROL:
Rating
1. Kid Safe
2. G
3. PG
4. PG-13
5. PG-R
6. R
7. NC-17
8. Adult
MISC:
Password
Screen Saver
Default Setting
Set Password
On
Select
8

TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
SOLUTION
Power connected but DVD
player does not work.
Plug not inserted correctly.
Connect the power supply again.
Disc inserted, but no tracks
and the play time shown on
the TV screen.
Disc inserted upside down, Disc
is dirty or cracked.
Correctly insert the disc, clean
or replace the disc.
No sound
The AV cable is not correctly
connected or is loose.
Reconnect the AV cable and
ensure the TV is on the correct
channel.
No picture.
The cables are not inserted
correctly.
Re-insert the cables, check
the SCART lead or AV cable is
connected correctly.
The remote control does not
work.
The battery does not have
enough power, the remote
controller is not correctly
pointed at the remote sensor or
the remote sensor is dirty.
Change the battery. Point the
remote controller directly at the
remote sensor, clean the surface
of the remote sensor.
During playing, the picture
stops moving, skips or the
sound is abnormal.
The disc is not in good condition
- cracked or dirty
The speaker is interfering with
DVD playback.
Clean or replace the disc, move
the speaker away from the
player.
NOTE:
1. In order to prolong the player life,
please restart the DVD player after 30
seconds when power off.
2. Please pull the plug out if the player is
not being used.
3. This player must be connected to a
matching rated voltage.
9

CLEANING & MAINTENANCE
DVD PLAYER:
Use a soft slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or
abrasives.
CLEANING DVDs:
When a disc becomes dirty, clean it with a
cleaning cloth. Wipe the disc from the centre out.
Do not use solvents such as benzene, thinner,
commercially available cleaners, or antistatic
spray intended for analogue records.
10

GLOSSARY OF TERMS
A-B Repeat: The A-B button on a remote
control, not to be confused
with the Repeat button.
Pressing the A-B button
allows you to manually
select a section to repeat.
AC IN: AC Input socket for AV
Cables
AV Cable: AV Cables are used to
transmit audio/visual
signals.
CVBS: Composite Video Blanking
and Sync. A type of video
signal which is mainly
analogue.
DVD: A compact disc that stores
large amounts of high-
resolution audio-visual
data.
DVCD: Double Video Compact Disc
- a type of VCD that holds
video and audio.
FPS: Frames per second.
L/R VIDEO
OUTPUT: Left and Right video
outputs for RCA Cable
input. Colour coded red
and white to match with
corresponding cable
connections.
NTSC: A television display system
used in the U.S and
Canada. Delivers a frame
rate of 30 fps using 525
lines.
OSD: On-screen Display. A
control panel that allows
you to select and edit the
display (such as brightness
and contrast) and select
viewing options.
PAL: A television display system
commonly used in Europe
and parts of Asia. Delivers
a frame rate of 25 fps with
625 lines.
PBC: Playback Control.
Ratings:
G Rating: Suitable for all audiences.
PG Rating: Parental guidance
suggested; some material
may not be suitable for
children.
PG-13 Rating: Parental guidance strongly
cautioned; some material
may be inappropriate for
children under 13.
R rating: Restricted; contains some
adult material, under 17’s
require an accompanying
parent or adult guardian.
NC-17: Adults only.
RCA Cable: A type of connector used to
transit audio/visual signals.
RGB: Video input in which red,
green and blue colour
information is transmitted
separately from the picture
information of an image.
A common Video Output
option.
SVCD: Super Video Compact
Disc – a digital format for
storing video on standard
compact discs.
SCART
OUTPUT: A 21 pin socket used to
connect video equipment.
SCART LEAD: Cable commonly used to
connect televisions and
DVD players, VCR or games
consoles.
USB: Universal Serial Bus. A
popular connection for
sharing and transferring
data from external devices.
USB PORT: A port to connect a USB
flash drive to.
VCD: Video Compact Disc,
designed to hold MPEG-1
video data and to include
interactive capabilities.
11

DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separatel
Need help?
For advice, spares and returns.
[email protected]
8.30am to 6.00pm Monday-Friday
Distributed throughout Amazon.com
SHIWAKOTO CUSTOMER SERVICES
[e-mail]
WARNING:
This appliance is double insulated.
Do not connect any wire to the earth terminal.
