Show Tec Mistique User manual

Mistique V2
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 60769
MANUAL
ENGLISH

1
Ordercode: 60769
Mistique
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
CO2Use...........................................................................................................................................................................5
Operating Determinations ..........................................................................................................................................6
Return Procedure..........................................................................................................................................................7
Claims..............................................................................................................................................................................7
Description of the device.................................................................................................................................................8
Frontside..........................................................................................................................................................................9
Backside .......................................................................................................................................................................10
Installation.........................................................................................................................................................................11
Setup and Operation ......................................................................................................................................................12
Remove cover and fan to change output direction ..........................................................................................12
Add hazer liquid to the tank.....................................................................................................................................13
Start-up..........................................................................................................................................................................14
Control Modes.............................................................................................................................................................16
One Mistique (Stand-alone) ..................................................................................................................................16
Multiple Mistiques (DMX Control)..........................................................................................................................16
Fixture Linking...............................................................................................................................................................17
Data Cabling...............................................................................................................................................................17
Control Panel ...............................................................................................................................................................18
Control Mode ..............................................................................................................................................................18
DMX Addressing ..........................................................................................................................................................18
Menu Overview...........................................................................................................................................................19
Main Menu Options....................................................................................................................................................23
Status Menu .................................................................................................................................................................24
1. Timer 1 .......................................................................................................................................................................25
1.1 Interval .................................................................................................................................................................25
1.2 Duration...............................................................................................................................................................26
1.3 Output Level.......................................................................................................................................................26
1.4 Fan Level .............................................................................................................................................................27
2. Timer 2 .......................................................................................................................................................................27
3. DMX Channel ..........................................................................................................................................................28
3.1 Address ................................................................................................................................................................28
3.2 Channel Mode...................................................................................................................................................29
3.3 Link Mode............................................................................................................................................................30
3.4 Wireless Mode ....................................................................................................................................................30
4. Power Off .................................................................................................................................................................31
5. Manual......................................................................................................................................................................31
5.1 Output Level.......................................................................................................................................................32
5.2 Fan Level .............................................................................................................................................................32
6. Clean ........................................................................................................................................................................33
7. Heater .......................................................................................................................................................................33
8. Menu .........................................................................................................................................................................35
8.1 DMX Setup ..........................................................................................................................................................35
8.1.1 Address.............................................................................................................................................................35
8.1.2 Channel Mode ...............................................................................................................................................36
8.1.3 Link Mode.........................................................................................................................................................37
8.1.4 Wireless Mode .................................................................................................................................................37
8.2 Information..........................................................................................................................................................38
8.2.1 Software Version.............................................................................................................................................38
8.2.2 Wireless Signal .................................................................................................................................................39
8.2.3 Temperature....................................................................................................................................................40
8.2.4 Pressure.............................................................................................................................................................40
8.2.5 Operating Hours .............................................................................................................................................41

2
Ordercode: 60769
Mistique
8.3 Setting ..................................................................................................................................................................41
8.3.1 LCD Backlight..................................................................................................................................................42
8.3.2 Auto Start .........................................................................................................................................................42
8.3.3 Factory Reset...................................................................................................................................................43
8.3.4 Language ........................................................................................................................................................44
8.3.5 Software Update ............................................................................................................................................45
8.3.6 Keypad Sound ................................................................................................................................................46
DMX Channels .............................................................................................................................................................47
1 channel ..................................................................................................................................................................47
3 channels .................................................................................................................................................................47
5 channels .................................................................................................................................................................47
Maintenance....................................................................................................................................................................48
Automatic Cleaning Procedure ..............................................................................................................................48
Automatic Protection Mechanism ..........................................................................................................................48
Fan Cleaning ...............................................................................................................................................................48
O-Ring Cleaning..........................................................................................................................................................49
Replacing a Fuse ........................................................................................................................................................49
Troubleshooting ...............................................................................................................................................................50
Message List of Errors..................................................................................................................................................50
Product Specifications....................................................................................................................................................51
Dimensions........................................................................................................................................................................52
Notes ..................................................................................................................................................................................53

3
Ordercode: 60769
Mistique
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Mistique
●True1 pro power cable (1,5 m)
●User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

4
Ordercode: 60769
Mistique
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Always disconnect power from the mains, when device is not used or before cleaning ! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
●Never remove warning or informative labels from the unit.
●Never use anything to cover the ground contact.
●Never aim the output nozzle directly at people.
●Never aim the output nozzle at open flames.
●Never add flammable liquids of any kind (oil, gas, perfume) to the haze liquid.
●Never drink haze liquid. If it is ingested, call a doctor immediately. If haze liquid comes in contact
with skin or eyes, rinse thoroughly with water.
●Never lock haze-filled rooms. Risk: panic among the locked persons!
●Never use the device permanently! The output should be active only for short periods of time.
●Do not insert objects into air vents.
●Do not open the device and do not modify the device.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this would reduce the device’s life.
●Do not touch the hazer output bare-handed during its operation (output becomes very hot).
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only use device indoors, avoid contact with water or other liquids.
●Only use haze in well-ventilated rooms.
●Only use the high-quality MHL-hazer liquid, recommended by your dealer (ordercode: 60569). Other
haze liquids may cause poor effect.
●Avoid flames and do not put close to flammable liquids or gases.
●Always make sure there is sufficient liquid in the haze liquid tank.
●Always allow free air space of at least 50 cm around the sides and top of the unit.
●Always allow free air space of at least 50 cm around the unit for ventilation.
●Always disconnect device from the CO2cylinder and the hose, when device is not used or before
cleaning! Always handle the CO2hose with care. Never pull out the CO2hose by tugging.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that all the required safety devices are in good condition and function properly.
●Make sure that the CO2hose is never crimped or damaged. Check the device and the CO2hose
from time to time.
●If text and/or icons are missing, damaged or illegible on the Mistique, they should be replaced
●Always drain tank before shipping or otherwise transporting this unit.
●Always keep tank cap closed while operating.
●Always keep the haze machine upright.
●Always unplug the Mistique before filling its tank.
●For adult use only. Haze machine must be installed out of the reach of children. Never leave the unit
running unattended. Leave the grid guarding the nozzle in place if the machine is to be used in the
presence of children
●Always keep the nozzle at least 50 cm away from contact with anything, while in operation.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power-
cord from time to time.
●Make sure that the core diameter of extension cords and power cords is sufficient for the required
power consumption of the device.
●The cable insert or the female part in the device must never be strained. There must always be
sufficient cable to the device. Otherwise, the cable may be damaged which may lead to deadly
electrical shocks.
●If the external cable is damaged, it has to be replaced by a qualified technician.
●If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.

5
Ordercode: 60769
Mistique
●If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
●If the Mistique fails to work properly, discontinue use immediately. Drain all haze liquid from the tank,
pack the unit securely (preferably in the original packing material), and return it to your Showtec
dealer for service.
●For replacement use fuses of same type and rating only.
●The haze vapour at the point of release is under pressure and is extremely hot.
●The output nozzle becomes very hot during operation (300 ºC). Keep flammable materials at least
50 cm away from the nozzle.
●The use of haze-fluid is only allowed for adults.
●In dense, haze-saturated surroundings, the oxygen portion is substantially reduced!
●The haze density must be portioned in a way that the visibility of at least 5 m is preserved - Danger of
anxiety state due to missing orientation!
●Every haze-filled room must be overseen by a skilled person.
●Allow time to cool down, before cleaning or servicing.
●Provide sufficient lighting of the surroundings when installing the device.
●The user is responsible for correct positioning and operating of the Mistique. The manufacturer will not
accept liability for unsafe situations, accidents, damages caused by:
- The misuse or incorrect installation of this device.
- Ignoring warnings or instructions as shown in this manual.
- Using the Mistique for purposes or conditions other than specified in this manual.
- Changes to the Mistique. This includes the use of other than original spare parts.
- Inadequate maintenance.
- The unauthorized removal of safety symbols, safety covers and / or guards.
- The improper use of the Mistique.
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.
CO2Use
The Mistique uses liquid or gaseous CO₂as input. The application of CO₂involves serious risks.
Make sure that you are aware of these risks before installation and/or operation.
Always use approved CO₂cylinders, hoses and connections.
Always consult your CO₂supplier for regulations and instructions on safe installation and use.
Showtec is not liable for unsafe situations, accidents and damages that are the result of incorrect working
with CO₂gas and CO₂cylinders.
Inadequate installation and/or operation of a CO₂powered machine and CO₂cylinders can lead
to death or serious injury. Always follow the instructions from this manual, from your CO₂supplier and from
local authorities.

6
Ordercode: 60769
Mistique
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The maximum ambient temperature ta = 40 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
We presume that you, your employees and others who come into contact with the
Mistique are familiar with how the machine must be dealt with. This includes the correct
use, maintenance and repair of Mistique as described in this user manual. The employees
should be familiar with the use of machines through training and/or experience.
Improper installation can cause serious damage to people and property !
You endanger your own safety and the safety of others!
Showtec excludes liability for unsafe situations, accidents and damage that are the result of:
●Disregard for the warnings or regulations as set out on the Mistique or in this manual.
●Use for other purposes or under other circumstances than those set out in this documentation.
●Alterations to the Mistique. This also includes the use of replacement parts other than the original
ones.
●Insufficient maintenance.
●Unauthorised removal of safety caps and/or safeguards.
●Incompetent operation of the machine.
Showtec is not liable for any consequential loss in the event of an Mistique breakdown.
This user manual has been drawn up with the utmost care. Showtec cannot be held responsible for any
mistakes made in this publication or for any consequences thereof.
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

7
Ordercode: 60769
Mistique
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail aftersal[email protected] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

8
Ordercode: 60769
Mistique
Description of the device
Features
The Mistique is a powerful hazer machine. This hazer produces an extremely fine haze due to the
combination of low pressurised CO2and a high quality oil-based dedicated hazer liquid.
●Input Voltage: 100–240 V AC, 50/60 Hz
●Power consumption: 1250 W max.
●Heating time: under 8 min.
●Maximum Output: 5000 cu.ft/min
●Output Direction: Up, down, forward
●Output Regulation: 5–40 psi
●Tank capacity: 2,5 L
●Liquid Type: MHL-2 only
●Liquid Consumption: 120 ml/hour (@40 psi)
●Gas Type: CO2or N2
●Gas Consumption: 0,36 kg/hour (@40 psi)
●Gas Pressure: 50 to 60 psi / 3,4 to 4,1 bar max.
●On Board: Battery powered LCD TFT touchscreen
●Control Mode: Manual mode, 2x Timer mode, DMX control, Wireless DMX control.
●DMX Mode: 1, 3, 5 channels
●Colour: Black
●Housing: Metal & Flame-retardant plastic
●Data Connection: Neutrik XLR 5-pin & 3-pin IN/OUT
●Gas Connection: Male Q-lock
●Power connection: Neutrik Powercon True1 IN/OUT
●Working environment: +5 °C ~ 45 °C
●Ingress Protection: IP20
●Fan Speed: 20–100 %
●Very even and thin haze ensures no visible cloudy effect on stage
●Extreme silent operation due to CO2supply
●Output and fan speed remote controllable by DMX and W-DMX
●Fast and easy setup with Q-lock CO2hose system
●Automatic fuse: 8A/250V
●Dimensions: 503 x 334 x 310 mm (LxWxH)
●Weight: 17 kg
Note: The Mistique needs a CO2connection with a gas tank to create haze.
Optional accessories:
60569 –MHL-2 Hazer Fluid
61017 –CO2 3/8 Q-Lock Hose
61019 –CO2 Q-Lock Regulator
61021 –CO2 90° 3/8 Q-Lock connector

9
Ordercode: 60769
Mistique
Frontside
Fig. 01
01) Fan
02) Plug with adapter for power to the fan
03) Output nozzle
04) Carry handle
05) MHL fluid tank (2,5 L)
Note: You can only fill 75 % of the tank, due to compression (that is, not more than 2 L in the tank).
06) Ventilation

10
Ordercode: 60769
Mistique
Backside
Fig. 02
07) LCD Touch Display
08) 3-pin DMX signal connector IN
09) 5-pin DMX signal connector IN
10) 100–240 V True1 pro power connector IN
11) Input for Gas; Only use CO2or N2, gas pressure min 50 psi, max 60 psi. / 3,4 to 4,1 bar max, Quick-lock
coupling
12) 100–240 V True1 pro power connector OUT
13) Automatic Fuse 8A/250V
14) Menu ON/OFF
Press and hold down for 3 seconds to activate the menu. You can check/ change your settings
without connecting the Mistique to the mains power.
Note: You cannot haze without connecting the Mistique to the mains power.
15) 5-pin DMX signal connector OUT
16) 3-pin DMX signal connector OUT
17) Wireless DMX receiver antenna

11
Ordercode: 60769
Mistique
Installation
Remove all packing materials from the Mistique. Check if all foam and plastic padding is removed,
especially in the haze output area.
Use the Mistique only with MHL-2 hazer fluid (60569). Any other types of liquid can damage the unit.
The unit can also be operated at floor level or sitting on any regular surface as well.
Do not point the output in a direction that will aim directly at a person.
Whatever installation method you choose, the unit must always be placed in horizontal position.
The maximum inclination angle of the device should not exceed 30º.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Always follow the instructions from this manual, from your CO₂supplier and from local authorities.
Precautions for operation
Using a damaged or an improperly installed machine can lead to death, serious injury or
property damage. Always inspect the machine thoroughly before operation.
Missing or obscured safety symbols on the machine can cause unawareness, which in turn can
lead to death, serious injury or property damage. Make sure all safety symbols are correctly in
place and visible. See front side of the device.

12
Ordercode: 60769
Mistique
Setup and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120 V specification product on 230 V power, or vice versa.
Note: Always monitor haze tank level liquid indicator when creating a fine haze!
Note: Be careful not to exceed the maximum fluid level. DO NOT OVERFILL!
Note: You can only fill 75 % of the tank, due to compression (that is, not more than 2 L in the tank).
Note: Running a haze machine with no hazer liquid can permanently damage the unit!
Note: Never shut down the Mistique while making haze.
Note: The Mistique needs a CO2connection with a gas tank to create haze.
Note: Installation and operation of the Mistique requires professional and trained personnel.
Remove cover and fan to change output direction
You can change the output direction by removing the metal cover or by turning the fan upside-down.
Change front only when device is not running and cold.
01) First unscrew the 2 screws (A).
02) Then remove the DC plug from the device (B).
03) Remove the cover by pulling it up and then away from the device (C).

13
Ordercode: 60769
Mistique
Add hazer liquid to the tank
Note: You can only fill 75 % of the tank, due to compression (that is, not more than 2 L in the tank).
Be careful not to exceed the maximum fluid level. This can lead to pressure errors or can damage the
device.
Tip: Use a funnel while adding the hazer liquid to the tank.
The device must always be placed in a horizontal position. The maximum inclination angle of the device
should not exceed 30º.
01) Loosen the cap on the fluid tank (05) and remove it.
02) Insert a funnel into the tank.
03) Add the hazer liquid to the tank.
Note: You can only fill 75 % of the tank, due to compression (that is, not more than 2 L in the tank).
Be careful not to exceed the maximum fluid level. This can lead to pressure errors or can damage
the device.
04) Remove the funnel.
05) Replace and tighten the cap on the fluid tank (05).

14
Ordercode: 60769
Mistique
Start-up
01) Put the Mistique Hazer on a flat surface and keep a minimum of 50 cm distance from any objects.
Make sure there is enough room to install all cables and CO2hoses.
02) Slowly fill in the liquid tank with the designated MHL-2 hazer fluid.
Note: It is strongly recommended to limit each refill to a maximum of 1 L of MHL-2 hazer fluid.
Note: Be careful not to exceed the maximum fluid level. DO NOT OVERFILL!
Note: You can only fill 75 % of the tank, due to compression (that is, not more than 2 L in the tank).
03) Connect the Machine "air-in" to the pressure regulator with gas tank and open the adjuster valve
between 50–60 psi (3,5-4,1 bar or 350–410 kPa) position.
04) Plug the power cord into a grounded electrical outlet. Set the power switch to ON.
05) You have to start the heater warm-up via the manual function or by DMX.
06) The device will now start to warm up and the display shows .
Warm-up is complete when the upper left corner of LCD control panel shows . The device
is now ready for operation.
07) Please go to the manual menu on the control panel and press Start to start hazing.
08) When you have finished hazing, press to activate the Power Off menu.
09) The next window will show:

15
Ordercode: 60769
Mistique
10) Close the CO2now.
11) The counter will count down from 10 to zero.
12) Let the Mistique decompress and please wait until the pressure is down.
13) Now you can decouple the CO2hose and the power cable.

16
Ordercode: 60769
Mistique
Control Modes
There are 2 modes:
●Stand-alone
●DMX512 (1CH, 3CH, 5CH)
One Mistique (Stand-alone)
01) Leave at least 1 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Mistique is not connected by a DMX cable, it functions as a stand-alone device.
04) Please see page 31 for more information about the stand alone mode.
Multiple Mistiques (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Use a 3-pin/5-pin XLR cable to connect the Mistiques and other devices.
04) Link the units as shown in Fig. 04. Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Mistiques DMX Set Up
Fig. 04
Note: Link all cables before connecting electric power

17
Ordercode: 60769
Mistique
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX
optically isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a power link @120 V: 3 fixtures
Maximum recommended number of fixtures on a power link @230 V: 3 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio Certified DMX Data Cables
●DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
●DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
●DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
The Mistique can be operated with a controller in control mode or without the controller in stand-alone
mode.

18
Ordercode: 60769
Mistique
Control Panel
A)
B)
C)
D)
E)
F)
G)
H)
I)
Status menu
Timer 2 button
Power OFF button
Manual button
Menu button
Heater button
Clean button
DMX button
Timer 1 button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Mistique will respond to the controller.
Please note when you use the controller, the unit has a maximum of 5channels.
When using multiple Mistiques, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Mistique should be 1(001); the DMX address of the second Mistique
should be 1+5=6 (006); the DMX address of the third Mistique should be 6+5=11 (011), etc.
Please, be sure that you do not have any overlapping channels in order to control each Mistique
correctly.
If two or more Mistiques are addressed similarly, they will work similarly. For address settings, please refer to
the instructions under ”Addressing’.
Controlling:
After having addressed all Mistique fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Mistique will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX input, the a red dot will be shown on the control panel.
The problem may be:
●The XLR cable from the controller is not connected with the input of the Mistique.
●The controller is switched off or defective, the cable or connector is defective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

19
Ordercode: 60769
Mistique
Menu Overview
