SH SERIES
HYDRAULIC USER MANUAL
To download your language go to www.side-power.com
Keep this
manual onboard !
2 019

26032 32 019
-
SEP user manual
DECLARATION OF CONFORMITY
Sleipner Motor AS
P.O. Box 519, Arne Svendsensgt. 6-8
N-1612 Fredrikstad, Norway
Declare that this product with accompanying standard control systems complies with
the essential health and safety requirements according to:
DIRECTIVE 2013/53/EU
DIRECTIVE 2014/30/EU
DIRECTIVE 2014/35/EU
MC_0020
Important User Considerations and Precautions................. 3
User Manual
Thruster Operation .................................................................... 4
Control Panel............................................................................. 5
Proportional Thruster Display .................................................... 6
Proportional Thruster Display Symbols ..................................... 6
HOLD Function.......................................................................... 7
Calibration ................................................................................. 7
Warning Signals When Using ’HOLD’ Function................... 7 - 8
MENU System........................................................................... 8
Alarm Descriptions ............................................................ 9 - 10
Maintenance...................................................................... 11- 12
Troubleshooting....................................................................... 13
Checklist.................................................................................. 14
Spare Parts.............................................................................. 15
Notes ............................................................................... 16 - 18
Product Information
Identifying your Product........................................................... 19
Contents
EN
MC_0048
Important Thruster User Considerations and Precautions
EN
• Always turn the main power switch off before touching any part of the thruster, as an incidental start while touching moving parts can cause serious
injuries.
• Always turn the control device off when the thruster is not in use.
• Never use a thruster close to objects/ persons or animals in the water, as the thruster will draw objects into the tunnel and contact with the
rotating propellers will cause serious injuries and damage the thruster.
• With the boat on land, only run the thruster for a fraction of a second, as without resistance it will accelerate very fast to a damaging rpm.
• While the thruster is in the air, ensure that the propellers have come to a complete stop before performing a directional change of the thruster, as it
might cause damage to the thruster.
• When leaving the boat always turn off the main power switch for the thruster.
• Make sure that only one control is used at the same time. If two panels are operated in opposite directions at the same time the thruster will not run. If
both are operated in the same direction, the thruster will run in this direction.
• If the thruster is not performing or functioning as usual, the cause must be found and corrected as soon as possible to avoid causing any other or
further damage to the equipment. You must also turn off the main battery switch immediately in case the problem is of electric origin.
• It is the owner/ captain/ other responsible parties full responsibility to assess the risk of any unexpected incidents on the vessel. If the thruster stops
giving thrust for some reason while manoeuvring you must have considered a plan on how to avoid damage to persons or other objects.
• The primary purpose of the thruster is to manoeuvre/ dock the vessel. Forward/ reverse speed must not exceed 4 knots when operated.
IMPORTANT
Failure to follow the Considerations and precautions can cause serious injury / damage and will render all warranty given
by Sleipner Motor AS VOID.

3
6032 32 019
-
SEP user manual
DECLARATION OF CONFORMITY
Sleipner Motor AS
P.O. Box 519, Arne Svendsensgt. 6-8
N-1612 Fredrikstad, Norway
Declare that this product with accompanying standard control systems complies with
the essential health and safety requirements according to:
DIRECTIVE 2013/53/EU
DIRECTIVE 2014/30/EU
DIRECTIVE 2014/35/EU
MC_0020
MC_0048
Important Thruster User Considerations and Precautions
EN
• Always turn the main power switch off before touching any part of the thruster, as an incidental start while touching moving parts can cause serious
injuries.
• Always turn the control device off when the thruster is not in use.
• Never use a thruster close to objects/ persons or animals in the water, as the thruster will draw objects into the tunnel and contact with the
rotating propellers will cause serious injuries and damage the thruster.
• With the boat on land, only run the thruster for a fraction of a second, as without resistance it will accelerate very fast to a damaging rpm.
• While the thruster is in the air, ensure that the propellers have come to a complete stop before performing a directional change of the thruster, as it
might cause damage to the thruster.
• When leaving the boat always turn off the main power switch for the thruster.
• Make sure that only one control is used at the same time. If two panels are operated in opposite directions at the same time the thruster will not run. If
both are operated in the same direction, the thruster will run in this direction.
• If the thruster is not performing or functioning as usual, the cause must be found and corrected as soon as possible to avoid causing any other or
further damage to the equipment. You must also turn off the main battery switch immediately in case the problem is of electric origin.
• It is the owner/ captain/ other responsible parties full responsibility to assess the risk of any unexpected incidents on the vessel. If the thruster stops
giving thrust for some reason while manoeuvring you must have considered a plan on how to avoid damage to persons or other objects.
• The primary purpose of the thruster is to manoeuvre/ dock the vessel. Forward/ reverse speed must not exceed 4 knots when operated.
IMPORTANT
Failure to follow the Considerations and precautions can cause serious injury / damage and will render all warranty given
by Sleipner Motor AS VOID.

46032 32 019
-
SEP user manual
Thruster Operation
EN
Take time to practice operation in open water to become familiar with the thruster and to avoid damages to your boat or people.
How to use a Bow Thruster
1. Turn on the main power switch for the bow thruster. (NB: Always turn off the main power switch when not onboard.)
2. Turn on the control panel by pushing both “ON” buttons on the original Side-Power panel simultaneously. (NB: If another type of control is
installed, push the On/Off switch for the bow thruster.)
* Turn off the control panel by pushing both “OFF” button
4. To Turn the bow in the desired direction push the red button for port movement or the green button for starboard.
- For joystick control, move the joystick in the direction you wish the bow to move.
-Other controls like footswitches or toggle-switches on the throttle can be used. Engage the port control, the bow will turn to port etc.
5. Depending on the sideways speed of the bow, you must disengage the control device shortly before the bow is in the desired position. (NB: The
boat will continue to move after disengaging the thruster control.)
How to use a single stern thruster
Due to space limitations, a vessel may only have a stern thruster. In this case, the stern thruster is used in the same way as a single bow thruster
for moving the boat’s stern. Follow the above instruction for operation use.
How to use a combined bow and stern thruster
The combination of a bow and stern thruster off ers total manoeuvrability to the boat and the ability to move the bow and the stern separately from each
other. This enables you to move the boat sideways in both directions and turn the boat around its axis 360º staying stationary.
Proportional control thruster
The overall operation of the thruster is the same as above. For proportional control move the joystick equivalent to the amount of thrust you intend to
receive.
NB: At any signifi cant cruising speed (+1-2 kn) the side thruster will have little eff ect to steer the vessel.
MC_0054
!Please refer to the graphic for special considerations relating to your model !
PJC221 PJC222 PJC211 PJC212
PRO proportional CONROL PANEL
*Developed for Hydraulic Thrusters
Compatible for all DC and AC thrusters

5
6032 32 019
-
SEP user manual
Thruster Operation
EN
Take time to practice operation in open water to become familiar with the thruster and to avoid damages to your boat or people.
How to use a Bow Thruster
1. Turn on the main power switch for the bow thruster. (NB: Always turn off the main power switch when not onboard.)
2. Turn on the control panel by pushing both “ON” buttons on the original Side-Power panel simultaneously. (NB: If another type of control is
installed, push the On/Off switch for the bow thruster.)
* Turn off the control panel by pushing both “OFF” button
4. To Turn the bow in the desired direction push the red button for port movement or the green button for starboard.
- For joystick control, move the joystick in the direction you wish the bow to move.
-Other controls like footswitches or toggle-switches on the throttle can be used. Engage the port control, the bow will turn to port etc.
5. Depending on the sideways speed of the bow, you must disengage the control device shortly before the bow is in the desired position. (NB: The
boat will continue to move after disengaging the thruster control.)
How to use a single stern thruster
Due to space limitations, a vessel may only have a stern thruster. In this case, the stern thruster is used in the same way as a single bow thruster
for moving the boat’s stern. Follow the above instruction for operation use.
How to use a combined bow and stern thruster
The combination of a bow and stern thruster off ers total manoeuvrability to the boat and the ability to move the bow and the stern separately from each
other. This enables you to move the boat sideways in both directions and turn the boat around its axis 360º staying stationary.
Proportional control thruster
The overall operation of the thruster is the same as above. For proportional control move the joystick equivalent to the amount of thrust you intend to
receive.
NB: At any signifi cant cruising speed (+1-2 kn) the side thruster will have little eff ect to steer the vessel.
MC_0054
!Please refer to the graphic for special considerations relating to your model !
PJC221 PJC222 PJC211 PJC212
PRO proportional CONROL PANEL
*Developed for Hydraulic Thrusters
Compatible for all DC and AC thrusters
MG_0056
Activating the bow thruster
Holding function for
auto running the
thrusters together in
the direction of the
arrows at selected
power Press “+” for
more and “-” for less
power.
*Developed for Hydraulic Thrusters
Compatible for all DC and AC thrusters
*Developed for DC and AC Thrusters
Not compatible for hydraulic thrusters
Holding function for
auto running the
thrusters together in
the direction of the
arrows at selected
power Press “+” for
more and “-” for less
power.
Press and hold “ON”
button for 1 second to
activate control panel.
Press to deactivate
control panel or
cancel or go back in
the menu system or
to mute internal
alarm buzzer.
Information display, see
following pages for details.
Emergency
stop button
Speed control joystick
for bow thruster
Speed control joystick
for stern thruster
*Control panel example
*Control panel example
*Control panel example*Control panel example
Activating the stern thruster
Activating both bow and
stern thruster to rotate the
boat on axis
Activating both bow and
stern thruster to push the
boat sideways
Proportional
Control Panel
Press to deactivate
control panel or
cancel or go back in
the menu system or
to mute internal
alarm buzzer.
Press and hold both
“ON” button for 1
second to activate
control panel. Press and hold for 3
second to activate
menu.
Press and hold for 3
second to activate
menu.

66032 32 019
-
SEP user manual
Proportional Thruster Display
EN MC_0053
Status indicators for bow
thruster. (Port bow thruster
in a dual bow thruster setup).
Runtime indicator will be shown here
in a single DC electric bow thruster
setup.
Status indicators for stern thruster. (Port
bow thruster in a dual stern thruster
setup)
Runtime indicator will be shown here
in a single DC electric stern thruster
setup.
Status indicators for starboard
bow thruster. Only shown in
a dual bow thruster setup.
Battery indicator will be
shown here in a single DC
electric bow thruster setup.
Status indicators for starboard
stern thruster. Only shown in a
dual stern thruster setup.
Battery indicator will be shown
here in a single DC electric stern thruster
setup.
BOW
STERN
BOW-STB
STERN-STB
Examples of display view for diff erent panels applications:
PJC211:
DC Electric Bow thruster
PJC221:
Hydraulic Bow thruster
PJC221:
AC Electric Bow thruster
PJC212:
DC Electric Bow thruster
DC Electric Stern Thruster
PJC222:
Hydraulic Bow thruster
Hydraulic Stern Thruster
PJC222:
AC Electric Bow thruster
Hydraulic Stern Thruster
PJC211:
DC Electric Stern thruster
PJC212:
Dual DC Electric Bow thrusters
Dual DC Electric Stern thrusters
PJC222:
Dual Hydraulic Bow thrusters
Dual Hydraulic Stern thrusters
PJC222:
Dual AC Electric Bow thrusters
Dual AC Electric Stern thrusters
PJC221:
Dual AC Electric Bow thrusters
PJC221:
Dual Hydraulic Bow thrusters
PJC221 PJC222 PJC211 PJC212

7
6032 32 019
-
SEP user manual
AC Thrusters:
Hydraulic Thrusters:
Retractable Thrusters:
DC Thrusters:
Motor temperature indicator.
Hydraulic oil temperature indicator.
Symbol shown when the thruster deploys. Symbol shown when the thruster retracts.
Symbol shown when the thruster is in position OUT.
When the thruster is deployed and no input is given
via the joysticks/buttons over a 10 second period,
the panel will give an audible signal every 10th
second to tell that the truster is still deployed.
Battery indicator.
From 8.5V to 12V for 12V thrusters,
15V to 24V for 24V thrusters
Motor temperature indicator.
From 70°C/ 158°F to 130°C/266°F.
Battery indicator.
From 8.5V to 12V for 12V thrusters,
15V to 24V for 24V thrusters
Motor temperature indicator.
From 70°C/ 158°F to 130°C/266°F.
Symbol shown when a DC Thruster is
used in a dual bow or dual stern setup:
Proportional Thruster Display Symbols
EN MC_0053
Thrust power and direction, Bow thruster(s)
Input from bow joystick on this panel.
The thrust indicator will be shown in this position on a single
joystick panel if the thruster is defi ned as a bow thruster
Indicating amount of thrust set by other control units in the system, i.e additonal
PJC panels, 8700 Retract panel, input via 8730 S-link external switch interface,
S-link remote control etc.
If two or more units are set to run the thruster in
opposite direction, this information will not be shown.
Thrust power and direction, Stern thruster(s)
Input from stern joystick on this panel
The thrust indicator will be shown in this position on a single joystick panel if the
thruster is defi ned as a stern thruster.

86032 32 019
-
SEP user manual
The ‘HOLD’ function is for auto-running of bow and stern thrusters together in the direction of the arrows at selected power.
Press “+” for more and “-” for less power (6 steps). The ‘HOLD’ function is normally used to hold the boat into the dock while mooring. The ‘HOLD’
function can be deactivated by running any thruster in the opposite direction from any control unit.
The ‘HOLD’ function can be calibrated to get balanced thrust from the bow and stern thruster.
See the PJC control panel manual on how to calibrate.
For safety! When oil pressure goes below 10bar, the ‘HOLD’ function is deactivated.
HOLD Function
Calibration
Warning Signals When Using ’HOLD’ Function
EN
EN
EN
MC_0053
MC_0053
MC_0053
The internal and external (if fi tted) buzzer will give the following warning signals:
Warning signals Cause Eff ect
1. Single short beep every 2.4 sec. • Voltage below 9.3V/17.5V (12V/24V system).
• Temperature above 85oC/185oF.
None
2. Two short beeps every 2.4 sec. • Voltage below 8.9V/16.3V (12V/24V system).
• Temperature above 100oC/212oF.
None
3. Red backlight in display and continous short
beeps.
• Voltage below 8.5V/15V (12V/24V system).
• Temperature above 110oC/230oF.
None
4. Red backlight in display and continous short
beeps.
If one or more of the thrusters enters an alarm state
- Voltage below 8.0V/12.0V (12V/24V system) or
temperature above 120oC/248oF.
“HOLD” function are canselled
and both thrusters will stop.
Temperature must drop below
110°C/230°F before the thruster
can be operated again. Low
Voltage alarm must be reset from
panel.
Access menu system by pressing and
holding Menu button for 3 seconds.
Move around in menus by using joystick.
Follow instructions on the screen and press the
buttons below the symbols indicated on LCD screen.
BUTTON SYMBOLS
On the bottom line of the display, a symbol will be shown over the buttons below.
These symbols will show what function each corresponding button has in the selected menu entry.
Return to
previous menu.
Select highlighted
menu text / Save edited
parameter.
Edit highlighted
parameter.
Cancel editing
without saving.
This symbol
indicates that the (stern)
joystick is used to move
between menu items /
parameters.
MAIN MENU ITEMS:
Move between main menu items with the (stern) joystick.
Language Stabilizer
( If installed)
Setup Info Default settings Panel setup

9
6032 32 019
-
SEP user manual
MENU System
EN MC_0053
LANGUAGE
LANGUAGE
• Choose language by moving joystick:
English, Norwegian, German, French,
Spanish, Italian and Danish.
• Press the button below to set
the language to the highlighted menu
entry. A star (*) on each side indicates
the laguage set.
DEFAULT
DEFAULT SETTINGS
• Reset all settings to factory default
- follow instructions on screen
• Press the button below to confi rm reset
• The following parameters/values will be set to the
factory settings:
Language = English
Backlight Level = 5
Backlight Night Color = Green
Backlight Nightlevel =1
Timer Auto-Off = 05 min
Hold Calibration =70% Bow and Stern
All system devices will be erased from memory.
(Setup procedure must be followed to reconfi gure the system)
STABILIZER
STABILIZER
(Shown only for yachts equipped with a Side-Power Stabilizer system)
Press the button below to edit the selected parameter.
ON/OFF will start to blink, use joystick to alter value.
Press the button below to save edited parameter to device.
(Default in systems
with stabilizers)
2. AnySpeed:
• Values: ON/OFF
• Switches the zero speed/at
anchor stabilization ON or OFF.
1. Stabilizer:
• Values: ON/OFF
• Switches the stabilizer ON or OFF.

10 6032 32 019
-
SEP user manual
Alarm Descriptions
EN MC_0053
1. PPC520, PPC820, PPC800, PPC840
2. Buzzer is only activated when any device is sending thrust on the S-link bus.
"Err.
No." Errors shown in display "Auto
Reset"
"Ext. buzzer
activation at
Alert Level"
Description Action
1Motor Overcurrent 2(²), 3 Motor current too high. "Thruster must be serviced by author-
ized personnel, reset or power OFF/ON
PPC(¹)."
2Motor Overtemp Yes 2(²), 3 "Motortemp has been over
120°C/248°F."
Motor cool down below 110°C /230°F.
3Controller Overtemp 2(²), 3 "PPC(¹)temp has been over
80°C/176°F."
PPC(¹)cool down below 45°C/113°F.
4Controller Overtemp 2(²), 3 "SR150000 temp has been over
80°C/176°F."
SR150000 cool down below 45°C
/113°F.
5Low Voltage 2(²), 3 Low motor voltage alarm when motor
is running.
12V thruster below 8.00V
24V thruster below 12.00V
Recharge battery, reset or power OFF/
ON device.
6Thermoswitch Yes 2(²), 3 Thermo switch input is activated and
there is an open circuit.
The thruster needs to cool down before
operating again.
7IPC Error 2(²), 3 Motor relay fault "Turn off thruster battery main switch.
Thruster must be serviced by author-
ized personel."
8Critical Error 2(²), 3 PPC(¹)output fail PPC(¹)must be sent for service.
9Low Motor Current 2(²), 3 Thruster uses no power Check thruster connections or motor
dead!
10 Motor Contactor 2(²), 3 No current on motor relay coil. Check motor relay connections, short
circuit or relay dead!
11 System Error 2(²), 3 Fatal error Device must be serviced by authorized
personel
12 No Communication 2(²), 3 No communication with device Check S-Link cables and power con-
nections.
13 Motor Temp Sensor 2(²), 3 Motor temperature sensor fail Check for an open circuit on the temp
sensor on the motor
14 Supply Voltage Fault 2(²), 3 No power Check power connections
15 Fuse Blown 2(²), 3 Fuse blown Replace fuse or check if main cable
from battery and main cable to thruster
has been switched
16 Manual Override Yes 2(²), 3 Main switch manually overridden Pull main switch
17 Motion OUT Fault 2(²), 3 Retract obstructed while deploying Turn off all panels. Go for lower speed/
deeper water and retry.
18 Motion IN Fault 2(²), 3 Retract obstructed while retracting Turn panel on and manually override
main switch. Remove obstruction and
try again.
Alarm Descriptions
EN MC_0053
1. PPC520, PPC820, PPC800, PPC840
2. Buzzer is only activated when any device is sending thrust on the S-link bus.
"Err.
No." Errors shown in display "Auto Reset"
"Ext. buzzer
activation at
Alert Level"
Description Action
19 Actuator Fault 2(²), 3 Actuator not getting any power "Check actuator connection or pow-
er to actuator. Reset alarm in alarm
menu on PJC 211/212/221/222 or
recycle power."
20 Pos.Sensor Fault 2(²), 3 Retract position sensor fail Check position sensor cables and
for sensor damage.
21 In Service Mode Yes 2(²), 3 "Retract controller in service mode. Switch
no. 4 is ON."
Check dipswitch setting on retract
control box.
22 High Oil Temp Yes 1, 2(²), 3 "Hydraulic oil temperature is higher than
75°C /167°F."
"Stop running and wait for tempera-
ture to drop.
Check if cooling pump is running."
23 Low Oil Level 1, 2(²), 3 Hydraulic oil lewel is to low Fill more hydraulic oil to the hydrau-
lic tank.
24 Warning Return Filter Yes 2(²), 3 Return fi lter element requiered
replacing.
25 Warning Pressure Filter Yes 2(²), 3 Pressure fi lter element requiered
replacing.
26 Warning High Speed Yes 1, 2(²), 3 "WARNING! High Speed.
Stabilizer not active!"
27 Stabilizer Fault Yes 1, 2(²), 3 Any Stabilizer alarm. See stabilizer panel for more info.
28 AC Motor Overtemp Yes 1, 2(²), 3 "Hydraulic AC motor power pack over-
temp. Higher than
120°C/248°F."
Stop running and wait for tempera-
ture to drop.
29 AC Motor Sensor Fail 2(²), 3 "Hydraulic AC motor power pack temp
sensor open curicuit"
Check sensor cables.
30 Temperature Warning Yes 2(²), 3(²)High temperature warning. Warns that the motor temperature is
getting high.
31 Motor Overtemp Yes 1, 2(²), 3 High temperature Alarm. See SAC manual for more details.
32 VFD Warning Yes 2(²), 3 There is an warning from VFD. Check VFD for more details.
33 VFD Not Ready Yes 2(²), 3 The VFD is not ready. Check VFD for more details.
34 VFD Fault 1, 2(²), 3 VFD has an Alarm. Check VFD for more details.
35 Warning Low Voltage Yes 2(²), 3(²)Low motor voltage warning when motor
is running.
12V thruster below 9.30V
24V thruster below 17.50V
36 Not Calibrated Yes 2(²), 3 Shaft Not Calibrated See manual for how to calibrate.
37 VFD Com. Fault 2(²), 3 No Modbus communication with VFD Check VFD Modbus cables and
power.
38 Cooling Fan Fault 2(²), 3 Cooling fan stopped running, or running
too slow
Device must be sent for service
39 Interlock 2(²), 3 S-link communication between PPC and
retract controller are missing
-Check PPC or retract controller has
power.
-Check S-Link connections to PPC
and retract controller.
-Check if not PPC or SR150000/
SR61242 is wrongly setup as SRP or
SRVP/SRLP.

11
6032 32 019
-
SEP user manual
Alarm Descriptions
EN MC_0053
1. PPC520, PPC820, PPC800, PPC840
2. Buzzer is only activated when any device is sending thrust on the S-link bus.
"Err.
No." Errors shown in display "Auto Reset"
"Ext. buzzer
activation at
Alert Level"
Description Action
19 Actuator Fault 2(²), 3 Actuator not getting any power "Check actuator connection or pow-
er to actuator. Reset alarm in alarm
menu on PJC 211/212/221/222 or
recycle power."
20 Pos.Sensor Fault 2(²), 3 Retract position sensor fail Check position sensor cables and
for sensor damage.
21 In Service Mode Yes 2(²), 3 "Retract controller in service mode. Switch
no. 4 is ON."
Check dipswitch setting on retract
control box.
22 High Oil Temp Yes 1, 2(²), 3 "Hydraulic oil temperature is higher than
75°C /167°F."
"Stop running and wait for tempera-
ture to drop.
Check if cooling pump is running."
23 Low Oil Level 1, 2(²), 3 Hydraulic oil lewel is to low Fill more hydraulic oil to the hydrau-
lic tank.
24 Warning Return Filter Yes 2(²), 3 Return fi lter element requiered
replacing.
25 Warning Pressure Filter Yes 2(²), 3 Pressure fi lter element requiered
replacing.
26 Warning High Speed Yes 1, 2(²), 3 "WARNING! High Speed.
Stabilizer not active!"
27 Stabilizer Fault Yes 1, 2(²), 3 Any Stabilizer alarm. See stabilizer panel for more info.
28 AC Motor Overtemp Yes 1, 2(²), 3 "Hydraulic AC motor power pack over-
temp. Higher than
120°C/248°F."
Stop running and wait for tempera-
ture to drop.
29 AC Motor Sensor Fail 2(²), 3 "Hydraulic AC motor power pack temp
sensor open curicuit"
Check sensor cables.
30 Temperature Warning Yes 2(²), 3(²)High temperature warning. Warns that the motor temperature is
getting high.
31 Motor Overtemp Yes 1, 2(²), 3 High temperature Alarm. See SAC manual for more details.
32 VFD Warning Yes 2(²), 3 There is an warning from VFD. Check VFD for more details.
33 VFD Not Ready Yes 2(²), 3 The VFD is not ready. Check VFD for more details.
34 VFD Fault 1, 2(²), 3 VFD has an Alarm. Check VFD for more details.
35 Warning Low Voltage Yes 2(²), 3(²)Low motor voltage warning when motor
is running.
12V thruster below 9.30V
24V thruster below 17.50V
36 Not Calibrated Yes 2(²), 3 Shaft Not Calibrated See manual for how to calibrate.
37 VFD Com. Fault 2(²), 3 No Modbus communication with VFD Check VFD Modbus cables and
power.
38 Cooling Fan Fault 2(²), 3 Cooling fan stopped running, or running
too slow
Device must be sent for service
39 Interlock 2(²), 3 S-link communication between PPC and
retract controller are missing
-Check PPC or retract controller has
power.
-Check S-Link connections to PPC
and retract controller.
-Check if not PPC or SR150000/
SR61242 is wrongly setup as SRP or
SRVP/SRLP.

PHC-3 Alarm Descriptions
EN MC_0117
Fault Code Description Cause Action
10500.0.10 PHC Oil Level - Level Low Hydraulic oil level is low
-Limit the use of thruster
-Inspect hydraulic oil level
-Check system for leaks and refi ll hydraulic oil
10500.0.13 PHC Oil Level - Open Circuit Analog oil level sensor open circuit
-Sensor not connected or wire break.
-Verify sensor type in parameter 0201
-Disconnect sensor and measure that sensor resistance value is in
range 0-180ohm.
10501.0.11 PHC Oil Temp - Level High Oil temperature higher than 75°C (167°F)
-Limit the use of thruster to prevent temperature to rise.
-Check if the cooling pump is running and there is cooling water fl ow.
-Inspect seawater fi lter
-Verify that cooling pump is enabled in parameter 0301
10501.0.13 PHC Oil Temp - Open Circuit Analog oil temp sensor open circuit
-Sensor not connected or wire break.
- Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
-The wrong sensor is defi ned in parameter 0201
10501.0.16 PHC Oil Temp - Short Circuit Analog oil temp input short circuit
-Input shorted to GND, check wiring/sensor
-Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
10502.0.13 PHC Stablizier Pressure - Open Circuit Stabilizer pressure sensor open circuit
-Sensor not connected or wire break.
-System incorrectly confi gured with stabilizer, parameter 1001
-Replace sensor
10502.0.16 PHC Stablizier Pressure - Short Circuit Stabilizer pressure sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10502.0.19 PHC Stablizier Pressure - Under Limit Stabilizer pressure has dropped below 20bar.
-Check accumulator charge pressure
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
10502.0.20 PHC Stablizier Pressure - Over Limit
Stabilizer pressure is higher than:
set point + 30bar running from PTO
or set point + 15bar running from AC motor
-Check PTO pressure setting
-Check accumulator charge pressure
10502.0.26 PHC Stablizier Pressure - VALUE MAX Stabilizer pressure reached sensor max value.
-Check that the correct sensor is fi tted
-Check that sensor range parameter 1010 match the sensor
-Check PTO pressure setting
10502.0.200 PHC Stablizier Pressure - Timeout Stabilizer pressure has not reached 50% of setpoint parame-
ter 1003 after 30sec.
-Check the pump feed shutoff valve.
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
10503.0.13 PHC System Pressure - Open Circuit System pressure sensor open circuit -Sensor not connected or wire break.
-Verify system pressure, parameter 0104
10503.0.16 PHC System Pressure - Short Circuit System pressure sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10504.0.13 PHC AI 1 - Open Circuit Analog Input 1 (4-20mA) sensor open circuit -Sensor not connected or wire break.
10504.0.16 PHC AI 1 - Short Circuit Analog Input 1 (4-20mA) sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10505.0.13 PHC AI 2 - Open Circuit Analog Input 2 (4-20mA) sensor open circuit -Sensor not connected or wire break.
10505.0.16 PHC AI 2 - Short Circuit Analog Input 2 (4-20mA) sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10508.0.13 PHC DOUT AC PUMP UNLOAD - Open Circuit AC Pump Unload valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10508.0.51 PHC DOUT AC PUMP UNLOAD - Current High AC Pump Unload valve current higher than 4.0A -Check wires and connections for short circuit
10509.0.13 PHC DOUT ACCUMULATOR DUMP - Open
Circuit Accumulator Dump valve open circuit -Check for open circuit, power < 5.0 Watt -System incorrectly confi gured with stabilizer, parameter 1001
10509.0.51 PHC DOUT ACCUMULATOR DUMP - Current
High Accumulator Dump valve current higher than 4.0A -Check wires and connections for short circuit
10510.0.13 PHC DOUT STABILIZER - Open Circuit Stabilizer valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10510.0.51 PHC DOUT STABILIZER - Current High Stabilizer valve current higher than 4.0A -Check wires and connections for short circuit
10511.0.13 PHC DOUT COOLING PUMP HYDRAULIC -
Open Circuit Hydraulic Cooling Pump valve open circuit -Check for open circuit, power consumption < 5.0 Watt -Wrong cooling pump confi gured, parameter 0301
10511.0.51 PHC DOUT COOLING PUMP HYDRAULIC -
Current High Hydraulic Cooling Pump valve current higher than 4.0A -Check wires and connections for short circuit
10512.0.13 PHC DOUT LS DUMP - Open Circuit LS-Dump valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System wrong confi gured with thrusters, parameter 2001 or 2101
10512.0.51 PHC DOUT LS DUMP - Current High LS-Dump valve current higher than 4.0A -Check wires and connections for short circuit
10513.0.51 PHC DOUT PUMP #2 - Current High Pump #2 valve current higher than 4.0A -Check wires and connections for short circuit
10514.0.13 PHC DOUT 5 - Open Circuit Digital Output 5 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0505
10514.0.51 PHC DOUT 5 - Current High Digital Output 5 current higher than 4.0A -Check wires and connections for short circuit
10515.0.13 PHC DOUT 6 - Open Circuit Digital Output 6 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0506
10515.0.51 PHC DOUT 6 - Current High Digital Output 6 current higher than 4.0A -Check wires and connections for short circuit
10516.0.13 PHC DOUT 3 - Open Circuit Digital Output 3 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0503
10516.0.51 PHC DOUT 3 - Current High Digital Output 3 current higher than 4.0A -Check wires and connections for short circuit
12 6032 32 019
-
SEP user manual

PHC-3 Alarm Descriptions
EN MC_0117
Fault Code Description Cause Action
10500.0.10 PHC Oil Level - Level Low Hydraulic oil level is low
-Limit the use of thruster
-Inspect hydraulic oil level
-Check system for leaks and refi ll hydraulic oil
10500.0.13 PHC Oil Level - Open Circuit Analog oil level sensor open circuit
-Sensor not connected or wire break.
-Verify sensor type in parameter 0201
-Disconnect sensor and measure that sensor resistance value is in
range 0-180ohm.
10501.0.11 PHC Oil Temp - Level High Oil temperature higher than 75°C (167°F)
-Limit the use of thruster to prevent temperature to rise.
-Check if the cooling pump is running and there is cooling water fl ow.
-Inspect seawater fi lter
-Verify that cooling pump is enabled in parameter 0301
10501.0.13 PHC Oil Temp - Open Circuit Analog oil temp sensor open circuit
-Sensor not connected or wire break.
- Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
-The wrong sensor is defi ned in parameter 0201
10501.0.16 PHC Oil Temp - Short Circuit Analog oil temp input short circuit
-Input shorted to GND, check wiring/sensor
-Disconnect sensor and measure that sensor resistance value is in
range 104ohm-147Kohm
10502.0.13 PHC Stablizier Pressure - Open Circuit Stabilizer pressure sensor open circuit
-Sensor not connected or wire break.
-System incorrectly confi gured with stabilizer, parameter 1001
-Replace sensor
10502.0.16 PHC Stablizier Pressure - Short Circuit Stabilizer pressure sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10502.0.19 PHC Stablizier Pressure - Under Limit Stabilizer pressure has dropped below 20bar.
-Check accumulator charge pressure
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
10502.0.20 PHC Stablizier Pressure - Over Limit
Stabilizer pressure is higher than:
set point + 30bar running from PTO
or set point + 15bar running from AC motor
-Check PTO pressure setting
-Check accumulator charge pressure
10502.0.26 PHC Stablizier Pressure - VALUE MAX Stabilizer pressure reached sensor max value.
-Check that the correct sensor is fi tted
-Check that sensor range parameter 1010 match the sensor
-Check PTO pressure setting
10502.0.200 PHC Stablizier Pressure - Timeout Stabilizer pressure has not reached 50% of setpoint parame-
ter 1003 after 30sec.
-Check the pump feed shutoff valve.
-Check PTO pressure (if PTO powered)
-Check system for oil leaks
10503.0.13 PHC System Pressure - Open Circuit System pressure sensor open circuit -Sensor not connected or wire break.
-Verify system pressure, parameter 0104
10503.0.16 PHC System Pressure - Short Circuit System pressure sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10504.0.13 PHC AI 1 - Open Circuit Analog Input 1 (4-20mA) sensor open circuit -Sensor not connected or wire break.
10504.0.16 PHC AI 1 - Short Circuit Analog Input 1 (4-20mA) sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10505.0.13 PHC AI 2 - Open Circuit Analog Input 2 (4-20mA) sensor open circuit -Sensor not connected or wire break.
10505.0.16 PHC AI 2 - Short Circuit Analog Input 2 (4-20mA) sensor short circuit -Wires shorted or sensor defective, check wiring/sensor
-Replace sensor
10508.0.13 PHC DOUT AC PUMP UNLOAD - Open Circuit AC Pump Unload valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10508.0.51 PHC DOUT AC PUMP UNLOAD - Current High AC Pump Unload valve current higher than 4.0A -Check wires and connections for short circuit
10509.0.13 PHC DOUT ACCUMULATOR DUMP - Open
Circuit Accumulator Dump valve open circuit -Check for open circuit, power < 5.0 Watt -System incorrectly confi gured with stabilizer, parameter 1001
10509.0.51 PHC DOUT ACCUMULATOR DUMP - Current
High Accumulator Dump valve current higher than 4.0A -Check wires and connections for short circuit
10510.0.13 PHC DOUT STABILIZER - Open Circuit Stabilizer valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System incorrectly confi gured with stabilizer, parameter 1001
10510.0.51 PHC DOUT STABILIZER - Current High Stabilizer valve current higher than 4.0A -Check wires and connections for short circuit
10511.0.13 PHC DOUT COOLING PUMP HYDRAULIC -
Open Circuit Hydraulic Cooling Pump valve open circuit -Check for open circuit, power consumption < 5.0 Watt -Wrong cooling pump confi gured, parameter 0301
10511.0.51 PHC DOUT COOLING PUMP HYDRAULIC -
Current High Hydraulic Cooling Pump valve current higher than 4.0A -Check wires and connections for short circuit
10512.0.13 PHC DOUT LS DUMP - Open Circuit LS-Dump valve open circuit -Check for open circuit, power consumption < 5.0 Watt
-System wrong confi gured with thrusters, parameter 2001 or 2101
10512.0.51 PHC DOUT LS DUMP - Current High LS-Dump valve current higher than 4.0A -Check wires and connections for short circuit
10513.0.51 PHC DOUT PUMP #2 - Current High Pump #2 valve current higher than 4.0A -Check wires and connections for short circuit
10514.0.13 PHC DOUT 5 - Open Circuit Digital Output 5 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0505
10514.0.51 PHC DOUT 5 - Current High Digital Output 5 current higher than 4.0A -Check wires and connections for short circuit
10515.0.13 PHC DOUT 6 - Open Circuit Digital Output 6 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0506
10515.0.51 PHC DOUT 6 - Current High Digital Output 6 current higher than 4.0A -Check wires and connections for short circuit
10516.0.13 PHC DOUT 3 - Open Circuit Digital Output 3 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0503
10516.0.51 PHC DOUT 3 - Current High Digital Output 3 current higher than 4.0A -Check wires and connections for short circuit
PHC-3 Alarm Descriptions
EN MC_0117
Fault Code Description Cause Action
10517.0.13 PHC DOUT 2 - Open Circuit Digital Output 2 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0502
10517.0.51 PHC DOUT 2 - Current High Digital Output 2 current higher than 4.0A -Check wires and connections for short circuit
10518.0.13 PHC DOUT 1 - Open Circuit Digital Output 1 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0501
10518.0.51 PHC DOUT 1 - Current High Digital Output 1 current higher than 4.0A -Check wires and connections for short circuit
10519.0.13 PHC DOUT 4 - Open Circuit Digital Output 4 is confi gured as crossover and output is open
circuit
-Check for open circuit, power consumption < 5.0 Watt
-Output confi gured wrong, parameter 0504
10519.0.51 PHC DOUT 4 - Current High Digital Output 4 current higher than 4.0A -Check wires and connections for short circuit
10520.0.51 PHC ECI PUMP POWER FEED - Current High ECI cooling pump power current higher than 8.0A
-Check pump cable for damage and short circuits
-Make sure the connector on the cooling pump is correctly inserted.
-Replace cooling pump
10521.0.51 PHC Bow Thruster Power - Current High Bow thruster PVG feed current higher than 3.0A -Check PVG wires and connections for short circuit
10522.0.51 PHC Stern Thruster Power - Current High Stern thruster PVG feed current higher than 3.0A -Check PVG wires and connections for short circuit
10523.0.51 PHC Thruster Power - Current High Bow or Stern PVG feed current higher than 3.3A Check all bow and stern PVG signal wires for short circuits
10524.0.51 PHC ECI Cooling Pump - Current High ECI cooling pump current higher than 13.0A -Check ECI cooling pump cable for damage and short circuits
-Replace ECI cooling pump
10524.0.53 PHC ECI Cooling Pump - Overvoltage ECI cooling pump overvoltage, voltage higher than 33.0V -Check PHC-3 input voltage is below 33.0V
-Replace ECI cooling pump
10524.0.54 PHC ECI Cooling Pump - Undervoltage ECI cooling pump under voltage, voltage is lower than 18.0V -Check PHC-3 input voltage is higher than 18.0V
-Replace ECI cooling pump
10524.0.55 PHC ECI Cooling Pump - Overtemp ECI cooling pump temperature higher than 100°C (212°F) -Check ECI cooling pump for damages
-Replace ECI cooling pump
10524.0.100 PHC ECI Cooling Pump - No Communication No communication with ECI cooling pump
-Check if ECI pump is connected
-Check wires to ECI pump for open circuits
-Check power supply cooling pump
-Wrong cooling pump confi gured, parameter 0301
10524.0.205 PHC ECI Cooling Pump - HW FAULT ECI cooling pump hardware fault -Replace ECI cooling pump
10526.0.0 PHC ECI Cooling Pump Blocked - - ECI cooling pump is blocked
-Reset fault and if fault reappears, cooling pump need service or
replacement.
-Check pump inlet for obstacles
10527.1.0 PHC VFD Not Ready Instance 1 - VFD not ready -VFD external run enable/power available signal is lost.
10528.1.10 PHC VFD ABB Parameter Instance 1 Level Low ABB ACS550 parameter values 2001 or 2002 cannot be a
negative value. -Check ABB ACS550 parameter 2001 and 2002.
10529.0.19 PHC ECI Cooling Pump Speed - Under Limit ECI pump motor speed under limit, below 100rpm -Check hose for dirt
-Check pump inlet for obstacles
10530.0.201 PHC PTO ENGINE INSTANCE - INIT FAIL Parameter 1011-PTO ENGINE INSTANCE is not defi ned -Set parameter 1011-PTO ENGINE INSTANCE
36000.1.24 ABB ACS550 Instance 1 Fault ABB ACS550 fault See ABB ACS550 drive for more details
36002.1.24 VACON Instance 1 Fault VACON VFD Fault See VACON drive for more details
36100.1.100 VFD Instance 1 No Communication Lost communication with VFD -VFD not powered up
-VFD communication cable not connected or incorrectly wired
36103.1.0 VFD IN LOCAL Instance 1 - VFD in local mode -Switch VFD to remote mode
PDC-301 Alarm Descriptions
EN MC_0119
Fault Code Description Cause Action
10600.0.208 SR150000 Fault - INTERLOCK Retract Interlock
-Check if retract is depoyed.
-No communication with Retract Controller, check Retract Controller
has power.
-Check PDC-301 and Restract Controller setup.
36100.1.24 VFD Instance 1 Fault VFD faulted -See VFD for more information
36100.1.100 VFD Instance 1 No Communication PDC-301 has no MODBUS communication with VFD. -Check communication cable with VFD
-Check if VFD has power
36101.1.200 VFD PMS Instance 1 Timeout VFD is not ready within 60 after power reqest. -Check if VFD has power
36101.1.204 VFD PMS Instance 1 SIGNAL LOST Lost Power Management signal from VFD, VFD not avilable
anymore. -Check VFD for more information.
36103.1.0 VFD IN LOCAL Instance 1 - VFD in Local or Hand Mode -Change mode in VFD panel.
13
6032 32 019
-
SEP user manual

14 6032 32 019
-
SEP user manual
MC_0047
MC_0047
Maintenance
Oil Change
EN
EN
As a part of the seasonal service of your Thruster before every season, always check that:
• The propeller is fastened securely to the gear leg.
• Bolts holding the thruster components together are fastened securely.
• The area around the thruster is clean and dry. Ensure there are no signs of water.
• Paint the propeller and gear leg with antifouling before every season to keep it clean from sea growth. (NB: Never paint the anode, sealings or
propeller shaft. Ensure paint does not enter the space between the propeller and the gear leg. Ensure to use antifouling designed for
drivers)
• Change the zinc anode before every season, or when half the anode has eroded. Always use a sealant or thread glue on the holding screw to
ensure that it does not fall off . (NB: In some water conditions, it may be necessary to install an extra zinc anode to ensure that it lasts for
the whole period between regular service lifts of the boat. Consult your dealer for information on how to do this.)
• Drain oil after fi rst 50 hours of runtime, then with 500 hours runtime intervals. Refi ll with GL-5 gear oil if needed.
• Change the gear oil a minimum of every second year. Check the gear oil quality in the guardhouse every time the boat is out of the water.
• If there is a problem with your Ignition Protected stern thruster, please contact your dealer.
OIL LUBRICATION GEAR LEGS: There must always be oil in the oil reservoir. Refi ll if necessary with gear oil EP90. Change the gear oil a minimum
of every second year. Check the gear oil quality in the gear house every time the boat is out of the water.
2. To drain the gear leg unscrew lower oil drain screw.
3. Unscrew upper oil drain screw.
4. The oil will drain out from the gear leg.
5. Attach oil fi lling equipment to the lower oil drain hole. (M8)
6. Pump oil until oil is fl owing out of the upper oil drain hole. (Approx. 200ml)
7. Tighten upper oil drain screw.
8. Remove oil fi lling equipment.
9. Tighten the lower oil drain screw.
!Please refer to the graphic for special considerations relating to your model !
!Please refer to the graphic for special considerations relating to your model !
MG_0148
KEY:
1. Hydraulic Motor
2. Mounting Plate
3. Motorbracket
4. Flexible coupling
5. Gear Leg (Pre filled)
6. Propeller
7. Anode
8. Drive pin
9. Washer
10. Lock Nut
11. Fastening Screw for anode
12. Oil drain screw
13. Shaft Key
14. Anode pins
SH
* 100
* 160
* 240
SH
* 320
SH
* 420
* 550
SH
* 700
* 1000
* 1400
11
13
11
11
10
10
10
9
9
9
8
8
7
7
7
7
7
7
6
6
6
6
6
6
5
5
5
5
5
5
4
4
4
3
3
3
2
2
2
1
1
1
11
14
12
12
13
10
9
7
7
6
6
5
5
4
3
2
1

15
6032 32 019
-
SEP user manual
MG_0148
KEY:
1. Hydraulic Motor
2. Mounting Plate
3. Motorbracket
4. Flexible coupling
5. Gear Leg (Pre filled)
6. Propeller
7. Anode
8. Drive pin
9. Washer
10. Lock Nut
11. Fastening Screw for anode
12. Oil drain screw
13. Shaft Key
14. Anode pins
SH
* 100
* 160
* 240
SH
* 320
SH
* 420
* 550
SH
* 700
* 1000
* 1400
11
13
11
11
10
10
10
9
9
9
8
8
7
7
7
7
7
7
6
6
6
6
6
6
5
5
5
5
5
5
4
4
4
3
3
3
2
2
2
1
1
1
11
14
12
12
13
10
9
7
7
6
6
5
5
4
3
2
1

MC_0161
Seasonal Checklist
EN
CHECK TO PERFORM DATE
The propeller is fastened securely to the gear leg. Bolts holding the thruster components together are fastened securely. The area around the thruster is clean and dry. If there are signs of water, try to fi nd the source and eliminate it. Paint the propeller and gear leg with antifouling. batteries are in good condition. All electrical connections are clean and fastened fi rmly. Check the drive shaft in the retract mechanism is lubricated. Check for excess movement in the break-away rings securing the actuator. Change the zinc anode. Check oil in the oil reservoir. *REPLACE EVERY 2 YEARS
16 6032 32 019
-
SEP user manual

MC_0161
Seasonal Checklist
EN
CHECK TO PERFORM DATE
The propeller is fastened securely to the gear leg. Bolts holding the thruster components together are fastened securely. The area around the thruster is clean and dry. If there are signs of water, try to fi nd the source and eliminate it. Paint the propeller and gear leg with antifouling. batteries are in good condition. All electrical connections are clean and fastened fi rmly. Check the drive shaft in the retract mechanism is lubricated. Check for excess movement in the break-away rings securing the actuator. Change the zinc anode. Check oil in the oil reservoir. *REPLACE EVERY 2 YEARS
17
6032 32 019
-
SEP user manual
1. The equipment manufactured by Sleipner Motor AS (The “Warrantor”) is warranted to be free from defects in workmanship and materials under normal
use and service.
2. This Warranty is in eff ect for of two years (Leisure Use) or one year (Commercial use) from the date of purchase by the user. Proof of purchase must be
included, to establish that it is inside the warranty period.
3. This Warranty is transferable and covers the product for the specifi ed time period.
4. In case any part of the equipment proves to be defective, other than those parts excluded in paragraph 5 below, the owner should do the following:
(a) Prepare a detailed written statement of the nature and circumstances of the defect, to the best of the Owner’s knowledge, including the date of
purchase, the place of purchase, the name and address of the installer, and the Purchaser’s name, address and telephone number;
(b) The Owner should return the defective part or unit along with the statement referenced in the preceding paragraph to the warrantor,
Sleipner Motor AS or an authorized Service Centre, postage/shipping prepaid and at the expense of the Purchaser;
(c) If upon the Warrantor’s or Authorized Service Centre’s examination, the defect is determined to result from defective material or workmanship, the
equipment will be repaired or replaced at the Warrantor’s option without charge, and returned to the Purchaser at the Warrantor’s expense;
(d) no refund of the purchase price will be granted to the Purchaser, unless the Warrantor is unable to remedy the defect after having a reasonable
number of opportunities to do so. Prior to refund of the purchase price, Purchaser must submit a statement in writing from a professional boating
equipment supplier that the installation instructions of the Installation and Operation Manual have been complied with and that the defect remains;
(e) warranty service shall be performed only by the Warrantor, or an authorized Service Centre, and any attempt to remedy the defect by anyone else
shall render this warranty void.
5. There shall be no warranty for defects or damages caused by faulty installation or hook-up, abuse or misuse of the equipment including exposure to
excessive heat, salt or fresh water spray, or water immersion except for equipment specifi cally designed as waterproof.
6. No other express warranty is hereby given and there are no warranties which extend beyond those described in section 4 above. This Warranty is
expressly in lieu of any other expressed or implied warranties, including any implied warranty of merchantability, fi tness for the ordinary purposes for
which such goods are used, or fi tness for a particular purpose, and any other obligations on the part of the Warrantor or its employees and
representatives.
7. There shall be no responsibility or liability whatsoever on the part of the Warrantor or its employees and representatives for injury to any person or
persons, or damage to property, loss of income or profi t, or any other consequential or resulting damage or cost which may be claimed to have been
incurred through the use or sale of the equipment, including any possible failure or malfunction of the equipment, or part thereof.
8. The Warrantor assumes no liability for incidental or consequential damages of any kind including damages arising from collision with other vessels
or objects.
9. This warranty gives you specifi c legal rights, and you may also have other rights which vary from country to country.
For the most up to date documentation, we advise you to
visit our website www.side-power.com for the spare parts
list.
Spare Parts
Warranty statement
EN
EN
MC_0024
MC_0024

MC_0037
Notes
EN
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
18 6032 32 019
-
SEP user manual

MC_0037
Notes
EN
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
MC_0037
Notes
EN
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
19
6032 32 019
-
SEP user manual

MC_0037
Notes
EN
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
..................................................................................................................................................................................................................................................
20 6032 32 019
-
SEP user manual
