Show Tec 40637 User manual

Flame Light 1,5m LED V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40637
MANUAL
ENGLISH

1
Ordercode: 40637
Flame Light 1,5m LED
Table of contents
Warning ...............................................................................................................................................................................2
Unpacking Instructions.................................................................................................................................................2
LED Expected Lifespan ................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Overview ........................................................................................................................................................................7
Installation...........................................................................................................................................................................8
Set Up and Operation.......................................................................................................................................................8
Control Modes...............................................................................................................................................................8
One Flame Light (Stand-alone Mode) ..................................................................................................................8
One Flame Light (Sound-controlled)......................................................................................................................8
Multiple Flame Lights (Master/Slave Mode) .........................................................................................................8
Multiple Flame Lights (DMX Control) ......................................................................................................................9
Fixture Linking...............................................................................................................................................................10
Data Cabling...............................................................................................................................................................11
Control Mode ..............................................................................................................................................................11
DMX Addressing ..........................................................................................................................................................11
Main Menu Options....................................................................................................................................................12
1. Stand-alone Mode ..............................................................................................................................................12
1.1 Strobe Mode.......................................................................................................................................................12
1.2 Color Flow Mode ...............................................................................................................................................12
1.3 7-Color Switch Mode ........................................................................................................................................12
1.4 5-Color Switch Mode ........................................................................................................................................12
1.5 Red & Green Switch Mode..............................................................................................................................13
1.6 Static Color Mode .............................................................................................................................................13
2. Sound-controlled Mode .....................................................................................................................................13
3. Master/Slave Mode.............................................................................................................................................13
4. DMX-512 Mode ....................................................................................................................................................14
DMX Address Quick Reference Chart .................................................................................................................15
DMX Channels.............................................................................................................................................................16
6 Channels ................................................................................................................................................................16
Maintenance....................................................................................................................................................................17
Replacing the Fuse.....................................................................................................................................................17
Troubleshooting................................................................................................................................................................17
No Light.........................................................................................................................................................................17
No Response to DMX..................................................................................................................................................18
Product Specifications....................................................................................................................................................19
Dimensions........................................................................................................................................................................20
Notes..................................................................................................................................................................................21

2
Ordercode: 40637
Flame Light 1,5m LED
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Flame Light 1,5m LED DMX
IEC power cable (1,10 m)
2 silk flame imitations
Velcro board
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 40637
Flame Light 1,5m LED
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the LEDs.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this will reduce the device’s life.
Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use the device indoors, avoid contact with water or other liquids.
Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep the case closed while operating.
Always allow a free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the LEDs are obviously damaged, they have to be replaced.
If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Flame Light. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.

4
Ordercode: 40637
Flame Light 1,5m LED
During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
Operating Determinations
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
The maximum ambient temperature ta= 40°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !

5
Ordercode: 40637
Flame Light 1,5m LED
The Flame Light 1,5m LED can only be placed on a flat stage.
Improper installation can cause serious injuries and damage of property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!

6
Ordercode: 40637
Flame Light 1,5m LED
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 40637
Flame Light 1,5m LED
Description of the device
Features
The Showtec Flame Light 1,5m LED DMX is an RGB flame machine with high output and great effects.
Input Voltage: 240V, 50Hz
Power consumption: 136W
Control modes: Stand-alone, Sound-controlled, Master/Slave, DMX-512
RGB color mixing
Light Source: 168 x 10mm RGB LED
Sound-controlled via built-in microphone
DMX-controlled via DMX controller
DMX modes: 6 channels
Flame length: 1,2 m
Total height: 1,5 m
Strobe: 0-20Hz
Strong metal housing
Data Connector: 3-pin XLR (IN/OUT)
Cooling: Convection
Fuse: F2AL/250V
Dimensions: 520 x 250 x 346 mm (LxWxH)
Weight: 11 kg
Silk flame imitation
Length: 700 mm
Width: 545 mm
Overview
Fig. 01
01) Sound sensitivity/color brightness/speed control
02) DIP switches
03) 3-pin DMX signal connector IN
04) Air intake grill
05) Power switch ON/OFF
06) IEC power connector 100-240V + Fuse F2AL/250V
07) Ground/earth connection
08) 3-pin DMX signal connector OUT
09) Silk flame imitation with a Velcro fastener

8
Ordercode: 40637
Flame Light 1,5m LED
Installation
Remove all packing materials from the Flame Light 1,5m LED. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply. The device can be sound-controlled as it is equipped
with a built-in microphone.
Control Modes
There are 4 modes:
1. Stand-alone Mode
2. Sound-controlled Mode
3. Master/Slave
4. DMX-512
One Flame Light (Stand-alone Mode)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Flame Light is not connected with a DMX-cable, it functions as a stand-alone device.
05) Please see pages 12-13 for more information about the Stand-alone Mode.
One Flame Light (Sound-controlled)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Flame Light is not connected with a DMX-cable, it functions as a stand-alone device.
05) Please see page 13 for more information about the Sound-controlled Mode.
Multiple Flame Lights (Master/Slave Mode)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Flame Light.
The pins:
01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in Fig. 02, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on pages 12-13 (Stand-alone or Sound-
controlled). This means that you can set your desired operation mode on the master device and all
slave devices will react the same as the master device.

9
Ordercode: 40637
Flame Light 1,5m LED
Multiple Flame Lights Master/Slave Set Up
Fig. 02
Multiple Flame Lights (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the Flame Light and other devices.
05) Link the units as shown in Fig. 03, Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.

10
Ordercode: 40637
Flame Light 1,5m LED
Multiple Flame Lights DMX Set Up
Fig. 03
Note: Link all cables before connecting electric power
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures

11
Ordercode: 40637
Flame Light 1,5m LED
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller (when you select the DMX address and save it,
the controller will display the saved DMX address the next time).
DMX Addressing
The control panel, equipped with DIP switches, on the front side of the base allows you to assign the DMX
fixture address, which is the first channel from which the Flame Light will respond to the controller.
Please note when you use the controller, the unit has 6 channels.
When using multiple Flame Lights, make sure that you set the DMX addresses right.
Therefore, the DMX address of the first Flame Light should be 1(001); the DMX address of the second
Flame Light should be 1+6=7 (007); the DMX address of the third Flame Light should be 7+6=13 (013), etc.
Please, be sure that you do not have any overlapping channels in order to control each Flame Light
correctly.
If two or more Flame Lights are addressed similarly, they will work similarly.
Controlling:
After having addressed all Flame Light fixtures, you may now start operating these via your lighting
controller.
Note: For more information on DMX control, see page 14 (4. DMX-512 Mode)
The problem may be:
The XLR cable from the controller is not connected with the input of the Flame Light.
The controller is switched off or defective, the cable or connector is defective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

12
Ordercode: 40637
Flame Light 1,5m LED
Main Menu Options
Before switching the device ON, make sure that the silk flame imitation IS NOT placed in
the vicinity of the air intake grill. Otherwise, the suction power generated by the air
intake grill will prevent the silk flame imitation from functioning properly.
1. Stand-alone Mode
1.1 Strobe Mode
01) Set DIP switch 1to ON position and all the remaining switches to OFF position, in order to activate the
Strobe Mode.
02) Turn the control (01) to decrease/increase the strobe speed.
1.2 Color Flow Mode
01) Set DIP switch 2to ON position and all the remaining switches to OFF position, in order to activate the
Color Flow Mode.
02) Turn the control (01) to decrease/increase the color flow speed.
1.3 7-Color Switch Mode
01) Set DIP switch 3to ON position and all the remaining switches to OFF position, in order to activate the
7-Color Switch Mode.
02) Turn the control (01) to decrease/increase the color switch speed.
1.4 5-Color Switch Mode
01) Set DIP switch 4to ON position and all the remaining switches to OFF position, in order to activate the
5-Color Switch Mode.
02) Turn the control (01) to decrease/increase the color switch speed.

13
Ordercode: 40637
Flame Light 1,5m LED
1.5 Red & Green Switch Mode
01) Set DIP switch 5to ON position and all the remaining switches to OFF position, in order to activate the
Red & Green Switch Mode.
02) Turn the control (01) to decrease/increase the switch speed.
1.6 Static Color Mode
01) Set DIP switch 6(Red), 7(Green) and 8(Blue) to ON position and all the remaining switches to OFF
position, in order to activate the Static Color Mode. The colors can be used separately or be
combined –in order to obtain an unlimited range of colors.
02) Turn the control (01) to decrease/increase the color brightness.
2. Sound-controlled Mode
01) Set DIP switch 9to ON position and all the remaining switches to OFF position, in order to activate the
Sound-controlled Mode.
02) Turn the control (01) to decrease/increase the sound sensitivity.
3. Master/Slave Mode
01) Set the master device to one of the forementioned modes (Stand-alone or Sound-controlled).
02) In all the connected slave devices, set DIP switch 10 to ON position and all the remaining switches to
OFF position in order to activate the Master/Slave Mode.
03) Now, all the connected slave devices will react the same as the master device.

14
Ordercode: 40637
Flame Light 1,5m LED
4. DMX-512 Mode
DMX products must have their own unique address to receive DMX signals.
Addresses on the controller are set by flipping the appropriate DMX DIP switches.
DMX address settings are the sum of the DIP switch values. The values, alongside with the corresponding
switches, can be found in the quick reference chart (see page 15).
Example 1
Flame Light 1,5m
LED DMX
Address Value
DMX DIP Switches "ON"
Unit 5
31
#1 , #2, #3, #4, #5
Switch
Value
#1
1
#2
2
#3
4
#4
8
#5
16 +
Total sum
31
Explanation: Since each unit has 6 channels, each address advances by 6 values (See Address Value
above).
Once address values are determined, add DMX dip switch values to obtain the appropriate address
(DMX DIP Switches "ON") for each unit. Flip appropriate DMX DIP switches on each unit.
Example 2
01) If you want to set a DMX address 133, you first have to find the number 133 in the DMX Address Quick
Reference Chart (see page 15).
02) Then look at the left side (DIP Switches #1-#5) horizontally from 133.
In the table you will see that #1=ON, #2=OFF, #3=ON, #4=OFF, #5=OFF.
03) Finally, look at the upper side of the table (DIP Switches #6-#9) vertically from 133.
In the table you will see that #6=OFF, #7=OFF, #8=ON, #9=OFF.

15
Ordercode: 40637
Flame Light 1,5m LED
DMX Address Quick Reference Chart

16
Ordercode: 40637
Flame Light 1,5m LED
DMX Channels
6 Channels
Channel 1 –DMX control
0-127
Not functional
128-255
DMX Mode
Channel 2 –Red ( CH1 must be set between 128-255 )
0-255
Gradual adjustment Red, from 0-100%
Channel 3 –Green ( CH1 must be set between 128-255 )
0-255
Gradual adjustment Green, from 0-100%
Channel 4 –Blue ( CH1 must be set between 128-255 )
0-255
Gradual adjustment Blue, from 0-100%
Channel 5 –Functions
0-10
Not functional
11-85
Strobe flash frequency, from slow to fast
86-160
Color switch, from slow to fast
161-235
Color flow, from slow to fast
236-255
Sound-controlled Mode
Channel 6 –Strobe ( CH1 must be set between 128-255 while CH2-CH4 must be active )
0-255
Strobe flash frequency, from slow to fast

17
Ordercode: 40637
Flame Light 1,5m LED
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The Flame Light 1,5m LED requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure that connections are thoroughly dry before linking equipment or supplying
electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out.
If the fuse burns out, the product will not function whatsoever. If this happens, follow the directions below:
01) Unplug the unit from electric power source.
02) Insert a flat-headed screwdriver into a slot in the fuse cover. Gently pry up the fuse cover. The fuse
will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder. Reinsert the fuse cover. Be sure to use a fuse of the
same type and specification. See the product specification label for details.
Troubleshooting
No Light
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
If the light effect does not operate properly, refer servicing to a technician.
Suspect three potential problem areas as: the power supply, the LEDs, the fuse.
01) Power supply. Check if the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Flame Light 1,5m LED to your Showtec dealer.
03) The fuse. Replace the fuse. See page 17 for replacing the fuse.
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the Flame Light 1,5m LED as
this may damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.

18
Ordercode: 40637
Flame Light 1,5m LED
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Solution
One or more
fixtures do not
function at all
No power to the fixture
•Check if power is switched on and
cables are plugged in
Primary fuse blown
•Replace fuse
Fixtures reset
correctly, but all
respond
erratically or not
at all to the
controller
The controller is not connected.
•Connect controller.
3-pin XLR Out of the controller
does not match XLR Out of the first
fixture on the link (i.e. signal is
reversed)
•Install a phase reversing cable
between the controller and the
first fixture on the link
Fixtures reset
correctly, but
some respond
erratically or not
at all to the
controller
Poor data quality
•Check data quality. If much lower
than 100 percent, the problem
may be a bad data link
connection, poor quality or
broken cables, missing termination
plug, or a defective fixture
disturbing the link
Bad data link connection
•Inspect connections and cables.
Correct poor connections. Repair
or replace damaged cables
Data link not terminated with 120
Ohm termination plug
•Insert termination plug in output
jack of the last fixture on the link
Incorrect addressing of the fixtures
•Check address setting
One of the fixtures is defective and
disturbs data transmission on the
link
•Bypass one fixture at a time until
normal operation is restored:
unplug both connectors and
connect them directly together.
•Have the defective fixture
serviced by a qualified technician
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed)
•Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture that behaves
erratically
No light or lamp
cuts out
intermittently
Fixture is too hot
•Allow the fixture to cool down
•Clean the fan
•Make sure that air vents and the
LEDs are not blocked
•Turn up the air conditioning
LEDs damaged
•Disconnect the fixture and return it
to your dealer
The power supply settings do not
match local AC voltage and
frequency
•Disconnect fixture. Check settings
and correct if necessary

19
Ordercode: 40637
Flame Light 1,5m LED
Product Specifications
Model:
Showtec Flame Light 1,5m LED DMX
Input Voltage:
AC 240V, 50Hz
Continuous Power:
136W
Fuse:
F2AL/250V
Dimensions:
520 x 250 x 346 mm (LxWxH)
Weight:
11 kg
Operation and Programming:
Setup and Addressing:
10 DIP switches, sensitivity/speed control
Power Connection:
IEC input
DMX modes:
6 Channels
Signal input:
3-pin DMX signal connector IN
Signal output:
3-pin DMX signal connector OUT
Signal pin OUT:
pin 1 earth, pin 2 (-), pin 3 (+)
Electro-mechanical effects:
Control modes:
Stand-alone, Sound-controlled, Master/Slave, DMX-512
Sound control:
via built-in microphone
Strobe:
0-20Hz
Housing:
Strong metal housing
Cooling:
Convection (no fans)
Included:
2 silk flame imitations, Velcro board, IEC power cable
LED:
Colors:
RGB
Light source:
168 x 10 mm RGB LED
Max. ambient temperature ta:
40°C
Max. housing temperature ta:
80°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: [email protected]l
