Siemens SIMATIC MV320 User manual

SIMATIC MV320 / SIMATIC MV325
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC Ident
Handheld reading systems
SIMATIC MV320 / SIMATIC MV325
Operating Instructions
08/2015
C79000
-G8976-C352-03
Preface
Safety notes
1
Description
2
Installing and connecting
(SIMATIC MV325)
3
Connecting (SIMATIC
MV320)
4
Commissioning
5
Operation
6
Alarm, error and system
messages
7
Service and maintenance
8
Technical data
9
Dimension drawings
10
Ordering data
11
Appendix
A

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNB
ERG
GERMANY
C79000-G8976-C352-03
Ⓟ
09/2015 Subject to change
Copyright © Siemens AG 2013 - 2015.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 3
Preface
Validity of these operating instructions
This document contains information on the products listed below.
Valid for devices with the following article numbers
Article number
Device
6GF3320-0HT01
SIMATIC MV320
6GF3325-0HT01
SIMATIC MV325
The SIMATIC MV320 and SIMATIC MV325 readers are sophisticated, powerful, and
versatile handheld barcode readers. Typical areas of application: Health care, pharmacy,
retail trade and manufacturing.
SIMATIC MV320
SIMATIC MV325
Product designation
In the remainder of this document, the term "device" or "reader" or "handheld reader" is also
used instead of the full product name "SIMATIC MV320" or "SIMATIC MV325".

Preface
SIMATIC MV320 / SIMATIC MV325
4Operating Instructions, 08/2015, C79000-G8976-C352-03
Purpose of the operating instructions
Note
The operating instructions contain all the important information about the device
Read the operating instructions before starting to work with this device.
Noting and acting on this information:
•
Ensures the device functions correctly
•
Saves you service costs
These operating instructions contain all the information you need for commissioning and
using the device.
It is intended both for persons who connect up the device electrically and commission and
operate it as well as for service technicians and maintenance technicians.
New in this release
●Revision of contents and editing
●Code configuration section updated and removed from manual.
Replaced operating instructions
These operating instructions replace the operating instructions edition 03/2014.
Current operating instructions on the Internet
You will also find the latest version of these operating instructions on the Internet pages of
Siemens Industry Online Support under the following entry ID:
78905254 (https://support.industry.siemens.com/cs/ww/en/view/78905254)
Additional documentation
A current list of the code configurations mentioned in this manual is available in the manuals:
●SIMATIC MV320 Configuration guide
(https://support.industry.siemens.com/cs/ww/en/ps/15160/man)
●SIMATIC MV325 Configuration guide
(https://support.industry.siemens.com/cs/ww/en/ps/15161/man)
Environmental protection
Devices described in this programming manual can be recycled owing to the low content of
noxious substances in their version. Please contact a certified waste disposal company for
eco-friendly recycling and to dispose of your old devices.

Preface
SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 5
History
Previous editions of these operating instructions:
Edition
Remark
12/2013
First edition
08/2015 Revision of contents and editing
Code configuration section updated and removed from manual.
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, solutions, machines, equipment and/or networks. They are
important components in a holistic industrial security concept. With this in mind, Siemens’
products and solutions undergo continuous development. Siemens recommends strongly
that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable
preventive action (e.g. cell protection concept) and integrate each component into a holistic,
state-of-the-art industrial security concept. Third-party products that may be in use should
also be considered. For more information about industrial security, visit
http://www.siemens.com/industrialsecurity.
To stay informed about product updates as they occur, sign up for a product-specific
newsletter. For more information, visit http://support.automation.siemens.com.

Preface
SIMATIC MV320 / SIMATIC MV325
6Operating Instructions, 08/2015, C79000-G8976-C352-03

SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 7
Table of contents
Preface ................................................................................................................................................... 3
1 Safety notes............................................................................................................................................ 9
2 Description............................................................................................................................................ 11
2.1 Product package .....................................................................................................................11
2.2 SIMATIC MV320 .....................................................................................................................12
2.3 SIMATIC MV325 .....................................................................................................................13
3 Installing and connecting (SIMATIC MV325) ......................................................................................... 15
3.1 Mounting the charging station.................................................................................................15
3.2 Mounting the charging station with base plate and rubber feet..............................................16
3.3 Charging station with base plate secured to a working surface .............................................19
4 Connecting (SIMATIC MV320) .............................................................................................................. 21
4.1 Connecting and removing cables ...........................................................................................21
4.2 Connector assignment USB and RS-232 cable .....................................................................22
4.3 Connector assignment reader ................................................................................................24
5 Commissioning ..................................................................................................................................... 25
5.1 Inserting and removing the battery (SIMATIC MV325)...........................................................25
5.2 Charging the reader (SIMATIC MV325) .................................................................................25
5.3 Turn the reader on ..................................................................................................................27
5.4 Establishing a Bluetooth connection (SIMATIC MV325) ........................................................28
6 Operation.............................................................................................................................................. 29
6.1 Working with the SIMATIC MV320 reader..............................................................................29
6.2 Aligning the SIMATIC MV325 reader......................................................................................31
6.3 Setting the communication mode (SIMATIC MV325).............................................................32
6.4 Communication in batch mode (SIMATIC MV325).................................................................33
6.5 Codes with enabled factory setting.........................................................................................35
6.6 Codes with disabled factory setting ........................................................................................36
6.7 Enabling "Suffix - Enter"..........................................................................................................38
7 Alarm, error and system messages ....................................................................................................... 39
7.1 Feedback from the reader ......................................................................................................39
7.2 Charge status displays of the battery (SIMATIC MV325).......................................................40
7.3 Batch mode display (SIMATIC MV325) ..................................................................................41

Table of contents
SIMATIC MV320 / SIMATIC MV325
8Operating Instructions, 08/2015, C79000-G8976-C352-03
8 Service and maintenance...................................................................................................................... 43
9 Technical data ...................................................................................................................................... 45
10 Dimension drawings.............................................................................................................................. 49
11 Ordering data........................................................................................................................................ 51
A Appendix .............................................................................................................................................. 53
A.1 Code configurations ............................................................................................................... 53
A.2 "Specify character length to be read" function....................................................................... 54
A.3 Service and Support .............................................................................................................. 57
A.4 Certificates and approvals ..................................................................................................... 59
A.4.1 FCC information..................................................................................................................... 61
A.4.2 IC-FCB information ................................................................................................................ 62
Index .................................................................................................................................................... 63

SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 9
Safety notes
1
Alterations to the device
CAUTION
Alterations to the devices are not permitted.
Failure to observe this requirement shall constitute a revocation of the radio equipment
approval, CE approval and warranty. Therefore do not make any alterations to the device.
Repairs
WARNING
Personal injury or equipment damage due to unauthorized opening or repairing
Unauthorized opening or repairing of the device can lead to personal injury or equipment
damage. Therefore do not carry out repairs yourself. Repairs may only be carried out by
authorized qualified personnel at the manufacturer's site. See section Service and
maintenance (Page 43).
Proper disposal and recycling
The HMI devices described in these Operating Instructions can be recycled due to the low
levels of pollutants. Contact a certified disposal service company for environmentally sound
recycling and disposal of your old devices.
When disposing of batteries, observe the locally applicable legal regulations.

Safety notes
SIMATIC MV320 / SIMATIC MV325
10 Operating Instructions, 08/2015, C79000-G8976-C352-03
Adherence to FCC requirements
NOTICE
Adherence to FCC requirements for RF radiation
To adhere to the FCC requirements relating to the effects of RF radiation, this device must
not be operated beside or in conjunction with other antennas or transmitting devices.
NOTICE
Changes or modifications to the device
Changes or modifications not expressly approved by the person responsible for adherence
to the relevant regulations could result in the loss of the user's operating approval for the
device.

SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 11
Description
2
2.1
Product package
SIMATIC MV320
The SIMATIC MV320 reader (article number 6GF3320-0HT01) is supplied with the following
components:
●SIMATIC MV320 handheld reader
The reader can be used on the USB or RS-232 interface. To use the RS-232 interface, you
need to order the RS-232 cable and, if necessary, the appropriate power supply as
accessories.
SIMATIC MV325
The SIMATIC MV325 reader (article number 6GF3325-0HT01) is supplied with the following
components:
●SIMATIC MV325 handheld reader with battery, charging station and USB cable (0.9 m)
The charging station has a USB interface and a Bluetooth wireless interface.

Description
2.2 SIMATIC MV320
SIMATIC MV320 / SIMATIC MV325
12 Operating Instructions, 08/2015, C79000-G8976-C352-03
2.2
SIMATIC MV320
Characteristics and areas of application
Due to the following features, the reader is also suitable for demanding applications.
●Due to the optical dual-field platform, the SIMATIC MV320 can read wide and extremely
small barcodes.
●Thanks to intuitive targeting, 1D and 2D barcodes as well as barcodes belonging to postal
services can be read reliably and at little expense.
●Thanks to glare control, barcodes can be read from bottles, packed foodstuffs and cans
without any problem.
Whether in health care, retail trade or in other areas of application with intensive use - the
plastic housing, which is resistant to disinfectants and has degree of protection IP54,
protects the performance and the working lifetime of the reader from aggressive cleaning
agents, dust, penetration of water and even being dropped.
Are you on the move, working in different environments or do you need to read codes
accurately on a large number of items? If so, the SIMATIC MV320 will be a valuable addition
to your equipment.
Areas of application
●Health care
●Mobile voucher or ticket reader (events, air tickets, cinema etc.)
●Pharmacy
●Retail trade and manufacturing
●Reading strongly reflecting barcodes
Overview of the functions and benefits
●Available on a stand or as a handheld device.
●Manual or automatic triggering
●Feedback on correct read function with programmable LED display, acoustic signal and
vibration.
●Optional metal stand
●Efficient current consumption

Description
2.3 SIMATIC MV325
SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 13
2.3
SIMATIC MV325
Characteristics and areas of application
Due to the following features, the reader is also suitable for demanding applications.
●The super fast and extremely durable device works with a high-performance scan engine
for recognition of all 1D and 2D barcodes, as well as barcodes of individual postal
services.
●With its patented dual-field optics, both wide and very small barcodes can be read.
●With the patented glare control technology, codes on shining surfaces can be reliably
detected.
●The long-life batteries of the device with their fast triggering mechanism measure the
battery charge level precisely and show the remaining lifetime of the battery in a 4 LED
level display at the press of a button.
●The charging station is available with an integrated Bluetooth modem.
●The housing, which is resistant to disinfectants and has degree of protection IP65,
prevents damage to plastic parts and protects the electronics and optics.
Areas of application
●Health care
●Manufacturing
●Retail trade
●Warehouse management
●Reading strongly reflecting barcodes
Overview of the functions and benefits
●Light design: The reader weighs only 171 g.
●Long-life batteries with fast trigger mechanism.
●Charge status LED with charge display.
●Read confirmation by vibration, acoustic and LED signal.
●Fast, direction-independent reading of 1D and 2D barcodes and barcodes of postal
services.
●Compatible with Bluetooth-supported Android, iOS and Windows mobile devices and
tablets.
●The housing, which is resistant to disinfectants and has IP65, prevents damage to plastic
parts and protects the electronics and optics.
●Paging button supports the localization of the mobile reader.
●Reads barcodes on mobile devices.

Description
2.3 SIMATIC MV325
SIMATIC MV320 / SIMATIC MV325
14 Operating Instructions, 08/2015, C79000-G8976-C352-03

SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 15
Installing and connecting (SIMATIC MV325)
3
3.1
Mounting the charging station
You can mount the charging station according to your requirements:
●Charging station without base plate (Page 15)
●Charging station with base plate (Page 16)
●Secure charging station with base plate to a working surface (Page 19)
1. Insert the USB cable or power cable with the cylindrical side into the charging station.
Figure 3-1 Inserting the USB cable/power cable into the charging station
2. To prevent the station from slipping: Secure the rubber feet to the corners ①on the
underside of the charging station.
Figure 3-2 Charging station: Securing the rubber feet

Installing and connecting (SIMATIC MV325)
3.2 Mounting the charging station with base plate and rubber feet
SIMATIC MV320 / SIMATIC MV325
16 Operating Instructions, 08/2015, C79000-G8976-C352-03
The charging station is ready for use.
3.2
Mounting the charging station with base plate and rubber feet
1. Insert the USB cable or power cable with the cylindrical side into the charging station.
Figure 3-3 Inserting the USB cable/power cable into the charging station
For mounting the weighted base plate:
2. Lay the side of the base plate marked with "THIS SIDE DOWN" on the supporting
surface.
3. Place the charging station on the base plate.

Installing and connecting (SIMATIC MV325)
3.2 Mounting the charging station with base plate and rubber feet
SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 17
4. Secure the charging station with the supplied screws ②in the threaded holes ①of the
base plate.
Figure 3-4 Base plate: Threaded holes
Figure 3-5 Charging station: Tightening the screws
You have secured the charging station to the base plate.

Installing and connecting (SIMATIC MV325)
3.2 Mounting the charging station with base plate and rubber feet
SIMATIC MV320 / SIMATIC MV325
18 Operating Instructions, 08/2015, C79000-G8976-C352-03
5. To prevent the charging station from slipping: Secure the rubber feet to the round
markers ③on the underside of the base plate.
Figure 3-6 Base plate: Rubber feet markers ③
Figure 3-7 Base plate: Rubber feet ④secured
The charging station is ready for use.

Installing and connecting (SIMATIC MV325)
3.3 Charging station with base plate secured to a working surface
SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03 19
3.3
Charging station with base plate secured to a working surface
1. Insert the USB cable or power cable with the cylindrical side into the charging station.
Figure 3-8 Inserting the USB cable/power cable into the charging station
To mount the charging station on a working surface:
2. Lay the side of the base plate marked with "THIS SIDE DOWN" on the supporting
surface.
3. Secure the base plate to the working surface with screws through the pre-drilled mounting
holes ①.
Note
Mounting screws are not supplied with the product
Since the mounting surfaces can differ, the mounting screws are not sup
plied with the
product.
Figure 3-9 Base plate: Mounting holes

Installing and connecting (SIMATIC MV325)
3.3 Charging station with base plate secured to a working surface
SIMATIC MV320 / SIMATIC MV325
20 Operating Instructions, 08/2015, C79000-G8976-C352-03
4. Place the charging station on the secured base plate.
5. Secure the charging station with the supplied screws ②in the threaded holes ①of the
base plate.
Figure 3-10 Base plate: Threaded holes
Figure 3-11 Charging station: Tightening the screws
You have secured the charging station with the base plate on the working surface.
The charging station is ready for use.
