Dear customer,
Congratulations on your choice. Thank you for purchasing one of our
appliances. This practical, modern and functional appliance is
manufactured using materials of the highest quality which are subject to
strict Quality Control checks throughout the entire manufacturing process.
The appliance is meticulously tested to ensure that it meets your demands
and produces perfect cooking results.
Do not remove the appliance from its protective packaging until it is
installed in the unit.
Please read these instructions carefully before proceeding to install and
use the appliance. The information contained in these instructions is
essential for the correct operation of the appliance and, more importantly,
for your safety.
The packaging of your appliance has been manufactured using only the
materials which are strictly necessary to guarantee efficient protection
during transport. These materials are 100% recyclable, thus reducing the
environmental impact. You can also contribute to caring for the
environment, by following the advice below:
- dispose of the packaging in the appropriate recycling bin,
- before you get rid of an old appliance, make sure you disable it. Contact
your local authority to find out the address of your nearest recycling centre
to dispose of your appliance.
- do not pour used oil down the sink. Collect it in a sealed container and
take it to an appropriate collection point or, failing that, place it in the
rubbish bin (it will end up in a controlled dump; this is probably not the best
option, but it will avoid contaminating ground water).
IMPORTANT:
In the unlikely event that the appliance should arrive damaged or not meet
your expectations in terms of quality, please inform us as soon as possible.
For the warranty to be valid, the appliance must not have been tampered
with, or used inappropriately.

4
Safety precautions
Read these instructions carefully. Reading these
instructions will enable you to use your appliance
safely and effectively.
Connection of Town Gas rubber tube
-It must be used approved rubber tube bearing EMSD
Approval marking (such as “EMSD Approval
GTXXXX”) and fuse cock for piped gas supply or
regulator for connection.
Connection of stainless steel flexible hose BSP
MALE
-It must be used approved stainless steel flexible hose
BSP MALE bearing EMSD Approval marking (such as
“EMSD Approval GTXXXX”) and approved fuse cock
or gas cock for connection.
HK Town Gas connection
-Governor Beckley 2300 should be installed.
“Under the Gas Safety (Registration of Gas
installers and Gas Contractors) regulations, only
registered gas installers (registered to the
appropriate class) employed by registered gas
contractors can personally carry out gas
installation, regulation and conversion, in
additional, only use the GTXXXX approved flexible
gas tubing for installation. This appliance must not
be converted to another type of gas.”
Please do not use additional fitting, such as aluminium
cover.
The installation engineer has to respect the standards
and the specifications of the gas and electricity
providers.
Before installing your new hob, ensure that it is being
installed according to the assembly instructions.

5
This appliance can only be installed in a well ventilated
place in accordance with existing regulations and
ventilation specifications. The appliance must not be
connected to a combustion product removal device.
This appliance has been designed for home use only.
This appliance cannot be installed on yachts or in
caravans.
The place in which the appliance is installed must
have fully-functioning ventilation, in accordance with
the regulations.
Do not subject the appliance to draughts. These might
blow out the burners.
This appliance leaves the factory set to the type of gas
that is indicated on the specification plate. It must not
be changed to another type of gas.
Do not tamper with the appliance’s interior. If
necessary, call our Technical Assistance Service.
These operating and installation instructions should be
retained, and passed onto the buyer if the appliance is
sold.
Do not switch on the appliance if it is damaged in any
way. Contact our Technical Assistance Service.
The surface of cooking appliances heat up during use.
Care must be taken when using these appliances.
Keep children well away from the appliance.
This appliance is only intended for cooking purposes,
not as a heating system.
Fat or oil which is overheated can catch fire easily. Do
not leave oil or fats to heat up unattended. If oil or fats
do catch fire, never use water to put the fire out. Risk
of burns! Put the fire out by covering the pan with a lid
and switch off the hotplate.
In the event of a malfunction, turn of the appliance’s
gas and electricity supply. For repairs, call our
Technical Assistance Service.

6
If one of the controls will not turn, do not force it. Call
the Technical Assistance Service immediately, so that
they can repair it.
Never place unstable pans on the hob or the burners,
as they may accidentally tip over.
Do not clean the appliance using a steam cleaner.
Risk of electrocution!
This appliance is class 3 type, according to EN 30-1-1
regulation for gas appliances: built-in appliance.
Do not store or use corrosive chemicals, products
which produce fumes, flammable materials or non-
food products below or near this domestic appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Never let children play with the appliance.
The graphics in this instruction manual are given as a
guide only.
The manufacturer is exempt from all responsibility if
the requirements of this manual are not complied with.

7
Your new appliance
Product description: Double-flame burner town gas hob with flame sensor
safety device.
Heat input: 0.2 ÷ 4.4 kW (with town gas G110 at 10 mbar)
0.2 ÷ 5.0 kW (with Hong Kong town gas at 12.5 mbar)
Product dimension: 520 x 302 x 45 mm (D x W x H)
Net weight: 7,0 kg
Operating gas pressure/
outlet pressure of
governor:
10 mbar (town gas G110)
12,5 mbar (Hong Kong town gas)
These individual appliance can be combined and/or with conventional hobs of the
same make, using the joint accessory. See the catalogue for details.
Pan support
Double-flame burner
Control knob

8
The gas burner
Operation
It is essential to ensure that all the burner parts and the
pan supports are correctly installed for the appliance to
work correctly.
Switching on
manually
1. Press the burner control and turn it anticlockwise to
the “large flame”.
2. Use any type of lighter or flame (cigarette lighter,
matches, etc.) and bring it close to the burner.
Switching on
automatically
1. Press the burner control and turn it anticlockwise to
the “large flame”.
While the control is still pressed down, sparks are
produced on the burner. The flame ignites (it is no
longer necessary to press down the control).
2. Turn the control to the required setting.
If it does not come on, turn the control to the off setting
and repeat the steps above. This time, press and hold
the control for longer (up to 10 seconds).
Warning! If after 15 seconds have elapsed, the flame
does not ignite, switch off the burner and open a nearby
window or door. Wait at least one minute before trying
to switch the burner back on.
Safety system
Your hob has a safety system (thermocouple) that
prevents the flow of gas if the burner accidentally
switches off. To ensure that this device is active, switch
on the burner as usual and, without releasing the
control, press and hold it down firmly for 4 seconds after
lighting the flame.

9
Switching off the
burner
Turn the control clockwise to the 0 setting.
Power levels
The progressive controls can be used to control the
power needed, from minimum to maximum power.
For dual double flame burners, the inner and outer
flames can be controlled separately.
The available power levels are as follows:
Inner and outer flame on full power.
Outer flame on minimum, inner flame on full power.
Inner flame on full power.
Inner flame on minimum.
Warnings
It is normal to hear a whistling noise while the burner is
operating.
When it is first used, it is normal for the burner to give
off fumes; this does not pose any risk and does not
indicate a malfunction; they will disappear in time.
A few seconds after switching off the burner, it will
make a sound (thud); this is not a fault – This means
that the safety device is no longer operating.

10
Keep the burner as clean as possible. If the ignition
sparkers are dirty, they will not light properly. Clean
them periodically using a small non-wire brush. Bear in
mind that the ignition sparkers must not suffer any
serious impacts.
An orange-coloured flame is normal. This is caused by
the presence of dust in the atmosphere, split liquids,
etc.
The kitchen will become hot and humid when this gas
appliance is used. You must therefore ensure that the
kitchen is well-ventilated. Either keep the natural
ventilation apertures open, or install an extractor hood.
If using the appliance intensively for prolonged periods
additional ventilation may be required, for example, by
opening a window; more effective ventilation may also
be required, for example, by increasing the hob’s
ventilation, if possible.
If the burner flames are accidentally blown out, switch
off the burner operating control and do not try to relight
it for at least one minute.
Suitable pans
Minimum pan diameter
22 cm
Wok pan
Especially suited to cooking with paella pans, Chinese
woks, pans with a concave base, etc. A wok is cooking
vessel originating in China; it is a kind of deep, round,
lightweight pan with handles and a flat or concave base.
Food can be prepared in various ways in a wok: it can
be stewed, stir fried, cooked on a low heat, pan-fried, or
steamed. It could be said that woks serve as both as a
saucepan and a frying pan and, owing to their shape
and size, they can be used to cook quite large
ingredients.
When cooking with a wok, heat is diffused more
uniformly and gently; the intense heat which
accumulates means that food takes less time to cook
and also requires less oil, making it one of the quickest
and healthiest ways of cooking. Always follow the
manufacturer’s instructions when cooking with a wok.

11
Accessories
The hob includes the following accessories. These are
also available from the Technical Assistance Service.
Additional wok pan
support
Only for use with pans which are more than 26 cm in
diameter (roasting dishes, earthenware pots, etc.) and
with pans with a concave base.
Additional coffee
maker support
Only for use with pans which are no more than 10 cm in
diameter.
The manufacturer accepts no liability if these additional
pan supports are not used or used incorrectly.
Cooking recommendations
Very high High Medium Low
Boiling, steaming, griddling,
toasting, paellas, Asian food
(wok).
Reheating and keeping things
hot: cooked and pre-cooked
dishes.

12
Precautions for use
The following advice is intended to help you save
energy and prevent cookware damage:
Use pans which are the right size for each burner.
Do not use small receptacles on large burners. The
flame should not touch the sides of receptacles.
Do not use damaged cookware, which does not sit
evenly on the hob. Pans may be overturned.
Only use a pan with thick, flat base.
Do not cook without lids or with lids only partially
covering receptacles. You are wasting energy.
Always place the cookware right over the burner, not to
one side. Otherwise it could be overturned.
Place the pans on the pan support, never directly on the
burner.
Pans should be placed on the hob carefully.
Do not strike the hob and do not place excessive weight
on it.
Make sure that the pan support and burner covers are
correctly positioned before using the appliance.
Kg

13
Cleaning and maintenance
Cleaning
Once the appliance is cool, use a sponge to clean it
with soap and water.
After each use, clean the surface of the respective
burner parts once they have cooled down. If any bits
are left (overcooked food, drops of grease etc.),
however few, they will become stuck to the surface and
more difficult to remove later. The holes and grooves
must be clean for the flame to ignite properly. These
should be cleaned using soapy water and scrubbed
using a non-wire brush.
If the pan supports are fitted with rubber rests, ensure
that these are also cleaned. The rests may come loose
and the pan support may scratch the hob.
Always dry the burner and pan supports completely.
Water droplets or damp patches on the hob at the start
of cooking may damage the enamel.
After cleaning and drying the burner, make sure the
burner covers are correctly placed on the burner flame
diffuser.
Unsuitable products
Never slide pans across the glass surface, as you may
scratch it. In addition, try not to drop heavy or sharp
objects on the glass. Never strike any part of the hob.
Don’t use steam cleaners. This could damage the hob.
Never use abrasive products, steel scourers, sharp
implements, knives, etc. to remove bits of hardened
food from the hob.
If your hob is fitted with a glass or aluminium panel,
never use a knife, scraper or similar to clean the point
where it joins the metal.
Do not use knives, scrapers or similar implements to
clean the point where the glass meets the burner trims,
the metal frames or the glass/aluminium panels, if fitted.

14
Maintenance
Always clean off any liquid as soon as it is spilt: you will
save yourself any unnecessary effort.
Grains of sand that may come from cleaning fruits and
vegetables will scratch the glass surface.
Melted sugar, or foods which contain a lot of sugar
which may have spilt, should be cleaned off the hotplate
immediately, using the glass scraper.

15
Faults
Sometimes certain faults detected can be easily
resolved. Before calling the Technical Assistance
Service, bear in mind the following advice:
Fault Possible cause Solution
The general electrical
system is
malfunctioning.
Defective fuse.
The automatic safety
switch has tripped or a
fuse has blown.
Check the fuse in the main fuse box
and change it if it is damaged.
Check the main control panel to see
if the automatic safety switch has
tripped or a fuse has blown.
The automatic ON
function does not
work.
There may be food or
cleaning products stuck
between the ignition
sparker and the burner.
The burner is wet.
The burner covers are not
correctly positioned.
The appliance is either not
earthed, not connected
properly or the earth
connection is fault.
The space between the ignition
sparker and the burner must be
clean.
Dry the burner covers carefully.
Check that the covers are correctly
positioned.
Contact an electrical engineer.
The burner flame is
not uniform.
The burner components
are not correctly
positioned.
The grooves on diffuser
are dirty.
Ensure the components are
correctly positioned
Clean the grooves on the diffuser.
The flow of gas does
not appear normal or
no gas comes out.
The gas mains are turned
off.
If the gas is supplied from
a gas bottle, check that
this is not empty.
Turn on all stop cocks.
Change the gas bottle.
The kitchen smells of
gas.
A gas tap has been left
on.
There may be a leak from
the coupling to the gas
bottle.
Turn off the gas taps.
Check that the coupling is sound.
The safety valve on
the burner is not
working.
The control knob was not
held down for long
enough.
The grooves on the
diffuser are dirty.
Once the burner is lit, hold the
control knob down a few seconds
longer.
Clean the grooves on the diffuser.

16
Technical Assistance Service
When contacting our Technical Assistance Service,
please provide the product number (E-Nr.) and
production number (FD) of the appliance. This
information is given on the specification plate located
on the lower section of the hob.
Warranty conditions
The applicable warranty conditions are those set out
by the company’s representative office in the country
of purchase. Detailed information is available from
retail outlets. Proof of purchase must be presented to
obtain the benefits of the warranty.
We reserve the right to introduce changes.
Used appliances and packaging
If the Ò symbol is shown on the specification plate,
bear in mind the following instructions.
Environmentally-
friendly waste
management
Unpack the appliance and dispose of the packaging by
environmentally-friendly means.
This appliance complies with European Directive
2002/96/CE on Waste Electrical and Electronic
Equipment (WEEE).

17

18

19
Siemens-Electrogeräte GmbH
Carl-Wery-Straße 34
81739 München
1030008 – 08.2010
