CHAPTER 1 Getting Started
The HE40T is a revolutionary new low cost bar code reader that
employs Siemens’ industry leading Direct Part Mark (DPM)
reading technology. Developed to be the first universal reader, no
other single device performs as many functions. With a cost of
ownership far less than comparable systems, the HE40T
incorporates a unique dual path optical system, a 1.3 million pixel
CMOS sensor, and a 400 MHz processor. This combination has
created a reading system that supports:
• DPM applications
• Department of Defense Unique Identification (DoD UID)
• High density matrix codes and larger low density linear
barcodes
• Superior working range
• High-speed omni-directional decoding
• Cordless and cabled interfaces
• Unsurpassed data rates
The HE40T features a variety of accessories including ruggedized
handles. For more information or for technical support, see the
Preface of the HE40T User Manual.

2HE40T Quickstart Guide Rev 1.0.1, Dec. 2006
Attaching the H2 Cabled Handle
The HE40T uses the battery compartment to “snap to” the handle.
Figure 1–1 shows the H2 handle with flexible connector.
Figure 1–2 shows the battery blank.
FIGURE 1–1. H2 Handle with Flexible Connector
FIGURE 1–2. H2 Handle with Battery Blank
To attach the handle to the reader:
1. Push the 8-pin DIN connector at the end of the reader into the
flexible connector at the end of the handle, as shown in
Figure 1–3.
Flexible Connector

Rev 1.0.1, Dec. 2006 HE40T Quickstart Guide 3
FIGURE 1–3. Attaching the H2 Handle
2. Insert the tab on the back of the handle into the reader
(Figure 1–3).
3. Snap the reader onto the handle, matching the battery
compartment to the battery connectors, visible inside the
handle, as shown in Figure 1–3.
The HE40T can be secured further with threaded screws on the
under side of the handle, and on the end of the flexible connector, as
shown in Figure 1–4.
FIGURE 1–4. Location of Threaded Screws
Flexible
Connector

4HE40T Quickstart Guide Rev 1.0.1, Dec. 2006
Attaching the BH1/BH2 Battery Handle
The HE40T uses the battery compartment to “snap to” the handle.
The BH1/BH2 handle is shown in Figure 1–5. The handle with
battery is shown in Figure 1–6.
FIGURE 1–5. BH1/BH2 Handle
FIGURE 1–6. BH1/BH2 Handle with Battery
To attach the handle to the reader:
1. Insert the tab on the back of the handle into the reader, as
shown in Figure 1–7.
2. Snap the reader onto the handle, matching the battery
compartment to the battery connectors, visible inside the
handle, as shown in Figure 1–7.

Rev 1.0.1, Dec. 2006 HE40T Quickstart Guide 5
FIGURE 1–7. Attaching the BH1/BH2 Handle
The HE40T can be secured further with threaded screws on the
under side of the handle, as shown in Figure 1–8.
FIGURE 1–8. Location of Threaded Screws

6HE40T Quickstart Guide Rev 1.0.1, Dec. 2006
HE40T Wireless
This HE40T features a Bluetooth® wireless radio. The radio allows
for point to point wireless communication with other Bluetooth
devices that support serial port protocol (SPP). The following
information will give you general instructions on connecting your
HE40T to a desktop or laptop computer with a Bluetooth radio.
Connecting With A QuickConnect Code
If you purchased a CodeXML Bluetooth Modem or a Belkin®
Bluetooth adapter from Siemens or from an authorized distributor, a
QuickConnect code was included, as shown in Figure 1–9.
FIGURE 1–9. Sample QuickConnect Code
The QuickConnect code has the information of the Bluetooth
address (often a reference to go to the BD_ADDR) of that device.
You can usually find the 12-character Bluetooth address
somewhere on the device near the device’s serial number
(Figure 1–10). This code will link your HE40T directly to the
desired Bluetooth device.
FIGURE 1–10. Locating the Bluetooth Address
HE40T Wireless Setup
Note: While installing the Bluetooth Configuration Manager
software that was included with your Bluetooth adapter, make sure
to note the Virtual COM Port number the software assigned for the
adapter (e.g., COM 10). This is the COM Port your HE40T will
connect through.
Sample Code

Rev 1.0.1, Dec. 2006 HE40T Quickstart Guide 7
To connect your reader:
1. Scan the Reset to RF Factory Defaults code shown in
Figure 1–11.
FIGURE 1–11. Reset to RF Factory Defaults Code
2. Scan the QuickConnect code you received.
3. The HE40T will automatically connect. By default, the HE40T
will beep once after it connects and beep three times in a row if
it did not connect.
4. Scan the Save Settings code (Figure 1–12) to the right if you
want to save the wireless connection settings to the HE40T so
that the HE40T will automatically try to connect wirelessly the
next time it is powered on.
FIGURE 1–12. Save Settings Code
Radio Range and Transferring Data
The HE40T radio is a Class 1 device. If connected to another Class
1 device, the unit has roughly a 300 foot line of sight operating
range. If connecting to a Class 2 or Class 3 device, the operating
range may drop to match the lower range. Once a unit is connected,
the application software on the host must be open to receive data.
When the HE40T detects the radio is out of range, the HE40T will
store data on the reader’s non-volatile memory.
Reset to RF
Factory Defaults QuickConnect (Sample)
Scan the QuickConnect code
that matches the Bluetooth
address of your device
Save Settings

8HE40T Quickstart Guide Rev 1.0.1, Dec. 2006
For more information about setting up and using the HE40T with a
wireless Bluetooth configuration, consult the HE40T User Manual.
HE40T Cables
The HE40T is available with USB, RS-232 and PS2 cables. All of
the cables are connected to the HE40T with a 8-pin DIN connector.
Different cables may be required for different hosts.
• HE40T with H2 Cabled Handle — The 8-pin DIN connection
is at the bottom of the handle. Firmly push the 8-pin connector
into the bottom of the handle. The cable has a locking
mechanism that will firmly hold the cable in place
(Figure 1–13). To detach the cable from the reader, you must
pinch the plastic on the 8-pin DIN (Figure 1–13) and pull back
to disengage the connector.
FIGURE 1–13. Handle with Cable Attached
Install the optional cable clip to further secure the cable to the
handle with two threaded screws, as shown in Figure 1–14.
FIGURE 1–14. Securing Cable Clip with Two Threaded Screws

Rev 1.0.1, Dec. 2006 HE40T Quickstart Guide 9
• HE40T with BH1/BH2 Battery Handle — Firmly push the
8-pin connector into the back end of the reader, as shown in
Figure 1–15. The cable has a locking mechanism that will
firmly hold the cable in place. To detach the cable from the
reader, you must pinch the plastic on the 8-pin DIN and pull
back to disengage the connector.
FIGURE 1–15. Handle with Cable Attached
USB Cable Connection
1. Attach the USB cable to the HE40T.
2. Connect the USB cable to the host in any available USB host
port, as shown in Figure 1–16. You DO NOT need to power off
your host computer.
FIGURE 1–16. Connecting the USB Cable
3. Once properly connected to the host computer, the HE40T will
power on and beep. The reader is shipped pre-configured.

10 HE40T Quickstart Guide Rev 1.0.1, Dec. 2006
PS2 Cable Connection
1. Power off the host computer. This process requires shutting
down your computer. If you disconnect your computer
keyboard while it is running, your computer will lock up.
2. Attach the PS2 cable to the HE40T.
3. If you have a cabled keyboard, detach the keyboard cable from
your computer and connect that same connector to the female
connection on the HE40T PS2 cable, as shown in Figure 1–17.
FIGURE 1–17. Connecting the Keyboard Cable
4. Now, connect the male HE40T PS2 connector into the
keyboard port on your computer, as shown in Figure 1–18.
FIGURE 1–18. Connecting the PS2 Connector to Your Computer
Table of contents
Other Siemens Barcode Reader manuals
