Siemens RV 5200 User manual

RV 5200 Bumperfit Color Rearview Camera
Installation and operating instructions
■Safety precautions
ATTENTION:
AInstallation may only be carried out by trained specialists! Observe all quality
standards of the automobile industry!
AConsult with your authorized car dealer if installation requires the drilling of holes or
other modifications of the vehicle.
AFire hazard! When drilling pay attention to the location of cable harnesses, tank and
fuel pipes! Never drill into car parts which are load-bearing or are important for safety
reasons!
AUse only the parts included with the unit to ensure proper installation. The use of
unauthorized parts can cause malfunctions.
ARoute and secure all wiring so it cannot touch any moving parts, such as the gear shift,
handbrake and seat rails. Do not route wiring in places that get hot, such as near the heater
outlet.
■Scope of delivery
1 Camera with 1.5 m connection cable
1 6 m Extension cable (also available as an accessory)
1 Mounting bracket (incl. screws and washers)
4 Self-tapping screws
1 Short instructions (English language)
1
© 2006 Siemens VDO Trading GmbH
All rights reserved.
These operating instructions are subject to copyright.
Subject to technical and visual changes and typing errors.

■Mounting examples
1. Bumperfit mounting
2. Mounting with bracket
2
7
21 85
364
Bumper
Align dot to the top
26 mm Ø
7
21
9
8
1112
5
364
13
Align dot to the top
10
14
1Front ring
2Tilt adjustment ring
(optional)
3O-ring (small)
4O-ring (large)
5Tilt adjustment ring
(optional)
6Clamping ring
7CCD camera
8Connector
9Screw 3 mm
0Spring washer
qToothed washer
wBracket base
eBracket
r4 self-tapping
screws for bracket
base fixation

Pin assignment
PIN No. Description
1 + 12 V DC power supply
2 CVBS Video output
3 Not connected
4 Not connected
5 Ground
Application examples
1) Direct connection to Monitor Navigation System with adapter cable
2) Connection to Multimedia System via MI 2200
3

Specifications
Video standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PAL, 625 lines, 50 Hz
Image sensor: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/3 inch CCD
Resolution: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 512 (h) x 582 (v) pixels
Sensitivity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.9 Lux / F 2.0
Viewing angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 ° diagonal
Video output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 V pp Composite Video, 75 Ohms
Supply voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . + 12 V / DC
Power consumption: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 mA max.
Operating temperature range: . . . . . . . . . . . . . . . . . . . . . . . . . - 25° Celsius to + 65° Celsius
Storage temperature range: . . . . . . . . . . . . . . . . . . . . . . . . . . . - 30° Celsius to + 80° Celsius
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 mm x 58 mm (caliber)
30 mm x 58 mm (exterior)
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 g
4
MI RV 5200
01/2006 ri
