SICK SiLink2 Master IOLA2US-01101 User manual

EN
SiLink2 Master
IOLA2US-01101
IO-Link USB Master
OPERATING INSTRUCTIONS

Operating instructions IO-Link USB Master SiLink2 Master
2 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
Copyright protection!
This work is protected by copyright. The resulting rights
are retained by SICK AG. Duplication of this work is only
permitted within the bounds of the statutory regulations
of the Urhebergesetz [Copyright Act]. The work may
not be altered or abridged without the express written
permission of SICK AG.

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•80173873
Operating instructions IO-Link USB Master SiLink2 Master
Table of Contents
Table of Contents
1 General ............................................................................................... 5
1.1 InformationontheOperatingInstructions...............................5
1.2 ExplanationofSymbols.............................................................5
1.3 ScopeofDelivery.......................................................................5
1.4 CustomerService......................................................................6
1.5 ECDeclarationofConformity....................................................6
2 Safety .................................................................................................. 7
2.1 CorrectUse.................................................................................7
2.2 IncorrectUse..............................................................................7
2.3 RequirementsforQualiedPersonnel.....................................8
3 Identication ...................................................................................... 9
3.1 TypeLabel..................................................................................9
4 StructureandFunction...................................................................... 9
4.1 Structure.....................................................................................9
4.2 Function................................................................................... 10
4.3 StatusIndicators..................................................................... 10
5 ElectricalConnection ...................................................................... 11
5.1 Safety....................................................................................... 11
5.2 ElectricalConnectionofSiLink2Master............................... 11
5.3 ConnectionDiagram............................................................... 12
5.3.1 USBConnectionDiagram....................................... 12
5.3.2 IO-LinkConnectionDiagram.................................. 12
6 Installing Software .......................................................................... 13
6.1 RequiredSoftware.................................................................. 13
6.2 InstallationwithSOPASETCongurationProgram.............. 13
6.3 InstallationwithFDTContainer.............................................. 14
7 CleaningandMaintenance............................................................. 16
8 Troubleshooting ............................................................................... 16
9 Disposal ............................................................................................ 16

Operating instructions IO-Link USB Master SiLink2 Master
Table of Contents
4 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
10 TechnicalData ................................................................................. 17
10.1 Dimensions............................................................................. 17
10.2 SupplyandInterface.............................................................. 18
10.3 AmbientConditions................................................................ 18
10.4 DesignConguration.............................................................. 18
Index .......................................................................................................... 19

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 5
Operating instructions IO-Link USB Master SiLink2 Master
General
1 General
1.1 Information on the OperatingInstructions
TheseoperatinginstructionssupplementthesuppliedQuickstartguide
andincludeadditionalinformationandmoredetaileddescriptionsof
workingwiththeIO-LinkUSBMasterSiLink2Master.
Theoperatinginstructionsareintendedtobeusedbyqualiedpersonnel
andelectricalspecialists.
1.2 Explanation of Symbols
PhysicalDamage Warningsintheseoperatinginstructionsarelabeledwithsymbols.
Thenotesmustbecompliedwithandcarefulactionsmustbetakenin
ordertoavoidphysicaldamage.
WARNING!
…indicatesapossiblehazardoussituationwhichmay
leadtophysicaldamageifitisnotavoided.
TipsandRecommendations
NOTE!
… highlights useful tips and recommendations as well as
information for efcient and hassle-free operation.
1.3 ScopeofDelivery
Includedwithdelivery:
• SiLink2 Master IOLA2US
• 1USBcable
• 1wallplug
Supplieddocumentation:
• Quickstart

Operating instructions IO-Link USB Master SiLink2 Master
General
6 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
1.4 CustomerService
Ifyourequireanytechnicalinformation,ourcustomerservicedepartment
willbehappytohelp.
Seethebackpageforyourrepresentative.
NOTE!
In order to allow us to deal with the matter quickly,
please note down the type designation and order number
before calling. You can nd the type designation and
order number on the type label. → See Page 9,
Chapter 3.1.
1.5 ECDeclarationofConformity
→ YoucandownloadtheECdeclarationofconformityonlineat
"www.mysick.com/de/silink".

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•80173877
Operating instructions IO-Link USB Master SiLink2 Master
Safety
2 Safety
2.1 CorrectUse
TheSiLink2MasterIOLA2USisusedasanadapterbetweenanIO-Link
deviceandaWindowsPC.IO-Linkdevicescanbeconguredviathe
SiLink2MasterandacongurationprogramsuchasSOPASEToranFDT-
basedcongurationprogram.
SICKAGacceptsnoliabilityfordirectorindirectlossesordamagewhich
resultfromtheuseoftheproduct.Thisappliesinparticularforadifferent
useoftheproductwhichdoesnotcomplywiththeintendedpurposeandis
notdescribedormentionedinthisdocument.
2.2 IncorrectUse
TheSiLink2MasterIOLA2USmustnotbeusedinexplosionareas.
Allusesnotdescribedundercorrectuseareprohibited.
Noaccessoriesmaybeconnectedwhichhavenotbeenexplicitlystipulated,
intermsofquantityandproperties,andapprovedbySICKAG.

Operating instructions IO-Link USB Master SiLink2 Master
Safety
8 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
2.3 Requirements for QualiedPersonnel
WARNING!
Damagetothedeviceintheeventofimproper
handling!
Improperhandlingmayleadtophysicaldamage.
Therefore:
• Allworkmustonlyeverbecarriedoutbythestipulated
persons.
Theoperatinginstructionsstatethefollowingqualicationrequirementsfor
thevariousareasofwork:
• Qualied personnel
areabletocarryouttheworkassignedtothemandindependently
recognizepotentialrisksduetotheirspecialisttraining,knowledgeand
experience,aswellasknowledgeoftherelevantregulations.
• Electrical specialists
areabletocarryoutworkonelectricalsystemsandindependently
recognizepotentialrisksduetotheirspecialisttraining,knowledge
andexperience,aswellasknowledgeoftherelevantstandardsand
regulations.
InGermany,theelectricalspecialistmustsatisfytheregulationsofthe
worksafetyregulationBGVA3(e.g.,masterelectrician).Corresponding
regulations,whichmustbeobserved,applyinothercountries.

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 9
Operating instructions IO-Link USB Master SiLink2 Master
Identication
3 Identication
3.1 Type Label
SiLink2 Master
IOLA2US-01101
1061790
D-79183 Waldkirch
www.sick.com
USB
Error
CH2 (DI/DO)
CH1 (C/Q)
IN-DC
Made in Germany
PWR
1
235
6
7
4
8
9
Fig. 1: Type Label
1 IO-Link symbol
2 LED labeling (side)
3 CE mark
4 Device type
5 Order number
6 Labeling
Mini USB B interface (side)
7 LED labeling (side)
8 Manufacturer address
9 Labeling of the connection of an
external wall plug (side)
4 StructureandFunction
4.1 Structure
1
2
3
45
6
7
Fig. 2: Structure of SiLink2 Master
1 Supply voltage DC 24 V connection of supplied power supply
2 Function display LED (yellow) 'PWR'
3 Mini USB B, connection of PC via supplied USB cable
4 Function display LED (green) 'C1 (C/Q)'
5 Function display LED (yellow) 'C2 (DI/DO)'
6 Function display LED (red) 'Error'
7 M12 male connector, connection IO-Link device

Operating instructions IO-Link USB Master SiLink2 Master
StructureandFunction
10 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
4.2 Function
TheSiLink2MasterisusedasanadapterbetweenanIO-Linkdeviceand
aPCwithaWindowsoperatingsystem.IO-Linkdevicescanbecongured
viatheSiLink2MasterandacongurationprogramsuchasSOPASETor
anFDT-basedcongurationprogram.
4.3 StatusIndicators
FunctionDisplays(LEDs)
FunctionDisplay Description
PWR •LEDyellow:
supplyviatheUSBport.
•LEDoff:nooperation
CH1(C/Q) DisplayIO-LinkandSIOmode
•LEDgreen
– Slowashing:noIO-Linkconnectionpresent
– Quickashing:IO-Linkconnectionisinthe
'Preoperate'mode
– Illuminated:adataexchange(operate)istakingplace
viatheIO-Linkconnection.
•LEDyellow:SIOmode
CH2(DI/DO) •LEDyellow
displaySIOmode
Error •LEDred
displayoferror:short-circuitordatatransmissionerror
Table 1: Function displays (LEDs)

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 11
Operating instructions IO-Link USB Master SiLink2 Master
ElectricalConnection
5 ElectricalConnection
5.1 Safety
IncorrectSupplyVoltage
WARNING!
Devicedamageduetoincorrectsupplyvoltage!
Incorrectsupplyvoltagecancausedamagetothedevice.
Therefore:
• Ifnecessary,onlyoperatetheSiLink2Masterusingthe
suppliedwallplug.
5.2 ElectricalConnectionofSiLink2Master
2
USB IO-Link
PC SiLink2 Master IO-Link Device
1
Fig. 3: Electrical Connection of SiLink2 Master
1 USB cable
2 Sensor cable
1. Ensurepowersupplyisnotconnected.
2. ConnectthePCtotheUSBMiniBfemaleconnectoroftheSiLink2
MasterusingthesuppliedUSBcable.
3. ConnectIO-LinkdevicetotheM12maleconnectoroftheSiLinkMaster
usingasensorcable.A3-poleor4-polecablemaybeusedasthe
sensorcable.
NOTE!
If the power requirement of the IO-Link device is
> 80 mA, connect the supplied wall plug to the DC 24 V
female connector of the SiLink Master and connect the
wall plug to the supply voltage.

Operating instructions IO-Link USB Master SiLink2 Master
ElectricalConnection
12 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
WallPlugUsage Asstandard,aUSBportprovides500mAat5V.Withoutawallplug,the
SiLink2MasterIOLA2USsuppliesapprox.80mAat24V.ForlotsofIO-Link
devices,apowersupplyof80mAissufcient.
IftheIO-Linkdeviceneedsmorepower,e.g.,whenstartingup,thenyouwill
needtousethesuppliedwallplug.
Fig. 4: Wall plug pin assignment
5.3 ConnectionDiagram
5.3.1 USBConnectionDiagram
12435
Fig. 5: Mini USB B connection diagram
Contact Signal Description
1 +5V VBUS+5VDC/500mA
2D– Data–
3 D+ Data+
4 ID nc:notassigned
5GND Ground(0V)
Table 2: Description Mini USB B
5.3.2 IO-LinkConnectionDiagram
12
4 3
5
Fig. 6: IO-Link connection diagram, M12 male connector, 5-pole, A-coding
Contact Signal Description
1 +24V Supplyvoltage:DC+24V
2 SIO SIO:CH2(DI/DO)
3 GND Supplyvoltage:0V
4IO-Link IO-Link:CH1(C/Q)
5–nc:notassigned
Table 3: Description IO-Link, M12 male connector, 5-pole, A-coding

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 13
Operating instructions IO-Link USB Master SiLink2 Master
Installing Software
6 Installing Software
6.1 Required Software
InordertobeabletoconguretheIO-LinkdeviceviatheSiLInk2Master,
youwilleitherneedtheSOPASETcongurationprogramfromSICKor
acongurationprogrambasedonFDT/DTMtechnology.
NOTE!
For additional information and for conguration programs,
go to 'www.mysick.com/de/silink'.
6.2 InstallationwithSOPASETCongurationProgram
YoucanusetheSOPASETcongurationprogramfromversion2.83upwards.
1. StartinstallationoftheSOPASETcongurationprogramusingthe
'setup.exe'le.Thefollowingwindowwillappear:
Fig. 7: SOPAS Engineering Tool Setup

Operating instructions IO-Link USB Master SiLink2 Master
Installing Software
14 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
2. InstallSOPASETcongurationprogramaccordingtotheinstallation
wizard.
3. InstallSDDleoftheIO-Linkdevice.
4. ConnectSiLink2MastertothePCandtotheIO-Linkdevice.
→SeePage11,Chapter5.
5. ConnectIO-LinkdeviceaccordingtotheConnectionWizardforIO-Link.
Fig. 8: IO-Link device in SOPAS ET
6.3 InstallationwithFDTContainer
YoucanusethegatewayDTMfromversion2.00upwards.
1. Startinstallationofthegatewayusingthe'setup.exe'le.
2. InstallDTMoftheIO-LinkdeviceorIODDinterpreter.Inordertodothis,
startinstallationusingthe'setup.exe'le.
3. UpdatedevicecatalogviatheFDT-basedcongurationprogram.
Inordertodothis,clickthe'Update'button.
Fig. 9: Update device catalog

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 15
Operating instructions IO-Link USB Master SiLink2 Master
Installing Software
NOTE!
The SiLink2 Master IOLA2US appears in the device
catalog as 'IO-Link USB' of the manufacturer 'IO-Link'.
4. Setupnetworkinthecongurationprogram.
5. ConnectSiLink2MastertothePCandIO-Linkdevice.→SeePage11,
Chapter5.
6. Setupconnectioninthecongurationprogram.
7. OpenuserinterfaceoftheIO-Linkdevicebydouble-clickingonthe
IO-Linkdeviceorviathecontextmenuinthecongurationprogram.
Fig. 10: Open user interface of the IO-Link device

Operating instructions IO-Link USB Master SiLink2 Master
CleaningandMaintenance
16 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
7 CleaningandMaintenance
SICKdevicesaremaintenance-free.Wedorecommendcheckingthescrew
andplugconnectionsandcleaningthedeviceatregularintervals.
8 Troubleshooting
Indication Possible Cause Troubleshooting
RedLED'Error'illuminated. Datatransmissionerror Transmitdataagain
Short-circuit ChangeSiLink2Master.
Table 4: Troubleshooting
9 Disposal
Observethefollowingpointsfordisposal:
• Donotdisposeofthedeviceindomesticrefuse.
• Disposeofthedeviceaccordingtotherelevantcountry-specic
regulations.

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 17
Operating instructions IO-Link USB Master SiLink2 Master
TechnicalData
10 TechnicalData
NOTE!
You can download, save and print the relevant online
data sheet with technical data, dimensions, and
connection diagram for your IO-Link USB Master online at
'www.mysick.com/de/silink'.
10.1 Dimensions
1
2
3
45
6
7
41
(1.61)
54
(2.13)
16
(0.63)
M 12
Fig. 11: Dimensions of IO-Link USB Master SiLink2
Dimensions with no brackets in mm. Dimensions with brackets in inches.
1 Supply voltage DC 24 V connection of supplied power supply
2 Function display LED (yellow) 'PWR'
3 Mini USB B, connection of PC via supplied USB cable
4 Function display LED (green) 'C1 (C/Q)'
5 Function display LED (yellow) 'C2 (DI/DO)'
6 Function display LED (red) 'Error'
7 M12 male connector, connection IO-Link device

Operating instructions IO-Link USB Master SiLink2 Master
TechnicalData
18 ©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387
10.2 SupplyandInterface
USB USB2.0(MiniUSBB)
PowerrequirementfromUSB ≤500mA
SupplyoftheIO-LinkdeviceviaUSB DC24V/80mA
Externalsupplyviasuppliedwallplug DC24V/1A
Polesafety Yes
IO-Linkcommunication IO-Linkspecication1.1
IO-Link port ClassA
Table 5: Supply
10.3 Ambient Conditions
Markofconformity CE
Protectionclass III
Ambienttemperaturerange • Operation:0°C…+45°C
• Storage:–40°C…+80°C
Enclosurerating IP20
Table 6: Ambient conditions
10.4 DesignConguration
Dimensions → SeePage17,Chapter10.1.
Connections • 1femaleconnector:connectionofexternalwallplug
• 1MiniUSBB:PCconnection
• 1maleconnectorM12,5-pole,A-coding:sensorcableconnection,
5-poleor4-pole
Table 7: Design Conguration

©SICKAG•PresenceDetection•Subjecttochangewithoutnotice•8017387 19
Operating instructions IO-Link USB Master SiLink2 Master
Index
A
Ambientconditions......................................................18
C
Cleaning........................................................................16
Congurationprogram.................................................13
Connectiondiagram
IO-Link.....................................................................12
USB..........................................................................12
Correct use..................................................................... 7
CustomerService........................................................... 6
D
Designconguration....................................................18
Dimensions...................................................................17
Disposal........................................................................16
E
ECDeclarationofConformity........................................ 6
Electricalconnection
SiLink2 Master.......................................................11
Electricalspecialist
Requirement............................................................. 8
Explanationofsymbols.................................................. 5
F
FDT/DTM.......................................................................13
Function........................................................................10
Functiondisplays..........................................................10
I
Incorrect use................................................................... 7
IO-Link
Connectiondiagram...............................................12
Interface..................................................................18
IO-Linkmode................................................................10
L
LEDs..............................................................................10
M
Maintenance................................................................16
O
Operating instructions................................................... 5
Q
Qualiedpersonnel........................................................ 8
Requirements........................................................... 8
S
Safety.............................................................................. 7
Electricalconnection..............................................11
Scopeofdelivery............................................................ 5
SIOmode......................................................................10
Software........................................................................13
SOPASET......................................................................13
Statusindicators..........................................................10
Supply...........................................................................18
T
Technicaldata..............................................................17
Troubleshooting............................................................16
U
USB
Connectiondiagram...............................................12
Interface..................................................................18
W
Wallplug.......................................................................12
Index

SICKAG | Waldkirch | Germany | www.sick.com
8017387/2014-03-03∙BGA/ITL(2014-03)∙A44cint42
Australia
Phone+61394570600
1800334802–toll-free
e-mail [email protected]
Belgium/Luxembourg
Phone+32(0)24665566
e-mail [email protected]
Brazil
Phone+55113215-4900
e-mail[email protected]
Canada
Phone+19057711444
e-mail[email protected]
Czech Republic
Phone+420257911850
e-mail[email protected]
China
Phone+864000121000
e-mail [email protected]t.cn
Phone+852-21536300
e-mail [email protected]
Denmark
Phone+4545826400
e-mail[email protected]
Germany
Phone+492115301-301
e-mail [email protected]
Spain
Phone+34934803100
e-mail [email protected]
France
Phone+33164623500
e-mail [email protected]
UK
Phone+44(0)1727831121
e-mail[email protected]
India
Phone+91–22–40338333
e-mail[email protected]
Israel
Phone+972-4-6881000
e-mail[email protected]
Italy
Phone+3902274341
e-mail [email protected]
Japan
Phone+81(0)333581341
e-mailsuppor[email protected]
Hungary
Phone+3613712680
e-mailof[email protected]
Netherlands
Phone+31(0)302292544
e-mail [email protected]
Norway
Phone+4767815000
e-mail[email protected]
Austria
Phone+43(0)223662288-0
e-mailof[email protected]
Poland
Phone+48228374050
e-mail [email protected]
Romania
Phone+40356171120
e-mailof[email protected]
Russia
Phone+7-495-775-05-30
e-mail [email protected]
Switzerland
Phone+41416192939
e-mailcontact@sick.ch
Singapore
Phone+6567443732
e-mail[email protected]
Slovenia
Phone+386(0)1-4769990
e-mailof[email protected]
South Africa
Phone+27114723733
e-mail[email protected]
South Korea
Phone+8227866321/4
e-mail[email protected]t
Finland
Phone+358-9-2515800
e-mail[email protected]
Sweden
Phone+46101101000
e-mail [email protected]
Taiwan
Phone+88622375-6288
e-mail [email protected]
Turkey
Phone+90(216)5285000
e-mail[email protected]
United Arab Emirates
Phone+971(0)48865878
e-mail [email protected]
USA/Mexico
Phone+1(952)941-6780
1(800)325-7425–toll-
free
e-mail[email protected]
Morerepresentativesandagencies
at www.sick.com
Table of contents
Other SICK Adapter manuals
